User’s Manual
CAMILEO X450

Introduction
Welcome and thank you for choosing a TOSHIBA product.
For your convenience, your TOSHIBA product is furnished with two guides:
a) a Quick Start Guide, and
b) this comprehensive PDF User’s Manual.

Contents
Section 1 Getting to Know Your Camcorder .................................... 6
Overview ............................................................................. 6
Check the Components..................................................... 6
Safety Instructions............................................................. 7
System Requirements ....................................................... 7
Front View........................................................................... 8
Side View/Rear View .......................................................... 8
Bottom View ....................................................................... 9
Section 2 Getting Started ................................................................. 10
About the battery pack .................................................... 10
Loading the Battery ......................................................... 10
Inserting and Removing an SD Card (Optional)............ 11
Turning the Camcorder On and Getting Started ........... 11
Turning the Camcorder Off ............................................. 11
Section 3 Record Mode .................................................................... 12
Button Function ............................................................... 12
LCD Monitor Information................................................. 13
Video Recording............................................................... 16
Photo Recording .............................................................. 16
Using Zoom Function ...................................................... 16
Using Advanced Zoom Function ................................... 17
Options for Menu ............................................................. 17
Operations ....................................................................... 18
Video Setting .................................................................... 18
Photo Setting.................................................................... 22
Effects ............................................................................... 25

Contents
Section 4 Playback Mode ................................................................. 28
Button Function ............................................................... 28
LCD Monitor Information................................................. 29
Operations for Playback Mode ....................................... 30
Video Playback................................................................. 30
Video Trim......................................................................... 31
Photo Playback ................................................................ 31
Delete File in Playback Mode.......................................... 32
Section 5 Setting Your Camcorder ................................................. 33
Setup Menu....................................................................... 33
Section 6 Viewing Photos and Videos on TV ................................. 37
Connecting to a High-Denition 16:9 (Wide) TV ........... 37
Section 7 Viewing Video & Photo on PC......................................... 38
Installing Bundled Software............................................ 38
Transferring Photos or Videos to a Computer .............. 38
Section 8 Uploading Files to Internet.............................................. 39
Section 9 Specications .................................................................. 42
Section 10 Troubleshooting............................................................... 43

5
EN
Contents
Section 11 Other Information............................................................. 44
TOSHIBA Support ............................................................ 44
Operating Environment Conditions ............................... 44
Regulatory Information.................................................... 44
Additional Information..................................................... 46

6
EN
Section 1
Getting to Know Your Camcorder
Overview
The camcorder with 8 Mega Pixel sensor can take H.264 videos. By way of using H.264 technology,
more videos can be taken within certain amount of memory. High quality images with up to 16 mega-
pixels can also be delivered smoothly. With a color LCD monitor, users can compose images and
examine them easily.
The camcorder features 3” LCD touch panel which is an ideal platform for you to operate your
camcorder. The menu options are accessible with your nger. With the touch panel, you can select the
options directly and quickly.
The camcorder also features video recording at Full HD resolution of 1920x1080. You can also
connect it to an HDTV via an HDMI cable, and easily playback the recorded high-denition videos on
the wide screen HDTV.
Moreover, the camcorder has an advanced uploading feature. With the exclusive built-in CAMILEO
UPLOADER application, you can upload the videos or photos captured by the camcorder to Internet
more effortlessly.
ISO sensitivity and color balance can either be adjusted automatically or changed manually. 60X
digital zoom helps you to control over the videos and photos you take.
The varied effect options, such as Time Lapse and Slow Motion, make recording more fun.
The built-in memory allows you to take photos and to record videos without a memory card. The
memory card slot allows users to increase the storage capacity.
Note
• Partialmemoryofthebuilt-inmemoryisusedforthecamcorder’sFirmwarecode.
• InstallthebundledsoftwareapplicationforviewingthevideoscorrectlyonaPC.
Check the Components
Unpack the package and make sure all standard accessories listed are included:
Note
• Pleaseremovethelensprotectlmonlensbeforeuse.
Camcorder HDMI Cable
USB Cable AC-Adaptor
Quick Start
Guide
MAGIX DVD
(Video Deluxe Trial
Version)
Cleaning
Cloth
CD-ROM
(Software, User’s
Manual)
Lithium-ion
Rechargeable
Battery
Warranty
Leaet
Wrist strap Lens Cover Set
with Strap
Pouch

