CAMILEO™ S30
Quick Start Guide

Introduction
2
Introduction
For more detailed information please refer to the User's Guide on the
included CD.
Safety instructions
1Do not drop, puncture or disassemble the camcorder; otherwise the
warranty will be voided.
2Avoid all contact with water, and dry hands before using.
3Do not expose the camcorder to high temperature or leave it in direct
sunlight. Doing so may damage the camcorder.
4Use the camcorder with care. Avoid pressing hard on the camcorder body.
5For your own safety, avoid using the camcorder when there is a storm
or lightning.
6Do not use batteries of different specifications. Doing so may lead to
the potential for serious damage.
7Remove the battery during long periods between usages, as a
deteriorated battery may affect the functionality of the camcorder.
8Remove the battery if it shows signs of leaking or distortion.
9Use only the accessories supplied by the manufacturer.
10 Keep the camcorder out of the reach of infants.
11 Risk of explosion if battery is replaced by an incorrect type.
12 Dispose of used batteries according to the instructions.
About the battery pack
❖Use only batteries recommended by TOSHIBA as replacements. The
battery pack is lithium ion batteries, which can explode if not
replaced, used, handled or disposed of properly. Dispose of the
battery as required by local ordinances or regulations.
❖Charge the battery pack only in an ambient temperature between 5
and 35 degrees Celsius. Otherwise, the electrolyte solution might
leak, battery pack performance might deteriorate and the battery life
might be shortened.
❖Never install or remove the battery pack without first turning off the
power and disconnecting the AC adaptor.
❖Only use the supplied AC adaptor or USB cable, or an optional
Toshiba battery charger to charge the battery pack. Never attempt to
charge the battery pack with any other charger.

Safety instructions 3
Handling the cord on this product will expose you to lead, a chemical
known to the State of California to cause birth defects or other
reproductive harm. Wash hands after handling.
Regulatory Information
TOSHIBA declares that this product conforms to the following Standards:
Following information is only valid for EU-member States:
Disposal of products
This symbol indicates that this product must not be disposed of with
normal household waste. The product must be disposed of separately.
FCC Conditions
This equipment has been tested and found to comply with Part
15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
CE compliance
This product is CE marked in accordance with the
requirements of the applicable EU Directives. Responsible for
CE marking is Toshiba Europe GmbH, Hammfelddamm 8,
41460 Neuss, Germany. A copy of the official Declaration of
Conformity can be obtained from following website:
http://epps.toshiba-teg.com.

Safety instructions
4
Contact
Trademarks
Adobe is either a registered trademark or trademark of Adobe Systems
Incorporated in the United States and/or other countries.
ArcSoft and MediaImpression are registered trademarks of ArcSoft, Inc.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC.
Secure Digital and SD are trademarks of SD Card Association.
All other brand and product names are trademarks or registered
trademarks of their respective companies.
Address: TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Telephone: [phone]

Getting Started 5
Getting Started
The battery comes pre-installed in the camcorder, however you must
remove the protective film on the battery before use.
To properly connect the battery:
1Flip open the LCD touch screen and slide the battery cover off.
2Remove the battery.
3Pull off the protective film.
4Reinsert the battery, making sure it is lined-up with the correct
polarity marks.
5Close the battery cover.
Protective film
Li-ion battery
Polarity marks
Li-ion battery
Battery cover

Getting Started
6
To insert the SD™ Card (optional):
1Open the SD™ Card cover.
2Insert the SD™ Card into the slot until it locks into place, as shown
below.
3Once inserted, close the SD™ Card cover.
Charging the battery
You must use the supplied AC adaptor or the USB cable to charge your
camcorder before use. Turn off the camcorder. A blinking light will
indicate active charging and a solid light indicates that charging is
complete. In AC charging mode, the light will turn off automatically after
5 minutes.
SD™ Card
SD™ Card cover
To remove the SD™ Card press
inward to release it. When the
card pops out, grasp it and pull
it straight out.

