- 1 -
SERVICE MANUAL
LCD Color Television
27HLV95
FILE NO. 020-200515
Published in Japan, Jul. 2005 (YC)
TOSHIBA CORPORATION 2005

- 2 -
TABLE OF CONTENTS
SERVICE SAFETY PRECAUTIONS .................................................................................................................................... 3
HANDLING THE LCD MODULE .......................................................................................................................................... 5
SERVICE MODE .................................................................................................................................................................. 7
LAYOUT OF MAJOR BOARDS .......................................................................................................................................... 12
MECHANICAL DISASSEMBLY .......................................................................................................................................... 13
EXPLODED VIEW .............................................................................................................................................................. 15
PACKING DISASSEMBLY ................................................................................................................................................. 17
CHASSIS AND CABINET REPLACEMENT PARTS LIST ................................................................................................. 18
PC BOARDS TOP & BOTTOM VIEW ................................................................................................................................ 25
CIRCUIT BLOCK DIAGRAM .............................................................................................................................................. 51
APPENDIX:
SCHEMATIC DIAGRAM

- 3 -
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICE SAFETY PRECAUTIONS
• The caution items shown here describe major safety issues and should always be observed.
• The meanings of the various indications are as follows.
WARNING
CAUTION
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users due to a product defect after the service operation is completed, could possibly be in
danger of injury or even death in the event of operational error.
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users after the service operation is completed, could possibly be in danger of injury, or
where there could be physical damage in the event of operational error.
* Physical damage means major damage to a home, furnishings and other possessions.
Examples of marks
SHOCK HAZARD
PROHIBIT DISASSEM-
BLING
UNPULUG
The " indicates caution (including danger and warning).
The actual meaning of this caution is indicated inside the
" or nearby illustrations or text.
The example shown to the left indicates the danger of "electrical shock".
The indicates a forbidden action.
The actual meaning of this caution is indicated inside the or nearby illustrations or text.
The example shown to the left indicates that disassembly is forbidden.
The
- indicates a forced action (an action that must be performed).
The actual meaning of this forced action is indicated by
- or nearby illustrations or text.
The example shown to the left indicates that the power plug must be disconnected.

- 4 -
WARNING
KEEP CHILDREN
AWAY
UNPULUG
SHOCK HAZARD
USE SPECIFIED
PARTS
CAUTION FOR
WIRING
CAUTION FOR
ASSEMBLING /
WIRING
CHECK INSULATION
RESISTANCE
PROHIBIT
REMODELING
• Always advise users to keep children away.
There is danger of injury to children from tools, disassembled products, etc.
• Always disconnect the power plug before starting work whenever power is not required.
Failure to disconnect the power plug before starting work can result in electrical shock.
• Depending on the model, use an insulation transformer or wear gloves when servicing with the
power on, and disconnect the power plug to avoid electrical shock when replacing parts.
In some cases, alternating current is also impressed in the chassis, so electrical shock is pos-
sible if the chassis is contacted with the power on.
• Always use the replacement parts specified for the particular model when making repairs.
The parts used in products have the necessary safety characteristics such as inflammability,
voltage resistance, etc.; therefore, use only replacement parts that have these same character-
istics.
Use only the specified parts when the mark is included in a circuit diagram or parts list.
• Parts mounting and routing of the wiring should be the same as that used originally.
For safety purposes, insulating materials such as tubing or tape is sometimes used and printed
circuit boards are sometimes mounted floating.
Also make sure that wiring is routed and clamped to avoid parts that generate heat and which
use high voltage. Always follow the original scheme.
• After a repair has been completed, reassemble all disassembled parts, and route and recon-
nect the wiring, in accordance with the original scheme.
Do not allow internal wiring to be pinched by cabinets, panels, etc.
Any error in reassembly or wiring can result in electrical leakage, flame, etc., and may be
hazardous.
• After completing the work, disconnect the power plug from the outlet, remove the antenna, turn
on the power switch. Then, use a 500V insulation resistance meter to check the insulation
resistance of the antenna terminal, other metallic parts and between the prongs of the power
plug to make sure that the insulation resistance is 1M 1or more.
The set will require inspection and repair if the insulation resistance is below this value.
• Never remodel the product in any way.
Remodeling can result in improper operation, malfunction, or electrical leakage and flame,
which may be hazardous