7
EN
Safety Instructions
1. Do not drop, puncture or disassemble the camcorder; otherwise the warranty will be voided.
2. Avoid all contact with water, and dry hands before using.
3. Do not expose the camcorder to high temperature or leave it in direct sunlight. Doing so may
damage the camcorder.
4. Use the camcorder with care. Avoid pressing hard on the camcorder body.
5. For your own safety, avoid using the camcorder when there is a storm or lightning.
6. Do not use batteries of different specications. Doing so may lead to the potential for serious
damage.
7. Remove the battery during long periods between usage, as a deteriorated battery may affect the
functionality of the camcorder.
8. Remove the battery if it shows signs of leaking or distortion.
9. Use only the accessories supplied by the manufacturer.
10. Keep the camcorder out of the reach of infants.
11. Risk of explosion if battery is replaced by an incorrect type.
12. Dispose of used batteries according to the instructions.
System Requirements
• Microsoft®Windows®XP, Vista®, Windows®7, Windows 8
• Intel®Core™ 2 Duo CPU or higher
• 1 GB RAM
• CD-ROM Drive
• 1 GB free HDD space
• Available USB port
• 16-bit Color Display
Note
TheLCDscreenismanufacturedusingextremelyhigh-precisiontechnology.However,some
tinyblackand/orbrightdots(white,red,blueorgreen)mayappearontheLCDscreen.These
dotsareanormalresultofthemanufacturingprocess,anddonotaffecttherecording.

8
EN
Front View
Side View/Rear View
[Tele/Wide] Button
[Photo] Button
Light
External Lens Mount
Lens
Microphone
Speaker
[Power] Button
Mini-USB Port
[Digital Light] Button
[Record] Button
Mini-HDMI Port
[Pause] ButtonLCD Touch Panel

9
EN
Bottom View
SD Card Cover Tripod Socket

10
EN
Section 2
Getting Started
About the battery pack
• Use only batteries recommended by TOSHIBA as replacements. The battery pack is lithium ion
batteries, which can explode if not replaced, used, handled or disposed of properly. Dispose of the
battery as required by local ordinances or regulations.
• Charge the battery pack only in an ambient temperature between 5 and 35 degrees Celsius.
Otherwise, the electrolyte solution might leak, battery pack performance might deteriorate and the
battery life might be shortened.
• Never install or remove the battery pack without rst turning off the power and disconnecting the
AC adaptor.
• Use only the product connected to an AC power source. Never attempt to charge the battery pack
with any other charger.
Loading the Battery
Before using the camcorder, users must load the Lithium-ion rechargeable battery come within the
package.
1. Insert the battery according to the correct polarity marks ( + or -).
2. Close the battery cover rmly.
Note
Pleasetakeoutthebatteryfromthecamcorderandremovetheinsulatoronthebattery
connectionbeforeuse.
REMOVE

11
EN
Inserting and Removing an SD Card (Optional)
The camcorder comes with an internal memory which allows you to store photos and videos. You can
expand the memory capacity by using an optional SD memory card.
1. Insert the memory card into the slot. Please refer to the gure on the right side.
2. To remove an installed SD card, press the card inwards to release it.
3. When the card pops out, gently remove it from its slot.
4. Recommended memory capacity: 1GB or above.
Note
• Whenamemorycardistted,videos/photosaresavedonthecardratherthanonthebuilt-in
memory.
• ProtectingDataonanSDCard:SDCardisread-onlywhenit
islocked.NophotosorvideoscanberecordedwhentheSD
cardislocked.Makesurethelockisonthewriteableposition
beforerecordinganymedia.
Turning the Camcorder On and Getting Started
• To turn on the camcorder:
1. Flip out the LCD panel; the camcorder will turn on automatically.
2. Or press [Power Button] for one second to turn it on.
• To record video: Touch (on-screen icon) to switch to the Video Record mode . Press
Record Button to record video. To stop recording, press it again.
• To pause recording:
1. Touch the screen to pause recording. To continue the recording, touch it again.
2. Or press [Pause Button] to pause recording.
• To snapshot during recording: Touch to take photo while recording.
• To take a photo: Touch (on-screen icon) to switch to Photo Record mode. Press Record
Button to capture photo.
• To view stored videos and photos: Touch (on-screen icon) to switch to the Playback mode.
Turning the Camcorder Off
• To turn off the camcorder: You can either press [Power Button] for one second, or you can place
the LCD panel back to its original position.
Writeable
position
Writeable-Protected
position

