Owner's Manual
Integrated High Definition
LCD Television
.. t nt6~~'i 8fH H~RDII.
For an overview of steps for setting up your new TV, see page 10.
Note: To display a High Definition picture, the TV must be receiving
a High Definition signal (such as an over-the-air High Definition
TV broadcast, a High Definition digital cable program, or a High
Definition digital satellite program). For details, please contact
your TV antenna installer, cable provider, or satellite provider.

It Makes A Difference How and Where You Use Your Flat
Panel Display
CHILD SAFETY:
Congratulations on your purchase! As you enjoy your
new product, please keep these safety tips in mind:
The Issue
• The home theater entertainment experience is a growing trend
and larger flat panel displays are popular purchases. However,
flat panel displays are not always supported on the proper stands
or installed according to the manufacturer's recommendations .
• Flat panel displays that are
inappropriately situated on dressers,
bookcases, shelves, desks,
speakers, chests or carts may fall
over and cause injury.
TOSHIBA Cares!
• The consumer electronics industry
is committed to making home
entertainment enjoyable and safe
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER·SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Dear Customer,
Thank you for purchasing this Toshiba LCD TV. This
manual will help you use the many exciting features
of your new LCD TV. Before operating your LCD TV,
please read this manual completely, and keep it
nearby for future reference.
www.CE.org/safety
A\
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
.... ~. . presence of uninsulated "dangerous voltage" within the
........ - product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
it
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
• operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
To prevent injury, this apparatus must be securely
attached to the floor/wall in accordance with the
installation instructions. See item 23 on page 4.
WARNING: If you decide to wall mount this
television, always use a UL Listed wall bracket
appropriate for the size and weight of this television.
The use of any wall bracket other than a UL Listed
wall bracket appropriate for the size and weight of this
television for wall mounting this television could result
in serious bodily injury and/or property damage. See
"Removing the Pedestal Stand" (Ifill' page 6).
NOTE TO CATV INSTALLERS
This is a reminder to call the CATV system installer's
attention to Article 820-40 of the U.S. NEC, which
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the POint of cable entry as practical. For
additional antenna grounding information, see items
30 and 31 on page 4.
Tune Into Safety
• One size does NOT fit all. Follow the manufacturer's recommendations
for the safe installation and use of your flat panel display.
• Carefully read and understand all enclosed instructions for
proper use of this product.
• Don't allow children to climb on or play with furniture and
television sets.
• Don't place flat panel displays on
furniture that can easily be used as
steps, such as a chest of drawers.
• Remember that children can
become excited while watching a
program, especially on a "larger
than life" flat panel display Care
should be taken to place or install
the display where it cannot be
pushed, pulled over, or knocked down.
• Care should be taken to route all cords and
cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
Wall Mounting: If you decide to wall mount your
flat panel display, always:
• Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory (such
as UL, GSA, ETL).
• Follow all instructions supplied by the display and wall mount
man ufactu rers.
• If you have any doubts about your ability to safely install your
flat panel display, contact your retailer about professional
installation.
• Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction If you
are unsure, contact a professional
installer.
• A minimum of two people are
required for installation. Flat panel
displays can be heavy.
2

Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
~L __ ~~_~_~t _~_s_~_!~!~_~ep.~~.a_t~~_~_~~L~ ~~_~L __ . .. _ .. __ .
?_L.~I_~~_~_~.~_~y-_~_i_t~._~_~y-_.c_I_~!~.: . __ ...... _ ...
7) Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
~-------'---' --- -------- -~~-----~~--- --- -~-----------~------ -.----
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
..... (L~.c.I_~.~i~9.~ Il1pl!!.i.~_r~) .t~~! PEg~.~g_e.~.e~!_ .
9) Do not defeat the safety purpose of the polarized
or grounding type plug. A polarized Wide blade ~
plug has two blades with one wider ~~.. ..... ~
than the other. A grounding type .'.
plug has two blades and a third ~ ~
grounding prong. The wide blade or
the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult
an el.e.ctrician for Ee.pl~~e._rllent~f.t.h.e. __ ~~~olete.g_u.tle.t ..
10) Protect the power cord from being walked on
or pinched, particularly at plugs, ~_
convenience receptacles, and the point . . .•. '. ,-
. .. __ ~_~_~.r.e. .!~e.X_e.~i!_f!-o.ll1_ !_~.e. __ ~P_p_~_r.~~~: 'W=
11) Only use attachments/accessories specified by the
manufacturer.
."- .... _---- -----, --_ .. _---------- _. . -------------._--. -' .. _ .. ---.-.-----------" .. __ .- .. ~
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer,
or sold with the apparatus. When a _I
cart is used, use caution when moving
~he cart/app~ratus combination to avoid • ~
Injury from tip-over. ~ 'i. _
- ----_._.',,--' ... -.------ .. _----_ ... _.... ---_ .... ---_._-- ------ -.•.."-- -_.' .- .. _---------.- _." - .. ---
13) Unplug this apparatus during lightning storms
or when unused for long periods of time.
-- -- -- ~- -- .--- ------ - -- ---- ---- -- -- ---- --~---- ~-----------------
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
Additional Safety Precautions
14a) CAUTION: If the TV is dropped and the cabinet or
enclosure surface has been damaged or the TV does
not operate normally, take the following precautions:
• ALWAYS turn off the TV and unplug the power
cord to avoid possible electric shock or fire.
• NEVER allow your body to come in contact
with any broken glass or liquid from the
damaged television. The LCD panel inside the
TV contains glass and a toxic liquid. If the
liquid comes in contact with your mouth or
eyes, or your skin is cut by broken glass, rinse
the affected area thoroughly with water and
consult your doctor.
• ALWAYS contact a service technician to inspect
the TV any time it has been damaged or dropped.
15) CAUTION:
• To reduce the risk of electric shock, do not
use the polarized plug with an extension cord,
receptacle, or other outlet unless the blades
can be inserted completely to prevent blade
exposure.
• To prevent electric shock, match wide blade of
______ __ .p!~_~_!_o __ ~!.~_e_ ~~o~;_~IJ~_!~s~rt. .. .. '
16) WARNING:
To prevent the spread of fire, keep candles or other
open flames away from this product at all times.
Installation, Care, and Service
Installation
Follow these recommendations and precautions and
heed all warnings when installing your TV:
---- -~------ --- ---._- .. _-- ------_. - --, - -----_._- -- .. --- --- ---- -- -- _. -- .....
17) WARNING: NEVER expose batteries to excessive
heat such as sunshine, fire or the like .
--_._-----_ .. _. ._--- ---. _ .. - ---------_._---_ .... - - -
18) ALWAYS plug the product into an outlet
;j\
that is located in such a manner that
~ it can be easily unplugged in case the
• pr_od_~ct req_uire~seryice.
...... -- .
19) NEVER route the product's power cord inside a wall
or similar enclosed area.
20) Never modify this equipment. Changes or
modifications may void: a) the warranty, and b) the
user's authority to operate this equipment under the
rules of the Federal Communications Commission.
21) it DANGER: RISK OF SERIOUS PERSONAL
INJURY, DEATH, OR EQUIPMENT
• DAMAGE!
Never place the TV on an unstable (I)
cart, stand, or table. The TV may 1I1
fall, causing serious personal • ~
injury, death, or serious damage i ~~
to the TV
------_._---~.~------------- ._-- -_. --_ .. _--- --_. ---._-_. -- - -- - .. _------------ ._--- ._. _. ---- '--
22) To avoid damage to this product, never place or store
the TV in direct sunlight; hot, humid areas; or areas
subject to excessive dust or vibration.
(COli! illllcd)
3

