Toshiba Qosmio G40 User manual

[CONFIDENTIAL]
1
Toshiba Personal Computer
QOSMIO G40
Maintenance Manual
TOSHIBA CORPORATION
File Number 960-632
Downloaded from LpManual.com Manuals

ii [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
Copyright
© 2007 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual cannot be
reproduced in any form without the prior written permission of Toshiba. No patent liability is
assumed with respect to the use of the information contained herein.
Toshiba QOSMIO G40 Maintenance Manual
First edition May 2007
Disclaimer
The information presented in this manual has been reviewed and validated for accuracy. The included
set of instructions and descriptions are accurate for the QOSMIO G40 at the time of this manual's
production. However, succeeding computers and manuals are subject to change without notice.
Therefore, Toshiba assumes no liability for damages incurred directly or indirectly from errors,
omissions, or discrepancies between any succeeding product and this manual.
Trademarks
IBM is a registered trademark and IBM PC is a trademark of International Business Machines
Corporation.
Intel, Intel SpeedStep, Intel Core, Celeron and Centrino are trademarks or registered trademarks of
Intel Corporation or its subsidiaries in the United States and other countries/regions.
Windows and Microsoft are registered trademarks of Microsoft Corporation.
Photo CD is a trademark of Eastman Kodak.
Sonic RecordNow! and Sonic PrimeTime are registered trademarks of Sonic Solutions.
Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license.
Memory Stick is a registered trademark and i.LINK is a trademark of Sony Corporation.
InterVideo and WinDVD are registered trademarks of the InterVideo Inc.
WinDVD Creator is trademarks of the InterVideo Inc.
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works. Copyright 1992-1997 Dolby Laboratories.
All rights reserved.
EdgeMotion, PalmCheck, TouchPad and Synaptics are trademarks or registered trademarks of
Synaptics Incorporated.
Other trademarks and registered trademarks not listed above may be used in this manual.
Downloaded from LpManual.com Manuals

QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer QOSMIO G40.
NOTE: Each model of QOSMIO G40 has a different configuration. For each model’s
configuration, refer to the parts list dedicated to it.
The procedures described in this manual are intended to help service technicians isolate
faulty Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your
attention. Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury, if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury, if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage, if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety
precautions are adhered to strictly.
Be sure to fasten screws securely with the right screwdriver. Be sure to use the PH
Point size “0” and “1” screwdrivers complying with the ISO/DIS 8764-1:1996. If a
screw is not fully fastened, it could come loose, creating a danger of a short circuit,
which could cause overheating, smoke or fire.
If you replace the battery pack or RTC battery, be sure to use only the same model
battery or an equivalent battery recommended by Toshiba. Installation of the wrong
battery can cause the battery to explode.
Downloaded from LpManual.com Manuals

iv [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the QOSMIO G40 system unit and each
FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve
FRU problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
Handling the LCD module
Board layout
Pin assignment
Keyboard Scan/Character Codes
Key layout
Wiring diagrams
BIOS Rewrite procedures
EC/KBC Rewrite procedures
Reliability
Maintenance of TOSHIBA RAID
Downloaded from LpManual.com Manuals

QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] v
Conventions
This manual uses the following formats to describe, identify, and highlight terms and
operating procedures.
Acronyms
On the first appearance and whenever necessary for clarification acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on
the keyboard is printed in boldface type.
Key operation
Some operations require you to simultaneously use two or more keys. We identify such
operations by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause
(Break) means you must hold down Ctrl and at the same time press Pause (Break). If
three keys are used, hold down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the QOSMIO G40 that appears on its display is presented in the type face
below:
Format complete
System transferred
Downloaded from LpManual.com Manuals

