T2200SX
(No longer manufactured)
General Information
Model number: T2200SX 40MB - PA1023U (FCC ID# CJ6UN521)
T2200SX 60MB - PA1024U (FCC ID# CJ6UN157)
T2200SX 80MB - PA1025U (FCC ID# CJ6UN521)
Dimensions: 11.7"W x 8.3"D x 1.6"H
Weight: 5.5 lbs. with battery pack
Voltage: Computer DC input - 18VDC, 1.1A
Universal AC adapter - 100-240 VAC 50-60 Hz
Battery: Removable rechargeable Nickel Hydride battery pack
CPU: 80386SX-20 (20/10MHz), 80387SX-20 coprocessor socket
RAM memory: 2MB standard (640KB conventional; 1.384MB extended or HardRAM)
Memory expandable up to 10MB via one credit card style memory slot
when optional 2MB, 4MB, or 8MB card is added
Video RAM: 256KB
Number of keys: 82
Keyboard type: 101-key keyboard compatible
Drives: One 1.44MB 3.5" floppy disjk drive
One 40MB, 60MB, or 80MB hard disk drive
Standard features: AutoResume
HardRAM
Automatic display and hard drive shutdown
CPU sleep mode
Intelligent power supply with battery "gas gauge"
Shadow BIOS ROM
Operating system included: Toshiba MS-DOS 5.0
Software Compatibility
Compatible with software written for the IBM PC/XT/AT using VGA, EGA, or CGA resolution graphics modes
Interfaces
VGA color video port
RS-232-C serial port
Parallel printer/external diskette or tape drive port
Numeric keypad/101-key keyboard adapter port
Credit card style modem slot
150 pin expansion interface connector
PS/2 mouse port
Credit card style memory slot
Fluorescent Sidelit Supertwist LCD Display
Display area: 7.6"W x 5.7"H; 9.5" diagonal
Resolution: 640 x 480
Dot dimension: .24mm x .24mm
Dot pitch: .27mm x .27mm
Aspect ratio: 1 : 1
Contrast: 15 : 1
Gray scales: 16 gray scales
T2200SX(continued)

Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to
change without notice. Copyright 1994 TAIS. 2200SX.DOC Rev. 1 05/27/94 MQC/nmm.
Page 3
2.5" 40MB Hard Disk Drive
Conner Peripherals HDD: CP2044
Interface: IDE
Average access time 19ms
Recording method: 2-7 RLL
2.5" 60MB Hard Disk Drive
Conner Peripherals HDD: CP2064
Interface: IDE
Average access time: 19ms
Recording method: 2-7 RLL
2.5" 80MB Hard Disk Drive
JVC HDD: JDE2085M
Interface: IDE
Average access time: 16ms
Recording method: 2-7 RLL
Soft Switches
1) Change CPU speed
Fn + PgUp 20MHz CPU Speed
Fn + PgDn 10MHz CPU Speed
2) Pop-up window
Fn + Esc Toggles pop-up window
3) Keypad overlay
Fn + F10 Toggles keypad overlay
Fn + F11 NUM LOCK
4) FN key
Fn + CTRL Simulate IBM enhanced keyboard Right Ctrl
Fn + ALT Simulate IBM enhanced keyboard Right Alt
Fn + enter Simulate IBM enhanced keyboard numeric keypad Enter
Hardware Switches and Controls
1) Power on/off
Located on left side of computer
2) Reset
Located on left side of computer
3) LCD brightness and contrast dials
Located on right side of display
Environmental Specifications
1) Operating condition
Ambient temperature: 41 to 95 degrees F. 5 to 35 degrees C.
Relative Humidity: 20% to 80% non-condensing
Altitude (from sea level): -200 to 10,000 ft. (-60 to 3,000 meters)
2) Non-Operating condition
Ambient temperature: -4 to 140 degrees F. -20 to 60 degrees C.
Relative Humidity: 8% to 80% non-condensing
Altitude (from sea level): 30,000 ft. (10,000 meters) max.
3) Wet bulb temperature condition
Ambient temperature: 79 degrees F. (26 degrees C.) maximum
T2200SX(continued)

Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to
change without notice. Copyright 1994 TAIS. 2200SX.DOC Rev. 1 05/27/94 MQC/nmm.
Page 3
Options and Extra Accessories
PC-PA2000U 2MB memory card (no longer manufactured)
PC-PA2001U 4MB memory card (no longer manufactured)
PC-PA2002U 8MB memory card (no longer manufactured)
PC22-T24M 2400 bps credit card size Hayes compatible MNP5 modem (no longer manufactured)
PC-PA7225U 5.25" 360KB external FDD with 18VDC adapter
PC-PA2404URA NiMh battery pack - 2200 mAh
PC-PA2500L Battery pack recharger with AC adapter (no longer manufactured)
PC-PA2400U Universal AC adapter 18 VDC
PC-PA750L Auto adapter - 12 VAC (no longer manufactured)
PC-PA801L Statpower Prowatt 125 auto adapter
PC-PA2113 Toshiba 150 pin SCSI adapter (replaces PC-PA2112)
PC-PA7354E 17-key numeric keypad
PC-PA8718U 101-key keyboard adapter with external power supply
PC-PA722L TD80 external tape backup drive (no longer manufactured)
PC-PA2700UXZ Desk Station lV (replaces PC-PA2700UX)
PC-PA2701U Desk Station IV (replaces PC-PA2700UXZ)
PC-PA270L Axonix Cablemate port replicator
PC-PA3300L PC Guardian computer lock (no longer manufactured)
PC-PA877LX Fabric carrying case (no longer manufactured)
PC-PA1000L Leather carrying case (no longer manufactured)
PC-PA1050L Leather attache case
PC13-PA874L Executive leather portfolio (no longer manufactured)
NWCCAFB Twin fabric carrying case
NWCCALB Twin leather carrying case
PC-PA180B Blue PC Pack carrying case
PC-PA180R Red PC Pack carrying case
PR-PA2750U ExpressWriter 201 portable printer (no longer manufactured)
PC-SW013 Toshiba MS-DOS 5.0 (no longer manufactured)
PC-SW015 Toshiba MS-DOS 5.0 (no longer manufactured)
PC-SW007 Toshiba MS-DOS 4.01 (no longer manufactured)
PC-SW004 Toshiba BASIC 3.30 (no longer manufactured)
PC-SW012 Toshiba MS OS/2 operating system 1.21 (no longer manufactured)
System Memory Map
Address range Space (Kilobytes) Used For:____________
'000000' 640 Conventional
'09FFFF' memory______________
'0A0000' 128 Video RAM
'0BFFFF' _____________________________________________
'0C0000' 32 VGA BIOS ROM
'0C7FFF' ______________________________________
'0C8000' 96 Reserved
'0DFFFF' ______________________________________
'0E0000' 32 HardRAM window
'0E7FFF' ______________________________________
'0E8000' 32 Backup RAM
'0EFFFF' ______________________________________
'0F0000' 64 System BIOS ROM
'0FFFFF' ______________________________________
'100000' 1,408 System working
'25FFFF' memory_______________
'260000' 8,192 Optional working memory
'A5FFFF' ______________________________________
'FF0000' 64 System BIOS ROM
'FFFFFF' (Duplicated)____________
T2200SX(continued)
Interrupts
Interrupt Level Assigned To:__________________
-- NMI RAM Parity Error, I/O Channel Error

Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to
change without notice. Copyright 1994 TAIS. 2200SX.DOC Rev. 1 05/27/94 MQC/nmm.
Page 3
0Timer
1 Keyboard
2 PIC 2 for level 8 to 15
1 3 Secondary Communications (COM 2)
4 Primary Communications (COM 1)
5PRT2
6FDC
7 PRT 1_________________________
8RTC
9 Software Redirect to INT '0A'
2 10 (Reserved)
11 (Reserved)
12 PS/2 Mouse
13 NDP
14 HDC
15 (Reserved)
I/O Port Assignment
Port Address
From / To Device / Function______
'000' / '01F' 82C37 : DMA Controller 1
'020' / '03F' 82C59 : PIC 1
'040' / '05F' 82C54 : Timer
'060' / '06F' 80C42 : KBC
'070' NMI
'070' / '07F' RTC
'080' / '09F' DMA Page Register
'0A0' / '0BF' 82C59 : PIC 2
'0C0' / '0DF' 82C37 : DMA Controller 2
'0E0' / '0EF' Special Register
'0F0' / '0F7' 80387SX : NDP
'100' / '1EF' VGA
'1F0' / '1FF' HDC
'200' / '207' Game I/O
'208' / '20F' (Not used)
'210' / '217' Expansion Unit
'218' / '277' (Not used)
'278' / '27F' Parallel PRT 2
'280' / '2F7' (Not Used)
'2F8' / '2FF' Serial Port 2 (COM 2)
'300' / '31F' Prototype card
'320' / '32F' XT type HDC
'330' / '337' (Not Used)
'338' / '33F' Serial Port 3 (COM 3)
'340' / '377' (Not Used)
'378' / '38F' Parallel PRT 1
'380' / '38F' SDLC, Bisynchronous 2
'390' / '39F' (Not Used)
'3A0' / '3AF' Bisynchrounous 1
'3B0' / '3BF' MDA, PRT
'3C0' / '3DF' CGA, EGA, VGA
'3E0' / '3E7' (Not Used)
'3E8' / '3FF' Serial Port 3 (COM 3)
'3F0' / '3F7' FDC
'3F8' / '3FF' Serial Port 1 (COM1)f
