Toshiba SD-V280UA User manual

SERVICE MANUAL
DVD VIDEO PLAYER & VIDEO
CASSETTE RECORDER
SD-V280UA
FILE NO. 810-200222
SD-V280CA
DOCUMENT CREATED IN JAPAN, Feb., 2003

Printed in ThailandJ2B01801A U
02/08
DVD VIDEO PLAYER & VIDEO
CASSETTE RECORDER
SD-V280A
OWNER’S MANUAL
2
14
22
29
34
39
Introduction
Connections
Basic setup
Playback
(VCR)
Recording (VCR)
ther functions
(VCR)
DIGITAL VIDE
42
45
53
Basic playback
(DVD)
Advanced
playback
(DVD)
Function setup
(DVD)
63
thers
2
Introduction
IMP RTANT SAFEGUARDS
WARNING: T REDUCE THE RISK F FIRE R ELECTRIC SH CK, do not expose this appliance to
rain or moisture.
CAUTI N: TO PREVENT ELECTR C SHOCK DO NOT USE TH S POLAR ZED PLUG W TH AN
EXTENS ON CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN
BE FULLY NSERTED TO PREVENT BLADE EXPOSURE.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. f this
equipment does cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- ncrease the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTI N:
Changes or modifications not expressly approved by the partly responsible for compliance with the
FCC Rules could void the user's authority to operate this equipment.
CAUTI N: TH S D G TAL V DEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF TH S PRODUCT, PLEASE READ TH S USER'S GU DE CARE-
FULLY AND RETA N FOR FUTURE REFERENCE. SHOULD THE UN T REQU RE MA NTE-
NANCE, CONTACT AN AUTHOR ZED SERV CE LOCAT ON-SEE SERV CE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPEC F ED HERE N MAY RESULT N HAZARDOUS RAD AT ON EXPOSURE.
TO PREVENT D RECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLO-
SURE. V S BLE LASER RAD AT ON MAY BE PRESENT WHEN THE ENCLOSURE S OPENED.
DO NOT STARE NTO BEAM.
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the presence
of uninsulated dangerous voltage within the product's
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
RISK F ELECTRIC SH CK
D N T PEN
CAUTI N
CAUT ON: TO REDUCE THE R SK OF ELECTR C
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERV CEABLE
PARTS NS DE. REFER SERV C NG TO
QUAL F ED SERV CE PERSONNEL.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
CERT F CAT ON: COMPL ES W TH FDA RAD AT ON PERFORMANCE
STANDARDS, 21 CFR SUBCHAPTER J.
7230007448
DVD OUT DVD, VCR OUT LNE ONE UHF/VHF
ANALOG AUDO
LY
P
B
P R
VDEO
L
R
AUDO
VDEO
L (MONO)
R3CH 4
AUDO
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSDG TAL AUD O
OPTCAL COAX AL
3
Introduction
1. READ INSTRUCTI NS
All the safety and operating instructions should be read before the unit is operated.
2. RETAIN INSTRUCTI NS
The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
4. F LL W INSTRUCTI NS
All operating and use instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning the exterior cabinet only.
6. ATTACHMENTS
The manufacturer of this unit does not make any recommendations for attachments, as they may cause
hazards.
7. WATER AND M ISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool.
8. ACCESS RIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table.
The unit may fall, causing serious injury, and serious damage to the unit.
8A. An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
9. VENTILATI N
Slots and openings in the cabinet back or bottom are provided for ventilation,
to ensure reliable operation of the unit, and to protect it from overheating.
These openings must not be blocked or covered. The openings should never be blocked by placing the unit
on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat
source. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided and/or the manufacturer’s instructions have been adhered to.
10. P WER S URCE
This unit should be operated only from the type of power source indicated on the rating plate. f you are not
sure of the type of power supply to your home, consult your appliance dealer or local power company. For
units intended to operate from battery power, or other sources, refer to the operating instructions.
11. GR UNDING R P LARIZATI N
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way. This is a safety feature. f you are unable to
insert the plug fully into the outlet, try reversing the plug. f the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug, if your
unit is equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only
fit into a grounding-type power outlet. This too, is a safety feature. f you are unable to insert the plug into
the outlet, contact your electrician to replace your obsolete outlet.Do not defeat the safety purpose of the
grounding-type plug.
12. P WER-C RD PR TECTI N
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the appliance.
S3125A
PORTABLE CART WARN NG
(symbol provided by RETAC)
IMP RTANT SAFEGUARDS

4
Introduction
IMP RTANT SAFEGUARDS
13. LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the
unit due to lightning and power line surges.
14. P WER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits, as
contact with them might be fatal.
15. VERL ADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
16. BJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
17. UTD R ANTENNA GR UNDING
f an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the
National Electrical Code, ANS /NFPA 70, provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
18. SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
19. DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
a. When the power-supply cord or plug is damaged.
b. f liquid has been spilled, or objects have fallen into the unit.
c. f the unit has been exposed to rain or water.
d. f the unit does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions, as an improper adjustment of other controls
may result in damage and will often require extensive work by a qualified technician to restore the
unit to its normal operation.
e. f the unit has been dropped or the cabinet has been damaged.
f . When the unit exhibits a distinct change in performance, this indicates a need for service.
20. REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by
the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21. SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
22. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
23. DISC TRAY
Keep your fingers well clear of the disc tray as it is closing. t may cause serious personal injury.
24. C NNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.
5
Introduction
EXAMPLE OF ANTENNA GROUND NG AS PER THE
NAT ONAL ELECTR CAL CODE
C NDENSATI N
Moisture will form in the operating section of the DVD/VCR if the player is brought from cool surroundings into a
warm room or if the temperature of the room rises suddenly. When this happens, the DVD/VCR's performance
will be impaired.
To prevent this, let the DVD/VCR stand in its new surroundings for about an hour before switching it on, or make
sure that the room temperature rises gradually.
Condensation may also form during the summer if the DVD/VCR is exposed to the breeze from an air
conditioner. n such cases, change the location of the DVD/VCR.
25. LASER BEAM
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the
laser beam. t may cause sight damage.
26. DISC
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and product malfunction.
27. N TE T CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be con-
nected to the grounding system of the building, as close to the point of cable entry as practical.
T USE AC P WER S URCE
Use the AC polarized line cord provided for operation on AC. nsert
the AC cord plug into a standard 120V 60Hz polarized AC outlet.
Notes:
•Never connect the AC line cord plug to other than the specified
voltage (120V 60Hz). Use the attached power cord only.
•f the polarized AC cord does not fit into a non-polarized AC
outlet, do not attempt to file or cut the blade. t is the user’s
responsibility to have an electrician replace the obsolete outlet.
•f you cause a static discharge when touching the unit and the
unit fails to function, simply unplug the unit from the AC outlet
and plug it back in. The unit should return to normal operation.
Polarized AC Cord Plug
(One blade is wider than the other.)
AC Outlet
Wider Hole
and Blade
Power source
ANTENNA
D SCHARGE UN T
(NEC SECT ON 810-20)
ANTENNA LEAD N W RE
GROUND NG CONDUCTORS
(NEC SECT ON 810-21)
GROUND CLAMPS
POWER SERV CE GROUND NG
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND CLAMP
ELECTR C SERV CE
EQU PMENT
NEC-NAT ONAL ELECTR CAL CODE
S2898A
IMP RTANT SAFEGUARDS / Power Source
6
Introduction
Notes on handling
When shipping the DVD/VCR, the original shipping
carton and packing materials come in handy. For
maximum protection, repack the unit as it was
originally packed at the factory.
Do not use volatile liquids, such as insect spray, near
the DVD/VCR. Do not leave rubber or plastic
products to contact the DVD/VCR for a prolonged
period. They will leave marks on the finish.
The top and rear panels of the DVD/VCR may
become warm after a long period of use. This is not a
malfunction.
When the DVD/VCR is not in use, be sure to remove
the disc and the video cassette turn off the power.
f you do not use the DVD/VCR for a long period, the
unit may not function properly in the future. Turn on
and use the DVD/VCR occasionally.
Notes on locating
Place the DVD/VCR on a level surface. Do not use it
on a shaky or unstable surface such as a wobbling
table or inclined stand. The loaded disc or the video
tape may become dis-aligned and damage the DVD/
VCR.
When you place this DVD/VCR near a TV, radio, or
VCR, the playback picture may become poor and the
sound may be distorted. n this case, place the DVD/
VCR away from the TV, radio, or VCR.
Notes on cleaning
Use a soft, dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe. Use a dry cloth to wipe
it dry.
Do not use any type of solvent, such as thinner and
benzine, as they may damage the surface of the
DVD/VCR.
f you use a chemical saturated cloth to clean the unit,
follow that product’s instructions.
To obtain a clear picture
The DVD/VCR is a high technology, precision device. f
the video head, the head drum, the optical pick-up lens
or disc drive parts are dirty or worn down, the picture
quality will deteriorate. To obtain a clear picture, we
recommend regular inspection and maintenance
(cleaning or parts replacement) every 1,000 hours of
use depending on the operating environment. For
details, contact your nearest dealer.
Notes on moisture condensation
Moisture condensation damages the DVD/VCR.
Please read the following carefully.
Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day. Drops of
water form on the outside of the glass. n the same way,
moisture may condense on the head drum or the optical
pick-up lens inside this unit, one of the most crucial
internal parts of the DVD/VCR.
Moisture condensation occurs during the
following cases.
When you bring the DVD/VCR directly from a cold
place to a warm place.
When you use the DVD/VCR in a room where you
just turned on the heater, or a place where the cold
wind from the air conditioner directly hits the unit.
n summer, when you use the DVD/VCR in a hot and
humid place just after you move the unit from an air
conditioned room.
When you use the DVD/VCR in a humid place.
Do not use the DVD/VCR when moisture
condensation may occur.
f you use the DVD/VCR in such a situation, it may
damage discs and internal parts. Remove the disc or
the video tape, connect the power cord of the DVD/
VCR to the wall outlet, turn on the DVD/VCR, and
leave it for two or three hours. After two or three
hours, the DVD/VCR will have warmed up and
evaporated any moisture. Keep the DVD/VCR
connected to the wall outlet and moisture
condensation will seldom occur.
Precautions
E
x
a
m
p
l
e
o
f
m
o
i
s
t
u
r
e
c
o
n
d
e
n
s
a
t
i
o
n
!
Tape
Head drum
It’s too
warm!
Wait!
Wall outlet
7
Introduction
Notes on discs
n handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
n cleaning discs
Fingerprints and dust on the disc cause picture and
sound deterioration. Wipe the disc from the center
outwards with a soft cloth. Always keep the disc
clean.
f you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. t may damage the disc.
n storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
DVD video disc
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 3 Track 4 Track 5
Structure of disc contents
Normally, DVD video discs are divided into titles, and
the titles are sub-divided into chapters. V DEO CDs and
audio CDs are divided into tracks.
DVD video disc
V DEO CD/audio CD
Each title, chapter or track is assigned a number, which
is called “title number”, “chapter number” or “track
number” respectively.
There may be discs that do not have these numbers.
Notes on copyright
t is forbidden by law to copy, broadcast, show,
broadcast on cable, play in public, and rent copyrighted
material without permission.
This device does not tape-record copy protected DVD
Video Discs.
The device is not to be used for copying copyrighted
content without the express written permission of the
copyright owner.
Obtaining such permission is the sole responsibility of
the user.
This product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights
owned by Macrovision Corporation and other rights
owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is
prohibited.
V DEO CD/audio CD

8
Introduction
DIGITAL VIDE
About this owner’s manual
This owner’s manual explains the basic instructions of
this DVD/VCR. Some DVD video discs are produced in
a manner that allows specific or limited operation during
playback. As such, the DVD/VCR may not respond to all
operating commands. This is not a defect in the DVD/
VCR. Refer to instruction notes of discs.
“” may appear on the TV screen during operation.
A “ ” means that the operation is not permitted by the
DVD/VCR or the disc.
Notes on region numbers
The region number of this DVD/VCR is 1. f region
numbers, which stand for their playable area, are printed
on your DVD video disc and you do not find
1
or
ALL
,
disc playback will not be allowed by the player. ( n this
case, the DVD/VCR will display a message on-screen.)
n VIDE CDs
This DVD/VCR supports V DEO CDs equipped with the
PBC (Version 2.0) function. (PBC is the abbreviation of
Playback Control.) You can enjoy two playback
variations depending on types of discs.
• VIDE CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this DVD/VCR in
the same way as an audio CD.
• VIDE CD equipped with PBC function
(Version 2.0)
n addition to operation of a V DEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the TV screen (Menu Playback).
Some of the functions described in this owner’s
manual may not work with some discs.
Playable discs
This DVD/VCR can play the following discs.
• You cannot play discs other than those listed above.
• You cannot play discs of DVD-RAM, DVD-RW, etc., or
non standardized discs even if they may be labeled as
above.
• This DVD/VCR uses the NTSC color system, and
cannot play DVD video discs recorded in any other
color system (PAL, SECAM, etc.).
Notes on discs (continued)
DVD
video
discs
Disc Mark
Contents
Disc
Size Maximum
playback time
VIDE
CDs
Approx. 4 hours
(single sided disc)
Approx. 8 hours
(double sided disc)
Approx. 80 minutes
(single sided disc)
Approx. 160 minutes
(double sided disc)
Approx. 74 minutes
Approx. 20 minutes
8 cm
12 cm
8 cm
12 cm
Audio
+
video
(moving
pictures)
Audio
+
video
(moving
pictures)
Audio
CDs
Approx. 74 minutes
Approx. 20 minutes
8 cm
(CD
single)
12 cm
Audio
The following discs are also available.
CD-R
CD-RW
CD-R/RW discs recorded by CD-DA method can be
played. Some CD-R/RW discs may be incompatible.
9
Introduction
MPORTANT SAFEGUARDS ..........................2
Power source ...................................................5
Precautions ......................................................6
Notes on discs..................................................7
Contents...........................................................9
dentification of Controls.................................10
Antenna connections......................................14
CATV (CABLE TV) connections.....................16
Connecting to a TV ........................................18
Connecting to optional equipment..................20
Introduction
Recording a TV program................................ 34
One-touch Timer Recording (OTR) ................ 36
Timer recording ..............................................37
Stereo recording and playback ...................... 39
Recording (VCR)
Separate audio program (SAP)...................... 39
Duplicating a video tape................................. 40
Recording a DVD/CD disc.............................. 41
ther functions (VCR)
Loading and unloading a cassette tape ......... 29
Cassette tape playback.................................. 30
Special playback ............................................ 31
Convenience function..................................... 32
Playback (VCR)
Setting the video channel............................... 22
Setting the language ...................................... 23
Clock setting................................................... 24
Tuner setting .................................................. 27
Basic setup
Playing a disc ................................................. 42
Basic playback (DVD)
MP3 playback................................................. 45
Zooming ......................................................... 46
Marking desired scenes ................................. 47
Repeat playback ............................................ 48
A-B Repeat playback ..................................... 48
Program playback .......................................... 49
Random playback .......................................... 49
Changing angles ............................................ 50
Title selection ................................................. 50
DVD menu...................................................... 50
Advanced playback (DVD)
Language code list ......................................... 63
Before calling service personnel .................... 64
Specifications ................................................. 65
L M TED WARRANTY ................................... 66
thers
Contents
Connections
Function setup (DVD)
Changing soundtrack language ..................... 51
Setting surround sound .................................. 51
Turning the subtitles on and off...................... 52
Changing the subtitle language...................... 52
Karaoke playback........................................... 52
Setting the aspect ratio of TV screen ............. 53
Setting on screen display ............................... 54
Status display of disc ..................................... 54
Dynamic Range Control ................................. 55
Parental control setting .................................. 56
To change the parental level.......................... 57
Temporary disabling of rating level by DVD disc .. 58
Setting setup language .................................. 59
Setting menu language .................................. 60
Changing subtitle language............................ 61
Setting audio soundtrack language................ 62
10
Introduction
REC button
34
EJECT
N/STANDBY VIDE
LINE IN 2
L(M N ) - AUDI - R CHANNEL INPUT SELECT VCR/DVD SELECT
VCR DVD
ST P PLAY /REW FWD/ REC
PEN/CL SE
Identification of Controls
See the page in for details.
Front panel
Rear panel
STOP button
PLAY button
OPEN/CLOSE button
Disc tray
POWER
button CHANNEL / buttons
AUD O (L/R)/V DEO N
(L NE N 2) jacks
FF (Fast Forward)
button
Remote sensor
EJECT button VCR indicator
VCR/DVD mode selector button
Cassette Loading Slot
REW (Rewind) button
DVD indicator
Display window
nput select button
When connecting the optical digital cable, remove
the cap and fit the connector into the jack firmly.
When not using the jack, keep the cap inserted
to protect it from dust intrusion.
AC power cord
DVD COAX AL D G TAL
AUD O OUT jack
RF N jack
DVD OPT CAL
D G TAL AUD O
OUT jack (dust
protection cap)
RF OUT jack
7230007448
DVD OUT DVD, VCR OUT L NE N1 UHF/VHF
ANALOG AUD O
LY
P
B
P R
V DEO
L
R
AUD O
V DEO
L (MONO)
R3CH 4
AUD O
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSD G TAL AUD O
OPT CAL COAX AL
3/4 Channel Selector Switch
DVD COMPONENT OUT jacks
AUD O (L/R)/V DEO
N (L NE N1) jacks
DVD AUD O (L/R) OUT jacks
DVD/VCR common
AUD O(L/R)/V DEO
OUT jacks
DVD S-V DEO
OUT jack
40
29
29
42
22
42
22
42
22
40
34
13
11
30
30 30
30
19
40
14
19
20
20
19 18
22
14
5
11
Introduction
VCR operation Status
CH 125
8 : 47
AM MON
00 : 00 : 00 SP
STEREO SAP
While watching TV
DAY OF THE WEEK
CHANNEL
TAPE SPEED
REAL T ME COUNTER
CLOCK
STEREO AND
SEPARATE
AUD O
PROGRAM
(SAP)
CH 125
8 : 30
AM MON
00 : 15 : 12 SP
H -F
While operating a tape
OPERAT NG
MODE
TAPE N
AUTO REPEAT
H -F STEREO
DVD/CD/VCD operation Status
VCR
SLP PM
SM CH
C
Play indicator (VCR)
Tape loaded indicator (VCR)
VCR indicator (VCR)
CATV channel indicator (VCR)
Play indicator (DVD)
Timer Recording indicator (VCR)
Tape speed indicator (VCR)
Multifunctional indicator
Recording indicator (VCR)
AM/PM indicator
Display window
Press CALL to display information on screen.
To cancel the display, press CALL again.
Recording :
Rec/Pause :
Play :
Stop :
Eject :
:
VCR Icons
Auto Repeat
34:56 71:33
Track 11/99
00:34:56 01:12:33
Each Press of DISPLAY, the status display of the disc will appear on the screen and change as follows.
DVD
00:34:56 01:12:33
1/9
Title 1/99
1/8
1/32
Chapter 1/999
Eng DolbyDigital
Eng
CD/VCD
OPERAT NG
TRACK NO.
ELAPSED T ME
CHAPTER NO.
ANGLE NO.
SUBT TLE NO.
OPERAT NG MODE
SOUNDTRACK NO.
T TLE NO.
ELASPED
T ME
TOTAL
T ME
TOTAL
T ME

