Toshiba TRX-2000 User manual

1
TRX 22, TRX 2000, TRX 2200, TRX2220
Add a New Satellite Missing Odd or Even Channels
Fine Tune a Satellite Initial Set Up
Delete a Satellite Main Functions List
Parental Control Missing Subscription Channels
Satellite Memory Realignment Troubleshooting Guide
Add a New Satellite
1. Refer to a current Satellite Television Guide. Locate the satellite channel chart pages. This
chart shows you where the satellites are and what channels are active. Move the dish to a
programmed, known satellite nearest to the desired new satellite.
2. Turn off the Parental Control.
3. Put the receiver in Program Mode.
a. Press FUNCTION.
b. Select No 1, Customer Choice.
c. Select No. 6, Receiver Mode.
d. Select No. 2, Program.
e. Press ENTER. The receiver is now in Program Mode.
4. Turn on the Channel Scan.
a. Press FUNCTION.
b. Select No. 1, Set-Up.
c. Select No. 2, Channel Scan.
d. Select No. 1, ON.
e. Press ENTER.
5. Turn on the Auto Tune.
a. Press FUNCTION.
b. Select No. 1, Set-Up.
c. Select No. 3, Auto Tune.
d. Select No. 1, ON.
e. Press ENTER.
6. Use the EAST or WEST keys to line the dish up on the new satellite. The receiver scans the
channels, alternating polarities, until it finds a strong signal.
7. Use the Channel up and down keys to view the channels on the new satellite.
8. Be sure this is the new satellite. Refer to your satellite chart for the channel listing.
9. Press C-SAT (Ku-SAT, if a Ku satellite).
10. Enter the 2-part alphanumeric name. If a letter is not available, use “O” for Other, or any
unused name.
11. Press ENTER. The receiver automatically fine tunes the new satellite position. The “Auto-
Skew” and “Auto-ANT.” messages stop when the tuning is complete.
12. Put the receiver back in Auto Mode.
a. Press FUNCTION.
b. Select No 1, Set-Up.
c. Select No. 6, Receiver Mode.
d. Select No. 1, Auto.
e. Press ENTER. The receiver is now in Auto Mode. The new satellite can now be selected
by its two-part alphanumeric name, like other programmed satellites.
Fine Tune a Satellite

2
If you must use your East or West keys to obtain a clear picture on a certain satellite, every time
you view that satellite, it is necessary to fine tune that satellite. Perform the following steps.
TRX 22, TRX 2000, TRX 2200, TRX2220
1. Move to the satellite in question.
2. Use the EAST and WEST keys to obtain the best possible picture.
3. Follow the steps in the Add a New Satellite procedure, as if you are entering this satellite as
a new satellite.
If you must frequently fine tune a particular satellite, there may be problems with your out door
unit. Contact your local satellite dealer/installer for assistance.
Delete a Satellite
As older satellites go out of service and new satellites are launched, you may need to delete old
satellite names to make room for new ones. Perform the following steps.
1. Turn off the Parental Control.
2. Put the receiver in Program Mode. (It does not matter what satellite you are currently
watching.)
a. Press FUNCTION.
b. Select No 1, Customer Choice.
c. Select No. 6, Receiver Mode.
d. Select No. 2, Program.
e. Press ENTER. The receiver is now in Program Mode.
3. Press C-SAT (or Ku-SAT). The on screen display reads “Satellite Memory.”
4. Press CANCEL. The satellite memory list appears.
5. Use the EAST or WEST keys to scroll the arrow through the list of satellites. Move the
arrow to the satellite name you wish to delete. Be sure this is the satellite name you wish to
delete.
6. Press CANCEL. This satellite name and location are erased from the memory.
7. Put the receiver back in Auto Mode.
a. Press FUNCTION.
b. Select No 1, Customer Choice.
c. Select No. 6, Receiver Mode
d. Select No. 1, Auto.
e. Press ENTER. The receiver is now in Auto Mode. If you have no picture, move to
another satellite.
Parental Control
If you can not put the satellite receiver in Program Mode, the Parental Control may be on.
Perform the following steps to turn off the Parental Control:
1. Press FUNCTION.
2. Select No. 4, Parental Control.
3. Enter your password. If you can not remember your password, please call Customer Service.
4. Press ENTER.
5. Select No. 3, Enable/Disable.
6. Select No. 2, Disable.
7. Press ENTER. Parental lock is now off.
After performing the desired programming, you may wish to re-enable the Parental Control. Put
the receiver back in Auto mode and repeat the above process, selecting “No. 1, Enable” at step 6.