- 5 -
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
HANDLING THE LCD MODULE
Safety Precautions
In the event that the screen is damaged or the liquid crystal
(fluid) leaks, do not breathe in or drink this fluid. Also, never
touch this fluid.
Such actions could cause toxicity or skin irritation. If this fluid
should enter the mouth, rinse the mouth thoroughly with wa-
ter. If the fluid should contact the skin or clothing, wipe off
with alcohol, etc., and rinse thoroughly with water. If the fluid
should enter the eyes, immediately rinse the eyes thoroughly
with running water.
Precautions for Handling the LCD Module
The LCD module can easily be damaged during disassembly
or reassembly; therefore, always observe the following pre-
cautions when handling the module.
1. When attaching the LCD module to the LCD cover, posi-
tion it appropriately and fasten at the position where the
display can be viewed most conveniently.
2. Carefully align the holes at all four corners of the LCD
module with the corresponding holes in the LCD cover
and fasten with screws. Do not strongly push on the mod-
ule because any impact can adversely affect the perform-
ance. Also use caution when handling the polarized screen
because it can easily be damaged.
CAUTION The metal edges of the LCD module
are sharp, so use caution to avoid in-
jury.
3. If the panel surface becomes soiled, wipe with cotton or a
soft cloth. If this does not remove the soiling, breathe on
the surface and then wipe again.
If the panel surface is extremely solied, use a CRT cleaner
as a cleaner.Wipe off the panel surface by drop the cleaner
on the cloth. Do not drop the cleaner on the panel. Pay
attention not to scratch the panel surface.
4. Leaving water or other fluids on the panel screen for an
extended period of time can result in discoloration or
stripes. Immediately remove any type of fluid from the
screen.
5. Glass is used in the panel, so do not drop or strike with
hard objects. Such actions can damage the panel.
6. CMOS-LSI circuitry is used in the LCD module, so avoid
damage due to static electricity. When handling the mod-
ule, use a wrist ground or anchor ground.

- 6 -
7. Do not expose the LCD module to direct sunlight or strong
ultraviolet rays for an extended period of time.
8. Do not store the LCD module below the temperature con-
ditions described in the specifications. Failure to do so
could result in freezing of the liquid crystal due to cold air
or loss of resilience or other damage.
9. Do not disassemble the LCD module. Such actions could
result in improper operation.
10. When transporting the LCD module, do not use packing
containing epoxy resin (amine) or silicon resin (alcohol or
oxim). The gas generated by these materials can cause
loss of polarity.
Safety Precautions for Laser Beam (DVD Player)
Do not look into the opening of the disc slot or ventilation
opening of the product to see the source of the laser beam.
It may cause sight damage.

- 7 -
CAUTION : Never try to perform initialization unless you have changed the memory IC.
SERVICE MODE
1. ENTERING SERVICE MODE
1) Press MUTE button twice on 2) Press MUTE button again and 3) While pressing the MUTE button,
Remote Control. keep pressing. press MENU button on TV set.
(Service mode display)
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on Remote Control.
Service mode Adjustment mode
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
Press
Press
MUTE
Test signal selection : TV/VIDEO button (on Remote)
Selection of the adjustment items : Channel / (on TV or Remote)
Change of the data value : Volume W/ X(on TV) or / (on Remote)
Adjustment menu mode ON/OFF : MENU button (on Remote)
Initialization of the memory : CALL + Channel button on TV ( )
Reset the count of operating protect circuit to “00” : CALL + Channel button on TV ( )
“RCUT” selection : 1 button
“GCUT” selection : 2 button
“BCUT” selection : 3 button
“CNTX” selection : 4 button
“COLC” selection : 5 button
“UVTT” selection : 6 button
Automatic A/D Adjustment(PC, Component) : 7 button
Self diagnostic display ON/OFF : 9 button
----- Color thickness correction
note: Displayed differently as shown below, depending
on the setting of the receiving color system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)

- 8 -
Signals Picture
• Red raster
• Green raster
• Blue raster
• All Black
• All White
R
All BlackAll White
BSignal off G
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL button in the service mode changes the adjustment items in the order of table-2.
(button for reverse order)
5. ADJUSTING THE DATA
1) Pressing of VOLUME W/ X, / button will change the value of data in the range from 00H to FFH. The
variable range depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
INITIALIZATION OF MEMORY DATA
After replacing EEPROM IC, the following initialization is required.
1.Enter the service mode, then select any register item.
2.Press and hold the CALL button on the Remote, then press the CHANNEL button on the TV. The initialization of
EEPROM IC has been completed.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto tune” on the owner’s manual.
CAUTION: Never attempt to initialize the data unless EEPROM IC has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of TV/VIDEO button on the Remote Control changes the built-in test patterns on screen as described
below in SERVICE MODE.

- 9 -
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s is executed properly.
2) During diagnosis, the following displays are shown.
000000
HLV95_1489
OK
1
2
3
4
5
1Firmware :
Version information of microprocessor
In case of file name : HLV95 and Version : 1489 indicates[HLV95_1489].
2Time : Total hour of turn the TV on. (Unit : H)
3Bus line : --"OK" is normal
"SCL-GND"(Red indication) : SCL-GND short circuit
"SDA-GND"(Red indication) : SDA-GND short circuit
"SCL-SDA"(Red indication) : SCL-SDA short circuit
4Bus cont : --- "OK" is normal.
NG is abnormal(Red indication).
When type name of semiconductor indicates.
5Block
UV : TV reception mode
V1 : VIDEO 1 input mode
V2 : VIDEO 2 input mode
V3 : ColorStream HD
V4 : HDMI IN
V5 : Buit-in DVD
PC : Personal Computer (PC)

