Toshiba Satellite P300-SE3 User manual

__________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________
P300-SE3
Model:i
Satellite P300-SE3
Intel® Centrino® Duo processor technology featuring
Intel® Core™ 2 Duo Processor T5550 - 1.83GHz,
17.1” WXGA+ TFT w/ TruBrite™, 3GB DDR2, 320GB
HDD S-ATA, ATI Mobility Radeon HD 3650 256MB,
DVD Super-Multi Double Layer, Modem, LAN, Intel
802.11 agn Wireless, IEEE 1394, Integrated Web
Camera, Integrated Microphone, HDMI/TV-Out,
Windows®Vista Home Premium
Processor
Intel® Core™ 2 Duo Processor T5550 (1.83GHz, 667MHz
FSB, L1 Cache 32KB/32KB, L2 Cache 2MB)
Operating System
Microsoft®Windows®Vista Home Premium
Memory
Standard Memory: 3GB DDR2 (667MHz)
Slot 1: 2GB DDR2 (667MHz)
Slot 2: 1GB DDR2 (667MHz)
Maximum Memory: 4GB DDR2
Expansion Modules: 512MB, 1GB or 2GB DDR2
Hard Disk Drive
320.0 billion bytes, 9.5mm height, S-ATA, 5400rpm
Optical Drive
Built-in DVD Super-Multi Double Layer Drive functions:
Read: CD-ROM (24x), DVD-ROM (8x),
Write: CD-R (24x), CD-RW (4x), DVD-R (8x), DVD-R DL
(4x), DVD-RW (4x), DVD+R (8x), DVD+R DL (4x)
DVD+RW (4x), DVD-RAM (5x)
Display System
Type: TFT Active Matrix colour LCD display
Size (diagonal): 17.1” Wide XGA+ TFT with TruBrite™
Native LCD Panel Resolution: 1440x900x16.7 million
colours
External Support and Max. Colour Support (dependant
On CRT): Up to 2,048 x 1536 x 16.7 million colours
Graphics Controller
ATI Mobility Radeon HD 3650
Video Memory: 256MB dedicated VRAM
Up to 1023MB available graphics memory using
Hypermemory
Sound System
Conexant CX20561 Software Sound, Intel High Definition
Audio, built-in harman kardon® speakers, 3D Sound
Support, Direct 3D Sound, DirectSound, DirectMusic, MIDI
(playback)
Communication
V.92 56K Data/Fax Modem
10/100 integrated Ethernet LAN,
Intel 802.11 agn Wireless LAN
Bluetooth V2.1 + EDR
Integrated 1.3 Megapixel Web Camera for Video over IP
Integrated microphone for Voice over IP
Expansion
2 memory slots – Slot 1 filled with 2GB, Slot 2 filled with
1GB. Zero free slots. Slots can be filled with 512MB, 1GB, 2
GB modules
1 Express Card Slot
Ports: 5-in-1 Bridge Media Adaptor (SDHC Card, xD picture
card, Memory Stick, Memory Stick Pro, Multi Media Card), 4
USB 2.0, RJ11, RJ45, IEEE 1394, external microphone port,
headphone port/ S/P DIF, RGB, HDMI/TV-Out (S-Video)
Keyboard
CANADIAN BILINGUAL KEYBOARD
Full sized 105 keys with 13 Function keys
Dedicated Windows Keys
CD/DVD Control Function: Play/Pause, Stop, Previous
track/Next track
Color: Glossy Black
Pointing Device
Touchpad Pointing device
Additional Software
Toshiba ConfigFree™
Adobe Acrobat Reader
TOSHIBA Disc Creator
TOSHIBA DVD PLAYER
Norton Internet Security™ 2007 – 90 day trial
Microsoft Office 2007 – 60 day trial
Physical Dimensions
Dimensions: (WxDxH) 398 x 288 x 34.6/38.9 mm
Weight: 3.35kg (7.4lbs)
Color: Mercury Silver
AC Adapter
120W external Universal AC adapter input voltage (100 –
240V 50/60Hz Frequency (Universal), output voltage
(19V, 6.3A)
Dimensions: (WxHxD) 155 x 67 x 36.5 mm
Weight: 570g
Battery
Battery Type: Removable, Rechargeable 6-cell
Lithium Ion (Li-ion) 10.8V x 4000mAh capacity
Battery Life: up to 3 hours
Dimensions: (WxHxD) 208 x 21 x 74 mm
Recharge Time: Up to 4 hours off / 12 hours on
BIOS
TSETUP support, ACPI support, PnP support, VESA
support, DPMS support, DDC Support, SM BIOS support,
PCI BIOS Support
Security
Cable lock slot, user power on password, supervisor
password, HDD password
Environmental Specifications
Temperature: Operating 5°to 35°C (41°to 95°F);
Non Operating –20°to 60°C (-4°to140°F)
Thermal Gradient: Operating 15°C per hr. max;
Non Operating 20°C per hr. max
Relative Humidity: Operating 20% to 80% non-condensing;
Non-Operating: 10% to 95% non-condensing
Altitude (relative to sea level): Operating: -9.14 to 3,048m;
Non-Operating: -9.14 to 12,192m.