3
TRX 22, TRX 2000, TRX 2200, TRX2220
Satellite Memory Realignment
If all satellites are misaligned in the same direction and by the same amount, the dish has most
likely been shifted by high winds or other force. This function allows you to realign your dish to
match the already stored satellite positions without having to reprogram or fine tune all of the
satellites individually.
Use this function ONLY if all of your satellites are misaligned in the same direction (east or
west) and by the same amount.
1. Call up or move to a satellite you are familiar with.
2. Choose a known active channel on that satellite. Use a channel easy for you to identify,
though the picture may be poor or missing.
3. Press FUNCTION.
4. Select No. 3, Change Program.
5. Select No. 4, Realign Sat. Memory. The name of the satellite and the channel is displayed.
Verify these are what you chose in steps 1 and 2.
6. Use the EAST and WEST keys to obtain a good, clear picture that matches the satellite and
channel you chose.
7. If this is the correct satellite and channel, press ENTER. The entire satellite memory has
been realigned to your dish.
8. Call up other satellites and verify they are aligned correctly. Repeat the above steps, if
necessary.
If you must frequently realign the satellite memory, there may be problems with your out door
unit. Contact your local satellite dealer/installer for assistance.
Missing Odd or Even Channels
If you are missing the odd or even known active channels on any or all satellites, perform the
following steps.
1. Move to the satellite with missing channels. Select the missing channel.
a. If the picture is black, the problem may be a missing subscription channel. Refer to the
“Missing Subscription Channel” flowchart near the end of this booklet.
b. If the picture is scrambled or very snowy, continue with step 2.
2. Turn off the Parental Control.
3. Check the Receiver’s Input Mode.
a. Put the receiver in Program Mode.
1) Press FUNCTION.
2) Select No. 1, Customer Choice.
3) Select No. 6, Receiver Mode.
4) Select No. 2, Program.
5) Press ENTER. The receiver is now in Program Mode.
b. Press FUNCTION.
c. Select No. 1, Set-Up.
d. Select No. 2, Channel Scan.
e. Select No. 2, OFF.
f. Press ENTER.
g. Press FUNCTION
h. Select No. 1, Set-Up.
i. Select No. 5, Input Mode.
j. Verify the input mode is “C/Ku.”

4
TRX 22, TRX 2000, TRX 2200, TRX2220
k. If not, Press No. 1, Then the ENTER key to change the input mode to “C/Ku.”
l. Go through the channels.
m. If this solved the problem, put the receiver back in Auto Mode, and you are done. To put
the receiver in Auto Mode.
1) Press FUNCTION.
2) Select No. 1, Set-Up.
3) Select No. 6, Receiver Mode.
4) Select No. 1, Auto.
5) Press ENTER. The receiver is now in Auto Mode.
n. If this did NOT solve the problem, change the Input Mode back to what it was. Put the
receiver back in Auto Mode, and proceed to step 4. (To put the receiver in Auto Mode,
follow the instructions in step 3.m.)
4. Perform the Skew Adjustment. Refer to page 57 of your Owner’s Manual for TRX 22 and
TRX 2220, page 48 for TRX 2200, and page 44 for TRX 2000.
a. Press FUNCTION.
b. Select No. 2, Tuning.
c. Select No. 2, Adjust Skew. Write down the current Skew Angle number. You may need
to reset this value later.
d. Use the EAST and WEST keys to run the Skew number all the way down to zero and all
the way up to 80.
e. If the picture does NOT come in clear somewhere in this range, set the skew number
back to what is was in step 4.c. Press ENTER and proceed to step 5.
f. If the picture DOES come in clear somewhere in this range, adjust the skew for the best
picture. Press ENTER.
g. Go through all the channels.
h. If all the channels are now OK, you are done. If NOT, repeat the above steps to adjust
the skew to what it was in step 4.c. Proceed to step 5.
5. Check the polarization wires. Refer to page 4 of your Owner’s Manual. At the bottom of the
page is a picture of the back panel of your receiver. Locate terminals number 24, 25, and 26.
Check the connections in these terminals. The wires are usually colored black in 24, white in
25, and red in 26. Reconnect any loose wires. Check all the channels again. If this solved
the problem, you are done. If not, proceed to step 6.
6. The problem is likely the polar rotor, at the out door unit. Contact your satellite
dealer/installer for assistance.
Initial Set Up
Initial Set Up was performed during the original system installation and should not have to be
repeated. However, if the receiver has been removed for repair or major repairs have been made
to the out door unit, the Initial Set Up should be repeated.
1. Put the Receiver in Program Mode.
a. Press FUNCTION.
b. Select No. 1, Customer Choice.
c. Select No. 6, Receiver Mode.
d. Select No. 2, Program.
e. Press ENTER. The receiver is now in Program Mode.