Quick Tour 7
Quick Tour
1 Flip to power on
Flip out the LCD touch screen or
hold the Power ( ....) button for
To conserve battery power, the
camcorder will turn off automatically
after 3 minutes of non-operation.
2 To start or stop recording videos
Press the Mode (.......) button or touch
the onscreen (....) icon to switch to
NOTE: The Video Record (......)
indicator light will glow.
Press the Record (......) button.
Press the Pause (.....) button.
3 To pause recording
4 To take photos
Press the Mode (.......) button or touch
the onscreen (....) icon to switch to
NOTE: The Photo mode (......)
indicator light will glow.
Press the Record (......) button.
5 To zoom in and out
Press T/W
6 To review videos/photos
Touch the onscreen (....) icon to access
7 To operate more advanced options
Touch the onscreen (.....) icon to
Touch the screen to view the main menu.
2 4
3
7
5
6
1
Record and Play
one second.
Video Record mode.
Photo Record mode.
the playback mode.
For more detailed operational instruction, please refer to the User’s Manual.
2 4
access the option menu.
Touch the screen to view the main menu.

Quick Tour
8
Front/Side
Switch between Macro
SD™ Card cover
Macro switch
Lens
NOTE: Remove the
Microphone
LED light
Power
Speaker
Battery
Mode button
Switch between Video mode and
Photo mode.
mode and Normal
protective film from
the lens before use.
Internet upload button
In Playback mode, press to select the file
you wish to upload to a Web site.
When the camcorder is connected to the
computer, press to launch the CAMILEO
Uploader application automatically.
button
cover
mode.
Mini tripod
Underside
Hand strap hook
socket

Quick Tour 9
Video mode indicator light
Tele (Up) button
Wide (Down) button
TV port
Rear
Record button
In Video Record mode, press to
Press to pause recording.
Pause button
Mini USB 2.0 port
Hand strap hook
Photo mode indicator light
HDMI™ port
Zoom out and Volume decrease.
record a video, press again to stop.
In Photo Record mode, press to take
photos.
Press it again, to continue recording.
Zoom in and Volume increase.
LED light button

Quick Tour
10
Onscreen hot key function
Touch the icon once to view the description, touch twice to
activate.
Video record mode (the camcorder icon is highlighted)
Stabilization ON when the icon is highlighted, OFF when not
highlighted.
Touch to open the Video Resolution menu. Four resolution settings are
available.
Touch to open the Light settings menu.
ON: The light turns ON and provides illumination while recording.
OFF: The light turns OFF.
Digital light: Extend the dynamic range for backlight and high contrast,
so that objects are brighter and clearer.
Photo Record mode (the camera icon is highlighted)
Self-timer ON and OFF.
Touch to open the Photo Resolution menu. Three resolution settings are
available.
Touch to open the Light settings menu.
ON: The light turns ON and provides illumination while recording.
OFF: The light turns OFF.
Digital light: Extend the dynamic range for backlight and high contrast,
so that objects are brighter and clearer.
Video/photo playback mode (after touching the playback ()icon in Preview mode.
Touch to open the Options menu.
Touch to display the SELECT & PLAY thumbnail screen.
Continuous play ON or OFF (Video playback mode only).
Slideshow ON or OFF (Photo playback mode only).

Quick Tour 11
Main Menu
Touch the Options ( ) icon
Video Settings
Light
ON The light turns ON and provides illumination while recording.
OFF The light turns OFF.
Digital light Extend the dynamic range for backlight and high contrast, so that
objects are brighter and clearer.
Resolution
Full HD 1920 x 1080p (30fps)
HD 60 1280 x 720p (60fps)
HD 30 1280 x 720p (30fps)
VGA 640 x 480 (30fps)
Stabilization ON Enables motion stabilization, providing smooth and stable recording.
OFF Disables motion stabilization.
Motion
detect
ON Initial video recording when motion is detected.
OFF Disables motion detection.
Slow motion ON Record videos in slow motion. When the video is played, the
playback time will be longer than the actual recording time.
OFF Disables slow motion.
Pre-record ON Enables pre-recording. The camcorder records one second before the
Record button is pressed.
OFF Disables pre-recording.
Time lapse
OFF Disables time lapse.
1 sec Record one frame per second.
3 sec Record one frame every three seconds.
5 sec Record one frame every five seconds.
Continuous
play
ON Playback a video file continuously.
OFF Disables continuous play.

