Toshiba Qosmio G35-AV650 Series Installation instructions

.
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio G35-AV650 Rev. 1.30 2006-06-29 DSM T20060428 CB1.00 Page 2 of 6
Article IV. Qosmio G35-AV650 Detailed Product Specification1
Model Name Description Part Number UPC
G35-AV650 Genuine Windows® XP Media Center Edition 2005, Intel® Core™ Duo Processor
T2500, 1024MB (2x512MB) DDR2 SDRAM, 200GB HDD (2x100GB HDD) (5400RPM),
17” WUXGA Ultimate TruBrite™, HD DVD-ROM and DVD SuperMulti Double Layer,
802.11a/b/g, NVIDIA® GeForce Go 7600 256MB GDDR3 SDRAM VRAM, Bluetooth V.
2.0 + EDR, TV Tuner, Toshiba QosmioPlayer
PQG31U-016007 032017536746
Article V.
Section 5.01Operating System2
•Genuine Windows® XP Media Center Edition 2005
•Windows Vista™ Capable
•TOSHIBA QosmioPlayer3
oQuick access for CD, DVD, and TV watching
oPause live TV for 1 to 5 hours (depending on video quality
selected)
Section 5.02Processor and Chipset4
Intel® Centrino® Mobile Technology featuring:
•Intel® Core™ Duo Processor T2500
o2.0GHz, 2MB L2, 667MHz FSB
•Mobile Intel® 945PM Express Chipset
•Intel® PRO/Wireless 3945ABG (802.11a/b/g)
Section 5.03Memory5
•Configured with 1024MB PC5300 DDR2 SDRAM (both memory
slots may be occupied)
•512MB (Min)/4096MB (Max), with 256MB, 512MB, 1024MB or
2048MB PC5300 DDR2 memory modules, dual-channel support
requires two memory modules of same capacity and clockspeed.
Section 5.04Hard Disk Drive6
•200GB using two Serial-ATA (SATA) hard disk drives; 9.5mm
height;
oPrimary + Secondary drive: 100GB + 100GB
o5GB (10GB with RAID) is reserved to support
QosmioPlayer features
oRAID 0 (striping) supported by TOSHIBA RAID Software7
oRAID 1 (mirroring) supported by TOSHIBA RAID
Software8
Section 5.05Fixed Optical Disk Drive9
•HD DVD-ROM10 and DVD SuperMulti (+/-R double layer) drive (in
one optical drive) supporting 12 formats
oMaximum speed and compatibility: HD DVD-ROM (1x),
CD-ROM (24x), CD-R (16x), CD-RW (10x), DVD-ROM
(8x), DVD-R (4x), DVD-RW (4x), DVD+R (Double Layer
(2x)), DVD+RW (4x), DVD-RAM (3x)
Section 5.06Toshiba TV Tuner11
•TOSHIBA TV Tuner (Internal):
oRegion/Standard - US/NTSC Standard Definition
(720x480)
oParental Control and Closed Caption
oTV Tuner Enhancements: 3D Y/C separator, Digital noise
reduction, 10-bit A/D conversion, Time-based correction
Section 5.07Display12
•17" diagonal widescreen Ultimate TruBrite™ TFT active-matrix LCD
display at 1920x1200 native resolution (WUXGA)
oSupports 1080p content
oMaximum Brightness Cd/m2
When Plugged into AC – Up to 350 Cd/m2
When in Battery Mode – Up to 146 Cd/m2
oColor Saturation: 72%
oContrast Ratio: 450:1
oHorizontal Viewing Angle: 140 Degree
oVertical Viewing Angle: 110 Degree
•QosmioEngine digital video processing system
Section 5.08Graphics13
•PCI-Express™ x16 graphics subsystem, featuring:
•NVIDIA® GeForce™ Go 7600 with 256MB DDR3 discrete graphics
memory
Section 5.09Sound
•1-bit Digital Amplifier
•Built-in harman/kardon® Bass Reflex stereo speakers
•Dolby® Home Theater™ Digital audio enhancements14
•Sound Volume Control Dial
•Built-in microphone
Section 5.10Input Devices
•Keyboard
o85 key US keyboard
oHot Key Functions (Fn)
oWindows Key Function
oApplication Key Function
•Dual Mode Pad pointing device
•Control Buttons:
oInternet button to launch default browser
oQosmioPlayer CD/DVD launch button
oQosmioPlayer TV launch button
oCD/DVD control buttons (Skip to Previous/Next Track,
Play, Stop)
•Remote Control
oToshiba QosmioPlayer and Microsoft Windows Media
Center Edition 2005 remote control
oExternal USB RC-6 IR Blaster receiver
Section 5.11Communications
•Toshiba V.92 software modem15
•Intel® PRO/1000 VE Network Connection - 10/100/1000 Base-TX
Ethernet
•Integrated Wireless-LAN:16
oIntel® PRO/Wireless Network Connection 3945ABG
(802.11a/b/g)
•Bluetooth® version 2.0 plus Enhanced Data Rate (EDR) with
Toshiba Bluetooth driver software
•Consumer Infrared for remote control
Section 5.12Expandability
•2 main memory slots. Both slots may be occupied.