23) Always place the TV on the floor or a sturdy, level,
stable surface that can support the weight of the unit.
To secure the TV, use a sturdy strap from the hook(s)
on the rear of the TV to a wall stud, pillar, or other
immovable structure. Make sure the strap is tight,
secure, and parallel to the floor.
JH'
f;:::;. Sturdy strap (as .. s. h .• o .... r ... t. a.s possible)
. ~ 4" ~
L~ min. HO(Ok t:~/ 9
~ . J
TV side TV top
24) The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such
, ., .. ~~. Y.~~~~ "~~~!~_~~ .pl.~~~~.~~ .. t~e. .. ~p-e~~~t~~._ ..
25) Never block or cover the slots or openings in the TV
cabinet back, bottom, and sides. Never place the TV:
• on a bed, sofa, rug, or
similar surface;
• too close to drapes,
curtains, or walls; or
• in a confined space such
as a bookcase, built-in
cabinet, or any other place with poor ventilation.
The slots and openings are provided to protect the
TV from overheating and to help maintain reliable
operation of the TV. Leave a space of at least 4 (four)
inches around the TV.
_._----~--------------------~~-_. --"._._------------- -------------- -~---_._.
26) Always place the back of the television at least four
(4) inches away from any vertical surface (such as a
._ .. _ .... ':Y.~!!U~il~g~.P!.~ p'.e!-_y~~!~~!!~~:. _. __ .. _ .. __ .. __ .. .~_
27) Never allow anything to rest on or rollover the power
cord, and never place the TV where the power cord is
.......... s.~.~Le.C!.!?_.~e..~~_~L.~~~_s.e:... ..
28) Never overload wall outlets and extension cords.
,-. - --_ ..- --- -. --_._---- --~-_._._- ---' .•. " ._~-,----~-_._----_.- - -~--- ----,- .-. __ .. __ .... _._-------
29) Always operate this equipment from a 120 VAC, 60
.. _ ... J:iU~Q'!Y.~L?Q_~.~9_e .. Q.oJy.:. .. _ .. ... __ . ..... __ ....
30) Always make sure the antenna system is properly
grounded to provide adequate protection against
voltage surges and built-up static charges (see
Section 810 of the National Electric Code).
31) Lh DANGER: RISK OF SERIOUS
PERSONAL INJURY OR DEATH!
•
• Use extreme care to make sure you are never
ina position where your body (or any item
you are in contact with, such as a ladder or
screwdriver) can accidentally touch overhead
power lines. Never locate the antenna near
overhead power lines or other electrical
circuits.
• Never attempt to install any of the following
during lightning activity: a) an antenna
system; or b) cables, wires, or any home
theater component connected to an antenna
or phone system.
Care
For better performance and safer operation of your TOSHIBA
TV, follow these recommendations and precautions:
32) If you use the TV in a room whose temperature is
32 OF (0 °C) or below, the picture brightness may
vary until the LCD warms up. This is not a sign of
malfunction.
33) Always unplug the TV before cleaning. Gently wipe
the display panel surface (the TV screen) using a dry,
soft cloth only (cotton, flannel, etc.). A hard cloth
may damage the surface of the panel. Avoid contact
with alcohol, thinner, ~,'
benzene, acidic or alkaline
solvent cleaners, abrasive 0~"
cleaners, or chemical
cloths, which may damage
the surface. Never spray
volatile compounds such as insecticide on the
cabinet. Such products may damage or discolor the
cabinet.
34) ~ WARNING: ;j\
~ RISK OF ELECTRIC SHOCK! Lb
Never spill liquids or push objects of any kind into
the TV cabinet slots.
35) While it is thundering, do not touch the
connecting cables or apparatus.
---_._------------------------------,-._-----------._---------
36) For added protection of your TV from lightning
and power surges, always unplug the power
cord and disconnect the antenna from the TV if
you leave the TV unattended or unused for long
periods of time.
/ Antenna lead-in wire
Antenna discharge unit
~/ (NEC Section 810-20)
~ Grounding conductors
(NEC Section 810-21)
/'
. Power service grounding
/.-:-- electrode system
(NEC Art 250 Part-H)
Ground clamps
//
// /Ground clamp ~
l-·:··::~ .. ~·:-=-.=·:=::::::.::..· ~
Electric service
equipment
(cOlltinued)
4

