Toshiba PDP 37 Series User manual

Confidential
TOSHIBA ASIA OCEANIA SERVICE CENTRE
TOSHIBA PDP 37-SERIES
42WP37E, C, F, H …VGA type
50XP37E, C, F, H …XGA type

TOSHIBA ASIA OCEANIA SERVICE CENTRE
DIFFERENCE of 27-37SERIES
1 Slot Structure to 4 Slot Structure
Power consumption 42“ :
295W→235W, 50“ : 495W→435W
Zoom in Function （２Ｘ２、３Ｘ３）
DISITAL ZOOM function （Ｘ２Ｘ３ )
２In screen function （POP 、PIP ）

TOSHIBA ASIA OCEANIA SERVICE CENTRE
Destination
Hong Kong 、Singapore 、Middle East
42WP37H
50XP37H
Korea 、Russia , Australia
42WP37F
50XP37F
China
42WP37C
50XP37C
England and Europe
42WP37E
50XP37E
Country / RegionType

TOSHIBA ASIA OCEANIA SERVICE CENTRE
Different between specification
POWER CORD x2,REMOCON
MANUAL x3, WARRANTY
x2COMPOSITE x1
COMPONENT x2
42WP37F
50XP37F
POWER CORD x1,REMOCON
MANUAL x2
COMPOSITE x1
COMPONENT x2
42WP37H
50XP37H
POWER CORD x1,REMOCON
MANUAL x2, WARRANTY
COMPOSITE x1
COMPONENT
42WP37C
50XP37C
POWER CORD x2,REMOCON
MANUAL x5
COMPOSITE,SCART
COMPONENT option
42WP37E
50XP37E
ACCESSORYBOARDType

TOSHIBA ASIA OCEANIA SERVICE CENTRE
TOSHIBA
x 2
EXIT
x 1
EXIT
x 2
Press Zoom Key
Zoom
x 3
*9 Points Digital Zoom x2 and x3

TOSHIBA ASIA OCEANIA SERVICE CENTRE
TOSHIBATOSHIBA
x 2
EXIT
x 1
EXIT
x 2
Press Zoom Key
MOVE
ZOOM
Original Picture Zoom Picture
*9 Points Digital Zoom x2

TOSHIBA ASIA OCEANIA SERVICE CENTRE
TOSHIBATOSHIBA
x 2
EXIT
x 2
EXIT
x 3
Press Zoom Key
MOVE
ZOOM
Original Picture Zoom Picture
*9 Points Digital Zoom x3

TOSHIBA ASIA OCEANIA SERVICE CENTRE
New Function : Dual Picture
TOSHIB
PDP
PRESENT TION
TOSHIB
PDP
PRESENT TION
TOSHIB
PDP
PRESENT TION
*Two Image can be displayed simultaneously
*Picture In Picture *Picture and Picture *Picture out Picture
ll Signals Combination is available as
E.g. PC- Composite, Composite – Component
S-video – Composite, Component - RGB
TOSHIB TOSHIB TOSHIB

TOSHIBA ASIA OCEANIA SERVICE CENTRE
Board Name Function Remarks
D Digital Signal Processor 1
J Slot Interface & SYNC processor 1
Z Audio out, DC-DC converter
SS Sustain Out 1
SC Scan out 1
SU Sustain connection (Upper) 1
SD Sustain connection (Lower) 1
C1 Data Drive (Lower Right)
C2 Data Drive (Lower Left)
H3 Speaker terminal
S1 Power switch
SS2 Sustain connection (Upper)
SS3 Sustain connection (Lower)
V1 Front SW. & Remote receiver
PF Line filter
P Power supply 1
HX PC_type_Input terminal
HY BNC Composite/Component Video 2
HZ BNC Component Video 3
HT SCART Video 4
n=20sheets
PCB Structure sheet of 37series 42”type

TOSHIBA ASIA OCEANIA SERVICE CENTRE
Remove : 4screws ( )
6screws ( )
16screws ( )
for PDP Back Cover
SU
SD
SC
C1 C2
PF
HX
J
P
D
Z
H3
V1 S1
SS3
SS2
SS
HYHZ HT
H3
SV 8page
Service Hint

TOSHIBA ASIA OCEANIA SERVICE CENTRE
Block Diagram

TOSHIBA ASIA OCEANIA SERVICE CENTRE
Power Supply

TOSHIBA ASIA OCEANIA SERVICE CENTRE
Power supply Block Diagram

TOSHIBA ASIA OCEANIA SERVICE CENTRE
PF-Board

TOSHIBA ASIA OCEANIA SERVICE CENTRE
P-BOARD

TOSHIBA ASIA OCEANIA SERVICE CENTRE
HX-BOARD

TOSHIBA ASIA OCEANIA SERVICE CENTRE
HY-BOARD

TOSHIBA ASIA OCEANIA SERVICE CENTRE
J-Board

TOSHIBA ASIA OCEANIA SERVICE CENTRE
D-BOARD

TOSHIBA ASIA OCEANIA SERVICE CENTRE
C1-BOARD