•One PCMCIA – Type II/Type I Card Slot
•ExpressCard™ slot supporting ExpressCard/34 and
ExpressCard/54
•5-in-1 Bridge Media Adapter
oSecure Digital, Memory Stick™, Memory Stick PRO™,
Multi Media Card, xD Picture Card [shared slots]

.
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio G35-AV650 Rev. 1.30 2006-06-29 DSM T20060428 CB1.00 Page 3 of 6
oSecure Digital slot supports SDIO
Section 5.13Ports
•Video
oRGB (monitor) output port
oS-Video output port
oHDMI output port
oComposite input port (shared with stereo input)
Via included 3-in-1 cable
oS-Video input port
•Audio
oS/P DIF output port (shared with headphone port)
oMicrophone input port
oHeadphone output port
•Data oi.LINK(tm) IEEE-1394
oUSB v2.0 – 4 ports
oRJ-45 LAN port
oRJ-11 modem port
Section 5.14Physical Description for this Product Series
•Dimensions (WxDxH Front/H Rear): 16.0” (406.0mm) x 11.6”
(295.0mm) x 1.79” (45.5mm)[F]/2.11” (53.5mm)[R] without feet
•Weight: Starting at 10.1 lbs (4.6 kg) depending upon configuration17
•Chassis Description
oCase material: Polycarbonate ABS
oLCD Cover Color: Silver
•Physical Security
oSlot for cable lock;
oItems protected by a screw: Memory, HDD
oFingerprint reader
•Software Security
oPasswords: User power-on password, supervisor
password
oHotkey locks: Screen Blank
Section 5.15Power Supply
•120W (15V x 8A) Auto sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
•Dimensions (WxDxH): 2.17” (55.1mm) x 1.73” (43.9mm) x 5.71”
(145.0mm)
•Weight: starting at 1.43 lbs (0.6 kg)
Section 5.16Battery18
•6-cell (4700mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
•Dimensions (WxDxH): 5.55” (140.0mm) x 13.86” (98.1mm) x 0.80”
(20.3mm)
•Weight: starting at 0.76 lbs (0.3 kg)
•Battery Life (measured by MobileMark™)19
oIncluded 6-cell battery: 1 hour, 48 minutes
oOptional 9-cell battery: 2 hours, 30 minutes
•Recharge Time
oMain Battery Off/On – approximately 3.0 hrs/approximately
3.0 to 5.0 hrs
Section 5.17BIOS
•ACPI v1.0b, VESA v2.0, DPMS, DDC, SM BIOS v2.3, PCI BIOS
v2.3 support, PCI BIOS v.2.1
Section 5.18Software20
•Toshiba Software and Utilities
oTOSHIBA ConfigFree®
oTOSHIBA Custom Utilities
oElectronic User’s Guide
oToshiba Bluetooth driver software
•Third-party Software
oWildTangent Game Console
oMicrosoft Office® OneNote® 2003
oMicrosoft Works® Version 8.5
oSun® Java™ 2 Runtime Environment
oAdobe® Acrobat® Reader 7.0
oInterVideo® WinDVD® 5
oInterVideo® WinDVD HD
oInterVideo® WinDVD Creator 2 Platinum
oSonic Solutions® PrimeTime™
oSonic Solutions® RecordNow!™ Basic for Toshiba
oSonic Solutions® Drive Letter Access™ (DLA)
oMicrosoft® Windows Media Player version 10
oYahoo! Music Engine
•Trial Software
oMicrosoft Office Trial Student Teacher Edition (60-day
trial)
oMcAfee® Internet Security Suite (6-month trial)
oMcAfee® VirusScan™ (6-month trial)
oMcAfee® Internet Security Suite (30-day trial)
oMcAfee® VirusScan™ (30-day trial)
oAOL® Internet Service (6-month trial)21
Section 5.19Environmental Specifications
Operating Non-operating
Temperature
22
5° to 35° C
(41° to 95° F) -20° to 65° C (-4° to 149° F)
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Relative Humidity
(non-condensing) 20% to 80% 10% to 90%
Altitude
(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters
Shock 1.5G 60G
Vibration 0.25G 1.0G
•This product is compatible with European Union Directive
2002/95/EC, Restriction of the use of certain Hazardous
Substances in electrical and electronic equipment (RoHS)23,
restricting use of lead, cadmium, mercury, hexavalent chromium,
PBB, and PBDE.
