SATELLITE 4020CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S4020.DOC Rev. 1 02/07/00 st. Page 1 of 3
MODEL 4020CDT/6.4 billion bytes
PART NUMBER PAS402U-T2CW8
PROCESSOR Intel Mobile PentiumII 300Mhz (1.7v/1.8v/3.3v)
Integrated Coprocessor Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE Yes: 512KB Integrated into CPU
Type of cache memory 2 Mbit Pipelined Burst Synchronous SRAM (2.5v)
Access Time 5 ns
Data Bus Width 64 bit
Data Bus Speed 66 MHz
SYSTEM ARCHITECTURE Chipset Connecting Devices
PCI BUS (v.2.1): (32-bit, 33 MHz) Intel 440BX Graphics Controller
ISA BUS: 16-bit, 8.33 MHz N/A BIOS, KBC, Sound chip
MEMORY: 64Mbit SDRAM, 3.3V
Standard 64 MB (32MB onboard; 32MB in memory slot --- no slots free)
Maximum 160 MB (Maximum expansion requires removal of standard 32MB memory card)
Speed 60ns
Hyper Page mode memory access Yes
Data Bus width 64 bit
Local Bus Clock Speed 66 MHz
BIOS (512KB: 4Mbit FLASH EPROM, 5V) Yes: supports APM (v.1.2); VESA (v2.0); DPMS, DCC2B, DMI (v.2.0); PCI BIOS
PnP 1.0a, ACPI
DISPLAY
Type TFT Active Matrix Color (1024 x 768)
Size 13.3” Diagonal
Dot Pitch .3075mm x .3075mm
Contrast Ratio 100:1 (Min)
VIDEO
Memory: 4Mbit EDO DRAM, 3.3V 2 MB
Speed 50ns
Hyper Page mode support Yes
Controller Chip C&T 65555
Data Bus Width 128-bit
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes with 64-bit BitBLT support
2D graphics support BitBLT, DirectDraw, H/W Cursor
3D graphics support Direct3D
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling/Interpolation Yes
DirectMPEG Yes
DirectVideo support Yes:w/Game SDK driver fr/Microsoft
Color Palette 16.7M colors
Internal Support Resolution Colors Support
Full Screen 1024 x 768 64K colors
Smaller Image 640 x 480 16.7M colors
Smaller Image 800 x 600 16.7M colors
Virtual Display Mode 1280 x 1024 256 colors
External Support Resolution Colors Support Vertical Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors 85Hz @ 64K color
800 x 600 16.7M colors 85Hz @ 64K color
1024 x 768 64K colors 60 Hz @ 64K color
1280 x 1024 256 colors 60 Hz @ 64K color

SATELLITE 4020CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S4020.DOC Rev. 1 02/07/00 st. Page 2 of 3
MODEL 4020CDT/6.4 billion bytes
PART NUMBER PAS402U-T2CW8
ALL-IN-ONE DESIGN
STORAGE
Removable HDD (2.5” Enhanced IDE) 6.4 billion bytes (13msec) with 512KB Buffer --- 1 screw service removable
Height 12.7mm
Burst Data Transfer Rate Ultra DMA Mode 2 (33.3MB/s); PIO Mode 4 (16.7MB/s)
FDD (3.5” 1.44MB; 12.7mm high) Yes
Simultaneous FDD & CD-ROM Support Yes: two independent units
CD-ROM: (5.25” ; 12.7mm high, .62 lbs.) 24X Maximum Speed (14X-Average speed)
Interface .ATAPI (Enhanced IDE)
Random Access Time 130 ms
Average Sustained Transfer Rate 3,600 KB/sec
Burst Data Transfer Rate PIO Mode 4 (16.7MB/sec); Multi Word DMA Mode2 (16.6MB/sec)
Supported Disc formats CD-DA, CD-ROM, CD-R, CD-ROM XA, CD-I FMV, Photo CD (Multi-session)
Video CD, CD Extra (CD Plus), CD-G, CD-RW (read only)
PC Card MODEM (Bundled) -- 3Com-Noteworhty 56K PC Card Modem
Data support
Protocols supported Bell-103,& 212A, V.23, V.22, V.22bis, V.32, V.32bis, V.34, V.34+, V.90
Error correction V.42/MNP 2-5
Data compression MNP 5, CCITT V.42 bis
