ABOUT THIS MANUAL
(주) 신광씨링
광주광역시 서구 하남대로
502번길 14
NO NEED PRINT
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 1 2020-07-17 �� 5:29:27

KOC9C0TBKT
Dual Heater Convection Oven
900w 0.9cuft 28ltre
OWNER'S MANUAL
PLEASE READ CAREFULLY
Before operating this oven, please read these instructions completely.
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 1 2020-07-17 �� 5:29:27

2
GREAT BRITISH DESIGN, INNOVATION
AND EXCELLENCE SINCE 1912
Since the turn of the 20th century, Tower has been designing,
developing and manufacturing housewares and small
appliances used by millions of households throughout the
UK and beyond. During the 1960s, the rise in popularity
of pressure cooking saw Tower become the UK’s largest
producer of pressure cookers, right through into the late
1980s. In recent years the Tower brand has been reborn with
an exciting and varied range of housewares and electrical
appliances that have quickly reinstated the brand’s richly
deserved status as a household name.
Visit
www.towerhousewares.co.uk
for more fantastic products.
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 2 2020-07-17 �� 5:29:27

3
Visit
www.towerhousewares.co.uk
for more fantastic products.
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door
open since open-door operation can result in harmful
exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) WARNING : If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person: (1) door (bent), (2) hinges and
latches (broken or loosened), (3) door seals and sealing
surfaces.
(d) WARNING : It is hazardous for anyone other than a
competent person to carry out any service or repair
operation which involves the removal of a cover which
gives protection against exposure to microwave energy.
(e) WARNING : Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
(f) WARNING : Only allow children to use the oven without
supervision when adequate instructions have been given
so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
(g) WARNING : When the appliance is operated in the
combination mode, children should only use the oven
under adult supervision due to the temperatures
generated.
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 3 2020-07-17 �� 5:29:27

4
TABLE OF CONTENTS
• INSTALLATION AND EARTHING INSTRUCTIONS ............................................................................................. 5
• IMPORTANT SAFETY INSTRUCTIONS................................................................................................................6
• WHICH UTENSILS CAN BE USED IN THE OVEN?........................................................................................... 10
• COOKING INSTRUCTIONS ................................................................................................................................ 11
• CONTROL PANEL ............................................................................................................................................... 12
• ACCESSORIES................................................................................................................................................... 13
• BEFORE OPERATION........................................................................................................................................ 14
SETTING THE CLOCK........................................................................................................................................ 14
CHILD LOCK AND POWER SAVE MODE......................................................................................................... 15
• OPERATION........................................................................................................................................................ 16
MICROWAVE COOKING ..................................................................................................................................... 16
GRILL COOKING................................................................................................................................................. 17
CONVECTION COOKING (WITH PRE-HEAT) .................................................................................................. 18
CONVECTION COOKING (TRADITIONAL COOKING)..................................................................................... 19
COMBINATION COOKING ................................................................................................................................ 20
(1) WEIGHT DEFROST MODE........................................................................................................................... 21
(2) TIME DEFROST MODE.................................................................................................................................. 21
AUTO COOK ........................................................................................................................................................ 22
SPEEDY COOK.................................................................................................................................................... 23
WARM................................................................................................................................................................... 23
DISH WARMER (FOR PREMIER OPTION MODEL ONLY)............................................................................... 24
STEAM CLEANING.............................................................................................................................................. 24
REMINDER MODE (FUNCTION TO REMIND COOKING COMPLETE) ........................................................... 24
TO STOP THE OVEN WHILE THE OVEN IS OPERATING............................................................................... 25
ABNORMAL MESSAGE....................................................................................................................................... 25
ARCING ................................................................................................................................................................ 25
• GENERAL GUIDE LINES..................................................................................................................................... 26
• KEEP THE OVEN CLEAN.................................................................................................................................... 27
• BEFORE CALLING FOR SERVICE..................................................................................................................... 28
• QUESTIONS AND ANSWERS ............................................................................................................................ 29
• SPECIFICATIONS................................................................................................................................................ 30
• PRINCIPLE OF MICROWAVE............................................................................................................................. 30
• DISPOSAL OF USED ELECTRICAL & ELECTRONIC EQUIPMENT ................................................................ 30
• WARRANTY ......................................................................................................................................................... 31
• YOUR RECEIPT................................................................................................................................................... 32
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 4 2020-07-17 �� 5:29:27

5
INSTALLATION AND EARTHING INSTRUCTIONS
How to examine your microwave oven after unpacking.
Unpack oven, remove all packing material, and examine the oven for
any damage such as dents, broken door, latches or cracks in the
door. Do not remove the film from inside the door. Notify dealer
immediately if the oven is damaged. Do not install if the oven is
damaged.
Where to place your microwave oven.
1. Place the oven on a flat and stable surface.
2. The microwave oven shall not be placed in a cabinet unless it is a
purpose built cabinet model.
3. The surface of the oven is protected by a plastic film which should
be removed before using.
4. Leave space behind and the sides and upper surface of the oven.
All air vents should be kept clear.
If all vents are covered during operation, the oven may overheat
and, eventually, lead to oven failure.
5. Keep away from radio and TV sets. If the oven is located close to a
TV, radio interference may result.
6. Keep away from heating appliances and water taps. Keep the oven
away from hot air, steam or splashes when choosing a place to
position it, or the insulation might be adversely affected and
breakdowns occur.
7. The minimum height of free space necessary above the top
surface of the oven is 170mm minimum.
Prior to use (If your oven has a grill element)
In order to protect your oven during transportation and storage, the
grill element is covered with a protective coating. To remove this
coating the grill element must be heated for 10 minutes. This
procedure will produce some bad odours as the protective coating on
the element disappears.
To remove the coating, use the following procedures:
1. Place an ovenproof or microwave safe bowl, containing 200cc of
water or more, in the oven.
2. Press the convection button.
3. Set the time to 10 minutes.
4. Press the start button.
5. When the 10 minutes has elapsed, an acoustic signal sounds.
Note:
The protective coating has now been removed and the oven is ready
to use. Please be aware that your oven is now very hot.
6. Open the oven door and remove the bowl of water (use oven
gloves when removing the bowl).
CHILD LOCK
To prevent a child from operating the oven, install the childlock key.
1. Touch Stop/Clear button for 3 seconds.
Indicator lock is indicated and all buttons do not operate.
2. Touch Stop/Clear button for 3 seconds once again, then childlock
is canceled.
- WARNING: Only allow children to use the oven without supervision
when adequate instructions have been given so that the child is able
to use the oven in a safe way and understands the hazards of
improper use.
Electrical Connection
WARNING-THIS APPLIANCE MUST BE EARTHED.
REFER TO THE RATING PLATE FOR VOLTAGE AND CHECK
THAT THE APPLIANCE VOLTAGE CORRESPONDS WITH THE
SUPPLY VOLTAGE IN YOUR HOME.
The flexible mains lead must be correctly re-connected, as below, to a
three pin plug of not less than 13 AMP capacity. You must use a 3 pin
plug which should be marked with the number BS 1363 and it should
be fitted with 13 AMP fuse marked with the number BS 1362.
We recommend the use of good quality plugs and wall sockets that
can be switched off when the machine is not in use.
IMPORTANT-The wires in the mains lead fitted to this appliance are
coloured in accordance with the following code
GREEN AND YELLOW-EARTH
BLUE-NEUTRAL
BROWN-LIVE
As the colour of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in
your plug, proceed as follows:
Power supply
• Check your local power source. This oven requires a current of
approximately 12amperes, 220-240V 50Hz.
• Power supply cord is about 1.0 meters long.
• The voltage used must be the same as specified on this oven.
Using a higher voltage may result in a fire or other accident causing
oven damage. Using low voltage will cause slow cooking. We are
not responsible for damage resulting from use of this oven with a
voltage of ampere fuse other than those specified.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard.
The wire which is coloured GREEN AND YELLOW must be
connected to the terminal in the plug which is marked with the letter
"E" or the earth symbol or coloured GREEN AND YELLOW, or
GREEN.
The wire which is coloured BLUE must be connected to the terminal
which is marked with the letter "N" or coloured BLACK, or BLUE.
The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter "L" or coloured RED , or
BROWN.
If the terminals in the plug are unmarked or you are in any doubt as to
the correct connections, consult a qualified electrician.
If you do not make the proper electrical connections you will damage
your microwave oven and possibly injure yourself. Neither the
manufacturer nor the supplier are liable if this happens.
MOULDED PLUGS
Should it be necessary to remove a moulded on plug from the mains
cable, it should be cut off and replaced with a suitable replacement.
The moulded plug cannot be used for any other appliance, therefore
remove the fuse and dispose immediately and safely to prevent
anyone, especially children from plugging it in to a wall socket, which
will create a safety hazard.
Should the mains lead ever require replacement, it is essential that
this operation be carried out by a qualified electrician and should only
be replaced with a flexible cord obtained from the manufacturer.
Applicable only if moulded plug is fitted.
After replacement of a fuse in the plug, the fuse cover must be
refitted. If the fuse cover is lost, a replacement cover must be
obtained. The colour of the correct replacement fuse cover is that of
the coloured insert in the base of the plug or the colour that is
embossed in words in the base of the plug recess or elsewhere on
the plug. Always state this colour when ordering a replacement fuse
cover.
Only 13 amp replacement fuses which are ASTA approved to BS
1362 should be fitted
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 5 2020-07-17 �� 5:29:27