Quick Tour
12
Photo Settings
Light
ON The light turns ON and provides illumination while recording.
OFF The light turns OFF.
Digital light Extend the dynamic range for backlight and high contrast, so that
objects are brighter and clearer.
Resolution
High -
16MP 4608 x 3456 (16MP)
Standard -
8MP 3264 x 2448 (8MP)
Low - 3MP 2048 x 1536 (3MP)
Self-timer ON Activates a 10-second delayed self-timer.
OFF Disables the self-timer.
ISO
Auto The camcorder adjusts the ISO sensitivity of the image automatically.
800 The larger the number, the higher the ISO sensitivity. Select a lower
number to shoot a smoother image. Select a higher number to shoot
an image in the dark or a subject moving at high speed.
NOTE: The image may appear blurry, while using a higher number.
1600
Slideshow
2 sec Display one photo every 2 seconds.
5 sec Display one photo every 5 seconds.
10 sec Display one photo every 10 seconds.
OFF Disables slideshow.
Effects
Scene
Auto Automatically adjusts to the current conditions.
Skin Adjusts skin tones to appear more natural.
Night Use in low light conditions or at night.
Backlight Use when the subject is brightly lit from behind.

Quick Tour 13
Filter
Auto Automatically adjusts to the current conditions.
Black &
White The image is converted to black and white.
Classic The image is converted to sepia.
Negative The image is converted to a negative of the original image.
White
balance
Auto Automatically adjusts to the current conditions.
Daylight Use while taking photos outside.
Fluorescent Use in fluorescent lighting.
Tungsten Use in tungsten lighting.
Setup
Sound ON Enables camcorder operation sounds.
OFF Disables camcorder operation sounds.
TV
NTSC
(60Hz) TV output setting is NTSC standard.
PAL (50Hz) TV output setting is PAL standard.
Language Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian, Norwegian,
Polish, Portuguese, Russian, Swedish, Spanish, Turkish.
Time setting Set up date and time.
Format YES Format the memory or the media card.
NO Do not format the memory or the media card.
Default
setting
YES Restore default factory settings.
NO Do not restore default factory settings.
Delete
Delete video Select video files to be deleted.
Delete photo Select photos to be deleted.
Select &
delete Select video and photo files to be deleted.
Delete all Delete all video and photo files.

Plug and share
14
Plug and share
Install the bundled software application, ArcSoft MediaImpression®, for
optimal video playback on your computer.
Connect the computer and camcorder with the supplied mini USB 2.0
cable as shown.
Videos and photos can be found on your computer at
My Computer\Removable Disk\DCIM\100MEDIA. In this folder, you
can view, delete, move, or copy the desired recorded videos and photos.
You can also share recorded videos on an Internet Web site via the built-in
CAMILEO Uploader application, which offers you an easy way to
upload your video clips to the Internet instantly. For more detailed
instructions, refer to the User’s Guide, chapter 9 on the supplied CD.
To install the bundled Software:
1Insert the supplied CD into your computer’s CD-ROM drive.
2The autorun screen appears. Then, click on [Install Application
Software]. Follow the on-screen instructions to complete the
installation.
❖ArcSoft MediaImpression®—a user-friendly application that helps
in the management of your media; burns a video to DVD, and
uploads videos to the Internet easily.

Toshiba Support 15
Toshiba Support
If you require help or are having problems operating your product, you
may need to contact Toshiba for additional technical assistance.
Before you call
Since some problems may be related to software, it is important that you
investigate other sources of assistance first. Try the following before
contacting Toshiba:
❖Review the User’s Guide supplied with your product.
❖If a problem occurs when you are running software applications,
consult the software documentation for troubleshooting suggestions.
Contact the software company’s technical support department for
assistance.
❖Consult the reseller or dealer from whom you purchased your
product. They are your best resource for current information and
support.
Contacting Toshiba
Toshiba’s technical support Web site
For technical support, or to stay current on the most recent software and
hardware options for your CAMILEO™ product and for other product
information, be sure to regularly check the Toshiba Web site at
www.pcsupport.toshiba.com.
Toshiba voice contact
For technical support, call the Toshiba Customer Support Center:
Within the United States at [phone]
Outside the United States at [phone]
Toshiba Phone Service Center for Latin America Specialized technical
service in Spanish.
Hours:
Monday through Friday from 8:00 a.m. to 9:00 p.m. EST
Argentina: 0-800-666-3701
Bolivia: 800-100-684
Chile: 800-64-6526
Colombia: 01-800-912-0539

Toshiba Support
16
Costa Rica: 0-800-011-1123
Ecuador: 949-587-6834*
El Salvador: 800-6601
Guatemala: 949-587-6835*
Honduras: 949-587-6836*
Nicaragua: 949-587-6843*
Panama: 00-8000-44-7813
Paraguay: 009-800-441-0059
Peru: 0-800-5-3817
Dominican Republic: 1-888-862-3225
Uruguay: 000-411-002-2297
Venezuela: 0-800-100-8819
*Phone charges apply
This product comes with a One (1) Year Standard Limited Warranty.
The One (1) Year Standard Limited Warranty for Toshiba Computer
Accessories can be found online at
http://pcsupport.toshiba.com/accessories1yr.