37) ALWAYS unplug the TV to completely disconnect
from mains power. When the TV is turned off using
the on/off switch, it is not completely disconnected
from power and a minute amount of current is still
consumed.
38) During normal use, the TV may make occasional
snapping or popping sounds. This is normal,
especially when the unit is being turned on or off. If
these sounds become frequent or continuous, unplug
the power cord and contact a Toshiba Authorized
Service Center.
42) If you have the TV serviced:
• Ask the service technician to use only replacement
parts specified by the manufacturer.
• Upon completion of service, ask the service
technician to perform routine safety checks to
_. det~_~J!!~ __ !ha!..!he }V is in safe_~e~~~~9-_~on~~~?..n..:_
43) The cold cathode fluorescent lamp in the LCD panel
contains a small amount of mercury.
When the TV reaches the end of its useful life,
dispose of the used TV by the approved method for
your area, or ask a qualified service technician to
properly dispose of the TV.
Note: The lamp(s) inside this product
.--.----------~---------~~--~-~----~--- I
I
I
I
I
I
I
I
39) Lh DANGER: RISK OF SERIOUS i
PERSONAL INJURY OR DEATH! i
• .. _"l"'ll!'b. II
0J)
"'.~~~~
Never strike the screen ~ I
___ ~~l:cl_ sh_a:_o_rh_::'~_. .~_~!;;~ I
40) • The LCD screen of this product can be damaged i
by ultraviolet radiation from the sun. When II
selecting a location for the television, avoid I'
locations where the screen may be exposed to
direct sunlight, such as in front of a window. I
• Never touch, press, or place anything on the LCD II,
screen. These actions will damage the LCD screen.
I
Never attempt to service the TV yourself. Opening I
and removing the covers may expose you to I
dangerous voltage or other hazards. Failure to follow ;1;
this WARNING may result in death or serious injury.
Refer all servicing not specified in this manual to a ,II
Toshiba Authorized Service Center.
I
I
I
contain mercury Disposal may be regulated
due
to environmental considerations. For
disposal
or recycling information, contact
your local authorities or the Electronics
Industries Alliance (www.eiae.org).
Choosing a location for your LCD TV
To Display your LCD TV on the included
Pedestal Stand:
Observe the following safety precautions:
I) Read and Follow the pedestal assembly instructions
included with the pedestal.
CAUTION: Before beginning pedestal assembly,
carefully lay the front of the LCD Panel face down
on aflat, cushioned surface such as aquilt or blanket.
Leave the bottom of the unit protruding over the edge
of the surface and assemble the pedestal as indicated
below.
Note: Extreme care should always be used
when attaching the pedestal stand
to avoid
damage
to the LCD panel.
2) Place the TV on asturdy, level surface that can
support the weight of the TV.
3) Be sure to secure the TV to awall, pillar. surface, or
other immovable structure. (1& item 23, page 4).
To Display your LCD TV using a Wall
Bracket:
If you decide to wall mount your LCD TV, always use
a UL listed wall bracket appropriate for the size and
weight of the LCD TV (1& page 2):
I) CAUTION: Two people are required for installation.
2) Unplug and remove any cables and/or other
component connectors from the rear of the TV.
3) Remove the screws of the VESA Mounting Pattern
show in the right diagram.
4) Follow the instructions provided with your
wall bracket. Before proceeding. make sure the
appropriate bracket(s) are attached to the wall and
the back of the TV as described in the instructions
provided with the wall bracket.
5) After attaching the appropriate bracket(s) to the wall
and the back of the TV, remove the pedestal stand
from the TV as described below.
(continued)
5

40" TV
CAUTION: Always place the TV on the floor or a sturdy,
level, stable surface that can support the weight of
the unit. To secure the TV, use a sturdy strap from
the hook(s) on the rear of the TV to a wall stud, pillar,
or other immovable structure. Make sure the strap is
tight, secure, and parallel to the floor.
Sturdy strap
(as short as possible)
Hook
Sturdy strap
(as short as possible)
VESA Mounting Pattern
VESA Mounting Pattern
Four screws
Four screws
46" TV
VESA Mounting Pattern
Four screws Sturdy strap
(as short
as possible)
(unit in mm)
Note: Extreme care should always be used
when removing the pedestal stand
to avoid
damage
to the LCD panel.
VESA Mounting Pattern
Removing the Pedestal Stand
I) Carefully lay the front of the unit face down on atlat.
cushioned surface such as aquilt or blanket. Leave
the stand protruding over the edge of the surface.
37" TV
2) Remove the four screws shown in the right diagram.
This wi II allow removal of the pedestal stand.
3) Once you have removed all four screws, holding the
pedestal stand in place, remove the pedestal sland
from the TV.
32" TV
6)
VESA Mounting Pattern
TV Size Hole Pattern( HxV)
Screw Size
31" 200x200 mm M6
31" 200x200
mm
M6
40"
200x200 mm M6
46" 400x200 mm
MR
Four screws
Hook
Stu rdy strap
(as short
as possible)
6

FCC Declaration of Conformity
Compliance Statement (Part 15):
The Toshiba 32RV525RZ, 32RV52RZ, 37RV525RZ,
37RV52RZ,40RV525R,40RV525RZ,40RV52R,
40RV52RZ, 46RV525R, and 46RV525RZ Televisions
comply with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(I) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may
cause undesired
operation.
The party responsible for compliance to these rules is:
Toshiba America
Consumer Products, L.L.C.
82 Totowa Rd. Wayne, NJ 07470.
Ph: 1-800-631-3811
Note: This equipment has been tested and found
to comply with the limits for aClass Bdigital
device, pursuant to Part
15 of the FCC rules.
These limits are designed to provide reasonable
protection against harmful interference
in a
residential installation. This equipment generates,
uses,
and can radiate radio frequency energy
and if not installed and used in accordance with
the Instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference
to radio or television
reception, which can be determined by removing
and applying power to the equipment, the user is
encouraged to try to correct the interference by
one or more of the following measures.
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
the receiver.
•Connect the equipment into an outlet on acircuit
ditferent from that to which the receiver
is connected.
•Consult the dealer
or an experienced radiorrV
technician for help.
Caution: Changes or modifications to this
equipment not expressly approved by Toshiba
could void the user's authority to operate this
equipment.
ENERGY STAf(BJ User
Information
ENERGY STAR User Information Statement: the
factory default settings
of this television meet ENERGY
STAR requirements. Changing Picture Settings may
increase energy consumption, possibly beyond the limits
required for
ENERGY STAR qualification.
To ensure your television
is operating at optimal energy
efficiency, select [Home1mode during initial activation.
To return to [Home] mode settings. select [Standard]
picture mode. [Standard] mode is
recommended for
normal home use.
ENERGY STAR® qualified TV.
Products that earn the ENERGY
STAR prevent green house
gas emissions by meeting
strict guidelines set by the
U.S. Environmental Protection
Agency. ENERGY STAR and
the ENERGY STAR mark are
registered U.S. marks.
Important notes about your
LCD TV
The following symptoms are technical limitations
of LCD Display technology and are not an
indication of malfunction; therefore, Toshiba is
not responsible for perceived issues resulting from
these symptoms.
1) An afterimage (ghost) may appear on the screen if
afixed, nonmoving image is displayed for a long
period of time. The afterimage is not permanent
and will disappear in a short period of time.
2) The LCD panel contained in this T~ is
manufactured using an extremely high level
of precision technology: however, there may
be an occasional pixel (dot of light) that does
not operate properly (does not light, remains
constantly lit, etc.). This is a structural property of
LCD technology, is not a sign of malfunction. and
is not covered under your warranty. Such pixels
are not visible when the picture is viewed from a
normal viewing distance.
Note: Interactive video games that involve
shooting a "gun" type of joystick at an on-
screen target may not work with this TV
Trademark Information
•OSound and [~] symbol are trademarks of
OSound Labs, Inc.
•Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol
are trademarks
of Dolby Laboratories.
•HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks
or
registered trademarks of HDMI Licensing LLC.
7

