*Subject to registering Your Extended Guarantee online at www.towerhouswares.co.uk.
2 in 1
Ceramic Health Grill and Oven
Safety and Instruction Manual
PLEASE READ CAREFULLY
T14009
*Subject to registering Your Extended Guarantee online at www.towerhousewares.co.uk.

2
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
1912 Midland Metal Spinners was founded by
George Cadman, who was then 65 years old, as
a metal holloware manufacturing company, in St.
Mark’s Street, Wolverhampton. They later moved
into the Tower and Fort Works in Pelham Street,
which ultimately gave rise to the famous Tower
brand name.
1937 Tower exhibited some of their latest holloware
designs at the British Industries Fair. As you can
see from the original poster, their stand No. A410
must have been a great sight as it promoted their
“Beautiful, inexpensive, untarnishable Plate, at
prices all can afford to pay”.
1961 Tower became one of the largest
manufacturers of aluminium holloware, electric
kettles, tea pots and other household articles with
over 1,000 employees.
1974 Russell Hobbs took ownership of the
expanding Tower brand.
Healthier, Easier & Cheaper
Enjoy healthy meals cooked to perfection, even
when time is at a premium. Ideal for grilled meat
and sh, and even veg, this stylish and functional
appliance will t neatly into your home.
A non-stick plate makes for easy cleaning and an
integrated grease tray even collects excess fat.
Simmer and keep warm controls are on hand to
ensure your food is cooked with precision.

Safety and Instruction Manual
3
Helpline: [phone]
CONTENTS:
Please read this Manual carefully BEFORE
using the Health Grill for your own safety.
Thank you for purchasing this Tower 2 in 1
Ceramic Health Grill and Oven from the Tower
range.
It has been designed to provide many years of
trouble-free cooking. There are many benets
to using the Tower 2 in 1 Ceramic Health Grill
and Oven:
• Simple to use thermostatic dial for ultimate
temperature control.
• Grill up a tasty breakfast or cook
an evening meal using the easily
interchangeable grill plate.
• Non-stick ceramic stone coated plates
allow you to cook great tasting food
without adding any extra oil.
• Removable, toughened glass lid which
closes to double up as an oven.
• Integrated grease tray to collect any
excess fat.
• Suitable for grilled meat, sh and
vegetables.
Contents:
1. Specications
Components and structure
Technical information
2. ImportantSafetyInformation
3. UsingyourTowerAppliance
4. TroubleShooting&Faq’s
5. Cleaning&Care
6. Recycling
7. WiringSafety
8. WarrantyInformation
9. YourReceipt
SeebackpageforCustomerService
Information

4
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
Components
This box contains:
Removable Toughened Glass Lid
Thermostatic Control
Drip Tray
Non-stick Interchangeable Grill Plate
Instruction Manual
Structureofyourceramichealthgrill:
1. Removable Toughened Glass Lid
2. Handles
3. Thermostatic Control Socket (not shown)
4. Earth Safety Pin (not shown)
5. Non-stick Interchangeable Grill Plate
6. Drip Tray
7. Non Slip Feet
1SPECIFICATIONS:
1
2
3
4
5
6
7
E
a
r
t
h
S
a
f
e
t
y
P
i
n
R
e
m
o
v
a
b
l
e
L
i
d

Safety and Instruction Manual
5
Helpline: [phone]
Technical Data
Description: 2 in 1 Ceramic Health Grill & Oven
Model: T14009
Rated Voltage: 220-240V ~50Hz
Power Consumption: 1800 Watts
Documentation
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2004/108/EC Electromagnetic Compatibility Directive.
2006/95/EC Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food (LFGB section 30 & 31).
RKW Quality Assurance, United Kingdom.
Guarantee
Spare parts are guaranteed for 1 year from date
of purchase.
The main body and housing are guaranteed
for the extended free warranty subject to
registration.
If any defect arises due to faulty materials of
workmanship, the faulty products must be
returned to the place of purchase.
Refund or replacement is at the discretion of
the retailer.
Should you encounter problems or require
a replacement part, contact The Tower
Customer Service Department on:
[phone].
Any necessary spare parts may be ordered
from the Tower website.
Your warranty becomes void should you decide
to use non Tower spare parts. Spare parts can
be purchased from
www.towerhousewares.co.uk

6
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
Please read these notes carefully BEFORE using your Tower appliance
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer,
its service agent or a similarly
qualied person.
• Do not let the cord hang over
the edge of a table or counter
or let it come into contact with
any hot surfaces.
• Do not carry the appliance by
the power cord.
• Do not use any extension cord
with this appliance.
• Do not pull the plug out by the
cord as this may damage the
plug and/or the cable.
• Switch off at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• Switch off and unplug before
tting or removing tools/
attachments, after use and
before cleaning.
• Close supervision is necessary
when any appliance is used by
or near children.
• Children should not play with
the appliance.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Cleaning and user maintenance
should not be undertaken by
children without supervision.
• Take care when any appliance
is used near pets.
• Do not use this product for
anything other than its intended
use.
2IMPORTANTSAFETYINFORMATION

