Toshiba multi-drive recorder. Allows users to record and playback their favorite videos in stunning MPEG-2 digital video on
DVD-RAM/DVD-R or DVD-RW formatted discs.
250GB HDD with over 220 hours of digital recording time using the 2.2mbps LP mode and even more with a lower bit rate.
Toshiba’s Network NAVI system provides connection and control within a home network for: advanced editing, streaming
content to a PC, e-mail timer and recordings and more.
Video Upconversion displays a pure digital signal at both 720p or 1080i, matching the resolution of the HDTV monitor
and thus eliminates signal degrading A/D-D/A conversion.
HDMI™ includes both digital audio and video signals in one convenient cable for uncompressed single wire
connection of home theater components to the television.
Preset bit rates and audio settings for 11 different recording options plus one user adjustable setting, including selections
for LPCM audio recording.
TV Guide On Screen™IPG allows users to schedule programs to record using the easy to use TV Guide functionality.
Satellite Programming and STB IR allow, via supplied IR blaster, channel control of DBS satellite boxes for manual timer
programming.
ADVANTAGE TOSHIBA
VIDEO

250GB Hard Disc Drive

Multi-Drive Playback and Recording with DVD-RAM/DVD-R/DVD-RW* Compatibility

High-Definition Multimedia Interface (HDMI™)

Upconversion to 720p/1080i Resolution

Digital Cinema Progressive Scan

3-D Y/C Comb Filter/Video DNR for Recording
AUDIO

WMA & MP3 Playback

LPCM/Dolby®Digital (2Ch) Audio Recording (based on mode)

3-D Virtual Surround Sound

Optical TosLink®Digital Audio Output
CONVENIENCE

Network NAVI

TV Guide On Screen™IPG

Satellite Programming and STB IR Control

IR Blaster for Cable Box Control (G-LINK™)

Front Panel A/V, S-Video & IEEE1394 DV Inputs

Time Slip: Chase Play and Live Chase Play "Pause Live TV"