- 10 -
9. VERSION CHECK MODE
1) Press “9” button twice on Remote Control during display of adjustment menu in the service mode. The version of main
MPU will begin to check.
2) During Version Check, the following displays are shown.
HLV95_1489 (U15)
FF
2A
1A
74 00 01 25 00 00
00000155
SHP-27
1
2
3
4
5
7
1MAIN MPU :
Version information of microprocessor
In case of file name : HLV95, Version 1489 for Code Program Version
and (U15) for OSD Version indicates [HLV95_1489(U15)]
2EEPROM :
Version information of EEPROM : Display 1 byte data.
3SUB MPU :
Version information of SUB MPU : Display 1 byte data.
4OPTION :
Option information : Display six numbers of 1 byte data.
5HDMI ID :
HDMI ID information : Display 4 byte data.
6DVD :
DVD information : Display 1 byte data.
7LCD Panel Vender information display
The following Panel Vender and screen size are displayed.
Example : SHP-32 indicates that vender is SHP and Screen Size is 32 inch.
6
Panel Vender Screen Size(Inch)
CMO -27
SHP -32

- 11 -
10. STATUS CHECK MODE
1) Press “9” button thrice on Remote Control during display of adjustment menu in the service mode. The status of this
model will begin to check.
2) During Status Check, the following displays are shown.
1MAIN :
Main source information :
Display RF position number (0 - 99) on the main screen, or Input Source (ANT1/2/HDMI etc.)
2MAIN FORMAT :
Display Video and PC format information
3MAIN PLL :
Main PLL information : Display five numbers of 2 byte data.
4SCREEN SIZE :
Display the screen size as follows.
ANT1 CABLE 12
480i
NATURAL
06 OF B0 CE 02
0000 0000 0000
1
2
4
5
3
5OTHER STATUS :
Other status information : Display three numbers of 2 byte data.
Theater Wide 1
Theater Wide 2
Theater Wide 3
FULL
NATURAL

- 12 -
LAYOUT OF MAJOR BOARDS
U105A
TN/AV-AOUT BOARD
U101
SIGNAL DVD-LCD BOARD
U104
RF-SW TIF BOARD
U105C
KEY-SW BOARD
U105B
LED-RMT BOARD
U105E
DVD-KEY BOARD
U802
AC-IN BOARD
U105D
PC-IN BOARD
U102
SEINE FOR FPD BOARD
U103
D-TUNER BOARD
U801
POWER BOARD

- 13 -
PV15
BITTB3×12 SBN ×10
PP3×8+SW+W SBN ×4
PP5×16 SW+W SBN
×3
A450
A401
A445
A420
MECHANICAL DISASSEMBLY
1. Remove the stand (foot) and back cover.
2. Remove the boards (RF-SWTIF, KEY-SW, PC-IN, DVD-KEY) and piece key ass'y.
PV15
PP4×12+SW+W SBN
×2
PP4×12+SW+W
SBN ×2
BITTB3×12 SBN
×2
PP4×12+SW+W SBN
PP3×8
+SW+W
SBN
PP3×8
+SW+W
SBN
PP3×8
+SW+W SBN
PP4×12+SW+W SBN ×6
PP3×8+SW+W
ECO ×3
PP3×8
+SW+W ECO
×3
PP4×12+SW+W SBN ×2
BITTB3×8
ECO ×2
A340
A507
BD01
A525
A320
U105C
H003C
U105D
4-40UNC
JFS-4S L=13
×2
BITTB3×8 ECO
×4
PP3×8+SW+W
SBN ×2
PP3×8
+SW+W SBN
×2
PP3×8
+SW+W SBN
×4
PP3×8+SW+W SBN
×4
PP3×8
+SW+W SBN
PP3×8
+SW+W SBN BITTB3×8
ECO ×3
BITTB3×12 SBN
×2
U105E
PP08
PP08
PP08
U104
PP08

- 14 -
PV15
P801
A315
PP3×8+SW+W SBN
×2
PP08
PP08
UF03
PP08
PP08
BITTB3×8 ECO
×2
PP3×8+SW+W ECO
×6
PP3×8+SW+W ECO ×3
PP3×8+SW+W ECO
×5
PP3×8+SW+W ECO ×4
PP4×20+SW+W SBN ×2
PP3×8+SW+W ECO
×5
PP3×8+
SW+W
ECO ×3
PP3×8+
SW+W
ECO ×4
U105B
U105A
U801
U802
U101 U103
U102
3. Remove the boards (SIGNAL DVD-LCD, SEINE FOR FPD, D-TUNER,TN/AV-AOUT, LED-RMT,
POWER, AC-IN) and speaker.
4. Remove the display.
W661
W661
BITTB4×16 SBN
×4
BITTB4×16 SBN ×4
PP08
PP08
B001
A201
PP4×12+SW+W SBN
×4 BITTB4×16 SBN
×14