6
IMPORTANT SAFETY INSTRUCTONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
1. Read all instructions before using
the appliance.
2. Read and follow the specific
“PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY” found on page 1.
3. This appliance must be grounded.
Connect only to a properly grounded
outlet.
4. Install or locate this appliance only in
accordance with the provided
installation instructions.
5. Some products such as whole eggs
and sealed containers - for example,
closed glass jars-are liable to
explode and should not be heated in
this oven.
6. Use this appliance only for its
intended use as described in this
manual. Do not use corrosive
chemicals or vapors in this
appliance. This type of oven is
specifically designed to heat, cook,
or dry food. It is not designed for
industrial or laboratory use.
7. As with any appliance, close
supervision is necessary when used
by children.
8. Do not operate this appliance if it
has a damaged cord or plug, if it is
not working properly, or if it has been
damaged or dropped.
9. This appliance should be serviced
only by qualified service personnel.
Contact your nearest authorized
service facility for examination, repair
or adjustment.
10. Do not cover or block any openings
on the appliance.
11. Do not store this appliance
outdoors. Do not use this product
When using electrical apliances, basic safety
precautions should be followed, including the following:
WARNING-To reduce the risk of burns, electric shock,
fire, injury to persons or exposure to excessive
microwave energy:
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 6 2020-07-17 �� 5:29:27

7
near water — for example, near a
kitchen sink, in a wet basement, or
near a swimming pool, or similar
locations.
12. Do not immerse the cord or plug in
water.
13. Keep the cord away from heated
surfaces.
14. Do not let cord hang over edge of
table or counter.
15. Either:
a) When cleaning surfaces of door
and oven that comes together
on closing the door, use only
mild, non-abrasive soaps or
detergents applied with a
sponge or soft cloth , or
b) When separate cleaning
instructions are provided, See
door surface cleaning
instructions on.
16. To reduce the risk of fire in the
oven cavity:
a) Do not overcook food.
Carefully attend the appliance
when paper, plastic, or other
com-bustible materials are
placed inside the oven to
facilitate cooking.
b) Remove wire twist-ties from
paper or plastic bags before
placing bag in the oven.
c) If materials inside the oven
ignite, keep oven door closed,
turn oven off, and disconnect the
power cord, or shut off power at
the fuse or circuit breaker panel.
d) Do not use the cavity for storage
purposes. Do not leave paper
products, cooking utensils, or
food in the cavity when not in
use.
17. Do not use this microwave oven to
heat corrosive chemicals (for
example, sulfides and chlorides).
Vapours from such corrosive
chemicals may interact with the
contact and springs of the safety
interlock switches thereby
rendering them inoperable.
18. Keep the waveguide cover clean at
all times. Wipe the oven interior
with a soft damp cloth after each
use. If you leave grease or fat
anywhere in the cavity it may
overheat, smoke or even catch fire
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 7 2020-07-17 �� 5:29:27

8
when next using the oven.
19. Never heat oil or fat for deep frying
as you cannot control the
temperature and doing so may
lead to overheating and fire.
20. Liquids, such as water, coffee, or
tea are able to be overheated
beyond the boiling point without
appearing to be boiling due to
surface tension of the liquid. Visible
bubbling or boiling when the
container is removed from the
microwave oven is not always
present. THIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN A SPOON
OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID. To
reduce the risk of injury to persons:
1Do not overheat the liquid.
2Stir the liquid both before and
halfway through heating it
3Do not use straight-sided
containers with narrow necks.
4After heating, allow the
container to stand in the
microwave oven for a short time
before removing the container.
5Use extreme care when
inserting a spoon or other
utensil into the container.
21. The contents of feeding bottles and
baby jars must be stirred or shaken
and check the temperature before
consumption to avoid burns.
22. The appliance must be positioned
so that the plug is accessible.
23. This appliance is not intended for
use by a person (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety.
24. Children should be supervised to
ensure that they do not play with
the appliance.
25. Due to extremely high
temperatures, do not touch the
surface of door and the Top heater
of oven during and after running
the heater related cooking mode.
SAVE THESE INSTRUCTIONS
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 8 2020-07-17 �� 5:29:27

