TOSHIBA
Portégé R200 Series1
Model Name Description Part Number UPC Code
Portégé R200-S214 Intel Pentium M Processor Ultra Low Voltage 753 [1.20GHz, 2MB L2 cache, 400MHz
FSB], 12.1” XGA diagonal TFT active-matrix LCD display at 1024x768 native
resolution, 512MB (256MBx2) DDR2 400MHz memory, 60GB (4200 RPM) Enhanced -
IDE (ATA-6) 1.8”, Atheros® (802.11b/g), Gigabit Ethernet, TPM, Finger Print
recognition, BlueTooth 2.0, Microsoft® Windows® XP Professional, Microsoft
OneNote, 1-year Standard, Limited Warranty
PPR20U-01S00P 032017352025
Portégé R200-S234 Intel Pentium M Processor Ultra Low Voltage 753 [1.20GHz, 2MB L2 cache, 400MHz
FSB], 12.1” XGA diagonal TFT active-matrix LCD display at 1024x768 native
resolution, 512MB (256MBx2) DDR2 400MHz memory, 60GB (4200 RPM) Enhanced-
IDE (ATA-6)1.8”, Atheros® (802.11b/g), Gigabit Ethernet, TPM, Finger Print
recognition, BlueTooth 2.0, Microsoft® Windows® XP Professional, Microsoft
OneNote, 3-year Standard, Limited Warranty
PPR20U-01S00Q 032017353633
System Characteristics2
Operating System3
•Microsoft® Windows® XP Professional
Processor and Chipset:
•Intel® Pentium® M Processor Ultra Low Voltage 753 [1.20GHz,
2MB L2 cache, 400MHz FSB]4
•Mobile Intel 915GMS Express Chipset
Memory5
•512MB (Min)/1280MB (Max), 256MB on-board memory and 1
available memory slot with choice of 256MB, 512MB, or
1024MB PC3200 400MHz DDR2 SODIMM memory module
(unit might ship with either speed memory); the slot may be
occupied.
Mass Storage6
•60GB (4200 RPM) Enhanced-IDE 1.8” hard disk drive; 5.0mm
height
Display7
•12.1” diagonal TFT active-matrix LCD display at 1024x768
native resolution (XGA)
•Brightness Control
Graphics8
•Intel Graphics Media Accelerator 900 (integrated video);
Minimum 8MB – Max. 128MB of shared dynamic memory.
Input Devices
•Keyboard: Full sized 84 keys with 12 function keys, 1.7mm key
stroke, 4.5mm height; Dedicated Windows® & Application keys
support;
•Mouse: Touch Pad
•Buttons: Toshiba Console, Presentation, and Zoom In/Out
Communications
•Integrated V.92 modem9
•Integrated Marvell® 88E8053 10BASE-T/100BASE-
TX/1000BASE-T (Gigabit) Ethernet Network Connection
•Atheros® (802.11b/g) with SuperG™ technology Integrated
Wi-Fi™ compliant wireless LAN10
Slots and Ports
•RGB (monitor) port
•Fast Infrared (IrDA 1.1) port
•2 Universal Serial Bus (USB) ports (v2.0)
•RJ-11 modem port
•RJ-45 Ethernet LAN port
•Headphone jack
•1 Type II, PCMCIA R2.01, PC Card16, CardBus PC Card slot
•1 Secure Digital® slot
•Slim Port Replicator
Sound
•Analog Devices AD1981B Software Sound 16-bit stereo
•Built-in speaker
•Built-in microphone
•Sound Support for: 3D Sound, Direct 3D, DirectSound,
DirectMusic, and MIDI (playback)
•Sound Volume Control Dial
Physical Description
•LCD Cover and base: Titanium Silver Magnesium case?
•Dimensions (W x D x H Front/H Rear): 11.25” (286 mm) x 9.01”
(229 mm) x 0.30”/0.77” (9.9/19.8 mm)
•Weight11: minimum 2.68 lbs. (1.22 kg.) to maximum 2.84 lbs.
(1.29 kg.)
