SERVICE MANUAL
FILE NO. 050-200127
29VH14P
PRINTED IN U. K
COLOUR TELEVISION

1. Precautions
1-1 Safety Precautions
1. Be sure that all of the built-in protective
devices are replaced. Restore any missing
protective shields.
2. When reinstalling the chassis and its
assemblies, be sure to restore all protective
devices, including: nonmetallic control knobs
and compartment covers.
3. Make sure that there are no cabinet openings
through which people—particularly
children—might insert fingers and contact
dangerous voltages. Such openings include
the spacing between the picture tube and the
cabinet mask, excessively wide cabinet
ventilation slots, and improperly fitted back
covers.
If the measured resistance is less than 1.0
megohm or greater than 5.2 megohms, an
abnormality exists that must be corrected
before the unit is returned to the customer.
4. Leakage Current Hot Check (Figure 1-1):
Warning: Do not use an isolation
transformer during this test. Use a leakage-
current tester or a metering system that
complies with American National Standards
Institute (ANIS C101.1, Leakage Current for
Appliances), and Underwriters Laboratories
(UL Publication UL1410, 59.7).
5. With the unit completely reassembled, plug
the AC line cord directly into the power
outlet. With the unit’s AC switch first in the
ON position and then OFF, measure the
current between a known earth ground (metal
water pipe, conduit, etc.) and all exposed
metal parts, including: antennas, handle
brackets, metal cabinets, screwheads and
control shafts. The current measured should
not exceed 0.5 milliamp. Reverse the power-
plug prongs in the AC outlet and repeat the
test.
Fig. 1-1 AC Leakage Test
6. Antenna Cold Check:
With the unit’s AC plug disconnected from the
AC source, connect an electrical jumper across
the two AC prongs. Connect one lead of the
ohmmeter to an AC prong. Connect the other
lead to the coaxial connector.
7. X-ray Limits:
The picture tube is especially designed to
prohibit X-ray emissions. To ensure continued
X-ray protection, replace the picture tube only
with one that is the same type as the original.
Carefully reinstall the picture tube shields and
mounting hardware; these also provide X-ray
protection.
8. High Voltage Limits:
High voltage must be measured each time
servicing is done on the B+, horizontal
deflection or high voltage circuits.
Correct operation of the X-ray protection
circuits must be reconfirmed whenever they
are serviced.
(X-ray protection circuits also may be called
“horizontal disable” or “hold-down”.)
Heed the high voltage limits. These include
the X–ray Protection Specifications Label, and
the Product Safety and X-ray Warning Note on
the service data schematic.
Precautions
1-1
LEAKAGE
CURRENT
TESTER
DEVICE
UNDER
TEST TEST ALL
EXPOSED METAL
SURFACES
3-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED) EARTH
GROUND
(READING SHOULD
NOT BE ABOVE
0.5mA)
Follow these safety, servicing and ESD precautions to prevent damage and protect against potential
hazards such as electrical shock and X-rays.

1-1 Safety Precautions (Continued)
9. High voltage is maintained within specified
limits by close-tolerance, safety-related
components and adjustments. If the high
voltage exceeds the specified limits, check
each of the special components.
10. Design Alteration Warning:
Never alter or add to the mechanical or
electrical design of this unit. Example: Do not
add auxiliary audio or video connectors. Such
alterations might create a safety hazard. Also,
any design changes or additions will void the
manufacturer’s warranty.
11. Hot Chassis Warning:
Some TV receiver chassis are electrically
connected directly to one conductor of the AC
power cord. If an isolation transformer is not
used, these units may be safely serviced only
if the AC power plug is inserted so that the
chassis is connected to the ground side of the
AC source.
To confirm that the AC power plug is inserted
correctly, do the following: Using an AC
voltmeter, measure the voltage between the
chassis and a known earth ground. If the
reading is greater than 1.0V, remove the AC
power plug, reverse its polarity and reinsert.
Re-measure the voltage between the chassis
and ground.
12. Some TV chassis are designed to operate with
85 volts AC between chassis and ground,
regardless of the AC plug polarity. These units
can be safely serviced only if an isolation
transformer inserted between the receiver and
the power source.
13. Some TV chassis have a secondary ground
system in addition to the main chassis ground.
This secondary ground system is not
isolated from the AC power line. The two
ground systems are electrically separated by
insulating material that must not be defeated
or altered.
14. Components, parts and wiring that appear to
have overheated or that are otherwise
damaged should be replaced with parts that
meet the original specifications. Always
determine the cause of damage or
overheating, and correct any potential
hazards.
15. Observe the original lead dress, especially
near the following areas: Antenna wiring,
sharp edges, and especially the AC and high
voltage power supplies. Always inspect for
pinched, out-of-place, or frayed wiring. Do
not change the spacing between components
and the printed circuit board. Check the AC
power cord for damage. Make sure that leads
and components do not touch thermally hot
parts.
16. Picture Tube Implosion Warning:
The picture tube in this receiver employs
“integral implosion” protection. To ensure
continued implosion protection, make sure
that the replacement picture tube is the same
as the original.
17. Do not remove, install or handle the picture
tube without first putting on shatterproof
goggles equipped with side shields. Never
handle the picture tube by its neck. Some
“in-line” picture tubes are equipped with a
permanently attached deflection yoke; do not
try to remove such “permanently attached”
yokes from the picture tube.
18. Product Safety Notice:
Some electrical and mechanical parts have
special safety-related characteristics which
might not be obvious from visual inspection.
These safety features and the protection they
give might be lost if the replacement
component differs from the original—even if
the replacement is rated for higher voltage,
wattage, etc.
Components that are critical for safety are
indicated in the circuit diagram by shading,
( ) or ( ).
Use replacement components that have the
same ratings, especially for flame resistance
and dielectric strength specifications.
A replacement part that does not have the
same safety characteristics as the original
might create shock, fire or other hazards.
Precautions
1-2
!

