Toshiba 26C100U1 User manual

Owner’s Manual
Integrated High Definition
HIGH-DEFINITION TELEVISION
LCD Television
2632C100U1EN-A5-Cover-O.ai2010/3/2下午02:05:54

2
Dear Customer,
Thank you for purchasing this Toshiba LCD TV. This
manual will help you use the many exciting features
of your new LCD TV. Before operating your LCD TV,
please read this manual completely, and keep it
nearby for future reference.
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
WARNING
RISK OF ELECTRIC
SHOCK DO NOT OPEN.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
To prevent injury, this apparatus must be securely
attached to the floor/wall in accordance with the
installation instructions. See item 25 on page 4.
WARNING: If you decide to wall mount this
television, always use a UL Listed wall bracket
appropriate for the size and weight of this television.
The use of any wall bracket other than a UL Listed
wall bracket appropriate for the size and weight of this
television for wall mounting this television could result
in serious bodily injury and/or property damage. See
“Removing the Pedestal Stand” ( page 6).
NOTE TO CATV INSTALLERS
This is a reminder to call the CATV system installer’s
attention to Article 820-40 of the U.S. NEC, which
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical. For
additional antenna grounding information, see items
32 and 33 on page 4.
Congratulations on your purchase! As you enjoy your
new product, please keep these safety tips in mind:
The Issue
• The home theater entertainment experience is a growing trend
and larger flat panel displays are popular purchases. However,
flat panel displays are not always supported on the proper stands
or installed according to the manufacturer’s recommendations.
• Flat panel displays that are
inappropriately situated on dressers,
bookcases, shelves, desks,
speakers, chests or carts may fall
over and cause injury.
TOSHIBA Cares!
• The consumer electronics industry
is committed to making home
entertainment enjoyable and safe.
Tune Into Safety
• One size does NOT fit all. Follow the manufacturer’s recommendations
for the safe installation and use of your flat panel display.
• Carefully read and understand all enclosed instructions for
proper use of this product.
• Don’t allow children to climb on or play with furniture and
television sets.
• Don’t place flat panel displays on
furniture that can easily be used as
steps, such as a chest of drawers.
• Remember that children can
become excited while watching a
program, especially on a “larger
than life” flat panel display. Care
should be taken to place or install
the display where it cannot be
pushed, pulled over, or knocked down.
• Care should be taken to route all cords and
cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
Wall Mounting: If you decide to wall mount your
flat panel display, always:
• Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory (such
as UL, CSA, ETL).
• Follow all instructions supplied by the display and wall mount
manufacturers.
• If you have any doubts about your ability to safely install your
flat panel display, contact your retailer about professional
installation.
• Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction. If you
are unsure, contact a professional
installer.
• A minimum of two people are
required for installation. Flat panel
displays can be heavy.
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat
Panel Display
26_32C100U1_EN-A5.indb 2 2010/3/2 上午 11:28:32

3
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized
or grounding type plug. A polarized
plug has two blades with one wider
than the other. A grounding type
plug has two blades and a third
grounding prong. The wide blade or
the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on
or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or
sold with the apparatus. When a cart is
used, use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms
or when unused for long periods of time.
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
Additional Safety Precautions
14a)CAUTION: If the TV is dropped and the cabinet or
enclosure surface has been damaged or the TV does
not operate normally, take the following precautions:
• ALWAYS turn off the TV and unplug the power
cord to avoid possible electric shock or fire.
• NEVER allow your body to come in contact with
Wide blade
any broken glass or liquid from the damaged
television. The LCD panel inside the TV contains
glass and a toxic liquid. If the liquid comes in
contact with your mouth or eyes, or your skin
is cut by broken glass, rinse the affected area
thoroughly with water and consult your doctor.
• ALWAYS contact a service technician to inspect the
TV any time it has been damaged or dropped.
15) CAUTION:
• To reduce the risk of electric shock, do not
use the polarized plug with an extension cord,
receptacle, or other outlet unless the blades can
be inserted completely to prevent blade exposure.
• To prevent electric shock, match wide blade of plug
to wide slot; fully insert.
16 ) CAUTION:
Do not let children swallow the product or play with
the plastic bag. Keep the product and the plastic bag
out of the reach of children.
17 ) CAUTION :
Do not let water or other liquids come into contact
with the product, as it may result in damage.
18 ) WARNING :
• To prevent the spread of fire, keep candles or other
open flames away from this product at all times.
• Keep the product away from direct sunlight, fire or
a heat source such as a heater. This may reduce the
product lifetime or result in fire.
Installation, Care, and Service
Installation
Follow these recommendations and precautions and
heed all warnings when installing your TV:
19) WARNING: NEVER expose batteries
to excessive heat such as sunshine,
fire or the like.
20) ALWAYS plug the product into an outlet that is
located in such a manner that it can be easily
unplugged in case the product requires service.
21) NEVER route the product’s power cord inside a wall
or similar enclosed area.
22) Never modify this equipment. Changes or
modifications may void: a) the warranty, and b) the
user’s authority to operate this equipment under the
rules of the Federal Communications Commission.
23) DANGER: RISK OF SERIOUS PERSONAL
INJURY, DEATH, OR
EQUIPMENT DAMAGE!
Never place the TV on an unstable
cart, stand, or table. The TV may fall,
causing serious personal injury,
death, or serious damage to the TV.
26_32C100U1_EN-A5.indb 3 2010/3/2 上午 11:28:33