Contents
Important Safety Instructions 3
Installation, Care, and Service 3
Chapter 1: Introduction 9
Features of your new TV 9
Overview of steps for installing. setting up, and using
your new TV 10
TV front and side panel controls and connections ll
TV back panel connections 12
Chapter 2: Connecting your TV 13
Overview of cable types 13
About the connection illustrations 13
Connecting a VCR (or a VCR with S-video) and antenna,
Cable TV or Camcorder 14
Connecting a DVD player with ColorStream'
(component video), a VCR, and a satellite receiver ... 15
Connecting an HDMITM or DVI device to the
HOMI input 16
REGZA-LlNK® connection 17
Connecting a digital audio system 18
Connecting an audio system 18
Connecting a personal computer (PC) 19
Chapter 3: Using the remote control 20
Prcparing the remote control for use 20
Installing the remote control batteries 20
Remote control effective range 20
Learning about the remote c;ntrol 21
Using the remote control to control your other devices 22
Remote Control functional key chart... 23
Programming the remote control to control
your other devices 24
Remote control codes 25
Chapter 4: Menu layout and navigation 27
Main menu 1ayout... 27
Setup/Installation menu layou!. 28
Navigating the menu system 28
Chapter 5: Setting up your TV 29
Setting the Energy Saving Mode 29
Selecting the menu language 29
TOSHIBA Logo LED 29
Configuring the antenna input source for the
ANT/CABLE terminal 29
Programming channels into the TV's channel memory 30
Programming channels automatically 30
Manually adding and deleting channels in
the channel memory 30
Labeling channels 31
Setting the HDMFM audio mode 32
Viewing the digital signal meter. 33
Setting the time zone 33
Viewing the system status 33
Chapter 6: Using the TV's features 34
Selecting the video input source to view 34
Labeling the video input sources 34
Tuning channels ~ 35
. Tuning channels using the Channel Browser
DI
35
Setting the Channel Tuning Mode 37
Tuning to the next programmed channe!.. 38
Tuning to a specific channel (programmed or
unprogrammed) 38
Switching between two channels using
Channel Return 38
Switching between two channels using SurfLock
H1
38
Selecting the picture size 38
8
Scrolling the TheaterWide@ picture
(TheaterWide 2 and 3 only) 40
Using the auto aspect ratio feature 40
Selecting the cinema mode 41
Using the FREEZE feature 41
Adjusting the picture 41
Selecting the picture mode 41
Adjusting the picture quality 42
Using the closed caption mode 42
Base closed captions 42
Digital CC Settings 43
CC Selector 43
Adjusting the audio 43
Muting the sound 43
Using the digital audio selector 43
Selecting stereo/SAP broadcasts 44
Adjusting the audio quality 44
Selecting the optical audio output fonnat... 44
Using the Dolbl' Digital Dynamic Range Control
feature 45
Usin
o
the Locks menu 45
En~ering the PIN code 45
If you cannot remember your PIN code 45
Changing your PIN code 45
Blocking TV programs and movies
by rating (V-Chip) 45
Downloading an additional rating system for
blocking TV programs and movies 46
Blocking channels 47
Unlocking programs temporarily 48
Using the input lock feature 48
Using the GameTimer@ 48
Using the control panel lock feature 49
Using the PC settings feature 49
Setting the PC Audio 50
Settin ~g the sleep timer 50
® "0
Using REGZA-L1NK )
REGZA-L1NK0 playback device
(DVD player, etc.) control 50
REGZA-L1NK® input source selection 51
VOLUME and MUTE controls of Audio Receiver 51
Other REGZA-L1NK(~ functions 51
Displaying TV status information 52
Understanding the auto power off feature 52
Undcrstanding the last mode memory feature 52
Chapter 7: Using the TV's advanced features 53
Using the advanced picture settings features 53
Using dynamic contrast 53
Using the static gamma feature 53
Using CableClear~ digital noise reduction 54
Using MPEG noise reduction 54
Using the Game Mode teature 54
Usin
o
the advanced audio settings features 55
b(f
Using the QSound') sound feature 55
Chapter 8: Troubleshooting 56
General troubleshooting 56
Chapter 9: Appendix 58
Specifications 58
Acceptable signal fonnats for PC IN and
HDMlterminals 59
Limited United States Warranty
for LCD Televisions 26" and Larger. 60
Limited Canadian Warranty
for Toshiba Brand Flat Panel Televisions 61