1-2 Servicing Precautions
1. Servicing precautions are printed on the
cabinet. Follow them.
2. Always unplug the unit’s AC power cord from
the AC power source before attempting to:
(a) Remove or reinstall any component or
assembly, (b) Disconnect an electrical plug or
connector, (c) Connect a test component in
parallel with an electrolytic capacitor.
3. Some components are raised above the printed
circuit board for safety. An insulation tube or
tape is sometimes used. The internal wiring is
sometimes clamped to prevent contact with
thermally hot components. Reinstall all such
elements to their original position.
4. After servicing, always check that the screws,
components and wiring have been correctly
reinstalled. Make sure that the portion around
the serviced part has not been damaged.
5. Check the insulation between the blades of the
AC plug and accessible conductive parts
(examples: metal panels, input terminals and
earphone jacks).
6. Insulation Checking Procedure: Disconnect the
power cord from the AC source and turn the
power switch ON. Connect an insulation
resistance meter (500V) to the blades of the AC
plug.
The insulation resistance between each blade
of the AC plug and accessible conductive parts
(see above) should be greater than 1 megohm.
7. Never defeat any of the B+ voltage interlocks.
Do not apply AC power to the unit (or any of
its assemblies) unless all solid-state heat sinks
are correctly installed.
8. Always connect a test instrument’s ground
lead to the instrument chassis ground before
connecting the positive lead; always remove
the instrument’s ground lead last.
Precautions
1-3
Warning1: First read the “Safety Precautions” section of this manual. If some unforeseen circumstance creates a conflict between
the servicing and safety precautions, always follow the safety precautions.
Warning2: An electrolytic capacitor installed with the wrong polarity might explode.

1. Some semiconductor (“solid state”) devices
are easily damaged by static electricity. Such
components are called Electrostatically
Sensitive Devices (ESDs); examples include
integrated circuits and some field-effect
transistors. The following techniques will
reduce the occurrence of component damage
caused by static electricity.
2. Immediately before handling any semicon
ductor components or assemblies, drain the
electrostatic charge from your body by
touching a known earth ground. Alternatively,
wear a discharging wrist-strap device. (Be
sure to remove it prior to applying power—
this is an electric shock precaution.)
3. After removing an ESD-equipped assembly,
place it on a conductive surface such as
aluminum foil to prevent accumulation of
electrostatic charge.
4. Do not use freon-propelled chemicals. These
can generate electrical charges that damage
ESDs.
5. Use only a grounded-tip soldering iron when
soldering or unsoldering ESDs.
6. Use only an anti-static solder removal device.
Many solder removal devices are not rated as
“anti-static”; these can accumulate sufficient
electrical charge to damage ESDs.
7. Do not remove a replacement ESD from its
protective package until you are ready to
install it. Most replacement ESDs are
packaged with leads that are electrically
shorted together by conductive foam,
aluminum foil or other conductive materials.
8. Immediately before removing the protective
material from the leads of a replacement ESD,
touch the protective material to the chassis or
circuit assembly into which the device will be
installed.
9. Minimize body motions when handling
unpackaged replacement ESDs. Motions such
as brushing clothes together, or lifting a foot
from a carpeted floor can generate enough
static electricity to damage an ESD.
Precautions
1-4
1-3 Precautions for Electrostatically Sensitive Devices (ESDs)