- 15 -
EXPLODED VIEWS
1. Chassis Block
4-40UNC
JFS-4S L=13
×2
PV15
PP08
PP08
PP08
PP08
PP4×12+SW+W SBN
×2
PP4×12+SW+W SBN
×2
PP3×8+SW+W
SBN BITTB3×12
SBN ×2
BITTB3×8 ECO
×4
PP4×12+SW+W
SBN
PP3×8+SW+W
SBN
PP3×8+SW+W
SBN ×2
PP3×8
+SW+W SBN
×2
PP3×8
+SW+W SBN
×4
PP3×8+SW+W SBN
×4
PP3×8
+SW+W SBN
PP3×8
+SW+W SBN
PP3×8
+SW+W
SBN
PP4×12+SW+W SBN ×6
BITTB3×12 SBN
×2
BITTB3×8
ECO ×3
BITTB3×12 SBN
×2
PP4×12 +SW+W
SBN ×2
BITTB3×12 SBN
×10
PP3×8+SW+W SBN
×4
A450
A445
A401
A420
PP5×16 SW+W SBN
×5
A340
BD01
A525
A501
A320
U105C
U105E
U105D
U104
H003C
PP3×8+SW+W ECO
×3
PP3×8+SW+W
ECO
×3

- 16 -
PV15
PP3×8+SW+W ECO
×3
PP3×8+SW+W
ECO ×3
PP3×8+SW+W
ECO ×4
PP4×20+SW+W
SBN ×2
PP3×8+SW+W ECO
×6
BITTB4×16 SBN
×4
BITTB4×16 SBN
×4
PP3×8+SW+W ECO
×5
PP3×8+SW+W ECO ×4
PP3×8+SW+W ECO
×5
BITTB3×8 ECO
×2
PP4×12+SW+W SBN
×4
BITTB4×16 SBN
×14
PP08
PP08
PP08
UF03
PP08
PP08
PP08
W661
W661
A201
B001
PP3×8+SW+W SBN
×2P801
A315
U105B
U105A
U801
U802
U101 U103
U102
2. Main Block

- 17 -
PACKING DISASSEMBLY
A702B
A702B
A702A
A702A
Y170 Y101
A701A
A703
K902

- 18 -
Location Parts No. Description
No.
Location Parts No. Description
No.
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “SERVICE SAFETY PRECAUTIONS” ON PAGE 3 OF THIS
MANUAL.
CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which
have special characteristics important for safety and should be replaced only with types identical to those in the original
circuit or specified in the parts list. The mounting position of replacements is to be identical with originals. Before replacing
any of these components, read carefully the SERVICE SAFETY PRECAUTIONS. Do not degrade the safety of the receiver
through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with ∗ mark is no longer available after the end of the production.
CHASSIS AND CABINET REPLACEMENT PARTS LIST
Model : 27HLV95
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CAPACITORS
C102 76073019 ELECTROLYTIC, 10V 470UF M 3A
C103 76109102 CERAMIC CHIP, 50V B 1000PF K
C104 76073084 ELECTROLYTIC, 50V 4.7UF M 3A
C105 76073019 ELECTROLYTIC, 10V 470UF M 3A
C150 76073041 ELECTROLYTIC, 16V 470UF M 3A
C151 76109103 CERAMIC CHIP, 50V B 0.01UF K
C152 76109103 CERAMIC CHIP, 50V B 0.01UF K
C153 76109103 CERAMIC CHIP, 50V B 0.01UF K
C161 76109102 CERAMIC CHIP, 50V B 1000PF K
C162 76105101 CERAMIC CHIP, 50V CH 100PF J
C164 76092730 CERAMIC CHIP, 16V B 0.1UF K
C168 76109103 CERAMIC CHIP, 50V B 0.01UF K
C169 76109103 CERAMIC CHIP, 50V B 0.01UF K
C660 76669479 ELECTROLYTIC, 50V 4.7UF M
C661 76669479 ELECTROLYTIC, 50V 4.7UF M
C662 76109681 CERAMIC CHIP, 50V B 680PF K
C663 76109681 CERAMIC CHIP, 50V B 680PF K
C668 76109102 CERAMIC CHIP, 50V B 1000PF K
C669 76109102 CERAMIC CHIP, 50V B 1000PF K