9
11. Do not use the oven for any reason other than
food preparation, such as for drying clothes,
paper, or any other nonfood items or for
sterilizing purposes.
They may catch on fire.
12. Do not use the oven when empty, this could
damage the oven.
13. Do not use the oven cavity for any type of
storage, such as papers, cookbook, cookware,
etc.
14. Do not operate the oven without the turntable
tray in place. Be sure it is properly sitting on the
rotating base.
15. Be cautious when removing the turntable tray
after cooking meats that may have caused an
accumulation of grease in the tray.
16. Unlike microwave-only ovens, this oven may
become hot on the cabinet and oven door.
Always use hot pads or oven mitts when
placing or removing food and/or accessories
from the oven.
Be cautious about touching parts other then the
control panel during or immediately following
grill or combination cooking.
17. If the oven is hot from combination cooking, do
not then use plastic or Styrofoam cookware for
microwave cooking. They may melt.
18. Do not use recycled paper products for
cooking.
They may contain impurities which could cause
sparks and/or fires when used during cooking.
19. Do not continue to cook with metal utensils if
sparking appears. See "Accessories" section
on page 8 for proper use of cookware.
10. Do not leave the oven unattended during short
cooking times. Overcooking and fire may
result.
11. Do not cook any food surrounded by a
membrane, such as egg yolks, potatoes,
chicken livers, etc., without first piercing them
several times with a fork.
12. Do not pop popcorn unless popped in a
microwave approved popcorn popper or unless
it's commercially packaged and recommended
especially for microwave ovens. Microwave
popped corn produces a lower yield than
conventional popping; there will be a number of
unpopped kernels. Do not use oil unless
specified by the manufacturer.
13. Do not attempt to operate this appliance with
the door open.
14. Do not attempt to remove covers, panels, etc.
15. Keep an eye on the oven from time to time
when food is heated or cooked in disposable
containers of plastic, paper or other
combustible materials.
16. If smoke is observed, switch off or unplug the
appliance and keep the door closed in order to
stifle any flames.
17. Microwave heating of berverages can result in
delayed eruptive boiling, therefore care must be
taken when handling the container.
18. Make sure you remove caps or lids prior to
cooking when you cook food sealed in bottles.
19. Do not put foreign material between the oven
surface and door. It could result in excessive
leakage of microwave energy.
20. Do not pop popcorn longer than the
manufacturer's directions. (popping time is
generally below 3 minutes). Longer cooking
does not yield more popped corn, it can cause
scorchings and fire.
Also, the cooking tray can become too hot to
handle or may break.
21. When heating food in plastic or paper
containers, keep an eye on the oven due to the
possibility of ignition.
22. Always test the temperature of food or drink
which has been heated in a microwave oven
before you give it to somebody, especially to
children or elderly people. This is important
because things which have been heated in a
microwave oven carry on getting hotter even
though the microwave oven cooking has
stopped.
23. Eggs in their shell and whole hard-boiled eggs
should not be heated in microwave ovens
since they may explode, even after microwave
heating has ended;
24. Keep the waveguide cover clean at all times.
Wipe the oven interior with a soft damp cloth
after each use. If you leave grease or fat
anywhere in the cavity it may overheat, smoke
or even catch fire when next using the oven.
25. Never heat oil or fat for deep frying as you
cannot control the temperature and doing so
may lead to overheating and fire.
26. During use the appliance becomes hot. Care
should be taken to avoid touching heating
elements inside the oven.
27. Do not use a steam cleaner in the oven.
General Use
Listed below are, as with all appliances, certain rules to follow and safeguards to assure top
performance from this oven:
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 9 2020-07-17 �� 5:29:27

