Toshiba L25-S1194 User manual

© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite L25-S1194 BTS Rev. 1.00 2005-08-19 CBB T20050720 CB0.9 Page 1 of 4
Satellite L25 Series Detailed Product Specification1
Model Name Description Part Number UPC
L25-S1194 Microsoft® Windows® XP Home Edition, Intel® Celeron® M Processor 360, 512MB
DDR2, 40GB (5400 RPM) PATA, CD-RW/DVD-ROM, 15.0” TruBrite™ XGA, ATI
RADEON® XPRESS 200M, TV-Out, 802.11 b/g, 1-year Limited Warranty
PSL2XU-01600D 032017415126
Operating System2
•Microsoft® Windows® XP Home Edition
Processor and Chipset3
•Intel Celeron® M Processor 360
o1.40GHz, 1MB L2, 400MHz FSB
•ATI RADEON® XPRESS 200M Chipset
Memory4
•Configured with 512MB DDR2 SDRAM (both memory slots may be
occupied)
•512MB(min)/2048MB (max), 2 memory slots using 256MB, 512MB,
or 1024MB PC4200 DDR2 533MHz SDRAM 1.8V SODIMM
memory modules, dual-channel support requires two memory
modules of same capacity and clockspeed
Hard Disk Drive5
•40GB (5400 RPM); Enhanced IDE (ATA-6) hard disk drive; 9.5mm
height; user removable
Fixed Bay Optical Disk Drive
•CD-RW/DVD-ROM drive maximum speed and compatibility:
oCD-ROM (24x:read), CD-R (24x:write), CD-RW
(24x:write), DVD-ROM (8x:read)
Display6
•15.0” diagonal TruBrite™ TFT active-matrix LCD display at
1024x768 native resolution (XGA)
Graphics7
•ATI RADEON® X200M 32MB-128MB dynamically allocated shared
graphics memory.
Sound
•16-bit stereo software sound
oSupports 3D Sound, Direct 3D Sound, DirectSound,
Direct Music, MIDI (playback)
•Sound Volume Control by keyboard
•Built-in stereo speakers
Input Devices
•Keyboard
o84 key US keyboard
oHot Key Functions (Fn)
oWindows Key Function
oApplication Key Function
•TouchPad™ pointing device
•CD/DVD control buttons (Skip to Previous/Next Track, Play, Stop)
Communications
•Integrated V.92 software modem8
•10/100 Base-TX Ethernet
•Atheros® 802.11b/g wireless-LAN9
Expandability
•2 main memory slots. Both slots may be occupied.
•1 PC Card slot support 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
Ports
•RGB (monitor) port
•TV-out (S-Video)
•3 Universal Serial Bus (USB) ports (v2.0)
•External Microphone jack
•Headphone jack
•RJ-45 LAN port
•RJ-11 modem port
Physical Description for this Product Series
•Dimensions (WxDxH Front/H Rear): 13.1” (332 mm) x 10.6”
(270mm) x 1.12” (28.5 mm)[F]/ 1.44” (36.6 mm)[R] without feet
•Weight: Starting at 5.88 lbs (2.67 kg) depending upon
configuration10
•Indicators: Power, Hard Drive, CD/DVD-ROM, Caps Lock, Wireless
Communication, Main Battery Charging Status, Sleep Suspend
Mode
•Chassis Description
oCase material: Polycarbonate ABS
oLCD Cover Color: Black
•Physical Security
oSlot for cable lock
oItems protected by screws: Memory & Hard Disk
oItems protected by sliding latch: Main Battery Pack
•Software Security
oPasswords: User power-on password, supervisor
password, set-up security
oHotkey locks: Screen Blank
oScreen Saver (by software)
Power Supply
•65W (19V 3.42A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•Dimensions (WxDxH): 4.25” (108.0mm) x 1.34” (34.0mm) x 1.85”
(47.0mm)
•Weight: starting at 0.55 lbs (250 g)
Battery11
•4-cell (2000mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•Dimensions (WxDxH): 8.10” (205.8mm) x 0.78” (19.8mm) x 2.40”
(60.9mm)
•Weight: starting at 0.62 lbs (281 g)
•Battery Life (measured by MobileMark™)12
oIncluded 4-cell battery: 1 hour, 30 minutes
•Recharge Time
oMain Battery Off/On – approximately 3 hrs/approximately
6 hrs

This product specification is variable and subject to change prior to product launch.
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite L25-S1194 BTS Rev. 1.00 2005-08-19 CBB T20050720 CB0.9 Page 2 of 4
BIOS
•ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS v2.31,
PCI BIOS v2.2 support
Software13
•Toshiba Software and Utilities
oTOSHIBA ConfigFree®
oTOSHIBA Custom Utilities
oToshiba Notebook Maximizer
oElectronic User’s Guide
•Third-party Software
oMicrosoft Office® OneNote™ 2003
oMicrosoft Works™ Version 8.0
oMcAfee® VirusScan™ (30-day Trial)
oSun® Java™ 2 Runtime Environment
oAdobe® Acrobat® Reader version 5.0
oInterVideo® WinDVD® 5
oInterVideo® WinDVD Creator 2 Platinum
oSonic Solutions® PrimeTime™
oSonic Solutions® RecordNow!™ Basic for Toshiba
oSonic Solutions® Drive Letter Access™ (DLA)
oMicrosoft® Windows Media Player version 10
oAOL® Internet Service (90-day trial)14
oAT&T® Worldnet® Service (30-day trial)15
oNapster® Digital Music Service (30-day Trial)
oCA EZFirewall® (30-day Trial)
Environmental Specifications
Operating
Temperature16 5° to 35° C
(41° to 95° F)
Thermal Gradient 15° C per hour (max)
Relative Humidity
(non-condensing) 20% to 80%
Altitude
(relative to sea level) 0 to 3,000 meters
Shock 10G
Vibration 0.5G
Satellite – 1-year standard limited warranty17
Standard Limited Warranty Upgrades and Extensions
Toshiba offers many different standard limited warranty extensions and
enhanced service plans such as SystemGuard®, At-Home Repair, and
Service Express to provide additional support to your notebook PC. For a
full description and complete list of programs and program extensions,
please visit www.pcsupport.toshiba.com
Recommended Services
Limited Warranty Extensions
Extends the standard limited warranty for up to 3 years from the original
notebook purchase date. See Toshiba Service Plan Agreement for
program terms and conditions at www.pcsupport.toshiba.com
Part Number Description
SWC-PEQQ2V 2nd Year Limited Warranty Extension
SWP-PEQQ3V 2nd/3rd Year Limited Warranty Extension
SystemGuard18 Advanced Protection Coverage w/ ServiceExpress
Provides advanced protection from damage caused by accidental drops,
spills and even screen breakage. Select your express repair service with
either Depot Express or Carry-In Express and go to the front of the line.
Limited Warranty Extension included except with 1 Year plan.
Part Number Description
SWC-PSGQ1V 1st Year
SWC-PEGQ2V 1st/2nd Year + Limited Warranty Extension
SWP-PEGQ3V 1st/2nd/3rd Year + Limited Warranty Extension
SystemGuard19 Advanced Protection Coverage + At-Home Repair
Combines SystemGuard and At-Home Repair coverage. Limited Warranty
Extension included except with 1 Year plan.
Part Number Description
SWC-PSGH1V 1st Year
SWC-PEGH2V 1st/2nd Year + Limited Warranty Extension
SWP-PEGH3V 1st/2nd/3rd Year + Limited Warranty Extension
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Toshiba will make reasonable efforts to complete
repair of your notebook and return the notebook to you by the next
business day via overnight shipment (excluding weekends and holidays).