Reference Information
2-1
2. Reference Information
2-1 Tables of Abbreviations and Acronyms
A
Ah
Å
dB
dBm
°C
°F
°K
F
G
GHz
g
H
Hz
h
ips
kWh
kg
kHz
kΩ
km
km/h
kV
kVA
kW
I
MHz
Ampere
Ampere-hour
Angstrom
Decibel
Decibel Referenced to One
Milliwatt
Degree Celsius
Degree Fahrenheit
degree Kelvin
Farad
Gauss
Gigahertz
Gram
Henry
Hertz
Hour
Inches Per Second
Kilowatt-hour
Kilogram
Kilohertz
Kilohm
Kilometer
Kilometer Per Hour
Kilovolt
Kilovolt-ampere
Kilowatt
Liter
Megahertz
MV
MW
MΩ
m
µA
µF
µH
µm
µs
µW
mA
mg
mH
mI
mm
ms
mV
nF
Ω
pF
Ib
rpm
rps
s
V
VA
W
Wh
Megavolt
Megawatt
Megohm
Meter
Microampere
Microfarad
Microhenry
Micrometer
Microsecond
Microwatt
Milliampere
Milligram
Millihenry
Milliliter
Millimeter
Millisecond
Millivolt
Nanofarad
Ohm
Picofarad
Pound
Revolutions Per Minute
Revolutions Per Second
Second (Time)
Volt
Volt-ampere
Watt
Watt-hour
Table 2-1 Abbreviations

Reference Information
2-2
Table 2-2 Table of Acronyms
ABL
AC
ACC
AF
AFC
AFT
AGC
AM
ANSI
APC
APC
A/V
AVC
BAL
BPF
B-Y
CATV
CB
CCD
CCTV
Ch
CRT
CW
DC
DVM
EIA
ESD
ESD
FBP
FBT
FF
FM
FS
GND
G-Y
H
HF
HI-FI
IC
IC
IF
Automatic Brightness Limiter
Alternating Current
Automatic Chroma Control
Audio Frequency
Automatic Frequency Control
Automatic Fine Tuning
Automatic Gain Control
Amplitude Modulation
American National Standards Institute
Automatic Phase Control
Automatic Picture Control
Audio-Video
Automatic Volume Control
Balance
Bandpass Filter
Blue-Y
Community Antenna Television (Cable TV)
Citizens Band
Charge Coupled Device
Closed Circuit Television
Channel
Cathode Ray Tube
Continuous Wave
Direct Current
Digital Volt Meter
Electronics Industries Association
Electrostatic Discharge
Electrostatically Sensitive Device
Feedback Pulse
Flyback Transformer
Flip-Flop
Frequency Modulation
Fail Safe
Ground
Green-Y
High
High-Frequency
High Fidelity
Inductance-Capacitance
Integrated Circuit
Intermediate Frequency
I/O
L
L
LED
LF
MOSFET
MTS
NAB
NEC
NTSC
OSD
PCB
PLL
PWM
QIF
R
RC
RF
R-Y
SAP
SAW
SIF
SMPS
S/N
SW
TP
TTL
TV
UHF
UL
UV
VCD
VCO
VCXO
VHF
VIF
VR
VTR
VTVM
TR
Input/output
Left
Low
Light Emitting Diode
Low Frequency
Metal-Oxide-Semiconductor-Field-Effect-Tr
Multi-channel Television Sound
National Association of Broadcasters
National Electric Code
National Television Systems Committee
On Screen Display
Printed Circuit Board
Phase-Locked Loop
Pulse Width Modulation
Quadrature Intermediate Frequency
Right
Resistor & Capacitor
Radio Frequency
Red-Y
Second Audio Program
Surface Acoustic Wave(Filter)
Sound Intermediate Frequency
Switching Mode Power Supply
Signal/Noise
Switch
Test Point
Transistor Transistor Logic
Television
Ultra High Frequency
Underwriters Laboratories
Ultraviolet
Variable-Capacitance Diode
Voltage Controlled Oscillator
Voltage Controlled Crystal Oscillator
Very High Frequency
Video Intermediate Frequency
Variable Resistor
Video Tape Recorder
Vacuum Tube Voltmeter
Transistor

