Toyota 4RUNNER 2010 User manual

TABLE OF CONTENTS Index
2
1-1. Key information
Keys ..................................... 30
1-2. Opening, closing and
locking the doors
Smart key system................. 33
Wireless remote control ....... 47
Side doors ............................ 51
Back door ............................. 56
1-3. Adjustable components
(seats, mirrors,
steering wheel)
Front seats ........................... 61
Rear seats............................ 65
Head restraints..................... 76
Seat belts ............................. 79
Steering wheel ..................... 86
Inside rear view mirror.......... 87
Outside rear view mirrors ..... 89
1-4. Opening and closing the
windows and moon roof
Power windows .................... 91
Power back window ............. 94
Moon roof ............................. 98
1-5. Refueling
Opening the fuel tank
cap ................................... 102
1-6. Theft deterrent system
Engine immobilizer
system .............................. 106
Alarm .................................. 109
Theft prevention labels
(for U. S. A.) ..................... 111
1-7. Safety information
Correct driving posture ....... 112
SRS airbags ....................... 114
Front passenger occupant
classification system......... 129
Child restraint systems ....... 135
Installing child restraints ..... 139
2-1. Driving procedures
Driving the vehicle .............. 154
Engine (ignition) switch
(vehicles without a
smart key system) ............ 164
Engine (ignition) switch
(vehicles with a smart
key system) ...................... 167
Automatic transmission ...... 173
Turn signal lever ................. 179
Parking brake ..................... 180
Horn.................................... 181
1Before driving
2When driving
Information Provided by:

1
2
3
4
5
6
7
3
2-2. Instrument cluster
Gauges and meters ............ 182
Indicators and warning
lights ................................. 189
Accessory meter ................. 194
2-3. Operating the lights and
wipers
Headlight switch.................. 198
Fog light switch ................... 204
Windshield wipers and
washer .............................. 205
Rear window wiper and
washer .............................. 207
2-4. Using other driving
systems
Cruise control...................... 209
Intuitive parking assist......... 213
Rear view monitor system
(rear view mirror-attached
type).................................. 218
Four-wheel drive system
(part-time 4WD models).... 223
Four-wheel drive system
(full-time 4WD models) ..... 226
Active traction control
system .............................. 230
AUTO LSD system
(2WD models)................... 232
Rear differential lock
system .............................. 235
Downhill assist control
system .............................. 238
Crawl Control ...................... 241
Multi-terrain Select .............. 245
Driving assist systems ........ 253
2-5. Driving information
Off-road precautions........... 262
Cargo and luggage............. 267
Vehicle load limits............... 273
Winter driving tips............... 275
Trailer towing...................... 280
Dinghy towing..................... 293
3-1. Using the air conditioning
system and defogger
Manual air conditioning
system.............................. 296
Automatic air conditioning
system.............................. 302
Rear window and
outside rear view
mirror defoggers............... 310
Windshield wiper de-icer .... 312
3-2. Using the audio system
Audio system types ............ 313
Using the radio ................... 317
Using the CD player ........... 324
Playing MP3 and WMA
discs ................................. 333
Operating an iPod®............ 341
Operating a USB
memory ............................ 348
Optimal use of the audio
system.............................. 355
Using the AUX adapter....... 360
Using the steering wheel
audio switches.................. 361
3Interior features
Information Provided by:

TABLE OF CONTENTS Index
4
3-3. Using the Bluetooth®
audio system
Bluetooth®audio system.... 364
Using the Bluetooth®
audio system.................... 367
Operating a Bluetooth®
enabled portable
player ............................... 372
Setting up a Bluetooth®
enabled portable
player ............................... 374
Bluetooth®audio system
setup ................................ 379
3-4. Using the hands-free
phone system
(for cellular phone)
Hands-free phone system
(for cellular phone)
features ............................ 380
Using the hands-free
phone system
(for cellular phone) ........... 384
Making a phone call ........... 392
Setting a cellular phone...... 396
Security and system
setup ................................ 401
Using the phone book ........ 405
3-5. Using the interior lights
Interior lights list ................. 413
• Interior lights .................... 414
• Personal lights ................. 414
3-6. Using the storage features
List of storage features ....... 416
• Glove box ......................... 417
• Console box ..................... 418
• Coin holder ....................... 419
• Tissue pocket ................... 420
• Pen holder ........................ 421
• Auxiliary box ..................... 422
• Cup holders ...................... 423
• Bottle holders ................... 427
3-7. Other interior features
Sun visors........................... 429
Vanity mirrors ..................... 430
Clock................................... 431
Outside temperature
display .............................. 433
Power outlets (12V DC)...... 436
Power outlets (120V AC) .... 439
Seat heaters ....................... 446
Armrest ............................... 448
Floor mat ............................ 449
Compass ............................ 450
Luggage compartment
features ............................ 456
Garage door opener ........... 462
Safety Connect ................... 469
Information Provided by:

1
2
3
4
5
6
7
5
4-1. Maintenance and care
Cleaning and protecting
the vehicle exterior............ 478
Cleaning and protecting
the vehicle interior............. 481
4-2. Maintenance
Maintenance
requirements..................... 484
General maintenance.......... 486
Emission inspection and
maintenance (I/M)
programs........................... 490
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ....................... 491
Hood ................................... 494
Engine compartment........... 495
Tires .................................... 514
Tire inflation pressure ......... 520
Wheels ................................ 524
Air conditioning filter............ 526
Wireless remote control/
electronic key battery........ 528
Checking and replacing
fuses ................................. 531
Light bulbs........................... 541
5-1. Essential information
Emergency flashers............ 554
If your vehicle needs to
be towed........................... 555
If you think something is
wrong ............................... 561
Fuel pump shut off
system.............................. 562
Event data recorder............ 563
5-2. Steps to take in an
emergency
If a warning light turns on
or a warning buzzer
sounds.............................. 565
If you have a flat tire ........... 578
If the engine will not start.... 590
If the shift lever cannot
be shifted from P .............. 592
If you lose your keys........... 594
If you cannot operate
back door opener ............. 595
If the electronic key does
not operate properly
(vehicles with a smart
key system) ...................... 596
If the vehicle battery is
discharged........................ 598
If your vehicle overheats .... 603
If the vehicle becomes
stuck................................. 606
4Maintenance and care 5When trouble arises
Information Provided by:

TABLE OF CONTENTS Index
6
6-1. Specifications
Maintenance data
(fuel, oil level, etc.) ........... 610
Fuel information ................. 623
Tire information .................. 626
6-2. Customization
Customizable features ....... 638
6-3. Initialization
Items to initialize................. 644
Reporting safety defects
for U.S. owners ................ 646
Seat belt instructions
for Canadian owners
(in French)........................ 647
Abbreviation list........................ 650
Alphabetical index .................... 652
What to do if... .......................... 661
6Vehicle specifications
7For owners
Index
Information Provided by:

1
2
3
4
5
6
7
7
Information Provided by:

CUSTOMER EXPERIENCE CENTER
1-80 0 - 331-4331
00505-QRG10-4RUN
Printed in U.S.A. 9/09
08-TCS-03067
413623M1.indd 2 9/8/09 11:19:05 AM
QUICK REFERENCE
GUIDE
4RUNNER
2010
413623M1.indd 1 9/8/09 11:18:59 AM
Information Provided by:

2010
4Runner
!A word about safe vehicle operations
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental
operations so you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for
the Owner’s Manual located in the vehicle’s glove box. We
strongly encourage you to review the Owner’s Manual and
supplementary manuals so you will have a better understanding
of the vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota Motor Sales,
U.S.A., Inc. wish you many years of satisfied driving in your
new 4Runner.
This Quick Reference Guide is not a full description of
4Runner operations. Every 4Runner owner should review the
Owner’s Manual that accompanies this vehicle.
Pay special attention to the boxed information highlighted in
color throughout the Owner’s Manual. Each box contains safe
operating instructions to help you avoid injury or equipment
malfunction.
All information in this Quick Reference Guide is current at
the time of printing. Toyota reserves the right to make
changes at any time without notice.
25
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Moving the lever to “LOCK” will allow the door to be opened only from
the outside.
Doors-Child safety locks
Rear door
Sparetire&tools
Tool location
Removing the spare tire
(1) Assemble the jack handle.
(2) Insert the jack handle end through the opening in the bumper, and into
the lowering screw.
(3) Turn the jack handle counterclockwise.
Refer to the Owner’s Manual for tire changing and jack positioning
procedures.
Tool bag
Jack
(1)
(2)
(3)
Spare tire
Information Provided by:

1
Engine maintenance 8
Fuel tank door and cap 6
Hood release 8
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry
1
6
Smart Key system17
Air Conditioning/Heating 18-19
Audio 20-21
Auto lock functions1,2 9
Automatic Transmission 9
Bluetooth
®
audio 23
Clock 14
Cruise control 17
Four-wheel drive 10
Garage door opener (HomeLink
®
)
3
19
iPod
®
/USB/AUX audio jack 21
Light control-Instrument panel 15
Lights1& turn signals 16
Moonroof114
Parking brake 9
Power outlets-12V DC 23
Power outlets-120V AC 22
Seat adjustments-Front 11
Seat adjustments-Second row seats 11
Seat heaters 18
Seats-Folding down second row seats 12
Seats-Head restraints 13
Seats-Returning third row seats 13
Seats-Stowing third row seats 13
Telephone controls (Bluetooth
®
)22
Tilt and telescopic steering wheel 10
VSC OFF button 15
Windows114
Window-Back window115
Windshield wipers & washers
17
Door locks 24
Doors-Child safety locks 25
Seat belts 24
Seat belts-Shoulder belt anchor 24
Sparetire&tools 25
Tire Pressure Monitoring (warning) System 24
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND
EMERGENCY FEATURES
INDEX
1Visit your Toyota dealer for information on customizing this feature.
2Programmable by customer. Refer to the Owner’s Manual for instructions and
more information.
3HomeLink®is a registered trademark of Johnson Controls, Inc.
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Information Provided by:

Power rearview mirror controls
Instrument panel light control
Intuitive parking assist switch and indicator1
Tilt and telescopic steering lock release
“RSCA OFF” (Roll Sensing of Curtain shield Airbags “OFF”) switch
120V AC Power outlet ON/OFF switch1
Windshield wiper de-icer switch1
Headlight, turn signal and front fog light1control
Wiper and washer controls
Accessory meter/Outside temperature display
Emergency flasher switch
Audio system1or navigation system2
Back window and outside rearview mirror defoggers switch
Front passenger seat belt reminder light
Front passenger occupant classification indicator
Engine immobilizer/Theft deterrent system indicator1
12V DC Power outlet
2
OVERVIEW
Instrument panel
Steering wheel controls
Center console box
Without Smart Key system
With Smart Key system
Manual Air
Information Provided by:

3
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
USB adapter1
AUX adapter
Four-wheel drive selector1
Hood release
Steering wheel audio controls1,2
Voice command button1,2
Telephone switches1,2
Ignition switch (standard key)/“ENGINE START STOP” button (Smart Key)1
Party mode switch
Cruise control1
Seat heater switch1
120V AC Power outlet1
Power back window switch
1If equipped
2For vehicles with a navigation system, refer to the “Navigation System
Owner’s Manual.”
Conditioning Automatic Air Conditioning 2WD models
Part-time 4WD models
Full-time 4WD models
Information Provided by:

4
OVERVIEW
Low Tire Pressure Warning1
Open door warning1
Airbag SRS warning1
Tachometer
Speedometer
Display change button
Engine coolant temperature
Fuel gauge
Eco driving indicator zone display
Odometer, trip meter and average fuel consumption display
Shift position and shift range indicators
Voltmeter
Instrument cluster
Charging system warning1
Low engine oil pressure warning1
Brake system warning1
Malfunction/Check Engine indicator1
Engine oil replacement reminder1
Indicator symbols
Driver/Front passenger seat belt reminder1
(alarm will sound if speed is over 12 mph)
Optitron type meters
AIR BAG ON and AIR BAG OFF indicator
Turn signal indicator
Headlight low/high beam indicator
1For details, refer to “If a warning light turns on or a warning buzzer sounds...” Section 5-2,
2010 Owner’s Manual.
2For details, see “SRS airbags” Section 1-7, 2010 Owner’s Manual.
Low fuel level warning1
Non-Optitron type meters
Information Provided by:

5
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Automatic Transmission fluid temperature warning1
Crawl Control indicator
Front fog light indicator
Four-wheel drive indicator3
Low speed four-wheel drive indicator3
Center differential lock indicator3
Slip indicator1
Vehicle Stability Control OFF indicator
Downhill Assist Control indicator
AUTO Limited Slip Differential indicator
Cruise control/Cruise control SET indicator4
Roll Sensing of Curtain shield Airbag OFF indicator2
Engine immobilizer/Theft deterrent system indicator
Anti-lock Brake System warning1
3If this light flashes, refer to “Four-wheel drive system,” Section 2-4, 2010 Owner’s Manual.
4If this light flashes, refer to “Cruise control,” Section 2-4, 2010 Owner’s Manual.
Multi-terrain select
Rear differential lock indicator
Active traction control indicator
Power steering system warning
1
Kinetic Dynamic Suspension System indicator1
Unengaged Park warning light
1
Smart Key system warning
Intuitive parking assist indicator
Eco driving indicator light
Traction Control OFF indicator
Information Provided by:

6
OVERVIEW
Fuel tank door and cap
Pull
Tu r n
NOTE: Tighten until one click is heard. If the cap is not properly sealed,
Check Engine “ ” indicator may illuminate.
Keyless entry
Locking
Unlocking
Panic button
Push and hold
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will
relock for safety.
Push ONCE: Driver door
TWICE: All doors
Push
Without Smart Key system With Smart Key system
Without Smart Key system With Smart Key system
Information Provided by:

7
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Smart Key system (if equipped)
Start function
Accessories such as the radio will operate.
Power ON; the engine not running.
All systems OFF.
ACCESSORY
ON
OFF
NOTE: Gear shift lever must be in Park and brake pedal depressed.
Push
Depress
brake pedal
Carrying
Green indicator ON
Without depressing the brake pedal, pressing the “ENGINE START STOP”
switch will change the operation mode in succession from:
* Driver door unlocking function can be programmed to unlock driver door
only, or all doors. Grasping passenger door handle will unlock all doors.
NOTE: Doors may also be locked/unlocked using remote.
Power (without starting engine)
Push
Unlock
Push
Lock
Locking Unlocking
Carry remote to unlock
Front door lock Front door unlock*
Grasp
Carry remote to lock/unlock/open
Back door lock/unlock/open
Carry remote to lock
To u c h
Open
Push
Information Provided by:

8
Windshield and back window washer fluid tank
Power steering fluid reservoir
Engine oil level dipstick
Engine coolant reservoir
Engine oil filler cap
NOTE: Regularly scheduled maintenance, including oil changes, will
help extend the life of your vehicle and maintain performance.
Please refer to the “Warranty Maintenance Guide.”
Engine maintenance
Hood release
Pull
Pull up latch and
raise hood
OVERVIEW
Information Provided by:

9
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
FEATURES/OPERATIONS
Automatic Transmission
* The engine/“ENGINE START STOP” switch must be “ON” and the brake
pedal depressed to shift from Park.
Downshifting increases power going uphill, or provides engine braking
downhill. For best fuel economy during normal driving conditions, always
drive with the shift lever in the “D” position.
Floor shift type:
+: Upshift (push and release)
-: Downshift (pull and release)
“S” (Sequential) mode
Shift the shift lever to “S” position from “D” position.
Park*
Reverse
Neutral
Drive
P
R
N
D
“S” mode
Auto lock functions
Automatic door locks can be programmed to operate in four different
modes, or turned OFF.
-Doors lock when shifting from Park.
-Doors lock when the vehicle speed is approximately 12 mph or higher.
-Doors unlock when shifting into Park.
-Doors unlock when the driver’s door is opened within 10 seconds after
turning the “ENGINE START STOP” switch or engine switch OFF.
Refer to the Owner’s Manual for more details.
Parking brake
Set: Depress
Release: Depress again
BRAKE BRAKE
Information Provided by:

10
Four-wheel drive (if equipped)
H2
Full-time four-wheel drive models
High speed (2WD)
High speed (4WD)
Turn to “H4” with speed
below 50 mph.
Low speed (4WD)
Shift to “N” position,
then push and turn to
“L4.”
High speed
(center differential locked)
Low speed
(center differential locked)
Shift to “N” position, then
push and turn to “L4L.”
H4L
L4L
Part-time four-wheel drive models
Neutral
High speed
H4F
FEATURES/OPERATIONS
Tilt and telescopic steering wheel
Hold wheel, push lever down, set angle and length, and return lever.
NOTE: Do not attempt to adjust while the vehicle is in motion.
Lock release lever
Length
Angle
Information Provided by:

11
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Seat position (forward/backward)
Height crank (driver side only)
Seatback angle
Lumbar support (driver side only)
Driver seat: seat position, cushion angle and height
Passenger seat: seat position (forward/backward)
Seatback angle
Lumbar support (driver side only)
Seat adjustments-Front
Manual seat Power seat
Seat adjustments-Second row seats
Seat position (forward/backward)
Seatback angle
Vehicles with third row seats Vehicles without third row seats
Information Provided by:

12
FEATURES/OPERATIONS
(1) Push
(2) Lower
(4) Pull up
Seats-Folding down second row seats
(3) Stow
(6) Fold down
(5) Push down
(1) Push
(2) Lower
(3) Stow
(5) Fold down
(4) Pull up
Without third row seats
With third row seats
Information Provided by:
