Toshiba M200 - Portege - Pentium M 1.5 GHz User manual

1
Toshiba Personal Computer
Portege M200
Maintenance Manual
TOSHIBA CORPORATION
File Number 960-457

ii Portege M200Maintenance Manual (960-457)
Copyright
© 2003 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual cannot be
reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed,with
respect to the use of the information contained herein.
Toshiba Portege M200 Maintenance Manual
First edition November 2003
Disclaimer
This manual has beenvalidated and reviewed for accuracy. The instructions and descriptions it contains are
accurate for the Toshiba Portege M200 at the time of this manual's production. However, succeeding computers
and manuals are subject to change without notice. Toshiba assumes no liability for damages incurred directly or
indirectly from errors, omissions or discrepancies betweenthe computer and the manual.
Trademarks
IBM is a registered trademark of International Business Machines Corporation.
Intel, Pentium and Centrino are registered trademarks and Speed Step is a trademark of Intel Corporation.
Windows and Microsoft are registered trademarks of Microsoft Corporation.
Bluetooth is a trademark owned by its proprietor and used by Toshiba under license.
Other trademarks and registered trademarks not listed above may be used in this manual.

Portege M200 Maintenance Manual (960-457) iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer Portege M200, referred to as Portege M200 in this manual.
The procedures described in this manual are intended to help service technicians isolate
faulty Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your
attention. Each of these messages will be italicized and identified as shown below.
DANGER:“Danger” indicates the existence of a hazard that could result in death or
serious bodily injury, if the safety instruction is not observed.
WARNING:“Warning” indicates the existence of a hazard that could result in bodily
injury, if the safety instruction is not observed.
CAUTION:“Caution” indicates the existence of a hazard that could result in property
damage, if the safety instruction is not observed.
NOTE:“Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety
precautions are adhered to strictly.
qBe sure to fasten screws securely with the right screwdriver. Be sure to use the PH
Point size “0”and “1”screwdrivers complying with the ISO/DIS 8764-1:1996. If a
screw is not fully fastened, it could come loose, creating a danger of a short circuit,
which could cause overheating, smoke or fire.
qIf you replace the battery pack or RTC battery, be sure to use only the same model
battery or an equivalent battery recommended by Toshiba. Installation of the wrong
battery can cause the battery to explode.

iv Portege M200Maintenance Manual (960-457)
The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the Portege M200 system unit and each
FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve
FRU problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
qHandling the LCD module
qBoard layout
qPin assignment
qKeyboard scan/character codes
qKey layout
qBIOS/KBC/EC Update
qReliability
qKey FD

Portege M200 Maintenance Manual (960-457) v
Conventions
This manual uses the following formats to describe, identify, and highlight terms and
operating procedures.
Acronyms
On the first appearance and whenever necessary for clarification acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on
the keyboard is printed in boldface type.
Key operation
Some operations require you to simultaneously use two or more keys. We identify such
operations by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause
(Break) means you must hold down Ctrland at the same time press Pause (Break). If
three keys are used, hold down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the Portege M200 that appears on its display is presented in the type face
below:
Format complete
System transferred

vi Portege M200Maintenance Manual (960-457)
Table of Contents
Chapter 1 Hardware Overview
1.1 Features...................................................................................................................... 1-1
1.2 2.5-inch Hard Disk Drive .......................................................................................... 1-9
1.3 Keyboard.................................................................................................................. 1-11
1.4 TFT Color Display................................................................................................... 1-12
1.5 Power Supply........................................................................................................... 1-14
1.6 Batteries ................................................................................................................... 1-16
1.7 AC Adapter.............................................................................................................. 1-18
Chapter 2 Troubleshooting Procedures
2.1 Troubleshooting......................................................................................................... 2-1
2.2 Troubleshooting Flowchart........................................................................................ 2-2
2.3 Power Supply Troubleshooting ................................................................................. 2-6
2.4 System Board Troubleshooting ............................................................................... 2-17
2.5 USB 3.5”FDD Troubleshooting ............................................................................. 2-31
2.6 2.5”HDD Troubleshooting ..................................................................................... 2-34
2.7 Keyboard Troubleshooting ...................................................................................... 2-39
2.8 Display Troubleshooting ......................................................................................... 2-40
2.9 Touch Pad Troubleshooting..................................................................................... 2-42
2.10 Modem Troubleshooting ......................................................................................... 2-43
2.11 LAN Troubleshooting.............................................................................................. 2-44
2.12 Sound Troubleshooting............................................................................................ 2-45
2.13 SD Card Slot Troubleshooting................................................................................. 2-47
2.14 Tablet Pen Troubleshooting..................................................................................... 2-48
2.15 Wireless LAN Troubleshooting............................................................................... 2-50
2.16 Bluetooth Troubleshooting...................................................................................... 2-54