Reference Information
2-3
2-2 IC Line Up
Table 2 - 3 IC Line - Up
NO
1
DESCRIPTION
Video Processor
Sipadoss-Module, Video Processor
Multistandard Sound Processor
MICOM, TTX(MTP)
EEPROM
Audio AMP
RGB Drive AMP Hybrid IC
100Hz Horizontal Pulse AMP
Vertical IC
Horizontal Drive IC
E/W Drive IC
SPS Controllor
Bridge Diode
Photo Coupler
Rectifier Diode
3.3V Regulator
6V Regulator
8V Controlled Regulator
3.3V Regulator
MICOM Reset IC
IIC Level Shifter
LOC. NO
IC201S
IC601
IC901
IC902
IC602
HIC201
HIC202
HIC203
HIC204
HIC401
IC301
Q402
Q401
D414
IC401
Q404
IC801S
D801S
PC801S
D805
D806
D807
D802
IC202
IC804
IC803
IC903
IC904
Q909
Q910
BOARD
MAIN
SPEC
VDP3140
DDP3310
VPC3230
SDA9401
MSP3411G
SDA555X
KSL51DC
TDA7297
DRGB001
DDRI001
LA7845
BUZ73A
2SC5446
FMP-3FU
LM393
IRF620
3S1265RD
GSIB660
PC123Y
FML-G12S
FMG-G2CS
KA78RM33
KA7806
KA78R08
KA78RM33
KIA7025AP
2N7000
REMARK
Refer to Table 2-3-1
Refer to Table 2-3-2
Refer to Table 2-3-3
VM Option
Option
HC401
HC801
VDPY

2-4
Table 2 - 3 IC Line - Up
NO
1
2
3
DESCRIPTION
Main Tuner with IF Block
Trans Switching
Trans FBT(ELDOR)
Video Output AMP R.G.B Drive
Push-Pull (VM)
TR-Power (TILT)
OP-AMP (TILT)
Video Switching IC with Adder Output
LOC. NO
TU01S
T801S
T444S
IC501
QF04
QF05
QG02
QG03
ICG01
ICS01
SPEC
TCPW3001PD16A
AA26-00046A
1372, 0079A
TDA6111Q
2SC2344
2SA1011
KSA940
KSD2073-H2
KA4558
TEA6425
REMARK
Refer to Table 2-3-4
Refer to Table 2-3-6
Refer to Table 2-3-7
Option
Option
BOARD
MAIN
CRT
V-S/W
Reference Information
SPEC
MSP3411G
MSP3410D
FUNCTION
Multistandard, A2 Stereo, Nicam, Vitual Dolby
Multistandard, A2 Stereo, Nicam
REMARK
SPEC
TDA7297
FUNCTION
15W x 2CH, 10W x 2CH
REMARK
SPEC
TCPW3001PD16A
FUNCTION
CW
REMARK
Main
Table 2-3-2 SOUND IC (IC601)
Table 2-3-3 SOUND AMP (IC602)
Table 2-3-4 1’st TUNER (TU01S)
SPEC
DDP3310
VPC3230
SDA9401
FUNCTION
Sipadoss Module
AA98-00134B(with SDA9401)
REMARK
Table 2-3-1 VIDEO IC (IC201S)

Specifications
3-1
3. Specifications
Specifications are subject to change.
Television
System
Antena Input
CW
Power
Consumption
Requirements
Frequency
Output
Sound Effect
Jacks
Front
(AV2)
Back
PAL/SECAM-B/G,D/K,L,I
130W (Applied When 29” Flat)
220V Only
50Hz
15W x 2CH
Vitual Dolby
Turbo Sound
Pseudo Stereo
RCA Input
S-VHS
Head-Phone
2Scart Input/Output
AV2 Monitor Audio Output
75ohms, Coaxial Cable
Option
Option
AV1 : Scart I/O, RGB Input,
RF Out
AV2 : Scart I/O, Monitor Out
Option

3-2
MEMO

Alignment and Adjustments
4-1
4. Alignment and Adjustments
4-1 General Alignment Instructions
1. Usually, a color TV-VCR needs only slight
touch-up adjustment upon installation. Check
the basic characteristics such as height,
horizontal and vertical sync and focus.
2. Observe the picture for good black and white
details. There should be objectionable color
shading; if color shading is present,
demagnetize, perform purity and convergence
adjustments described below.
3. Use the specified test equipment or its
equivalent.
4. Correct impedance matching is essential.
5. Avoid overload. Excessive signal from a
sweep generator might overload the front-end
of the TV. When inserting signal markers, do
not allow the marker generator to distort test
results.
6. Connect the TV only to an AC power source
with voltage and frequency as specified on the
backcover nameplate.
7. Do not attempt to connect or disconnect any
wires while the TV is turned on. Make sure
that the power cord is disconnected before
replacing any parts.
8. To protect against shock hazard, use an
isolation transformer.
4-2 Automatic Degaussing
A degaussing coil is mounted around the
picture tube, so that external degaussing after
moving the TV should be unnecessary. But
the receiver must be properly degaussed upon
installation.
The degaussing coil operates for about 1
second after the power is switched ON. If the
set is moved or turned in a different direction,
the power should be OFF for at least 10
minutes.
If the chassis or parts of the cabinet become
magnetized, poor color purity will result. If
this happens, use an external degaussing coil.
Slowly move the degaussing coil around the
faceplate of the picture tube and the sides and
front of the receiver. Slowly withdraw the coil
to a distance of about 6 feet before turning
power OFF.
If color shading persists, perform the
following Color purity and Convergence
adjustments.
4-3 High voltage Check
CAUTION : There is no high voltage adjustment
on this chassis. The B+ power supply should be
+135 volts (with full color- bar input and normal
picture level).
1. Connect a digital voltmeter to the second
anode of the picture tube.
2. Turn on the TV. Set the Brightness and
Contrast controls to minimum (zero beam
current).
3. Adjust the Brightness and contrast controls to
both extremes. Ensure that the high voltage
does not exceed 32 KV under any conditions.