vi [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
Table of Contents
Chapter 1 Hardware Overview
1.1 Features......................................................................................................................1-1
1.2 System Block Diagram..............................................................................................1-7
1.3 2.5-inch Hard Disk Drive.........................................................................................1-11
1.4 Optical Drive............................................................................................................1-13
1.5 Keyboard..................................................................................................................1-17
1.6 TFT Color Display...................................................................................................1-18
1.7 Power Supply...........................................................................................................1-20
1.8 Batteries ...................................................................................................................1-22
1.9 AC Adapter ..............................................................................................................1-25
Chapter 2 Troubleshooting Procedures
2.1 Troubleshooting.........................................................................................................2-1
2.2 Troubleshooting Flowchart........................................................................................2-3
2.3 Power Supply Troubleshooting..................................................................................2-8
2.4 System Board Troubleshooting................................................................................2-18
2.5 USB FDD Troubleshooting .....................................................................................2-39
2.6 2.5” HDD Troubleshooting......................................................................................2-43
2.7 Keyboard Troubleshooting ......................................................................................2-48
2.8 Touch pad Troubleshooting.....................................................................................2-50
2.9 Display Troubleshooting..........................................................................................2-52
2.10 Optical Disk Drive Troubleshooting........................................................................2-55
2.11 Modem Troubleshooting..........................................................................................2-56
2.12 LAN Troubleshooting..............................................................................................2-58
2.13 Wireless LAN Troubleshooting...............................................................................2-59
2.14 Bluetooth Troubleshooting ......................................................................................2-62
2.15 Sound Troubleshooting............................................................................................2-65
Downloaded from LpManual.com Manuals

QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] vii
2.16 TV Tuner Troubleshooting......................................................................................2-67
2.17 Bridge media Slot Troubleshooting.........................................................................2-69
2.18 PCI ExpressCard Slot Troubleshooting...................................................................2-70
2.19 Fingerprint sensor ....................................................................................................2-71
2.20 Web camerta Troubleshooting.................................................................................2-81
2.21 Intel Turbo Memory Troubleshooting.....................................................................2-83
Chapter 3 Tests and Diagnostics
3.1 The Diagnostic Test...................................................................................................3-1
3.2 Executing the Diagnostic Test...................................................................................3-4
3.3 Setting of the hardware configuration........................................................................3-8
3.4 Heatrun Test.............................................................................................................3-10
3.5 Subtest Names..........................................................................................................3-11
3.6 System Test..............................................................................................................3-13
3.7 Memory Test............................................................................................................3-15
3.8 Keyboard Test..........................................................................................................3-16
3.9 Display Test.............................................................................................................3-17
3.10 Floppy Disk Test......................................................................................................3-20
3.11 Printer Test...............................................................................................................3-20
3.12 Async Test ...............................................................................................................3-24
3.13 Hard Disk Test.........................................................................................................3-25
3.14 Real Timer Test........................................................................................................3-28
3.15 NDP Test..................................................................................................................3-30
3.16 Expansion Test.........................................................................................................3-31
3.17 CD-ROM/DVD-ROM Test .....................................................................................3-33
3.18 Error Code and Error Status Names.........................................................................3-34
3.19 Hard Disk Test Detail Status....................................................................................3-37
3.20 ONLY ONE TEST...................................................................................................3-39
3.21 Head Cleaning..........................................................................................................3-46
3.22 Log Utilities.............................................................................................................3-47
3.23 Running Test............................................................................................................3-49
3.24 Floppy Disk Drive Utilities......................................................................................3-50
Downloaded from LpManual.com Manuals