Features of your new TV
The following are just afew of the many exciting
features
of your new Toshiba widescreen, integrated
HD, LCD TV:
•
Integrated digital tuning (8VSB ATSC and
QAM) eliminates the need for aseparate digital
converter set-top box (in most cases).
• I080p output resolution.
•
Three HDMJTM digital, high-definition
multimedia interfaces I080p input support (IrE
page 16).
•
HDMI new capability
Lip-Sync Latency activates an audio/video
display timing adjustment function that allows
HDMI source devices to accurately perform
synchronization automatically.
•Two sets
of ColorStream® HD high-resolution
component video inputs (IrE page 15).
•QSound® audio technologies (IrE page 52).
•Digital Audio
Out optical audio connection with
Dolby® Digital optical output format (IrE page 45).
•CableClear® digital picture noise reduction (IrE
page 54).
•
PC IN (Analog RGB) computer terminal (IrE page
19).
•
Channel Labeling allows you to put the Call
Letters (e.g. ABC, HBO, etc.) on the screen along
with the station numbers, so you always know
what you're watching
(IrE page 31).
•
REGZA-LINK allows control of external devices
from the TV remote via HDMI connection(1rE
page 50).
9

Overview of steps for installing,
setting up, and using your new TV
Follow these steps to set up your TV and begin using
its many exciting features.
1Carefully read the important safety, installation,
care, and service information. Keep this manual
for flllure reference.
2Observe the following when choosing alocation
for the TV:
•Read "Important notes about your LCD TV"
(u~\' page 7).
•Place the TV
on the noor or asturdy, level.
stable surface that can support the weight
of the
unit. Secure the TV
to awall. pillar, or other
immovable structure
(I@\' page 4).
•Place the TV
in alocation where light does not
reflect
on the screen.
•Place the TV far enough
frol11 walls and other
objects to allow proper ventilation, Inadeljuate
ventilation may cause overheating. which will
damage the
TV THIS TYPE OF DAMAGE
IS NOT COVERED UNDER THE TOSHIBA
WARRANTY.
3Do not plug in any power cords until AFTER you
have connected all cables and devices to your
TV
4BEFORE connecting cables or devices to the TV
learn the functions (;-]. the TV's connections and
controls
(1fM' pages I1-12).
5Connect your other electronic device(s) to the TV
(u,~' pages D-19).
6Install the batteries in the remote control (Irs" page
20).
7See "Learning about the remote control" (I@' page
21 ) for an overview of the buttons on the remote
control.
8Program the remote control to operate your other
devlce(s) (((i'\' pages
22-26).
9AFTER connecting all cables and devices, plug
in the power cords for your TV and other devices.
Then press POWER on the TV control panel or
remote control to turn on the TV If the TV stops
responding
to the controls on the remote control
or TV control panel and you cannot turn the TV
off or on, please unplug the power cords
few
seconds then re-plug to try again,
I 10
10 See "Menu layout and navigation" for a ljuick
overview
of navigating the TV's menu system
(II§,' page 27).
11 Program channels into the TV's channel memory
(o~' page 30).
12 For details on using the TV's features, see
Chapters 6and
7.
13 For help, refer to the Troubleshooting Guide.
Chapter
8.
14 For technical specifications and warranty
information, see Chapter 9,
15 Enjoy your new TV'

TV front and side panel controls and connections
Model40RV525RZ is used in this manual for illustration purposes.
TV top
21
TV front
SERVKJE
ONLY
4-
1
'------'
Control panel
1 Green LED and TOSHIBA Logo LED
Power LED(Green) =Power indicator
TOSHIBA Logo LED= On or Off (1& page 28).
2 Remote sensor -Point the remote control
toward this remote sensor (1& "Remote control
effective range"
on page 20).
3 VIDEO-2 IN -The side panel AN connections
are refened to
as "VIDEO 2" and include standard
AN connections.
6 ARROWS A....... ~ -When amenu is on-
screen, these buttons function
as up/down/left!
right menu navigation buttons.
7 MENU (ENTER) -Press to access the menu
system
(1& pages 27-28). When amenu is on-
screen, the
MENU button on the TV's control
panel functions
as the ENTER button.
8 EXIT -Press to instantly close an on-screen
menu.
4 Service port -For service use only. Used for
updating the television's firmware.
5 POWER -Press to tum the TV on and off.
If the TV stops responding to the controls on
the remote control or TV control panel and
you cannot tum off the
TV, press and hold the
POWER button on the TV control panel for 5or
more seconds to reset the
TV.
9 CHANNEL A .... -When no menu is on-screen,
these buttons change the channel (programmed
channels only; 1& page 30).
10 VOLUME .... ~ -These buttons adjust the
volume level.
11 INPUT -Repeatedly press to change the source
you are viewing
(ANT/CABLE, VIDEO 1, VIDEO 2,
ColorStream H01, ColorStream H02, HOMI1,
HOMI 2, HOMI 3, PC).
11

TV back panel connections
For an explanation of cable types and connections, see pages 14~20.
1
TV back
1 HDMITM IN -High-Definition Multimedia
Interface input receives digital audio and
uncompressed digital video from an HDMI
device
or uncompressed digital video from aDVI
device.
HDMI connection is necessary to receive
I080p signals.
2 ColorStream® HD-l and ColorStream® HD-2
-Two sets of ColorStream® high-definition
component video inputs (with standard stereo
audio inputs) for
connecting devices with
component video output, such as aToshiba DVD
player with ColorStream®.
Note: Component video cables carry only
video information; separate audio cables
are required for acomplete connection.
3 VIDEO-l IN -Standard (composite) video and
standard audio inputs plus optional
S-video
inputs for connecting devices with composite
video or S-video output.
Note: Standard (composite) video and
S-video cables carry only video information;
separate audio cables are required for a
complete connection.
I 12
4 Audio OUT Variable - Analog audio outputs for
connecting an audio amplifier.
5 ANT/CABLE - Antenna input that supports
analog
(NTSC) and digital (ATSC) off-air
antenna signals and analog and digital Cable TV
(QAM) signals.
6 Digital Audio OUT -Optical audio output in
Dolby Digital or PCM (pulse-code modulation)
format for
connecting an external Dolby Digital
decoder, amplifier, A/V receiver,
or home theater
system with optical audio input.
7 PCIHDMI-l (AUDIO) IN -PC audio input
terminals are shared with
HDMI-I analog audio
input terminals, and their use can be configured
in the Audio Setup menu (u:w page 50).
8 PC IN -For use when connecting apersonal
computer.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.Manufactured
under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.