Alignment and Adjustments
4-2
4-4 SCREEN Adjustment
1. Input Toshiba Pattern
2. Enter “Service Mode”.(Refer to “Service Mode”)
3. Select “G2-Adjust”.
4. Set the values as below.
5. Turn the SCREEN VR until “MRCR G B” and “MRWDG” are green and those value are about 100.
(The incorrect SCREEN Voltage may result that “MRCR G B” and “MRWDG” should be red)
When you do not have Toshiba Pattern, follow this method.
1. Set the TV on the condition that AV mode no signal(black)
2. Enter the “Menu” and set the mode to blue screen off.
3. Enter the “Service Mode”.
4. Select “ G2-Adjust”.
5. Set the values as below.
IBRM = 215
WDRV = 47
CDL = 210
COLR G B = 45
6. Turn the SCREEN VR until the value of “ MRCR G B” is about 120. Do not mind that
the “OSD” Color is red.
♦After completing G2-Adjust, follow this procedure.
!Enter the “Video Adjust 1”.
@Choose any item in menu. (ex. Select “Red Cutoff”)
#Change the value of item you select, and recover the value.
For example, when the value of “Red Cutoff” is 127, change the value to 128 and restore
the value to 127.
If you do not follow this procedure, the picture may be abnormal.
For example, when the TV set is on, the picture becames brighter gradually.
Note 1.
29 Inch
IBRM = 215
WDRV = 44 -> 47
CDL = 235 -> 210
COLR G B = 122 -> 45

Alignment and Adjustments
4-3
4-5 E2PROM (IC902) Replacement
1. When IC902 is replaced, all adjustment data revert to the initial values.
So, all adjustment values when servicing should be readjusted.
2. After IC902 is replaced, connect the AC power supply cord.
3. Turn the power switch ON.
4. In stand-by, warm up the TV for at least 10 seconds.
5. Power on the TV.
4-6 White Balance Adjustment
■ Equipment : Color-Analyzer (CA-100)
■ Input Signal : Pattern signal (Toshiba pattern)
1. Select STANDARD from the menu.
2. Input an 100% White pattern.
3. Enter the “Service Mode”. (Refer to “4-8 Service Mode”)
4. Warm up the TV set at least for 30 minutes.
5. Input a Toshiba pattern signal.
6. Enter the “Video Adjust1”.
- Adjust “Sub Contrast” so that Y (luminance) becomes 34 ft ± 3.
- Use “Red Drive” and “ Blue Drive” to adjust High-Light (x : 290, y : 300)
- Adjust “Sub Bright” so that Y (luminance) becomes 1.3ft ± 0.3.
- Use “Red Cutoff” and “Blue Cutoff” to adjust Low-Light (x : 290, y : 300).
7. Adjust CA-100 so that the final adjustment value can be fixed.
8. Use the Channel Up/Down (▲/▼) buttons to move the cursor on the adjustment modes.
9. Use the Volume +/- buttons to change the adjustment value.