12
Introduction
Remote control
* MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “DVD Menu.”
50
T MER REC button
OPEN/CLOSE button
42
ENTER button
23
TRACK NG +/ - buttons
SET +/
- buttons
31
23
TAPE EJECT button
29
TOP MENU button
50
SET UP button
VCR MENU button
23
53
TV/VCR button
52
22
SUB T TLE button
ATR button
31
ANGLE button
COUNTER RESET
button
50
32
37
REW button
30
MEMORY button
ZERO RETURN
button
32
47
STOP button
30
44
33
REC button
OTR button
34
36
MENU button*
RETURN button
53
CANCEL button
37
CLOCK COUNTER
button
33
ZOOM button
CM SK P button
31
46
A-B RPT button
24 54
NPUT SELECT button
40
PAUSE/ST LL button
SLOW button
DVD/VCR button
22
31
PLAY MODE button
SP/SLP button
34 48
AUD O button
AUD O SELECT button
39
51
( / / / )
Direction buttons
45
Direct channel
selection buttons
Number buttons
45
28
FWD button
30
31
SK P button
NDEX + button
44
33
48
PLAY button
30
22
) buttonPower (
Channel / buttons
34
D SPLAY button
CALL button
SK P button
NDEX
- button
Identification of Controls (continued)
The instructions in this manual describe the functions on the remote control. See the page in for details.
13
Introduction
peration
• Aim the remote control at the remote sensor and press control buttons to
operate.
• Operate the remote control within 30° angle on either side of the remote
sensor, up to a distance of Approx. 7 meters.
Replace the compartment
cover.
nstall two "AAA" batteries
(supplied),
paying attention to the
polarity diagram in the battery
compartment.
Open the battery compartment
cover in the direction of the
arrow.
Approx. 7 meters
Battery precautions
The precautions below should be followed when using batteries in this device:
1.Use only the size and type of batteries specified.
2.Be sure to follow the correct polarity when installing the batteries as indicated in the battery compartment.
Re-
versed batteries may cause damage to the device. To avoid a potential short circuit, insert the “–” end first.
3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old batteries with fresh ones.
4. f the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from
possible battery leakage.
5.Do not try to recharge batteries not intended to be recharged; they can overheat and rupture. (Follow battery
manufacturer’s directions.)
•Press P WER ( ) to turn the DVD/VCR on or off.
•Select your desired operating mode (DVD or VCR) using DVD/VCR.
(DVD or VCR indicator on the front panel will show you which mode is selected.)
•Press CH or CH to move through the channels one channel at a time.
•The CH / ( / ) and SET +/– ( / ) are also used to navigate on-screen menu system.
•You can directly access specific channels using Number buttons.
• Each press of DVD/VCR on the remote control, switches the screen between the VCR screen (VCR mode) and the
DVD screen (DVD mode).
123
Remote control basics
Inserting Batteries
14
Connections
OUT
(TO TV)
N
(FROM ANT)
OUT
(TO TV)
N
(FROM ANT)
OUT
(TO TV)
N
(FROM ANT)
Notes: • A clear picture will not be obtained by the DVD/VCR unless the antenna signal is good. Connect the antenna to
the DVD/VCR properly.
•For better quality recording, an indoor antenna or a telescopic antenna is not recommended. The use of an outdoor
type antenna is required.
•f you are not sure about the connection, please refer to qualified service personnel.
The DVD/VCR must be connected "between" the antenna and the TV. First, disconnect the antenna from the TV and
connect it to the DVD/VCR. Then connect the DVD/VCR to the TV. Below are 3 common methods of connecting an
antenna system to a DVD/VCR. Find the type of antenna system you are using and follow the connection diagram.
f both VHF and UHF antennas have 300 ohm twin lead (flat) wires, use a combiner having two 300 ohm inputs and
one 75 ohm output.
Note:
Combination VHF/UHF Antenna with 75 ohm Coaxial Cable
Combination VHF/UHF Antenna with 300 ohm Twin Lead (Flat) Wire
Separate VHF and UHF Antennas
DVD/VCR
VHF UHF
300 ohm Twin Lead (Flat) Wire
Matching Transformer 300 ohm nput 75
ohm output (not supplied)
300 ohm Twin Lead (Flat) Wire
75 ohm Coaxial Cable
75 ohm Coaxial Cable
Combiner 75/300 ohm nputs 75 ohm output
(not supplied)
DVD/VCR
DVD/VCR
Antenna connections
f you are using an antenna system, follow these instructions. f you are a cable (CATV) subscriber, skip ahead to page 16
for the proper connections.
Antenna to DVD/VCR connection
1
2
3
15
Connections
UHF
VHF
UHF
VHF
VHF/UHF N
Note: If a VHF or UHF antenna is used,
set the TV/CATV menu option to
the "TV" mode.
Note: If a VHF or UHF antenna is used,
set the TV/CATV menu option to
the "TV" mode.
Note: If a VHF or UHF antenna is used,
set the TV/CATV menu option to
the "TV" mode.
75 ohm Coaxial Cable (supplied)
Splitter 75 ohm nput
75/300 ohm outputs
(not supplied)
Splitter 75 ohm nput
300 ohm outputs
(not supplied)
TV with single 75 ohm VHF/UHF antenna
input
TV with 300 ohm UHFand 75 ohm VHF
antenna inputs
TV with 300 ohm UHF and 300 ohm VHF
antenna inputs
After you have connected the antenna to the DVD/VCR, you must connect the DVD/VCR to the TV.
Below are 3 common methods of connecting your DVD/VCR to a TV. Find the type of TV you are using and follow the
connection diagram.
This DVD/VCR has a single 75 ohm output for connection to a TV. f your TV has separate VHF and UHF antenna
inputs (numbers 2 and 3 below), use a splitter to connect the DVD/VCR to the TV for VHF and UHF reception.
TV
TV
TV
75 ohm Coaxial Cable
(supplied)
75 ohm Coaxial Cable
(supplied)
DVD/VCR to TV connection

16
Connections
CATV (CABLE TV) connections
VHF/UHF
N (ANT)
OUT
(TO TV)
N
(FROM ANT)
VHF/UHF
N (ANT)
OUT
(TO TV)
N
(FROM ANT)
VHF/UHF
N (ANT)
OUT
(TO TV)
N
(FROM ANT)
Many cable companies offer services permitting reception of extra channels including pay or subscription channels. This
DVD/VCR has an extended tuning range and can be tuned to most cable channels without using a cable company
supplied converter box, except for those premium channels which are intentionally scrambled. f you subscribe to a
premium channel which is scrambled, you must have a descrambler box for proper reception.
Allows: *Recording of nonscrambled channels.
*Use of the programmable timer.
*Recording of one channel while watching another.
Allows: *Recording of channels through the converter box
(scrambled and unscrambled).
*Using the programmable timer to record only the
channel selected at the converter box.
Prevents: *Recording one channel while watching another.
*Using the DVD/VCR tuner to select channels.
DVD/VCR
ncoming Cable
TV
Converter/
Descrambler
ncoming
Cable
TV
TV
To record from converter/descrambler,
DVD/VCR tuner must be tuned to the con-
verter output channel, usually channel 3
or 4.
Note:
DVD/VCR
DVD/VCR
Note: Whenever a Converter/Descrambler box is placed before the DVD/VCR, you must tune the DVD/VCR to the output
of the Converter/Descrambler box, usually channel 3 or 4.
ncoming Cable Converter/Descrambler
Allows: *Recording of nonscrambled channels.
*Use of the programmable timer.
*Recording an unscrambled channel while watching
any channel selected at the converter box.
Prevents: Recording scrambled channels.
f you are playing a tape or using the tuner
built into the DVD/VCR, the converter must
be set to the video channel output of the
DVD/VCR (either 3 or 4).
Note:
1
2
3
17
Connections
VHF/UHF
N (ANT)
A
B
OUT
(TO TV)
N
(FROM ANT)
VHF/UHF
N (ANT)
A
B
OUT
(TO TV)
N
(FROM ANT)
This DVD/VCR cannot receive scrambled programs since it does not contain a descrambler. n order to receive scram-
bled programs, your existing descrambler must be used. Descrambler boxes are available from cable companies. Con-
sult your local cable company for more information concerning connection to their descrambler equipment. There are
many ways to connect your DVD/VCR to a cable system. Below are six common methods of connection.
IMP RTANT: Make sure the TV/CATV menu option is set to the "CATV" mode.
ncoming Cable
Allows: *Recording of one channel while watching another.
*Using the programmable timer to record only the channel selected at the converter box.
*Recording of all channels through the converter box.
Prevents: *Watching scrambled channels while recording another channel.
*Using the DVD/VCR tuner to select channels.
DVD/VCR
Splitter
Converter/Descrambler
TV
DVD/VCR
Converter/Descrambler A/B Switch
TV
ncoming Cable
Splitter
Allows: *Recording of nonscrambled channels.
*Recording of one channel while watching another.
*
Watching premium channels through the converter while recording nonscrambled channels.
*Using the programmable timer.
Prevents: Recording scrambled channels.
DVD/VCR
Splitter TV
Converter/Descrambler
A/B Switch
VHF/UHF
N (ANT)
A
B
OUT
(TO TV)
N
(FROM ANT)
Allows: *Recording of all channels through the converter box.
*Recording a scrambled or unscrambled channel while watching another (scrambled or
unscrambled) channel.
*Using the programmable timer to record only the channel selected at the converter box.
Prevents: Using the DVD/VCR tuner to select channels.
A/B Switch
ncoming Cable Converter/Descrambler
4
5
6
18
Connections
7230007448
DVD OUT DVD, VCR OUT L NE N1 UHF/VHF
ANALOG AUD O
LY
P
B
P R
V DEO
L
R
AUD O
V DEO
L (MONO)
R3CH 4
AUD O
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSD G TAL AUD O
OPT CAL COAX AL
Connecting to a TV
Connect the DVD/VCR to your TV.
Note: This method transports VHS and DVD-video signals. For enhanced DVD-video performance, we recommend you
also connect the S-video or ColorStream® component video outputs to your TV/monitor. (see page 19.)
To V DEO
OUT
To ANALOG AUD O OUT
(red) (white) (yellow)
Signal flow
To wall outlet
To video input
(yellow) (red) (white)
Audio/video cable (supplied)
To audio inputs
Notes:
• Refer to the owner’s manual of the connected TV as well.
• When you connect the DVD/VCR to your TV, be sure to turn off the power and unplug both units from the wall outlet before
making any connections.
• f your television set has one audio input, connect the left and right audio outputs of the DVD/VCR to a Y cable adapter (not
supplied) and then connect to your TV.
• Connect the DVD/VCR directly to your TV. f you connect the DVD/VCR to a VCR, TV/VCR combination or video selector,
the playback picture may be distorted as DVD video discs are copy protected.
TV or monitor with
audio/video inputs
Connecting to a TV
19
Connections
To P R video input
7230007448
DVD OUT DVD, VCR OUT L NE N 1 UHF/VHF
ANALOG AUD O
LY
P
B
P R
V DEO
L
R
AUD O
V DEO
L (MONO)
R3CH 4
AUD O
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSD G TAL AUD O
OPT CAL COAX AL
To P R
V DEO
OUT
Notes:
• Refer to the owner’s manual of the connected equipment as well.
• When you connect the DVD/VCR to other equipment, be sure to turn off the power and unplug all of the equipment from the
wall outlet before making any connections.
• f you place the DVD/VCR near a tuner or radio, the radio broadcast sound might be distorted. n this case, place the DVD/
VCR away from the tuner and radio.
• The output sound of the DVD/VCR has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate
listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
• Turn off the amplifier before you connect or disconnect the DVD/VCR’s power cord. f you leave the amplifier power on, the
speakers may be damaged.
• An S-Video connection is superior to Video (Yellow) output. Use this method for DVD playback when the connected
television has S-Video input, and does not have component video inputs.
Connecting to an audio system and TV equipped with S video input/component video inputs
Signal flow
To wall outlet
To audio inputs of
the amplifier
(red)
(white)
(red)
(white)
To Y
V DEO
OUT
To P B
V DEO
OUT
To Y video input
To P B video input
TV or monitor with
ColorStream®
component video inputs
Audio system
Component video (ColorStream®) outputs/inputs
Some TVs or monitors are equipped with component video inputs. Connecting to these inputs allows you to enjoy
the highest quality DVD picture playback.
Actual labels for component video inputs may vary depending on the TV manufacturer. (ex. Y, R-Y, B-Y or Y, CB, CR)
n some TVs or monitors, the color levels of the playback picture may be reduced slightly or the tint may change. n
such a case, adjust the TV or monitor for optimum performance.
To ANALOG AUD O OUT
To S
V DEO
OUT
S video cable
(not supplied)
f you connect the DVD/VCR to your TV
with the DVD OUT jacks, select the
corresponding video input on your
television to watch DVD video discs.
To S video input
Note: VCR and DVD are output from the composite video output. The S-video output and component video output
transports the DVD-video signal exclusively and will deliver enhanced DVD video picture performance.