10
WHICH UTENSILS CAN BE USED IN THE OVEN?
Only use utensils that are suitable for use in microwave ovens.
Before use, the user should check that utensils are suitable for use in microwave ovens.
1. Eggs
Never cook eggs in their shells. Steam will build up inside the
shell during cooking and the egg will explode.
If you want to cook or reheat eggs which have not been
broken up by scrambling or mixing, you must always pierce
the yolks or these will also explode. You should slice shelled
hard boiled eggs before you reheat them in your microwave
oven.
2. Piercing
Always pierce food which has a skin or membrane, for
example, potatoes, tomatoes, apples, sausages etc. If you
don't pierce them, steam will build up inside and they may
explode.
3. Lids
Always remove the lids of jars and containers and take away
food containers, before you cook using your microwave oven.
If you don't, then steam and pressure might build up inside
and cause an explosion even after the microwave cooking
has stopped.
Shallow containers give more even cooking results.
Utensils made of china and ceramic are excellent to use in your
microwave oven. Most types of glass are also very good.
Lead crystal glass can crack and should therefore, not be used.
Plastics and paper can also be used, provided they can
withstand the temperature of the heated food. For cooking only
use plastics, which will withstand a temperature of over 120˚C,
e.g. polypropene and polyamide. Some plastic materials, e.g.
melamine, will be heated by the microwave, and be damaged.
To find out if a certain container is suitable, the following simple
test can be made:
Place the empty container and a glass of water inside the
microwave oven. The water is needed because the oven must
not be operated empty or with empty containers only.
Let the oven work on full power for one minute. A suitable
container will only be lukewarm.
Metal containers, e.g. saucepans or frying pans should not be
used in microwave ovens. Nor should plates or vessels with
decorations be used since metal e.g. gold, might be part of the
decoration and such decorations will be damaged.
Small pieces of aluminiuum foil can be
used, but only to shield the areas that
would over-cook (e.g. for covering chicken
wings, leg tips and fish tails) but the foil
must not touch the side of the oven as
damage may occur.
WARNING
Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to
be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from the
microwave oven is not always present. this could result in
very hot liquids suddenly boiling over when a spoon or
other utensilis is inserted into the liquid.
To reduce the risk of injury to persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
e) Use extreme care when inserting a spoon or other
utensil into the container.
Material
Grill &
Convection
cooking
Microwave
cooking
Combined
cooking
Glass (general) No Yes (1) No
Glass (heat resistant) Yes Yes Yes
Glass-ceramic and
ceramic (heat resistant) Yes Yes (1) Yes (1)
Earthenware Yes Yes Yes
China (heat resistant) Yes Yes Yes
Plastic (general) No Yes (2) No
Plastic (heat resistant) Yes (2) Yes (2) Yes (2)
Aluminium foil containers
/aluminium foil Yes Yes (3) Yes
Metal baking tins Yes (4) No Yes (4)
Metal (pots.pans, etc) Yes No No
Paper No Yes No
1. Without metal parts or metal trims.
2. Some plastics are heat-proof only to certain temperatures.
Check carefully!
3. It is possible to use aluminium foil to shield deliate areas of
food (this prevents over-cooking).
4. Metal tins can be used in the combination methods,
however if these are very deep, they will greatly reduce
the efficiency, as metal shields the microwave energy
from the food.
Microwave function only
Utensils and cooking containers used in a microwave oven
should be of a material that does not act as a barrier to
microwave energy. Generally this means that you should cook in
either (paper), plastic, glass or ceramic. Metal pans reflect
microwave energy and inhibit cooking, and should not be used.
In addition to material, the shape of the container should also be
considered. Round oval shapes give the most even cooking.
Square or rectangular containers may over-cook foods in the
corners because more energy is absorbed there.
TO AVOID EXPLOSION AND SUDDEN BOILIING
Caution:
• There are a number of accessories available on the
market. Before you buy, make sure they are suitable
for microwave use.
• When you put food in the microwave oven, make sure that
food, food supports or covering do not come in direct
contact with any of the internal walls or the ceiling of the
cavity since discolouration may take place.
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 10 2020-07-17 �� 5:29:27

