Toshiba Tecra Z40-A Series User manual

QUICK START
Tecra®
Z40–A Series

Check the components
Getting started
• AC adaptor and adaptor cord
• Power cord/cable
• Documentation, including this Quick Start document and a Standard Limited Warranty
• Other components, depending upon model
Connect to a power source
Assemble the power cord/cable and AC adaptor and then connect it to your computer
and a live electrical outlet. You are now ready to start using your computer.
Connect to the Internet
Connect to a network to take full advantage of your computer’s features.
Backup your computer
It is strongly recommended that you create a back up of your computer before using
it for the rst time. This will enable you to return it to its out-of-box state, if necessary.
For complete instructions on how to create recovery media, see the “Creating recovery
media” section in this document.
Register your computer
Enhance your ownership experience by taking a few minutes to register your Toshiba
Product at register.toshiba.com. Completing Product registration allows Toshiba to
provide you with Product information updates, special oers and promotions. Failure
to complete Product registration will not diminish your rights under the Standard
Limited Warranty.
California Prop 65 Warning
This product contains chemicals, including lead, known to the State of
California to cause cancer and birth defects or other reproductive harm.
Wash hands after handling.
• Avoid prolonged physical contact with the underside or surface of the
computer.
• Computer base and palm rest can become hot! Avoid prolonged
contact to prevent heat injury to skin.
Note: The computer’s battery is not accessible by the user.
Notice
• Certain computer chassis are designed to accommodate all possible congurations
for an entire product series. Your select model may not have all the features and
specications corresponding to all of the icons or switches shown on the computer
chassis, unless you have selected all those features.
•Subject to Change. Product specications, congurations, prices, system/
component/options availability are all subject to change without notice.
Your computer comes with:

Underside
Front with display open
* Available on certain models.
** Location may vary.
Keyboard
Screen
Power button
Primary and
secondary
control
buttons
Web Camera*
Web Camera indicator*
NOTE: Your computer
may be enabled with a
touch screen feature.
Internal microphone*Internal microphone*
Touch pad
Touch pad
ON/OFF button
eco Utility®button
AccuPoint®II
pointing device*
Primary and
secondary
control
buttons
Fingerprint reader*
System indicator lights
ON/OFF light
AC power light/
Battery light
Internal storage drive light
Expansion port*
*Available on certain models.
Quick Tour

Front with display closed
Back
Left side
Right side
Speakers
Wireless indicator
*Available on certain models.
HDMI™ Out port*
RGB (Monitor) port* Memory card reader
USB 3.0 port*
(USB Sleep and Charge )
Cooling Vents
*Available on certain models.
Network port
Headphone/microphone jack
USB 3.0 port
USB 3.0 port*
DC-In
Smart card reader*
Security lock slot

Creating Recovery Media
To create recovery DVDs/media with Microsoft®Windows®7:
1. Click the Start button and, in the Search eld, type Recovery Media Creator. In the
list that appears above, click on your selection.
The TOSHIBA Recovery Media Creator dialog box displays.
2. Select DVD or USB Flash from the drop-down list next to “System Recovery
Media,” depending on the type of external media you want to use.
3. Check the Information area of the dialog box to determine the number of DVDs you
will need and/or the minimum amount of storage space required for copying your
system’s recovery les to USB ash drive(s).
4. Do one of the following:
• If you are copying les to DVD, insert a blank DVD into the optical disc drive.
• If you are copying les to a USB ash drive, connect a USB ash drive of the
required minimum capacity (as specied in the TOSHIBA Recovery Media Creator
utility) to your computer.
All information stored on your DVDs or USB ash drive(s) will be erased
during the process of creating the recovery DVDs/media. Be sure to save the
information stored on your external media to another storage device before
executing this procedure, or use blank media.
5. Click the Create button in the TOSHIBA Recovery Media Creator utility dialog box.
6. Follow the on-screen prompts to complete the copy process.
NOTE: If you are copying the recovery les to DVDs, be sure to label each DVD in the
set sequentially (for example, “1 of 3,” “2 of 3,” etc.), so that you will know in
which order to insert the discs during recovery.