CAMILEO™ S30
Guía de inicio rápido

Introducción
2
Introducción
Para obtener información detallada consulte el Manual del usuario en el
CD que se incluye.
Instrucciones de seguridad
1No deje caer la videocámara ni la perfore o desarme, de lo contrario
se anula la garantía.
2Evite el contacto con el agua y séquese las manos antes de usar la
videocámara.
3No exponga la videocámara a temperaturas elevadas ni la deje en
contacto directo con la luz del sol ya que la videocámara podría
averiarse.
4Use la videocámara con cuidado. No presione el cuerpo de la
videocámara con fuerza.
5Para su seguridad personal, no utilice la videocámara durante una
tormenta ni cuando relampaguea.
6No utilice baterías de especificaciones diferentes, ya que se podrían
causar daños graves.
7Extraiga la batería cuando no esté utilizando la videocámara durante
un período prolongado, ya que una batería deteriorada puede afectar
el funcionamiento de la videocámara.
8Extraiga la batería si da muestras de que tiene una fuga o una
deformación.
9Utilice solamente los accesorios suministrados por el fabricante.
10 Mantenga la videocámara fuera del alcance de los niños.
11 Se corre el riesgo de una explosión cuando se reemplaza la batería
con una de tipo incorrecto.
12 Elimine las baterías usadas de acuerdo con las instrucciones.
Información sobre la batería
❖Utilice solamente las baterías recomendadas por TOSHIBA como
repuestos. La batería es de iones de litio y puede explotar si no se
reemplaza, utiliza, manipula o elimina en forma correcta. Deseche la
batería según lo requieran la legislación y los reglamentos locales.

Instrucciones de seguridad 3
❖Cargue la batería a temperatura ambiente entre 5 y 35 grados
centígrados. De lo contrario, es posible que se fugue la solución
electrolítica, que disminuya el rendimiento de la batería y se acorte
su duración.
❖Nunca instale o extraiga la batería sin antes apagar la alimentación y
desconectar el adaptador de CA.
❖Para cargar la batería utilice solamente el adaptador de CA o el cable
USB suministrado o un cargador de baterías Toshiba opcional. Nunca
trate de cargar la batería con cualquier otro tipo de cargador.
Al tocar el cable de este producto las personas se exponen al plomo,
una sustancia química que el estado de California sabe que ocasiona
anomalías congénitas u otros daños a la reproducción. Lávese las
manos después de tocar el cable.
Información reglamentaria
TOSHIBA declara que este producto cumple con las siguientes normas:
Requisitos de la FCC
Este equipo se probó y se comprobó que cumple con la
sección 15 de las normativas de la FCC.
Su funcionamiento está sujeto a las siguientes dos condiciones:
(1) Este dispositivo no debe causar interferencias perjudiciales.
(2) Este dispositivo debe aceptar cualquier interferencia,
incluidas aquellas que puedan comprometer su
funcionamiento.
Declaración de conformidad CE
Este producto ostenta la marca CE de conformidad con las
directivas de la Comunidad Europea pertinentes. La oficina
responsable de la obtención de la marca en la Comunidad
Europea es Toshiba Europe GmbH, Hammfelddamm 8, 41460
Neuss, Alemania. Una copia de la Declaración de
conformidad oficial se puede obtener en el siguiente sitio:
http://epps.toshiba-teg.com.
A D V E R T E N C I A

Instrucciones de seguridad
4
La siguiente información es sólo para estados miembros
de la Unión Europea: Desecho de productos
Este símbolo indica que este producto no se debe desechar con los
desechos domésticos normales sino separadamente.
Contacto
Marcas comerciales
Adobe es una marca registrada o una marca comercial de Adobe Systems
Incorporated en Estados Unidos y/u otros países.
ArcSoft y MediaImpression son marcas registradas de ArcSoft, Inc.
HDMI, el logotipo de HDMI y High-Definition Multimedia Interface son
marcas comerciales o marcas registradas de HDMI Licensing, LLC.
Secure Digital y SD son marcas comerciales de la SD Card Association.
Todos los demás nombres de marcas y productos son marcas comerciales
o marcas registradas de sus respectivas compañías.
Dirección: TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Teléfono: [phone]