4
24) To avoid damage to this product, never place or store
the TV in direct sunlight; hot, humid areas; or areas
subject to excessive dust or vibration.
25) Always place the TV on the floor or a sturdy, level,
stable surface that can support the weight of the unit.
To secure the TV, use a sturdy strap from the hook(s)
on the rear of the TV to a wall stud, pillar, or other
immovable structure. Make sure the strap is tight,
secure, and parallel to the floor.
potVTedisVT
4"
min.
Hook
Sturdy strap (as short as possible)
26) The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such
as vases, shall be placed on the apparatus.
27) Never block or cover the slots or openings in the TV
cabinet back, bottom, and sides. Never place the TV:
• on a bed, sofa, rug, or similar surface;
• too close to drapes,
curtains, or walls; or
• in a confined space such
as a bookcase, built-in
cabinet, or any other place
with poor ventilation.
The slots and openings are provided to protect the
TV from overheating and to help maintain reliable
operation of the TV. Leave a space of at least 4 (four)
inches around the TV.
28) Always place the back of the television at least four
(4) inches away from any vertical surface (such as a
wall) to allow proper ventilation.
29) Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord is
subject to wear or abuse.
30) Never overload wall outlets and extension cords.
31) Always operate this equipment from a 120 VAC, 60
Hz power source only.
32) Always make sure the antenna system is properly
grounded to provide adequate protection against
voltage surges and built-up static charges (see
Section 810 of the National Electric Code).
Antenna lead-in wire
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system
(NEC Art 250 Part-H)
Ground clamp
Electric service
equipment
Ground clamps
33) DANGER: RISK OF SERIOUS
PERSONAL INJURY OR DEATH!
• Use extreme care to make sure you are never in
a position where your body (or any item you are
in contact with, such as a ladder or screwdriver)
can accidentally touch overhead power lines.
Never locate the antenna near overhead power
lines or other electrical circuits.
• Never attempt to install any of the following
during lightning activity: a) an antenna system;
or b) cables, wires, or any home theater
component connected to an antenna or phone
system.
Care
For better performance and safer operation of your TOSHIBA
TV, follow these recommendations and precautions:
34) If you use the TV in a room whose temperature is
32 °F (0 °C) or below, the picture brightness may
vary until the LCD warms up. This is not a sign of
malfunction.
35) Always unplug the TV before cleaning. Gently wipe
the display panel surface (the TV screen) using a dry,
soft cloth only (cotton, flannel, etc.). A hard cloth
may damage the surface
of the panel. Avoid contact
with alcohol, thinner,
benzene, acidic or alkaline
solvent cleaners, abrasive
cleaners, or chemical
cloths, which may damage the surface. Never spray
volatile compounds such as insecticide on the
cabinet. Such products may damage or discolor the
cabinet.
36) WARNING:
RISK OF ELECTRIC SHOCK!
Never spill liquids or push objects of any kind into
the TV cabinet slots.
37) While it is thundering, do not touch the
connecting cables or apparatus.
38) For added protection of your TV from lightning
and power surges, always unplug the power
cord and disconnect the antenna from the TV if
you leave the TV unattended or unused for long
periods of time.
39) ALWAYS unplug the TV to completely disconnect
from mains power. When the TV is turned off using
the on/off switch, it is not completely disconnected
from power and a minute amount of current is still
consumed.
(continued)
26_32C100U1_EN-A5.indb 4 2010/3/2 上午 11:28:34

