Portege Z835-P330 Page 1 of 4
Portege Z835 Detailed Product Specification1
Model Name: Z835-P330 Part Number: PT224U-001001 UPC: 883974910816
Operating System C1 2
Genuine Windows®7 Home Premium 64-bit, SP1
Processor3and Graphics4
Intel®Core™ i3-2367M Processor
o1.4 GHz, 3MB L3 Cache
Mobile Intel®HM65 Express Chipset
Mobile Intel®HD Graphics with 64MB-1696MB dynamically allocated
shared graphics memory
Memory5
Configured with 4GB DDR3 1333MHz (max 6GB)
2 main memory slots. Both slots occupied. (not user upgradable)
Storage Drive6
128GB Serial ATA solid state drive
Fixed Optical Disk Drive7
Not Available
Display8
13.3” diagonal widescreen TruBrite®TFT display at 1366 x 768 native
resolution (HD)
oNative support for 720p content
o16:9 aspect ratio
LED backlit
Intel®Wireless Display Ready9
Sound
Built-in stereo speakers
MaxxAudio®LE
Input Devices
Premium Spill-resistant Raised Tile backlit Keyboard (black)
Touch pad pointing device with multi-touch control
Communications
Webcam and microphone
10/100/1000 Ethernet
Intel®802.11b/g/n wireless LAN10
Expandability
Memory Card Reader
oSecure Digital, Secure Digital High Capacity, Mini SD Card, Micro
SD, Micro SDHC, Multi Media Card [shared slot may require
adapter for use]
Ports
Video
oRGB
oHDMI®
Audio
oMicrophone input port
oHeadphone output port
Data
o3 USB ports (1 USB 3.011 port + 2 USB 2.0 ports (1 with USB
Sleep and Charge12)
oRJ-45 LAN port
Security
oSlot for security lock
Physical Description
Ultimate Silver
Dimensions (W x D x H Front/H Rear): 12.44” x 8.94” x 0.33”/0.63” with
feet
Weight: Starting at 2.47 lbs. depending upon configuration13
Power
45W (19V 2.37A) 100-240V/50-60Hz AC Adapter
Dimensions (W x H x D): 3.6” x 1.8” x 1.0”
Weight: starting at 0.45 lbs.
Battery14
8 cell/47Wh Lithium Ion battery pack (not user replaceable)
Battery Life Rating (measured by MobileMark™ Productivity 2007)
oIncluded 8 cell battery: up to 8 hours, 17 minutes
Software C1 15
Toshiba Software and Utilities
oTOSHIBA Assist
oTOSHIBA Bulletin Board
oTOSHIBA Disc Creator
oTOSHIBA eco Utility™
oTOSHIBA Face Recognition
oTOSHIBA Fingerprint Utility
oTOSHIBA HDD/SSD Alert
oTOSHIBA HDD Protection
oTOSHIBA HW Setup Utility
oTOSHIBA Media Controller16
oTOSHIBA Password Utility
oTOSHIBA PC Health Monitor
oTOSHIBA Recovery Disc Creator
oTOSHIBA ReelTime
oTOSHIBA Service Station
oToshiba Security Assist
oTOSHIBA Sleep Utility
oTOSHIBA Resolution+® Upconvert Plug-in for Media Player17
oTOSHIBA Value Added Package
oTOSHIBA Web Camera Application
Third-party Software
oAdobe®Acrobat®Reader
oAdobe®Flash®Player
oMaxxAudio®LE
oGoogle®Toolbar
oGoogle®Chrome
oIntel®Wireless Display Technology (WiDi 2.1)
oInternet Explorer®9
oMicrosoft®Office Starter 201018
oMicrosoft®Windows Media Player 12
oMicrosoft®Silverlight®
oMicrosoft®Live Essentials
Photo Gallery
Messenger
Mail
Writer
Movie Maker
Trial Software
oNorton Internet Security™ 2012 (30-day trial subscription)
Environmental Specifications
This product is RoHS19 compatible
Energy Star Qualified
EPEAT™ Gold Compliant
Operating Non-operating
Temperature
20
5° to 35° C -20° to 65° C
Thermal Gradient 15° C per hour (max) 20° C per hour
Relative Humidity
(non-condensing) 20% to 80% 10% to 90%
Altitude
(relative to sea level) -60 to 3,000 metres -60 to 10,000 metres
Shock 10G 60G
Vibration 0.5G 1.0G
1 YEAR STANDARD LIMITED WARRANTY21