viii [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
3.25 System Configuration ..............................................................................................3-55
3.26 Wireless LAN Test Program (Intel-made b/g ,a/b/g Setting up of REF PC)...........3-57
3.27 Wireless LAN Test Program on DUT PC(Intel-made)............................................3-62
3.28 LAN/Modem/Bluetooth/IEEE1394 Test Program ..................................................3-70
3.29 Sound Test program.................................................................................................3-77
3.30 SETUP .....................................................................................................................3-78
Chapter 4 Replacement Procedures
4.1 Overview....................................................................................................................4-1
4.2 Battery pack...............................................................................................................4-8
4.3 ExpressCard & PC card / Bridge media ..................................................................4-11
4.4 HDD.........................................................................................................................4-14
4.5 Memory module.......................................................................................................4-18
4.6 Fan hood...................................................................................................................4-20
4.7 Keyboard..................................................................................................................4-21
4.8 MDC ........................................................................................................................4-24
4.9 Bluetooth module.....................................................................................................4-26
4.10 Wireless LAN card ..................................................................................................4-28
4.11 Cover assembly/Base assembly...............................................................................4-32
4.12 Speaker.....................................................................................................................4-38
4.13 Woofer .....................................................................................................................4-40
4.14 USB/Jack board .......................................................................................................4-41
4.15 Battery lock/Battery latch ........................................................................................4-43
4.16 Optical disk drive.....................................................................................................4-44
4.17 AV-IN board/F-jack/Rear con cover .......................................................................4-47
4.18 Splitter/TV antenna holder.......................................................................................4-51
4.19 1st tuner.....................................................................................................................4-55
4.20 2nd tuner....................................................................................................................4-56
4.21 RTC battery..............................................................................................................4-57
4.22 1bit amp ...................................................................................................................4-59
4.23 LED board................................................................................................................4-60
4.24 Touch pad/Fingerprint sensor board........................................................................4-61
Downloaded from LpManual.com Manuals

QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] ix
4.25 Cover latch...............................................................................................................4-64
4.26 AV controller button................................................................................................4-66
4.27 GPU heat sink/North bridge heat sink/GPU fan......................................................4-68
4.28 CPU heat sink/CPU fan/CPU...................................................................................4-72
4.29 System board............................................................................................................4-77
4.30 Robson card .............................................................................................................4-80
4.31 PC card slot..............................................................................................................4-82
4.32 Modem jack .............................................................................................................4-84
4.33 AV11 button.............................................................................................................4-85
4.34 Volume board...........................................................................................................4-87
4.35 LCD assembly/Hinge assembly...............................................................................4-89
4.36 LCD unit/FL inverter...............................................................................................4-93
4.37 Display latch cover ..................................................................................................4-99
4.38 Display latch hook .................................................................................................4-100
4.39 Wireless LAN antennas/Bluetooth antenna...........................................................4-101
4.40 Tweeter ..................................................................................................................4-107
4.41 Internal microphone/web camera...........................................................................4-110
4.42 Hinge......................................................................................................................4-112
4.43 Fluorescent lamp....................................................................................................4-116
Appendices
Appendix A Handling the LCD Module ........................................................................ A-1
Appendix B Board Layout ............................................................................................. B-1
Appendix C Pin Assignment.......................................................................................... C-1
Appendix D Keyboard Scan/Character Codes ............................................................... D-1
Appendix E Key Layout..................................................................................................E-1
Appendix F Wiring Diagrams.........................................................................................F-1
Appendix G BIOS Rewrite procedures.......................................................................... G-1
Appendix H EC/KBC Rewrite procedures..................................................................... H-1
Appendix I Reliability.....................................................................................................I-1
Appendix J Maintenance of TOSHIBA RAID ...............................................................J-1
Downloaded from LpManual.com Manuals

x [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
Downloaded from LpManual.com Manuals

[CONFIDENTIAL]
Chapter 1
Hardware Overview
Downloaded from LpManual.com Manuals

1 Hardware Overview
1-ii [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
1 Hardware Overview
Downloaded from LpManual.com Manuals