Alignment and Adjustments
4-4
Note 2. 29V1 CHANGE
LOC NO CODE NO SPEC LOC NO CODE NO SPEC
R226 AZ261102 1KOHM,5%,1/8W R226 AZ261471 470 OHM,5%,1/8W
J221 AZ664147 WIRE-NO SHEATH CU C203 AZ164009 C-AL;50V 10uF
J908 AZ664147 WIRE-NO SHEATH CU R944 AZ261392 3.9 KOHM,5%,1/8W
NONE NONE NONE R954 AZ261473 47 KOHM,5%,1/8W
NONE NONE NONE R910 AZ261223 22 KOHM,5%,1/8W
NONE NONE NONE R955 AZ261101 100 OHM,5%,1/8W
R910 AZ261102 1KOHM,5%,1/8W R956 AZ261471 470 OHM,5%,1/8W
R911 AZ261301 300 OHM,5%,1/8W R911 AZ261331 330 OHM,5%,1/8W
R912 AZ261301 300 OHM,5%,1/8W R912 AZ261103 10 KOHM,5%,1/8W
C923 AZ161102 C-C,AXIAL;50V 1NF L910 AZ363067 8.2uH AL02
C926 DELETE DELETE C926 AZ664147 C-C,AXIAL;150 PF
J204 AZ664147 JUMPER J204 DELETE DELETE
NONE NONE NONE J913 AZ664147 JUMPER
L210 AZ361008 AL02 3.3uH L210 AZ664147 JUMPER
J406 AZ362003 F/BEAD ,6MM J406 AZ664147 JUMPER
L222 NONE NONE L222 AZ361010 4.7uH AL02
C410 DELELTE DELETE C410 AZ162005 C-FILM,PEF;220nF,5%,250V,TP
J239 AZ664147 JUMPER J239 DELETE DELETE
J817 NONE NONE J817 AZ664147 JUMPER
L413 NONE NONE L413 AZ664147 JUMPER
J709 AZ664147 JUMPER DELETE DELETE DELETE
J701 NONE NONE J701 AZ664147 JUMPER
L412 NONE NONE L412 AZ362003 F/BEAD ,6MM
R403 AZ263070 2W 10 ohm
D403 AZ462005 DIODE 1N4004
NONE NONE NONE CN701A AZ760241 ASSY-LEAD CONNECTOR;3P
J226 DELETE DELETE J226 AZ664147 WIRE-NO SHEATH CU
J231 AZ261222 2.2KOHM,5%,1/8W J231 DELETE DELETE
R301 AZ268057 1.6KOHM,5%,1/2W R301 AZ264003 4.7Kohm,1%,1/2W
R302 AZ268058 7.5Kohm,1%,1/2W R302 AZ264007 22Kohm,1%,1/2W
R304 AZ268059 0.68ohm,5%,2W,AG R304 AZ263061 1.2ohm,5%,2W,AG
TOP DELETE DELETE R307 AZ263061 1.2ohm,5%,2W,AG
R314 AZ268048 22Kohm,1%,1/2W R314 AZ268048 22Kohm,1%,1/2W
R315 DELETE DELETE R315 AZ268041 51Kohm,1%,1/2W
C303 AZ166050 O.O15nF,5%,50V C303 AZ166032 O.O05nF,5%,500V
R926 NONE NONE R926 AZ664147 JUMPER
Q907 NONE NONE Q907 AZ561003 KSC815,NPN,400mW,TO-92,TP
R902 NONE NONE R902 AZ261102 1KOHM,5%,1/8W,AA,
R952 NONE NONE R952 AZ261103 10KOHM,5%,1/8W
J902 NONE NONE J902 AZ664147 JUMPER
R919 AZ261103 10KOHM,5%,1/8W R919 AZ261471 470 OHM,5%,1/8W
TOP AZ166023 C-C;400V 103 C830 AZ166023 C-C;400V 103 Model adapted ELDOR FBT
TOP AZ263076 2W 27 R826 AZ263076 2W 27 Model adapted ELDOR FBT
J630 NONE NONE J630 AZ664147 JUMPER Delete, If VIDEO S/W MODULE
D405 AZ462001 1N4148 D405 AZ664147 JUMPER
C415 AZ162031 POLY 50V 222 C415 AZ162031 POLY 50V 272
C416 AZ166022 POLY 100V 103 C416 AZ162012 POLY 50V 472
C411 AZ166034 POLY 50V 332 C411 AZ162031 POLY 50V 222
C212 AZ162006 POLY 50V 223 C212 AZ166022 POLY 100V 103
R241 AZ664147 JUMPER R241 AZ261680 68ohm,5%,1/8W
R242 DELETE DELETE R242 AZ261750 75ohm,5%,1/8W
L208 AZ664147 JUMPER L208 AZ363060 INDUCTOR-AXIAL;2.2uH,5%
C246 DELETE DELETE C246 AZ161271 C-C,-AXIAL;270PF,10%,50V
C247 DELETE DELETE C247 AZ161999 C-C,-AXIAL;18PF,10%,50V
C248 DELETE DELETE C248 AZ161271 C-C,-AXIAL;270PF,10%,50V
J829 AZ664147 JUMPER J829 DELETE DELETE
J830 AZ664147 JUMPER J830 DELETE DELETE
F802A DELETE DELETE F802A AZ664014 FUSE-HOLDER;-,-,30MOHM
F802B DELETE DELETE F802B AZ664014 FUSE-HOLDER;-,-,30MOHM
FD802S DELETE DELETE FD802S AZ760242 FUSE;800mA
FD802S DELETE DELETE FD802S AZ760243 FUSE;1A
LX801S AZ363064 28-20MH 1.5A,+-2.0,1.5K LX801S AZ363064 28-20MH 1.5A,+-2.0,1.5K
LX802S DELETE DELETE LX802S AZ363064 28-20MH 1.5A,+-2.0,1.5K
CX801S AZ166013 220nF,20%,250V,TP,-,22.5mm CX801S AZ166013 220nF,20%,250V,TP,-,22.5mm
CX802S AZ166013 220nF,20%,250V,TP,-,22.5mm CX802S AZ166013 220nF,20%,250V,TP,-,22.5mm
BEFORE AFTER
Against Conduction
A Improvement of TTX Error
100Hz Model
100Hz ModelV-SIZE DRIFT
Linearity
Against 2H-Noise
50Hz : 800mA
100Hz : 1 A
All Model
MODEL
A Improvement of OSD JITTER
(Added H-Sync Buffer) All Model
100Hz Model
CAUSE
AV- CROSSTALK
All Model
100Hz Model
ASSY-MAIN

