Toshiba 40RL900A User manual

40RL900A
32RL900A
© TOSHIBA CORPORATION, 2012
All Rights Reserved
OWNER'S MANUAL
VX1A00248500

2
Contents
INSTALLING YOUR TV
Safety Precautions ......................................................... 4
Installation and important information ................. 6
The remote control ........................................................ 8
Inserting batteries and eective range ......... 8
CONNECTING YOUR TV
Connecting external equipment .............................. 9
Connecting an HDMI® device .................................... 10
To connect an HDMI device ............................... 10
HDMI’s ARC (Audio Return Channel) feature ... 10
REGZA-LINK connection .............................................. 11
Connecting a computer .............................................. 12
To connect a PC to the RGB/PC terminal ...... 12
To connect a PC to the HDMI terminal .......... 12
Connecting a home network ..................................... 13
To connect the TV to a home network - Wired ... 13
To connect the TV to a home network
with an internet connection - Wireless ........ 13
To connect the TV to the PC with
Intel® Wireless Display ....................................... 13
Controls and input connections ............................... 14
Switching on ........................................................... 14
Using the menu system ...................................... 14
Using the TV controls and connections ........ 14
MENU structure .............................................................. 15
SETTING UP YOUR TV
Startup Application ....................................................... 16
Quick Setup ............................................................. 16
Auto Tuning ............................................................. 18
ATV Manual Tuning ....................................................... 19
Tuning ........................................................................ 19
Skip ............................................................................. 20
Sorting positions ................................................... 20
DTV Manual Tuning ....................................................... 21
Manual Tuning ........................................................ 21
DTV Settings .................................................................... 21
Channels ................................................................... 21
Standby Channel Update ................................... 22
Location setting ..................................................... 22
Analogue switch-o ............................................ 22
CONTROLS AND FEATURES
General controls ............................................................. 23
Quick Menu ............................................................. 23
Selecting channels ................................................ 23
The Time Display – analogue only ................. 23
Stereo and Bilingual transmissions ................. 23
Sound controls ................................................................ 24
Volume controls and sound mute ................... 24
Dual ............................................................................ 24
Balance ...................................................................... 24
Bass, Treble ............................................................... 24
Voice Enhancement .............................................. 24
Dynamic Bass Boost ............................................. 24
Stable Sound® ......................................................... 24
Dynamic Range Control ...................................... 24
Audio Level Oset ................................................. 24
TV Speakers On/O .............................................. 25
Headphone Settings ............................................ 25
Audio Description ................................................. 25
Widescreen viewing ...................................................... 26
Picture controls ............................................................... 28
Picture Mode ........................................................... 28
Picture preferences ............................................... 28
Reset ........................................................................... 28
ColourMaster .......................................................... 28
Base Colour Adjustment ..................................... 28
Colour Temperature .............................................. 29
Auto Brightness Sensor ....................................... 29
Active Backlight Control ..................................... 29
Black/White Level .................................................. 29
MPEG NR – Noise Reduction ............................. 29
DNR – Digital Noise Reduction ......................... 30
Cinema Mode ......................................................... 30
Resetting the advanced picture settings ...... 30
Automatic Format (Widescreen) ...................... 30
4:3 Stretch ................................................................ 30
Blue Screen .............................................................. 30
Picture Position ...................................................... 30
Picture still ................................................................ 31
Using your home network .......................................... 31
Setting up the Network ............................................... 32
Wireless Setup ........................................................ 32
Advanced Network Setup................................... 34
DNS Setup ................................................................ 35
Network Connection Test ................................... 36
Using the software keyboard ............................ 36
Network Device Setup ................................................. 37
External Control Setup ........................................ 37
Device Name Setup .............................................. 37
Using Toshiba Places ..................................................... 37
Using Intel® Wireless Display ..................................... 38
Intel® Wireless Display Name ............................ 38
PC List ........................................................................ 38
Using the Media Player ................................................ 39
Basic operation ....................................................... 39
Viewing photo les
(on a DLNA CERTIFIED™ Server or USB device) ... 40
Viewing movie les
(on a DLNA CERTIFIED™ Server or USB device) ... 42
Playing music les
(on a DLNA CERTIFIED™ Server or USB device) ... 44
Other features ................................................................. 45
Panel Lock ................................................................ 45
The timers ......................................................................... 45
Programme Timers – digital only ................... 45