EASY NAVI
KEY FEATURES
DVD RECORDER
RD-XS55

TECHNOLOGY
& BENEFITS
VIDEO
Network NAVI - The Network NAVI system connects you to your home
network via a LAN 10/100 port (Ethernet), allowing for greater
integration with a PC and other Network NAVI products with the ability to:
- Dub copy-free content from one RD-XS55 to another if both are
connected to the same network
- Stream recorded content or even live programming to a PC
- Upload custom Menu backgrounds for creating DVD-R/RW discs
- Edit and add title information to recorded content from a PC
- Remotely schedule recordings via email
- Receive automiatic software upgrades
- Use a PC scroll mouse to control the recorder for detailed video
editing.
Video Upconversion - 720p/1080i - HDMI™ can support uncom-
pressed digital video up to HDTV level resolution. Thus, the player makes
use of this conduit by upconverting the standard DVD picture resolution
to nearly HDTV-quality with output resolutions of 720p or 1080i. This
makes a DVD player with an HDMI™ connection the perfect match for
today's digital televisions. And because this conversion is performed in
the player, the signal remains free from excessive digital-to-analog
conversion artifacts.
Multi-Drive Recorder - Toshiba Multi-Drive DVD recorders are multi-for-
mat DVD recorders designed to provide the greatest flexibility in record-
ing and playback by supporting DVD-RAM, DVD-R, and DVD-RW*
recordable disc formats.
AUDIO
WMA & MP3 Playback - Recordable Compact Discs (CD-R &
CD-RW) with music stored in either the Windows Media™ Audio or MP3
file formats can be enjoyed.
CONVENIENCE
TV Guide On ScreenTM - This Interactive Program Guide provides an
easy to read listing of the television programs available to view or record.
The full 2004 version incorporated in the RD-XS54 provides: an 8-day
program listing, flexibility of recording directly to DVD or the HDD, the
ability to perform keyword searches for locating favorite programs and
includes the G-Link IR Blaster for controlling cable boxes. When record-
ing television programs, the name of the show, along with the channel
and date, are automatically captured.
Chase Play & Live Chase Play (Pause Live TV) - Chase Play allows
the user to begin watching a recording that is already in progress. The
Live Chase Play feature lets you 'pause' a live recording and then return
to it later. During playback of both modes, a bar graph can be
displayed on-screen depicting the 'progress' or location of the playback
signal with regards to the real time recorded signal.
Satellite Programming and STB IR allow, via supplied IR blaster,
channel control of DBS satellite boxes for manual timer programming.
SPECIFICATIONS
DVD
http://www.tacp.toshiba.com Customer Service: 800.631.3811
Marketing Communications © Toshiba America Consumer Products, L.L.C.
82 Totowa Road, Wayne, NJ 07470 (2006). All Rights Reserved (06/06.03)
Firewire is a registered trademark of Apple. Dolby is a registered trademark of Dolby
Laboratories. DTS is a registered trademark of Digital Theater Systems. TosLink is a
registered trademark of Toshiba Corporation. ColorStream is a registered trademark of
Toshiba America Consumer Products, L.L.C. TV Guide On-Screen is a registered
trademark of Gemstar-TV Guide International, Inc and/or one of its affiliates. Product
design and specifications subject to change or modification without notice.
TERMINALS
Disc Qty 1
Disc Play DVD-Video/DVD/CD/CD-R/CD-RW**/
VCD/SVCD/DVD-R/DVD-RW/DVD-RAM
Disc Record DVD-RAM, DVD-R, DVD-RW*
Hard Disc Drive 250GB
Video D/A 10-Bit/54MHz
HDMITM Output X
Video Upconversion 720p or 1080i
Component Video Output ColorStream Pro® Progressive Scan
3:2 Pulldown Digital Cinema Progressive
181-Channel Tuner X
3-D Y/C Comb Filter X
Black Level Expansion X
0 IRE / 7.5 IRE Recording Selection X
Digital Video Noise Reduction Recording 3D-DNR
Digital Video Noise Reduction Playback 3 D,
Block and Mosquito DNR X
Simultaneous Recording & Playback X
Chase Play & Live Chase Play (Pause Live TV) X
Digital Time Base Correction X
Instant Replay, Instant Skip X
On-Screen Camcorder Download Controls X
JPEG Viewer X
Fast Forward with Audio 1.5 X
Fast Scan, Slow Motion X
Audio D/A 24-bit/192kHz
Dolby®Digital/DTS®Compatible X
WMA & MP3 Playback X
3-D Virtual Surround Sound X
Auto Clock, Daylight Savings Time Adjust X
Time Zone Adjust X
One-Touch Record X
Auto Title/Chapter/Thumbnail Creation X
Network NAVI Menu X
TV Guide On ScreenTM X
Auto Channel Setup X
Parental Lock X
High-Speed Dubbing X
Remote Control Universal with TV Controls
TERMINALS
Outputs (rear panel)
HDMITM 1 set (all sources)
Y/Pr/Pb 1 set (all sources)
S-Video 1
RCA-Video 1 front & 2 rear
L-R Audio (pair) 1 front & 2 rear
Optical Out 1
RF 1 (tuner pass through only)
IR Blaster cable boxes and DBS
Ethernet Port X
Inputs
S-Video 2
RCA-Video 1 front & 2 rear
L-R Audio (pair) 1 front & 2 rear
IEEE 1394 DV 1 front
RF 1 rear
Dimension (WHD) 17.09 x 13.35 x 3.19 inches
UPC Code 22265412084
*DVD-RW Recording in the Video Format only. Playback with VR or Video format.
**CDR/CD-RW discs recorded by CD-DA method can be played back. Some CD-R/CD-
RW discs may be incompatible due to laser pick-up and disc design. DVD-R discs
recorded by DVD Video method can be played. Some DVD-R discs may be incompatible
due to laser pick-up and disc design. WMA, MP3 and JPEG discs may be incompatible
due to different recording format or condition of disc.