20
Connections
75 Ω coaxial cable
7230007448
DVD OUT DVD, VCR OUT LNE N1 UHF/VHF
ANALOG AUDO
LY
P
B
P R
VDEO
L
R
AUDO
VDEO
L (MONO)
R3CH 4
AUDO
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSDG TAL AUD O
OPTCAL COAX AL
7230007448
DVD OUT DVD, VCR OUT LNE N1 UHF/VHF
ANALOG AUDO
LY
P
B
P R
VDEO
L
R
AUDO
VDEO
L (MONO)
R3CH 4
AUDO
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSDG TAL AUD O
OPTCAL COAX AL
7230007448
DVD OUT DVD, VCR OUT LNE N1 UHF/VHF
ANALOG AUDO
LY
P
B
P R
VDEO
L
R
AUDO
VDEO
L (MONO)
R3CH 4
AUDO
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSDG TAL AUD O
OPTCAL COAX AL
Connecting to optional equipment
You can enjoy high quality dynamic sounds of DVD video discs or audio CDs by
connecting the DVD/VCR to optional audio equipment.
For connection to your TV, see “Connecting to a TV”
18 19
.: Front speaker
: Rear speaker
: Sub woofer
: Center speaker
: Signal flow
Connecting to an amplifier equipped with a Dolby Digital decoder
Connecting to an amplifier equipped with Dolby Pro Logic Surround
Dolby Pro Logic Surround
You can enjoy the dynamic realistic sound of Dolby Pro Logic Surround by connecting an amplifier and speaker system (right and left
front speakers, a center speaker, and one or two rear speakers).
Connecting to an amplifier equipped with a DTS decoder
Digital Theater Systems (DTS)
DTS is a high quality surround technology used in theaters and now available for home use,
on DVD video discs or audio CDs.
f you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS
encoded sound tracks on DVD video discs or audio CDs.
Manufactured under license from Dolby
Laboratories. “Dolby” “Pro Logic” and
the double-D symbol are trademarks of
Dolby Laboratories. Confidential
unpublished works. ©1992-1997 Dolby
Laboratories. All rights reserved.
• Use DVD video discs encoded via
the Dolby Digital recording
system.
• Use DVD video discs or audio
CDs encoded via the DTS
recording system.
* Connect one or two rear speakers.
The output sound from the rear speakers will be
monaural even if you connect two rear speakers.
“DTS” and “DTS Digital Surround” are
trademarks of Digital Theater Systems,
nc.
With an amplifier equipped with Dolby Digital
Connect the equipment the same way as described in “Connecting to an amplifier
equipped with a Dolby Digital decoder.” Refer to that amplifier’s owner’s manual and set
the amplifier so you can enjoy Dolby Pro Logic Surround sound.
With an amplifier not equipped with Dolby Digital
Connect the equipment as follows.
Dolby Digital
Dolby Digital is the surround sound technology used in theaters showing the latest movies,
and is now available to reproduce this realistic effect in the home. You can enjoy motion
picture and live concert DVD video discs with this dynamic realistic sound by connecting the
DVD/VCR to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital
processor. f you have a Dolby Pro Logic Surround decoder, you will obtain the full benefit of
Pro Logic from the same DVD movies that provide full 5.1-channel Dolby Digital
soundtracks, as well as from titles with the Dolby Surround mark.
Connect either.
To OPT CAL
type digital
audio input
Amplifier equipped with a
Dolby Digital decoder
Optical digital cable
75 Ω coaxial cable
To COAX AL
type digital
audio input
Amplifier equipped with
Dolby Pro Logic Surround
To audio input
Audio cable
*
To ANALOG
AUD O OUT
Amplifier equipped with
a DTS decoder
Connect either.
To OPT CAL
type digital
audio input
Optical digital cable
To COAX AL
type digital
audio input
21
Connections
7230007448
DVD OUT DVD, VCR OUT LNE N1 UHF/VHF
ANALOG AUDO
LY
P
B
P R
VDEO
L
R
AUDO
VDEO
L (MONO)
R3CH 4
AUDO
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSDG TAL AUD O
OPTCAL COAX AL
75 Ω coaxial cable
Optical digital cable
75 Ω coaxial cable
7230007448
DVD OUT DVD, VCR OUT LNE N1 UHF/VHF
ANALOG AUDO
LY
P
B
P R
VDEO
L
R
AUDO
VDEO
L (MONO)
R3CH 4
AUDO
N
(FROM ANT)
OUT
(TO TV)
R
COMPONENTSDG TAL AUD O
OPTCAL COAX AL
Warning
When playing DTS-encoded discs (DVD/VCR), excessive noise may be output from the analog stereo jacks. To avoid
possible damage to the audio system, you should take proper precautions when the ANALOG AUD O OUT (L/R) jacks of the
DVD/VCR are connected to an amplification system. To enjoy DTS Digital Surround™ playback, an external 5.1 channel
DTS Digital Surround™ decoder system must be connected to the B TSTREAM/PCM AUD O OUT jack of the DVD/VCR.
Connecting to an amplifier equipped with an MPEG2 audio decoder
MPEG2 sound
You can enjoy motion picture and live concert DVD video discs with dynamic
realistic sound by connecting an amplifier equipped with an MPEG2 audio decoder
or MPEG2 audio processor.
Connecting to an amplifier equipped with a digital audio input
2 channel digital stereo
You can enjoy the dynamic sound of 2 channel digital stereo by connecting an
amplifier equipped with a digital audio input and speaker system (right and left front
speakers).
Notes:
• DO NOT connect the B TSTREAM/PCM AUD O OUT jack of the DVD/VCR to the AC-3 RF input of a Dolby Digital Receiver.
This input on your A/V Receiver is reserved for Laserdisc use only and is incompatible with the B TSTREAM/PCM AUD O
OUT jack of the DVD/VCR.
• Connect the B TSTREAM/PCM AUD O OUT jack of the DVD/VCR to the “OPT CAL” or “COAX AL” input of a Receiver or
Processor.
• Refer to the owner’s manual of the connected equipment as well.
• When you connect the DVD/VCR to other equipment, be sure to turn off the power and unplug all of the equipment from the
wall outlet before making any connections.
• The output sound of the DVD/VCR has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate
listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
• Turn off the amplifier before you connect or disconnect the DVD/VCR’s power cord. f you leave the amplifier power on, the
speakers may be damaged.
• Use DVD video discs encoded via
the MPEG2 recording system.
Amplifier equipped with an
MPEG2 audio decoder
Connect either.
To OPT CAL
type digital
audio input
Optical digital cable
To COAX AL
type digital
audio input
Amplifier equipped with
a digital audio input
Connect either.
To OPT CAL
type digital
audio input
To COAX AL
type digital
audio input
22
Basic setup
Setting t e video c annel
When a TV is connected with the 75 ohm coaxial cable only.
To view playback of a recorded tape or DVD disc, or to watch a
program selected by the VCR's channel selector, the TV must be set to
channel 3 or 4 (video channel).
Setting the video channel
Press P WER to turn on the DVD/VCR.
Press DVD/VCR to select the VCR mode.
Set the 3/4 Channel selector switch on the rear
panel to CH 3 or 4.
Turn N the TV and set to CH 3 or 4 to corre-
spond with the channel selected in step 3.
Press TV/VCR to select the VCR position.
Select any channel to receive a TV station in your area.
The channel number will appear on the screen for
about 4 seconds.
1
The VCR indicator on the
front panel will light.
2
3
4
5
6
The VCR indicator will
appear in the display
window.
For a push-button TV tuner
f CH 3 or 4 corresponding to the video channel cannot
be tuned on your TV, proceed as follows: set the VCR
3/4 channel selector and the TV to CH 3 or 4, play
back a prerecorded tape and tune the TV to receive a
sharp color picture from the video cassette recorder.
Refer to your TV owner's manual for details.
3CH 4
Notes:
•If the unit does not operate properly, or No key op-
eration (by the unit and/or the remote control): Static
electricity, etc., may affect the player's operation. Discon-
nect the AC power cord once, then connect it again.
• When you turn on the DVD/VCR which has disc inside,
DVD playback will start automatically.
f the operating mode was VCR, when you turned on the
DVD/VCR which has disc inside, it will play back auto-
matically and stop after about 5 minutes.
• During the DVD playback if you change the operating
mode from DVD to VCR, the DVD will continue to play
back the disc and stop after about 5 minutes.
POWER
DVD/VCR
TV/VCR
23
Basic setup
Press SET + or – to select “LANGUAGE”, then
press ENTER.
Press VCR MENU.
f you use the unit for the first time and
press VCR MENU, instead of the
main menu screen on the right the
“SYSTEM SET UP” menu screen in
step 2 may appear.
Setting the language
Setting t e language
You can choose from three different languages (English,
French and Spanish) for the on-screen displays.
1
2
Press SET + or – to select the desired language:
English (ENGLISH), Spanish (ESPAÑ L) or
French (FRANCAIS), then press ENTER.
3
Press VCR MENU until the MENU screen is
cleared.
4
〈+/-/ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
〈+/ - /ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
ON OFF
Notes:
• Both the VCR and the DVD have their own player menus
53
.
• f no buttons are pressed for more than 60 seconds, the
VCR MENU screen will return to normal TV-operation au-
tomatically.
Preparation:
• Turn ON the TV and select to the corresponding
video input.
• Press DVD/VCR to select the VCR mode. (The VCR
indicator will light.)
2, 3
2, 3
1, 4

24
Basic setup
Connect the Antenna or Cable system.
• f you use a cable box, turn it on.
Clock setting
The Auto Clock function will automatically set the built-in clock (Month,
Day, Year and Time) when the DVD/VCR is connected to an Antenna or
Cable system and it is turned off. The DVD/VCR searches for a station
in your area containing the necessary Auto clock setting signals. Once
received, it will take approximately 4 minutes for the clock to set itself
automatically.
Preparation:
• Turn ON the TV and select the corresponding video input.
• Press DVD/VCR to select the VCR mode. (The VCR
indicator will light.)
1
Auto clock setting
Plug the AC Power cord to the AC outlet.
2
Make sure the DVD/VCR is turned off.
• f you press P WER, the Auto Clock
set is not programmed.
3
Wait at least three minutes and press
P WER.
4
Press CALL to check the clock setting on
the on screen display.
5
If the clock is not set, check the antenna
condition. The auto clock may not function
properly if the reception condition is not
good.
6
Auto clock adjustment
To set auto clock to off
The auto clock adjustment will be updated at
12:00 PM everyday if you turn off the DVD/VCR.
• f you use a cable box and you want auto clock
adjustment to be performed, the cable box must be
left on.
• The auto clock adjustment is not effective when
there is a difference of more than 5 minutes exists
between the built-in clock time and the actual time.
When shipped from factory the AUTO CLOCK is set to “ON”.
But if you do not want auto clock set (Adjustment):
Press VCR MENU.
1
Press SET + or – to select “SYSTEM SET
UP”, then press ENTER.
2
Press SET + or – to select “AUT CL CK”.
3
Press ENTER to select “ FF”.
4
Press VCR MENU repeatedly to return to the
normal screen.
• When the AUTO CLOCK is set to
“OFF”, the Auto Clock adjustment
does not function.
• Set the clock manually
26
.
5
CH 125
8 : 47
AM MON
00 : 00 : 00 SP
STEREO SAP
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
〈+/ - /ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
ON OFF
〈+/ - /ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
ON OFF
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
POWER
2, 3
2, 4
1, 5
CALL
25
Basic setup
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
Press VCR MENU.
1
Press SET + or – to select “SYSTEM SET
UP”, then press ENTER.
2
Press SET + or – to select “STANDARD
TIME”
, then Press ENTER.
3
Press SET + or – to select your time zone,
then press ENTER.
4
Press VCR MENU twice to return to the
normal screen.
5
n the rare event that you live within broadcast range of two
stations in two different time zones, the DVD/VCR may
recognize the wrong station for the Auto Clock set.
To correct the situation:
Notes:
• To be able to select the standard time, the clock must first
be set by “AUTO CLOCK” once.
• f you live in Newfoundland and the Auto Clock does not
function properly, set the AUTO CLOCK menu option to OFF
and set the clock manually.
Press VCR MENU.
Press SET + or – to select “SYSTEM SET
UP”, then press ENTER.
1
Press SET + or – to select “DAYLIGHT
SAVING TIME”, then press ENTER.
2
Press SET + or – to select one of the
options, then press ENTER. Press VCR
MENU until the MENU screen is cleared.
3
Notes:
•When shipped from factory, the DAYL GHT SAV NG
T ME is set to “AUTO” position.
• When the clock is not set, Daylight Saving Time setting
is not available.
• When there is no Daylight Saving Time in your area,
always select “OFF” position in step 3.
When you want to set the Daylight
Saving Time manually, on the first
Sunday in April you set to “ON”, and
on the last Sunday in October you
set to “OFF”.
N:
FF:
AUT :
for manual setting
(forward one hour)
for manual setting
(back one hour)
for automatic setting
(read XDS in the signal)
〈+/-/ENTER/MENU〉
DAYL GHT SAV NG T ME
ON
OFF
AUTO
ATLANT C : GMT–4hours
EASTERN : GMT–5hours
CENTRAL : GMT–6hours
MOUNTA N : GMT–7hours
PAC F C : GMT–8hours
ALASKA : GMT–9hours
HAWA : GMT–10hours
AUTO : AUTO SET
(GMT: Greenwich Mean Time)
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
〈+/ - /ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
ON OFF
〈+/ - /ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
ON OFF
To set daylight saving time
You can set the Daylight Saving Time automatically or
manually.
To set standard time
26
Basic setup
2-4
Press VCR MENU.
EXAMPLE: Setting the clock to "8:30 AM" October,
26 (SAT), 2002.
1
8 : 30AM SAT
Manual clock setting
After setting the clock, date and time starts
functioning automatically.
6
Note:
After a power failure or disconnection of the power, the timer
settings will be lost. n this case, reset the present time.
To make corrections any time during the process
Press CANCEL repeatedly until the item you want to
change blinks, then press SET + or –.
Press SET + or – to select “SYSTEM SET
UP”, press ENTER.
2
Press SET + or – to select “CL CK SET”,
then press ENTER.
3
Press SET + or – to set the month, then press
ENTER.
4
Set the day, year and time as in step 4.
5
〈+/ - /ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
ON OFF
á +/–/ENTER/CANCEL/MENU ñ
MONTH
DAY
YEAR
T ME
10
1 (TUE)
2002
12 : 00
AM
á +/–/ENTER/CANCEL/MENU ñ
MONTH
DAY
YEAR
T ME
10
26 (SAT)
2002
8 : 30
AM
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
Clock setting (continued)
f the auto clock process did not set the date and time correctly, you
must set them manually for timer recording and daylight saving time. 2-4
1
27
Basic setup
Tuner setting
This DVD/VCR is equipped with a channel memory feature which allows
channels to skip up or down to the next channel set into memory,
skipping over unwanted channels. Before selecting channels, they must
be programmed into the DVD/VCR’s memory. n addition to normal
VHF and UHF channels, this DVD/VCR can receive up to 113 Cable
TV channels. To use this DVD/VCR with an antenna, set the TV/CATV
menu option to the TV mode. When shipped from the factory, this menu
option is in the CATV mode.
Press VCR MENU. Press SET + or – to select
“CH SET UP”, then press ENTER.
Preparation:
• Turn ON the TV and set to the video input mode.
• Press DVD/VCR to select the VCR mode. (The
VCR indicator will light.)
1
Press SET + or – to select “TV/CATV”.
2
〈+/ - /ENTER/MENU〉
CH SET UP
TV CATV
AUTO CH MEMORY
ADD/DELETE
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
TV/CATV selection Setting channels automatically
Repeat left step 1 and press SET + or – to
select “AUT CH MEM RY”.
1
Press ENTER.
Auto tuning will begin. The channel
display will count up and when fin-
ished, the screen returns to normal.
2
〈+/—/ENTER/MENU〉
CH SET UP
TV CATV
AUTO CH MEMORY
ADD/DELETE
CH 002
Note:
You can’t select “CH SET UP” if you set the channel to “L1” or
“L2”.
Press ENTER to select the TV or CATV mode.
The arrow indicates the selected mode.
3
Press VCR MENU until the menu screen is
cleared.
4
TV - VHF/UHF channels
CATV - CABLE TV channels
〈+/ - /ENTER/MENU〉
CH SET UP
TV CATV
AUTO CH MEMORY
ADD/DELETE
1-2
1, 3
1, 4