5
40) During normal use, the TV may make occasional
snapping or popping sounds. This is normal,
especially when the unit is being turned on or off. If
these sounds become frequent or continuous, unplug
the power cord and contact a Toshiba Authorized
Service Center.
41) DANGER: RISK OF SERIOUS
PERSONAL INJURY OR DEATH!
Never strike the screen
with a sharp or heavy
object.
42) •TheLCDscreenofthisproductcanbedamaged
by ultraviolet radiation from the sun. When
selecting a location for the television, avoid
locations where the screen may be exposed to
direct sunlight, such as in front of a window.
• Never touch, press, or place anything on the LCD
screen. These actions will damage the LCD screen.
If you need to clean the LCD screen, follow the
instructions in item 35 on page 4.
Service
43)
WARNING:
RISK OF ELECTRIC SHOCK!
Never attempt to service the TV yourself. Opening
and removing the covers may expose you to
dangerous voltage or other hazards. Failure to follow
this WARNING may result in death or serious injury.
Refer all servicing not specified in this manual to a
Toshiba Authorized Service Center.
44) If you have the TV serviced:
• Ask the service technician to use only replacement
parts specified by the manufacturer.
• Upon completion of service, ask the service technician
to perform routine safety checks to determine that the
TV is in safe operating condition.
45) The cold cathode fluorescent lamp in the LCD panel
contains a small amount of mercury.
When the TV reaches the end of its useful life,
dispose of the used TV by the approved method for
your area, or ask a qualified service technician to
properly dispose of the TV.
Note: The lamp(s) inside this
product contain mercury. Disposal
may be regulated due to
environmental considerations. For disposal
or recycling information, contact your local
authorities or the Electronics Industries
Alliance (www.eiae.org).
Choosing a location for your LCD TV
To Display your LCD TV on the included
Pedestal Stand:
Observe the following safety precautions:
1) Read and Follow the pedestal assembly instructions
included with the pedestal.
CAUTION: Before beginning pedestal assembly,
carefully lay the front of the LCD Panel face down on
a flat, cushioned surface such as a quilt or blanket.
Leave the bottom of the unit protruding over the edge
of the surface and assemble the pedestal as indicated
below.
Note: Extreme care should always be used
when attaching the pedestal stand to avoid
damage to the LCD panel.
2) Place the TV on a sturdy, level surface that can
support the weight of the TV.
3) Be sure to secure the TV to a wall, pillar, surface, or
other immovable structure. (item 25, page 4).
To Display your LCD TV using a Wall
Bracket:
If you decide to wall mount your LCD TV, always use
a UL listed wall bracket appropriate for the size and
weight of the LCD TV (page 2):
1) CAUTION: Two people are required for installation.
2) Unplug and remove any cables and/or other
component connectors from the rear of the TV.
3) Remove the screws of the VESA Mounting Pattern
show in the next page.
4) Always use the screws supplied or recommended
by the wall mount manufacturer.
5) Follow the instructions provided with your wall
bracket. Before proceeding, make sure the
appropriate bracket(s) are attached to the wall and
the back of the TV as described in the instructions
provided with the wall bracket.
6) After attaching the appropriate bracket(s) to the
wall and the back of the TV, remove the pedestal
stand from the TV as described below.
(continued)
26_32C100U1_EN-A5.indb 5 2010/3/2 上午 11:28:34

6
7) VESA Mounting Pattern
TV Size Hole Pattern(HxV) Screw Size
26” 200x100 mm M4
32” 200x200 mm M6
(unit in mm)
Removing the Pedestal Stand
1) Carefully lay the front of the unit face down on a
flat, cushioned surface such as a quilt or blanket.
Leave the stand protruding over the edge of the
surface.
Note: Extreme care should always be used
when removing the pedestal stand to avoid
damage to the LCD panel.
2) Remove the four screws shown in the below
diagram. This will allow removal of the pedestal
stand.
3) Once you have removed all four screws, holding
the pedestal stand in place, remove the pedestal
stand from the TV.
CAUTION: Always place the TV on the floor or a
sturdy, level, stable surface that can support the
weight of the unit. To secure the TV, use a sturdy
strap from the hook(s) on the rear of the TV to a wall
stud, pillar, or other immovable structure. Make sure
the strap is tight, secure, and parallel to the floor.
26” TV
Four screws
VESA Mounting Pattern
Hook
Sturdy strap
(as short as possible)
32” TV
Four screws
VESA Mounting Pattern
Hook
Sturdy strap
(as short as possible)
26_32C100U1_EN-A5.indb 6 2010/3/2 上午 11:28:35

7
FCC Declaration of Conformity
Compliance Statement (Part 15):
The Toshiba 26C100U1, 26C10U1, 32C100U1, and
32C10U1 Televisions comply with Part 15 of the FCC
rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
The party responsible for compliance to these rules is:
Toshiba America Consumer Products, L.L.C.
82 Totowa Rd. Wayne, NJ 07470.
Ph: 1-800-631-3811
Note: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by removing
and applying power to the equipment, the user is
encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
the receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications to this
equipment not expressly approved by Toshiba
could void the user’s authority to operate this
equipment.
Important notes about your
LCD TV
The following symptoms are technical limitations
of LCD Display technology and are not an
indication of malfunction; therefore, Toshiba is
not responsible for perceived issues resulting from
these symptoms.
1) An afterimage (ghost) may appear on the screen if
a fixed, nonmoving image is displayed for a long
period of time. The afterimage is not permanent
and will disappear in a short period of time.
2) The LCD panel contained in this TV is
manufactured using an extremely high level
of precision technology; however, there may
be an occasional pixel (dot of light) that does
not operate properly (does not light, remains
constantly lit, etc.). This is a structural property of
LCD technology, is not a sign of malfunction, and
is not covered under your warranty. Such pixels
are not visible when the picture is viewed from a
normal viewing distance.
Note: Interactive video games that involve
shooting a “gun” type of joystick at an on-
screen target may not work with this TV.
Trademark Information
• Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol are trademarks
of Dolby Laboratories.
• HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in
the United States and other countries.
• MPEG Layer-3 audio coding technology
licensed from Fraunhofer IIS and Thomson.
26_32C100U1_EN-A5.indb 7 2010/3/2 上午 11:28:36