11
Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or
absorbed by the dish used.
Care must therefore be taken choosing the utensil. If the utensil is marked microwave-safe, you do not need to worry.
The following table lists various utensil and indicates whether and how they should be used in a microwave oven.
●: Recommended use
▲ : Limited Use
✕ : Not Recommended
Utensil Safe Comments
Aluminium foil ▲Can be used in small quantities to protect areas against overcooking. Arcing
can occur if the foil is too close to the oven wall or if too much foil is used.
Crust plate ●Do not preheat for more than 8minutes.
China and earthenware ●Porcelain, pottery, glazed earthenware and bone china are usually suitable,
unless deco-rated with a metal trim.
Disposable polyester
cardboard dishes
●Some frozen foods are packaged in these dishes.
Fast-food packaging
• Polystyrene cups containers
• Paper bags or newspaper
• Recycled paper or metal trims
●
✕
✕
Can be used to warm food. Overheating may cause the polystyrene to melt.
May catch fire.
May cause arcing.
Glassware
• Oven-to-table ware
• Fine glassware
• Glass jars
●
●
●
Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.
Metal
• Dishes
• Freezer bag twist ties
✕
✕
May cause arcing or fire.
Paper
• Plates, cups, napkins and
Kitchen paper
• Recycled paper
●
✕
For short cooking times and warming. Also to absorb excess moisture.
May cause arcing.
Plastic
• Containers
• Cling film
• Freezer bags
●
●
▲
Particularly if heat-resistant thermoplastic. Some other plastics may warp or
discolour at high temperatures. Do not use Melamine plastic.
Can be used to retain moisture. Should not touch the food.
Take care when removing the film as hot steam will escape.
Only if boilable or oven-proof. Should not be airtight. Prick with a fork, if
necessary.
Wax or grease-proof paper ●Can be used to retain moisture and prevent spattering.
COOKING INSTRUCTIONS
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 11 2020-07-17 �� 5:29:28

12
1Display : Cooking time, power level, program
indicators and present time are displayed.
MW ( ): When blinking, the oven is operating in
MICROWAVE COOK mode.
Grill ( ): When blinking, the oven is operating in
GRILL mode.
Combi ( ): When blinking, the oven is operating
in COMBI mode.
Convection ( ): When blinking, the oven is operating
in CONVECTION mode.
Defrost ( ): When blinking, the oven is operating in
DEFROST mode.
Auto-cook ( ): When blinking, the oven is operating in
AUTO COOK mode.
Warm ( ): When blinking, the oven is operating in
WARM mode.
Steam Cleaning ( ): When blinking, the oven is
operating in STEAM CLEANING mode.
gram ( ): When blinking, the oven is operating in
weight input mode.
2Auto cook : Used to cook or reheat.
3MW : Used to set power level of the microwave.
4Defrost : Used to defrost foods.
5Grill : Used to select grill mode.
6Combi : Used to select combi mode.
7Convection : Used to select convection mode and
selected temp.
8Clock : Used to set clock.
9STEAM CLEANING : Used to clean the inside of
the oven
0Warm : Used to keep the food warm.
qDial knob : Used to set time, weight and quantity.
wSTART/SPEEDY COOK : Used to start a program or a
speedy start(each press adds 30 seconds of
microwave cooking time).
eSTOP/CLEAR : Used to stop the oven operation or to
delete the cooking data.
3
1
q
w
2
e
4
5
6
7
8
9
0
CONTROL PANEL
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 12 2020-07-17 �� 5:29:28

13
■Glass Turntable ■Metal rack
1Glass Turntable - Centre the tray on the roller guide when using the microwave features. Place food or
microwave-safe cookware directly on the glass turntable.
2Roller Guide - The roller guide must be in place when using the oven.
IMPORTANT : The roller guide must be placed at the centre of the oven cavity.
3Metal Rack - Centre the rack on the glass tray when using the grill cooking, convection cooking, and auto
cooking menus.
NOTE : The Glass Turntable can be found attached to the left polystyrene packing material in the carton.
■HOW TO USE THE ACCESSORIES FOR COOKING
• All Cooking modes. • Grill cooking
• Convection cooking
• Combination cooking
• Auto cooking menu 1~4.
ACCESSORIES
This oven comes equipped with several accessories. They can be used in various ways to facilitate cooking.
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 13 2020-07-17 �� 5:29:28

14
BEFORE OPERATION
When your oven is plugged in, the display will show “ :0” and a tone will sound. If the AC power goes off and comes back
on, the display will show “:0”.
Your oven has a multiple(12hr/24hr) clock system. To set the clock, follow the procedure below.
Example : To set 5:30 AM in a 24hr clock system.
1. Press Clock button once.
The display will show “ 12H ”. This is a 12 hour clock system.
2. Press Clock button once more, the display shows “24H”.
This is a 24hour clock system. If you want 12hour clock
system, omit this step.
3. Turn the dial knob to set the hour number “5:”.
The hour digit starts blinking, the colon will light.
4. Press Clock button. “5:00” shows in display.
The minute digit starts blinking, the colon and hour number will
light.
5. Turn the dial knob until “5:30” shows in the display window.
6. Press Clock button. The colon starts blinking.
If you selected the 12hour clock system, this digital clock
allows you to set the time from 1:00 to 12:59.
If you selected the 24hour clock system, this digital clock
allows you to set the time from 0:00 to 23:59.
SETTING THE CLOCK
Note : You can check the current time while cooking is in
progress by pressing the Clock button.
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 14 2020-07-17 �� 5:29:29

