Toyota 4Runner 1999 User manual

For your safety and comfort,
read carefully and keep in the vehicle.

4RUNNER (ᝌᛆ)
i
Foreword
Welcome to the growing group of value−conscious people who drive Toyotas. We
are proud of the advanced engineering and quality construction of each vehicle we
build.
This Owner’s Manual explains the features of your new Toyota. Please read it and
follow the instructions carefully so that you can enjoy many years of safe motoring.
When it comes to service, remember that your Toyota dealer knows your vehicle
best and is interested in your complete satisfaction. He will provide quality mainte-
nance and any other assistance you may require.
Please leave this Owner’s Manual in this vehicle at the time of resale. The next
owner will need this information also.
All information and specifications in this manual are current at the time of
printing. However, because of Toyota’s policy of continual product improve-
ment, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
©1998 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in
part, without the written permission of Toyota Motor Corporation.

4RUNNER (ᝌᛆ)
ii
New vehicle warranty
Your new vehicle is covered by the following Toyota
limited warranties:
DNew vehicle warranty
DEmission control systems warranty
DOthers
For further information, please refer to the separate
"Owner’s Warranty Information Booklet" or "Owner’s
Manual Supplement".
Your responsibility for maintenance
It is owner’s responsibility to make sure that the speci-
fied maintenance is performed. Part 6 gives details of
these maintenance requirements. Also included in Part 6
is general maintenance. For scheduled maintenance in-
formation, please refer to the separate "Scheduled Main-
tenance Guide" or "Owner’s Manual Supplement".
Accessories, spare parts and
modification of your Toyota
A wide variety of non−genuine spare parts and accesso-
ries for Toyota vehicles are currently available in the
market. You should know that Toyota does not warrant
these products and is not responsible either for their
performance, repair or replacement, or for any damage
they may cause to, or adverse effect they may have on,
your Toyota vehicle.
This vehicle should not be modified with non−genuine
Toyota products. Modification with non−genuine Toyota
products could affect its performance, safety or durabili-
ty, and may even violate governmental regulations. In
addition, damage or performance problems resulting from
the modification may not be covered under warranty.

4RUNNER (ᝌᛆ)
iii
Spark ignition system of your
Toyota
The spark ignition system in your Toyota meets all re-
quirements of the Canadian Interference−Causing Equip-
ment Standard.
Installation of a mobile
two−way radio system
As the installation of a mobile two−way radio system in
your vehicle could affect electronic systems such as
multiport fuel injection system/sequential multiport fuel
injection system, cruise control system, anti−lock brake
system, SRS airbag system and seat belt pretensioner
system, be sure to check with your Toyota dealer for
precautionary measures or special instructions regarding
installation.
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in
your Toyota contain explosive chemicals. If the vehicle
is scrapped with the airbags and pretensioners left as
they are, it may cause an accident such as a fire. Be
sure to have the systems of the SRS airbag and seat
belt pretensioner removed and disposed of by a qualified
service shop or by your Toyota dealer before you dis-
pose of your vehicle.
On−pavement and off−road
driving tips
This vehicle will handle and maneuver differently from
an ordinary passenger car because it is also designed
for off−road use. As with other vehicles of this type,
failure to operate this vehicle correctly may result in
loss of control or an accident. Be sure to read "Off−
road vehicle precautions" in Part 2 and "Off−road driving
precautions" in Part 3.