28
Basic setup
Repeat the step 1 on page 27. Then press SET +
or – to select the “ADD/DELETE” and press
ENTER.
1
To ADD/DELETE channels
Press VCR MENU until the menu screen is
cleared.
3
To Add or Delete desired channels
2
〈+/—/ENTER/MENU〉
CH SET UP
TV CATV
AUTO CH MEMORY
ADD/DELETE
〈+/—/0—9/ENTER/MENU〉
ADD CH 003
Press Number buttons or SET + or – to select
a channel number you want to add or delete.
To add channels
Press ENTER until “ADD” appears on the
screen.
To delete channels
Press ENTER until “DELETE” appears on the
screen. The channel number will blink.
1
2
Repeat to to add or delete other channel.
3 1 2
Tuner setting (continued)
Noise elimination
When you don't want to receive a weak signal broadcast, a Blue
back screen can be obtained by selecting the NO NO SE BACK-
GROUND "ON". When the unit is shipped from the factory, the
NO NO SE BACKGROUND is set to "ON".
Repeat the steps 1~2 on page 26 and press
SET + or – to select “N N ISE
BACKGR UND”.
1
Press ENTER to select “ N” position.
2
〈+/-/ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
ON OFF
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
Press VCR MENU until the menu screen is
cleared.
3
NUMBER BUTTONS
1, 2
3
1, 2
〈+/-/ENTER/MENU〉
SYSTEM SET UP
CLOCK SET
LANGUAGE/ D OMA/LANGUE
NO NO SE BACKGROUND
ON OFF
AUTO CLOCK
STANDARD T ME
DAYL GHT SAV NG T ME
ON OFF
29
Basic setup
Loading and unloading a cassette tape
Use only video cassette tapes marked and .
Loading
Remove the erase prevention tab with a screwdriver. Cover the hole with a piece of adhesive tape.
To record again
Screwdriver
Automatic tape eject
This DVD/VCR will automatically rewind the tape when the tape has ended. Once the tape is rewound to its beginning,
the cassette tape will be ejected automatically.
Press EJECT on the front panel or TAPE EJECT
on the Remote.
Push the center of the tape until it is automatically
inserted. nsert the cassette tape with its labeled side facing up
and the erase prevention tab positioned at your left. An
inverted cassette tape cannot be inserted.
Automatic playback
When loading a cassette tape without an erase prevention tab, playback will start automatically.
Automatic power N
When you insert a cassette tape the DVD/VCR power will turn ON automatically.
12
Erase prevention tab
Adhesive tape
Remove the cassette tape.
Erase prevention tab
Unloading
To prevent accidental erasure
To prevent accidental erasure
Tape speed and maximum recording time
Video cassette tape
Tape Speed
SLP (Super Long Play)
T-160 T-120 T-90 T-60 T-30
2-2/3 hours 2 hours 1-1/2 hours 1 hour 30 minutes
8 hours 6 hours 4-1/2 hours 3 hours 1-1/2 hours
SP (Standard Play)
Playback (VCR)
Playback (VCR)
TAPE EJECT
30
Playback (VCR)
Cassette tape playback
To play a prerecorded tape.
Load a prerecorded tape
(When loading a cassette tape without the erase
prevention tab, playback will start automatically).
Preparation:
• Turn ON the TV and select the corresponding video input.
• Press DVD/VCR to select the VCR mode. (The VCR
indicator will light).
1
Press PLAY.
Playback will start. " " will appear
on the screen for about 4 seconds.
Press ST P once.
The tape will stop but remain fully
loaded and ready to play.
" " will appear on the screen for
about 4 seconds.
To stop playback
Stop the playback or recording via ST P on remote.
To discontinue the tape-winding, press ST P. To switch to
playback directly (without ST P), press PLAY.
Notes:
• This VCR selects the playback tape speed SP, LP or SLP au-
tomatically.
• The Cassette tape and DVD disc can be played back simulta-
neously. f you press DVD/VCR, the tape playback and DVD
playback alternate with each other on the screen (via CH3, 4
or video connection).
• When you select the VCR mode during DVD playback, DVD
playback will stop automatically after approx. 5 minutes.
2
To start playback
Playback Rewind or forward the tape
To rewind the tape:
Press REW.
To forward the tape:
Press FWD.
Forward/Reverse picture search mode
When the tape is being winded, you can switch to picture
search mode (see next page). To do this, press REW or
FWD and hold it down. The unit will resume the tape
advance or rewinding as soon as the button is released.
PLAY
STOP
FWD
REW
31
Playback (VCR)
Special playback
Picture search
Reverse picture search function
Press REW once or twice during playback.
Forward picture search function
Press FWD once or twice during playback.
To return to playback, press PLAY.
Press PAUSE during playback.
To resume normal playback, press PLAY or PAUSE/STILL.
During playback press SL W.
To return to playback, press PLAY or SL W.
Whenever you insert a tape and start playback, the
automatic tracking feature continuously analyzes the signal
to enable optimum picture quality during playback.
Press PAUSE/STILL during playback.
Press SL W repeatedly: The picture advances frame by
frame.
To return to playback, press PLAY or PAUSE/STILL.
Slow tracking and vertical lock adjustment
f noise bars appear in the picture during slow motion,
press the TRACKING + / – to reduce the noise bars.
f the still picture jitters excessively, press TRACKING
+ / – to stabilize the still picture.
Automatic tracking adjustment
f automatic tracking cannot eliminate noises well during
playback, press TRACKING +/– to eliminate the noise.
“MANUAL TR.” will appear on the screen. Press it briefly
for a fine adjustment, or press and hold for a coarse
adjustment.
Manual tracking adjustment
SPEED SEARCH TIMES
Adjusting tracking condition
Still picture
Slow motion
Frame by frame picture
Notes:
•
The audio output is muted during SPEED SEARCH, ST LL,
FRAME ADVANCE and SLOW MOT ON.
• During picture search mode there will be noise bars. This is
not a defect.
• Playback will commence after approx. 5 minutes to protect
the video tape against excessive wear during pause mode.
Press ATR to reactivate automatic tracking again.
“AUTO TR.” will appear on the screen.
AUTO TR.
P CTURE SEARCH SPEED
PRESS TW CE
TAPE SPEED PRESS ONCE
SP (Standard Play)
LP (Long Play)
SLP (Super Long Play)
5 X
9 X
15 X
3 X
7 X
9 X
REW
PLAY
FWD
STOP
SLOW
ATR
TRACK NG +/–
PAUSE/ST LL
Video head cleaning
Video head clogging
The video heads are the means by
which the DVD/VCR reads the picture
from the tape during playback. n the
unlikely event that the heads become
dirty enough to be clogged, no picture
will be displayed. This can easily be
determined if, during playback of a
known good tape, there is good sound,
but no picture (picture is extremely
snowy). f this is the case, have the
DVD/VCR checked and cleaned by
qualified service personnel.
Notes:
•
DO NOT ATTEMPT TO CLEAN THE V DEO HEADS OR
SERV CE THE UN T BY REMOV NG THE REAR COVER.
•Video heads may eventually wear out and should be re-
placed when they fail to produce clear pictures.
•To help prevent video head clogging, use only good qual-
ity VHS tapes. Discard worn out tapes.
Good Picture
Snowy Picture
CM skip
Press CM SKIP during playback. The DVD/VCR will search
forward through approximately 30 seconds of the tape (e.g.
unwanted commercial time) for each press of CM SKIP
(maximum six presses) and then resume normal playback.
For example : 1 press: 30 seconds of tape
2 press: 60 seconds of tape
3 press: 90 seconds of tape
CM SK P

32
Playback (VCR)
Convenience function
To cancel repeat mode:
Follow the above step 1, then press ENTER to select
“OFF” position. Press VCR MENU to return to the TV.
Press VCR MENU.
Press SET + or – to select “AUTO
REPEAT”.
1
Press ENTER to select “ N” or “ FF”.
f “ON” is selected, the playback
will be repeated endlessly.
2
Press VCR MENU until the menu screen is
cleared.
f you press CALL, " " will
appear on the screen
11
.
3
To commence playback, press PLAY.
The playback will be repeated
endlessly.
4
〈+/—/ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
This function rewinds the tape to the 00:00:00 counter position
automatically.
Press CL CK/C UNTER.
The counter display shows the tape run-
ning time during playback or recording.
1
Press C UNTER RESET at the desired tape
position.
The counter display will be reset to
"00:00:00" position (e.g. the beginning
of recording).
2
Press ST P when playback or recording is
completed.
Press ZER RETURN.
The tape will automatically rewind or fast
forward to the “00:00:00” counter posi-
tion.
3
Repeat playback
The entire video tape will play until its end. The tape will
automatically rewind to the beginning and the playback will be
repeated.
〈+/ - /ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
Zero return function
VCR
S P
SM H
VCR
S P
SM H
COUNTER RESET
PLAY
VCR MENU
SET +/–
ENTER
STOP
ZERO RETURN
CLOCK COUNTER
33
Playback (VCR)
This function enables you to locate the beginning of any recording
made on the VCR.
Recording an INDEX MARK
The ndex Search function auto-
matically records an NDEX mark
on the tape whenever a record-
ing is initiated.
Index search
Press INDEX or during stop or play mode.
For Succeeding programs: Press INDEX .
For Preceding programs: Press INDEX .
(As many as 9 index points can be accessed via this
method.)
When the INDEX or is
pressed, the unit starts searching
the NDEX NO. selected and finds
the portion, then playback starts
automatically. To stop the ndex
Search, press ST P.
CH 001
NDEX
SQPB (S-VHS Quasi Playback)
You can playback video cassette tapes recorded in the
S-VHS system.
However, the picture will not have the high resolution of
S-VHS system.
Note: You cannot record S-VHS video format with this VCR.
Notes:
• When you record an NDEX mark at the very beginning of the
tape, the mark may not be found.
• During NDEX search, the tape may stop and begin to play at a
slightly different location.
• NDEX may not function properly with old or worn out video tapes.
• NDEX marks may not be found if it is extremely close to the point
where the search began.
• n recording, if you stop recording temporarily, the NDEX mark is
not recorded on the tape.
Video index search system
Press CL CK/C UNTER. The clock and tape counter
alternate with each other in the display window.
Notes:
• f you rewind the tape beyond “00:00:00”, a minus sign (“–”)
will be displayed in front of the time.
• When you load a tape, the counter will reset to “00:00:00”.
• The counter does not function on nonrecorded (blank)
sections of the tape. When you rewind, fast forward or play
tapes through blank sections, the counter stops.
Clock/counter display
VCR
SM H
S P
C UNTER
CL CK
VCR
S P
PM CH
C
Press DVD/VCR. The DVD mode and the VCR mode
alternate with each other in the display.
VCR
SM H
DVD mode
VCR mode
VCR
S P
SM H
+3
NDEX NO. (up to 9)
or is displayed
STOP
DVD/VCR
NDEX /
CLOCK COUNTER
34
Recording (VCR)
Recording a TV program
Recording and viewing the same TV program
Recording a TV program
Load a cassette tape with the erase prevention
tab intact.
The DVD/VCR will automatically turn on.
Preparation:
• Turn ON the TV and set to the video input mode.
• Press DVD/VCR to select the VCR mode. (The VCR
indicator will light.)
1
00 : 00 : 00 SP
CH 110
CH 110
NDEX
Press SP/SLP to select the desired tape speed
SP or SLP.
The tape counter and SP or SLP will
appear on the screen for about 4
seconds.
2
Select “TV” or “CATV” to the appropriate
position
27
.
3
TV - VHF/UHF channels
CATV - CABLE TV channels
Press Number button or CH / to select the
channel to be recorded.
4
Press REC.
" " will appear on the screen
for about 4 seconds and “ ” will
appear on the display window.
5
VHF/UHF/CATV CHANNELS
TV CATV
VHF
2-13
UHF
14-69
VHF
2-13
STD/HRC/ RC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-125 (100)(125)
01 (5A)
1-9 Press 0 twice and then 1-9 as required.
Example: To select 2, Press “002”.
10-12 Press 0 first and then the remaining 2 digits in
order from left to right.
Example: Press 012 for “12”.
13-99 Press 2 digits in order.
Example: Press 22 for “22”.
100-125 Press the 3 digits in order.
Example: Press 110 for “110”.
4
4
2
5
DVD/VCR
35
Recording (VCR)
Recording one program while
watching another
Press ST P to stop recording.
" " will appear on screen for about
4 seconds.
Press PAUSE/STILL to avoid recording unwanted
material. Press again to continue the recording.
" " will appear on screen for
about 4 seconds.
Notes:
• The pause function will be released after 5 minutes to prevent
damage to the tape or the VCR. The VCR will change to the
STOP mode.
• You can select a recording channel in the recording pause
mode.
To stop recording temporarily
While the VCR is recording, select your desired channel
on the TV.
When a TV is connected with an antenna cable only,
press TV/VCR to select the TV position.
The “VCR” display will go off and recording will continue.
Select the TV channel you want to watch by using the
TV channel selector.
Note:
Some CATV hookups do not permit viewing one channel
while recording another. See pages
16
and
17
.
This VCR will automatically rewind the tape when the tape
has ended (except during OTR and timer recording). t will
also eject the tape.
Auto Rewind feature
To stop recording
TV/VCR
STOP
PAUSE/ST LL

