SERVICE MANUAL
HARD DISK CAMERA
FILE NO. 400-200604GR
GSC-R60/GSC-R30
CREATED IN JAPAN, March, 2006 S

(*1) GREEN PRODUCT PROCUREMENT
The EC is actively promoting the WEEE & RoHS Directives that define standards for recycling
and reuse of Waste Electrical and Electronic Equipment and for the Restriction of the use of
certain Hazardous Substances. From July 1, 2006, the RoHS Directive will prohibit any marketing
of new products containing the restricted substances.
Increasing attention is given to issues related to the global environmental. Toshiba Corporation
recognizes environmental protection as a key management tasks, and is doing its utmost to
enhance and improve the quality and scope of its environmental activities. In line with this,
Toshiba proactively promotes Green Procurement, and seeks to purchase and use products,
parts and materials that have low environmental impacts.
Green procurement of parts is not only confined to manufacture. The same green parts used in
manufacture must also be used as replacement parts.
(*2) LEAD-FREE SOLDER
This product is manufactured using lead-free solder as a part of a movement within the consumer
products industry at large to be environmentally responsible. Lead-free solder must be used in the
servicing and repair of this product.
WARNING
This product is manufactured using lead free solder.
DO NOT USE LEAD BASED SOLDER TO REPAIR THIS PRODUCT !
The melting temperature of lead-free solder is higher than that of leaded solder by 86°F to 104°F
(30°C to 40°C). Use of a soldering iron designed for lead-based solders to repair product made
with lead-free solder may result in damage to the component and or PCB being soldered. Great
care should be made to ensure high-quality soldering when servicing this product especially
when soldering large components, through-hole pins, and on PCBs as the level of heat required to
melt lead-free solder is high.

Contents
1. Product Outline............................3
1-1. Appearance Monaural..............................3
1-2. Photography Mode...................................4
1-2-1. OSD..............................................................4
1-2-2. Main key operations......................................5
1-3. Playback Mode.........................................6
1-3-1.OSD...............................................................6
1-3-2. Main key operation........................................7
1-3-3. Video Playback with Tricks............................8
1-4. USB Mode................................................9
1-5. LAN Mode...............................................10
2. Mechanical Parts........................11
2-1. Explode Diagram....................................11
2-2. Camera Part List.....................................13
2-3. Screw List...............................................19
3. System Overview.......................20
3-1. System Block Diagram...........................20
3-2. Composition............................................21
3-2-1. Camera.......................................................21
3-2-2. Cradle.........................................................22
3-3. Operation................................................23
3-3-1. Start-Up Operation......................................23
3-3-2. Power-Off Operation...................................23
3-3-3. Photography Mode (Movie).........................23
3-3-4. Photography Mode (Still image)..................23
3-3-5. Playback Mode (Movie)...............................23
3-3-6. Playback Mode (Still Image)........................23
3-3-7. USB Communication...................................23
3-3-8. LAN Communication...................................24
3-3-9. Flash Operation..........................................24
3-3-10. Battery Charge Operation.........................24
3-3-11. Irregular Mode Detect Line........................24
4. Troubleshooting.........................25
5. Disassembly / Assembly............27
5-1. Disassembly............................................27
5-2. Assembly................................................34
6. Adjustment.................................41
6-1. Items to adjust........................................41
6-2. Devise to Use.........................................41
6-3. Adjustment Procedure............................42
6-3-1. CCD2CH Adjustment (CCD2CH)................42
6-3-2. CCD Sensitivity (SENSITIVE).....................43
6-3-3. IRIS/ND.......................................................44
6-3-4. Shutter.........................................................45
6-3-5. CCD Defect Pixel........................................46
6-3-6. White Balance.............................................47
6-3-7. Zoom/Focus................................................48
6-3-8. HDD Format Procedure..............................49
6-3-9. Procedure to Update the Firmware.............50
6-3-10. Procedure for Factory Setting...................52
7. Packing Parts.............................53
7-1. Packing Explode Diagram......................53
7-2. Packing Part List.....................................54
8. Specifications.............................55
9. Service Parts List.......................56
2

1. Product Outline
Microphone
Stereo Speaker Monaural
1-1. Appearance
Still REC button
Zoom lever
Also use for level change
at playback.
Lens
10x o
p
tical zoom
Auxiliary light
2 LED lam
p
s
Flash
Gri
p
belt
Backlight adjustment button
Auxiliary light button STATUS LED MEDIA LED
Terminal cover
DC IN 10V terminal
A/V OUT terminal
Video REC button
Jog dial
OK button
MENU button
LCD monito
r
POWER switch
SD slot
Mode LED
Mode leve
r
3

1-2. Photography Mode
1-2-1. OSD
Enter the photography mode by sliding mode lever to the photography side.
213
6
4115
12
13 14
16
7
9
10
24
8
23
20
17 18 19
21 22
15
1 Battery level gauge
2 Indicator - Videos
3 Time remained for video shooting
4 Indicator – still images
5 Number of still images can be taken
6 Zoom bar
7 Focus
8 Scene
9 Flash
10 Exposure adjustment
11 Self-timer
12 White balance
13 ISO sensitivity
14 Photometry mode
15 Camera shake adjustment
16 Video quality
17 Wind noise reduction
18 Still image size
19 Still image quality
20 Continuous shooting
21 Media
22 Album
23 Date and time
24 Focus area
4