Overview of cable types
Cables can be purchased from most stores that sell audio/
video devices. Before purchasing
any cables, be sure of
connector types required
by your devices and the length
of each cable.
Coaxial (F-type) cable
@)~~-----
Coaxial (F-type) cable is used for connecting your
antenna, cable TV service, and/or cable converter box
to the
ANT/CABLE input on your TV.
Standard AN cables (red/white/yellow)
~~
~ -~-----
~
Standard AN cables (composite video) usually come
in sets of three, and are for use with video devices with
analog audio and composite video output. These cables
(and
the related inputs on your TV) are typically color-
coded according
to use: yellow for video, red for stereo
right audio, and white for stereo left (or mono) audio.
S-video cable
~~ UJIIIW--------
S-video cable is for use with video devices with
S-video output. Separate audio cables are required for a
complete connection.
Note: An S-video cable provides better picture
performance than acomposite video cable. Ifyou
connect an S-video cable, be sure
to disconnect
the standard (composite) video cable or the picture
performance will be unacceptable.
Component video cables (red/green/blue)
I~·---
~~
Component video cables come in sets of three and are
for
use with video devices with component video output.
(ColorStream® is Toshiba's brand of component video.)
These cables are typically color-coded red, green, and
blue. Separate audio cables are required for acomplete
connection.
Note: Component video cables provide better
picture performance than astandard (composite)
video or S-video cable.
HOMITM cable
(with HOMI Logo "HOml")
O~
HDMI (High-Definition Multimedia Interface) cable
is for use with devices with an HDM! output. An
HDMI cable delivers digital audio and video in its
native format. This cable carries both video and audio
information; therefore, separate audio cables are not
required for acomplete HDMI device connection
(1&
page 16 and page 19).
Note: HOMI cable provides betterpicture
performance than astandard (composite) video
or
S-video cable.
Optical audio cable
[Q] cECJ::lto----
Optical audio cable is for connecting receivers with
Dolby Digital or PCM (pulse-code modulation) optical
audio input
to the TV's DIGITAL AUDIO OUT terminal
(1& page 18).
Analog RGB (1S-pin) computer cable
i{D;==
Analog RGB (IS-pin) computer cable is for connecting
a
PC to the TV's PC IN terminal (1& page 19).
About the connection illustrations
You can connect different types and brands of devices to
your TV in several different configurations. The connection
illustrations
in this manual are representative of typical
device connections only. The input/output terminals on
your devices may differ from those illustrated herein. For
details
on connecting and using your specific devices, refer
to each device's owner's manual.
13 I

Connecting a VCR (or a VCR with S-video) and antenna, Cable TV or
Camcorder
From Cable TV or From Cable TV
antenna
Camcorder
AUDIO
OUT
l~ ~
on TV right side
panel
r---...
~E~l
I ~oo ~
_,.ur-~=e~
I AUDIO :;:
'..:::.u.- .......... ; ..... ~ J
~
SERVICE
ONLY
You will need:
•coaxial cables
•S-video cable
-For betterpicture performance, if your VCR
has S-video, use an S-video cable (plus the
audio cables) instead
of the standard video
cable.
00 not connect both types of video
cable to
VIDEO 1 at the same time or the
picture performance will be unacceptable.
-For betterpicture performance,
if your
camcorder has S-video, connect an S-video
cable (plus the audio cables)
to VIDEO 1on
the
TV back side instead of the VIDEO 2on
the
TV side panel.
-Ifyou have amono
VCR, connect UMaNa
on the TV to your VCR's audio out terminal
using the white audio cable only
•S-video cable (if your VCR or camcorder has S-video)
00 not connect both types of video cable
to VIDEO 1at the same time or the picture
performance will be unacceptable.
•standard audio cables (If you have amono VCR or
camcorder has S-video)
Note: When you use a Cable box, you may not
be able to use the remote control to program or
access certain features on the TV.
To view the antenna or Cable signal:
Select the ANTICABLE video input source on the TV. *
To view basic and premium Cable channels:
Turn OFF the VCR. Select the ANTICABLE video
input source on the
TV. *Tune the TV to channel 3or
4(whichever channel the Cable box output is set to).
Use the Cable box controls to change channels.
To view the VCR:
Turn ON the VCR. Select the VIDEO 1video input
source on the
TV. *
To view the camcorder video:
Select the VIDEO 2video input source on the TV. *
* To select the video input source, press INPUT on
the remote control (1rW page 21). To program the
TV remote control to operate other devices, see
Chapter
3.
The unauthorized recording, use, distribution, or
revision of television programs, videotapes, DVDs,
and other materials is prohibited under the Copyright
Laws of the United States and other countries, and may
subject you to civil and criminal liability.
I 14

Connecting a DVD player with ColorStream® (component video), a VCR,
and a satellite receiver
Your TV has two sets of ColorStream® (component video) inputs.
Satellite receiver with component video
...--- 3E>>-+-----I---.;~-----------
L..... __ ...I
You will need:
•coaxial cables
•standard
NV cables
-For better picture performance, if your VCR
has S-video, use an S-video cable (plus the
audio cables) instead
of the standard video
cable.
00 not connect both types of video
cable to VIDEO 1 at the same time or the
picture performance will be unacceptable.
-
If you have amono VCR, connect UMaNa
on the TV to your VCR's audio out terminal
using the white audio
cable only
•standard audio cables
•
component video cables
- You can connect the component video cables
(plus audio cables) from the
OVO player or
satellite receiver to either set of ColorStream
terminals on the TV (HD-1 or HD-2). The
ColorStream HD-1 and HD-2 terminals
can
be used with Progressive (480p, 720p)
and Interlaced (480i, 1080i) scan systems.
A1080i signal will provide the
best picture
performance (1080p is notsupported).
-
If your OVO player or satellite receiver does
not have component video, connect a
standard AN cable to VIDEO 2on the side
panel.
If your OVO player has HOMI video,
see
page 16.
To view antenna or Cable channels:
Select the ANT/CABLE video input source on the TV.*
To view the DVD player:
Turn ON the DVD player. Select the ColorStream
HD-1 video input source on the TV.*
To view satellite programs using the
component video connections:
Turn on the satellite receiver. Select the ColorStream
HD-2 video input source on the TV.*
To view the VCR or view and record
antenna channels:
Turn ON the VCR. Tune the VCR to the channel you want
to watch. Select the VIDEO 1video input source on the TV. *
To record a TV program while watching a DVD:
Turn ON the VCR. Tune the VCR to the channel to
record. Select the
ColorStream HD-1 video input source
on the TV* to view the DVD.
* To select the video input source, press INPUT on
the remote control (1& page 21). To program the
TV remote control to operate other devices, see
Chapter
3.
The unauthorized recording, use, distribution, or
revision of television programs, videotapes, DVDs,
and other materials is prohibited under the Copyright
Laws of the United States and other countries, and may
subject you to civil and criminal liability.
15 I