8
Contents
Important Safety Instructions ............................... 3
Installation, Care, and Service............................. 3
Chapter 1: Introduction ...................................... 9
Features of your new TV .............................................................9
Overview of steps for installing, setting up,
and using your new TV ......................................................10
TV front and side panel controls and connections....................11
TV back panel connections........................................................12
Chapter 2: Connecting your TV ............................13
Overview of cable types.............................................................13
About the connection illustrations.............................................13
Connecting a VCR and antenna, Cable TV or Camcorder .......14
Connecting a DVD player with ColorStream®
(component video), a VCR, and a satellite receiver ..........15
Connecting an HDMI®or DVI device to the HDMI input .......16
REGZA-LINK®connection.......................................................17
Connecting a digital audio system.............................................18
Connecting a personal computer (PC).......................................18
Chapter 3: Using the remote control......................20
Installing the remote control batteries .......................................20
Remote control effective range..................................................20
Learning about the remote control.............................................21
Chapter 4: Menu layout and navigation ..................22
Main menu layout......................................................................22
Setup/Installation menu layout ..................................................23
Navigating the menu system......................................................23
Chapter 5: Setting up your TV..............................24
Initial Setup ................................................................................24
Selecting the menu language .....................................................24
Configuring the antenna input source for the ANT/CABLE
terminal...............................................................................24
Programming channels into the TV’s channel memory............24
Programming channels automatically.......................................24
Setting channel skip ...................................................................25
Labeling channels ......................................................................26
Setting the HDMI®audio mode.................................................27
Viewing the digital signal meter ................................................27
Setting the time zone..................................................................27
Viewing the system status..........................................................28
Chapter 6: Using the TV’s features........................29
Selecting the video input source to view...................................29
Labeling the video input sources...............................................29
Tuning channels .........................................................................30
Tuning channels using the Channel Browser™......................30
Setting the Channel Tuning Mode.............................................32
Tuning to the next programmed channel ..................................33
Tuning to a specific channel
(programmed or unprogrammed) ..................................33
Switching between two channels using SurfLock™ ...............33
Selecting the picture size ...........................................................33
Scrolling the TheaterWide®picture
(TheaterWide 2 and 3 only)................................................35
Using the auto aspect ratio feature ............................................35
Selecting the cinema mode .......................................................36
Using the FREEZE feature........................................................36
Adjusting the picture..................................................................36
Selecting the picture mode.........................................................36
Adjusting the picture quality .....................................................37
Using the closed caption mode..................................................37
Base closed captions ..................................................................37
Digital CC Settings ...................................................................38
CC Selector.................................................................................38
Adjusting the audio....................................................................38
Muting the sound........................................................................38
Using the digital audio selector .................................................38
Selecting stereo/SAP broadcasts ...............................................39
Adjusting the audio quality........................................................39
Selecting the optical audio output format .................................39
Using the Dolby®Digital Dynamic Range Control feature.....40
Using the Locks menu ...............................................................40
Entering the PIN code................................................................40
If you cannot remember your PIN code....................................40
Changing your PIN code ...........................................................40
Blocking TV programs and movies
by rating (V-Chip) ..........................................................40
Downloading an additional rating system
for blocking TV programs and movies..........................41
Locking channels .......................................................................42
Unlocking programs temporarily..............................................43
Using the input lock feature.......................................................43
Using the GameTimer®..............................................................43
Using the control panel lock feature..........................................43
Using the PC settings feature.....................................................44
Setting the PC Audio..................................................................44
Using the Media Player..............................................................45
Using the Media Player with USB............................................45
To select the Auto Start function ...............................................45
To open the Media Player .........................................................45
Viewing photo files ...................................................................46
Single View.................................................................................46
Slideshow....................................................................................46
Playing music files .....................................................................46
During playback.........................................................................47
Viewing photo files with playing music files at same time......47
Setting the sleep timer................................................................48
Using REGZA-LINK®...............................................................48
REGZA-LINK®playback device (DVD player, etc.) control 48
REGZA-LINK®input source selection ....................................49
VOLUME and MUTE controls of Audio Receiver .................49
Other REGZA-LINK®functions...............................................49
Displaying TV status information .............................................50
Understanding the auto power off feature.................................50
Understanding the last mode memory feature ..........................50
Chapter 7: Using the TV’s advanced features ...........51
Using the advanced picture settings features.............................51
Using Dynamic Contrast............................................................51
Using the static gamma feature .................................................51
Selecting the color temperature.................................................51
Using CableClear®digital noise reduction ...............................52
Using MPEG noise reduction....................................................52
Using the Game Mode feature...................................................52
Chapter 8: Troubleshooting ................................53
General troubleshooting.............................................................53
Chapter 9: Appendix.........................................55
Specifications .............................................................................55
Acceptable signal formats for PC IN and HDMI terminals......56
Limited United States Warranty for LCD Televisions ..............57
Limited Canadian Warranty for Toshiba Brand Flat Panel
Televisions ..........................................................................58
26_32C100U1_EN-A5.indb 8 2010/3/2 上午 11:28:36

9
Features of your new TV
The following are just a few of the many exciting
features of your new Toshiba widescreen, integrated
HD, LCD TV:
• Integrated digital tuning (8VSB ATSC and
QAM) eliminates the need for a separate digital
converter set-top box (in most cases).
• 1366 x 768 output resolution.
• Two HDMI®digital, high-definition multimedia
interfaces 1080p input support ( page 16).
• One set of ColorStream®HD high-resolution
component video inputs ( page 15).
• Digital Audio Out optical audio connection with
Dolby®Digital optical output format ( page 39).
• CableClear®digital picture noise reduction (
page 52).
• PC IN (Analog RGB) computer terminal ( page
18-19).
• Channel Labeling allows you to put the Call
Letters (e.g. ABC, HBO, etc.) on the screen along
with the station numbers, so you always know
what you’re watching ( page 26).
• REGZA-LINK allows control of external devices
from the TV remote via HDMI connection(
page 49).
• Media Player allows you to view photo files and
to play music files.(page 45).
Chapter 1: Introduction
26_32C100U1_EN-A5.indb 9 2010/3/2 上午 11:28:36