36
Recording (VCR)
One-touc Timer Recording (OTR)
The One-touch Timer Recording feature provides a simple and
convenient way to make a timed recording.
ne-touch Timer Recording ( TR)
Press
once
twice
3 times
4 times
5 times
NORMAL REC
0:30
1:00
1:30
2:00
3:00
4:00
5:00
NORMAL REC
Recording time Press
6 times
7 times
8 times
9 times
Recording time
Load a cassette tape with the erase
prevention tab intact.
The VCR will automatically turn on.
Preparation:
• Turn ON the TV and select the corresponding video input.
• Press DVD/VCR to select the VCR mode. (The VCR
indicator will light.)
Example: One-touch Timer Recording for 30 minutes.
1
Press SP/SLP to select the desired tape speed
SP or SLP.
The tape counter and SP or SLP will
appear on the screen for about 4
seconds.
2
Set “TV” or “CATV” option to the appropriate
position
27
.
3
00 : 00 : 00 SP
CH 110
CH 125
NDEX
OTR 0 : 30
TV - VHF/UHF channels
CATV - CABLE TV channels
Press Number button or CH / to select the
channel to be recorded.
4
Press TR. Recording begins. Press the button
again to stop recording after 30 minutes. Each
additional press of TR will increase recording
time as shown in the chart below, up to a
maximum of 5 hours.
The OTR and recording time will
appear on the screen for about 4
seconds. And, “ ” will appear on
the display.
5
To cancel TR
Press ST P or turn off the power.
" " will appear on screen for about 4 seconds.
Note:
f you wish to watch the DVD playback during OTR or standard
recording, press DVD/VCR to change to DVD mode and perform
the DVD playback
43
.
4
4
2
5
DVD/VCR
STOP
37
Recording (VCR)
Timer recording
Timer recording can be programmed on-screen with the remote control.
The built-in timer allows automatic unattended recording of up to 8
programs within 1 month.
Timer recording
Notes:
• Press CANCEL to move cursor backward for correction.
• To record from external source set the channel to "L1" or
"L2". "L1" or "L2" will appear next to CH 125 (or 69).
Notes:
• f the timer symbol ( ) blinks when the timer recording ended,
the TV program has not been completely recorded because of
an insufficient tape length. Press TIMER REC to cancel the
timer program or press TAPE EJECT to remove the cassette
tape.
• During timer recording standby mode, the VCR mode cannot be
operated. To use the VCR, press TIMER REC at first, then press
DVD/VCR to change to VCR mode. After you use the VCR,
press TIMER REC again to put the VCR into timer recording
standby mode.
• f you press TIMER REC during timer recording, the recording
operation will be interrupted. f you press TIMER REC again
within the programmed time, the recording operation will start
again.
• After a power failure or disconnection of the power plug, all
programmed recording settings and time display will be lost
upon resumption of power. n this case, reset the clock
24
and
reprogram any timer recording.
Press VCR MENU. Select “TIMER REC SET”,
then press ENTER.
Preparation:
• Press DVD/VCR to select the VCR mode.
• Load a cassette tape with the erase prevention tab
intact.
• Check the time and date are correct
24
.
Example: Program a timer recording for the 26th day,
channel 125
(CATV), 11:00 - 11:30 PM on timer program
number 1 (Tape speed: SLP).
1
Press SET + or – to select one of the program
line, then press ENTER.
2
Press SET + or – to select the date, then press
ENTER.
3
Set the start time, end time, channel and tape
speed as in step 3.
4
á +/-/ENTER/MENU ñ
MENU
TIMER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
〈+/-/ENTER/CANCEL/MENU〉
DATE START END CH
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
—
—
—
—
—
—
—
—
〈+/-/ENTER/CANCEL/MENU〉
DATE START END CH
———————:—— —:—— ———
—:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
—
—
—
—
—
—
—
—
26(SU)
á +/-/ENTER/CANCEL/MENU ñ
DATE START END CH
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
Ð
Ð
Ð
Ð
Ð
Ð
Ð
26(SU) 11 :00 PM 11 :30 PM 125
SLP
á +/-/ENTER/CANCEL/MENU ñ
DATE START END CH
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
ÐÐÐÐÐÐ Ð:ÐÐ Ð:ÐÐ ÐÐÐ
Ð
Ð
Ð
Ð
Ð
Ð
Ð
26(SU) 11 :00 PM 11 :30 PM 125
SLP
To enter other programs, repeat step 2
through 4.
•To return to the normal screen,
press VCR MENU twice.
5
Press TIMER REC. The timer symbol ( ) will
appear on the display and the VCR stands by
for recording.
At the same time, VCR mode will
change to DVD mode automatically.
You can use DVD even if the VCR is
in the Timer recording mode.
f you do not use the DVD, turn the
power off.
6
Notes:
• The timer recording will start at 5 seconds before the time
you predetermined.
• f the timer symbol( ) does not appear on the display in
spite of the pressing of TIMER REC, the cassette may not
have been loaded.
29
• f the cassette is ejected in spite of the pressing of TIMER
REC, the erase prevention tab of the cassette may have
been removed.
29
2, 3
1-3
DVD/VCR
T MER REC
CANCEL
1, 5
TAPE EJECT
38
Recording (VCR)
Setting procedure
To set daily/weekly timer
To confirm Timer program:
At picture 1 on the previous page select “T MER
REC SET” and press ENTER.
The timer program list will appear on the screen.
2
The current day (Friday) SU-SA (Sunday to Saturday)
MO-SA (Monday to Saturday)
MO-FR (Monday to Friday)
WKL-WE WKL-TH (Weekly Thursday)
(Weekly Wednesday)
One month later
minus one day
Weekly (e.g. WKL-TU: each Tuesday) or daily (e.g. M -
SA: Monday to Saturday) Timer recording
Follow the procedure of timer recording on the previous
page. At picture 3 press SET + or – repeatedly until the
desired setting appears. Then press ENTER.
When you press SET – repeatedly, the
DATE indicator will change as follows, in
this case the day is Friday.
If the programs overlap another
Do not overlap timer programs as portions of the
conflicting programs will be lost. The first recording
time has priority over the next recording time as shown
in the diagram below.
Notes:
• The daily/weekly recording can be made continuously until the
recording is canceled or the tape reaches the end.
• During timer recording the automatic rewinding mechanism
does not function.
8 : 00 11 : 00 9 : 00 10 : 00
Program 1
Prog.1
Deleted Parts
Non Recorded Portion Parts
Prog.2 Prog.3
Program 2
Program 3
Recording
Control Settings
〈+/—/ENTER/CANCEL/MENU〉
DATE START END CH
WKL-WE
〈+/-/ENTER/CANCEL/MENU〉
DATE START END CH
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
———————:—— —:—— ———
—
—
—
—
—
—
—
—
〈+/—/ENTER/CANCEL/MENU〉
DATE START END CH
26(SU) 11 :00 PM 11 :30 PM 125
SLP
Notes:
• f there are other timer record programs remaining, TIMER
REC must be pressed to reactivate the timer, otherwise the
remaining timer record programs will be ignored.
• You cannot confirm the Timer program during timer recording
operation.
• You can correct or cancel a programmed setting in program
confirm mode.
If the Timer has been activated, press TIMER
REC to deactivate the Timer.
The timer symbol ( ) will
disappear. Then press DVD/VCR to
change to VCR mode.
1
To cancel Timer program:
Press SET + or – to select the unwanted program,
then press CANCEL to cancel the program.
3
Press VCR MENU repeatedly until the menu
screen is cleared.
4
Timer recording (continued)
To confirm or cancel a program
SET +/–
ENTER
VCR MENU
CANCEL
DVD/VCR
T MER REC
39
Recording (VCR)
Stereo recording and playback /
Separate Audio Program (SAP)
When a MTS STEREO broad-
cast is received, “STEREO” will
appear on the screen and the
program can be viewed or re-
corded in stereo.
The Hi-Fi stereo recording pro-
cedure is the same as for normal
recordings.
Notes:
• When playing back a tape that is not recorded in Hi-Fi stereo
mode, the audio will automatically be monaural.
• When listening to a VHS Hi-Fi video tape or MTS broadcast
through the VHF/UHF jack (Audio/Video cord not connected),
the sound will be monaural.
When viewing an MTS stereo TV program, or playing a
prerecorded VHS Hi-Fi stereo videotape, press AUDI
SELECT to select how the audio will be heard through
the speakers. Normally set to the Hi-Fi stereo position,
this button can be set to the MONO position if the stereo
broadcast or videotape audio is of poor quality. The "R"
and "L" positions allow the audio from the Right or Left Hi-
Fi channel to be heard over both TV speakers. This
button has no effect when viewing a MONO videotape or
TV program. Each time when you press the button,
OUTPUT SELECT ON display appears on the screen for
several seconds. Refer to the chart below.
utput selection
Your DVD/VCR is fitted with a SAP broadcast system which
enables you to switch to a separate audio program when
viewing a selected channel.
This function applies only when the program is broadcast in
multi-languages through the SAP broadcast system.
When the VCR is turned on or a channel selection is
made, make certain the letters "SAP" appears on the
screen. This means that the "Separate Audio Program"
broadcasting is available.
Listening to SAP
Stereo recording and playback
The VHS Hi-Fi audio system permits high fidelity record-
ing of MTS STEREO TV broadcasts.
Separate Audio Program (SAP)
OUTPUT
SELECT ON
STEREO
L CH
R CH
MONO
SOUND HEARD ON BOTH
SPEAKERS
STEREO
LEFT CHANNEL AUD O
R GHT CHANNEL AUD O
MONO
Press VCR MENU. Then press SET + or – to
select "SAP".
1
Press ENTER to select “ N”.
Then press VCR MENU until the
menu screen is cleared.
2
STEREO
STEREO SAP SAP
〈+/—/ENTER/MENU〉
MENU
T MER REC SET
AUTO REPEAT ON OFF
ON OFF
SAP
CH SET UP
SYSTEM SET UP
R
TRACK NG
ENTER
CANCEL
DVD/VCR
T MER REC
ther functions (VCR)
Note:
When using a CATV system, stereo TV programs may be
transmitted over a mono cable channel. n this case
"STEREO" will not appear and the sound will be in mono.
ther functions (VCR)
AUD O SELECT

40
ther functions (VCR)
S P
PM
Duplicating a video tape
f you connect the DVD/VCR to another VCR or Camcorder, you can duplicate
a previously recorded tape. Make all connections before turning on the power.
Duplicating a video tape
For duplicating a previously recorded tape from a
camcorder, follow the camcorder manufacturer’s
instructions. A typical camcorder dubbing hookup is
shown above.
To AUD O (L) N
To AUD O (L) OUT
AUD O/V DEO Cord (supplied)
Playback VCR
To V DEO OUT To AUD O (R) OUT
Recording VCR
To V DEO N To AUD O (R) N
AUD O/V DEO Cord (not supplied)
To AUD O (R) N
To AUD O (L) N
To V DEO N
Recording VCR
To AV Jack
Playback Camcorder
Connection with second video recorder
Connection with Camcorder
Press SP/SLP to select the desired tape speed
SP or SLP. t is recommended that you set the
Speed to the SP mode on the
recording VCR for best results.
1
Press INPUT SELECT once or twice to select
AUDI /VIDE input position.
"L1" or "L2" will appear in the display.
2
Press REC on the recording VCR.
The duplicating process begins.
3
Press PLAY on the playback VCR or Camcorder.
4
Press ST P after duplicating a video tape.
5
L1: on the rear panel
L2: on the front panel
Preparation:
• Turn ON the TV and select the corresponding video
input.
• Press DVD/VCR to select the VCR mode. (The VCR
indicator will light.)
• Load a cassette tape with the erase prevention tab
intact.
• Load a previously recorded tape into the playback
VCR or Camcorder.
5
1
4
2
DVD/VCR
41
ther functions (VCR)
Recording a DVD/CD disc
You can record disc material in DVD, Audio CD, etc. onto a Video
tape with this DVD/VCR.
Duplicating a DVD or CD disc
Press SP/SLP to select the desired tape speed
SP or SLP.
Preparation:
• Turn ON the TV and select the corresponding video
input.
• Press DVD/VCR to select the VCR mode. (The VCR
indicator will light.)
•
Load a cassette tape with the erase prevention tab intact.
• Load a DVD/CD disc.
1
Press DVD/VCR to select the DVD mode.
The DVD indicator will light.
2
Press PLAY to start playback.
3
Press REC to start recording.
The DVD/VCR will change to the
VCR mode automatically and the
playback picture or sound will be
duplicated on the video cassette
tape.
4
Press ST P if you finish recording.
f you wish to stop a DVD/CD disc,
press DVD/VCR to change the DVD
mode, then press STOP.
5
Notes:
• You may not be able to record the beginning of the disc.
Begin VCR recording once program playback commances
on the DVD.
• You can not record discs encorded with copy guard
function. The following icon and text will show up on the
TV screen.
5
1
4
2
3
ther functions (VCR)
D SC S COPY PROTECTED
42
Playing a disc
This section shows you the basics on how to play a disc.
CAUTI N
Keep your fingers well clear of the disc tray as it is closing.
Neglecting to do so may cause serious personal injury.
Basic playback
Preparations:
• When you want to view a disc, turn on the TV and select the corresponding video input connected to the DVD/VCR. This
may include S-video or component video inputs which are exclusive to DVD playback.
• When you want to enjoy the sound of discs from the audio system, turn on the audio system and select the input connected
to the DVD/VCR.
1
3
4
5
Press the power button (I / ).
The DVD/VCR turns on.
Press DVD/VCR to select the DVD mode.
The DVD indicator will light.
Press PEN/CL SE.
The disc tray opens.
Place the disc on the disc tray.
With the playback
side down
• There are two different disc sizes. Place the disc
in the correct guide on the disc tray. f the disc is
out of the guide, it may damage the disc and
cause the DVD/VCR to malfunction.
• Do not place a disc which is unplayable in this
DVD/VCR.
DVD
VCD
CD
2
1
43
, 5
Display window STOP PLAY 2
N/STANDBY
VCR/DVD SELECT
PEN/CL SE
PEN/CL SE
Press PLAY or PEN/CL SE on the unit.
The disc tray closes automatically.
On the TV-screen, changes to
“Reading” and then playback
commences.
• A menu screen will appear on the TV screen, if
the disc has a menu feature.
Press / or /to select title.
Press ENTER.
• Title is selected and play
commences.
Press ST P to end playback.
• The unit records the stopped point,
depending on the disc. “ ”
appears on the screen. Press
PLAY to resume playback (from
the scene point).
• f you press ST P again or unload
the disc (“ ” appears on the
screen.), the unit will clear the
stopped point.
Reading
6
7
8
To start playback in the stop mode
Press PLAY.
PLAY
Basic playback (DVD)
43
Basic playback (DVD)
To pause playback (still mode)
Press PAUSE/STILL during playback.
To resume normal playback, press
the PLAY button.
• The sound is muted during still
mode.
To stop playback
Press ST P.
To remove the disc
Press PEN/CL SE.
Remove the disc after the disc tray
opens completely.
Be sure to press the OPEN/CLOSE button to close
the disc tray after you remove the disc.
Playing a Disc while the VCR section is
recording or standing by for timer recording
1) Start to record.
Follow step 1~5 on page 34.
• f the DVD/VCR is standing by for recording, turn on
the DVD/VCR.
2) Press DVD/VCR to select DVD mode. The DVD
indicator will light.
3) Play a disc.
Follow step 3 ~ step 5 on page 42.
•Press PLAY if the DVD/VCR does not start to play a
disc automatically.
4) Stop to play
Press STOP to stop play back a disc.
Notes:
• f a non-compatible disc is loaded, " ncorrect Disc", "Region Code Error" or "Parental Error" will appear on the TV screen
according to the type of loaded disc. n this case, check your disc again (See pages 8 and 56).
• Some discs may take a minute or so to start playback.
• When you set a single-faced disc label downwards (ie. the wrong way up) and press the PLAY button or the OPEN/CLOSE
button on the unit, "Reading" will appear on the display for 10 seconds and then " ncorrect Disc" will continue to be displayed.
• Some playback operations of DVDs may be intentionally fixed by software producers. Since this unit plays DVDs according
to the disc contents the software producers designed, some playback features may not be available. Also refer to the
instructions supplied with the DVDs.
• When playing DTS-encoded Audio CDs, excessive noise will be heard from the analogue stereo outputs. To avoid possible
damage to the audio system, the consumer should take proper precautions when the analogue stereo outputs of the DVD
player are connected to an amplification system.
• Do not move the DVD/VCR during playback. Doing so may damage the disc.
• Use the OPEN/CLOSE button to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may
cause the DVD/VCR to malfunction.
• Do not push up on the disc tray or put any objects other than discs on the disc tray. Doing so may cause the DVD/VCR to
malfunction.
• n many instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen
menu may damage your television set, permanently etching that image onto its screen. To avoid this, be sure to press the
STOP button on your remote control once the movie is completed.
• During the DVD playback if you change the operating mode from DVD to VCR, the DVD will continue to play back the disc
and stop after about 5 minutes.
• There may be a slight delay between you pressing the button and the function activating.
• The unit is capable of holding a still video image or On screen display image on your television screen indefinitely. f you
leave the still video image or On screen display image displayed on your TV for an extended period of time, you risk
permanent damage to your television screen. Projection televisions are very susceptible.
To obtain a higher quality picture
Occasionally, some picture noise not usually visible during a normal broadcast
may appear on the TV screen while playing a DVD video disc because the high
resolution pictures on these discs include a lot of information. While the amount of
noise depends on the TV you use with this DVD/VCR, you should generally
reduce the sharpness adjustment on your TV when viewing DVD video discs.
About
DVD VCD CD
The
DVD VCD CD
icons on the heading bar show the playable discs for the
function described under that heading.
DVD
: You can use this function with DVD video discs.
VCD
: You can use this function with V DEO CDs.
CD
: You can use this function with audio CDs.
OPEN/CLOSE
STOP
PAUSE/ST LL
DVD/VCR
PLAY