Shock: Operating: 10G; Non-Operating 60G
Vibration: Operating 0.5G; Non-Operating: 1G
Environmental Credentials
Energy Star 4.0
RoHS
Canada and InternationalLimited Warranty
This Satellite notebook comes with a one (1) year parts and
labour Limited International Warranty. Note the original
battery is warranted for one year from date of purchase. Pre-
installed software is excluded form TCL standard limited
warranty. For complete details on this warranty program and
other Warranty Programs such as On-site and Next Business
Day Service visit toshiba.ca
Accessories
PA3537U-1BRS 9 Cell Li-ion Battery Pack
PA3516C-1AC3 Universal AC Adapter
ACC021 USB FDD Kit
PA3511U-1M51 512MB DDR2 667MHz memory
PA3512U-1M1G 1GB DDR2 667MHz memory
PA3513U-1M2G 2GB DDR2 667MHz memory
Part Number/UPC code
PSPC4C-SE308C (Bilingual)/ 6-23506-01791-6
iToshiba of Canada Limited Information Systems Group shall
not be liable for damages of any kind for use of this
information, which is subject to change without notice.
Central Processing Unit (“CPU” Performance Disclaimer:
CPU performance in your computer product may vary from
specifications under the following conditions:
•use of certain external peripheral products
•use of battery power instead of AC power
•use of certain multimedia games or videos with special
effects
•use of standard telephone lines or low speed network
connections
•use of complex modeling software, such as high end
computer aided design applications
•use of computer in areas with low air pressure (high
altitude >1,000 meters or >3,280 feet above sea level)
•use of computer at temperatures outside the range of 5°C
to 35°C (41°F to 95°F) or > 25°C (77°F) at high altitude
(all temperature references are approximate).
CPU performance may also vary from specifications due to design
Toshiba recommendsWindows Vista™Home Premium

configuration. Under some conditions, your computer product may
automatically shutdown. This is a normal protective feature designed to
reduce the risk of lost data or damage to the product when used outside
recommended conditions. To avoid risk of lost data, always make back-
up copies of data by periodically storing it on an external storage
medium. For optimum performance, use your computer product only
under recommended conditions. Read additional restrictions under
“Environmental Conditions” in your product Resource Guide. Contact
Toshiba Technical Support for more information.
Hard Disk Drive Disclaimer: 1 Gigabyte (GB) means 1,000,000,000
bytes using powers of 10. The computer operating system, however,
reports storage capacity using powers of 2 for the definition of 1 GB =
1,073,741,824 bytes, and therefore shows less storage capacity. Available
storage capacity will also be less if the product includes pre-installed
operating system and/or application software. Actual formatted capacity
may vary.
GPU: Graphics processor unit ("GPU") performance may vary depending
on product model, design configuration, applications, power management
settings and features utilized. GPU performance is only optimized when
operating in AC power mode and may decrease considerably when
operating in battery power mode.
Memory: Part of the main system memory may be used by the graphics
system for graphics performance and therefore reduce the amount of main
system memory available for other computing activities. The amount of
main system memory allocated to support graphics may vary depending
on the graphics system, applications utilized, system memory size and
other factors. For PC's configured with 4 GB of system memory, the full
system memory space for computing activities will be considerably less
and will vary by model and system configuration.
TFT Display Disclaimer: Small bright dots may appear on your TFT
display when you turn on your PC. Your display contains an extremely
large number of thin-film transistors (TFT) and is manufactured using
high-precision technology. Any small bright dots that may appear on your
display are an intrinsic characteristic of the TFT manufacturing
technology.
LCD: Over a period of time, and depending on the usage of the computer,
the brightness of the LCD screen will deteriorate. This is an intrinsic
characteristic of LCD technology. Maximum brightness is only available
when operating in AC power mode. Screen will dim when the computer
is operated on battery power and you may not be able to increase the
brightness of the screen.
Weight: Weight may vary depending on actual configuration.
Battery: Battery life may vary considerably depending on product model,
configuration, applications, power management settings and features
utilized, as well as the natural performance variations produced by the
design of individual components. Published battery life numbers are
achieved on select models and configurations tested by Toshiba at the
time of publication. Recharge time varies depending on usage. Battery
may not charge while computer is consuming full power. After a period
of time, the battery will lose its ability to perform at maximum capacity
and will need to be replaced. This is normal for all batteries. To purchase
a new battery pack, see the accessories information that shipped with
your computer or visit the Toshiba of Canada website at
toshiba.ca/accessories
Subject to Change:
While Toshiba has made every effort at the time of publication to ensure
the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all
subject to change without notice. For the most up-to-date product
information about your computer, or to stay current with the various
computer software or hardware options, visit Toshiba’s website at
toshiba.ca/support 3/26/2008 v.1