12
EN
Section 3
Record Mode
Button Function
Record Button:
1. In Video Record Mode, press to take video. To stop recording, press it
again.
Light Button:
1. Press to get 3 light mode: Light on / Light off / Digital light sequentially.
Pause Button:
1. Press to pause the recording. To continue , press it again.
Photo Button:
1. Press halfway down to focus, then press fully to take photo.
2. When recording video, press to capture the image.
Tele Button:
1. Zoom In.
Wide Button:
1. Zoom out.
Power Button:
1. Press down for one second to turn on or turn off the camcorder.

13
EN
LCD Monitor Information
The indicators shown below may display on LCD when videos and photos are recorded:
On-screen information icon On-screen touchable function icon
1
6
6
1
5
3
39
4
2
15
8 9 710
11
11
12
13
12
14
13 14
16917
(1)
Battery: full power
Battery: more than medium power
Battery: medium power
Battery: less than medium power
Battery: low power
DC power mode
(2)
00:02:23 Recording time
00:02:23 Pause recording
(3)
234 The amount of photos that can still be taken at current
resolution
00:02:23 The time of videos that can still be taken at current
resolution

14
EN
(4)
Light mode set
Resolution set
Stabilization on
Self-Timer on
Smile Detection on
1600
3200
6400
ISO set
Macro Mode set
Exposure set
Scene mode set
Filter mode set
White Balance mode set
Anti-Glare on
(5)
Light mode set
Resolution set
Motion Detect on
Face Tracking on
Slow Motion on
Pre-Record on
Time Lapse on
Macro Mode set
Exposure set
Scene mode set
Filter mode set
White Balance mode set
Anti-Glare on
(6)
Zoom meter:
1X ~ 1380X (23X optical zoom and 60x digital zoom)
1X ~ 1800X (30X advanced zoom and 60x digital zoom)

15
EN
(7) Self-Timer on/off
(8)
Digital Light On
Light On
Light Off
(9)
Video Resolution
FHD Full HD (30fps)
HD+ HD60 (60fps)
HD HD30 (30fps)
WVGA WVGA (30 fps )
Photo Resolution
16MP High-16M
8MP Standard-8M
3MP Low-3M
(10)
ISO Auto
ISO 800
1600
ISO 1600
3200
ISO 3200
6400
ISO 6400
(11) Menu icon
(12) Playback Mode icon
(13) Photo Mode icon
(14) Video Mode icon
(15) Face Tracking on/off
(16) Anti-Glare on/off
(17) Advanced zoom on/off
Note
• Taponthescreentoclosethetouchableinformationlayer.Tapagaintoshowitagain.
• Stabilization,TimeLapse,andSlowMotionfunctionscannotbeusedsimultaneously.
• Pre-Record,MotionDetection,TimeLapse,andSlowMotionfunctionscannotbeused
simultaneously.
• MotionDetect,TimeLapse,SlowMotion,andPausefunctionscannotbeused
simultaneously
• IfonefeatureissettoON,theotherfeatureswillautomaticallysettoOFFbythermware.

16
EN
Video Recording
• In Video Record Mode, press [Record Button] to start recording. When a video is being recorded, a
time indicator will display on the LCD monitor. To stop recording, press [Record Button] again.
• To pause recording: Touch screen to pause recording. To continue the recording, touch it again.
• To snapshot photo during video recording, touch the photo icon to capture the image.
• Touch (on-screen icon) to view the recorded video.
• Four resolution settings are available:
Video Quality
FHD Full HD: 1920x1080 (30fps)
HD+ HD60: 1280x720p (60fps)
HD HD30: 1280x720p (30fps)
WVGA WVGA: 848x480 (30fps)
Photo Recording
• In Photo Record Mode, press [Record Button] to take photo.
• Touch (on-screen icon) to view the photo.
• Three resolution settings are available:
Image Quality
High-16 Mega Pixels 4608 x 3456
Standard-8 Mega Pixels 3264 x 2448
Low-3 Mega Pixels 2048 x 1536
Using Zoom Function
The zoom magnies images when recording videos or taking photos.
1. To zoom in/out, press the Tele/Wide Button. The camcorder will zoom in by optical zoom rst.
When the optical zoom factor is at maximum, zooming stops temporarily. When you want to zoom
in beyond the optical zoom range, hold the Tele button again, the digital zoom will be activated and
zooming continues.
2. It can be set from 1X ~ 1380X ( 23X optical zoom and 60X digital zoom )