15
Child lock : The Child Lock function helps to prevent accidents from children operating the oven without being monitored by
the parents.
Power save mode : This function is used for saving energy.
To set child lock
1. Press the STOP/CLEAR button.
“: 0” or clock appears in the display.
2. Press and hold the STOP/CLEAR button for 3 seconds.
A beep sounds and the display shows “ LOC ” for 3 seconds.
Now the oven cannot be operated.
3. To cancel child lock simply repeat procedure 2.
The oven will beep.
The oven is again available for normal use.
To set power save mode
1. Press the STOP/CLEAR button.
“: 0” or clock appears in the display.
2. Press and then hold the Clock button for 3 seconds.
The display will turn off and a beep sounds.
To operate the oven in power save mode, press any key or
turn the knob.
Then “:0” or clock will be shown and the operation of all
function keys will be the same as in the normal mode.
But if there is no operation within 10 seconds in clear mode or
while manipulating the key, all the contents of display will
disappear.
3. To cancel the power save mode, simply repeat the setting
procedure.
The power save mode will be canceled and a beep sounds.
The oven is again available for normal use.
CHILD LOCK AND POWER SAVE MODE
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 15 2020-07-17 �� 5:29:29

16
Tips : Please read this OPERATION section for the proper safety information and the operating instructions before
using the oven. Prior to setting the controls, place one cup of water in the oven, in a heat-proof glass measuring
cup, for testing purposes.
The oven could be damaged if you operate the oven in microwave mode without anything in the cavity.
Note : When the cooking time has elapsed the oven beeps three times and "End" appears on the display. The
glass turntable stops and the oven-light turns off. The oven will continue to beep every one-minute until
either the STOP/CLEAR button is pressed or the door is opened. Opening the door while cook is in
progress will cause the oven to stop and any displayed countdown will pause. If the START/SPEEDY
COOK button is pressed, the countdown will resume. If the STOP/CLEAR button is pressed, the cook will
cancel. The oven can display the set cooking time in 10 second steps (up to 5 minutes cooking time), in 30
second steps (up to 10 minutes cooking time), and in 1 minute steps (up to 60 minutes cooking time).
When the door is opened after cooking, the cooling fan may start to operate for 5 minutes to cool down the
inside of oven. (Display shows "cool" and " :0 or clock")
Also note that when the Cooling mode operates, lamp, tray, and fan runs at the same time and “cool” shows
on the display.
Note : The oven will automatically work on 100% microwave
power if a cooking time is entered without the power
level previously being selected.
You can check the power level while cooking is in
progress by pressing the MW button.
Power level table
OPERATION
This microwave cooking method allows you to cook food for a desired time. In addition to the maximum power level(100%),
you can select different microwave power from 9 other levels, 10% to 90% for the foods that require slower cooking.
If you have used the appliance for grilling, convection or combination cooking, let the oven cool down before using again.
Never switch the microwave oven on when it is empty.
MICROWAVE COOKING
1. Press the MW button once. MW indicator ( ) lights.
“P-HI”(POWER HIGH) shows in display.
2. Select the appropriate power level by pressing the MW button
again until the corresponding percentage is displayed. Refer
to the power level table below for further details.
3. Turn the dial knob to set the cooking time.
For a cooking time of 5 minutes 30 seconds, turn the dial
knob to set 5:30.
(up to 60 minutes can be set)
“5:30” shows in display.
4. Press the START/SPEEDY COOK button.
The oven light comes on and the turntable starts rotating.
Cooking starts and the time in the display will count down.
P-HI
P-90
P-80
P-70
P-60
100%
990%
980%
970%
960%
900W
810W
720W
630W
540W
P-50
P-40
P-30
P-20
P-10
P-00
50%
40%
30%
20%
10%
90%
450W
360W
270W
180W
90W
900W
Power level percentage Output Power level percentage Output
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 16 2020-07-17 �� 5:29:29