C670 76669100 ELECTROLYTIC, 50V 10UF M
C671 76669100 ELECTROLYTIC, 50V 10UF M
C673 76619102 ELECTROLYTIC CHIP, 16V 47UF M
C674 76092731 CERAMIC CHIP, 16V B 1UF K
C677 76092731 CERAMIC CHIP, 16V B 1UF K
C678 76285104 CERAMIC CHIP, 50V B 0.1UF K
C679 76285104 CERAMIC CHIP, 50V B 0.1UF K
C680 76073073 ELECTROLYTIC, 35V 2200UF M 3A
C681 76073073 ELECTROLYTIC, 35V 2200UF M 3A
C682 76073073 ELECTROLYTIC, 35V 2200UF M 3A
C684 76109103 CERAMIC CHIP, 50V B 0.01UF K
C685 76619113 ELECTROLYTIC CHIP, 50V 1UF M
C690 76669101 ELECTROLYTIC, 50V 100UF M
C691 76092463 CERAMIC CHIP, 16V B 0.22UF K
C692 76092463 CERAMIC CHIP, 16V B 0.22UF K
C801 76503507 PLASTIC FILM, AC275V 0.22UF K
C802 76503507 PLASTIC FILM, AC275V 0.22UF K
C803 76503250 PLASTIC FILM, 400V 0.22UF M, 7E2G224J-SC
C804 76214103 CERAMIC DISC, 500V B 0.01UF K
C805 76092281 CERAMIC DISC, AC250V E 4700PF
C806 76092281 CERAMIC DISC, AC250V E 4700PF
C810 76073233 ELECTROLYTIC, 200V 560UF M
C811 76092569 CERAMIC DISC, AC250V E 2200PF M
C812 76092569 CERAMIC DISC, AC250V E 2200PF M
C813 76503047 PLASTIC FILM, 63V 0.33UF J
C815 76503049 PLASTIC FILM, 63V 0.47UF J
C816 76073183 ELECTROLYTIC, 35V 220UF M
C817 76567224 PLASTIC FILM, 50V 0.22UF J
C819 76214101 CERAMIC DISC, 500V B 100PF K
C820 76567224 PLASTIC FILM, 50V 0.22UF J
C821 76092343 CERAMIC DISC, 2KV 680PF K
C822 76092344 CERAMIC DISC, 2KV 820PF K
C823 76092341 CERAMIC DISC, 2KV R 470PF K
C824 76591102 PLASTIC FILM, 50V 1000PF J
C825 76503053 PLASTIC FILM, 63V 1UF J
C826 76092341 CERAMIC DISC, 2KV R 470PF K
C827 76678229 ELECTROLYTIC, 200V 2.2UF M
C851 76092538 CERAMIC CHIP, 10V F 1UF Z
C852 76109102 CERAMIC CHIP, 50V B 1000PF K
C883 76073193 ELECTROLYTIC, 35V 2200UF M
C884 76073193 ELECTROLYTIC, 35V 2200UF M
C888 76105101 CERAMIC CHIP, 50V CH 100PF J
C889 76073094 ELECTROLYTIC, 50V 1000UF M 3A
C890 76503047 PLASTIC FILM, 63V 0.33UF J
C8110 76073233 ELECTROLYTIC, 200V 560UF M
CB01 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB02 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB03 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB04 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB05 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB38 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CC16 76109102 CERAMIC CHIP, 50V B 1000PF K
CC17 76109102 CERAMIC CHIP, 50V B 1000PF K
CD11 76073181 ELECTROLYTIC CE04P 35V 56UF M 3A
CD21 76666470 ELECTORLYTIC, 16V 47UF M 3A
CD22 76539474 PLASTIC FILM, 50V 0.47UF J
CD23 76666470 ELECTORLYTIC, 16V 47UF M 3A
CD41 76105330 CERAMIC CHIP, 50V CH 33PF J
CD42 76105330 CERAMIC CHIP, 50V CH 33PF J
CD43 76105330 CERAMIC CHIP, 50V CH 33PF J
CD45 76105330 CERAMIC CHIP, 50V CH 33PF J
CD46 76105330 CERAMIC CHIP, 50V CH 33PF J