3
On Timer ................................................................... 45
Sleep Timer .............................................................. 46
Energy Saving Settings ................................................ 46
Automatic Power Down ...................................... 46
No Signal Power Down ........................................ 46
Digital on-screen information ................................... 47
Information .............................................................. 47
Using EPG (Electronic Programme Guide) ............ 48
Genre selection/searching ................................. 48
Digital settings – parental control .......................... 49
Parental PIN Setup ................................................ 49
Parental Setup ........................................................ 49
Network Lock .......................................................... 49
Digital settings – Channel Options ........................ 50
Selecting favourite channels ............................. 50
Favourite Channel Lists ....................................... 50
Skip channels .......................................................... 50
Locking channels ................................................... 50
Digital settings – other settings .............................. 51
Subtitles .................................................................... 51
Audio languages .................................................... 51
Software Upgrade and Licences ............................... 51
Network Upgrade .................................................. 51
Software Licences ................................................. 51
System Information and ResetTV ............................ 52
System Information .............................................. 52
Reset TV .................................................................... 52
PC Settings ....................................................................... 52
Horizontal and Vertical Position ....................... 52
Clock Phase .............................................................. 52
Sampling Clock ...................................................... 53
Reset ........................................................................... 53
Input selection and AV connections ....................... 53
Input selection ....................................................... 53
Labeling video input sources ............................ 53
Digital Audio Output ............................................ 54
Using REGZA-LINK ......................................................... 55
Enable REGZA-LINK .............................................. 55
TV Auto Power ........................................................ 55
Auto Standby .......................................................... 55
Amplier Control ................................................... 55
Initial Speaker Setting .......................................... 55
REGZA-LINK input source selection ................ 55
REGZA-LINK one touch play .............................. 56
REGZA-LINK system standby ............................. 56
TEXT SERVICES
Text services ..................................................................... 57
Selecting modes .................................................... 57
Text information .................................................... 57
Navigating pages using Auto ........................... 57
Navigating pages using LIST ............................. 57
Control buttons ...................................................... 58
PROBLEM SOLVING
Questions and Answers ............................................ 59
INFORMATION
License Information ...................................................... 62
Information ...................................................................... 63
Specications and accessories .................................. 71
During the life of your TV rmware updates will be made available to ensure that your TV
maintains optimum performance:
USB HDD Recording is supported on this TV, if this functionality is not implemented at time of purchase
it will be made available via rmware update in the last quarter of 2012.
If your TV is connected to the internet, rmware will be automatically made available.

INSTALLING YOUR TV
4
Safety Precautions
This equipment has been designed and
manufactured to meet international safety
standards but, like any electrical equipment,
care must be taken to obtain the best results
and for safety to be assured. Please read the
points below for your own safety. They are
of a general nature, intended to help with
all electronic consumer products, and some
points may not apply to the goods you have
just purchased.
Air Circulation
Leave more than 10cm clearance around the
television to allow adequate ventilation. This will
prevent overheating and possible damage to the
television. Dusty places should also be avoided.
Heat Damage
Damage may occur if the television is left in direct
sunlight or near a heater. Avoid places subject to
extremely high temperatures or humidity. Place in
a location where the temperature remains between
5°C min. and 35°C max.
Mains Supply
The mains supply required for this equipment is
220-240v AC 50Hz. Never connect to a DC supply
or any other power source. DO ensure that the
television is not standing on the mains lead. Use
only the supplied lead.
DO NOT cut o the mains plug from this equipment,
this incorporates a special Radio Interference Filter,
the removal of which will impair its performance.
IF IN DOUBT, PLEASE CONSULT A COMPETENT
ELECTRICIAN.
Do
DO read the operating instructions before you
attempt to use the equipment.
DO ensure that all electrical connections
(including the mains plug, extension leads and
inter-connections between pieces of equipment)
are properly made and in accordance with the
manufacturers’instructions. Switch o and
withdraw the mains plug before making or
changing connections.
DO consult your dealer if you are ever in doubt
about the installation, operation or safety of your
equipment.
WARNING: To prevent injury, this apparatus must
be securely attached to the oor/wall in accordance
with the installation instructions. See page 6.
DO be careful with glass panels or doors on
equipment.
DO NOT REMOVE ANY FIXED COVERS AS THIS
WILL EXPOSE DANGEROUS AND‘LIVE’PARTS.
THE MAINS PLUG IS USED AS A DISCONNECTING
DEVICE AND THEREFORE SHOULD BE READILY
OPERABLE.
Do not
DO NOT obstruct the ventilation openings of
the equipment with items such as newspapers,
tablecloths, curtains, etc. Overheating will cause
damage and shorten the life of the equipment.
DO NOT allow electrical equipment to be exposed
to dripping or splashing or objects lled with liquids,
such as vases, to be placed on the equipment.
DO NOT place hot objects or naked ame sources,
such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and
lead to res.
WARNING: To prevent the spread of
re, keep candles or other open ames
away from this product at all times.
DO NOT use makeshift stands and NEVER x legs
with wood screws. To ensure complete safety,
always t the manufacturer’s approved stand,
bracket or legs with the xings provided according
to the instructions.
DO NOT leave equipment switched on when it is
unattended, unless it is specically stated that it is
designed for unattended operation or has a standby
mode. Switch o by withdrawing the plug, and
make sure your family knows how to do this. Special
arrangements may need to be made for people with
disabilities.
DO NOT continue to operate the equipment if you
are in any doubt about it working normally, or it
is damaged in any way – switch o, withdraw the
mains plug and consult your dealer.