Safety and Instruction Manual
7
Helpline: [phone]
• This appliance is for household
use only.
• Cook meat, poultry, and any
derivatives (mince, burgers, etc.)
until the juices run clear. Cook
sh until the esh is opaque
throughout.
• Do not wrap food in plastic lm,
metal foil or polythene bags.
This will damage the grill plate
and may cause a re hazard.
• Do not use metal implements
or anything sharp as this will
damage the non-stick plates.
Use wooden or plastic spatulas
and tongs.
• Important: Take care of hot
steam escaping when you lift
the lid.
• Always use the drip tray when
cooking.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the service
department:
[phone]

8
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
3USINGYOURAPPLIANCE
• Place the health grill on a at, heat
resistant surface.
• Plug the thermostat into the thermostat
socket.
• Plug the health grill into the wall.
• Adjust the thermostat dial to your desired
setting. The temperature light will illuminate
when the thermostat reaches the required
temperature.
• Once the grill has reached the required
temperature, the thermostat light will go
out. The grill is now ready for use.
• When grilling or frying, use a spatula
to turn your food over frequently whilst
cooking.
• You can choose to cook with the lid
closed in order to use the health grill for
oven cooking.
Thermostat:
Setting 1: On
Setting 2: Keep Warm
Setting 3: Grilling at a low temperature
Setting 4: Grilling at a medium temperature
Setting 5: Grilling at a high temperature
ReversiblePlates:
The 2 in 1 Ceramic Health Grill and Oven has
two cooking areas. The at plate is suitable for
cooking fried eggs and vegetables. The grill
is suitable for cooking meat such as burgers,
chicken and sausages.
To change the plate, lift the reversible plate out
of the base unit, using the black handles on
either side.
Before removing the reversible plate, ensure
that the thermostat is unplugged and removed
from the unit. Make sure that the Health Grill
and Oven is off and has had sufcient time to
cool.
If you have cooked on one side of the reversible
grill plate and would now like to cook on the
other side, it is recommended to wipe the plate
down with a kitchen towel.
To replace the plate align it above the base.
Ensure you have aligned it correctly, with the
thermostat socket on the right. Lower the plate
into place, allowing the earth safety pin to insert
into the corresponding earth
safety connector on the grill
plate. This ensures correct
assembly and a safe earth
connection.
Fittingthelid:
When the lid is tted correctly, it will click into
place, and the latch at the front will be shut.
The glass lid is removable. To remove the lid,
unclip the front latch and move the lid upwards
and away from the back of the unit. On the
back of the unit there are two slats which allow
you to attach and detach the lid.
E
a
r
t
h
S
a
f
e
t
y
P
i
n

Safety and Instruction Manual
9
Helpline: [phone]
It is recommend to familiarise yourself with
removing the lid before using the 2 in 1 Health
Grill and Oven for the rst time. Stand in front of
the back of the Health Grill and Oven to observe
the slats and the movement of the lid.
To stand the lid up during cooking, unclip the
latch and move the lid upwards, as you would
during removal. Once you have lifted the lid
up, instead of moving it
backwards to remove, move
the lid down so it slides down
the standing slats. When the
lid is correctly in place it will
stand securely.
RemovableDripTray:
• Always allow the 2 in 1 Health Grill and
Oven to fully cool before attempting to
remove the drip tray.
• Wearing oven gloves, lift the drip tray out
of the base of the Health Grill and Oven.
• Dispose of grease and fat securely.
• Ensure the drip tray is clean and dry before
returning it to the base of the product.
• For your safety and to reduce the risk of
re, do not use the 2 in 1 Health Grill and
Oven without the drip tray in place.
CookingGuide:
• The following temperature and time
settings are a guide only and will vary
according to individual preferences and
the size/thickness of the food being
cooked. Some thicker items, such as pork
or chicken, which need to be cooked
thoroughly, may benet from being pre-
cooked in an oven or microwave.
• If you are cooking frozen food, please
check the package instructions to see if it
is suitable for grilling.
NOTE: These times are approximate. Times
can vary depending on the thickness and
quantities used.
Do not leave the health grill and oven
unattended whilst cooking.
Food Heat
Setting Approximate Time
Grilled
Sandwich 3 2 – 5 minutes
Peppers
(1/2 inch
wide strips)
3 6 -7 minutes
Whole
mushrooms 3 3 – 4 minutes
Onions (½
inch thick
slices)
3 5 -7 minutes
Whole Fish 3 15 – 20 minutes
Fish Steaks 3 15 minutes
Prawns 3 6 minutes
Chicken
Drumstick 4 35 – 40 minutes
Boneless
Chicken
Breast
4 25 – 30 minutes
Steak 5 3 – 5 minutes (rare)
15 - 20 minutes (well done)
Sausage 5 20 – 25 minutes
Bacon 5 6 – 8 minutes
Kebabs 5 10 – 15 minutes
Burgers 5 10 – 15 minutes
Frozen
Sausages 3 28 minutes
R
e
m
o
v
a
b
l
e
L
i
d

