Toshiba Satellite A60 User manual

TOSHIBA Satellite A60
Portable Personal Computer
User’s Manual

Copyright
© 2004 by TOSHIBA Corporation. All rights reserved. Under the copyright laws,
this manual cannot be reproduced in any form without the prior written permission
of TOSHIBA. No patent liability is assumed, with respect to the use of the information
contained herein.
TOSHIBA Satellite A60 series Portable Personal Computer User’s Manual
FirsteditionMarch2004
Copyright authority for music, movies, computer programs, data bases and other
intellectual property covered by copyright laws belongs to the author or to the
copyright owner. Copyrighted material can be reproduced only for personal use or
use within the home. Any other use beyond that stipulated above (including
conversion to digital format, alteration, transfer of copied material and distribution
on a network) without the permission of the copyright owner is a violation of
copyright or author’s rights and is subject to civil damages or criminal action. Please
comply with copyright laws in making any reproduction from this manual.
Disclaimer
This manual has been validated and reviewed for accuracy. The instructions and
descriptions it contains are accurate for the TOSHIBA Satellite A60 series Portable
Personal Computer at the time of this manual’s production. However, succeeding
computers and manuals are subject to change without notice. TOSHIBA assumes
no liability for damages incurred directly or indirectly from errors, omissions or
discrepancies between the computer and the manual.
Trademarks
IBM is a registered trademark, and IBM PC and PS/2 are trademarks of International
Business Machines Corporation.
Intel, Intel SpeedStep and Pentium are trademarks or registered trademarks of Intel
Corporation or its subsidiaries in the United States and other countries/regions.
Windows and Microsoft are registered trademarks of Microsoft Corporation.
Photo CD is a trademark of Eastman Kodak.
Memory Stick is a registered trademark and i.LINK is a trademark of Sony
Corporation.
CompactFlash is a trademark of SunDisk Corporation.

FCC information
Product Name : Satellite A60
Model number : PSA60
FCC notice “Declaration of Conformity Infor-
mation”
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
❑Reorient or relocate the receiving antenna.
❑Increase the separation between the equipment and receiver.
❑Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
❑Consult the dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the FCC class B limits may
be attached to this equipment. Operation with non-compliant peripher-
als or peripherals not recommended by TOSHIBA is likely to result in
interference to radio and TV reception. Shielded cables must be used
between the external devices and the computer’s external monitor port,
USB port, serial port, parallel port, keyboard port and microphone jack.
Changes or modifications made to this equipment, not expressly ap-
proved by TOSHIBA or parties authorized by TOSHIBA could void the
user’s authority to operate the equipment.

FCC conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
Contact
Address: TOSHIBAAmericaInformationSystems,Inc.
9740IrvineBoulevard
Irvine,California92618-1697
Telephone: [phone]

EUDeclarationofConformity
TOSHIBA declares, that the product: PSA60* conforms to the following Standards:
SupplementaryInformation: “The product complies with the requirements
ofthe Low Voltage Directive 73/23/EEC, the
EMCDirective89/336/EECand/ortheR&TTE
Directive1999/05/EEC.”
This product is carrying the CE-Mark in accordance with the related European
Directives.ResponsibleforCE-MarkingisTOSHIBAEurope,Hammfelddamm8,
41460Neuss,Germany.
VCCI Class B Information
Modem warning notice
Conformity Statement
The equipment has been approved to [Commission Decision “CTR21”] for pan-
European single terminal connection to the Public Switched Telephone Network
(PSTN).
However, due to differences between the individual PSTNs provided in different
countries/regions the approval does not, of itself, give an unconditional assurance
of successful operation on every PSTN network termination point.
In the event of problems, you should contact your equipment supplier in the first
instance.