INSTALLING YOUR TV
5
WARNING: Excessive sound pressure from
earphones or headphones can cause hearing loss.
ABOVE ALL - NEVER let anyone, especially
children, push or hit the screen and cabinet back,
or push anything into holes, slots or any other
openings in the case.These actions will damage
screen or internal parts.
NEVER guess or take chances with electrical
equipment of any kind - it is better to be safe
than sorry.
NEVER
NEVER place the TV in an unstabilized location
such as on a shaky table, incline or location
subject to vibration.
Only use cabinets or stands recommended by the• TV manufacturer.
Only use furniture that can safely support the TV.•
Ensure that the TV is not hanging over the edge• of the supporting furniture.
Never place the TV on tall furniture (for example,• cupboards or bookcases) without anchoring both
the furniture and the TV to a suitable support.
Never stand the TV on cloth or other material• placed between the TV and supporting furniture.
The TV may drop or fall o, which may cause an
injury or damage.
NEVER stand or climb on the TV.
Educate children about the dangers of climbing• on furniture to reach the TV or its controls.
Be especially careful in households with children to
prevent them through climbing on top of the TV.
It may move, fall over, break, become damaged or
cause an injury.

INSTALLING YOUR TV
6
Installation and important information
Where to install
Locate the television away from direct sunlight and
strong lights. Soft, indirect lighting is recommended for
comfortable viewing. Use curtains or blinds to prevent
direct sunlight falling on the screen.
Place theTV on a stable, level surface that can support
the weight of theTV. In order to prevent injury and
maintain stability of this apparatus, secure theTV to
the level surface using the strap if tted, or to a wall
using a sturdy tie to the P clips provided. Otherwise
secure the TV on the level surface using the supplied
mounting screw.
The LCD display panels are manufactured using an
extremely high level of precision technology; however,
sometimes some parts of the screen may be missing
picture elements or have luminous spots. This is not a sign
of a malfunction.
Make sure the television is located in a position where it
cannot be pushed or hit by objects, as pressure will break
or damage the screen. Also, please be certain that small
items cannot be inserted into slots or openings in the case.
Sturdy tie (as short as possible)
Stand clip
Fixing strap
Screw
(supplied)
Fixing strap
‘P’ Clip
Avoid using chemicals (such as air refreshers, cleaning agents, etc.) on or near the TV pedestal.
Studies indicate that plastics may weaken and crack over time from the combination eects of
chemical agents and mechanical stress (such as weight of TV). Failure to follow these instructions could
result in serious injury and/or permanent damage to TV and TV pedestal.
When using a Wall Bracket
Please use a wall bracket appropriate for the size
and weight of the LCD TV.
Two people are required for installation.• To install a wall-mount from another manufacturer,• use the SPACERS (supplied).
1Unplug and remove any cables and/or other
component connectors from the rear of the TV.
2Carefully lay the front of the unit face down on a
at, cushioned surface such as a quilt or blanket.
3Follow the instructions provided with your
wall bracket. Before proceeding, make sure
the appropriate bracket(s) are attached to the
wall and the back of the TV as described in the
instructions provided with the wall bracket.
4Make sure to place the spacers supplied between
the bracket and the back of the TV.
5Always use the screws supplied or recommended
by the wall mount manufacturer.
Removing the Pedestal Stand:
1Carefully lay the front of the unit face down on a
at, cushioned surface such as a quilt or blanket.
Leave the stand protruding over the edge of the
surface.
NOTE: Extreme care should always be used when
removing the pedestal stand to avoid damage to
the LCD panel.
2Remove the four screws.
Four screws
3Once you have removed all four screws holding
the pedestal stand in place, remove the pedestal
stand from the TV by sliding the pedestal stand
away from the TV.
Place four spacers (supplied).
CAUTION: The diameter and length of the screws dier
depending on wall bracket model. Use of screws other
than the screws specied may result in internal damage
to the TV set or cause it to fall, etc.
Screw
Wall bracket
Spacer (supplied)
TV back panel
28–32mm
M6 (32RL)
M8 (40RL)
Stand style is dependent on model

INSTALLING YOUR TV
7
Please take note
If stationary images generated by 4:3 broadcasts, text services, channel identication logos, computer
displays, video games, on-screen menus, etc. are left on the television screen for any length of time, they
could become conspicuous. It is always advisable to reduce both the brightness and contrast settings.
Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the
4:3 outlines. This is not a defect of the LCD TV and is not covered under the manufacturer’s warranty. Regular
use of other size modes (e.g.: Super Live) will prevent permanent retention.
EXCLUSION CLAUSE
Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by:
i) Fire;
ii) Earthquake;
iii) Accidental damage;
iv) Intentional misuse of the product;
v) Use of the product in improper conditions;
vi) Loss and/or damage caused to the product whilst in the possession of a third party;
vii) Any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set
out in the owner’s manual;
viii) Any loss or damage caused directly as a result of misuse or malfunction of the product when used
simultaneously with associated equipment;
Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage
including but not limited to the following: loss of prot, interruption of business, the loss of recorded data
whether caused during normal operation or misuse of the product.