QOSMIO – 1 YEAR STANDARD LIMITED WARRANTY +
ON-SITE REPAIR24
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs, please
visit www.pcsupport.toshiba.com.
Recommended Services
Extended Service Plan
Provides an extended service plan for up to 4 total years from the original
notebook purchase date. On-site service will be provided at customer’s
home or business location (excluding weekends and holidays) to perform
the necessary hardware repairs.
Part Number Description
WSN-QEQH2V 2nd Year Extended Service Plan + On-Site Repair
WSN-QEQH3V 2nd/3rd Year Extended Service Plan + On-Site Repair
WSN-QEQH4V 2nd/3rd/4th Year Extended Service Plan + On-Site
Repair
SystemGuard Accidental Damage Service25
Provides advanced protection from damage caused from handling. On-site
service will be provided at customer’s home or business location
(excluding weekends and holidays) to perform the necessary hardware
repairs. Extended Service Plan included except with 1 Year plan.
SystemGuard coverage must be purchased within the first 30 days of
notebook purchase.
Part Number Description
WSN-QEGH2V 1st/2nd Year + Extended Service Plan + On-Site
Repair
WSN-QEGH3V 1st/2nd/3rd Year + Extended Service Plan + On-Site
Repair

.
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio G35-AV650 Rev. 1.30 2006-06-29 DSM T20060428 CB1.00 Page 4 of 6
WSN-QEGH4V 1st/2nd/3rd/4th Year + Extended Service Plan + On-
Site Repair
Recommended Services
Extended Service Plan
Provides an extended service plan for up to 4 total years from the original
notebook purchase date.
Part Number Description
WSN-PNQQ1V 1st Year Extended Service Plan
WSN-PNQQ3V 1st/2nd/3rd Year Extended Service Plan
SystemGuard Accidental Damage Service26
Provides advanced protection from damage caused from handling.
Extended Service Plan included. SystemGuard coverage must be
purchased within the first 30 days of notebook purchase.
Part Number Description
WSN-PNGQ1V 1st Year + Extended Service Plan
WSN-PNGQ3V 1st/2nd/3rd Year + Extended Service Plan
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Your notebook will be repaired and returned via
overnight shipment (excluding weekends and holidays). Carry-In Express:
Take your notebook into a Premier ASP and go to the front of the line for
expedited repair service. Extended Service Plan included.
Part Number Description
WSN-PNQP1V 1st Year + Extended Service Plan
WSN-PNQP3V 1st/2nd/3rd Year + Extended Service Plan
Article VI. Accessories
For memory compatibility and the most updated accessories, please visit
www.accessories.toshiba.com
Memory
Part Number Description
PA3389U-2M25 Toshiba 256MB DDR2-533 Memory Kit, RoHS
PA3412U-2M51 Toshiba 512MB DDR2-533 Memory Kit, RoHS
PA3411U-2M1G Toshiba 1GB DDR2-533 Memory Kit, RoHS
Power
Part Number Description
PA3237U-3ACA Toshiba 120W Global AC Adapter, RoHS
PA3475U-1BRS Toshiba Primary Li ION Battery Pack (9 cell), RoHS
PA3091U-2CHG Toshiba Battery Charger w/Integrated AC Adapter
Security & Protection
Part Number Description
PA1370U-1ETC Toshiba Keyboard Protector
Wireless/Bluetooth
Part Number Description
PA3466U-1ETC Toshiba Wireless Stereo Headset with Bluetooth
Technology
PA1380U-1NMS Toshiba Wireless Travel Mouse with Bluetooth
Technology
Article VII.Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Article VIII. Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks and Qosmio and EasyGuard are trademarks of Toshiba
America Information Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo
are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are
registered trademarks and OneNote registered is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered
trademark and BatteryMark™ is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the
Business Applications Performance Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA
Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2Operating System. Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH
EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.
Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice

.