1-2-2. Main key operations
Focus setting Video REC start
Zoom
MENU
Zoom Video
REC
OK up
OK Right
Press
OK
OK left
Still REC
Half push
OK
down
Flash setting Exposure bias setting
AF/AE lock OSD details display
Recording menu Scene setting
5

1-3. Playback Mode
1-3-1.OSD
Enter the playback mode by sliding mode lever to the playback side.
1465 9 2
78
11
24 5 6
12 10 3
Video
1
7 8
3
Still image
12
1 Playback mode
2 Battery level gauge
3 Recoding date and time
4 Drive
5 Album
6 File number
7 Previous image
8 Next image
9 Playback mode
10 Video icon
11 Video record time
12 Guide
6

1-3-2. Main key operation
Chapter selection Zooming playback
OK押
No OSD indication
TT
Press
OK
Press
OK
OK up
OK left
or
JOG left
OK right
or
JOG right
Display previous
Display next
Video playback Information display
OK down OK down
W W
Thumbnail display
W
W
MENU
MENU
Video playback method Rotation display
Play menu Album display Drive display
7

1-3-3. Video Playback with Tricks
8
Pla
y
back
UPDOWN
Pause
UP
Rewindin
g
Frame rewind
Fast Forward
Frame
p
la
y
back
JOG-RJOG-L
JOG-L
/
UP
JOG-R/U
DOWN
DOWN
High-speed
rewinding High-speed
Fast Forward
JOG-RJOG-L
DOWN
JOG-RJOG-L
RIGHTLEFT
Ke
y
Sto
p
video
p
la
y
back
－
－
－
Volume u
p
Volume down
Video
p
la
y
back with zoomin
g
(
MENU -> T/W for zoomin
g)
Sto
p
One-touch re
p
la
y
(
1/20
)
One-touch ski
p
(
1/20
)
To
gg
le for OSD dis
p
la
y
/ no OSD dis
p
la
y
RIGHT(EXP.)
MODE-R
MODE-P
M-REC
H-SHUTTER
F-SHUTTER
T
W
MENU
UP(FOCUS)
DOWN(SCENE)
LEFT(FLASH)
OK
JOG-L
JOG-R
To
p
hoto
g
ra
p
h
y
mode
Rewindin
g
(
3x
)
F. Forward
(
3x
)
Pla
y
back Pause F. Forward
(
3x
)
F. Forward
(
15x
)
Pause Pla
y
back
－
－
Rewindin
g
(
3x
)
Rewindin
g
(
15x
)
Frame rewind
Frame
p
la
y
back Pla
y
back
F. Forward
(
15x
)
F. Forward
(
3x
)
F. Forward
(
30x
)
F. Forward
(
15x
)
Pla
y
back Rewindin
g
(
30x
)
Rewindin
g
(
3x
)
Create still image
－

1-4. USB Mode
The USB mode becomes available by following two procedures below.
1) Connect the AC adaptor to the cradle, and connect PC to the cradle with a USB cable. Set the camera on
the cradle, and then press the USB button located on the cradle.
2) Attach the connection adapter to the camera. Turn on the power while PC is connected to the connection
adapter.
When PC is connected under the USB mode, the indication of either [HIGH SPEED MODE] or [FULL SPEED
MODE] will be displayed on the LCD monitor. Since the camera is in the protection state during the FULL
SPEED connection, writing from PC to the camera will be prohibited.
The arrow direction changes as well.
Connection status is displayed.
HIGH SPEED FULL SPEED
9

1-5. LAN Mode
Connect the AC adapter to the cradle then connect the cradle via a LAN cable to the RD that has "Dubbing
through network" function. The LAN mode becomes available by pressing the LAN button on the cradle.
Connection completed
Press OK
10

2. Mechanical Parts
2-1. Explode Diagram
GSC-R60
11

GSC-R30
12

Part Cord Part Name Qty Purchase Code
AA01 Main Cover
ASSY 1 P000461920
P000462420
(GSC-R60)
P000462300
(GSC-R30)
AA06 Top Cover
ASSY 1 P000461930
AA11 Lens Cover
ASSY 1 P000461940
AA08 Back Cover
ASSY 1 P000461950
AA05 Zoom Cover
ASSY 1 P000461960
AA14 Sensor Cover
ASSY 1 P000461970
Mechanical Parts
2-2. Camera Part List
1
Left Cover
ASSY
AA02
13

Part Cord Part Name Qty Purchase Code
AC11 Battery Case
ASSY 1 P000461980
A110 Screw Cap 1 P000461990
A306 Lens Cushion 4 P000462000
P000462450
(GSC-R60)
P000462330
(GSC-R30)
A706 SN Label 1 P000462010
P000462430
(GSC-R30)
P000462310
(GSC-R30)
for GSC-R60 4 P000462440
for GSC-R30 2 P000462320
A358 Protection Gel
A316 Protection
Rubber 2
A703 Rating Label 1
14