•LED Indicators: DC-In, Power, Primary Battery, Hard Disk Drive,
Wireless indicator, Caps Lock, Arrow Lock, Numeric Lock, Main
Battery Charging Status, Sleep Suspend Mode, SD Card
Power Supply
•45W (15V x 3A) Auto Sensing external AC Adapter, 100-240V /
50-60Hz frequency (Universal) input.
Battery12
•Battery Life: Up to 5 Hours 13
•6-cell (3800mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
oWeight: 0.58lb (265 g.)
oDimensions (WxHxD): 8.75” (222.5 mm) x 0.48” (12.2 mm) x
3.30” (83.87 mm)
oMain Battery Recharge Time (off/on): 3.5hrs/More than
4.5hrs (depending on system condition)
Security
•Built-in finger print reader
•Trusted Platform Module (TPM) Embedded Security Chip
•Slot for cable lock;
•Items protected by a screw: Memory (1 screw), Main HDD (1
screw), SelectBay (1 screw)
•Main Battery Pack protected by sliding lock
•Passwords: User Power-on password, Supervisor Password
•Hotkey locks: Keyboard Lock and Screen Blank
•Software lock: Screen Saver
BIOS
•ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS
v2.3, PC BIOS v2.1 support
Software14
Toshiba Software and Utilities
•Toshiba ConfigFree™ Version 5.00
•Toshiba Custom Utilities
oHard Disk Recovery Utilities
oToshiba Assist
oToshiba Controls
oToshiba Display Device Change Utility
oToshiba HDD Protection
oToshiba Hotkey Utility for Display Devices
oToshiba Zooming Utility
oTouch Pad Enable/Disable Utility
oToshiba Password Utility
oToshiba Power Saver
•Toshiba PC Diagnostic Tool
•Toshiba Management Console Version 3.5
© Copyright 200x Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R200 BTS 2005-03-31 PT CB V1.0 T0008 Page 1 of 4

TOSHIBA
•Toshiba MyConnect Special Offer
© Copyright 200x Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R200 BTS 2005-03-31 PT CB V1.0 T0008 Page 2 of 4
•Electronic User’s Guide
Third-party Software
•Adobe Acrobat Reader Version 5.0
•Infineon TPM Software Professional Package
•OmniPass Finger Print Software Version 3.50
•Microsoft® Office® OneNote™ 2003
•Napster Software Trial Version
•Windows Media Player 10 with Napster Plug-In
•RecordNow! Basic
•Sun Java 2 Runtime Environment
•Symantec Norton AntiVirus 2005 Trial Version
•Computer Associates eTrust™ EZ Firewall for TOSHIBA Trial
Version
•Google Toolbar for Toshiba
•AT&T Free Internet Trial with AT&T Worldnet Software15
•Toshiba AOL 9.0 Offer16
Environmental Specifications
Operating Non-Operating
Temperature17 5°to 35°C
(41°to 95°F) -20°to 65°C (-4°to 149°F)
Thermal Gradient 15°C per hour
maximum 20°C per hour maximum
Relative Humidity 20% to 80% 10% to 95%
Altitude (relative to sea
level) -60 to 3000 meters -60 to 10,000 meters
Shock 7G, 1.5G if ODD
installed 60G
Vibration 0.2G, 0.25G if ODD
installed 1.0G
Limited Warranty18
Choice of:
•1-year standard limited warranty, or
•3-year standard limited warranty
Limited Warranty Upgrades and Extensions for Portégé
notebook computers with a 1-year standard, limited warranty
Toshiba offers many different warranty extensions and enhanced service
plans such as SystemGuard®, At-Home Repair, and Service Express to
provide additional support to your notebook PC. For a full description and
complete list of programs, please visit
http://www.accessories.toshiba.com.
Warranty Extension
Extends the standard warranty for up to 4 years from the original
notebook purchase date. See Toshiba Service Plan Agreement for
program terms and conditions at http://www.pcsupport.toshiba.com.
Part Number Description
SWC-PEQQ2V 2nd Year Warranty Extension
SWP-PEQQ3V 2nd/3rd Year Warranty Extension
SystemGuard Accidental Damage Coverage
Provides coverage of accidental damage caused by drops, spills and
even screen breakage. Warranty Extension included except with 1 Year
plan.