4RUNNER (ᝌᛆ)
iv

4RUNNER (ᝌᛆ)
v
Part
1 OPERATION OF INSTRUMENTS AND CONTROLS
Chapter Page
1−1 Overview of instruments and controls 1. . . . . . . . . . . . . . . . . . . . . . . .
1−2 Keys and Doors 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1−3 Seats, Seat belts, Steering wheel and Mirrors 33. . . . . . . . . . . . . . . .
1−4 Lights, Wipers and Defogger 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1−5 Gauges, Meters and Service reminder indicators 85. . . . . . . . . . . . .
1−6 Ignition switch, Transmission and Parking brake 93. . . . . . . . . . . . .
1−7 Car audio system and Air conditioning system 117. . . . . . . . . . . . . . .
1−8 Other equipment 161. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 INFORMATION BEFORE DRIVING YOUR TOYOTA 171. . . . . . . . . .
3 STARTING AND DRIVING 185. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 IN CASE OF AN EMERGENCY 197. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 CORROSION PREVENTION AND APPEARANCE CARE 217. . . . .
6 VEHICLE MAINTENANCE AND CARE 223. . . . . . . . . . . . . . . . . . . . . . .
7 DO−IT−YOURSELF MAINTENANCE
Chapter
7−1 Introduction 229. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7−2 Engine and Chassis 237. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7−3 Electrical components 247. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 SPECIFICATIONS 259. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 REPORTING SAFETY DEFECTS FOR U.S. OWNERS
AND UNIFORM TIRE QUALITY GRADING 267. . . . . . . . . . . . . . . . . . .
10INDEX 269. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4RUNNER (ᝌᛆ)
vi
Important information about this manual
Safety and vehicle damage warnings
In this manual, you will see CAUTION and NOTICE warn-
ings. These are used in the following ways:
CAUTION
This is a warning against something which may cause
injury to people if the warning is ignored. You are
informed what you must or must not do in order to
avoid or reduce the risk to yourself and other people.
NOTICE
This is a warning against something which may cause
damage to the vehicle or its equipment if the warning
is ignored. You are informed what you must or must
not do in order to avoid or reduce the risk of damage
to your vehicle and its equipment.
Safety symbol
In this manual, you will also see a circle
with a slash through it. This means "Do
not", "Do not do this", or "Do not let this
happen".

4RUNNER (ᝌᛆ)
1
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS
Chapter 1−1
Overview of instruments
and controls
DInstrument panel overview
DInstrument cluster overview
DIndicator symbols on the
instrument panel

4RUNNER (ᝌᛆ
)
2
Instrument panel overview
1. Side vents
2. Tilt steering lock release lever
3. Instrument cluster
4. Center vents
5. Garage door opener box or eyeglass
holder
6. Electric moon roof switch
7. Personal lights
8. Glove box
9. Power door lock switches
10. Power window switches
11. Automatic transmission selector lever
or manual transmission gear shift lever
12. Parking brake lever
13. Front drive control lever
14. Lower vent
15. Hood lock release lever
16. Fuel filler door opener
17. Power rear view mirror control switch
(with power windows)

4RUNNER (ᝌᛆ)
3
1. Clutch start cancel switch
2. Headlight and turn signal switch, and
front fog light switch
3. Wiper and washer switches
4. Back window and rear view mirror de-
foggers switch
5. Driving pattern selector button
6. Clock
7. Emergency flasher switch
8. Power back window switch
9. Theft deterrent system/Engine immobi-
liser system indicator light
10. Front passenger’s seat belt reminder
light
11. Air conditioning controls
12. Car audio
13. Ashtray
14. Power outlets
15. Cigarette lighter
16. "OUT/T" (outside temperature) button
17. Ignition switch
18. Cruise control switch
19. Rear differential lock switch
20. Instrument panel light control knob
21. Power rear view mirror control switch
(without power windows)

4RUNNER (ᝌᛆ
)
4
22. Power back window lock button
(without power windows)
23. Back door lock switch (without power
door lock)

4RUNNER (ᝌᛆ)
5
Instrument cluster overview
1. Service reminder indicators and
indicator lights
2. Engine coolant temperature gauge
3. Tachometer
4. Speedometer
5. Odometer and two trip meters
6. Fuel gauge
7. Trip meter reset knob

4RUNNER (ᝌᛆ
)
6
Indicator symbols on the instrument panel
(type A)
(type B)
Driver’s seat belt reminder light∗1
Low oil pressure warning light∗1
Low fuel level warning light∗1
Brake system warning light∗1
Malfunction indicator lamp∗1
Discharge warning light∗1
Anti−lock brake system warning light∗1
Automatic transmission fluid temperature
warning light∗1
SRS airbag warning light∗1
Unengaged "Park" warning light∗1
Open door warning light∗1
Low windshield washer fluid level warning
light∗1
Headlight high beam indicator light
Overdrive−off indicator light
Turn signal indicator lights
Automatic transmission indicator light
Front passenger’s seat belt reminder light∗1

4RUNNER (ᝌᛆ)
7
Cruise control indicator light∗2
Driving pattern ("PWR" mode) indicator light
Four−wheel drive indicator light
Rear differential lock indicator light
∗1:For details, see "Service reminder indicators and warning
buzzers" in Chapter 1−5.
∗2:If this light flashes, see "Cruise control" in Chapter 1−6.
Four−wheel drive indicator light