1 Hardware Overview
QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] 1-iii
Chapter 1 Contents
1.1 Features......................................................................................................................1-1
1.2 System Block Diagram..............................................................................................1-7
1.3 2.5-inch Hard Disk Drive.........................................................................................1-11
1.4 Optical Disk Drive...................................................................................................1-13
1.4.1 HD DVD-ROM Drive........................................................................1-13
1.4.2 HD DVD-R Drive ..............................................................................1-15
1.5 Keyboard..................................................................................................................1-17
1.6 TFT Color Display...................................................................................................1-18
1.6.1 LCD Module ......................................................................................1-18
1.6.2 FL Inverter Board...............................................................................1-19
1.7 Power Supply........................................................................................................... 1-20
1.8 Batteries ...................................................................................................................1-22
1.8.1 Main Battery....................................................................................... 1-22
1.8.2 Battery Charging Control...................................................................1-23
1.8.3 RTC battery........................................................................................1-24
1.9 AC Adapter ..............................................................................................................1-25
Downloaded from LpManual.com Manuals

1 Hardware Overview
1-iv [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
Figures
Figure 1-1 Front of the computer and the system units configuration ............................1-5
Figure 1-2 System block diagram.................................................................................... 1-7
Figure 1-3 2.5-inch HDD...............................................................................................1-11
Figure 1-4 HD DVD-ROM drive .................................................................................. 1-13
Figure 1-5 HD DVD-R drive.........................................................................................1-15
Figure 1-6 Keyboard......................................................................................................1-17
Figure 1-7 LCD module.................................................................................................1-18
Tables
Table 1-1 2.5-inch HDD dimensions ........................................................................... 1-11
Table 1-2 2.5-inch HDD specifications........................................................................1-12
Table 1-3 HD DVD-ROM drive .................................................................................. 1-13
Table 1-4 HD DVD-ROM drive .................................................................................. 1-14
Table 1-5 HD DVD-R drive outline dimensions..........................................................1-15
Table 1-6 HD DVD-R drive specifications..................................................................1-16
Table 1-7 LCD module specifications..........................................................................1-18
Table 1-8 FL inverter board specifications ..................................................................1-19
Table 1-9 Power supply output rating..........................................................................1-21
Table 1-10 Battery specifications...................................................................................1-22
Table 1-11 Time required for charges of main battery ..................................................1-23
Table 1-12 Data preservation time.................................................................................1-23
Table 1-13 Time required for charges of RTC battery...................................................1-24
Table 1-14 AC adapter specifications............................................................................1-25
Downloaded from LpManual.com Manuals

1.1 Features 1 Hardware Overview
QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] 1-1
1 Features
1.1 Features
The QOSMIO G40 series are high performance all-in-one PCs running an Intel®CoreTM 2
Duo processor.
There some models and options. Refer to the Parts List for the configuration of each model
and options.
The features are listed below.
Microprocessor
Microprocessor that is used will be different of the model.
Intel ®CoreTM 2 Duo 2.00GHz ( T7300),2.20GHz (T7500),2.4GHz(T7700)
L1 cache : 64KB (32KB + 32KB),L2 cache : 4MB
FSB : 800MHz
Intel ®CoreTM 2 Duo 1.80GHz ( T7100),
L1 cache : 64KB (32KB + 32KB),L2 cache : 2MB
FSB : 800MHz
Memory
Two DDR2-533/DDR2-667 SDRAM slots. Memory modules can be installed to
provide a maximum of 4GB. Memory modules are available in 512MB, 1024MB and
2048MB sizes.
VGA
nVIDIA NB8P-GS is mounted.
HDD
Double (or single) 120GB, 160GB, 200GB internal serial-ATA drive. 2.5 inch x
9.5mm height .( 160GB HDD has a case of 9.5mm and 12.5mm.)
Optical Disk Devices
A HD DVD-ROM or HD DVD-R drive is equipped.
Downloaded from LpManual.com Manuals