Fax support Group 3, EIA/TIA, Fax class 1
Protocols supported V.17, V.21 Channel 2, V.27 ter, V.29, V.33
Command Set Hayes, Microcom compatible AT commands
SOUND SYSTEM Yamaha Sound System
Chipset: Yamaha OPL3-SA3
16-bit stereo audio playback/record Yes
Maximum sampling rate 48 kHz
FM Synthesis support Yes (Soft Wave Table included)
Full duplex function Yes
Sound formats supported: SoundBlaster ProV3.01, Windows Sound System V2.0
3D Sound Support Yes
Direct3DSound, DirectSound support Yes: with Windows 98 Game SDK driver from Microsoft
Speaker system Two top-mounted stereo speakers (28mm, 8 Ω)
KEYBOARD
84/86 keys, 3mm Travel Yes with Windows 98 key support & 12 dedicated function keys
Cursor control (8 Keys, Inverted “T”) Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device AccuPoint
EXPANSION SLOTS
Two Stacked PC Card Slots Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
Support Standards Yes: Supports 32-bit, 3.3V PC CardBus cards and 16-bit, 5.0V PC card standards
Internal Memory Slot (One only) Yes
EXPANSION PORTS
One 9-Pin Serial (16550 UART equivalent) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One 15-Pin RGB (SVGA video) Yes
Fast Infrared port (Back only) Yes: IrDA 1.1:4Mbps compatible
One (PS/2) 101 Keyboard/Mouse port Yes: “Y”connector supported
Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
Microphone (3.5mm mini jack, stereo) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
Noteworthy security lock port Yes

SATELLITE 4020CDT Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Copyright 1996 TAIS S4020.DOC Rev. 1 02/07/00 st. Page 3 of 3
MODEL 4020CDT/6.4 billion bytes
PART NUMBER Win98 Version PAS402U-T2CW8
POWER
Autosensing External AC Adapter 6.87”L x 2.76”W x 0.73”H --- .86 lbs.
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3A (max)
Power Output (Watts) 45W
Battery Type: Li-Ion (10.8V, 3600mAH) Yes (one standard): Part# PA2487URN
Battery Life: (Full Power) 2.5+ hrs.
Recharge Time (Computer Off/On) 2.5+/10 hrs. depending on the computer function performed
Power Saving Features APM v.1.2 BIOS, Processing speed change, Auto Resume, Display Auto Off
HDD Auto Off, CPU Sleep mode, LCD Brightness switch (software)
DIMENSIONS Dimensions Weight
Notebook 11.97”W x 9.4”D x 2.13”H 7.0 lbs.
AC Adapter 6.87”L x 2.76”W x 0.73”H .86 lbs.
Battery (Standard) 6.87”L x 2.76”W x 0.73”H .88 lbs.
BUNDLED SOFTWARE (Windows 98)
Windows®98; Prodigy Internet; Symantec Norton Antivirus Scanner 4.0; Mediamatics Arcade Pak;
Ring Zero Ring Central Dialer application, Intel Indeo Video, Fn-esse, Online documentation, Online registration
CD’s Included: Enhanced Recovery CD
SECURITY Hardware Cable Lock slot, PC Card lock slot (by screw), HDD (by screw only)
Password Power-on, Supervisor, & HDD password
Miscellaneous screen blank, keyboard lock
WARRANTY 1 YR Parts / 1 YR. Labor / 1 YR. Battery
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient: 20º C per hour (max.) N/A N/A
Relative Humidity 20%to 80%non-condensing 10%to 90%non-condensing
Altitude -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock 10G; 1.5G w/CD-ROM installed 60G; 50G w/CD-ROM installed
Vibration 0.5G; 0.25G w/CD-ROM installed 1G; 1G w/CD-ROM installed