INSTALLING YOUR TV
8
The remote control
Simple at-a-glance reference of your remote control.
5
14
4
1
15
13
19
27
26
23
11
9
2
3
86
10
12
2120
22
24
25
17
16
7
18
1For On/Standby mode
2To select external input sources
3Selectable Picture
4Widescreen viewing
5sStereo/bilingual transmissions
6To access the“TOSHIBA PLACES”Top Page
When network is not connected, an error message
will be displayed.
7To select TV Mode (DTV Ant/DTV Cable/ATV)
8To access the analogue or digital Channel List
9Number buttons
10 Switch the Audio Description On/O
11 To return to previous channel
12 To alter the TV volume
13 To change programme positions
To change TEXT pages
14 To display on-screen information
To access the index page inText mode
15 To mute the TV sound
16 To access Quick Menu
17 On-screen Menus
18 To display the digital on-screen Programme Guide
19
When using menus, the arrows move the cursor on
the screen up, down, left or right. Press OK to conrm
your selection
20 To return to previous Menu
21 To exit menus and applications
22
Colour buttons: Text and interactive service control
buttons
23 When inTV mode:
D
Analogue
time display
When inText mode:
A To reveal concealed
text
B
To hold a wanted page
C
To enlarge text display
size
D
To select a page while
viewing a normal
When using
Programme Guide:
Z–24 hours
z+24 hours
CC –1 page
cc +1 page
During Playback:
c To PLAY
v To STOP
W/w To PAUSE/STEP
Z To SKIP-BACK
CC To REWIND
cc To FAST FORWARD
z To SKIP-FORWARD
24 Not available for this TV
25 Picture still
26 To call up text services
27
Digital Subtitles or AnalogueTEXT Subtitle pages if
available
Inserting batteries and eective range
Remove the back cover
to reveal the battery
compartment and
make sure the batteries
are inserted the proper
way. Suitable battery
types for this remote
are AAA, IEC R03 1.5V.
Do not combine a used, old battery with a new
one or mix battery types. Remove dead batteries
immediately to prevent acid from leaking into the
battery compartment. Dispose of batteries in a
designated disposal area.
Warning: Batteries must not be exposed to
excessive heat such as sunshine, re or the like.
The performance of the remote control will
deteriorate beyond a distance of ve metres or
outside an angle of 30 degrees from the centre
of the television. If the operating range becomes
reduced, the batteries may need replacing.

CONNECTING YOUR TV
9
Connecting external equipment
Before connecting any external equipment, turn o all main power switches. If there is no
switch, remove the mains plug from the wall socket.
Media Recorder
or
LAN port
SCART (EXT 1)
DIGITAL AUDIO OUTPUT
(OPTICAL)
HDMI 3 INPUT
HEADPHONE jack
HDMI 1/2 INPUTS
COMPONENT VIDEO/AUDIO INPUT
VIDEO/AUDIO INPUT (Y/L/R)
(EXT 2)
Scart/RCA adaptor
(supplied)
RGB/PC INPUT
Aerial Cable
Power cord
ILLUSTRATION SHOWS 40RL900A.
Aerial cables:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the aerial to the socket on the rear of the
television. If you use a decoder and/or a media
recorder, it is essential that the aerial cable is
connected through the decoder and/or through the
media recorder to the television.
SCART leads: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the media recorder IN/OUT socket to the
television.
Connect the decoder TV socket to the television.
Before running Auto Tuning, put your decoder and
media recorder to Standby.
The RCA sockets alongside the COMPONENT
VIDEO INPUT sockets will accept L and R audio
signals.
When connecting the VIDEO/AUDIO devices,
connect those cables to Y/L/R sockets.
The Digital Audio Output socket enables the
connection of a suitable surround sound system.
NOTE: This output is always active.
HDMI® (High-Denition Multimedia Interface) is for
use with a DVD decoder or electrical equipment
with digital audio and video output. For acceptable
video or PC signal formats through the HDMI
terminals, see page 64.
NOTE: Although this television is able to connect
to HDMI equipment, it is possible that some
equipment may not operate correctly.
LAN port is used to connect the TV to your home
network. This TV can play digital content stored on a
DLNA CERTIFIED™ product with server function.
A wide variety of external equipment can
be connected to the back of the television;
therefore, the relevant owner’s manuals for all
additional equipment must be referred to for
exact instructions.
If the television automatically switches over to
monitor external equipment, return to normal
television by pressing the desired programme
position button. To recall external equipment, press
oto select between TV, EXT1, EXT2,HDMI1,
HDMI2, HDMI3 or PC.
When the external input mode is selected while
viewing DTV mode, the SCART socket does not
output video/audio signals.

CONNECTING YOUR TV
10
Connecting an HDMI® device
The HDMI input on your television receives
digital audio and uncompressed digital video
from an HDMI source device.
This input is designed to accept HDCP (High-
Bandwidth Digital-Content Protection) programme
material in digital form from EIA/CEA-861-D–
compliant consumer electronic devices (such as a
set-top box or DVD player with HDMI output). For
acceptable video signal formats, see page 64.
NOTE: Supported Audio format: Linear PCM, Dolby
Digital (AC-3), sampling rate 32/44.1/48kHz.
To connect an HDMI device
Connect an HDMI cable (type A connector) to the
HDMI terminal.
For proper operation, it is recommended that you
use an HDMI cable with the HDMI Logo ( ).
If your HDMI connection is capable of 1080p• and/or your television is capable of refresh rates
greater than 50Hz, you will need a Category 2
cable. Conventional HDMI/DVI cable may not work
properly with this model.
HDMI cable transfers both video and audio.• Separate analogue audio cables are not required
(see illustration).
HDMI cable
HDMI device
the back of your television
To view the HDMI device video, press the obutton
to select HDMI1, HDMI2 or HDMI 3 mode.
HDMI’s ARC (Audio Return Channel)
feature
This feature enables the audio signal of the
TV to be sent to the AV amplier via the HDMI
cable. It will not be necessary to connect a
cable from the audio output of the TV to the
audio input of the AV amplier to reproduce
the audio received from the tuner of the TV
through the AV amplier.
the back of your television
AV amplifier that supports ARC
HDMI cable