Network Compatibility Statement
This product is designed to work with, and is compatible with the following
networks. It has been tested to and found to conform with the additional require-
mentsconditionalinEG201121.
Germany ATAABAN005,AN006,AN007,AN009,AN010and
DE03,04,05,08,09,12,14,17
Greece ATAABAN005,AN006andGR01,02,03,04
Portugal ATAABAN001,005,006,007,011andP03,04,08,10
Spain ATAABAN005,007,012,andES01
Switzerland ATAABAN002
All other countries/regions ATAABAN003,004
Specific switch settings or software setup are required for each network, please refer
to the relevant sections of the user guide for more details.
The hookflash (timed break register recall) function is subject to separate national
type approvals. It has not been tested for conformity to national type regulations,
and no guarantee of successful operation of that specific function on specific
national networks can be given.
Japan regulations
Region selection
If you are using the computer in Japan, technical regulations described in the
Telecommunications Business Law require that you select the Japan region mode. It
is illegal to use the modem in Japan with any other selection.
Redial
Up to two redial attempts can be made. If more than two redial attempts are made,
the modem will return Black Listed. If you are experiencing problems with the
Black Listed code, set the interval between redials at one minute or longer.
Japan’s Telecommunications Business Law permits up to two redials on analogue
telephones, but the redials must be made within a total of three minutes.
The internal modem is approved by Japan Approvals Institute for Telecommunications
Equipment.
A02-0604JP

Pursuant to FCC CFR 47, Part 68:
When you are ready to install or use the modem, call your local telephone company
and give them the following information:
❑The telephone number of the line to which you will connect the modem
❑The registration number that is located on the device
The FCC registration number of the modem will be found on either the device
which is to be installed, or, if already installed, on the bottom of the computer
outside of the main system label.
❑The Ringer Equivalence Number (REN) of the modem, which can vary. For the
RENof your modem, referto your modem’s label.
The modem connects to the telephone line by means of a standard jack called the
USOCRJ11C.
Type of service
Your modem is designed to be used on standard-device telephone lines. Connec-
tion to telephone company-provided coin service (central office implemented
systems) is prohibited. Connection to party lines service is subject to state tariffs. If
you have any questions about your telephone line, such as how many pieces of
equipment you can connect to it, the telephone company will provide this informa-
tion upon request.
Telephone company procedures
The goal of the telephone company is to provide you with the best service it can. In
order to do this, it may occasionally be necessary for them to make changes in their
equipment, operations, or procedures. If these changes might affect your service or
the operation of your equipment, the telephone company will give you notice in
writing to allow you to make any changes necessary to maintain uninterrupted
service.

If problems arise
If any of your telephone equipment is not operating properly, you should immedi-
ately remove it from your telephone line, as it may cause harm to the telephone
network. If the telephone company notes a problem, they may temporarily discon-
tinue service. When practical, they will notify you in advance of this disconnection.
If advance notice is not feasible, you will be notified as soon as possible. When you
are notified, you will be given the opportunity to correct the problem and informed
of your right to file a complaint with the FCC. In the event repairs are ever needed
on your modem, they should be performed by TOSHIBA Corporation or an
authorized representative of TOSHIBA Corporation.
Disconnection
If you should ever decide to permanently disconnect your modem from its present
line, please call the telephone company and let them know of this change.
Fax branding
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person
to use a computer or other electronic device to send any message via a telephone
fax machine unless such message clearly contains in a margin at the top or bottom
of each transmitted page or on the first page of the transmission, the date and time it
is sent and an identification of the business, other entity or individual sending the
message and the telephone number of the sending machine or such business, other
entity or individual. In order to program this information into your fax modem, you
should complete the setup of your fax software before sending messages.
Instructions for IC CS-03 certified equipment
1The Industry Canada label identifies certified equipment. This certification
means that the equipment meets certain telecommunications network protective,
operational and safety requirements as prescribed in the appropriate Terminal
Equipment Technical Requirements document(s). The Department does not
guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company. The
equipment must also be installed using an acceptable method of connection.

The customer should be aware that compliance with the above conditions may
not prevent degradation of service in some situations. Repairs to certified
equipment should be coordinated by a representative designated by the
supplier. Any repairs or alterations made by the user to this equipment, or
equipment malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connec-
tions of the power utility, telephone lines and internal metallic water pipe system,
if present, are connected together. This precaution may be particularly important
in rural areas.
CAUTION: Users should not attempt to make such connections
themselves, but should contact the appropriate electric inspection
authority, or electrician, as appropriate.
2The user manual of analog equipment must contain the equipment’s Ringer
EquivalenceNumber(REN)andanexplanation notice similar to the following:
The Ringer Equivalence Number (REN) of the modem, which can vary. For the
RENof your modem, referto your modem’s label.
NOTICE: The Ringer Equivalence Number (REN) assigned to each
terminal device provides an indication of the maximum number of
terminals allowed to be connected to a telephone interface. The termina-
tion on an interface may consist of any combination of devices subject
only to the requirement that the sum of the Ringer Equivalence Numbers
of all the devices does not exceed 5.
3The standard connecting arrangement (telephone jack type) for this equipment is
jacktype(s):USOC RJ11C.
The IC registration number of the modem is shown below.
Canada:1353 11026A