5
TRX 22, TRX 2000, TRX 2200, TRX2220
2. Check the Actuator wiring. Confirm that when the EAST key is pressed, the dish moves to
the east. If not, reverse the connections on M1 and M2 on the rear panel of the receiver.
Check again.
3. Set the Input Mode.
a. Press FUNCTION.
b. Select No. 1, Set-Up.
c. Select No. 5, Input Mode.
d. Select No. 1 or No. 2 to select the correct input mode for your system. The majority of
systems are No. 1, “C/Ku.” If you are not sure, contact your local satellite dealer/installer
for assistance.
e. Press ENTER.
4. Clear all data memory. CAUTION. This will clear all the receiver memory. This is
necessary only when an Initial Set Up is required.
a. Press FUNCTION.
b. Select No. 4, Installation.
c. Select No. 5, All Data Clear. (No. 4 on TRX 2200)
d. Select No. 1, Yes.
e. Press ENTER. The screen will now display, “Satellite Memory is all cleared. Move dish
to East Limit (EL). Then ENTER.”
5. Set the Antenna limits.
a. Press and hold the EAST key until the screen displays, “Error. No Return Pulse.” To
avoid possible damage to the actuator or other out door components, have an assistant
near the dish to warn you when the dish is reaching its limit.
b. Release the EAST key when the “No Return Pulse” message is displayed.
c. Press and hold the WEST key for about 1 to 2 seconds.
d. Press ENTER. The screen now displays, “Move dish to West Limit (WL). Then
ENTER.”
e. Press and hold the WEST key until the screen displays, “Error. No Return Pulse.” Have
your assistant watch the dish to avoid any damage as the dish moves towards its western
limit.
f. Release the WEST key when the “No Return Pulse” message is displayed.
g. Press and hold the EAST key for about 1 to 2 seconds.
h. Press ENTER. The antenna limits are now set.
6. Program the satellite positions. Refer to a current Satellite Television Guide. Locate the
satellite channel chart pages. This chart shows you where the satellites are and what
channels are active. Since the dish is at its West Limit, start with the furthest west satellite.
At the time this booklet was written, that was Satcom C1 (F1).
a. Turn on the Channel Scan and the Auto Tune.
1) Press FUNCTION.
2) Select No. 1, Set-Up.
3) Select No. 2, Channel Scan.
4) Select No. 1, ON.
5) Press ENTER.

6
TRX 22, TRX 2000, TRX 2200, TRX2220
6) Press FUNCTION.
7) Select No. 1, Set-Up.
8) Select No. 3, Auto Tuning.
9) Select No. 1, ON.
10)Press ENTER.
b. Press and hold the EAST key for 2 to 3 seconds. Allow the receiver to scan through the
channels. The channel scanning will stop on a strong video signal. Press and hold the
EAST key for another 2 to 3 seconds. Allow the receiver time to scan through all the
channels again. Repeat short east moves until the receiver locks on a channel. The
picture may be snowy or scrambled.
c. Use the Channel UP or DOWN keys to view other channels. The receiver may start
scanning again. Wait until it stops scanning. Identify any active channel on this first
satellite. You may need to use the EAST or WEST keys a little to get a clear enough
picture.
d. When you are sure this is the desired satellite, press the C-SAT key (Ku-SAT, if a Ku
satellite), followed by the alphanumeric name. (In this example, Satcom C1 can be called
C 1 or F 1.)
e. Press ENTER. The receiver automatically fine tunes the new satellite position. The
“Auto-Skew” and “Auto-ANT.” messages flash on screen. The flashing stops when the
process is complete.
f. Repeat steps 6.b through 6.e for each satellite in turn, moving eastward, until you have
entered all the desired satellites. When the last satellite has been entered, the receiver
must be put back in Auto Mode.
g. Press FUNCTION.
h. Select No. 1, Set-Up.
i. Select No. 6, Receiver Mode.
j. Select No. 1, Auto.
k. Press ENTER. The receiver is now in Auto Mode. Any of the programmed satellites
may be called by pressing the “C-SAT” key (Ku-SAT, if a Ku satellite), followed by the
2 digit satellite name.