Location Parts No. Description
No. Location Parts No. Description No.
- 19 -
CD47 76105330 CERAMIC CHIP, 50V CH 33PF J
CD48 76105330 CERAMIC CHIP, 50V CH 33PF J
CD61 76105330 CERAMIC CHIP, 50V CH 33PF J
CD62 76105330 CERAMIC CHIP, 50V CH 33PF J
CD63 76105330 CERAMIC CHIP, 50V CH 33PF J
CD64 76105330 CERAMIC CHIP, 50V CH 33PF J
CD65 76105330 CERAMIC CHIP, 50V CH 33PF J
CD66 76105330 CERAMIC CHIP, 50V CH 33PF J
CD67 76105330 CERAMIC CHIP, 50V CH 33PF J
CD81 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD82 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD83 76109102 CERAMIC CHIP, 50V B 1000PF K
CD84 76109102 CERAMIC CHIP, 50V B 1000PF K
CD85 76105221 CERAMIC CHIP, 50V CH 220PF J
CD87 76092731 CERAMIC CHIP, 16V B 1UF K
CD88 76105221 CERAMIC CHIP, 50V CH 220PF J
CD89 76105221 CERAMIC CHIP, 50V CH 220PF J
CD90 76105221 CERAMIC CHIP, 50V CH 220PF J
CD91 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD92 76109102 CERAMIC CHIP, 50V B 1000PF K
CD93 76105101 CERAMIC CHIP, 50V CH 100PF J
CD94 76109102 CERAMIC CHIP, 50V B 1000PF K
CD95 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CD96 76619040 ELECTROLYTIC CHIP, 16V 10UF M 3A
CE04 76092281 CERAMIC DISC, AC250V E 4700PF
CE05 76092281 CERAMIC DISC, AC250V E 4700PF
CE07 76503049 PLASTIC FILM, 63V 0.47UF J
CE09 76668339 ELECTROLYTIC, 35V 3.3UF M 3A
CE10 76073217 ELECTROLYTIC, 200V 560UF M
CE12 76503041 PLASTIC FILM , 63V 0.1UF J
CE13 76092561 CERA CAP B 250V 101 CD70-B2GA101KYNS
CE14 76092561 CERA CAP B 250V 101 CD70-B2GA101KYNS
CE15 76092337 CERAMIC DISC, 2KV 220PF K
CE16 76073181 ELECTROLYTIC CE04P 35V 56UF M 3A
CE17 76092339 CERAMIC DISC, 2KV 330PF K
CE18 76503253 PLASTIC FILM, 1250VH 0.01UF H
CE23 76214471 CERAMIC DISC, 500V B 470PF K
CE24 76285104 CERAMIC CHIP, 50V B 0.1UF K
CE26 76795101 ELECTROLYTIC, 25V 100UF M
CE29 76436331 CERAMIC DISC, 50V SL 330PF J
CE40 76073183 ELECTROLYTIC, 35V 220UF M
CE42 76539104 PLASTIC FILM, 50V 0.1UF J
CE43 76503041 PLASTIC FILM , 63V 0.1UF J
CE51 76617023 ELECTROLYTIC, 16V 330UF M
CE52 76092179 CERAMIC CHIP, 25V B 0.22UF K
CE53 76092179 CERAMIC CHIP, 25V B 0.22UF K
CE55 76073181 ELECTROLYTIC CE04P 35V 56UF M 3A
CE73 76073186 ELECTROLYTIC, 35V 470UF M
CE74 76073189 ELECTROLYTIC, 35V 1000UF M
CE75 76073128 ELECTROLYTIC, 6.3V 1000UF M
CE76 76073181 ELECTROLYTIC CE04P 35V 56UF M 3A
CE82 76676470 ELECTROLYTIC, 100V 47UF M 3A
CE83 76073175 ELECTROLYTIC, 25V 1800UF M
CE84 76073178 ELECTROLYTIC, 25V 3300UF M
CE85 76073190 ELECTROLYTIC CE04P 35V 1200UF M 3A
CE86 76073190 ELECTROLYTIC CE04P 35V 1200UF M 3A
CE87 76669100 ELECTROLYTIC, 50V 10UF M
CE90 76503047 PLASTIC FILM, 63V 0.33UF J
CE91 76503041 PLASTIC FILM , 63V 0.1UF J
CE92 76794101 ELECTROLYTIC, 16V 100UF M
CE94 76503047 PLASTIC FILM, 63V 0.33UF J
CE95 76503041 PLASTIC FILM , 63V 0.1UF J
CE96 76794101 ELECTROLYTIC, 16V 100UF M
CS10 76092628 CERAMIC CHIP, 6.3V B 10UF K
CS11 76092628 CERAMIC CHIP, 6.3V B 10UF K
CS12 76109473 CERAMIC CHIP, 25V B 0.047UF K
CS15 76092628 CERAMIC CHIP, 6.3V B 10UF K
CS16 76092628 CERAMIC CHIP, 6.3V B 10UF K
CS40 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS41 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS42 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS43 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS44 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS45 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS46 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS47 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS50 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS51 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS52 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS53 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS54 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS55 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS56 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS57 76619102 ELECTROLYTIC CHIP, 16V 47UF M
CS64 76619101 ELECTROLYTIC CHIP, 16V 22UF M
CS82 76092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS501 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CS502 76092726 CERAMIC CHIP, 10V B 2.2UF K
CS503 76619100 ELECTROLYTIC CHIP, 16V 10UF M
CS504 76105470 CERAMIC CHIP, 50V CH 47PF J
CS505 76105470 CERAMIC CHIP, 50V CH 47PF J
CV10 76109102 CERAMIC CHIP, 50V B 1000PF K
CV59 76105220 CERAMIC CHIP, 50V CH 22PF J
CV61 76105270 CERAMIC CHIP, 50V CH 27PF J
CV62 76105330 CERAMIC CHIP, 50V CH 33PF J
CV63 76092730 CERAMIC CHIP, 16V B 0.1UF K
CV68 76092621 CERAMIC CHIP, 10V B 1UF K
CV69 76092621 CERAMIC CHIP, 10V B 1UF K
CV72 76794471 ELECTROLYTIC, 16V 470UF M
CV74 76666101 ELECTROLYTIC, 16V 100UF M 3A
CV76 76100104 CERAMIC CHIP, 25V F 0.1UF Z
RESISTORS
R103 76011101 CHIP, 1/20W 100 OHM J
R104 76011103 CHIP, 1/20W 10K OHM J
R105 76011273 CHIP, 1/20W 27K OHM J
R107 76000445 CHIP JUMPER, 1608TYPE
R108 76000445 CHIP JUMPER, 1608TYPE
R110 76011682 CHIP, 1/20W 6.8K OHM J
R114 76000445 CHIP JUMPER, 1608TYPE
R161 76011102 CHIP, 1/20W 1K OHM J
R165 76011392 CHIP, 1/20W 3.9K OHM J
R166 76011472 CHIP, 1/20W 4.7K OHM J
R167 76011101 CHIP, 1/20W 100 OHM J
R168 76011101 CHIP, 1/20W 100 OHM J
R664 76011104 CHIP, 1/20W 100K OHM J
R665 76011104 CHIP, 1/20W 100K OHM J
R670 76011472 CHIP, 1/20W 4.7K OHM J
R671 76011472 CHIP, 1/20W 4.7K OHM J
R672 76011182 CHIP, 1/20W 1.8K OHM J
R673 76011182 CHIP, 1/20W 1.8K OHM J
R678 76871229 CHIP, 1/8W 2.2 OHM J
R679 76871229 CHIP, 1/8W 2.2 OHM J
R680 76011473 CHIP, 1/20W 47K OHM J
R681 76011473 CHIP, 1/20W 47K OHM J
R683 76011223 CHIP, 1/20W 22K OHM J
R684 76011104 CHIP, 1/20W 100K OHM J
R685 76011183 CHIP, 1/20W 18K OHM J
R686 76011102 CHIP, 1/20W 1K OHM J
R688 76552331 OXIDE METAL FILM, 1/2W 330 OHM J
R691 76000445 CHIP JUMPER, 1608TYPE
R693 76552331 OXIDE METAL FILM, 1/2W 330 OHM J