Portege M200 Maintenance Manual (960-457) vii
Chapter 3 Tests and Diagnostics
3.1 The Diagnostic Test................................................................................................... 3-1
3.2 Executing the Diagnostic Test ................................................................................... 3-3
3.3 Setting of the hardware configuration....................................................................... 3-7
3.4 Subtest........................................................................................................................ 3-9
3.5 System Test.............................................................................................................. 3-11
3.6 Memory Test............................................................................................................ 3-15
3.7 Keyboard Test.......................................................................................................... 3-17
3.8 Display Test ............................................................................................................. 3-20
3.9 USB Floppy Disk Test............................................................................................. 3-23
3.10 ASYNC Test............................................................................................................ 3-25
3.11 Hard Disk Test......................................................................................................... 3-26
3.12 Real Timer Test ....................................................................................................... 3-29
3.13 NDP Test ................................................................................................................. 3-31
3.14 Expansion Test......................................................................................................... 3-32
3.15 Wireless LAN Test .................................................................................................. 3-34
3.16 Bluetooth Test ......................................................................................................... 3-37
3.17 Sound/LAN/Modem Test ........................................................................................ 3-46
3.18 Thermal Radiation Control Test .............................................................................. 3-49
3.19 Error Status Code..................................................................................................... 3-50
3.20 HDC Status .............................................................................................................. 3-52
3.21 FDD Cleaning.......................................................................................................... 3-54
3.22 Log Utilities ............................................................................................................. 3-55
3.23 Running Test............................................................................................................ 3-57
3.24 Floppy Disk Drive Utilities ..................................................................................... 3-59
3.25 System Configuration.............................................................................................. 3-65
3.26 SETUP ..................................................................................................................... 3-67
Chapter 4 Replacement Procedures
4.1 Overview.................................................................................................................... 4-1
4.2 Battery pack ......................................................................................................... 4-8

viii Portege M200Maintenance Manual (960-457)
4.3 PC card/SD memory card .................................................................................. 4-10
4.4 Keyboard............................................................................................................ 4-12
4.5 Touchpad .......................................................................................................... 4-14
4.6 Memory module................................................................................................. 4-15
4.7 HDD................................................................................................................... 4-17
4.8 Base cover assembly.......................................................................................... 4-19
4.9 Mini PCI ............................................................................................................ 4-21
4.10 MDC modem..................................................................................................... 4-23
4.11 FAN/CPU .......................................................................................................... 4-25
4.12 RTC battery....................................................................................................... 4-29
4.13 Bluetooth module............................................................................................... 4-30
4.14 Hinge cables....................................................................................................... 4-32
4.15 System board ..................................................................................................... 4-34
4.16 Speaker/LED board ........................................................................................... 4-36
4.17 Second FAN....................................................................................................... 4-39
4.18 Pen holder/Battery lock/Base latch assembly.................................................... 4-40
4.19 LCD unit/FL inverter......................................................................................... 4-43
4.20 Application switch board/Power switch board/LCD latch assembly ................ 4-47
4.21 Digitizer ............................................................................................................. 4-50
4.22 LCD harness/Hinge assembly............................................................................ 4-56
4.23 Hinge switch board ............................................................................................ 4-59
4.24 Fluorescent Lamp .............................................................................................. 4-60
Appendices
Appendix A Handling the LCD Module .........................................................................A-1
Appendix B Board Layout ..............................................................................................B-1
Appendix C Pin Assignment...........................................................................................C-1
Appendix D Keyboard Scan/Character Codes ................................................................D-1
Appendix E Key Layout .................................................................................................E-1
Appendix F BIOS/KBC/EC Update ...............................................................................F-1
Appendix G Reliability ...................................................................................................G-1

Portege M200 Maintenance Manual (960-457) ix
Appendix H Key FD........................................................................................................H-1

xPortege M200Maintenance Manual (960-457)

Chapter 1
Hardware Overview

1Hardware Overview
1-ii Portege M200 Maintenance Manual(960-457)
1HardwareOverview

1Hardware Overview
Portege M200 Maintenance Manual(960-457) 1-iii
Chapter 1 Contents
1.1 Features ......................................................................................................................1-1
1.2 2.5-inch Hard Disk Drive...........................................................................................1-9
1.3 Keyboard..................................................................................................................1-11
1.4 TFT Color Display...................................................................................................1-12
1.4.1 LCD Module.......................................................................................1-12
1.4.2 FL Inverter Board ...............................................................................1-13
1.5 Power Supply...........................................................................................................1-14
1.6 Batteries ...................................................................................................................1-16
1.6.1 Main Battery.......................................................................................1-16
1.6.2 Battery Charging Control...................................................................1-16
1.6.3 RTC battery........................................................................................1-17
1.7 AC Adapter..............................................................................................................1-18

1Hardware Overview
1-iv Portege M200 Maintenance Manual(960-457)
Figures
Figure 1-1 Front of the computer.....................................................................................1-4
Figure 1-2 System units configuration............................................................................1-4
Figure 1-3 System Block Diagram..................................................................................1-5
Figure 1-4 2.5-inchHDD.................................................................................................1-9
Figure 1-5 Keyboard......................................................................................................1-11
Tables
Table 1-1 2.5-inch HDD dimensions .............................................................................1-9
Table 1-2 2.5-inchHDD Specifications .......................................................................1-10
Table 1-3 LCD module specifications..........................................................................1-12
Table 1-4 FL inverter board specifications ..................................................................1-13
Table 1-5 Power supply output specifications .............................................................1-15
Table 1-6 Battery specifications ...................................................................................1-16
Table 1-7 Time required for charges of main battery...................................................1-17
Table 1-8 RTC battery charging/data preservationtime ..............................................1-17
Table 1-9 AC adapter specifications ............................................................................1-18

1.1 Features 1Hardware Overview
Portege M200 Maintenance Manual(960-457) 1-1
1Features
1.1 Features
The Portege M200 is anultra thin and lightweight PC realizing cable-less environment on a
table by wireless function with a Pentium-M processor realizing high performance.
qMicroprocessor
A 1.4/1.5/1.6/1.7GHz Mobile Pentium-M (Banias) processor with a
1.4/1.5/1.6/1.7GHz internal clock, 400MHz bus and 1.48/0.96V core operation,
supporting SpeedStep III.
qChipset
The computer is equipped with Intel Odem+, Intel ICH4-Mand YEBISU-SS.
qCache memory
A Banias has 32KB primary cache and 1MB secondary cache (in CPU.)
qGPU Controller
The computer has an nVIDIA MAP34-232 controller. The internal VRAM is 32MB.
qMemory
Two DDR SO-DIMM slots support DDR333 (standard)/DDR226. Memory modules
can be installed to a maximum of 2GB (2,048MB). Memory modules in 128MB (only
for expansion), 256MB, 512MB and 1GB sizesare available.
qHDD
Single 40/60/80GB internal drive. 2.5-inch x 9.5mm height
qUSB FDD
Three-mode 3.5 inch USB FDD supports 720KB, 1.2MB and 1.44MB formats.
qDisplay
Display swivels automatically 0/90/180/270 degrees by display driver. LCD and CRT
can be displayed at the same time.
LCD
Built-in 12.1 inch, 16M colors, SXGA+ (1,400×1,050 dots), thin type low
temperature poly-silicon TFT color display.

1Hardware Overview 1.1 Features
1-2Portege M200 Maintenance Manual(960-457)
CRT
Supported via an RGB connector
qDigitizer
Digitizer is installed at the rear of LCD. The supplied Tablet pen enables pen
computing.
qKeyboard
Keyboard has 84(US)/85(UK)-key and supports Windows key and Hot key.
qTouch pad
Touch pad is installed as a pointing device.
qTablet pen (Tablet PC pen)
Tablet pen can be used as a mouse by touching the display softly with the pen tip.
Tablet button on the side of the pen corresponds to the right click of the mouse. Erase
button on the pen tail can be used as an eraser depending on the application.
qReserve pen
Reserve pen can be used instead of the tablet pen at the time of loss or breakage.
Some computers in the series are equipped with a Reserve pen.
qBatteries
The computer has two batteries: a rechargeable Lithium-Ion main battery pack and an
RTC battery (that backs up the Real Time Clock and CMOS memory).
qUSB (Universal Serial Bus)
The adopted chip for this computer equips six USB ports supporting USB 2.0. Three
of them are occupied by the internal system, one is not used and others are usable as
external ports.
qPC card slot
A PC card Type II is acceptable. Supports ToPIC-100 (3.3V/CardBus).
qSD card slot
One SD card slot. Supports only memory card.