Notes for Users in Australia and New Zealand
Modem warning notice for Australia
Modems connected to the Australian telecoms network must have a valid Austel
permit. This modem has been designed to specifically configure to ensure compli-
ance with Austel standards when the country/region selection is set to Australia.
The use of other country/region setting while the modem is attached to the
Australian PSTN would result in you modem being operated in a non-compliant
manner. To verify that the country/region is correctly set, enter the command ATI
which displays the currently active setting.
To set the country/region permanently to Australia, enter the following command
sequence:
AT%TE=1
ATS133=1
AT&F
AT&W
AT%TE=0
ATZ
Failure to set the modem to the Australia country/region setting as shown above
will result in the modem being operated in a non-compliant manner. Consequently,
there would be no permit in force for this equipment and the Telecoms Act 1991
prescribes a penalty of $12,000 for the connection of non-permitted equipment.
Notes for use of this device in New Zealand
❑The grant of a Telepermit for a device in no way indicates Telecom acceptance
of responsibility for the correct operation of that device under all operating
conditions. In particular the higher speeds at which this modem is capable of
operating depend on a specific network implementation which is only one of
many ways of delivering high quality voice telephony to customers. Failure to
operate should not be reported as a fault to Telecom.
❑In addition to satisfactory line conditions a modem can only work properly if:
a/ it is compatible with the modem at the other end of the call and
b/ the application using the modem is compatible with the application at the
other end of the call - e.g., accessing the Internet requires suitable software
in addition to a modem.
❑This equipment shall not be used in any manner which could constitute a
nuisance to other Telecom customers.

❑Someparametersrequiredforcompliancewith Telecom’s PTC Specifications
are dependent on the equipment (PC) associated with this modem. The
associated equipment shall be set to operate within the following limits for
compliancewithTelecomSpecifications:
a/ There shall be no more than 10 call attempts to the same number within
any 30 minute period for any single manual call initiation, and
b/ The equipment shall go on-hook for a period of not less than 30 seconds
between the end of one attempt and the beginning of the next.
c/ Automatic calls to different numbers shall be not less than 5 seconds
apart.
❑Immediately disconnect this equipment should it become physically damaged,
and arrange for its disposal or repair.
❑The correct settings for use with this modem in New Zealand are as follows:
ATB0(CCITToperation)
AT&G2(1800Hzguardtone)
AT&P1(Decadicdialingmake-breakratio=33%/67%)
ATS0=0 (not auto answer)
ATS10=less than 150 (loss of carrier to hangup delay, factory default of 15
recommended)
ATS11=90(DTMFdialingon/offduration=90ms)
ATX2 (Dial tone detect, but not (U.S.A.) call progress detect)
❑When used in the Auto Answer mode, the S0 register must be set with a value
of 3 or 4. This ensures:
a/ a person calling your modem will hear a short burst of ringing before the
modem answers. This confirms that the call has been successfully
switched through the network.
b/ caller identification information (which occurs between the first and
second ring cadences) is not destroyed.
❑The preferred method of dialing is to use DTMF tones (ATDT...) as this is
faster and more reliable than pulse (decadic) dialing. If for some reason you
must use decadic dialing, your communications program must be set up to
record numbers using the following translation table as this modem does not
implement the New Zealand “Reverse Dialing” standard.
Number to be dialed: 0 1 2 3 4 5 6 7 8 9
Number to program into computer: 0 9 8 7 6 5 4 3 2 1
Note that where DTMF dialing is used, the numbers should be entered
normally.