Location Parts No. Description
No. Location Parts No. Description No.
- 20 -
R801 76004716 METAL GLAZE, 1/2W 2.2M OHM J
R803 76366182 CARBON FILM, 1/6W 1.8K OHM J
R805 76366102 CARBON FILM, 1/6W 1K OHM J
R806 76552470 OXIDE METAL FILM, 1/2W 47 OHM J
R807 76366153 CARBON FILM, 1/6W 15K OHM J
R808 76552101 OXIDE METAL FILM, 1/2W 100 OHM J
R809 76321689 OXIDE METAL FILM, 1/2W 6.8 OHM J
R812 76552681 OXIDE METAL FILM, 1/2W 680 OHM J
R813 76366120 CARBON FILM, 1/6W 12 OHM J
R814 76552330 OXIDE METAL FILM, 1/2W 33 OHM J
R815 76552100 OXIDE METAL FILM, 1/2W 10 OHM J
R816 76011681 CHIP, 1/20W 680 OHM J
R817 76382823 0XIDE FILM 1W 82K J
R821 76382680 OXIDE METAL FILM, 1W 68 OHM J
R827 76383103 OXIDE METAL FILM, 2W 10K OHM J
R850 76011101 CHIP, 1/20W 100 OHM J
R851 76011102 CHIP, 1/20W 1K OHM J
R852 76011471 CHIP, 1/20W 470 OHM J
R853 76011103 CHIP, 1/20W 10K OHM J
R854 76011102 CHIP, 1/20W 1K OHM J
R855 76011471 CHIP, 1/20W 470 OHM J
R856 76011102 CHIP, 1/20W 1K OHM J
R857 76011471 CHIP, 1/20W 470 OHM J
R858 76011471 CHIP, 1/20W 470 OHM J
R859 76011102 CHIP, 1/20W 1K OHM J
R861 76007416 CERAMIC COVERED, 5W 82 OHM J
R862 76120002 CERAMIC COVERED G 5W 68 J
R873 76366152 CARBON FILM, 1/6W 1.5K OHM J
R890 76011102 CHIP, 1/20W 1K OHM J
R899 76004718 METAL GLAZE, 1/2W 8.2M OHM J
R4100 76011102 CHIP, 1/20W 1K OHM J
R4101 76011681 CHIP, 1/20W 680 OHM J
R4102 76011471 CHIP, 1/20W 470 OHM J
R4103 76011102 CHIP, 1/20W 1K OHM J
R4104 76011152 CHIP, 1/20W 1.5K OHM J
R4105 76011102 CHIP, 1/20W 1K OHM J
R4106 76011681 CHIP, 1/20W 680 OHM J
R4107 76011471 CHIP, 1/20W 470 OHM J
R4108 76011102 CHIP, 1/20W 1K OHM J
R4109 76011152 CHIP, 1/20W 1.5K OHM J
R4120 76000445 CHIP JUMPER, 1608TYPE
R4122 76000445 CHIP JUMPER, 1608TYPE
R6601 76011223 CHIP, 1/20W 22K OHM J
R6602 76011472 CHIP, 1/20W 4.7K OHM J
R6603 76011223 CHIP, 1/20W 22K OHM J
R6604 76011102 CHIP, 1/20W 1K OHM J
R6605 76011103 CHIP, 1/20W 10K OHM J
R6606 76011104 CHIP, 1/20W 100K OHM J
RA71 76011683 CHIP, 1/20W 68K OHM J
RA72 76011223 CHIP, 1/20W 22K OHM J
RA73 76011103 CHIP, 1/20W 10K OHM J
RA74 76000445 CHIP JUMPER, 1608TYPE
RA76 76011223 CHIP, 1/20W 22K OHM J
RA77 76011103 CHIP, 1/20W 10K OHM J
RA78 76000445 CHIP JUMPER, 1608TYPE
RA79 76000445 CHIP JUMPER, 1608TYPE
RB08 76011470 CHIP, 1/20W 47 OHM J
RB09 76011470 CHIP, 1/20W 47 OHM J
RB10 76011222 CHIP, 1/20W 2.2K OHM J
RB15 76011471 CHIP, 1/20W 470 OHM J
RB24 76000445 CHIP JUMPER, 1608TYPE
RD11 76011393 CHIP, 1/20W 39K OHM J
RD12 76011152 CHIP, 1/20W 1.5K OHM J
RD21 76367101 CARBON FILM, 1/6W 100 OHM G