Part Cord Part Name Qty Purchase Code
A320 Speaker
Cushion 1 P000462020
A355 Shield Gasket
A1 P000462030
A356 Shield Gasket
B1 P000462040
AC15 HDD Case
ASSY 1 Not Service Part
AC40 HDD Cover
ASSY 1 Not Service Part
A305 Lens Holder 1 Not Service Part
AC12 Flash Plate
ASSY 1 Not Service Part
A152 Microphone
Plate 1 Not Service Part
15

Part Cord Part Name Qty Purchase Code
A313 LCD Plate 1 Not Service Part
A346 Thermal Sheet
A1 Not Service Part
A347 Thermal Sheet
B2 Not Service Part
A349 EMI Sheet A 1 Not Service Part
A350 EMI Sheet B 1 Not Service Part
A351 EMI Sheet C 1 Not Service Part
A900 Screw Kit 1 P000462050
HA52 Lens Module
ASSY 1 P000462060
Module
16

Part Cord Part Name Qty Purchase Code
HA54 LCD ASSY 1 P000462070
P000462460
(GSC-R30)
P000462340
(GSC-R30)
HA56 Microphone
ASSY 1 P000462080
HA55 Speaker ASSY 1 P000462090
W999 FLASH-MAIN
FPC 1 P000462170
U001 MAIN PCB
ASSY 1 P000462100
UA51 FLASH PCB
ASSY 1 P000462110
UA02 JACK PCB
ASSY 1 P000462120
PCB Assembly
HA5A HDD ASSY 1
17

Part Cord Part Name Qty Purchase Code
U006 SENSOR PCB
ASSY 1 P000462130
UA11 TERMINAL
PCB ASSY 1 P000462140
U008 3-WAY FPC
ASSY 1 P000462150
UA09 LENS-MAIN
FPC ASSY 1 P000462160
18

2-3. Screw List
Details of the "Screw Kit" (A900) TOTAL : 39 screws
No. Part Code Specification Head D Head T Plating Positon used Qty
1 A324 M1.4x2.0 M 2.5 0.5 Ni(Silver) Top Cover ASSY (AA06) --- Flash Plate ASSY (AC12) 1 4
FLASH PCB ASSY (UA51) --- Flash Plate ASSY (AC12) 1
JACK PCB ASSY (UA02) --- Flash Plate ASSY (AC12) 2
2 A325 M1.7x2.0 M 3 0.5 Ni(Silver) Battery Case ASSY (AC11) --- Main Cover ASSY (AA01) 1 2
TERMINAL PCB ASSY (UA11) --- Main Cover ASSY (AA01) 1
3 A326 M1.7x2.5 M 3 0.5 Ni(Silver) Main Cover ASSY (AA01) --- Left Cover ASSY (AA02) 1 11
Back Cover ASSY (AA08) --- Flash Plate ASSY (AC12) 1
Zoom Cover ASSY (AA05) --- HDD Case ASSY (AC15) 1
Zoom Cover ASSY (AA05) --- Flash Plate ASSY (AC12) 1
Microphone Plate (A152) --- Flash Plate ASSY (AC12) 3
MAIN PCB ASSY (U001) --- Main Cover ASSY (AA01) 1
MAIN PCB ASSY (U001) --- Battery Case ASSY (AC11) 3
4 A327 M1.7x3.0 M 3 0.5 Ni(Silver) TERMINAL PCB ASSY (UA11) --- Main Cover ASSY (AA01) 2 2
5 A330 M1.7x3.5 M 3 0.5 Ni(Silver) Lens Cover ASSY (AA11) --- Flash Plate ASSY (AC12) 1 1
6 A328 M1.7x4.0 M 3 0.5 Ni(Silver) Left Cover ASSY (AA02) --- HDD Case ASSY (AC15) 2 5
Left Cover ASSY (AA02) --- Flash Plate ASSY (AC12) 1
LCD Plate (A313) --- LCD ASSY (HA54) 2
7 A331 Φ1.7x3.0 Tapping 3 0.5 Ni(Silver) Main Cover ASSY (AA01) --- Lens Holder (A305) 1 6
Lens Cover ASSY (AA11) --- Main Cover ASSY (AA01) 1
Microphone Plate (A152) --- Main Cover ASSY (AA01) 1
SENSOR PCB ASSY (U006) --- Battery Case ASSY (AC11) 1
Main Cover ASSY (AA01) --- Back Cover ASSY (AA08) 2
8 A332 Φ1.7x4.0 Tapping 3 0.5 Ni(Silver) Left Cover ASSY (AA02) --- Back Cover ASSY (AA08) 1 8
Battery Case ASSY (AC11) --- Main Cover ASSY (AA01) 4
HDD Case ASSY (AC15) --- Main Cover ASSY (AA01) 2
Lens Holder (A305) --- Main Cover ASSY (AA01) 1
19