CONNECTING YOUR TV
11
REGZA-LINK connection
You can control the basic functions of connected audio/video devices using the television’s
remote control if you connect a REGZA-LINK compatible AV amplier or playback device. For an
explanation of setup and operations, see pages 55 – 56.
AV amplifier Playback device
Playback device
the back of your television
For the setup shown above, you will need three
HDMI cables.
NOTE:
If several devices are connected, the REGZA-LINK• feature may not operate properly.
For proper operation, it is recommended that you• use HDMI cables with the HDMI Logo ( ).
This function is available when one PC and one• AV amplier are connected separately. However,
it may not operate properly if the PC is connected
via the AV amplier.
Before controlling the device(s):
After completing the above connections, set the• REGZA-LINK Setup menu as you desire (see page
55).
The connected devices must also be set. For• details, see the operation manual for each device.
The REGZA-LINK feature uses CEC technology as• regulated by the HDMI standard.
This feature is limited to models incorporating• Toshiba’s REGZA-LINK. However, Toshiba is not
liable for those operations. Refer to individual
instruction manuals for compatibility information.

CONNECTING YOUR TV
12
Connecting a computer
With either an RGB/PC or an HDMI connection,
you can watch your computer’s display on the
television.
To connect a PC to the RGB/PC terminal
When connecting a PC to the RGB/PC terminal
on the television, use an analogue RGB (15-pin)
computer cable.
the back of your television
Conversion adaptor
if required
(not supplied)
Computer
RGB PC cable (not
supplied)
Mini D-sub
15 pin connector
To use a PC, set the monitor output resolution on
the PC before connecting it to the television. For
acceptable PC signal formats, see page 63.
To display the optimum picture, use the PC setting
feature (see page 63).
NOTE:
Some PC models cannot be connected to this• television.
An adaptor is not needed for computers with a• compatible mini D-sub15-pin terminal.
Depending on the DVD’s title and the• specications of the PC on which you are playing
the DVD-Video, some scenes may be skipped or
you may not be able to pause during multi-angle
scenes.
A band may appear at the edges of the screen• or parts of the picture may be obscured. This is
due to scaling of the picture by the set, it is not a
malfunction.
When PC input mode is selected, some of the• television’s features will be unavailable e.g. Colour
System in the System Setup menu.
Some PC models may output unique signals that• the television may be unable to detect (see page
63).
If connecting a certain PC model with a unique• PC signal, the PC signal may not be detected
correctly.
To connect a PC to the HDMI terminal
When connecting a PC to the HDMI terminal on the
television, use an HDMI-to-DVI adaptor cable.
If connecting a PC with an HDMI terminal, use an
HDMI cable (type A connector).
HDMI-to-DVI
adaptor cable
the back of your television
Computer
For acceptable PC and video signal formats, see
page 63.
NOTE:
The edges of the images may be hidden.•
If connecting a certain PC model with a unique• PC signal, the PC signal may not be detected
correctly.

CONNECTING YOUR TV
13
Connecting a home network
The LAN port allows your Toshiba TV to
connect to your home network. You can
use this revolutionary home entertainment
networking system to access photo, video
and audio les that are stored on a DLNA
CERTIFIED™ server and play/display them on
your TV.
NOTE:
If you connect to a shared network outside your• home, it is advisable to use a router. Always use
DLNA CERTIFIED™ products in private network
environments. Connect this TV to the same router
as other DLNA CERTIFIED™ products (server).
If you use a hub or switch to connect the TV to• your home network, you may not be able to use
the automatic setup and will have to manually set
up the network address. See page 33.
If you use a router with built-in DHCP functionality,• use the automatic setup. Manual setup may not work.
If you connect the TV and PC directly, use a• crossover LAN cable.
Please consult your PC manufacturer about details• of PC settings.
Wireless devices may interfere with Intel® Wireless• Display.
To connect the TV to a home network -
Wired
Modem (if available)
Server PC
Router with Hub
the back of your television
Cable or Phone jack
[1] [2]
[2]
[3][2]
[1] Coaxial or telephone cable (depending on your
modem type)
[2] Standard LAN cable
[3] Do NOT connect a phone jack directly to the TV’s
LAN port.
To connect the TV to a home network
with an internet connection - Wireless
Please refer to“Wireless Setup”section on page 32.
Access point (AP)
Wireless LAN router
Modem
TOSHIBA Dual
Band WLAN
adaptor
the back of your television
Computer
How to use this Dual Band Wireless LAN Adaptor
If this device is going to be operated in the• frequency range of 5.15 GHz to 5.35 GHz, it is
restricted to indoor use.
To connect the TV to the PC with
Intel® Wireless Display
PC with Intel®
Wireless Display
Intel® WiDi
TOSHIBA Dual
Band WLAN
adaptor