RD22 76367222 CARBON FILM, 1/6W 2.2K OHM G
RD31 76011153 CHIP, 1/2OW 15K OHM J
RD32 76011473 CHIP, 1/20W 47K OHM J
RD41 76011101 CHIP, 1/20W 100 OHM J
RD43 76000445 CHIP JUMPER, 1608TYPE
RD44 76000445 CHIP JUMPER, 1608TYPE
RD45 76011101 CHIP, 1/20W 100 OHM J
RD50 76000445 CHIP JUMPER, 1608TYPE
RD51 76000445 CHIP JUMPER, 1608TYPE
RD52 76000445 CHIP JUMPER, 1608TYPE
RD53 76000445 CHIP JUMPER, 1608TYPE
RD54 76000445 CHIP JUMPER, 1608TYPE
RD55 76000445 CHIP JUMPER, 1608TYPE
RD56 76000445 CHIP JUMPER, 1608TYPE
RD57 76000445 CHIP JUMPER, 1608TYPE
RD59 76000445 CHIP JUMPER, 1608TYPE
RD61 76011101 CHIP, 1/20W 100 OHM J
RD62 76011101 CHIP, 1/20W 100 OHM J
RD63 76011101 CHIP, 1/20W 100 OHM J
RD73 76011153 CHIP, 1/2OW 15K OHM J
RD74 76000445 CHIP JUMPER, 1608TYPE
RD76 76011563 CHIP, 1/20W 56K OHM J
RD77 76011153 CHIP, 1/2OW 15K OHM J
RD78 76000445 CHIP JUMPER, 1608TYPE
RD82 76011471 CHIP, 1/20W 470 OHM J
RD83 76011562 CHIP, 1/20W 5.6K OHM J
RD84 76011562 CHIP, 1/20W 5.6K OHM J
RD85 76011562 CHIP, 1/20W 5.6K OHM J
RD86 76011562 CHIP, 1/20W 5.6K OHM J
RD88 76011222 CHIP, 1/20W 2.2K OHM J
RD89 76011562 CHIP, 1/20W 5.6K OHM J
RD90 76011102 CHIP, 1/20W 1K OHM J
RD100 76011562 CHIP, 1/20W 5.6K OHM J
RD101 76011102 CHIP, 1/20W 1K OHM J
RD102 76011562 CHIP, 1/20W 5.6K OHM J
RD103 76011562 CHIP, 1/20W 5.6K OHM J
RD105 76011471 CHIP, 1/20W 470 OHM J
RD106 76011562 CHIP, 1/20W 5.6K OHM J
RD107 76011562 CHIP, 1/20W 5.6K OHM J
RE03 76553683 OXIDE METAL FILM, 1W 68K OHM J
RE04 76553683 OXIDE METAL FILM, 1W 68K OHM J
RE05 76554683 OXIDE RES 2W 68K J
RE12 76552221 OXIDE METAL FILM, 1/2W 220 OHM J
RE13 76366473 CARBON FILM, 1/6W 47K OHM J
RE15 76366102 CARBON FILM, 1/6W 1K OHM J
RE16 76366102 CARBON FILM, 1/6W 1K OHM J
RE17 76366363 CARBON FILM, 1/6W 36K OHM J
RE18 76019463 METAL PLATE, 2W 0.22 OHM J
RE19 76310829 OXIDE METAL FILM, 1/2W 8.2 OHM J
RE20 76871152 CHIP, 1/8W 1.5K OHM J
RE23 76552152 OXIDE METAL FILM, 1/2W 1.5K OHM J
RE25 76011103 CHIP, 1/20W 10K OHM J
RE26 76011271 CHIP, 1/20W 270 OHM J
RE27 76011472 CHIP, 1/20W 4.7K OHM J
RE29 76321828 METAL FILM, 1/2W 0.82 OHM J
RE40 76871681 CHIP, 1/8W 680 OHM J
RE43 76011753 CHIP, 1/20W 75K OHM J
RE44 76000593 METAL FILM CHIP 1/16W 10K F
RE45 76000445 CHIP JUMPER, 1608TYPE
RE46 76000605 CHIP, 1/16W 6.8K OHM F
RE48 76011222 CHIP, 1/20W 2.2K OHM J
RE51 76011393 CHIP, 1/20W 39K OHM J
RE52 76011152 CHIP, 1/20W 1.5K OHM J
RE53 76871222 CHIP, 1/8W 2.2K OHM J
RE54 76871222 CHIP, 1/8W 2.2K OHM J
RE56 76190012 METAL FILM CHIP 1/16W 1.5K F
RE57 76190012 METAL FILM CHIP 1/16W 1.5K F
RE58 76190013 CHIP RES 1/16W 22K F