44
FWD
Playing a disc (continued)
You can play discs at various speeds.
Playing in fast reverse or fast forward directions
Playing frame by frame
Press PAUSE/STILL during still playback.
Each time you press the PAUSE/
ST LL button, the picture advances
one frame.
To resume normal playback
Press PLAY.
Note:
The sound is muted during frame by frame playback.
DVD
VCD
CD
REW
PLAY
PAUSE/ST LL
SK P +
SK P –
SLOW
Playing in slow-motion
Press SL W during playback.
Each time you press the SLOW
button, the slow-motion speed
changes.
To resume normal playback
Press PLAY.
Note:
The sound is muted during slow-motion playback.
DVD
VCD
Locating a chapter or track
Press SKIP( ) Forward or SKIP( ) Reverse
during playback to locate a chapter that you
want to watch. Each time you press the button, a
chapter or track is skipped.
DVD
VCD
Basic playback (DVD)
Press REW or FWD during playback.
REW: Fast reverse playback
FWD: Fast forward playback
Each time you press the REW or
FWD button, the playback speed
changes.
To resume normal playback
Press PLAY.
Notes:
• The DVD/VCR mutes sound and subtitles during reverse
and forward scan of DVD video discs. However, the DVD/
VCR plays sound during fast forward or fast reverse play
of audio CDs.
• The playback speed may differ depending on the disc.
The unit is capable of holding a still video image or On screen display image on your television screen indefinitely.
f you leave the still video image or On screen display image displayed on your TV for an extended period of time,
you risk permanent damage to your television screen. Projection televisions are very susceptible.
Note:
DVD
VCD
CD
45
Basic playback (DVD)
Advanced playback (DVD)
MP3 playback
This player can play back the MP3-data which has been recorded on CD-R or
CD-RW. To produce the MP3-data, you need a Windows-PC with CD-ROM
drive and a MP3-encoding Software (not supplied).
The Apple-HFS-System can not be played.
Advanced playback (DVD)
0-9
ENTER
POWER
PLAY
OPEN/CLOSE
STOP
MP3 Playback
CD
1
3
4
Press PEN/CL SE.
The disc tray will open.
Place a disc onto the tray.
Press PLAY or PEN/CL SE.
The disc tray closes automatically.
On the TV-screen,“Reading” and then
reading file number
will appear.
Reading will take as
much time as the
number of file.
A MP3 menu screen will appear on the TV
screen.
Press / or
ENTER to select
folder.
Press / or / or Number keys to select
the desired track, then press ENTER.
Track is selected and play commences.
• n case the folder includes more
than 11 tracks, press or to
display next track list.
2
Reading
MP3 15
1
Track - - /12 00:00
/0-9/Enter/Play Mode
1
2
3
4
5
Japan
Bay Bridge
CLOSE MY EYES
DIVE TO BLUE
Honey
6
7
8
9
10
BLUE EYES
Blurry Eyes
flower
Lies and Truth-
winter fall
Jazz
1
Jazz
Track 1/12 01:28 Japan
/0-9/Enter/Play Mode
1
2
3
4
5
Japan
Bay Bridge
CLOSE MY EYES
DIVE TO BLUE
Honey
6
7
8
9
10
BLUE EYES
Blurry Eyes
flower
Lies and Truth
winter fall
Jazz
1
Jazz
/0-9/Enter/Play Mode
11
12
Mother
Hold Your Last
Jazz
Track 1/12 01:28 Japan
Then press PEN/CL SE.
The disc tray opens.
Remove the disc and press P WER.
The disc tray closes automatically
and DVD/VCR turns off.
6
Limitations on MP3 CD playback
• MP3 CD is the disc that is standardized by SO9660, its file
name must include 3-digits extension letters, “mp3”.
• The directory and file names of the MP3 CD must be
correspond to the SO standardized files.
• This unit can read 200 files per disc. f one directory has
more than 200 files, it reads up to 200 files, the remaining
files will be omitted.
• As for multi-session disc, only the first session can be played.
• f the CD has both audio tracks and MP3 files, only audio
tracks are played.
• t may take more than one minute for this unit to read MP3
files depending on its structure.
• Music recorded by “Joliet Recording Specification” can be
played back, the file name is displayed (within 17 letters) on
the screen Long file names will be condensed.
• The music files recorded by “Hierarchical File System”
(HFS) cannot be played.
Limitations on display
• The maximum number for display is 17 letters. Available letters
for display are the following: capital or small alphabets of A
through Z, numbers of 0 through 9, and _ (under score).
• Other letters than those above are replaced in hyphen.
Notes on MP3 files
To play back MP3 CD in the recorded order,
1. Use MP3 software that records data alphabetically or numerically.
2. Name each file including two-digit or three-digit number
(e.g. "01" "02" or "001" "002").
3. Refrain from making too many sub-folders.
CAUTI N:
• Some MP3 CDs can not be played back depending on the
recording conditions.
• The CD-R/RW that has no music data or non-MP3 files can
not be played back.
MP3 CD Information
Notes:
During MP3-Playback, you can not use SEARCH,
A-B Repeat functions.
You can use Repeat (Track, All or Folder), Random functions and
Program playback for MP3 CD Playback. (See page 48 and 49)
•
•
Press ST P to end playback.
• The unit records the stopped point.
“” appears on the screen. Press
PLAY to resume playback (from the
scene point).
• f you press STOP again or unload the
disc, the unit will clear the stopped point.
5
▲/▼//
46
Zooming
1
2
Press Z M during playback.
The centre part of the image will be zoomed in.
Each press of Z M will change the ZOOM 1 (x 1.3), 2
(x 1.5) and 3 (x 2.0).
▲/▼/ /
Zooming
Advanced playback (DVD)
DVD
VCD
This unit will allow you to zoom in on the frame image. You can then make selections by switching the position of the
frame.
1
Press / / / to view a different part of the frame.
You may move the frame from the centre position to UP, DOWN, LEFT or R GHT direction.
In the zoom mode press Z M repeatedly to return to a 1:1 view ( ff).
3
Notes:
• You can select the Pause, Slow or Search playback in the zoom mode.
• Some discs may not respond to zoom feature.
ZOOM
47
Basic playback (DVD)
Marking the Scenes
▲/▼
MEMORY
Advanced playback (DVD)
Returning to the Scenes
1
Press MEM RY during playback.
Select the blank Marker using / .
Then press ENTER at the desired scene.
• Repeat this procedure to set
the other 2 scenes.
Press MEM RY to remove this display.
Press MEM RY during playback or stop mode.
Press / to select the Marker 1-3.
Press ENTER.
Playback starts from the marked
scene.
2
1
3
Marking desired scenes
The unit stores the points that you want to watch again up to 3 points. You can
resume playback from each scene.
Marker 2
Marker 1
Marker 3
/Enter/Cancel/Marker
Marker 2
Marker 1
Marker 3
/Enter/Cancel/Marker
2700 54
Marker 2
Marker 1
Marker 3
/Enter/Cancel/Marker
27
16
08
54
25
31
00
01
02
Marker 2
Marker 1
Marker 3
/Enter/Cancel/Marker
27
16
08
54
25
31
00
01
02
2
3
Notes:
Some discs may not work with the marking operation.
The marking is canceled when you
open the disc tray
or turn the power off.
Some subtitles recorded around the marker may fail
to appear.
While the MARKER screen is displayed, if you do a
special playback as the Fast Forward/Review Playback
or SK P, the MARKER screen will disappear. Press
MEM RY again as soon as you find the desired
scene.
•
•
•
•
ENTER
CANCEL
To cancel the Marker
Follow the above steps 1~2, then press CANCEL.
DVD
VCD
DVD
VCD

48
Title, Chapter, Track Playback
1
Press PLAY M DE during playback or stop mode.
DVD
Press / or ENTER once or twice to select
“Chapter” or “Title”.
ENTER
▼//
Repeat playback
CD/VCD
Press to select “Repeat”.
Press / or ENTER once or twice to select
“Track” or “All”.
You can also select “Folder” when
playing MP3 encoded CD’s.
Press PLAY M DE again to make the screen
disappear.
Press PLAY to start Repeat playback.
To resume normal playback, select Repeat “ ff”.
3
Note:
Some discs may not work with the repeat operation.
A-B Repeat Playback
1
Press REPEAT A-B during playback.
The start point is selected.
Press A-B RPT again.
The end point is selected. Playback
starts at the point that you selected.
Playback stops at the end point, re-
turns to Point A automatically, then
starts again.
A-B repeat playback allows you to repeat material between
two selected points.
2
PLAY MODE
A-B RPT
Advanced playback (DVD)
2
Repeat
/Enter/Play Mode
Off
:
Chapter : Repeat
/Enter/Play Mode
Repeat Title
:
/Enter/Play Mode
Play Mode Off
Repeat Off
/Enter/Play Mode
:
:
Track
Play Mode Off
Repeat
:
:
/Enter/Play Mode
Repeat
Play Mode Off
All
:
:
/Enter/Play Mode
DVD
VCD
CD
A
Notes:
• n A-B repeat mode, subtitles near point A or B may not
appear.
• During the A-B Repeat Playback the ANGLE feature will
not operate.
• You may not be able to set A-B Repeat, depending on
the scenes of the DVD.
• A-B repeat does not work with an interactive DVD.
To resume normal playback
Press A-B RPT again.
“
Off
” appears on the screen.
AB
Folder
Play Mode Off
Repeat
:
:
/Enter/Play Mode
DVD
VCD
CD
49
Basic playback (DVD)
Program Playback
Press PLAY M DE in the stop mode.
Press / to select Play Mode, then press
/ to select program.
Press / or / to select the programming
position. Use Numbered buttons (0-9) to input
the Track numbers.
• To program others, repeat Step 3.
• f you input a wrong number, press
CANCEL.
1
Press / or / to select “Program
Playback”
and press ENTER.
The programmes you selected will start
to playback in the order.
To return to normal playback, select
Play Mode: “Off”.
4
To cancel program play
Select “Clear” and press ENTER.
• The program is cancelled when
you open the disc tray or turn the
power off.
Program playback/Random playback
You can arrange the order of tracks on the disc.
VCD
CD
2
Repeat
1
2
3
4
5
6
7
8
9
10
11
12
Clear Program Playback
Play Mode
: Program
: Off
/Enter/0 9/Cancel/Play Mode
3
Program Playback
23 5 8 11
31
16 9 12
19 4710
Repeat
: Off
Play Mode
: Program
/Enter/0 9/Cancel/Play Mode
Clear
Program Playback
Random Playback
VCD
CD
Press PLAY M DE in the stop mode.
Press / to select Play Mode, then press
/ to select “Random”.
1
Press PLAY .
The Random Playback will start.
3
2
Repeat
Play Mode : Random
: Off
/Enter/Play Mode
ENTER
▲/▼//
PLAY MODE
PLAY
0-9
Advanced playback (DVD)
50
C anging angles/Title selection/DVD menu
Changing Angles
Press ANGLE during playback.
The current angle will appear.
Advanced playback (DVD)
DVD
When playing back a disc recorded with multi-angle facility, you can change the angle that you are viewing the scene
from.
1
1/9
Press ANGLE repeatedly until the desired angle
is selected.
2
Note:
Depending on the DVD, you may not be able to change the
angles even if multi-angles are recorded on the DVD.
Title Selection
Press T P MENU during playback.
Title menu appears on the screen.
Press / or / to select the desired title.
DVD
Two or more titles are recorded on some discs. f the title menu is recorded on the disc, you can select the desired title.
1
Press ENTER or PLAY.
The playback of the selected title will
start.
3
Note:
Depending on the DVD, you may not be able to select the title.
Depending on the DVD, a "title menu" may simply be called a
"menu" or "title" in the instructions supplied with the disc.
2
DVD Menu
Press MENU during playback.
The DVD menu appears on the screen.
• Press MENU again to resume
playback at the scene when you
pressed MENU.
Press / or / to select the desired item.
DVD
Some DVDs allow you to select the disc contents using the menu.
When you play back these DVDs, you can select the subtitle language and sound-track language,etc. using the menu.
1
Press ENTER.
The menu continues to another
screen. Repeat steps 2 and 3 to set
the item completely.
3
2
ANGLE
ENTER
▲/▼//
TOP MENU
DVD/VCR
PLAY
MENU
51
Advanced playback (DVD)
During disc playback press AUDI .
Press or to select “ n”.
1
Changing soundtrack language
1
2
Press AUDI during playback.
The current soundtrack language will
appear.
Press AUDI repeatedly until the desired lan-
guage is selected.
The on-screen display will disappear
after a few seconds.
C anging soundtrack language/
Setting surround sound
You can select the language when you play a multilingual disc.
Notes:
• f the desired language is not heard after pressing the
button several times, the language is not recorded on
the disc.
• Changing soundtrack language is cancelled when you
open the disc tray or turn the power off. The initial default
language or available language will be heard if the disc
is played back again.
• f desired language is not selected after pressing the
button several times, the language is not recorded on
the disc.
AUD O
2/8 Fra Dolby Digital
Spatializer Off
1/8 Eng Dolby Digital
Spatializer Off
/
In case of VIDE CD playback
Audio type changes as follows each time you press AUDI .
LR
Spatializer Off
L
Spatializer Off
R
Spatializer Off
Setting surround sound
This DVD/VCR equipped with a “SPAT AL ZER V RTUAL SURROUND”. t can produce the effect of being in a cinema or
a concert hall.
Spatializer
®
3-Dimensional Sound Processing provided by
Desper Products. nc.
Certain audio features of this product manufactured under
a license from Desper Products, nc., Spatializer
®
and the
circle-in-square device are trademarks owned by Desper
Products, nc.
2
To cancel Surround mode:
Follow the left steps 1~2, then press or to select the
“Off” position.
Notes:
•
f the selected language is not recorded on the disc, the
original language will be heard.
• The “SPAT AL ZER V RTUAL SURROUND” is effective
only for the sound of disc.
2/8 Fra Dolby Digital
Spatializer On
DVD
VCD
CD
DVD
VCD