7
TRX 22, TRX 2000, TRX 2200, TRX2220
Main Functions List
AUTO MODE PROGRAM MODE
1. CUSTOMER CHOICE
1.1 Beep
1.2 Basic OSD
1.3 Antenna Move Blank
1.4 Audio Level Indicator
1.5 Skip Tuning
1.6 Receiver Mode
1. SET UP
1.1 Beep
1.2 Channel Scan
1.3 Auto Tuning
1.4 Signal Bar Shift
1.5 Input Mode
1.6 Receiver Mode
2. TUNING
2.1 Change Polarity
2.2 Adjust Skew
2.3 TI Filter & Channel Fine Tuning
2.4 Channel Skip
2. TUNING
2.1 Change Polarity
2.2 Adjust Skew
2.3 TI Filter & Channel Fine Tuning
3. CHANGE PROGRAM
3.1 Audio Program
3.2 Category Selection
3.3 Favorite Program
3.4 Realign Satellite Memory
3. CHANGE PROGRAM
3.1 Audio Program
3.2 Category Selection
3.3 Antenna Limit
4. PARENTAL CONTROL
4.1 Antenna Lock
4.2 Channel Lockout
4.3 PL Enable/Disable
4.4 Change Password
4. INSTALLATION
4.1 Ku-Sat Format
4.2 Calibrate Ku Channel
4.3 Rem Noise Sensor (Not on TRX 2200)
4.4 All Satellites Clear
4.5 All Data Clear
To access any of the functions, put the receiver into the desired mode (Auto or Program), then
press the FUNCTION key. If you can not access the Program Mode, you must disable the
Parental Control.

8
MISSING SUBSCRIPTION CHANNELS, 1
IS THE PICTURE BLACK
OR
SNOW / SCRAMBLED
?
BLACK
SNOW OR
SCRAMBLED
PRESS SETUP KEY,THEN
1, AND 1 AGAIN.
IS THE INSTALLATION
DATA ON SCREEN
?
NO
PRESS TV / SAT KEY,
IF EQUIPPED.
IS INSTALLATION DATA
ON SCREEN NOW
?
IS THE "SIGNAL QUALITY"
HIGHER OR LOWER
THAN 85
?
YES
YES
RESET THE RECEIVER;
UNPLUG THE AC POWER
CORD. WAIT 30
SECONDS AND PLUG IT
BACK IN. CHECK THE
MISSING CHANNEL.
IS THE PICTURE GOOD
NOW
?
NO
HIGHER LOWER
FOLLOW THE "FINE TUNE
A SATELLITE"
INSTRUCTIONS FOR
YOUR MODEL. CHECK
THE MISSING CHANNEL.
IS THE PICTURE GOOD
NOW
?
NO
YES
CALL YOUR
PROGRAMMER. ASK FOR
A "RE-HIT". WAIT THE
RECOMMENDED TIME.
IS THE PICTURE GOOD
NOW
?
NO
YES
NO
YES
Go to
next
page
A
TUNE TO THE
MISSING CHANNEL.
START HERE.
DONE
CONTACT YOUR
SATELLITE DEALER/
INSTALLER.

9
SNOW OR
SCRAMBLED
CHANGE TO A KNOWN
ACTIVE FREE CHANNEL
ON THIS SATELLITE.
IS THE PICTURE GOOD
OR SNOW / SCRAMBLED
?
GOOD
IS THIS AN EVEN OR AN
ODD NUMBERED
CHANNEL
?
ODD
EVEN
CHANGE TO AN EVEN
NUMBERED FREE
CHANNEL. IS THE
PICTURE GOOD
?
CHANGE TO AN ODD
NUMBERED FREE
CHANNEL. IS THE
PICTURE GOOD
?
YES
A
From
previous
page
SNOW OR
SCRAMBLED
RESET THE RECEIVER;
UNPLUG THE AC POWER
CORD. WAIT 30
SECONDS AND PLUG IT
BACK IN. CHECK THE
MISSING CHANNEL.
IS THE PICTURE GOOD
NOW
?
YES
FOLLOW THE "FINE TUNE
A SATELLITE"
INSTRUCTIONS FOR
YOUR MODEL. CHECK
THE MISSING CHANNEL.
IS THE PICTURE GOOD
NOW
?
NO
NO
NO
YES
Go to
next
page
B
MISSING SUBSCRIPTION CHANNELS, 2
C
From next
page
YES
FOLLOW THE "MISSING
ODD OR EVEN
CHANNELS"
INSTRUCTIONS FOR
YOUR MODEL. CHECK
THE MISSING CHANNEL.
IS THE PICTURE GOOD
NOW
?NO
YES
NO
CONTACT YOUR
SATELLITE DEALER/
INSTALLER.
DONE

