Toshiba ColorStream TP43H60 User manual

TOSHIBA FILE NO. 020-9813
SERVICE MANUAL
COLOR TELEVISION
N8SS Chassis
TP43H60 is the same
on back of this sheet.
Use this service manu_
and bus data of micro-processor tabk
of TP50H60 (File No. 020-9806).

SETTING & ADJUSTING
[ SERVICE MODE ]
ADJUSTING ITEMS AND DATA IN THE SERVICE MODE:
DATA DIFFERENCES
Item Nameofadjustment Preset Data
PCNT PIPCONT 12H 1AH
PYOF PIP Y OFFSET 07H 05H
PIOF PIP I OFFSET 1DH 2FH
PQOF PIP Q OFFSET 1DH 2FH
Table.-2
[ DESIGN MODE ]
ADJUSTING ITEMS AND DATA INTHE DESIGN MODE:
Item Name of adjustment Preset Data Data Remarks
OPT0 OPTION 0 0AH 00H
OPT1 OPTION 1 01H 00H
"Fable-3
-2-

REPLACEMENT PARTS
Location Part No. Description
No.
A101 23465852
A201 23510392
A257 23836492
A258 23451204
A268 23475620
A701 23525619
A703 23935778
A707 23935780
A708 23935779
A709 23935781
C360 24667100
C361 24669100
C362 24567104
C363 24085942
C364 24666100
C477 24092347
CB11 24794470
CV130 24794100
D360 23316677
DB11 23358501
DB13 23358522
DB14 23118859
Klll 23430512
Kl13 23430512
K501 23837525
K502 23837526
K503 23527001
K601 23430514
K912 23306267
KB11 23904946
L470 23248196
PV12 23365763
Q360 72112051
Q361 23314548
QB11 23114528
R354 24366222
R356 24366562
R357 24382114
R360 24366102
R361 24366113
R362 24366754
R363 24366103
R364 24366103
R365 24366103
Cabinet
Bezel
Spring
Push Catch for Door
Front Cover
Case
Top Packing
Bottom Assy
Bottom Packing
Base, Tray
EL, 10/zF, :!:20%
EL, 10/iF, +20%, 50V
PF, 0.l/iF
EL, 10/JF, +20%
EL, 10/_F, _+20%
CD, 1500pF, _+10%
EL, 47pF, _+20%, 16V
EL, 10/iF, ±20°/o, 16V
Diode, Zener, MTZJ6.8A
LED, SCL003URC5F
LED, SIR-56SB3F
Diode, 1SS133
Delta, 67-A/B Assembly
Delta, 67-AJB Assembly
Lenti Sheet, SCREEN43DH-L
Fresnel Sheet, SCREEN43DH-F
Front-P43H, SCREEN43DH
Mirror43H
Remote Hand Unit, CT-9952
Remote Sensor,
RPM-676CBR-S
Coil, Choke, TLN3457AD
Jack, Phono, 3P
IC, TA75558S
Transistor, 2SC4256
Transistor, 2SC1740S-Q
CF, 2200 ohm
CF, 5600 ohm
OMF, 110k ohm
CF, lk ohm
CF, 11k ohm
CF, 750k ohm
CF, 10k ohm
CF, 10k ohm
CF, 10k ohm
LIST DIFFERENCES
Location Part No. Description
No.
R366 24366103 CF, 10k ohm
R367 24366752 CF, 7500 ohm
R368 24366183 CF, 18k ohm
R369 24366562 CF, 5600 ohm
R475 24532102 FR, lk ohm, lW
R480 24942185 CC, 1.8M ohm
R496 24382114 OMF, 110k ohm
R933 24000929 FRN98Z3D159J
RA81 24366683 CF, 68k ohm
RA82 24366223 CF, 22k ohm
RA83 24366103 CF, 10k ohm
RA86 24366103 CF, 10k ohm
RA87 24366223 CF, 22k ohm
RA88 24366683 CF, 68k ohm
RB11 24366271 CF, 270 ohm
RB14 24366103 CF, 10k ohm
RB15 24366471 CF, 470 ohm
RB19 24366470 CF, 47 ohm
RR48 24366222 CF, 2200 ohm
RV130 24368750 CF, 75 ohm
SA11 23145226 Switch,
SA12 23145226 Switch,
SA13 23145226 Switch,-
SA14 23145226 Switch,
SA15 23145226 Switch
SA16 23145226 Switch
SA17 23145226 Switch
SA18 23145226 Switch
Push, 1CIP
Push, 1CIP
Push, 1CIP
Push, 1CIP
Push, 1C1P
Push, 1CIP
Push, 1CIP
Push, 1CIP
U701
U801
U901
UA01
UM01
/_V901R
/kV902G
/kV903B
W661
W662
Y101
Y101F
Z410
Z470
ZY01
23796496
23796494
23796495
23351131
23351131
23563387
23563388
23110842
23110843
23148278
D-Conver, Board, PB8132
CONV Board, PB8104
Main Board, PB8103
CRT/FRONT Board, PB8105
V/C/D Micom Board, PB8185
Projection Tube Assy, 43H R
Projection Tube Assy, 43H G
Projection Tube Assy, 43H B
Speaker, SPK-1390
Speaker, SPK-1390
Owner's Manual, English,
TP43H60
Owner's Manual, French,
TP43H60
Focus Pack, TPA6031
Focus Pack, TPA6032AH
Module, PMUS08H
-3-

TOSHIBA CORPORATION
1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-01, JAPAN