52
Advanced playback (DVD)
Subtitles/Karaoke playback
Turning the subtitles on and off
Press SUB TITLE during playback until “ ff”
appears.
When playing back a disc recorded with subtitles, you can turn the subtitles on or off.
SUB T TLE
DVD
Note:
Depending on the DVD, you may not be able to turn
the subtitles on even if they are recorded on it.
Depending on the DVD, you may not be able to turn
the subtitles off.
Off
Changing the subtitle language
Press SUBTITLE repeatedly during playback until
your desired language appears.
The on-screen display will disappear after a few
seconds.
You can select the language when playing back a disc recorded with multi-lingual subtitles.
DVD
Notes:
• Changing subtitle language is cancelled when you open
the disc tray or turn the power off.
• Depending on the DVD, you may not be able to change
the subtitles even if multilingual subtitles are recorded
on it. While playing the DVD, the subtitle may change
when: -you open or close the disc tray -you change the
title.
• n some cases, the subtitle language is not changed to
the selected one immediately.
1
1/32 Eng
2
Karaoke playback
During DVD KARA KE disc playback, press
AUDI .
Press or to select “ n”.
ff : The primary vocal is not output.
n:The primary vocal is output
when it is recorded on the disc.
You can turn the vocal on or off recorded on the DVD KARAOKE.
DVD
Notes:
• The vocal output feature is used during playback of
Dolby Digital (multi-channel) recorded DVD KARAOKE
discs. This feature allows you to turn off vocal audio
tracks, or restore them for background accompaniment.
• When playing KARAOKE, connect appropriate audio
equipment such as an amplifier to the DVD/VCR.
1
2
2/8 Fra Dolby Digital
On
/
AUD O
53
Advanced playback (DVD)
Setting the aspect ratio of TV screen
1
Press SET UP in the stop mode or No Disc.
Press or to select “Picture”.
Press or ENTER, then press or to select
“Tv Screen”.
Press or ENTER.
Press or to select your desired screen
type, then press ENTER.
ENTER
▲/▼//
Setting t e aspect ratio of TV screen
You can select the aspect ratio for your TV.
The following pages describe the setup/operation in DVD mode.
DVD
RETURN
SET UP
/Enter/Setup/Return
Language Picture Parental OtherSound
2
Tv Screen
Display On
4:3
/Enter/Setup/Return
Language Picture Parental OtherSound
3
Tv Screen
Display On
4:3 4:3
16:9
4:3
/Enter/Setup/Return
Language Picture Parental OtherSound
Function setup (DVD)
Function setup (DVD)
You have the following screen sizes to choose from:
4:3 Normal TV
Select this mode when connecting to a conventional TV.
When playing back a wide screen-DVD disc, it displays
the wide picture with black bands at the top and bottom of
screen.
4:3 PAN SCAN
t displays the wide picture on the whole screen with left
and right edges automatically cut off.
16:9 WIDE SCREEN
Select this mode when connecting to a wide-screen TV.
A wide screen picture is displayed full size.
To make SETUP screen disappear, press SET UP
or RETURN while the SETUP screen is being
displayed.
4
Note:
f the DVD disc is not formatted in the pan & scan style, it
displays 4:3 style.
54
00:34:56 01:12:33 00:34:56 01:12:33
1/9
Title 1/99
1/8
1/32
Chapter 1/999
Eng DolbyDigital
Eng
Each Press of DISPLAY, the status display of the disc
will appear on the screen and change as follows.
DVD
To make status display disappear, press DISPLAY again.
Setting on screen display
1
Press SET UP in the stop mode or No Disc.
Press or to select “Picture”.
Press or ENTER, then press or to select
“Display”.
Setting on screen display/Status display of disc
DVD
On screen display can be switched on or off when you press the buttons.
Function setup (DVD)
2
Tv Screen
Display On
4:3
/Enter/Setup/Return
Language Picture Parental OtherSound
/Enter/Setup/Return
Language Picture Parental OtherSound
Press / or ENTER to select “ n” or “ ff”.
N: On screen displays appear
when you press the buttons
(factory setting).
FF: On screen displays do not
appear when you press any
buttons.
To make SETUP screen disappear, press SET UP or
RETURN while the SETUP screen is being displayed.
3
4
Tv Screen
Display Off
4:3
/Enter/Setup/Return
Language Picture Parental OtherSound
Status display of disc
DVD
VCD
CD
When you playback the CD disc, the status display will
appear on the screen and continue displaying.
ENTER
▲/▼//
RETURN
SET UP
D SPLAY
AUDI CD
VIDE CD
34:56 71:33
Track 11/99
00:12 04:32
Track 1/3
PBC
00:12 04:32
55
Function setup (DVD)
Dynamic Range Control
Press SET UP in the stop mode.
Press or to select “Sound”.
Press or ENTER to select “DRC”.
Press or ENTER, then press or to select
desired setting.
Max: Full dynamic range is
increased.
Std: Full dynamic range is
maintained.
Min: Dynamic range is reduced.
1
To make SETUP screen disappear, press SET UP
or RETURN while the SETUP screen is being
displayed.
4
Dynamic Range Control
DRC (Dynamic Range Control) enables you to control the dynamic range
so as to achieve a suitable sound for your equipment. ENTER
▲/▼//
RETURN
SET UP
DVD
/Enter/Setup/Return
Language Picture Parental OtherSound
2
DRC
Std
/Enter/Setup/Return
Language Picture Parental OtherSound
3
DRC
Max
Std
Min
/Enter/Setup/Return
Language Picture Parental OtherSound
Std
Notes:
• This function works only during playback of Dolby Digital
recorded discs.
• The level of Dynamic Range Reduction may differ
depending on DVD video disc.

56
Parental control setting
Some discs are specified not suitable for children. Such discs can be limited
not to play back with the unit.
Parental control setting
Press SET UP in the stop mode or No Disc.
Press or to select “Parental”. Then press
or ENTER.
Press or to select “Parental”, then press
or until the level you require appears.
• Level ff : The parental control
setting does not function.
• Level 8 : All DVD software can
be played back.
• Level 1 : DVD software for
adults cannot be
played back.
•Select from the level 1 to level 8. The
limitation will be more severe as the
level number is lower.
Press or to select “Password”.
Press number buttons (0-9) to input a 4-digit password.
Be sure to remember this number!
• f you input a wrong number,
press CANCEL.
DVD
Function setup (DVD)
1
2
3
Press ENTER to store the password.
Note: Now the rating is locked and the
setting cannot be changed unless you
enter the correct password.
Press SET UP or RETURN to remove the paren-
tal control screen.
4
5
Language
Password
Parental
Picture Parental Other
Off
09/Cancel
/Enter/Setup/Return
Sound
Password
Parental
1
/Enter/Setup/Return
Language Picture Parental OtherSound
Password
Parental
1
1
2 3 4
09/Cancel
/Enter/Setup/Return
Language Picture Parental OtherSound
Password
Parental
1
09/Cancel
/Enter/Setup/Return
Language Picture Parental OtherSound
Notes:
• If each setup (P. 53~62) has been completed, the
unit can always be worked under the same
conditions (especially with DVD discs).
Each setup will be retained in the memory if you turn
the power off.
• Depending on the discs, the unit cannot limit playback.
• Some discs may not be encoded with specific rating
level information though its disc jacket says "adult." For
those discs, the age restriction will not work.
ENTER
▲/▼//
RETURN
SET UP
0-9
CANCEL
57
Function setup (DVD)
To change the parental level
1
2
Press SET UP in the stop mode or No Disc.
Press
or to select “Parental”.
Then press or ENTER.
Press number buttons (0-9) to enter the
password you have stored.
Press ENTER.
The rating is now unlocked.
Press or to select “Parental”, then press
or to change the parental level.
To c ange t e parental level
DVD
Note:
Do not forget the password. f you forget the password,
contact the dealer that you purchased the unit from.
Password
Parental
1
/Enter/Setup/Return
0 9/Cancel
Language Picture Parental OtherSound
Password
Parental
1
1 2 3 4
/Enter/Setup/Return
09/Cancel
Language Picture Parental OtherSound
3
Password
Parental
1
09/Cancel
/Enter/Setup/Return
Language Picture Parental OtherSound
4
Password
Parental
5
/Enter/Setup/Return
Language Picture Parental OtherSound
Press or to select “Password”, then press
number buttons (0-9) to enter the password.
Note: You can change the password
if you want.
Press ENTER.
Now the parental level is changed and
locked.
Press SET UP or RETURN
to remove the parental control screen.
5
6
Password
Parental
5
1 2 3 4
/Enter/Setup/Return
0 9/Cancel
Language Picture Parental OtherSound
Password
Parental
5
0 9/Cancel
/Enter/Setup/Return
Language Picture Parental OtherSound
7
ENTER
▲/▼//
RETURN
SET UP
0-9
58
Temporary disabling of rating level by DVD disc
Depending on the DVD disc, the disc may try to temporarily cancel the
rating level that you have set.
t is up to you to decide whether to cancel the rating level or not.
Temporary disabling of rating level by DVD disc
Load a DVD disc and press PLAY or PEN/
CL SE on the unit (see P. 42).
If the DVD disc has been designed to temporarily
cancel the Rating level, the screen which follows
the “Reading” screen will change, depending on
which disc is played. If you select “YES” with the
ENTER key, “Your disc exceeds The parental
control level#.” screen will then appear.
If you wish to cancel the set rating level temporarily,
select “Parental Control Level” with or , then
press ENTER. If the 4-digit password at step 3 on
P.56 has been set, the password entering screen
will appear as shown in step 4 below.
Alternatively, if the password has not been set,
playback will commence. If you don’t know (or have
forgotten) the password, select “Cancel Picture”.
The setting screen will disappear. Press PEN/
CL SE to remove the disc.
Note:
This temporary cancellation of rating level will be kept until
the disc is ejected.
When the disc is ejected, the original rating level will be set
again automatically.
Function setup (DVD)
DVD
1
Enter the password with number buttons (0-9).
Then press ENTER.
f you interrupt the entering, press
RETURN.
Playback will commence if the entered
password was correct.
4
2
Your disc exceeds
the parental control level#.
Parental Control Level
Cancel Picture
/Enter/Return
3
Please enter the
4 digit password
9/ Cancel/ReturnEnter/0
-
5
ENTER
▲/▼
RETURN
PLAY
0-9
OPEN/CLOSE
welcome
Reading
59
Function setup (DVD)
Setting setup language
Press DVD/VCR to select the DVD mode.
“Reading” changes to “No Disc”.
( f DVD disc has already loaded, the
playback will start automatically.)
Press SET UP in the stop mode.
Press or to select “ ther”.
Press or ENTER to select “ SD Language”.
DVD
VCD
CD
1
welcome
Reading
Language Other
/Enter/Setup/Return
Picture ParentalSound
2
3
Language
OSD Language English Other
/Enter/Setup/Return
Picture ParentalSound
Press or ENTER and then press or to
select desired language (e.g. English), then
press ENTER.
To make SETUP screen disappear, press SET UP
or RETURN while the SETUP screen is being
displayed.
4
5
Language
OSD Language English English
Francais
Espanol
Other
/Enter/Setup/Return
Picture ParentalSound
If the unit does not operate properly: Static electricity,
etc., may affect the player's operation. Disconnect the
AC power cord once, then connect it again.
DVD/VCR
ENTER
▲/▼//
RETURN
SET UP
Setting setup language
The setup language can be selected.

60
Function setup (DVD)
Setting menu language
1
Press SET UP in the stop mode or No Disc.
Press or to select “Language”.
Press or ENTER, then press or to select
“Menu”.
Press or ENTER.
Press or to select your desired language,
then press ENTER.
English, Francais, Espanol
The selected language is the first-
priority Menu language.
ther: Other language can be
selected (See the Language code list
on page 63).
ENTER
▲/▼//
Setting menu language
You can select the language of the disc menu messages of DVDs.
DVD
To make SETUP screen disappear, press SET UP
or RETURN while the SETUP screen is being
displayed.
4
RETURN
SET UP
2
3
/Enter/Setup/Return
Language Picture Parental OtherSound
Language Picture Parental OtherSound
Menu
Subtitle
Audio
English
Automatic
English
/Enter/Setup/Return
Menu
Subtitle
Audio
English
Automatic
English Francais
English
Espanol
Other
/Enter/Setup/Return
Language Picture Parental OtherSound
61
Function setup (DVD)
Changing subtitle language
1
Press SET UP in the stop mode or No Disc.
Press or to select “Language”.
Press or ENTER, then press or to select
“Subtitle”.
Press or ENTER.
Press or to select your desired language,
then press ENTER.
English, Francais, Espanol
The subtitle is displayed with the selected
language if it is recorded on the disc.
ther:
f you want to select another language, enter
the language code (see the language code
list on page 63).
Automatic:
•The unit will automatically select the
same language in the AUD O setting.
•When the unit selects the same
language as the
AUD O, the subtitles
will not appear during playback.
•When you do not use the same
language as
the AUD O, the subtitles
will appear during playback.
ff:
Subtitles do not appear.
DVD
2
To make SETUP screen disappear, press SET UP
or RETURN while the SETUP screen is being
displayed.
4
ENTER
▲/▼//
RETURN
SET UP
Note:
f the selected language is not recorded on the disc, the first-
priority language is selected.
Menu
Subtitle
Audio
English
Automatic
English
/Enter/Setup/Return
Language Picture Parental OtherSound
/Enter/Setup/Return
Language Picture Parental OtherSound
3
Menu
Subtitle
Audio
English
Automatic
English Francais
English
Espanol
Other
Automatic
Off
/Enter/Setup/Return
Language Picture Parental OtherSound
C anging subtitle language
The same subtitle language can always be selected even if you replace
the disc or turn the power off.
62
Setting audio soundtrack language
Press SET UP in the stop mode or No Disc.
Press or to select “Language”.
Press or ENTER, then press or to
select “Audio”.
Press or ENTER.
Press or to select your desired Audio
Language, then press ENTER.
• English, Francais, Espanol:
The language you have selected
will play if it is recorded on the disc.
• ther: f you want to select
another language, enter the
language code (See the Language
code list on page 63).
• riginal: The unit will select the
first priority language of each disc.
1
To make SETUP screen disappear, press SET UP
or RETURN while the SETUP screen is being
displayed.
4
Setting audio soundtrack language
The same audio soundtrack language can always be selected by your unit
even if you replace the disc or turn the power off. ENTER
▲/▼//
RETURN
SET UP
DVD
2
3
/Enter/Setup/Return
Language Picture Parental OtherSound
Language Picture Parental OtherSound
Menu
Subtitle
Audio
English
Automatic
English
/Enter/Setup/Return
Menu
Subtitle
Audio
English
Automatic
English Francais
English
Espanol
Other
Original
/Enter/Setup/Return
Language Picture Parental OtherSound
Note:
f the selected language is not recorded on the disc, the
original language will be heard.
Function setup (DVD)
63
thers
Language code list
Enter the appropriate code number for the initial settings "AUD O", "SUBT TLE" and/or "MENU LANGUAGE" (see pages 60-62).
Language code list
Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919
Afar 1111 Finnish 1619 Lithuanian 2230 Slovak 2921
Afrikaans 1116 French 1628 Macedonian 2321 Slovenian 2922
Albanian 2927 Frisian 1635 Malagasy 2317 Somali 2925
Amharic 1123 Galician 1722 Malay 2329 Spanish 1529
Arabic 1128 Georgian 2111 Malayalam 2322 Sundanese 2931
Armenian 1835 German 1415 Maltese 2330 Swahili 2933
Assamese 1129 Greek 1522 Maori 2319 Swedish 2932
Aymara 1135 Greenlandic 2122 Marathi 2328 Tagalog 3022
Azerbaijani 1136 Guarani 1724 Moldavian 2325 Tajik 3017
Bashkir 1211 Gujarati 1731 Mongolian 2324 Tamil 3011
Basque 1531 Hausa 1811 Nauru 2411 Tatar 3030
Bengali; Bangla 1224 Hebrew 1933 Nepali 2415 Telugu 3015
Bhutani 1436 Hindi 1819 Norwegian 2425 Thai 3018
Bihari 1218 Hungarian 1831 Oriya 2528 Tibetan 1225
Breton 1228 celandic 1929 Panjabi 2611 Tigrinya 3019
Bulgarian 1217 ndonesian 1924 Pashto, Pushto 2629 Tonga 3025
Burmese 2335 nterlingua 1911 Persian 1611 Turkish 3028
Byelorussian 1215 rish 1711 Polish 2622 Turkmen 3021
Cambodian 2123 talian 1930 Portuguese 2630 Twi 3033
Catalan 1311 Japanese 2011 Quechua 2731 Ukrainian 3121
Chinese 3618 Javanese 2033 Rhaeto-Romance 2823 Urdu 3128
Corsican 1325 Kannada 2124 Romanian 2825 Uzbek 3136
Croatian 1828 Kashmiri 2129 Russian 2831 Vietnamese 3219
Czech 1329 Kazakh 2121 Samoan 2923 Volapük 3225
Danish 1411 Kirghiz 2135 Sanskrit 2911 Welsh 1335
Dutch 2422 Korean 2125 Scots Gaelic 1714 Wolof 3325
English 1524 Kurdish 2131 Serbian 2928 Xhosa 3418
Esperanto 1525 Laothian 2225 Serbo-Croatian 2918 Yiddish 2019
Estonian 1530 Latin 2211 Shona 2924 Yoruba 3525
Faroese 1625 Latvian, Lettish 2232 Sindhi 2914 Zulu 3631
Language Name Code Language Name Code Language Name Code Language Name Code