1 Hardware Overview 1.1 Features
1-2 [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
Keyboard
An-easy-to-use 85(US)/86(UK)-key keyboard provides a numeric keypad overlay for
fast numeric data entry or for cursor and page control. The keyboard also includes
two keys that have special functions in Microsoft® Windows® Vista. It supports
software that uses a 101- or 102-key enhanced keyboard.
Touch pad
A Touch Pad and control buttons in the palm rest enable control of the on-screen
pointer and scrolling of windows.
Display
LCD
Built-in 17.1-inch, WUXGA (1,920 x 1,200 dots) amorphous silicon TFT color
display.
Interface
To external monitor via - RGB connector
- S-video OUT connector
- HDMI port OUT connector
To internal monitor via - S-video IN connector
- TV IN port
Sound system
Harman/Kardon-made stereo speaker is equipped. An internal microphone, external
monaural microphone jack and two stereo headphone jacks (one stereo headphone
jack can be used also as S/PDIF connector) are also equipped.
Battery
The RTC battery is equipped inside the computer.
The main battery is a detachable lithium ion battery (7,050mAh:Li-Ion, 9cell).
TV-tuner (Mini Card)
This enables to watch TV and record it. (Supporting world wide signal : NTSC, PAL
and SECAM).
Downloaded from LpManual.com Manuals

1.1 Features 1 Hardware Overview
QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] 1-3
Wireless LAN
The computer is equipped with PCI Express Mini Card type wireless LAN card that
supports 802.11 a/b/g or 802.11 a/b/g/n in the PCI Express Mini Card slot. This
function can be switched on and off by a switch on the computer.
LAN/MODEM
Connectors for LAN and Modem are separately mounted.
Bluetooth
Depending on the model, the computer is equipped with a dedicated Bluetooth
module. This enables a communication to devices that support Bluetooth
Version 2.0. Adopting AFH (Adaptive Frequency Hopping), reduce the interference
with the wireless communication in 2.4GHz. It can be switched on or off with a
switch on the computer.
Remote controller
A remote controller for easy operation from some distance.
USB FDD
USB FDD supports 720KB and 1.44MB.
PC card slot
The PC card slot (PCMCIA) accommodates one 5mm Type II card. (Based on PC
Card Standard, supporting CardBus)
ExpressCard slot
The ExpressCard slot accommodates an ExpressCard.
Bridge Media slot
One SD memory card/ SDIO card/Memory stick (PRO)/xD picture card/MultiMedia
card slot. Data can be read and written by inserting each media to the slot.
USB (Universal Serial Bus)
Five USB ports are provided. The ports comply with the USB2.0 standard, which
enables data transfer speeds 40 times faster than USB1.1 standard. USB1.1 is also
supported.
Downloaded from LpManual.com Manuals

1 Hardware Overview 1.1 Features
1-4 [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
IEEE1394 port
The computer has one IEEE 1394 port. It enables high-speed data transfer directly
from external devices such as digital video cameras.
S/PDIF
This port can send or receive the digital sound data with the equipment like CD, MD
Player. (This port is also used for headphone I/F.)Fingerprint sensor
Infrared transmitter cable ports
Connect the infrared transmitter cable to the infrared transmitter cable port on the
computer and to the set-top box.
Fingerprint sensor
The computer is equipped with a fingerprint sensor and fingerprint authentication
utility. They enable only person who has registered his/her fingerprint to use the
computer.
Web Camera
Web Camera Web Camera is a device that allows you to record video or take
photographs with your computer.
Intel Turbo Memory (Robson)
Intel Turbo Memory is a non - volatile memory disk - CaChe accelerator . 1GB Flash
memory has 2 features ( “Ready Boot” and “Hybrid Disk”) .
Downloaded from LpManual.com Manuals

1.1 Features 1 Hardware Overview
Figure 1-1 shows the front of the computer and the system units configuration
QOSMIO G40 Maintenance Manual (960-632) [CONFIDENTIAL] 1-5
Downloaded from LpManual.com Manuals

1 Hardware Overview 1.1 Features
Figure 1-1 Front of the computer and the system units configuration
1-6 [CONFIDENTIAL] QOSMIO G40 Maintenance Manual (960-632)