10
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
4TROUBLESHOOTING&FAQ’S
Questions Answers
Do I need to use oil
when cooking?
Some non-fatty meats and veg may requite the addition of a small amount
of oil to assist the non-stick surface.
Do I need to place
my food in the middle
of the grill for it to
cook?
No, the grill plate is heated consistently along its length, so you don’t need
to worry about some food getting more heat than others.
My frozen chicken
breasts are still
pink inside but look
cooked outside.
To make sure that meats and poultry are safely cooked through, be sure to
thaw them before grilling.
My grill is not getting
hot.
Make sure that the power cord is plugged into a suitable outlet.
Check that the thermostat has is set and the temperature light is on.
There is smoke
escaping from my
grill.
When using the grill for the rst time, it may produce some smoke. This is
normal.
Tips:
• Prepare any garnishes you require (lettuce,
tomato, cheese) before you begin grilling
and set to the side.
• Tender cuts of meat are more suitable
for grilling. It is recommended to avoid
cooking tough cuts of meat on your Health
Grill and Oven.
• For best results, cook foods of uniform
thickness together.
• Prepare all vegetable ingredients by
chopping them to roughly the same size
and shape, for even grilling.
• Ensure you turn food frequently during
cooking. Take care as some spitting may
occur.
• Ingredients cut into small pieces will cook
better and quicker than large pieces.

Safety and Instruction Manual
11
Helpline: [phone]
6RECYCLING
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information
about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be recycled,
rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
5CLEANING&CARE
• Never move the appliance whilst it is
switched on or is still hot. Switch off the
appliance, and wait until it has cooled
down before you move it.
• Never immerse the thermostat in water,
or in other liquids. If this happens do not
use the appliance anymore; dispose of the
appliance.
• Never use corrosive or scouring cleaning
agents.
• Make sure that the appliance’s thermostat
socket is completely dry before you use it
again!
• The appliance should be cleaned after
each use
• The connector must be removed before
the appliance is cleaned and that the
appliance inlet must be dried before the
appliance is used again.
• Always remove the plug from the wall
socket and allow the appliance to cool
down completely before you clean it.
• Remove any residues with kitchen paper
towel.
• Clean the thermostat with a damp cloth.
• You can clean other parts in a dishwasher
or hot washing-up water.
• The glass lid can be removed. If you want
to use a dishwasher to clean it, place it on
the top rack to avoid any possible damage
to the glass
Note: Never immerse the power cord’s
thermostat plug in water; always use a damp
cloth.
• Never pour cold water onto the grill plate;
this will damage the grill plate, and the
water will boil and splash
IMPORTANT!
After cleaning allow to dry fully before using
again.
Do not use the appliance if damp. Ensure the
appliance is completely clean and dry before
storing.
Storage
To store your appliance:
Unplug power cord from the power outlet and
clean as above.
Allow the appliance to dry fully.
Store on a at, dry level surface out of reach
of children.

12
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
7WIRINGSAFETYFORUKUSEONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must be
connected to the terminal marked [N] or coloured
black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
The wire coloured green/yellow must be
connected to the terminal marked with the letter
[E] or marked .
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - and then cut it off the mains
lead and immediately dispose of its safely. Never
attempt to reuse the plug or insert it into a socket
outlet as there is a danger of an electric shock.
WARNING:
This Appliance MUST be Earthed
FUSE

Safety and Instruction Manual
13
Helpline: [phone]
8WARRANTY
This product is guaranteed for 12 months from
the date of original purchase.
If any defect arises due to faulty materials of
workmanship, the faulty products must be
returned to the place of purchase.
Refund or replacement is at the discretion of
the retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase.
• The product must be installed and
used in accordance with the instructions
contained in this instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear, damage,
misuse or consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire Only.
The standard one year guarantee is only
extended to the maximum available for each
particular product upon registration of the
product within 28 days of purchase. If you
do not register the product with us
within the 28 day period, your product is
guaranteed for 1 year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and register
with us online. Alternatively, call our customer
registration line on +(44) (0) 844 984 0055.
Please note that length of extended warranty
oered is dependent on product type and
that each qualifying product needs to be
registered individually in order to extend its
warranty past the standard 1 year.
Extended warranty is only valid with proof of
purchase.
Wehopethatyouwillenjoy
yourTowerCeramicHealth
Grillformanyyears.
Asathankyoufor
purchasingoneofour
fantasticproducts,
wearegivingyou3years
peaceofmind.
To receive your 3 year
guarantee, simply register
your appliance
online by visiting
www.towerhousewares.co.uk

14
Register online at www.towerhousewares.co.uk for your FREE extended guarantee.
9 YOUR RECEIPT
Afx your store receipt to this page for safe
keeping.

Safety and Instruction Manual
15
Helpline: [phone]
NOTES

thank you!
We hope you enjoy your appliance for
many years. As a thank you for purchasing
one of our fantastic products, we are giving
you an extra 2 years peace of mind.
*To receive your extra 2 years guarantee,
register your appliance online by visiting:
www.towerhousewares.co.uk
Should you have a problem with your
appliance, or need any spare parts,
please call our Service Department on:
[phone]
great british design, innovation and excellence since 1912
0815.V1
Your warranty becomes void should you decide
to use non Tower spare parts. Spare parts can be
purchased from www.towerhousewares.co.uk