CONNECTING YOUR TV
14
Controls and input connections
A wide variety of external equipment can be connected to the input sockets on the side of the
television.
While all the necessary adjustments and controls for the television are made using the remote control,
the buttons on the television may be used for some functions. 40RL900A.ILLUSTRATION SHOWS
Ambient
Light Sensor
REDLED– Standby
GREEN LED– Power on
ORANGE LED– Programme
timer set (digital only)
USBport
Media Player/Wireless LAN adaptor ready for ahome
network
Control panel
Switching on
If the RED LED is not lit, check that the mains plug
is connected to the power supply and press 1on
the remote control; it may take a few moments. The
GREEN LED will be lit.
To put the television into Standby, press 1on the
remote control. To view the television, press 1again.
The picture may take a few seconds to appear.
For energy saving:
We recommend that you use the television with
the factory settings. The factory settings are for
energy saving.
Unplugging the mains plug will cut energy use to
zero for all televisions.This is recommended when
the television is not being used for a long time,
e.g. when on holiday. Reducing the brightness of
the screen will reduce energy use.
Energy eciency cuts energy consumption and
thus saves money by reducing electricity bills.
NOTE: Putting the television into standby mode
will reduce energy consumption, but will still
draw some power.
Using the menu system
Press MENU on the remote control to display the menu.
The menu appears as a list of ve topics. As each
symbol is selected by pressing C or con the remote
control, its respective options will appear above.
NOTE: The same menu is displayed in DTV (Digital
TV) and ATV (Analogue TV) modes; however, where
some items are not available in a mode, they will
appear grayed out.
To use the option, press Band bon the remote
control to move up and down and press Cor cto
select your desired setting.
Using the TV controls and connections
To turn on or o the TV, press• ! .
To alter the volume, press + or – .• + and – buttons operate as volume up/down as
default.
To alter the programme position, press• p/oonce
and press uor U.
To select an external input, press and hold• p/o
until the Inputs window appears, and then press
uor Uto select the appropriate input source.
The Media Player feature provides access to photo,
movie and music les stored on a USB storage
device that is connected via the USB port or on a
network device.
The USB port also has to be used with the“TOSHIBA
Dual Band WLAN Adaptor WLM-20U2”in order to
access a wireless network.
You must use the TOSHIBA Wireless LAN device to
ensure correct operation of this feature. This feature
is available only when the“TOSHIBA Dual Band
WLAN Adaptor“ is used.
Please always refer to the owner’s manual of the
equipment to be connected for full details.
NOTE:
The USB socket has limited functionality and• Toshiba can take no responsibility for damage to
other connected equipment.
Interactive video games that involve shooting a“gun”• at an on-screen target may not work with this TV.

CONNECTING YOUR TV
15
MENU structure
To open the main menu (illustration below) , press MENU on the remote control.
TV Programmes Media Player Connected TV
Setup
Function
Genre Search
Guide Programme
Timers
1st Layer 2nd Layer 3rd Layer
Press MENU. Press Cc/ B. Press Cc. Press OK. Press BbC c.
TV Programmes
Guide
Genre Search
Programme Timers
Jump to Programme Guide (EPG)
Jump to Genre Search
Jump to Programme Timers
Media Player
USB Media Player
Network Media Player USB Media Player Menu
Network Media Player Menu
Connected TV
Toshiba Places Jump to Toshiba Places
NOTE: This menu item is
subject to change without
notice.
Function
On Timer
Sleep Timer
Intel® Wireless Display
On Timer Menu
Sleep Timer Menu
Intel® Wireless Display Menu
Setup
Sound
Preferences
System Setup
Picture Menu
Sound Menu
Preferences Menu
System Setup Menu

SETTING UP YOUR TV
16
Startup Application
Before switching on the TV, make sure your
decoder/media recorder, if applicable, is in
standby. To set up the television, use the
buttons on the remote control as detailed on
page 8.
Quick Setup
aPress the
1button. The Menu Language
screen will appear. This screen will appear
the rst time that the television is switched
on and each time Reset TV is selected.
bPress
Cor cto select the menu language
English or Français.
cPress OK to display the Primary/Secondary
Language and Primary/Secondary Audio
Language item. Press B b C c to select
the language as desired.
Quick Setup
Primary Subtitle Language English
Secondary Subtitle Language
English
French
French
Primary Audio Language
Secondary Audio Language
dPress OK, and the Time Zone screen will
appear.
Time Zone
New South Wales
ePress
Cor c to select Time Zone.
fPress OK, and the Location screen will
appear.
Location
Home
To use the TV for displaying in a store showroom,
please select [Store]. [Home] mode is
recommended for normal use.
gPress
Cor cto select Home or Store. For
normal home use, select Home.
hPress OK, and the AutoView screen will
appear, press Cor cto select Yes or No.
AutoView
No
AutoView mode automatically adjusts picture
settings to suit ambient light conditions. Do you
wish to enable AutoView mode?
iPress OK, and the Network Setup screen
will appear. Press Cor cto select Yes or No.
Network Setup
Yes
Do you want to configure network setup?
When you select• No, skip to step 17.
jPress OK, and the Network Type screen
will appear. Press Cor cto select Wired or
Wireless.
Network Type
Wired
Please select a network type.
When you select• Wired (LAN cable
connection), skip to step 14.
When you select• Wireless (USB WLAN
adaptor connection), follow step 11.
NOTE: If the USB WLAN adaptor is not
connected, Network Type screen does not
display and skip to step 14.
kPress OK, and the Wireless Setup screen
will appear. Press Cor cto select the
Wireless Setup type.
Assisted Setup• - follow step 12.
Input the Security Key only.
Manual Setup• , skip to step 13.
Input the all settings.
Wireless Setup
Assisted Setup
Please select a kind of wireless network.
NOTE: EXIT is available during settings.
lIn step 11, when you select Assisted Setup;
Press OK, and the Assisted Setup screen
will appear. Press Bor bto select the
desired AP and press OK.
NOTE: Check the MAC address on the label of
the AP or in the manual, and select your AP.
Press Bor bto select Security Key and
press OK.
The Software Keyboard window will appear
(page 36).
Input the Security Key by using the Software
Keyboard.
To save your setting, press the BLUE button.