Alignment and Adjustments
4-5
CAUSE MODEL
LOC NO CODE NO SPEC LOC NO CODE NO SPEC
IC201S AZ760240 Assy-sipados,SDA9401,F5 IC201S AZ760244 Assy-sipados,SDA9401,F6
IC3 AZ760222 DDP3310B-E4,PLCC,68P,-,5V,- IC3 AZ760245 DDP3310B-F6,PLCC,68P,5V, A Improvement of TTX
C29 AZ166044 0.27nF,5%,50V,NP0,TP,1608 C29 DELETE DELETE
C30 AZ166041 0.018nF,5%,50V,NP0,TP,1608 C30 AZ268050 0ohm,5%,1/16W,DA,TP,1608
C31 AZ166044 0.27nF,5%,50V,NP0,TP,1608 C31 DELETE DELETE
R8 AZ268055 75ohm,5%,1/16W,DA,TP,1608 R8 DELETE DELETE
R7 AZ268053 68ohm,5%,1/16W,DA,TP,1608 R7 AZ268050 0ohm,5%,1/16W,DA,TP,1608
L1 AZ363074 2.2uH,10%,6x4mm L1 DELETE DELETE
A Improvement of AV CROSSTALK ASSY-SIPADOSS MODULE
BEFORE AFTER
ASSY-SIPADOS(9401)
LOC PCB correction contents Remark
C242 DELETE
C410 DELETE
J220 DELETE
J221 DELETE
J231 delete only material(LOC exist)
J913 JUMPER added
C203 16V 10uF added
R944 1/8W 3.9K
R956 1/8W 470 added
R954 1/8W 47K added
R955 1/8W 100 added
C926 C-AXIAL;150P
L222 JUMPER added H-OUT LINE
J701 JUMPER added 2H-Noise
CN701A 3P WIRE OPTION(AA39-00306A) 2H-Noise (TO CN702A)
CN702 Polarit
y
chan
g
ed.(Pattern chan
g
ed
)
Against 2H-Noise
J817 JUMPER added Against 2H-Noise
J204 JUMPER added GND JUMPER
CN302 DELETE Delete if R307 add.
R307 2W 1.2ohm(AG) added Process changed(E -> V)
L910 8.2uH AL02
Delete unnecessary materials
and locations
A Improvement of TTX ERROR
Note 3. PCB CORRECTION CONTENTS

Alignment and Adjustments
4-6
4-7 Factory Adjustment
1. To enter the “Service Mode”, Press the remote-control keys in this sequence :
- If you do not have Factory remote-control
- If you have Factory remote-control
2. After the Service Mode is entered, the initial screen is as shown in the figure below.
*
Service
Deflection
Video Adjust 1
Video Adjust 2
Video Adjust 3
Option(81h 0Ch)
Reset
G2-Adjust
Others
3. Use the Channel Up/Down buttons to move the cursor in the adjustment parameters.
- When CRT, CRT PCB, FBT, E2PROM (sometimes MICOM) is replaced, the adjustment values
should be controlled.
- After the Service adjustment is completed, Do not select “Reset” in the service mode menu.
(After above procedure is done, power is on initially and the “Plug and Play” will be operated.)
PICTURE OFF PICTURE ON
DISPLAY() MENU MUTE
PICTURE ON DISPLAY() FACTORY
4-7-1 Service Mode
*These hexa digits are check sum value which
depends on the MICOM.
If check sum value is changed, the value of
E2PROM Data newly initialed.
Note 2.