Connecting an HDMITM or DVI
device to the HDMI input
The HDMI input on your TV receives digital audio
and uncompressed digital video from an HDMI
source device, or uncompressed digital video from a
DVI (Digital Visual Interface) source device.
This input is designed to accept HDCP (High-
Bandwidth Digital-Content Protection) program
material in digital form from EIA/CEA-861-D-
compliant[ll consumer electronic devices (such as
aset-top box or DVD player with HDMI or DVI
output).
The HDMI input can accept and display VGA,
SVGA, XGA, WXGA, SXGA, 480i (60Hz), 480p
(60Hz),
nop (60Hz), 1080i (60Hz) and I080p
(24Hz/60Hz) signal formats. For detailed signal
specifications, see page 59.
Supported Audio format: Linear PCM, sampling rate
32/44.11 48 kHz
Note: To connect a PC to the HOMI input, see page 19.
To connect an HDMI device, you will need:
• one HDMI cable (type Aconnector) per HDMI device
- For proper operation, it is recommended that
you use an HOMI cable with the HOMI Logo (
HOml).
- To display an 1080i/60Hz signal format, you
will need aCategory 2cable. Conventional
HOM I/O VI cable may not work properly
-
HOMI cable transfers both video and audio.
Separate analog audio cables
are not
required
(see illustration).
-
See "Setting the HOMITM audio mode"
(1& page 34).
To view the HDMI device video:
Select the HDMI 1, HDMI 2or HDMI 3video input
source on the
TV. *
* To select the video input source, press INPUT on
the remote control (~ page 21). To program the
TV remote control to operate other devices, see
Chapter
3.
16
To connect aDVI device, you will need:
•one HDMI-to-DVI adapter cable (HDMI type A
connector) per DVI device
- For proper operation, the length of an HOMI-
to-OVI adapter cable should not exceed 9.8 ft
(3m). The recommended length is 6.6 ft (2m).
•one pair of standard analog audio cables per DVI
device
- An HOMI-to-OVI adapter cable transfers
video only Separate analog audio cables
are required (see illustration).
-
See "Setting the HOMfT
Maudio mode"
(1& page 32).
TV back panel
I
-~ I
HDmI
, 2 3 rn'JlJl)I--~
~ e BJ i
v@T@ '€~:·:m~ PC~
"IQ\;IQ\. ~ 1 fr(-~
~IW 10~\
'.@',@
rr:\~ &:\ [Q] ~
wr~ w· """ ..
~@!@ r@ '@
.@ @
Note: To ensure that the HOMI or OVI device is reset
properly it is recommended that you follow these
procedures:
• When turning on your electronic components,
turn on the TV first, and then the HOMlor
OVI device.
•
When turning offyour electronic components,
turn off the HDMI or DVI device first, and
then the TV.
[1] EIA/CEA-861-D compliance covers the
transmission of uncompressed digital video
with high-bandwidth digital content protection,
which is being standardized for reception of
high-definition video signals. Because this is
an evolving technology, it is possible that some
devices may not operate properly with the TV.
HDMI, the HOMIIogo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.

REGZA-LINK@) connection
You can control the basic functions of connected audio/video devices using the TV's remote control if you
connect aREGZA-LINK compatible audio receiver or playback device. For an explanation
of setup and
operations, see pages 51.
TV back panel
,---- HDMIIN -----,
Hi:Jml
2 3
Playback device
(REGZA-L1NK DVD player,etc.)
Playback device
(REGZA-L1NK HD DVD player,etc.)
~;;~g4' -8'-]
,~" -' . .' II ill ill
To connect an Audio Receiver and Playback
Devices, you will need:
•HDMI cables (1& page 16)
Note:
• If several devices are connected, REGZA-LINK
feature may not operate properly.
•For proper operation, it
is recommended that you
use HDMI cables with the HDMI Logo
(HOm. ).
Before controlling the device(s):
•After completing the above connections, set the
REGZA-liNK Setup menu as you desire (1& page
51).
•The connected devices must also be set. For
details, see the operation manual for each device.
•The REGZA-LINK feature uses the CEC
technology
as regulated by the HDMI standard.
•This feature is limited to models incorporating
Toshiba's REGZA-LINK. However, Toshiba is not
liable for those operations. Refer
to the individual
instruction manuals for compatibility information.
Note: This feature may not work properly
depending on the devices that are connected.
17 I