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege Z835-P330 Page 2 of 4
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.support.toshiba.com.
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Power
Part Number Description
PA3822U-1ACA Toshiba 45W Global AC Adapter
Expansion
Part Number Description
PA3834U-1DV2 Toshiba USB Portable DVD SuperMulti Drive (Tray
Load)
PA3845U-1DV2 Toshiba USB Portable DVD SuperMulti Drive (Slot
Load)
PA3778U-1PRP Toshiba dynadock V Universal Docking Station
PA3575U-1PRP Toshiba dynadock U Universal Docking Station
PA3686U-1SET Toshiba dynadock Wireless U Universal Docking
Station w/USB Adapter
Carrying Case
Part Number Description
PA1454U-1SN2 Toshiba Neoprene Case, Black (Fits up to 13.3"
Ultralight)
PA1444U-1CS2 Toshiba Envoy Ballistic Polyester Carrying Case (Fits
up to 13.3" Ultralight)
PA1459U-1CL2 Toshiba Envoy Leather Carrying Case (Fits up to 13.3"
Ultralight)
PA1503U-1SL3 Toshiba Envoy Extreme Sling Back Pack, Black & Blue
(Fits up to 14.1")
Bluetooth
Part Number Description
PA3710U-1BTM Toshiba Bluetooth 2.1+EDR USB Nano Adapter
Storage
Part Number Description
PA3877U-1M8B Toshiba 8GB USB Hi-Speed Swivel-Retractable Flash
Drive
PA3877U-1MAB Toshiba 16GB USB Hi-Speed Swivel-Retractable Flash
Drive
PA3877U-1MBB Toshiba 32GB USB Hi-Speed Swivel-Retractable Flash
Drive
HDTC605XK3A1 Toshiba Canvio USB 3.0 500GB Portable Hard Drive,
Black
HDTC607XK3A1 Toshiba Canvio USB 3.0 750GB Portable Hard Drive,
Black
HDTC610XK3B1 Toshiba Canvio USB 3.0 1TB Portable Hard Drive,
Black
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.support.toshiba.com
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS Support website: http://support.toshiba.com
Qosmio, Satellite, Portégé, Tecra, SelectBay, ConfigFree, SystemGuard, EasyGuard are registered trademarks of Toshiba America Information Systems, Inc.
and/or Toshiba Corporation. All other products and names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating System
- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. See "Detailed Specs" for more information.
1Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2Operating System.
Also see 64-Bit Computing Legal Footnote, if applicable.

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege Z835-P330 Page 3 of 4
Certain Microsoft®software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical
Service and Support for more information.
4Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features
utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, System Video Memory and Shared System Memory. Shared System Memory will vary
depending on system memory size and other factors.
5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.
6Storage Drive
Computer (Internal) HDD Capacity. One Gigabyte (GB) means 109= 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity
using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer
includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity
may vary.
7Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9Intel® Wireless Display. Copy protection technology, if any, associated with the content may prevent or limit viewing of content.
10 Wireless. May require purchase of additional software, external hardware, or services. Transmission speeds may vary. Certain optional features within the wireless-n
specifications (if available on your system) may not be supported
11 USB 3.0. 5Gbps is the maximum theoretical interface transfer rate per the specifications of the Universal Serial Bus 3.0. Actual transfer rate will vary depending on your system
configuration and other factors.
12 USB Sleep & Charge.The "USB Sleep & Charge function" may not work with certain external devices even if they are compliant with the USB specification. In those cases, turn
the power of the computer ON to charge the device.
13 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
14 Battery Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark
Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. See “Detailed Specifications” for test used.
Details of MobileMark 2007 testing are available at www.bapco.com

This product specification is variable and subject to change prior to product launch.
© Copyright 2011 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege Z835-P330 Page 4 of 4
Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any individual user. Actual battery life may vary considerably from
specifications depending on product model, configuration, applications, power management settings and features utilized, as well as the natural performance variations produced by
the design of individual components. The battery life rating is only achieved on the select models and configurations tested by Toshiba under the specific test settings at the time of
publication and is not an estimate of a system’s battery life under any conditions other than the specific test settings.
After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries
15 Software. Also see 64-Bit Computing Legal Footnote, if applicable.
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Includes Microsoft® Office 2010 preloaded. Purchase a Product Key to activate a full Microsoft Office 2010 suite.
16 Toshiba Media Controller. Copy protection technology, if any, associated with the content may prevent or limit sharing of content.
17 Upconverter/UpconversionTechnology (Resolution+® Technology). Viewing enhancements may vary depending upon content quality and display device
capability/functionality/settings. Depending on the quality of the content, some video noise may be visible.
18 Microsoft®Office Starter 2010. Office Starter consists of reduced-functionality versions of Word and Excel with advertising. PowerPoint, Outlook, OneNote, Access and
Publisher are not included.
19 RoHS.This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment
(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements
and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
20 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
21 Warranty.The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
18 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
