i
Important information about this manual
For safety reasons, this manual indicates
items requiring particular attention with the
following marks.
CAUTION
This is a warning against something
that may cause injury to people if the
warning is ignored. You are informed
about what you must or must not do in
order to avoid or reduce the risk to
yourself and other people.
NOTICE
This is a warning against something
which may cause damage to the ve-
hicle or its equipment if the warning is
ignored. You are informed about what
you must or must not do in order to
avoid or reduce the risk of damage to
your vehicle and its equipment.
INFORMATION
This provides additional information.
Initial screen
UN001
When you start the engine or turn the ignition
key to ”ACC”, the initial ”TOYOTA” screen
appears and the system begins operating.
CAUTION
When the vehicle is stopped with the
engine running, always apply the park-
ing brake for safety.
After a few seconds, the ”CAUTION” screen
appears.

ii
UN002
Please read it and follow the instructions.
If a screen other than for the navigation sys-
tem is displayed (i.e., for the trip information
screen), the current screen would change to
the ”CAUTION” screen by pushing the
”MAP/VOICE”, ”DEST” or ”MENU”
button on the bezel or by touching the
”Maintenance” switch on the informa-
tion menu screen.
When you touch the ”I agree” switch on
the screen, the ”map” screen appears.

iii
Safety Instruction
UN003
To use your system as safely as possible, fol-
low all the safety tips shown below.
This system is intended to assist you in
reaching your destination and, if used prop-
erly, can do so. You, as the driver, are solely
responsible for the safe operation of your ve-
hicle and the safety of your passengers.
Do not use any feature of this system to the
extent it distracts you from safe driving. Your
first priority while you are driving should al-
ways be the safe operation of your vehicle.
While you are driving, be sure to observe all
traffic regulations.
Before attempting to use this system while
you are driving, learn how to use it and be-
come thoroughly familiar with it. Read the
entire Navigation System Manual to make
sure you understand the system. Do not al-
low others to use this system until they have
read and understood these and other in-
structions in this manual.
For your safety, some functions may become
inoperable when you start driving. Unavail-
able switches are dimmed. You can input
your destination and select your route only
when the vehicle is not moving.
CAUTION
DFor safety, the driver should not
operate the navigation system while
he/she is driving. Inattention to the
road and traffic may cause an
accident.
DWhile you are driving, be sure to
follow the traffic regulations and
keep the road condition in mind. If a
traffic sign on the road has been
changed, route guidance may
provide wrong information such as
the direction of a one way street.

iv
While you are driving, listen to the voice in-
structions as much as possible and glance at
the screen briefly and only when it is safe.
However, do not totally rely on voice guid-
ance. Use it just for your information. If the
system cannot determine your current posi-
tion correctly, there is a possibility of incor-
rect, late or non−voice guidance.
The data in the system may occasionally be
incomplete. Road conditions, including driv-
ing restrictions (no left turns, street closures,
etc.) frequently change. Therefore, before
you follow an instruction from the system,
look to see whether you can comply with the
instruction safely and legally.
This system cannot warn you about such
things as the quality of a neighborhood, con-
dition of streets, and availability of emergen-
cy services. If you are unsure about the safe-
ty of an area, don’t drive into it. Under no
circumstances is this system a substitute
for the driver’s personal judgement.
We recommend that you obtain updated
map data, when it becomes available, in or-
der to help use the system as effectively and
safely as possible.
Use this system only in locations where it is
legal to do so. Some states/provinces may
have laws prohibiting video screens within
sight of the driver.

v
Overview of Touch Screen and Switches
Switch operation
This system operates mainly by the
switches on the screen. To protect the
screen, lightly touch switches on the
screen with your finger. When you touch
a switch on the screen or push the button,
a beep sounds.
INFORMATION
DIf the system does not respond to a
touch of a switch, move your finger
away from the screen and then touch
it again.
DYou cannot operate dimmed
switches.
DWipe off fingerprints on the surface
of the display using a glass cleaning
cloth.
DThe displayed image may become
darker and moving images may be
slightly distorted when the display is
cold.

UNC001
INFO button
Push this button to display the
information menu screen. For
details, see page 68.
MAP/VOICE button
Push this button to repeat a
voice guidance, cancel the one
touch scroll and start a guid-
ance. For details, see page 23.
DEST button
Push this button to display the
Destination screen. For de-
tails, see page 4.
MENU button
Push this button to display the
menu screen. This screen al-
lows you to make adjustments
or correct settings of various
options and functions.
North−up symbol and scale
of map
To indicate a map view with
North up. Touching this sym-
bol changes the map view to a
heading−up respective. The
figure also indicates the map
scale. For details, see page
34.
GPS (Global Positioning
System) mark
Whenever your vehicle is re-
ceiving signals from the GPS,
this mark is displayed. For de-
tails, see page 35.
Current vehicle position
mark
To indicate the current position.
For details, see page 22.
Map/Guide
Push this switch to change the
screen mode. For details, see
page 20.
zoom IN/zoom OUT
These switches magnify or re-
duce the map scale. For de-
tails, see page 33.
vi
Symbols, Switches and Buttons
Changing the route
guidance
s−007u
When you touch this switch, the Change
Route screen will appear. For details, see
page 21.

vii
One −touch registra-
tion of marked point
s−008u
To register the current vehicle position as a
marked point. For details, see page 56.
Display of point of
interest
s−009u
Symbols such as restaurants and hotels, etc.
can be displayed on the screen. For details,
see page 29.
Deletion of point of
interest
s−010u
Symbols such as restaurants and hotels, etc.
displayed on the screen can be deleted. For
details, see page 29.
Heading−up symbol
and scale of map
On the map, the vehicle travel direction is up.
The red arrow indicates North. Touching this
symbol directly on the screen changes the
map to North−up. For details, see page 34.

SECTION I
1
BASIC FUNCTIONS
Descriptions of basic operations in frequent use
Inputting letters and numbers 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to move the cursor 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination input Explains 10 ways to input your destination 4. . . . . . . . . . . . .
Explains 10 ways to input your destination
Entering destination 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Route guidance screen 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current position display 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voice guidance 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Typical voice guidance prompts 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Registration of your home 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Detour setting 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying points of interest 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn list 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Guidance screen 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen scrolling 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Orientation of the map 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limitations of the navigation system 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map database information and updates 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2
The navigation system operates by
switches on the screen and on the bezel.
When you touch a switch, a beep sounds.
When using the switches on the touch
screen, please use only light pressure
with your finger to protect the screen
from damage. Do not use objects other
than your finger to touch the screen.
UN005
To type in an address etc., directly touch al-
phabet keys on the screen. If you touch a
wrong letter, delete it using the switch.
Touching the switch erases one letter.
Touching the ”List” switch will change the
screen to a display of the database items that
match the name or address that you have
entered on the screen. The number of
matching items is shown to the right side of
the screen. If the matching item is more than
9,999, the system displays ”::::”on the
screen.
To input numerals, touch the ”0–9” switch
and the display will change the screen to
number input display.
UN006
Touching the ”A–Z” switch changes the
screen back to the previous name input dis-
play.
UN007
When a list is displayed, you can scroll or
page through the list by using the appropri-
ate switch.
To shift to the next or previous
page.
To scroll up or down one item at
a time.
This expresses a displayed
screen position.
Inputting letters and numbers

3
If a or a appears to the right
or left of the item name, the
complete name is too long for
the display. Touch the name,
and the name will scroll to the
end or beginning of the name. UN008
1. Touch the ”Scroll” switch to move
the cursor .
UN009
"Position locating screen on the map
2. When you touch an arrow facing your
desired point, the map scrolls in that
direction. When you release your finger,
scrolling stops.
3. If you touch the ”Enter” switch, the
position of cursor is set.
How to move the cursor