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio G35-AV650 Rev. 1.30 2006-06-29 DSM T20060428 CB1.00 Page 5 of 6
3QosmioPlayer: The QosmioPlayer is not a Windows-based application. When using the QosmioPlayer, the audio/video recording feature will not function.
4Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature
references are approximate and may vary depending on the specific computer model – please visit the Toshiba website at
www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. Use your computer product only under recommended conditions. Read additional restrictions under “Environmental
Conditions” in your product “Detailed Specs.” Contact Toshiba Technical Service and Support for more information.
5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount
of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on
the graphics system, applications utilized, system memory size and other factors. For PC's configured with 4 GB of system memory, the full system memory
space for computing activities will be considerably less and will vary by model and system configuration.
6Hard Disk Drive (HDD) Capacity.
1 Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2
for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the product
includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content.
Actual formatted capacity may vary.
7Toshiba RAID: Toshiba RAID is only supported on Toshiba-certified hard disk drives. Visit Toshiba’s website for details.
8Toshiba RAID: Toshiba RAID is only supported on Toshiba-certified hard disk drives. Visit Toshiba’s website for details.
9Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain
cases, your Toshiba optical drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or
optical media recorders. Additionally, certain optical media recorded on your optical drive may not playback or operate properly on other PCs or optical
media players. These problems are not due to any defect in your Toshiba PC or optical drive. Please refer to your PC's product specification for listing of
specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
10 HD DVD Technology - General.
Because HD DVD is a new format that makes use of new technologies, certain disc, digital connection and other compatibility and/or performance issues are
possible. Advanced interactive and navigation features of the HD DVD Video format including, but not limited to, Picture in Picture (PIP) and network
download features are not supported by this product. HD DVD Application Logo (HD DVD-ROM) represents the optical drive’s conformity with the DVD
Forum’s verification criteria for HD DVD physical format, and does not represent compliance with the HD DVD Video specification defined by the DVD Forum.
Advanced Access Content System (AACS) keys are integrated into your PC for copy protection purposes. Occasional renewal of the AACS key is required,
and easily done by connecting to the Internet. Toshiba will provide AACS key renewal for your new PC for 5 years from the date of purchase by the original
purchaser at no charge, after which key renewal will be available pursuant to the software player provider’s then current terms and conditions. For more
information on AACS key, visit www.aacsla.com/home.
HD DVD Playback Capabilities.
Depending on HD DVD content, you may experience “frame dropping” or lower performance. HD DVD viewing on external display requires an HDCP capable
HDMI™ or DVI input. External power required for viewing of HD DVD content. Since CPU power is dedicated to support HD DVD playback function, you must
close all other applications before launching HD DVD playback. QosmioPlayer does not support HD DVD playback function. QosmioEngine is not operative
during playback of HD DVD. Dolby Digital audio enhancements are available in the Microsoft Windows operating system only. Audio content with a high
sampling (>48 kHz) rate will be down sampled when using Dolby Virtualizer with the internal speakers or the analog audio output or digital audio output
(HDMI and S/P DIF).
11 Qosmio TV Tuner: TV tuner will function only in the country where the computer was purchased.
12 Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film
transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic
of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This
is also an intrinsic characteristic of the screen technology.

.
© Copyright 2005 – 2006 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Qosmio G35-AV650 Rev. 1.30 2006-06-29 DSM T20060428 CB1.00 Page 6 of 6
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery
power.
13 Graphics (Graphics Processing Unit).
GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU
performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
14 Dolby Digital Audio Enhancements. Dolby Digital audio enhancements are available in the Microsoft Windows operating system only.
15 Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission
speeds will vary depending on line conditions.
16 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public
wireless LAN access points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary
depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware
configurations. The actual transmission speed will be lower than the theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless
function, if available, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format
of data transmitted.
17 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
18 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings
and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are
achieved on select models and configurations tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test.
Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its
ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories
information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
The QosmioPlayer is not a Windows based application. Battery life will be less than when using similar applications in the Windows Operating System
19 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
20 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT
BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures
and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations
of the computer, and may be completed by Internet or telephone (toll charges may apply).
21 AOL® Internet Service. Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE,
SIMPLY CANCEL BEFORE THE SIX-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges may
apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling plan,
even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is required.
22 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from
specifications even when operating within the recommended temperature range.
23 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and
electronic equipment (RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook
component suppliers to meet RoHS requirements and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling
inspections during the product design approval process.
24 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
25 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
26 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
