Satellite A505-S6997 Page 1 of 4

Satellite A505 Detailed Product Specification1

Model Name: A505-S6997 Part Number: PSAT3U-00U002 UPC: 883974309795

Operating System C1 2

•Genuine Windows®7 Home Premium 64-bit

Processor3and Graphics4

•Intel®Core™ 2 Duo processor P7450

o2.13GHz, 3MB L2 Cache, 1066MHz FSB

•Mobile Intel®GM45 Express Chipset

•NVIDIA®GeForce®GT 230M with 1GB GDDR3 discrete graphics

memory plus up to 1790MB dynamically allocated shared graphics

memory using NVIDIA®TurboCache™ technology.

oTotal Available Graphics memory 2814MB

Memory5

•Configured with 4GB DDR3 1066MHz (max 8GB)

Storage Drive6

•500GB (5400 RPM) Serial ATA hard disk drive

Fixed Optical Disk Drive7

•Blu-ray Disc™ ROM with SuperMulti DVD±R/RW Double Layer drive

Display8

•16.0” diagonal widescreen TruBrite® TFT LCD display at 1366x768

native resolution (HD)

oNative support for 720p content

oEdge-to-Edge display

Sound

•Built-in harman/kardon®stereo speakers

Input Devices

•104 key US LED backlit keyboard with 10-key

•TouchPad™ pointing device with multi-touch control

•TouchPad™ Enable/Disable button

•Media Control Buttons:

oeco utility button (Energy-saving mode)

oMute

oMedia

oCD/DVD control buttons

oVolume up, volume down

Communications

•Webcam and microphone

•Modem9

•10/100 Ethernet

•Realtek®802.11b/g/n wireless LAN10

Expandability

•2 main memory slots. Both slots may be occupied.

•ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)

•Memory Card Reader

oSecure Digital, Secure Digital High Capacity, Memory Stick™,

Memory Stick PRO™, Multi Media Card, xD Picture Card

[shared slot]

Ports

•Video

oRGB (monitor) output port

oHDMI-CEC

•Audio

oS/P DIF output port (shared with headphone port)

oMicrophone input port

oHeadphone output port

•Data

oi.LINK™ IEEE-1394

o4 USB v2.0 ports

o3 x USB v2.0 ports

o1 x eSATA/USB combo port with USB Sleep and

Charge11

oRJ-45 LAN port

oRJ-11 modem port

•Security

oSlot for Security Lock

Physical Description

•Fusion™ Finish with Sonic Pattern in Black Onyx

•Dimensions (W x D x H ): 15.1” x 10.2” x 1.51”/1.69”

•Weight: Starting at 7.17 lbs., depending upon configuration12

Battery13

•9000 mAh (12 cell) Lithium Ion battery pack

Power Supply

•90W (19V x 4.74A) Auto-sensing ,100-240V/50-60Hz AC Adapter

•Dimensions (W x D x H): 5.2” x 2.3” x 1.2”

•Weight: starting at .81 lbs.

Software C1 14

•Toshiba Software and Utilities

oElectronic User’s Guide

oBluetooth Stack for Windows by Toshiba

oTOSHIBA Recovery Media Creator

oTOSHIBA ConfigFree®

oTOSHIBA Disc Creator

oTOSHIBA DVD Player

oTOSHIBA Power-saving eco utility

oTOSHIBA Hard Drive Impact Sensor (3D sensor)

oTOSHIBA Face Recognition

oTOSHIBA PC Health Monitor

oHard Disc Drive (HDD) Recovery

•Third-party Software

oMicrosoft®Windows Media Player

oMicrosoft®Works 9

oInternet Explorer 8

oAdobe®Acrobat®Reader

oGoogle™ Toolbar

oDolby®Sound Room®

oCorel® DVD MovieFactory®for TOSHIBA

oSun®Java™ 2 Runtime Environment

oWildTangent®Orb™ Game Console

•Trial Software

oNorton Internet Security™ 2009, 30-day trial

oMicrosoft®Office Home and Student 2007 Edition, 60-day trial

•Special Offers

oToshiba Online Backup

oNetZero®Internet Service

oSkype®

oIntuit®Quickbooks®Financial Center

Environmental Specifications

•This product is RoHS15 compatible

•Energy Star 5.0 Qualified

•EPEAT™ Gold Compliant

1 YEAR STANDARD LIMITED WARRANTY17

Operating Non-operating

Temperature

5° to 35° C -20° to 60° C

Relative Humidity

(non-condensing) 20% to 80% 10% to 90%

Thermal Gradient 15° C per hour (max) 20° C per hour (max)

Altitude

(relative to sea level) 0 to 3,000 meters

0 to 10,000 meters

Shock 10G 60G

Vibration 0.5G 1.0G

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A505-S6997 Page 2 of 4

•Includes International Limited Warranty for obtaining service when

traveling outside the United States.

Service Upgrades and Extensions

Toshiba offers many different enhanced services such as SystemGuard®,

On-Site Repair, and ServiceExpress to provide additional support to your

notebook PC. For a full description and complete list of programs and

program terms and conditions, please visit www.pcsupport.toshiba.com.