❑The transmit level from this device is set at a fixed level and because of this
there may be circumstances where the performance is less than optimal. Before
reporting such occurrences as faults, please check the line with a standard
Telepermitted telephone, and only report a fault if the phone performance is
impaired.
❑It is recommended that this equipment be disconnected from the Telecom line
during electrical storms.
❑When relocating the equipment, always disconnect the Telecom line connec-
tion before the power connection, and reconnect the power first.
❑This equipment may not be compatible with Telecom Distinctive Alert ca-
dences and services such as FaxAbility.
NOTE THAT FAULT CALLOUTS CAUSED BY ANY OF THE
ABOVE CAUSES MAY INCUR A CHARGE FROM TELECOM
General conditions
As required by PTC 100, please ensure that this office is advised of any changes to
the specifications of these products which might affect compliance with the relevant
PTCSpecifications.
The grant of this Telepermit is specific to the above products with the marketing
description as stated on the Telepermit label artwork. The Telepermit may not be
assigned to other parties or other products without Telecom approval.
A Telepermit artwork for each device is included from which you may prepare any
number of Telepermit labels subject to the general instructions on format, size and
colour on the attached sheet.
The Telepermit label must be displayed on the product at all times as proof to
purchasers and service personnel that the product is able to be legitimately
connected to the Telecom network.
The Telepermit label may also be shown on the packaging of the product and in the
sales literature, as required in PTC 100.
The charge for a Telepermit assessment is $337.50. An additional charge of $337.50
is payable where an assessment is based on reports against non-Telecom New
Zealand Specifications. $112.50 is charged for each variation when submitted at the
same time as the original.
An invoice for $NZ1237.50 will be sent under separate cover.

Optical disc drive standards
TOSHIBA Satellite A60 series computer is shipped with one of the following
drivespreinstalled: DVD-ROM,CD-RW/DVD-ROM,DVD-R/-RW,
DVD+-R/+-RWorDVDSuperMultidrive.
The drive has one of the following labels :
CLASS 1 LASER PRODUCT
LASERKLASSE1
LUOKAN1LASERLAITE
APPAREILA LASER DE CLASSE1
KLASS 1 LASER APPARAT
Before it is shipped, the Class 1 Laser is certified to meet the United States
Chapter 21 Standards of the Department of Health and Human Services (DHHS 21
CFR).
For any other country, the drive is certified to meet the Class 1 Laser stan-
dardsofIEC825andEN60825.

Location of the required label
PRODUCT IS CERTIFIEDBY THE
MANUFACTURERTOCOMPLYWITH
DHHS RULES 21 CFR SUBCHAPTER
JAPPLICABLEATTHEDATE OF
MANUFACTURE.
MANUFACTURED:
TOSHIBASAMSUNGSTORAGE
TECHNOLOGY CORPORATION 580,
HORIKAWA-CHO,SAIWAI-KU,
KAWASAKI-SHI,KANAGAWA,212-0013,
JAPAN
Location of the required label
DVD-ROM drive safety instructions
** means any letters or numbers.
CAUTIONS:1. The drive employs a laser system. To ensure proper
use of this product, please read this instruction
manualcarefully andretainfor futurereference.
Should the unit ever require maintenance, contact an
authorizedservicelocation.
2. Use of controls, adjustments or the performance of
procedures other than those specified may result in
hazardousradiationexposure.
3. To prevent direct exposure to the laser beam, do not
try to open the enclosure.
Toshiba Samsung SD-C2612

Location of the required label
PRODUCT IS CERTIFIEDBY THE
MANUFACTURERTOCOMPLY
WITH DHHS RULES 21 CFR
SUBCHAPTER JAPPLICABLEAT
THEDATE OF MANUFACTURE.
MANUFACTURED:
TOSHIBASAMSUNGSTORAGE
TECHNOLOGYCORPORATION
580,HORIKAWA-CHO,SAIWAI-KU,
KAWASAKI-SHI,KANAGAWA,212-
0013,JAPAN
DVD-R/-RW drive safety instructions
CAUTIONS:1. The drive employs a laser system. To ensure proper
use of this product, please read this instruction
manualcarefully andretainfor futurereference.
Should the unit ever require maintenance, contact an
authorizedservicelocation.
2. Use of controls, adjustments or the performance of
procedures other than those specified may result in
hazardousradiationexposure.
3. To prevent direct exposure to the laser beam, do not
try to open the enclosure.
Toshiba Samsung SD-R6332