You will need:
Connecting a digital audio system
You will need:
•standard audio cables
standard optical out signals may not work
properly, creating ahigh noise level that
may damage speakers or headphones
THIS DAMAGE IS NOT COVERED BY YOUR
WARRANTY
•
The DIGITAL AUDIO OUT terminal may not
output some digital audio sources because
of copy restrictions.
*Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
This connection allows you to use external speakers with
an external analog audio amplitier to adjust the sound level.
Connecting an audio system
[i
..
L.INiJ'N Cj;;;;;:'"
L R AlJd'o IN
@ .. @. [Q]
.V;Io
o
o
•optical audio cable (Use an optical audio cable
that has the larger "TosLink" connector and not
the smaller "mini-optical" connector.)
Dolby Digital decoder or
other digital audio system
The TV's DIGITAL AUDIO OUT terminal outputs a
Dolby'()o1' DigitallIlD"?,,~?~ or 2-channel down-mixed
peM (pulse-code modulation) signal for use with
an external Dolby@ Digital decoder or other external
audio system with optical audio input.
TV back panel
o
o
Analog audio amplifier
o
o
Audio
Digital Audio Selector
TV back panel
.-@T@~.'---.- .. - .. ~, -""-"1
'@I@ ~m'"~b ©
:~I@ "fJ ,c,'-J
r@ @ @. 'c<:~.=
L"@I@;@~. 1
:OLOR COlOR T~ ~,._.L= I
ST~M SWM
MR
~ R~~L~j
To control the audio:
1 Turn on the TV and the stereo amplifier.
2 Set up aoptimum volume level of the stereo amplifier.
Then you can adjust the sound volume level from the
TV's volume control or the amplifier's volume control.
3 Menu item of Speakers can turn to OFF to mute the
TV's built in speakers.
No
Auto
Stereo
PC Audio
HDMI 1Audio
MTS
Audio Setup
4 In the Optical Output Format field. select either Dolby
Digital or PCM, depending on your device (1l;;,"Selecting
the optical audio output format" on page 44).
DIGITAL
AUDIO OUT
Audio
Digital Audio Selector
Audio Settings
Advanced Audio Settings
To control the audio:
1 Turn on the TV and the digital audio device.
2MENU ,I I I
Press 0 on the TV s remote contro anl open t le
Audio menu.
3 Highlight Audio Setup and press @.
English Advanced Audio
Audio Setup
Dolby Digital
Dynamic Range Control Compressed
Note:
•Some audio systems may not be compatible
with Dolby Digital bitstream signals Older
audio systems that are not compatible with
Reset Done Audio
settings
Bass
Treble
Balance
Reset
10
10
o
Done
o
o
o
I 18

PC audio
cable
PC audio
output
I6
Ground II
2G7
Ground 12 SDA
3B8
Ground 13
H-sync
4·
Reserved
9
5V
14 V-sync
5
Reserved 10 Ground 15 SCL
,.--- HOMIIN --~
Homl
2 3
~Jl ~ a c:l2 II~I ----1IIIIllIl
The HDMI input can accept and display VGA, SVGA,
XGA, WXGA, SXGA, 480i (60Hz), 480p (60Hz), nop
(60Hz), I080i (60Hz), and I080p (24Hz/60Hz) signal
formats. For detailed signal specifications, see page 59.
Note:
• The edges of the images may be hidden.
• If receiving a 480i (HOM!), 480p (HoMI), 720p,
1080i, or 1080p signal program, Native mode
scales the video to display the entire picture within
the borders of the screen (i.e. no overscanning).
To connect a PC to the HDMI terminal on the TV:
When connecting aPC to the HDMI terminal on the
TV, use an HDMI-to DVI adapter cable and analog
audio cables.
If connecting aPC with an HDMI terminal, use an
HDMI cable (type Aconnector). Separate analog
cables are not necessary
(~page 15).
TV back panel
PC audio
output
Conversion adapter
(if necessary)
• To use a PC, set the monitor output resolution on the
PC before connecting it to the TV. The PC IN terminal
can accept and display VGA, SVGA, XGA, WXGA and
SXGA signal formats. For detailed signal specifications
(1& page 59).
Other formats or non-standard signals will not be
displayed correctly.
• To display the optimum picture, use the PC setting
feature (1& "Using the PC settings feature" on page 48).
Note:
• The PC audio input terminals on the TV are shared
with the HOMI-1 analog audio input terminals (1&
page 48).
• Some PC models cannot be connected to this TV
• An adapter is not needed for computers with a
compatible mini O-sub 15-pin terminal.
•Depending on the OVO'S title and the
specifications of the PC on which you are playing
the OVO-Video, some scenes may be skipped or
you may not be able to pause during multi-angle
scenes.
To connect a PC to the PC IN terminal on the TV:
When connecting a PC to the PC IN terminal on the TV, use
an analog RGB (15-pin) computer cable and a PC audio cable.
TV back panel
"':;';'I':l
1 2 3
~ ~ t3
:=-W-=;~==w', '
y@T@.~--=l
~@'I@ J'(lg',b @1!~ <=1 __ ----,
~@x@ ~~
@I@-@t~_
\([?)@ ';@ [@J--] ~:~~;o
~~r@ R@ ~
With either the PC IN or HDMI connection, you can watch
your computer's display on the TV and hear the sound
from the TV's speakers.
Connecting a personal computer (PC)
19 I

Preparing the remote control for
use
Your TV remote control can operate your TV and
many other devices such as cable converter boxes,
satellite receivers, VCRs, DVD players, and HTIBs
(home theater
in abox), even if they are different
brands.
If you have a Toshiba device:
Your TV remote control is preprogrammed to operate
most Toshiba devices
(~page 24).
If you have a non· Toshiba device or a
Toshiba device that the remote control is not
preprogrammed to operate:
You can program the TV remote control so it will
operate the other device
(~pages 22-26).
Installing the remote control
batteries
1Remove the battery cover from the back of the
remote control.
• If the remote control does not operate
correctly,
or if the operating range becomes
reduced, replace batteries with newones.
•
When necessary to replace batteries in the
remote control, always replace both batteries
with newones. Never mix battery types
or use
new
and used batteries in combination.
•Always remove batteries from the remote
control if they are dead or if the remote
control
is not to be used for an extended
period of time. This will prevent battery acid
from leaking into the battery compartment.
Remote control effective range
For optimum performance, aim the remote control
directly at the TV and make sure there is no
obstruction between the remote control and the
TV.
Point remote control
toward remote sensor
on front of
TV.
Squeeze tab
and lift cover.
r
2Install two "AAA" size batteries, making sure to
match the +and -signs on the batteries to the
signs on the battery compartment.
3Reinsert the battery cover in. the remote control
until the tab snaps.
Caution: Batteries must not be exposed to
excessive heat such as sunshine, fire or the
like.
Note:
•Be sure to use AAA size batteries.
•Dispose
of batteries in adesignated disposal
area.
•Batteries should always
be disposed of with
the environment
in mind. Always dispose of
batteries in accordance with applicable laws
and regulations.
I 20
16.4 It (5m)
I