SETTING UP YOUR TV
17
NOTE:
The Security Key must adhere to these• conditions:
- TKIP/AES: 8-63 ASCII or 64 Hex characters
- WEP: 5 or 13 ASCII or 10 or 26 Hex
characters
There is only one key ID to set for WEP• encryption.
Press
Bor bto highlight Done and press
OK.
NOTE:
If Network Name is not displayed, see• Manual Setup below to set Network Name
before pressing Done.
If• BACK is pressed before Done is selected,
settings are not saved.
When the message“Wireless conguration
is complete.”appears on screen, press OK.
The screen will skip to step 14.
mIn step 11, when you select Manual Setup;
Press OK, and the Manual Setup screen
will appear. Press Bor bto select Network
Name and press OK.
The Software Keyboard window will appear
(page 36).
Input the Network Name by using the
Software Keyboard.
To save your setting, press the BLUE button.
Press Bor bto select Authentication and
then press Cor cto select Open System,
Shared Key, WPA-PSK or WPA2-PSK.
Press Bor bto select Encryption, and then
press Cor cto select None, WEP, TKIP or
AES.
NOTE:
Certain encryption types are only• compatible with specic authentication
types.
- When Authentication is Open System, only
WEP or None is compatible.
- When Authentication is Shared Key, only
WEP is compatible.
- When Authentication is WPA-PSK or WPA2-
PSK, only TKIP or AES is compatible.
When incompatible Authentication/• Encryption pairings are detected, a
warning message will be displayed, and
no connection attempt will be made until
the incompatibility is resolved.
There is only one key ID to set for WEP• encryption.
Press Bor bto select Security Key and
press OK. Input the Security Key by using
the Software Keyboard (page 36).
To save your setting, press the BLUE button.
This item is grayed out when Encryption is
None.
When Encryption is WEP, Key ID setting is
available. Press Bor bto select Key ID and
press Cor cto select 1(default), 2, 3or 4.
Press Bor bto select Done and press OK.
When the message“Wireless conguration
is complete.”appears on screen, press OK.
NOTE: Settings are not saved if BACK is
pressed before Done is selected.
nThe Advanced Network Setup screen will
appear.
When the DHCP function of the router
connected with this TV is On, you can set
Auto Setup to On or O. (This should
usually be set to On.)
When the DHCP function of the router is
O, set Auto Setup to O, and set the IP
Address DNS address(es) manually.
IP Address Setup
Auto Setup
Default Gateway
Subnet Mask
IP Address
On
On
00:11:22:33:44:55
DNS Setup
Auto Setup
Secondary DNS Address
MAC Address
Primary DNS Address
Next
XXX . XXX . XXX . XXX
XXX . XXX . XXX . XXX
XXX . XXX . XXX . XXX
XXX . XXX . XXX . XXX
XXX . XXX . XXX . XXX
Advanced Network Setup
You can view the xed MAC address for the
TV and for the Dual Band WLAN Adaptor, if
one is installed.
Press Bor bto select Next.

SETTING UP YOUR TV
18
oPress OK, and Network Connection Test will
start.
A message will appear to indicate if the
connection was successful or it could not be
completed.
OK
Network connection was completed successfully.
NOTE: The result of Network Connection Test
does not always guarantee the connection.
To cancel the Network Connection Test:
Press BACK while searching for the Internet
connection.
pPress OK, and The Auto Tuning will appear.
Auto Tuning
DTV and ATVTuning Mode
Start Scan
Bandwidth 7MHz
qPress
Cor cto select DTV and ATV, DTV
or ATV, if available, and press bto select
Bandwidth.
Press Cor cto select 7MHz, 8MHz or 7MHz
and 8MHz, then highlight Start Scan and
press OK to continue with the Auto Tuning.
The television will start to search for all
available DTV and/or ATV services.
You must allow the television to complete
the search.
When the search is complete, the Auto
Tuning screen will display the services
found.
rPress
Bor bto move through the list to
select a channel and press OK to view.
PLEASE NOTE
The Quick Setup menu can also be
accessed at any time from the Setup /
System Setup menu.
Auto Tuning
NOTE: As new services are broadcast, it will be necessary
to re-tune the television in order to view them.
Auto Tuning will completely re-tune the television
and can be used to update the channel list. It is
recommended that AutoTuning is run periodically
to ensure that all new services are added.All current
channels and settings, i.e. locked channels, will be
lost.
aPress MENU / Ccto highlight Setup icon.
bPress
B/Ccto highlight System Setup icon
and press OK.
cPress
Bor bto select Auto Tuning and
press OK.
System Setup
Menu Language English
Location
Colour System
Quick Setup
Auto Tuning
ATV Manual Tuning
DTV Manual Tuning
DTV Settings
dPress
Cor cto select Yes and press OK.
Auto Tuning
DTV and ATVTuning Mode
Start Scan
Bandwidth 7MHz
Press Cor cto select DTV and ATV, DTV
or ATV, if available, and press bto select
Bandwidth.
Press Cor cto select 7MHz, 8MHz or 7MHz
and 8MHz, then highlight Start Scan and
press OK to continue with the Auto Tuning.
The television will start to search for all
available DTV and/or ATV services.
You must allow the television to complete
the search.
When the search is complete, the Auto
Tuning screen will display the services
found.
ePress
Bor bto move through the list to
select a channel and press OK to view.