4RUNNER (ᝌᛆ
)
8

4RUNNER (ᝌᛆ)
9
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS
Chapter 1−2
Keys and Doors
DKeys
DEngine immobiliser system
DSide doors
DPower windows
DPower backwindow
DBack door
DHood
DTheft deterrent system
DFuel tank cap
DElectric moon roof
Your vehicle is supplied with two kinds
of key.
1. Master keyThis key works in every
lock.
2. Sub keyThis key will not work in the
glove box.
To protect things locked in the glove box
when you have your vehicle parked, leave
the sub key with the attendant.
Since the doors can be locked without a
key, you should always carry a spare
master key in case you accidentally lock
your keys inside the vehicle.
KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend you to write down the key
number and keep it in safe place.
Keys
(without engine immobiliser
system)

4RUNNER (ᝌᛆ
)
10
Your vehicle is supplied with the two
kinds of key.
1. Master key (black)This key works in
every lock. Your Toyota dealer will
need it to make you a new key with
built−in transponder chip.
2. Sub key (gray)This key does not
work in the glove box.
The master key and sub key each have
a transponder chip in their key head
which is very important for the system
function, so be careful not to lose these
keys. If you make your own duplicate key,
you will not be able to cancel the system
or start the engine.
To protect things locked in the glove box
when you have your vehicle parked, leave
the sub key with the attendant.
Since the side doors can be locked with-
out a key, you should always carry a
spare master key in case you accidentally
lock your keys inside the vehicle.
For information on use of the wireless
remote control key, see "Side doors" in
this chapter.
NOTICE
When using a key containing a trans-
ponder chip, observe the following
precautions:
zWhen starting the engine, do not
use the key with a key ring resting
on the key grip and do not press
the key ring against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts.
Keys
(with engine immobiliser
system)

4RUNNER (ᝌᛆ)
11
zWhen starting the engine, do not
use the key with other transponder
keys around (including keys of oth-
er vehicles) and do not press other
key plates against the key grip.
Otherwise the engine may not start,
or may stop soon after it starts. If
this happens, remove the key once
and then insert it again after taking
off other transponder keys (includ-
ing keys of other vehicles) from the
ring or while gripping or covering
them with your hand to start the
engine.
zDo not bend the key grip.
zDo not cover the key grip with any
material that cuts off electromagnet-
ic waves.
zDo not knock the key hard against
other objects.
zDo not leave the key exposed to
high temperatures for a long period,
such as on the dashboard and hood
under the direct sunlight.
zDo not put the key in water or
wash it in an ultrasonic washer.
zDo not use the key with electromag-
netic materials.

4RUNNER (ᝌᛆ
)
12
KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend you to write down the key
number and keep it in safe place.
Engine immobiliser system
The engine immobiliser system is a
theft prevention system. When you in-
sert the key in the ignition switch, the
transponder chip in the key’s head
transmits an electronic code to the ve-
hicle. The engine will start, only when
the electronic code in the chip corre-
sponds to the registered ID code for
the vehicle.
The system is automatically set when the
key is removed from the ignition switch.
The indicator light will start flashing every
2 seconds to show the system is set.
If either of the following indicator condi-
tions occurs, contact your Toyota dealer.
DThe indicator light stays on except
when the theft deterrent system is set-
ting or activating. (See Theft deterrent
system.)
DThe indicator light does not start flash-
ing when the key is removed from the
ignition switch.
DThe indicator light flashes unsteady.

4RUNNER (ᝌᛆ)
13
Inserting the registered key in the ignition
switch automatically cancels the system,
which enables the engine to start. The
indicator light will go off.
For your Toyota dealer to make you a
new key with built−in transponder chip,
your dealer will need your key number
and master key. However, there is a limit
to the number of additional keys your
Toyota dealer can make for you.
If you make your own duplicate key,
you will not be able to cancel the sys-
tem or start the engine.
For vehicles sold in U.S.A.
FCC ID: MOZ RI−4BTY
MADE IN JAPAN
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
For vehicles sold in Canada
This device complies with RSS−210 of
Industry Canada. Operation is subject to
the following two conditions:
(1) This device may not cause interfer-
ence, and (2) this device must accept
any interference, including interference
that may cause undesired operation of
the device.