Part Number Description
SWC-PSGQ1V 1st Year
SWC-PEGQ2V 1st/2nd Year + Warranty Extension
SWP-PEGQ3V 1st/2nd/3rd Year + Warranty Extension
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Notebook repaired the same day it is received,
and returned via overnight delivery. Shipping and box provided. Carry-In
Express: Notebook repaired by the next business day at any Premier
Authorized Service Provider. Warranty Extension included except with 1
Year plan.
Part Number Description
SWC-PSQP1V 1st Year
SWC-PEQP2V 1st/2nd Year + Warranty Extension
SWP-PEQP3V 1st/2nd/3rd Year + Warranty Extension
Business On-Site Repair
A technician arrives with parts at the customer’s business location the
next business day and performs the necessary hardware repairs.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWC-PSQN1V 1st Year
SWC-PEQN2V 1st/2nd Year + Warranty Extension
SWP-PEQN3V 1st/2nd/3rd Year + Warranty Extension
SystemGuard + ServiceExpress
Combines SystemGuard and ServiceExpress coverage. Warranty
Extension included except with 1 Year plan.
Part Number Description
SWC-PSGP1V 1st Year
SWC-PEGP2V 1st/2nd Year + Warranty Extension
SWP-PEGP3V 1st/2nd/3rd Year + Warranty Extension
SystemGuard + Business On-Site Repair
Combines SystemGuard and Business On-Site Repair coverage.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWC-PSGN1V 1st Year
SWC-PEGN2V 1st/2nd Year + Warranty Extension
SWP-PEGN3V 1st/2nd/3rd Year + Warranty Extension
Limited Warranty Upgrades and Extensions for Portégé
notebook computers with a 3-year standard, limited warranty
Toshiba offers many different warranty extensions and enhanced service
plans such as SystemGuard®, At-Home Repair, and Service Express to
provide additional support to your notebook PC. For a full description and
complete list of programs, please visit
http://www.accessories.toshiba.com.
Warranty Extension
Extends the standard warranty for up to 4 years from the original
notebook purchase date. See Toshiba Service Plan Agreement for
program terms and conditions at http://www.pcsupport.toshiba.com.
Part Number Description
SWC-PTQQ4V 4th Year Warranty Extension
SystemGuard Accidental Damage Coverage
Provides coverage of accidental damage caused by drops, spills and
even screen breakage. Warranty Extension included except with 1 Year
plan.
Part Number Description
SWC-PSGQ1V 1st/2nd/3rd Year
SWC-PTGQDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTGQ4V 4th Year Only + Warranty Extension
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Notebook repaired the same day it is received,
and returned via overnight delivery. Shipping and box provided. Carry-In
Express: Notebook repaired by the next business day at any Premier
Authorized Service Provider. Warranty Extension included except with 1
Year plan.
Part Number Description
SWP-PQQP3V 1st/2nd/3rd Year
SWC-PTQPDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTQP4V 4th Year Only + Warranty Extension
Business On-Site Repair
A technician arrives with parts at the customer’s business location the
next business day and performs the necessary hardware repairs.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWP-PQQN3V 1st/2nd/3rd Year
SWC-PTQNDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTQN4V 4th Year Only + Warranty Extension
SystemGuard + ServiceExpress
Combines SystemGuard and ServiceExpress coverage. Warranty
Extension included except with 1 Year plan.