Alignment and Adjustments
4-7
4-7-2 Memory Data
4-7-2(A) DEFLECTION (GEOMETRIC ADJUSTMENT VALUE)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
V Amp
V Shift
V Slope
V SC
H EW
H Trapizium
H Parabola
H Corner U
H Corner L
H Shift
BOW
Amgle
H Corner U6
H Corner L6
V Max
Zoom1 Amp
Zoom2 Amp
Zoom Trap
Zoom 4:3 Para
4:3~16:9 Para
Adjusts Vertical picture size. Adjusts 4:4 upper and lower picture size
in a lion head pattern at factory.
Adjusts Vertical picture position.
Adjusts Vertical Slope Correction.
Adjusts Vertical s-correction.
Horizontal east west width. Adjusts 5:5 left and right picture size in a
lion head pattern at factory.
Adjusts horizontal Trapezium.
Adjusts Horizontal Parabola.
Adjusts the top horizontal corner of picture.
Adjusts so that the top of H corner can be linear.
Adjusts the bottom horizontal corner of picture.
Adjusts so that the bottom of H corner can be linear.
Adjusts Horizontal Position.
Adjusts Horizontal BOW.
Adjusts Horizontal Angle.
Adjusts so that the top horizontal corner of picture can be linear.
Adjusts so that the bottom horizontal corner of picture can be linear.
Adjusts Max value of vertical amplitude
Adjusts vertical amplitude in zoom1.
SIM-806HEW only.
Adjusts horizontal Trapezium in Zoom
Corrects the vertical linearity in Zoom mode of P-SIZE.
The data depends on CRT (see data above).
Corrects the vertical linearity in 16:9 mode of P-SIZE.
The data depends on CRT (see data above).
GEOM
GEOM
FIX
FIX
GEOM
GEOM
GEOM
FIX
FIX
GEOM
GEOM
GEOM
GEOM
GEOM
FIX
FIX
FIX
FIX
FIX
FIX
98
143
125
230
193
72
75
112
138
161
128
128
140
141
200
175
202
128
125
138
No. OSD Initial Value Function Remark

Alignment and Adjustments
4-8
4-7-2(B) SCREEN CHANGE (I2C BUS GEOMETRIC ADJUSTMENT)
8
H Corner U
9 H Corner L
6H Trapizium
7 H Parabola
10 H Shift
5 H EW
3
13 H Corner L 14 H Corner L
15 Zoom Trap
V Slope 4V SC
11 BOW 12 Angle
16 Zoom 4:3 Para
1 V Amp 2 V Shift
17 4:3~10:9 Para

Alignment and Adjustments
4-9
4-7-2(C) VIDEO ADJUST 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Red Cufoff
Green Cutoff
Blue Cutoff
Red Drive
Green Drive
Blue Drive
Sub Bright
Sub Contrast
Sub Color
Sub Tint
Sub Threshold
BCL Gain
BCL Time
BCL Time2
BCL Bri Reduction
P.DK.YC Delay
P.I.YC Delay
P.L.YC Delay
S.BG.YC Delay
S.DK.YC Delay
S.L.YC Delay
P.BG.YC Delay
P.YC Delay
S.YC. Delay
N.YC. Delay
Adjusts the gain of red output from low light.
Adjusts the gain of green output from low light.
Fix this gain to 127.
Adjusts the gain of blue output from low light.
Adjusts the gain of red output from high light.
Adjusts the gain of green output from high light. After “G2-Adjustment”
and White Balance adjustments are complete, this data is fixed to 127."
Adjusts the gain of blue output from high light.
Adjust sub brightness level to set the low light luminance in Picture
Standard mode.
Adjust sub brightness level to set the low light luminance in Picture
Standard mode. Set the value of sub contrast to near 50. The user
control“contrast” depends on this value.
User contrast=[sub cont*2/100]If sub contrast data is 10, user contrast
changes into 1/5step.
Adjusts sub color level to set the gain for color in Picture Standard mode.
Adjusts the sub tint level of NTSC color system.
Beam Current Limit threshold current if SENSE input used 0...-2048 BCL
threshold current if RSW1 input used(max. ADC output ~2047)
Beam Current Limit loop Gain
BCL time constant; 0 = off
Teletext Contrast Level
BCL Brighness Reduction
PAL-D/K Y/C Delay
PAL-I Y/C Delay
PAL-L Y/C Delay
SECAM-B/G Y/C Delay
SECAM-D/K Y/C Delay
SECAM-L Y/C Delay
PAL-B/G Y/C Delay
External PAL Y/C Delay
SExternal SECAM Y/C Delay
External NTSC Y/C Delay
W/B
FIX
W/B
W/B
FIX
W/B
W/B
W/B
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
FIX
127
127
127
127
127
127
90
52
2
17
128
59
144
1
125
5
7
6
7
2
5
7
6
2
3
No. OSD Initial Value Function Remark