10
MISSING SUBSCRIPTION CHANNELS, 3
B
From
previous
page
SNOW OR
SCRAMBLED
CHECK ALL CHANNELS
ON THIS SATELLITE.
ARE ONLY SOME
CHANNELS OR ARE ALL
CHANNELS SNOW /
SCRAMBLED
?
ALL
CHECK OTHER
SATELLITES. ARE ALL
SATELLITES SNOW /
SCRAMBLED, OR IS THIS
THE ONLY ONE
?
FOLLOW THE
INSTRUCTIONS FOR
"SATELLITE MEMORY
REALIGNMENT" FOR
YOUR MODEL. CHECK
THE MISSING CHANNEL.
IS THE PICTURE GOOD
NOW
?
ALL
ONLY THIS
ONE
FOLLOW THE "FINE TUNE
A SATELLITE"
INSTRUCTIONS FOR
YOUR MODEL. CHECK
THE MISSING CHANNEL.
IS THE PICTURE GOOD
NOW
?
YES
NO
YES
NO
SOME
Go to
previous
page
C
TUNE TO A
GOOD CHANNEL
DONE
CONTACT YOUR
SATELLITE DEALER/
INSTALLER.

11
QUICK REFERENCE TROUBLESHOOTING GUIDE
Problem: Missing pay channels or missing any channel.
Solution: See the "Missing Subscription Channels" flow chart.
Problem: Strange computer type graphics appear on all pay channels, resulting in no
video or audio.
Solution: Reset the receiver. Unplug the AC power cord, wait 30 seconds , and plug it back
in.
Problem: Cannot access setup menu for VideoCipher module.
Solution: See the "Missing Subscription Channels" flow chart.
Problem: Cannot authorize VideoCipher module for Pay Per View (PPV).
Solution: Check signal quality on that channel. Check telephone jack and cable by
connecting a regular telephone. If these are OK, do a receiver reset and try again
to authorize.
Problem: Forgot your ratings ceiling or purchase passwords.
Solution: Call your program provider or the Satellite Video Center at 1-800-54-VIDEO.
Problem: Cannot put the receiver in Program Mode.
Solution: Confirm the Parental Control is off. See the "Parental Control" instructions for
your model receiver.
Problem: Forgot your receiver's parental control password.
Solution: Call our Customer Service at 1-800-631-3811.
Problem: The receiver will not accept any new satellite names.
Solution: The receiver's memory may be full. Push the "C-SAT" key two times to see a list
of programmed satellites. Delete some old or unwanted satellite names. See
"Delete A Satellite" instructions for your model receiver.
Problem: Unusual operation and loss of function control.
Solution: Reset the receiver. Unplug the AC power cord, wait 30 seconds, and plug it back
in.
Problem: The receiver is responding poorly or intermittently to your UHF controls.
Solution: See the "Troubleshooting The UHF Remote Control" on the next page.
See your Owner's Manual for additional troubleshooting hints.
If the tips in this operations and troubleshooting video and booklet do not help solve your
problem, please consult your local satellite Dealer/Installer. Look in your local telephone
directory under SATELLITE, or call the C Band Industry Group at:
1-877-CBANDTV (1-877-222-6388)
for assistance in locating your nearest C band Satellite Dealer/Installer.

12
TROUBLESHOOTING THE UHF REMOTE CONTROL
If you are experiencing problems with poor range or intermittent operation of your UHF remote
control, try the following steps.
1. Put new batteries in the remote control.
2. Check that the UHF antenna is securely fitted on the remote sensor connector on the back
panel of the satellite receiver.
3. Check for possible UHF noise or interference in the your receiver's environment. Do a
Remote Sensor test. The steps are different for each model receiver. Refer to your
owner's manual.
4. If this test indicates interfering noise is present, try the following remedies.
A. While watching the Remote Noise display, unplug surrounding equipment, one
piece at a time. If the noise suddenly disappears when a certain piece of
equipment is unplugged, you have located the offending source of the
interference.
B. Relocate the offending noise source or relocate the Receiver's UHF antenna.
C. To relocate the antenna, connect a short piece of coaxial cable to the remote
sensor connector on the receiver back panel. Connect the antenna to the other end
of this cable. You may need a barrel connector. Move the antenna to various
locations, while watching the Remote Noise display.
D. Permanently mount the antenna in the best location.
5. Put the receiver back in AUTO MODE when you are finished.
For help locating your nearest Satellite Dealer/Installer, the C Band Industry Group may be able
to help you. Call toll free at 1-877-CBANDTV (1-877-222-6388) or visit their web site at
www. cbandtv.com.
For Toshiba America Consumer Products Customer Service Center, call 1-800-631-3811.
Visit our web site at www.toshiba.com.