17
EN
Using Advanced Zoom Function
• In addition to the 23X optical zoom range, the advanced sensor transforms the 23X optical zoom
into the higher advanced zoom. The advanced zoom obtains a larger zoom range without any
deterioration of the video quality. Once the advanced zoom is activated, you can record the farther
subjects by zooming in.
1. When you are going to record video, touch the on screen icon to activate advanced zoom.
Advanced Zoom Function
The magnication is approximately 1.33 times and the lens is enhanced to be
30X advanced zoom.
When recording video, press the Tele/Wide Button and it can be set from
1X~1380X (23X advanced zoom and 60X Digital zoom)
1X~1800X (30X advanced zoom and 60x digital zoom)
Normal 23X Optical Zoom Advanced Zoom
Note
• Theadvancedzoomisonlyavailableforvideorecording.
Options for Menu
Video Setting Photo Setting Effects Setup*
• Resolution
• Light
• Face Tracking
• Motion Detect
• Slow Motion
• Time Lapse
• Pre-Record
• Stabilization
• Resolution
• Light
• Slideshow
• Smile Detection
• ISO
• Self-Timer
• Date Printing
• Macro Mode
• Exposure
• Scene
• Filter
• White Balance
• Sound
• TV Format
• Language
• Date & Time
• Format
• Anti-Glare
• Default Setting
*PleaserefertoSection5forthedetailedinformationabout[Setup].

18
EN
Operations
Operation Screen
1. Touch on the screen. The main menu will
show on the screen.
2. The options are Video Settings, Photo Settings,
Effects, and Camera Settings.
3. Swipe to get all menu options on the screen.
4. Touch to select the specic option you want to adjust
to enter its setting menu.
5. Select required option to validate the setting.
6. Or touch the Exit icon ( ) to exit.
Video Setting
Operation Display Screen
1. Touch on the screen. The main menu will
show on the screen.
2. Touch the [Video Setting ] icon on the screen
to enter its setting menu.
3. The Video Setting menu contains 7 options--
Resolution, Light, Face Tracking, Motion Detect,
Slow Motion, Time Lapse, Pre-Record--for you to
adjust the camcorder settings.

19
EN
Resolution
Four resolution settings are available.
Full HD Record videos at 1920x1080p 30 resolution.
HD+ Record videos at 1280x720p 60 resolution.
HD Record videos at 1280x720p 30 resolution.
WVGA Record videos at 848x480p 30 resolution.
Operation Display Screen
1. In the Video Setting menu, nd the [Resolution] on
the screen.
2. Touch arrow to select the desired option.
3. Touch the Exit icon ( ) to exit.
Light
You can select the mode to brighten the area or to extend the brightness of the objects.
ON The light will be turned on and provides light when recording.
OFF The light is turned off.
DIGITAL LIGHT Extend the dynamic range for backlight and high contrast sense, so that the
objects will be brighter and clearer.
Operation Display Screen
1. In the Video Setting menu, nd the [Light] on the
screen.
2. Touch arrow to select the desired option.
3. Touch the Exit icon ( ) to exit.
4. Or press the [Light Button] to get 3 options
sequentially.

20
EN
Face Tracking
The camera can detect up to 6 human face (s) and focus on the face (s) automatically.
Operation Display Screen
1. In the Video Setting menu, nd the [Face Tracking].
2. Touch arrow to select the desired option.
3. Or touch the Exit icon ( ) to exit.
Motion Detection
Record videos automatically when the camcorder detects a movement.
Operation Display Screen
1. In the Video Setting menu, nd the [Motion Detect]
on the screen.
2. Touch arrow to select the desired option.
3. Touch the Exit icon ( ) to exit.
4. Camcorder will start to record video automatically if
it detects a movement. Stop recording if it does not
detect a movement.
Slow Motion
Record videos with slow motion effect. When the video is played, the playback time will be longer than
the actual recording time.
Operation Display Screen
1. In the Video Setting menu, nd the [Slow Motion].
2. Touch arrow to select the desired option.
3. Or touch the Exit icon ( ) to exit.