17
The Grill enables you to heat and make food to turn brown quickly without using microwave.
GRILL COOKING
Note : When using the grill heater for the first time, smoke
and odour will be given off. To avoid this happening
when food is being cooked, turn the heater on with a
microwave safe bowl containing 200cc of water in the
oven for 10 minutes and the odour will disappear from
then on.
Grill food by placing it directly on the rack, in a flat dish
or on a heat resistant plate on the rack.
Note : The heating element is located on the top surface of
the oven.
1. Press the Grill button once. The GRILL indicator ( )lights.
2. Turn the dial knob to set the grilling time.
For a grilling time of 11 minutes, turn the dial knob to set
11:00.
(up to 60 minutes can be set)
“11:00” shows in display.
3. Press the START/SPEEDY COOK button.
The oven light comes on and the turntable starts rotating.
Cooking starts and the time in the display will count down.
WARNING :
The temperature inside the oven and window is very high.
Do not touch the oven window and metallic interior of the
oven when taking food in and out.
Use thick oven gloves while handling food or accessories.
This method is ideal for toasting bread or muffins.
Remember the oven will be hot.
Place all food on the metal rack.
Use oven-proof cookware.
As there is no microwave energy being used you can
place metal tins directly onto the metal rack with no
danger of arcing.
Suggested use Cookware
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 17 2020-07-17 �� 5:29:30

18
For convection cooking, it is recommended to preheat the oven to the appropriate temperature (except for the 40C that
displays only) before placing food in the oven.
The maximum preheating time is 30 minutes.
If cooking is not started immediately after preheating, the convection indicator will continue to flash and the preheated oven
temperature will be displayed. It will be maintained for 15 minutes; then switch off automatically.
CONVECTION COOKING(With pre-heat)
1. Press the Convection button once. The CONVECTION
indicator ( )lights.
“180°C” shows in display.
2. Select the convection cooking temperature by pressing the
Convection button again until the corresponding temperature
is displayed.
3. Press START/SPEEDY COOK button. The CONVECTION
indicator ( ) blinks.
The temperature of preheating and “PrE-” blink altematively in
the display.
The oven will now preheat. When the oven reaches the
preheated temperature the oven will beep and the preheated
oven temperature will appear in the display.
Then open the door and place your food in the oven.
The oven temperature now shows in the display.
4. Turn the dial knob to set the cooking time.
For a cooking time of 11 minutes, turn the dial knob to set
11:00.
(up to 60 minutes can be set)
“11:00”shows in display.
5. Press the START/SPEEDY COOK button.
The oven light comes on and the turntable starts rotating.
Cooking starts and the time in the display will count down.
180°C →190°C →200°C →210°C →220°C →
40°C →100°C →110°C →120°C →
130°C →140°C →150°C →160°C →170°C →
Temperature sequence
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 18 2020-07-17 �� 5:29:30

19
The convection mode enables you to cook food in the same way as in a traditional oven. Microwaves are not used.
Always use oven gloves when touching the utensils in the oven, as they will be very hot.
CONVECTION COOKING(Traditional cooking)
1. Press the Convection button once. The CONVECTION
indicator ( ) lights.
“180°C” shows in display.
2. Select the convection cooking temperature by pressing the
Convection button again until the corresponding temperature
is displayed.
3. Turn the dial knob to set the cooking time.
For a cooking time of 11 minutes, turn the dial knob to set
11:00.
(up to 60 minutes can be set)
“11:00” shows in display.
4. Press START/SPEEDY COOK button.
The oven light comes on and the turntable starts rotating.
Cooking starts and the time in the display will count down.
Note: You can check the setting temperature while cooking is in progress by pressing the Convection button.
180°C → 190°C → 200°C → 210°C → 220°C →
40°C → 100°C → 110°C → 120°C →
130°C → 140°C → 150°C → 160°C → 170°C →
Temperature sequence
This function is ideal for cooking meringues, cookies,
biscuits, scones, bread, puddings, large fruit cakes
and all pastries.
Remember the oven will be hot.
Place all food on the metal rack.
Use oven-proof cookware.
As there is no microwave energy being used you can
place metal tins directly onto the metal rack with no
danger of arcing.
Suggested use Cookware
• 40C of convection cooking temperature is adequate for fermenting bread-like foods.
• High temperatures in the inside of oven may reduce the quality of fermentation. Cool it down to the room
temperature before use.
Fermentation
RKW(TOWER)_KOC9C0TBKT(KOC9Q0TTBUB017UBC5)(�)_A5.indd 19 2020-07-17 �� 5:29:30
Table of contents