Accessories

For additional and most updated accessories, please visit

www.accessories.toshiba.com

Memory Upgrade

Part Number Description

PA3670U-1M4G Toshiba 4GB DDR2-800 Memory Module

Power

Part Number Description

PA3717U-1ACA Toshiba 120W Global AC Adapter

PA3534U-1BRS Toshiba Primary Li Ion Battery Pack (6 cell)

PA3727U-1BRS Toshiba Primary High Capacity Li Ion Battery Pack

(12 cell)

Expansion

Part Number Description

PA3575U-1PRP dynadock USB Docking Station with DVI/VGA port

PA3579U-1ETC Toshiba Universal Notebook/Projector Stand

Storage

Part Number Description

PA3556U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive, ReadyBoost

PA3556U-1M4G Toshiba 4GB USB Hi-Speed Flash Drive, ReadyBoost

PA3556U-1M8G Toshiba 8GB USB Hi-Speed Flash Drive, ReadyBoost

HDDR320E04XW Toshiba External USB Hard Drive, 320GB (White)

HDDR500E04XL Toshiba External USB Hard Drive, 500GB (Blue)

HDDR640E04XR Toshiba External USB Hard Drive, 640GB (Red)

Protection

Part Number Description

PA3611U-1ETC Toshiba Keyboard Protector

Bluetooth

Part Number Description

PA3573U-1ETA Toshiba Bluetooth Optical Tilt-Wheel Mouse

(Black/Silver)

PA3573U-1ETB Toshiba Bluetooth Optical Tilt-Wheel Mouse

(Black/Red)

Carrying Case

Part Number Description

PA1446U-1CS6 Toshiba 16" Envoy Ballistic Polyester Carrying Case

(Fits up to 16")

PA1448U-1RS6 Toshiba 16" Envoy Roller Case (Fits up to 16")

Subject to Change

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,

configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your

computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

Return Policy

Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information

Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on

individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the

TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.

Toshiba America Information Systems, Incorporated (“TAIS”)

9740 Irvine Boulevard

Irvine CA 92618

ToshibaDirect website: http://www.toshibadirect.com

TAIS website for resellers: http://sell.toshiba.com

TAIS PC Support website: http://pcsupport.toshiba.com

Satellite, ConfigFree and SystemGuard are registered trademarks of Toshiba America Information Systems, Inc. and/or Toshiba Corporation. All other

products and names mentioned are the property of their respective owners.

C164-bit computing:

64-bit computing requires that the following hardware and software requirements are met:

- 64-bit Operating System

- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)

- 64-bit Device drivers

- 64-bit applications

Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. See "Detailed Specs" for more information.

1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may not

have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,

please visit Toshiba's Web site at pcsupport.toshiba.com.

Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice

2Operating System. Also see 64-Bit Computing Legal Footnote, if applicable.

Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE

PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A505-S6997 Page 3 of 4

during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll

charges may apply).

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Offers. Offer terms, duration and product availability all subject to change without notice

3Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.

CPU performance in your computer product may vary from specifications under the following conditions:

1. use of certain external peripheral products

2. use of battery power instead of AC power

3. use of certain multimedia, computer generated graphics or video applications

4. use of standard telephone lines or low speed network connections

5. use of complex modeling software, such as high end computer aided design applications

6. use of several applications or functionalities simultaneously

7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)

8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are

approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).

CPU performance may also vary from specifications due to design configuration.

Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product

when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your

computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical

Service and Support for more information.

4Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features

utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.

Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary

depending on system memory size and other factors.

5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system

memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications

utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a

64-bit operating system can address 4 GB or more of system memory.

6Storage Drive (Internal HDD Capacity). One Gigabyte (GB) means 109 = 1,000,000,000 bytes and One Terabyte (TB) means 1012 = 1,000,000,000,000 bytes using powers of

10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes and 1TB = 240 =

1,099,511,627,776 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer includes one or more pre-installed operating

systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.

7Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical

drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical

media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or

optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.

Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.

8Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is

manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a

period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.

When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.

9Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary

depending on line conditions.

10 Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,

certain Wi-Fi® equipment.

11 USB Sleep & Charge.The "USB Sleep & Charge function" may not work with certain external devices even if they are compliant with the USB specification. In those cases, turn

the power of the computer ON to charge the device.

12 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.

13 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as

well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations

tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test. Recharge time varies depending on usage. Battery may not charge while

computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.

To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.

14 Software. Also see 64-Bit Computing Legal Footnote, if applicable.

Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.

Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE

PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed

This product specification is variable and subject to change prior to product launch.

TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.

Satellite A505-S6997 Page 4 of 4

during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll

charges may apply).

Microsoft® Office 2007 60-Day Trial Version: This trial software will work for 60 days after you first use it. You will not be able to use the software if you do not activate it as

described the first time you use the software. You can activate the software by Internet. Internet service charges may apply. If you want to keep the software after the 60-day trial

period, you must convert to the perpetual version. You can convert online by following the conversion instructions presented during setup and paying the required fees.

15 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment

(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements

and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.

16 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when

operating within the recommended temperature range.