1.1 Features 1Hardware Overview
Portege M200 Maintenance Manual(960-457) 1-3
qSound system
Incorporates an internal speaker, three internal microphones, an external monaural
microphone connector and a stereo headphone connector.
qOne touch buttons
Windows Security tablet button (Ctrl+Alt+Del), ESC/Rotation button and Cross
Function button (Enter, Menu, scroll) are installed.
qInternal Modem
The internal modem is equipped as a modem daughter card (MDC).
The computer contains a MDC, enabling data and fax communication. It supports
ITU-TV.90. The transfer rates are 56 Kbps for data reception, 33.6 Kbps for data
transmission, and 14,400 bps for fax transmission. However, the actual speed depends
on the line quality. The RJ11 modem jack is used to accommodate a telephone line.
In U.S., Canada and Australia, the MDC supports V.90 and V.92.
qLAN
The internal LAN supports 10/100Mbit Ethernet.
qWireless LAN
The internal wireless LAN supports Mini PCI Type III.
The 802.11b/g (Atheros) mini PCI card is supported.
qFIR(Fast Serial InfraRed) communicationport
Fast Serial InfraRed (FIR) communicationport supports IrDA1.1. and realizes
115Kbps or 1.15Mbps wireless communication.
qBluetooth
The computer is equipped with Bluetooth communication standards supporting Host
interface and USB v1.1. It enables the communication between devices supporting
Bluetooth version 1.1. The switch on the computer can switch on/off the
communication function.

1Hardware Overview 1.1 Features
1-4Portege M200 Maintenance Manual(960-457)
Figure 1-1 shows the front of the computer and Figure 1-2 shows the system units
configuration.
Figure 1-1 Front of the computer
Appli
Switch
Board
Power
Switch
Board
PJ3291 PJ3290
PJ3260
LED
Board
PJ3261
PJ6000
PJ6003
Internal
Microphone
Speaker
SD card
Dock
IS1420
IS1440
PJ3540
PJ5620
PJ1800
PJ4600
PJ4601
PJ8400
PJ8425
PJ8490
PJ8810
PJ8800
Memory 2
Memory 1
SW1/SW2/
DIGITIZER
RGB
HDD
USB 0*
USB 1*
FAN for VGA
FAN
RTC Battery
1st Battery
DC-IN
Network
PAD
Debug Port
PC card
PJ4100
PJ3240
PJ2000
PJ2110
PJ2130
System Board
PJ4410
Bluetooth
PJ2300
MDC
Keyboard PJ3230
PJ3020
PJ6005 PJ6004
PJ5205, PJ5206
LCD
PJ2200
Wireless LAN
board
Antenna (right)
Antenna (left)
Headphone
External
Microphone
Figure 1-2 System units configuration
* The drawing above shows the physical configuration of USB ports. In the logical
configuration, the connector PJ4600 is assigned to USB 1 and PJ4601 is assigned to USB0.

1.1 Features 1Hardware Overview
Portege M200 Maintenance Manual(960-457) 1-5
Figure 1-3 shows the system block diagram.
Figure 1-3System Block Diagram

1Hardware Overview 1.1 Features
1-6Portege M200 Maintenance Manual(960-457)
The PC contains the following components.
qCPU
Mobile Pentium-M (Banias)
•A1.4/1.5/1.6/1.7GHz Pentium-M (Banias) processor with a
1.4/1.5/1.6/1.7GHz internal clock, 400MHz bus and 1.48/0.96V core
operationvoltage (built-in NDP), supporting SpeedStep III.
•Internal cache memory: 32KB Data and 32KB Instruction, Write-Back
•Secondary cache memory: 1MB (in CPU)
qMemory
Two DDR SO-DIMM slots support DDR333 (standard)/DDR226. Memory modules
in 256MB, 512 MB and 1GB can be installed to a maximum of 2GB (2,048MB).
•3.3V operation
•200 pin, SO Dual In-line Memory Modules (SO-DIMM)
•Supports PC2700
•Access time :6ns
qBIOS ROM (Flash memory)
•4Mbit (256K×16-bit chip)
−64KB used for logo
−64KB used for setup and checksum
−128KB used for system BIOS
−64KB used for VGA-BIOS
−64KB used for ACPI
−8KB used for PnP
−8KB used for password security
−16KB used for booting
−64KB used for LAN
−32KB are reserved
•5.0V operation
•Access time :120 ns or 90 ns
•Data transfer: 8-bit