SETTING UP YOUR TV
19
ATV Manual Tuning
Tuning
The television can be tuned-in manually using ATV
Manual Tuning. For example, you might use the
feature if the television cannot be connected to a
media recorder/decoder with a SCART lead or when
you want to tune-in a station on another System.
Use Cand cto move across the screen and select
any of the ATV Manual Tuning options. Then use B
or bto adjust the settings.
ATV Manual Tuning
System
IA
1C20C
VR
123 4 65 7 8 9
1Position
The number to be pressed on the remote
control to tune the channel.
2System
Specic to certain areas.
3Colour System
Factory set to Auto, should only be changed if
problems are experienced, i.e. NTSC input from
external source.
4Skip
Set Skip to On (8) or O (() for the selected
channel. See page 20.
5Signal Class
The channel classication.
6Channel
The channel number on which a station is being
broadcast.
7Search
Search up and down for a signal.
8Manual Fine Tuning
Only used if interference/weak signal is
experienced. See page 59.
9Station
Station identication. Use the Bband C c
buttons to enter up to seven characters.
To allocate a position on the television for a decoder
and media recorder: turn the decoder on, insert a
pre-recorded lm in the media recorder, press PLAY
and manually tune.
aIn the System Setup menu, press bto
select ATV Manual Tuning and press OK.
System Setup
Menu Language English
Colour System
Location
Quick Setup
ATV Manual Tuning
DTV Settings
Auto Tuning
DTV Manual Tuning
bUse
Bor bto select the desired position.
We suggest Pos. 0 for a media recorder.
Pos. Channel Station
ATV Manual Tuning
1
2
3
4
6
7
8
C2
C5
C4
C7
C9
5
C12
C23
C27
Dierent Channel numbers may be displayed.
cPress OK to select. If the channel chosen for
the media recorder is set to skip, Skip should
be removed before storing.
dPress
cto select System and press Bor b
to change if required.
ATV Manual Tuning
System
IA
1C20
eThen press
cto select Search.
fPress
Bor bto begin the search.The search
symbol will ash.
ATV Manual Tuning
Search
IA
1C20
gEach signal will show on the television. If it is
not your media recorder, press Bor bagain
to restart the search.
hWhen your media recorder signal is found,
press cto move along to Station. Use B, b,
Cand cto put in the required characters,
e.g. VCR.
ATV Manual Tuning
Station
IA
1C20C
VR

SETTING UP YOUR TV
20
iPress OK to save.
jRepeat for each position you want to tune.
kPress EXIT when you have nished.
PLEASE NOTE
This television has direct channel entry if
the channel numbers are known.
Select the ATV Manual Tuning screen in
Step 3. Enter the Position number, the
System, then Cfor standard (terrestrial)
channels or Sfor cable channels and the
Channel number. Press OK to save.
Skip
To prevent certain channels from being viewed,
positions can be skipped.
aSelect ATV Manual Tuning from the System
Setup menu.
bUse
Bor bto highlight the position to be
skipped and press OK to select.
Pos. Channel Station
ATV Manual Tuning
1
2
3
4
6
7
8
C2
C5
C4
C7
C12
ABC1
ABC1
5
C23
C27
C40
cPress
cto select Skip.
dUse
Bor bto turn Skip on.
Press OK.
8on the screen indicates a skipped
position.
ATV Manual Tuning
Skip: On
IA
1C20
ePress EXIT and repeat steps 1 through 4 to
set other positions if necessary.
Each position has to be individually selected.
To turn Skip o, repeat the procedure for
each position.
Skipped positions cannot be selected by PU
and Puor by the controls on the television
but can still be accessed by the number
buttons on the remote control.
Sorting positions
Channels may be moved and saved to the position of
your choice.
aSelect ATV Manual Tuning from the System
Setup menu.
bWith the list of channels showing, use B
or bto highlight the channel you want to
move and press c.
Pos. Channel Station
ATV Manual Tuning
1
2
3
4
6
7
8
C2
C5
C4
C7
C12
ABC1
ABC1
5
C23
C27
C40
cUse
Bor bto move through the list to your
preferred position. As you do so, the other
channels will move to make room.
dPress
Cto save your move.
Repeat as necessary and press EXIT.
