4. Power On:
The power indicator lits when Power on. When input signal is larger than
66dBM, the LED indicator will lit.
3. Cautions:
The frequency range is between 470MHz~960MHz, and it works with any
MI-808T transmitter within this specified range. To obtain optimal transmission
efficiency ensure the transmitting antenna is of the same frequency band as
the transmitter itself. MIPRO AT-90T wide band directional antennas is highly
recommended to work with AD-808.
Use 50Ωimpedance coaxial cable (like RG-58) to connect the receiver and
the antenna combiner system. Coaxial cable within 10 meters is the
recommended length.
AD-808
3. Installation of Extension Antennas
MIPRO AT-70 or AT-90T Extension Antennas can be installed with MS-10
wall mount brackets or general microphone stand and connect by coaxial
cables. It is recommended to use higher quality but minimized the length of
coaxial cables and ensure antenna is positioned higher than the crowd and
away from obstacle objects for optimal reception.
Wide-band Extension Antenna Stand
Wide-band Extension Antenna Mount Brackets
AT-90T
MS-10
4-channel Active Antenna Combiner
4-channel Active Antenna Combiner
OPERATING MANUAL
AS110531
MIPRO Electronics Co., Ltd.
Headquarters: 814 Pei-Kang Road, Chiayi, 60096, Taiwan.
Web: www.mipro.com.tw
E-mail: [email protected]
Design and specifications are subject to change without prior notice