General Safety Instructions
Please read the following safety and operating instructions before using your
Product. Keep the information near your Product for future reference.
To reduce the risk of re, bodily injury and/or damage to your Product, please
observe all of the following instructions:
AC Adaptor
Always use the Toshiba AC adaptor that was provided with your Product or as
specied by Toshiba.
Base or Palm Rest
Avoid extended contact between Product base or palm rest and your skin. Under
certain operating conditions such prolonged contact may result in skin irritation
and/or heat injury. Consider using a hard computer insulating pad or similarly
suitable hard insulating material when using Product on your lap.
(Internal) Battery
Your Product may contain an internal battery for powering the real-time clock.
Replacement or service should be done by an authorized Toshiba service provider.
Circulation and Cooling
Allow sucient air circulation around Product and AC adaptor during use and
while charging the battery to ensure adequate cooling of the device. Prevent
direct exposure to heat sources.
Cleaning
Unplug Product from the electrical outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. The injected combustible gas produced by these
types of cleaners may remain inside of your product. The electrostatic spark from
the motor or contact point of switch may ignite the gas residue, which could
result in an explosion, re, or burn injury. Instead use a lightly dampened cloth for
cleaning in general and remove dust with a dry cloth.
Comfort Recommendations
When you use your Product, rest your eyes periodically and relax or stretch
your muscles to avoid strain. Adjust your chair, feet and Product accordingly
to achieve optimal working posture. Please refer to Toshiba’s “User Comfort
Recommendations” in the User’s Guide.
Viewing Recommendations
Some individuals may experience health-related complications when exposed
to certain images or ashing lights (for example when playing videos or games).
Discontinue use and consult a physician if you experience any health-related
complications.
Choking Hazards
Keep Product away from small children. This Product is not a toy and may be
hazardous to small children, for example, small detachable parts may be a
choking hazard.
Disassembly
Do not disassemble, modify, tamper with or repair your Product.
Disposal
Dispose of Product or any components in compliance with all applicable laws.

Foreign Objects
Never push a foreign object through an opening in the Product. Never allow metal
objects (such as screws, staples, or paper clips) to enter Product. This could
cause a short circuit.
Heat
Keep Product away from radiators, stoves, heat sources or other equipment that
produce heat.
Hot Surfaces
Allow the equipment’s internal components and hot-pluggable drives to cool
before touching them.
Unstable Surfaces
Do not use Product on an unstable table, cart or stand.
Operating Environment
Never expose your Product to excess heat, extremely low temperatures,
sudden temperature variations, or dusty environments. This could cause system
malfunction, loss of data or damage to Product.
Power Cables/Cords and Power Source
Always use power cables/cords and power sources that comply with the voltage
and frequency specications and requirements of the country of use.
Service Provider
Disconnect Product from the electrical outlet and take Product to an authorized
Toshiba service provider if:
• AC adaptor or power cable/cord is damaged.
• Liquid has spilled into Product or an object (such as a screw, staple or paper
clip) has entered Product.
• Product has been dropped, subject to shock or impact and/or damaged in
some way.
• Noticeable signs of overheating, smoke, deformation, cracks, leaks or unusual
odor occur.
• Service is needed on component inside compartments requiring opening or
removal of covers.
Thunderstorm
Never operate your Product during a thunderstorm. An electrical surge caused by
the storm may cause system failure, loss of data or hardware damage.
Wireless Functionalities
Turn o your Product and/or all wireless functionalities where electronic devices
are regulated or controlled or when near a person with any medical electric
devices.
Ventilation
Operate your Product on a hard at surface to ensure reliable operation and good
ventilation. Using your Product on a soft surface such as carpet or sofa can block
slots, vents or openings and cause overheating.
Water and moisture
Do not use Product in a wet location. Do not connect/disconnect a power plug/
cord with wet hands.

©2014 Toshiba America Information Systems, Inc.
GMA501251011 • 11/14
Printed on recycled paper
Tecra, AccuPoint, and eco Utility are registered trademarks or trademarks of Toshiba America Information Systems, Inc. and/or Toshiba Corporation.
HDMI, the HDMI Logo and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
All other brand and product names are trademarks or registered trademarks of their respective companies.
Need Help?
Visit Toshiba’s Support Web site
Technical support is available online at Toshiba’s Web site at
support.toshiba.com. At this Web site, you will nd answers for many
commonly asked technical questions plus many downloadable software
drivers, BIOS updates, and other downloads.