Part Number Description
SWP-PQGP3V 1st/2nd/3rd Year
SWC-PTGPDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTGP4V 4th Year Only + Warranty Extension
SystemGuard + Business On-Site Repair
Combines SystemGuard and Business On-Site Repair coverage.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWP-PQGN3V 1st/2nd/3rd Year
SWC-PTGNDV 1st/2nd/3rd/4th Year + Warranty Extension
SWC-PTGN4V 4th Year Only + Warranty Extension

TOSHIBA
© Copyright 200x Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R200 BTS 2005-03-31 PT CB V1.0 T0008 Page 3 of 4
Accessories
For additional and most updated accessories, please visit
http://www.accessories.toshiba.com
Memory
Part Number Description
KTT533D2/256 Kingston DDR2 533, 256MB
KTT533D2/512 Kingston DDR2 533, 512MB
KTT533D2/1G Kingston DDR2 533, 1GB
Power
Part Number Description
PA3241U-1ACA Toshiba 45W Global AC Adapter
PA3444U-1BRS Toshiba Primary Li Ion Battery Pack (6 Cell)
PA3155U-2BRL Toshiba High Capacity 2nd Battery Pack (6 Cell)
Storage
Part Number Description
PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit
Expansion
Part Number Description
PA3401U-1DVD Toshiba External DVD-ROM drive (USB 2.0)
PA3352U-2CD2 Toshiba External CDRW/DVD-ROM drive (USB 2.0)
PA3402U-1DV2 Toshiba External DVD SuperMulti Drive (USB 2.0)
PA3156U-2PRP Toshiba Slim Port Replicator
Security & Protection
Part Number Description
PA1371U-1ETC Toshiba Keyboard Protector (Portege)
NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://pcsupport.toshiba.com. The product
specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or
illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
http://pcsupport.toshiba.com.
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are registered trademarks and
OneNote is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered trademark and BatteryMark™ is a
trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the Business Applications Performance
Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States
and/or other countries. All other trademarks are the property of their respective owners.
1Build-to-Order/Configure-to-Order. Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your
select model may not have all the features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have
selected all those features. Configuring (customization) of your notebook takes an additional 12 to 15 working days.
2Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may
not have all the features and specifications listed or illustrated.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
3Operating System. Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH
EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES.
Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply). Some software may differ from its
retail version (if available), and may not include user manuals or all program functionality.
4Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature
references are approximate and may vary depending on the specific computer model – please visit the Toshiba website at
www.pcsupport.toshiba.com for details).

TOSHIBA
© Copyright 200x Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R200 BTS 2005-03-31 PT CB V1.0 T0008 Page 4 of 4
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. Use your computer product only under recommended conditions. Read additional restrictions under “Environmental
Conditions” in your product “Detailed Specs.” Contact Toshiba Technical Service and Support for more information.
5Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount
of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on
the graphics system, applications utilized, system memory size and other factors.
6Hard Disk Drive (HDD) Capacity. 1 Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating
system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show
less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft
Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film
transistors (TFT) and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic
of the TFT manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This
is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery
power.
8Graphics (Graphics Processing Unit).GPU performance may vary depending on product model, design configuration, applications, power management
settings and features utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in
battery power mode.
9Modem Speed.Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission
speeds will vary depending on line conditions.
10 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public
wireless LAN access points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary
depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and software/hardware
configurations. The actual transmission speed will be lower than the theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless
function, if available, your client and access point must support the corresponding feature. Performance of these functions may vary depending on the format
of data transmitted.
11 Weight.Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
12 Battery Life.Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings
and features utilized, as well as the natural performance variations produced by the design of individual components. Published battery life numbers are
achieved on select models and configurations tested by Toshiba at the time of publication. Recharge time varies depending on usage. Battery may not
charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be
replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that shipped with your computer or visit the
Toshiba web site at www.accessories.toshiba.com.
13 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
14 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT
BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures
and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations
of the computer, and may be completed by Internet or telephone (toll charges may apply).
15 AT&T® Worldnet® Service. Telephone access and other charges and other terms and conditions may apply. Offer available to new customers only.
16 AOL® Internet Service. Availability may be limited, especially during peak times. TO AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE,
SIMPLY CANCEL BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services carry surcharges and communication surcharges
may apply, including AK, even during promotional period. Members may incur telephone charges on their phone bill, depending on their location and calling
plan, even during promotional period. Available to new AOL members in the United States, age 18 or older; a major credit card or checking account is
required.
17 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from
specifications even when operating within the recommended temperature range.
18 Warranty. Toshiba’s standard limited warranty, extended warranty and service upgrade terms and conditions are available at
http://www.warranty.toshiba.com.
