SATELLITE 100CS/105CS Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is
subject to change without notice. Copyright 1995TAIS 100CS.DOC Rev. 7 09/23/96 nmm.
Page 11 of 2
Satellite 100CS Satellite 105CS
504MB: PA1217U-S2W 504MB: PA1217U-S6W
PROCESSOR
Intel SL-Enh. Pentium 75Mhz(2.9V/3.3V) Yes
Integrated Coprocessor Yes
Processor Cache 16KB: (8KB code; 8KB data)
STORAGE
Fixed HDD (2.5” IDE) 528mb=504MB (13msec)
Fixed FDD (3.5” 1.44MB) Integrated
FDD Dimensions 4.47”L x 3.78”W x .6”H
FDD Weight Weight: .29 lbs
MEMORY: 16Mbit EDO DRAM, 3.3V
Standard 8MB
Maximum 40MB
Speed (hyper-page mode supported) 70ns
Data width 64 bit
BIOS (128KB FLASH EPROM, 150ns) Yes
PnP 1.0a SUPPORT Yes
DISPLAY
Type Dual Scan Color Passive Matrix
Size 10.4" (8.31"W x 6.24"H)
Dot Pitch .33mm x .33mm
Contrast Ratio 30:1 (typ); 15:1 (min)
VIDEO
VRAM: 4Mbit DRAM, 5V 1 MB
Speed (fast-page mode supported) 60ns
Controller Chip C&T CT65548
Bus Type Vesa Local Bus
Graphics Accelerator BitBLT support
Color Palette 226,981 colors
Internal Resolution 640 x 480 x 256 colors
Virtual Display Mode 800 x 600 x 256 colors
1024 x 768 x 256 colors
External Resolution1Colors/Palette
640 x 480 16.7M colors/16.7M colors
800x600 64K colors/64K colors
1024 x 768 256 colors/256K
Refresh Rate(Vert./Hor.)275Hz/60kHz
KEYBOARD
82 keys, 3mm Travel Yes
12 dedicated function keys Yes
Cursor control (8 Keys, Inverted "T") Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
1. SVGA color requires Windows driver includeded by Toshiba. Simultaneous viewing not provided at resolutions greater than 640 x
480 x 256colors. 2. Refresh rate taken @ 1024x768 Non-Interlaced.

SATELLITE 100CS/105CS Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is
subject to change without notice. Copyright 1995TAIS 100CS.DOC Rev. 7 09/23/96 nmm.
Page 11 of 2
Satellite 100CS Satellite 105CS
504MB: PA1217U-S2W 504MB: PA1217U-S6W
EXPANSION SLOTS
One Stacked PC Card Slot3Yes
Internal Memory Slot Yes
EXPANSION PORTS
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (ECP) Yes
One 15-Pin RGB (SVGA video) Yes
One 101 Key Keyboard/Mouse port
(PS/2) Yes
Enh. Port Replicator w/PC card Slots Optional: Part# PA2711UX
Port Replicator (NO PC card Slots) Optional: Part# NWPR100
POWER
INTERNAL AC Power Unit Yes
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 2.0A
Power Output (Watts) 30W
Battery Type: NiMH (12V, 2600mAH) Yes: Part# PA2437UR
Battery Life (Full power/Low Power) 2.5 hrs./ 5hrs.
Recharge Time (Computer Off/On) 2-3 hrs.(Off) /3-6 hrs.(On)
MaxTimePower Management Yes
DIMENSIONS 11.8"W x 9.1"D x 2.2”H
WEIGHT (Includes .8 lbs. battery) 6.9 LBS.
BUNDLED SOFTWARE (All Models)4Choice of Windows 95 or Windows 3.11;
Note: Satellite 105CS offers MS-DOS 6.22w/Special Enhancements;
Windows



95 only SystemSoft Card & Socket Services
SECURITY (All Models) Kensingtionslot, Power-on password, screen blank, keyboard lock
WARRANTY 1 YR Parts & Labor
ENVIRONMENTAL SPECIFICATIONS
Temperature: Operating 41°F (5°C) to 95°F (35°C)
Non-operating -4°F (-20°C) to 149°(65°C)
Thermal Gradient 20°C per hour (max.)
Relative Humidity: Operating 20%to 80%non-condensing
Non-operating 10%to 90%non-condensing
Altitude: Operating -197 to 9,843ft.
Non-operating -197 to 32,808ft
Shock: Operating 10G
Non-operating 60G
Vibration: Operating 0.25G
Non-operating 1G
3. Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III. 4. Satellite 105CS (Part# PA1217U-S6W) is the Retail
equivalent of the Satellite 100CS, but comes with the following additional Windows 95 software: Microsoft Works 4.0, Microsoft
Schedule Plus 7.0, Microsoft Money 4.0, and Microsoft Golf 2.0.