10
Chapter 1: Introduction
Overview of steps for installing,
setting up, and using your new TV
Follow these steps to set up your TV and begin using
its many exciting features.
1Carefully read the important safety, installation,
care, and service information. Keep this manual
for future reference.
2Observe the following when choosing a location
for the TV:
•Read “Important notes about your LCD TV”
( page 7).
•Place the TV on the floor or a sturdy, level,
stable surface that can support the weight of the
unit. Secure the TV to a wall, pillar, or other
immovable structure (page 4).
•Place the TV in a location where light does not
reflect on the screen.
•Place the TV far enough from walls and other
objects to allow proper ventilation. Inadequate
ventilation may cause overheating, which will
damage the TV. THIS TYPE OF DAMAGE
IS NOT COVERED UNDER THE TOSHIBA
WARRANTY.
3Do not plug in any power cords until AFTER you
have connected all cables and devices to your TV.
4BEFORE connecting cables or devices to the TV,
learn the functions of the TV’s connections and
controls ( pages 11–12).
5Connect your other electronic device(s) to the TV
( pages 13–19).
6Install the batteries in the remote control ( page
20).
7See “Learning about the remote control” ( page
21) for an overview of the buttons on the remote
control.
8AFTER connecting all cables and devices, plug
in the power cords for your TV and other devices.
Then press POWER on the TV control panel or
remote control to turn on the TV. If the TV stops
responding to the controls on the remote control
or TV control panel and you cannot turn the TV
off or on, please unplug the power cords few
seconds then re-plug to try again.
9See “Menu layout and navigation” for a quick
overview of navigating the TV’s menu system
( page 22).
10 Program channels into the TV’s channel memory
( page 24).
11 For details on using the TV’s features, see
Chapters 6 and 7.
12 For help, refer to the Troubleshooting Guide,
Chapter 8.
13 For technical specifications and warranty
information, see Chapter 9.
14 Enjoy your new TV!
26_32C100U1_EN-A5.indb 10 2010/3/2 上午 11:28:36

11
Chapter 1: Introduction
7無 CHANNEL pq — When no menu is on-screen,
these buttons change the channel (programmed
channels only;  page 24).
8無 VOLUME tu — These buttons adjust the
volume level.
9無 INPUT — Repeatedly press to change the
source you are viewing (ANT/CABLE, VIDEO,
ColorStream HD, HDMI 1, HDMI 2, PC).
10無 USB port — To access photo or music files.
TV front and side panel controls and connections
Model 26C100U1 is used in this manual for illustration purposes.
12
3
7
8
9
4
5
6
10
1無 Green LED
Power LED(Green) = Power indicator
2無 Remote sensor — Point the remote control
toward this remote sensor (“Remote control
effective range” on page 20).
3無 POWER — Press to turn the TV on and off.
If the TV stops responding to the controls on
the remote control or TV control panel and you
cannot turn off the TV, please unplug the power
cord few seconds then re-plug to try again.
4無 ARROWS pqtu — When a menu is on-
screen, these buttons function as up/down/left/
right menu navigation buttons.
5無 MENU (ENTER) — Press to access the menu
system ( pages 22–23). When a menu is on-
screen, the MENU button on the TV’s control
panel functions as the ENTER button.
6無 EXIT — Press to instantly close an on-screen
menu.
TV front TV top
Left side panel
Control panel
26_32C100U1_EN-A5.indb 11 2010/3/2 上午 11:28:37

12
Chapter 1: Introduction
1無 PC IN — For use when connecting a personal
computer.
2無 HDMI®IN — High-Definition Multimedia
Interface input receives digital audio and
uncompressed digital video from an HDMI
device or uncompressed digital video from a
DVI device. HDMI connection is necessary to
receive 1080p signals.
3無 PC/HDMI-1 (AUDIO) IN — PC audio input
terminals are shared with HDMI-1 analog audio
input terminals, and their use can be configured
in the Audio Setup menu ( page 44).
4無 ANT/CABLE — Antenna input that supports
analog (NTSC) and digital (ATSC) off-air
antenna signals and analog and digital Cable TV
(QAM) signals.
5無 Digital Audio OUT — Optical audio output in
Dolby Digital or PCM (pulse-code modulation)
format for connecting an external Dolby Digital
decoder, amplifier, A/V receiver, or home theater
system with optical audio input.
6無 VIDEO IN — Standard (composite) video and
standard audio inputs plus for connecting devices
with composite video.
Note: Standard (composite) video cable
carry only video information; separate
audio cables are required for a complete
connection.
7無 ColorStream®HD — ColorStream®high-
definition component video input (with standard
stereo audio inputs) for connecting devices with
component video output, such as a Toshiba DVD
player with ColorStream®.
Note: Component video cables carry only
video information; separate audio cables
are required for a complete connection.
TV back panel connections
For an explanation of cable types and connections, see pages 13–19.
1
6
7 5
2
3
4
TV back
Power Cord
26_32C100U1_EN-A5.indb 12 2010/3/2 上午 11:28:37