Instructions and box will be provided to you for packing and shipping the
notebook to Toshiba. Carry-In Express: A Premier ASP will make
reasonable efforts to complete repair of your notebook by the next
business day (excluding weekends and holidays). Limited Warranty
Extension included except with 1 Year plan. See Toshiba Service Plan
Agreement for program terms and conditions at
www.pcsupport.toshiba.com
Part Number Description
SWC-PSQP1V 1st Year
SWC-PEQP2V 1st/2nd Year + Limited Warranty Extension
SWP-PEQP3V 1st/2nd/3rd Year + Limited Warranty Extension
At-Home Repair
Toshiba will make reasonable efforts to provide on-site service at
customer’s home location by the second business day (excluding
weekends and holidays) to perform the necessary hardware repairs.
Limited Warranty Extension included except with 1 Year plan. See
Toshiba Service Plan Agreement for program terms and conditions at
www.pcsupport.toshiba.com
Part Number Description
SWC-PSQH1V 1st Year
SWC-PEQH2V 1st/2nd Year + Limited Warranty Extension
SWP-PEQH3V 1st/2nd/3rd Year + Limited Warranty Extension
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory
Part Number Description
KTT533D2/256 Kingston DDR2 533, 256MB
KTT533D2/512 Kingston DDR2 533, 512MB
KTT533D2/1G Kingston DDR2 533, 1GB
Power
Part Number Description
PA3396U-1ACA Toshiba 65W Global AC Adapter
PA3420U-1BRS Toshiba Primary Battery Pack 8 cell
Security & Protection
Part Number Description
NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

This product specification is variable and subject to change prior to product launch.
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite L25-S1194 BTS Rev. 1.00 2005-08-19 CBB T20050720 CB0.9 Page 3 of 4
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba
America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo
are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are
registered trademarks and OneNote registered is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered
trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the
Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA
Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2Operating System. Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH
EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.
Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
3Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 35°C (41°F to 95° F) or >25°C (77°F) at high altitude (all temperature
references are approximate and may vary depending on the specific computer model – please visit the Toshiba website at
www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. Use your computer product only under recommended conditions. Read additional restrictions under “Environmental
Conditions” in your product “Detailed Specs.” Contact Toshiba Technical Service and Support for more information.
4Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount
of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on
the graphics system, applications utilized, system memory size and other factors.
5Hard Disk Drive (HDD) Capacity.
1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity
using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available storage
capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed
software applications, or media content. Actual formatted capacity may vary.
6Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film
transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic
of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This
is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery
power.

This product specification is variable and subject to change prior to product launch.
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Satellite L25-S1194 BTS Rev. 1.00 2005-08-19 CBB T20050720 CB0.9 Page 4 of 4
7Graphics (Graphics Processing Unit).
GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU
performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
8Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission
speeds will vary depending on line conditions.
9Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public
wireless LAN access points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary
depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware
configurations. The actual transmission speed will be lower than the theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless
function, if available, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format
of data transmitted.
10 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
11 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings
and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are
achieved on select models and configurations tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test.
Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its
ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories
information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
12 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
13 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT
BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures
and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations
of the computer, and may be completed by Internet or telephone (toll charges may apply).
14 AOL® Internet Service. Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE,
SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges
may apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling
plan, even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is
required.
15 AT&T® Worldnet® Service. Telephone access and other charges and other terms and conditions may apply. Offer available to new customers only.
16 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from
specifications even when operating within the recommended temperature range.
17 Warranty. Toshiba’s standard limited warranty, extended warranty and service upgrade terms and conditions are available at www.warranty.toshiba.com.
18 SystemGuard coverage must be purchased within the first 30 days of purchase. See Toshiba Service Plan Agreement for program terms and conditions at
www.pcsupport.toshiba.com
19 SystemGuard: SystemGuard coverage must be purchased within the first 30 days of purchase. See Toshiba Service Plan Agreement for program terms
and conditions at www.pcsupport.toshiba.com