64
thers
Before calling service personnel
Check the following guide for the possible cause of a problem before contacting service.
SYMPT MS P SSIBLE S LUTI NS
• Make sure the power cord is plugged in.
• Try another AC outlet.
• Power is off, check fuse or circuit breaker.
• Unplug unit, then plug it back in.
• Select the DVD or VCR mode before operating.
DVD/VCR does not operate.
DVD/VCR PAGE
5
–
–
5
30,42
The remote control does not function.
• Aim at the remote control at the remote sensor.
• Operate within Approx. 7 Meters or reduce the light in the room.
• Clear the path of the beam.
• The batteries are weak. Replace the batteries.
• Check the batteries are inserted correctly.
13
DVD
No picture.
• Antenna connection is not correct or antenna cable is disconnected.
• The video channel is not in the correct position or the TV is not set to the video
channel 3 or 4.
• Check the unit is connected correctly.
• The video input selector of the TV is not set to V DEO. Set to V DEO (or
equivalent).
• Channel is set to the external mode.
No sound. • Check the unit is connected correctly.
• Check the input selector of the amplifier is set properly.
• The unit is in the Special playback mode.
14~17
22
14~19
–
–
14~19
–
31,34
• Select proper language in the menu options.Display is not shown in your language. 59
Playback doesn’t start. • No disc is inserted. • The disc may be dirty. Clean up the disc.
• The unit cannot play DVD-ROMs, etc.
Stopping playback, slow-motion play, repeat
play, or memory play, etc. cannot be
performed. • Some discs may not do some of the functions.
42
42
42
–
No CATV reception • Check all CATV connections.
• Station or CATV system problems, try another station. 16,17
Noise bars on screen. • Tracking adjustment beyond range of automatic tracking circuit. Try Manual
tracking adjustment.
• Video heads are dirty.
• The tape is worn or damaged.
VCR • The erase prevention tab of the video cassette is broken off.
• The unit is in the external input mode.
TV recording does not work. 29,34
Timer recording does not work. • The time is not set correctly.
• The recording start/end time is not set correctly.
• The T MER has not been pressed ( is not lit).
24
37
37
31
31
–
No subtitle • Some discs have no subtitles.
• Subtitles are cleared. Press SUB T TLE.
Angle cannot be changed. • Multi-angles are not recorded on the DVD disc.
• The function is prohibited with the unit or the disc.
appears on the screen.
51
50
–
No 4:3 (16:9) picture • The setup does not match your TV.
No on-screen display • Select Display On.
53
54
No surround sound • The setup does not match your stereo system.
The unit or remote operation key is not
functioning. • Turn off the unit and unplug the AC power cord for several minutes, then replug it.
20
Playback does not start when the title is
selected. • Check the Parental setup.
Audio soundtrack and/or subtitle language
is not changed when you play back a DVD. • Multilingual language is not recorded on the DVD disc.
–
56,57
61,62
Symptoms and correction
65
thers
AC 120V 60Hz
Operation: 20W, Stand by: 4W
9.9lbs (4.5 kg)
Width : 16-15/16 inches (430 mm)
Height : 3-7/8 inches (99 mm)
Depth : 12-3/8 inches (314.5 mm)
181 channel freq. synthesized
VHF 2-13
UHF 14-69
CATV 125 Channels
UHF/VHF n/Out : 75 ohm coaxial
Channel 3 or 4, Switchable
NTSC
4 Rotary heads
Hi-Fi sound - 2 Tracks / MONO sound - 1 Track
20Hz to 20,000Hz
More than 90dB
Approx. 1minute and 48 seconds (with T-120 Cassette Tape)
DVD (12cm, 8cm), CD (12cm, 8cm)
DVD linear sound: 48 kHz sampling 4Hz-22kHz
96 kHz sampling 4Hz-44 kHz
90dB (DVD)
0.008% (DVD)
Below measurable level (DVD)
90dB (DVD)
Temperature: 5˚C-40˚C (41˚F-104˚F), Operating status: Horizontal
Power supply
Power consumption
Weight
Dimensions
Tuner
Antenna input/output
RF channel output
Color system
Video head
Audio track
Hi-Fi frequency response
Hi-Fi dynamic range
F.FWD/REW time at 25˚C (77˚F)
Applicable disc
Frequency range
S/N ratio
Harmonic distortion
Wow and flutter
Dynamic range
Operating conditions
Specifications
General / input / output / supplied accessories
GENERAL
Input/ utput
DVD/VCR
Video input 1.0 V (p-p), 75 Ω, negative sync., pin jack x 2
Video output 1.0 V (p-p), 75 Ω, negative sync., pin jack x 1
Audio input 300mV (rms), 50kΩ. negative sync., pin jack (L/R) x 2
Audio output 300mV (rms), 1kΩ. negative sync., pin jack (L/R) x 1
DVD
S video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini D N 4-pin × 1
(C) 0.286 V (p-p), 75 Ω
Component video output (Y) 1.0 V (p-p), 75 Ω, negative sync., pin jack × 1
(PB)/(PR) 0.7 V (p-p), 75 Ω, pin jack × 2
Audio output (B TSTREAM/PCM 0.5V (p-p), 75 Ω, pin jack × 1
COAX AL)
Audio output (B TSTREAM/PCM Optical connector × 1
OPT CAL)
Audio output (ANALOG) 2.0 V (rms), 220 Ω, pin jacks (L, R) × 1
Supplied accessories
Audio/video cable ................................................. 1
Remote control (SE-R0066) ................................. 1
Batteries (AAA) ..................................................... 2
75 ohm coaxial cable ............................................ 1
• Designs and specifications are subject to change without notice.
66
thers
LIMITED WARRANTY DVD VIDE PLAYER
Toshiba America Consumer Products, nc. (“TACP”), Toshiba Hawaii (“TH ”) and Toshiba Canada Limited (“TCL”) make the
following limited warranties. These limited warranties extend to original purchaser or any person receiving this set as a gift
from the original purchaser and to no other purchaser or transferee.
Limited Ninety (90) Day Warranty
TACP/TH warrant this product against defects in materials
or workmanship for a period of ninety (90) days after the
date of original retail purchase. During this period, TACP/
TH will repair or replace a defective product or part, at their
option, with a new or refurbished product or part without
charge to you. You must deliver the entire product to a
TACP/TH Authorized Service Station. You are responsible
for all transportation and insurance charges for the unit to
and from the Authorized Service Station. f you live in the
U.S.A. you may, at your option, return your DVD Unit to:
Toshiba America Consumer Products nc.
Returns Center
1420C Toshiba Dr.
Lebanon, TN 37087
Upon receipt we will, at our option, exchange the DVD Unit
with a new or refurbished unit. Canadian consumers are
requested to contact TCL. In Hawaii consumers are
requested to contact THI.
Limited ne (1) Year Warranty
TACP/TH further warrant the parts in this product against
defects in materials or workmanship for a period of one (1)
year after the date of original retail purchase. During this
period, TACP/TH will repair or replace a defective product
or part, at their option, with a new or refurbished product or
part without charge to you, except that if a defective part is
replaced after ninety (90) days from the date of the original
retail purchase you pay labor charges involved in the
replacement. You must also deliver the entire product to a
TACP/TH Authorized Service Station. You are responsible
for all transportation and insurance charges for the unit to
and from the Authorized Service Station. f you live in the
U.S.A. you may, at your option, return your DVD Unit to:
Toshiba America Consumer Products nc.
Returns Center
1420C Toshiba Dr.
Lebanon, TN 37087
Upon receipt we will, at our option, exchange the DVD Unit
with a new or refurbished unit. Canadian Consumers are
requested to contact TCL. In Hawaii consumers are
requested to contact THI.
Rental Units
The warranty for rental units begin with the first rental or
thirty (30) days from the date of shipment to the rental firm,
whichever comes first.
Commercial Units
Products sold and used for commercial use have a limited
ninety (90) day warranty for all parts and labor.
wner’s Manual
You should read the owner’s manual thoroughly before
operating this product. You should complete and mail the
enclosed Demographic card within ten (10) days after you,
or the person who has given you this product as a gift,
purchased this product. This is one way to enable TACP to
provide you with better customer service and improved
products. Failure to return the card will not affect your rights
under this warranty.
Your Responsibility
The above warranties are subject to the following
conditions:
(1) You must retain your bill of sale or provide other proof of
purchase.
(2) You must notify a TACP/TH /TCL /Authorized Service
Station within thirty (30) days after you discover a
defective product or part.
(3) All warranty servicing of this product must be made by a
TACP/TH /TCL Authorized Service Station.
(4) U.S.A. warranties are effective only if the product is
purchased and operated in the Continental U.S.A. or
Puerto Rico.
(5) Labor service charges for set installation. Set up,
adjustment of customer controls and installation or
repair of antenna systems are not covered by this
warranty. Reception problems caused by inadequate
antenna systems are your responsibility.
(6) Warranties extend only to defects in materials or
workmanship as limited above and do not extend to any
product or parts which have been lost or discarded by
you or to damage to products or parts caused by
misuse, accident, damage caused by Acts of God, such
as lighting or fluctuations in electric power, improper
installation, improper maintenance or use in violation of
instructions furnished by us; or to units which have
been altered or modified without authorization of TACP/
TH /TCL or to damage to products or part thereof which
have had the serial number removed, altered, defaced
or rendered illegible.
(7) Should you elect to return your DVD Unit to TACP after
the ninety (90) days and within one (1) year, or after the
warranty period has expired: Call (800)-631-3811 to
receive information concerning an exchange price.
Payment must be enclosed with product in the form of a
certified check or money order including reason for
return.
(8) Physically damaged DVD Units are not acceptable for
repair or exchange whether in or out of warranty and
will be returned as received.
(Continued)
66
thersthers
67
thers
How to btain Warranty Service
(1) Refer to the troubleshooting guide in your owner’s manual. This check list may solve your problem.
(2) n the U.S.A., only call the TACP toll free number 800-631-3811, or if in Hawaii or Canada see listing below within (30)
days after you find a defective product or part.
(3) Arrange for the delivery of the product to the TACP/TH /TCL Authorized Service Station or TACP Return Center.
Products shipped to the Service Station must be insured and safely and securely packed, preferably in the original
shipping carton, and a letter explaining the defect and also a copy of the bill of sale or other proof of purchase must be
enclosed.
In Hawaii contact:
Toshiba Hawaii nc.
327 Kamakee Street
Honolulu, HA 96814
(808)-521-5377
In Canada contact:
Consumer Electronics Group
191 McNabb Street
Markham, Ontario L3R 8H2
(905)-470-5400
Consumer Electronics Group
22171 Fraserwood Way
Richmond, B.C. V6W 1J5
(604)-303-2500
Consumer Electronics Group
18050 Trans canada
Kirkland, Quebec H9J 4A1
(514)-390-7766
Toll Free
800-631-3811
All warranties implied by state law, including the implied warranties of merchantability and fitness for a particular purpose, are
expressly limited to the duration of the limited warranties set forth above. With the exception of any warranties implied by state
law as hereby limited, the foregoing warranty is exclusive and in lieu of all other warranties, guarantees, agreements and
similar obligations of manufacturer or seller with respect to the repair or replacement of any parts. n no event shall TACP/TH
be liable for consequential or incidental damages.
No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of these warranties in
any manner whatsoever. The time within which an action must be commenced to enforce any obligation of TACP/TH arising
under the warranty or under any statute, or law of the United States or any state thereof, is hereby limited to ninety (90) days
from the date you discover or should have discovered, the defect. This limitation does not apply to implied warranties arising
under state law.
This warranty gives you specific legal rights and you may also have other rights which may vary from state to state. Some
states do not allow limitation on how long an implied warranty lasts, when an action may be brought, or the exclusion or
limitation of incidental or consequential damages, so the above provisions may not apply to you.
ATTENTI N CANADIAN C NSUMERS:
Canadian consumers are requested to complete the special Canadian “Warranty Registration Form” enclosed, and forward
this completed form with a copy of bill of sale to TOSH BA OF CANADA to “Register and Validate” their warranty. Product
must be purchased from an Authorized Canadian Dealer. Products purchased in the U.S.A. and used in Canada are not
covered by these warranties.
IMP RTANT: PACKING AND SHIPPING INSTRUCTI N
When you send the product to a Service Station, you must use the original carton box and packing material, then insert the
original carton box containing the unit into another carton using more packing material.
LIMITED WARRANTY DVD VIDE PLAYER (continued)
In the Continental United States contact:
67

CAUTION
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CARE-
FULLYAND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE,
CONTACTAN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE.
VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT
STARE INTO BEAM.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS,
21 CFR SUBCHAPTER J.
A1-1

IMPORTANT SAFEGUARDS
1.
2.
3.
4.
5.
6.
7.
8.
8A.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
ATTACHMENTS
Do not use attachments not recommended by the unit’s manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near
a swimming pool.
ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall,
causing serious injury, and serious damage to the unit. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance and cart combination to overturn.
VENTILATION
Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure reliable operation of the unit,
and to protect it from overheating. These openings must not be blocked or covered. The openings should never be blocked by
placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat
source. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been adhered to.
POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the type of
power supply to your home, consult your appliance dealer or local power company. For units intended to operate from battery
power, or other sources, refer to the operating instructions.
GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will
fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug. If your unit is equipped with a 3-wire grounding-type plug, a plug having a third (grounding)
pin, this plug will only fit into a grounding-type power outlet. This too, is a safety feature. If you are unable to insert the plug into
the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power line
surges.
POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits,
or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken
to keep from touching such power lines or circuits, as contact with them might be fatal.
OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out parts that could
result in fire or electric shock. Never spill or spray any type of liquid into the unit.
OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded so as to
provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/
NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A
A1-2