13
Overview of cable types
Cables can be purchased from most stores that sell audio/
video devices. Before purchasing any cables, be sure of
connector types required by your devices and the length
of each cable.
Coaxial (F-type) cable
Coaxial (F-type) cable is used for connecting your
antenna, cable TV service, and/or cable converter box
to the ANT/CABLE input on your TV.
Standard A/V cables (red/white/yellow)
Standard A/V cables (composite video) usually come
in sets of three, and are for use with video devices with
analog audio and composite video output. These cables
(and the related inputs on your TV) are typically color-
coded according to use: yellow for video, red for stereo
right audio, and white for stereo left (or mono) audio.
Component video cables (red/green/blue)
Component video cables come in sets of three and are
for use with video devices with component video output.
(ColorStream®is Toshiba’s brand of component video.)
These cables are typically color-coded red, green, and
blue. Separate audio cables are required for a complete
connection.
Note: Component video cables provide better
picture performance than a standard (composite)
video.
HDMI®cable
(with HDMI Logo “ ”)
HDMI (High-Definition Multimedia Interface) cable
is for use with devices with an HDMI output. An
HDMI cable delivers digital audio and video in its
native format. This cable carries both video and audio
information; therefore, separate audio cables are not
required for a complete HDMI device connection (
page 16 and page 19).
Note: HDMI cable provides better picture
performance than a standard (composite) video.
Optical audio cable
Optical audio cable is for connecting receivers with
Dolby Digital or PCM (pulse-code modulation) optical
audio input to the TV’s DIGITAL AUDIO OUT terminal
( page 18).
Analog RGB (15-pin) computer cable
Analog RGB (15-pin) computer cable is for connecting
a PC to the TV’s PC IN terminal ( page 18).
About the connection illustrations
You can connect different types and brands of devices to
your TV in several different configurations. The connection
illustrations in this manual are representative of typical
device connections only. The input/output terminals on
your devices may differ from those illustrated herein. For
details on connecting and using your specific devices, refer
to each device’s owner’s manual.
Chapter 2: Connecting your TV
26_32C100U1_EN-A5.indb 13 2010/3/2 上午 11:28:38

14
Chapter 2: Connecting your TV
Connecting a VCR and antenna, Cable TV or Camcorder
VIDEO
AUDIO
OUT
L
R
IN
OUT
CH 3
CH 4
IN
from
ANT
VIDEO AUDIO
OUT
to
TV
L R
R
L
OUT
IN
CH 3
CH 4
TV back panel Stereo VCR
Cable box
From Cable TV
From Cable TV or
antenna
You will need:
• coaxial cables
• standard A/V cables
− If you have a mono VCR, connect L/MONO
on the TV to your VCR’s audio out terminal
using the white audio cable only.
• standard audio cables (If you have a mono VCR)
Note: When you use a Cable box, you may not
be able to use the remote control to program or
access certain features on the TV.
To view the antenna or Cable signal:
Select the ANT/CABLE video input source on the TV.*
To view basic and premium Cable channels:
Turn OFF the VCR. Select the ANT/CABLE video
input source on the TV.* Tune the TV to channel 3 or
4 (whichever channel the Cable box output is set to).
Use the Cable box controls to change channels.
To view the VCR:
Turn ON the VCR. Select the VIDEO video input
source on the TV.*
To view the camcorder video:
Select the VIDEO video input source on the TV.*
*To select the video input source, press INPUT on the
remote control (page 21).
The unauthorized recording, use, distribution, or
revision of television programs, videotapes, DVDs,
and other materials is prohibited under the Copyright
Laws of the United States and other countries, and may
subject you to civil and criminal liability.
Camcorder
26_32C100U1_EN-A5.indb 14 2010/3/2 上午 11:28:38

15
Chapter 2: Connecting your TV
Connecting a DVD player with ColorStream®(component video), a VCR,
and a satellite receiver
IN from ANT
VIDEO AUDIO
OUT to TV
L R
R
L
OUT
IN
CH 3
CH 4
S-VIDEO
OUT
VIDEO
OUT
AUDIO
OUT
COMPONENT VIDEO
L
R
Satellite
IN
PBPR
Y
TV back panel Stereo VCR
From antenna
From satellite dish
Satellite receiver with component video or
DVD player with component video
You will need:
• coaxial cables
• standard A/V cables
− If you have a mono VCR, connect L/MONO
on the TV to your VCR’s audio out terminal
using the white audio cable only.
• standard audio cables
• component video cables
− You can connect the component video cables
(plus audio cables) from the DVD player or
satellite receiver to the ColorStream terminal
on the TV. The ColorStream HD terminal
can be used with Progressive (480p, 720p)
and Interlaced (480i, 1080i) scan systems.
A 1080i signal will provide the best picture
performance (1080p is not supported).
To view antenna or Cable channels:
Select the ANT/CABLE video input source on the TV.*
To view the DVD player:
Turn ON the DVD player. Select the ColorStream HD
video input source on the TV.*
To view satellite programs using the
component video connections:
Turn on the satellite receiver. Select the ColorStream
HD video input source on the TV.*
To view the VCR or view and record
antenna channels:
Turn ON the VCR. Tune the VCR to the channel you want
to watch. Select the VIDEO video input source on the TV.*
To record a TV program while watching a DVD:
Turn ON the VCR. Tune the VCR to the channel to
record. Select the ColorStream HD video input source
on the TV* to view the DVD.
*To select the video input source, press INPUT on the
remote control ( page 21).
The unauthorized recording, use, distribution, or
revision of television programs, videotapes, DVDs,
and other materials is prohibited under the Copyright
Laws of the United States and other countries, and may
subject you to civil and criminal liability.
26_32C100U1_EN-A5.indb 15 2010/3/2 上午 11:28:39