Location of the required label
PRODUCT IS CERTIFIEDBY THE
MANUFACTURERTOCOMPLY
WITH DHHS RULES 21 CFR
SUBCHAPTER JAPPLICABLEAT
THEDATE OF MANUFACTURE.
MANUFACTURED:
Manufactured by
Panasonic Communications Co.,
LTD 1-62, 4-Chome,Minoshima,
Hakata-ku, Fukuoka, JAPAN
Matsushita UJ-811BTJA-A
PioneerDVR-K13TBA
Location of the required label
COMPLIESWITHFDARADIATION
PERFORMANCESTANDARDS,21
CFR SUBCHAPTER J.
MANUFACTURED:
Manufactured by
PIONEER CORPORATION4-1,
Meguro 1-chome, Meguro-ku,
TOKYO 153-8654, JAPAN

Location of the required label
COMPLIESWITHFDARADIATION
PERFORMANCESTANDARDS,21
CFR SUBCHAPTER J.
MANUFACTURED:
Manufactured by
Panasonic Communications Co.,
LTD 1-62, 4-Chome,Minoshima,
Hakata-ku, Fukuoka, JAPAN
CD-RW/DVD-ROM drive safety in-
structions
CAUTIONS:1. The drive employs a laser system. To ensure proper
use of this product, please read this instruction
manualcarefully andretainfor futurereference.
Should the unit ever require maintenance, contact an
authorizedservicelocation.
2. Use of controls, adjustments or the performance of
procedures other than those specified may result in
hazardousradiationexposure.
3. To prevent direct exposure to the laser beam, do not
try to open the enclosure.
Matsushita UJDA760

PRODUCT IS CERTIFIED BY THE
MANUFACTURERTOCOMPLY
WITH DHHS RULES 21 CFR
SUBCHAPTER JAPPLICABLEAT
THEDATEOFMANUFACTURE.
MANUFACTURED:
TOSHIBASAMSUNGSTORAGE
TECHNOLOGYCORPORATION
580,HORIKAWA-CHO,SAIWAI-KU,
KAWASAKI-SHI,KANAGAWA,212-
0013,JAPAN
Location of the required label
CERTIFICATIONTISH PRODUCT
COMPLIES WITHDHHS RULES 21 CFR
CHAPTER 1, SUBCHAPTER JAPPLI-
CABLEDATEOFMANUFACTURE
MANUFACTURED:
TEACCORPORATION
3-7-3NAKA-CHO, MUSASHINO-SHI,
TOKYO,JAPAN
Location of the required label
Toshiba Samsung SD-R2512
.
TEAC DW-224E

Location of the required label
COMPLIESWITHFDARADIATION
PERFORMANCESTANDARDS,21
CFR SUBCHAPTER J.
MANUFACTURED:
Manufactured by
PIONEER CORPORATION4-1,
Meguro 1-chome, Meguro-ku,
TOKYO 153-8654, JAPAN
DVD +-R/+-RW drive safety instruc-
tions
CAUTIONS:1. The drive employs a laser system. To ensure proper
use of this product, please read this instruction
manualcarefully andretainfor futurereference.
Should the unit ever require maintenance, contact an
authorizedservicelocation.
2. Use of controls, adjustments or the performance of
procedures other than those specified may result in
hazardousradiationexposure.
3. To prevent direct exposure to the laser beam, do not
try to open the enclosure.
Pioneer DVR-K13TBT

Location of the required label
COMPLIESWITHFDARADIATION
PERFORMANCESTANDARDS,21
CFR SUBCHAPTER J.
MANUFACTURED:
Hitachi-LGData Storage, Inc.
20,YOIDO-DONG,YOUNG-
DUNGPO-GU,
SEOUL, KOREA
HLDS GWA-4040N
HLDS GCC-4243N
Location of the required label
COMPLIESWITHFDARADIATION
PERFORMANCESTANDARDS,21
CFR SUBCHAPTER J.
MANUFACTURED:
Hitachi-LGData Storage, Inc.
20,YOIDO-DONG,YOUNG-
DUNGPO-GU,
SEOUL, KOREA