16
Chapter 2: Connecting your TV
Connecting an HDMI®or DVI
device to the HDMI input
The HDMI input on your TV receives digital audio
and uncompressed digital video from an HDMI
source device, or uncompressed digital video from a
DVI (Digital Visual Interface) source device.
This input is designed to accept HDCP (High-
Bandwidth Digital-Content Protection) program
material in digital form from EIA/CEA-861-D–
compliant[1] consumer electronic devices (such as
a set-top box or DVD player with HDMI or DVI
output).
The HDMI input can accept and display VGA,
SVGA, XGA, WXGA, SXGA, 480i (60Hz), 480p
(60Hz), 720p (60Hz), 1080i (60Hz) and 1080p
(24Hz/60Hz) signal formats. For detailed signal
specifications, see page 56.
Supported Audio format: Linear PCM, sampling rate
32/44.1/ 48 kHz
Note: To connect a PC to the HDMI input, see page 19.
To connect an HDMI device, you will need:
• one HDMI cable (type A connector) per HDMI device
− For proper operation, it is recommended that
you use an HDMI cable with the HDMI Logo (
).
− To display an 1080i/60Hz signal format, you
will need a Category 2 cable. Conventional
HDMI/DVI cable may not work properly.
− HDMI cable transfers both video and audio.
Separate analog audio cables are not
required (see illustration).
− See “Setting the HDMI
®
audio mode”
(page 27).
HDMI device
TV back panel
To view the HDMI device video:
Select the HDMI 1 or HDMI 2 video input source on
the TV. *
*To select the video input source, press INPUT on the
remote control ( page 21).
To connect a DVI device, you will need:
• one HDMI-to-DVI adapter cable (HDMI type A
connector) per DVI device
− For proper operation, the length of an HDMI-
to-DVI adapter cable should not exceed 9.8 ft
(3m). The recommended length is 6.6 ft (2m).
• one pair of standard analog audio cables per DVI
device
− An HDMI-to-DVI adapter cable transfers
video only. Separate analog audio cables
are required (see illustration).
− See “Setting the HDMI®audio mode”
(page 27).
VIDEO AUDIO
L R
R
L
OUT
IN
DVI/HDCP
OUT
IN
DVI device
TV back panel
Note: To ensure that the HDMI or DVI device is reset
properly, it is recommended that you follow these
procedures:
•When turning on your electronic components,
turn on the TV first, and then the HDMI or
DVI device.
•When turning off your electronic components,
turn off the HDMI or DVI device first, and
then the TV.
[1] EIA/CEA-861-D compliance covers the
transmission of uncompressed digital video
with high-bandwidth digital content protection,
which is being standardized for reception of
high-definition video signals. Because this is
an evolving technology, it is possible that some
devices may not operate properly with the TV.
26_32C100U1_EN-A5.indb 16 2010/3/2 上午 11:28:39

17
Chapter 2: Connecting your TV
REGZA-LINK®connection
You can control the basic functions of connected audio/video devices using the TV’s remote control if you
connect a REGZA-LINK compatible audio receiver or playback device. For an explanation of setup and
operations, see pages 48-50.
TV back panel
Audio receiver
Playback device
(REGZA-LINK DVD player,etc.)
Playback device
(REGZA-LINK DVD player,etc.)
To connect an Audio Receiver and Playback
Devices, you will need:
• HDMI cables ( page 13)
Note:
• If several devices are connected, REGZA-LINK
feature may not operate properly.
• For proper operation, it is recommended that you
use HDMI cables with the HDMI Logo
( ).
Before controlling the device(s):
• After completing the above connections, set the
REGZA-LINK Setup menu as you desire (page
49).
• The connected devices must also be set. For
details, see the operation manual for each device.
• The REGZA-LINK feature uses the CEC
technology as regulated by the HDMI standard.
• This feature is limited to models incorporating
Toshiba’s REGZA-LINK. However, Toshiba is not
liable for those operations. Refer to the individual
instruction manuals for compatibility information.
Note: This feature may not work properly
depending on the devices that are connected.
26_32C100U1_EN-A5.indb 17 2010/3/2 上午 11:28:40

18
Chapter 2: Connecting your TV
Connecting a digital audio system
The TV’s DIGITAL AUDIO OUT terminal outputs a
*Dolby®Digital or 2-channel down-mixed PCM
(pulse-code modulation) signal for use with an
external Dolby®Digital decoder or other external
audio system with optical audio input.
You will need:
• optical audio cable (Use an optical audio cable
that has the larger “TosLink” connector and not
the smaller “mini-optical” connector.)
Dolby Digital decoder or
other digital audio system
TV back panel
To control the audio:
1無 Turn on the TV and the digital audio device.
2無 Press on the TV’s remote control and open the
Sound menu.
3無 Highlight Audio Setup and press .
4無 In the Optical Output Format field, select either
Dolby Digital or PCM, depending on your device
(“Selecting the optical audio output format” on
page 39).
Note:
•Some audio systems may not be compatible
with Dolby Digital bitstream signals. Older
audio systems that are not compatible with
standard optical out signals may not work
properly, creating a high noise level that
may damage speakers or headphones.
THIS DAMAGE IS NOT COVERED BY YOUR
WARRANTY.
•The DIGITAL AUDIO OUT terminal may not
output some digital audio sources because
of copy restrictions.
*Manufactured under license from Dolby
Laboratories. Dolby, and the double-D symbol are
trademarks of Dolby Laboratories.
Connecting a personal computer (PC)
With either the PC IN or HDMI connection, you can watch
your computer’s display on the TV and hear the sound
from the TV’s speakers.
To connect a PC to the PC IN terminal on the TV:
When connecting a PC to the PC IN terminal on the TV, use
an analog RGB (15-pin) computer cable and a PC audio cable.
PC audio
cable
PC audio
output
Conversion adapter
(if necessary)
Computer
TV back panel
• To use a PC, set the monitor output resolution on the
PC before connecting it to the TV. The PC IN terminal
can accept and display VGA, SVGA, XGA and WXGA
signal formats. For detailed signal specifications (
page 56).
Other formats or non-standard signals will not be
displayed correctly.
• To display the optimum picture, use the PC setting
feature (“Using the PC settings feature” on page 44).
(continued)
26_32C100U1_EN-A5.indb 18 2010/3/2 上午 11:28:40

19
Chapter 2: Connecting your TV
Note:
•The edges of the images may be hidden.
•If receiving a 480i (HDMI), 480p (HDMI), 720p,
1080i, or 1080p signal program, Native mode
scales the video to display the entire picture within
the borders of the screen (i.e. no overscanning).
Note:
•The PC audio input terminals on the TV are shared
with the HDMI-1 analog audio input terminals (
page 44).
•Some PC models cannot be connected to this TV.
•An adapter is not needed for computers with a
compatible mini D-sub15-pin terminal.
•Depending on the DVD’s title and the
specifications of the PC on which you are playing
the DVD-Video, some scenes may be skipped or
you may not be able to pause during multi-angle
scenes.
• Signal names for mini D-sub 15-pin connector
Pin
No.
Signal
name
Pin
No.
Signal
name
Pin
No.
Signal
name
1 R 6 Ground 11 Reserved
2 G 7 Ground 12 SDA
3 B 8 Ground 13 H-sync
4 Reserved 9 5V 14 V-sync
5 Reserved 10 Ground 15 SCL
To connect a PC to the HDMI terminal on the TV:
When connecting a PC to the HDMI terminal on the
TV, use an HDMI-to DVI adapter cable and analog
audio cables.
If connecting a PC with an HDMI terminal, use an
HDMI cable (type A connector). Separate analog
cables are not necessary (page 13).
PC audio
output
PC audio
cable
TV back panel
Computer
The HDMI input can accept and display VGA, SVGA,
XGA, WXGA, SXGA, 480i (60Hz), 480p (60Hz), 720p
(60Hz), 1080i (60Hz), and 1080p (24Hz/60Hz) signal
formats. For detailed signal specifications, see page 56.
26_32C100U1_EN-A5.indb 19 2010/3/2 上午 11:28:41

20
Installing the remote control
batteries
1無 Remove the battery cover from the back of
the remote control.
Squeeze tab
and lift cover.
2無 Install two “AAA” size batteries, making
sure to match the + and – signs on the
batteries to the signs on the battery
compartment.
3無 Reinsert the battery cover in the remote
control until the tab snaps.
Caution: Batteries must not be exposed
to excessive heat such as sunshine, fire or
the like.
Note:
•Be sure to use AAA size batteries.
•Dispose of batteries in a designated disposal
area.
•Batteries should always be disposed of with
the environment in mind. Always dispose of
batteries in accordance with applicable laws
and regulations.
•If the remote control does not operate
correctly, or if the operating range becomes
reduced, replace batteries with new ones.
•When necessary to replace batteries in the
remote control, always replace both batteries
with new ones. Never mix battery types or use
new and used batteries in combination.
•Always remove batteries from the remote
control if they are dead or if the remote
control is not to be used for an extended
period of time. This will prevent battery acid
from leaking into the battery compartment.
Remote control effective range
For optimum performance, aim the remote control
directly at the TV and make sure there is no
obstruction between the remote control and the TV.
16.4 ft (5m)
Point remote control toward
remote sensor on front of TV.
Chapter 3: Using the remote control
26_32C100U1_EN-A5.indb 20 2010/3/2 上午 11:28:42
