Pocket Reference Guide
Customer Experience Center
1-800-331-4331
MN 00452-PRG07-LC
Printed in USA 07/06
07 Landcruiser PRG Cover 9/25/06 11:33 AM Page 1

Doors-Child safety locks
21
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Spare tire & tools
2007
Land Cruiser
!Aword about safe vehicle operations
This Pocket Reference Guide is a summary of
basic vehicle operations. It contains brief
descriptions of fundamental operations so you
can locate and use the vehicle’s main
equipment quickly and easily.
The Pocket Reference Guide is not intended
as a substitute for the Owner’s Manual
located in the vehicle’s glove box. We
strongly encourage you to review the Owner’s
Manual and supplementary manuals so you
will have a better understanding of the
vehicle’scapabilities and limitations.
Your dealership and the entire staff of Toyota
Motor Sales, U.S.A., Inc. wish you many years
of satisfied driving in your new Land Cruiser.
This Pocket Reference Guide is not a full
description of Land Cruiser operations.
Every Land Cruiser owner should review
the Owner’s Manual that accompanies this
vehicle.
Pay special attention to the boxed
information highlighted in yellow
throughout the Owner’s Manual.Each box
contains safe operating instructions to
help you avoid injury or equipment
malfunction.
All information in this Pocket Reference
Guide is current at the time of printing.
Toyota reserves the right to make changes
at any time without notice.
Utility vehicles have a significantly higher
rollover rate than other types of vehicles. Refer
to the Owner’s Manual for important rollover
information.
Moving the lever to “LOCK” will allow the door to
be opened only from the outside.
Removing the spare tire
Assemble the jack handle.
Remove the access hole cover with the
screwdriver.
Insert the jack handle end through the opening in
the bumper, and into the lowering screw.
Turn the jack handle counterclockwise.
Refer to the Owner’s Manual for tire changing and
jack positioning procedures.
Tool location
Tool bag
Jack
Spare tire
Rear door Rear hatch
07 Landcruiser PRG Cover 9/25/06 11:33 AM Page 2

1
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
INDEX
Item Page no.
OVERVIEW
Engine maintenance 7
Fuel tank door opener and cap 6
Hood release 7
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry26
FEATURES/OPERATIONS
Air Conditioning/Heating 18
Antenna-Power 12
Audio 16-17
Auto lock functions1, 2 9
Automatic Transmission 8
Clock 17
Cruise control 14
Cup holders 15
Door locks 19
Four-Wheel drive 9
Garage door opener (HomeLink®)319
Light control-Instrument panel 10
Lights2&turn signals 11
Moonroof 13
Parking brake 9
Power outlets 14
Rear hatch 13
Seat adjustments-Front 10
Seat adjustments-Rear 10
Seat heaters 19
Seats-Head restraints 10
Tilt and telescopic steering wheel 15
Windshield wiper & washer 12
Windows 12
Windows-Power rear quarter 13
SAFETY AND EMERGENCY FEATURES
Doors-Child safety locks 21
Seat belts 20
Seat belts-Shoulder belt anchor 20
Spare tire & tools 21
Tire Pressure Warning System reset 20
1Programmable by customers.
2Visit your Toyota dealer for information on
customizing this feature.
3HomeLink®is a registered trademark of Johnson Controls, Inc.
07 Landcruiser PRG Inside 9/25/06 11:37 AM Page 1

3
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Power rear view mirror controls
Tire Pressure Warning System reset
Power quarter window switch (left-hand side)
Power quarter window switch (right-hand side)
“RSCA OFF” (Roll Sensing of Curtain shield
Airbags “OFF”) switch1
Navigation system including Air Conditioning
controls1, 2
Power outlet
Cigarette lighter
Ashtray
1If equipped
2For details, refer to the Navigation System
Owner’s Manual.
2
OVERVIEW
Headlight, turn signal and front fog light controls
Cruise control
Ignition switch
Wiper and washer controls
Emergency flasher switch
Clock, outside temperature and trip information
display1
Audio system
Front passenger occupant classification indicator/
Front passenger seat belt reminder light
Air Conditioning controls
Outside rear view mirror heater switch
Rear Air Conditioning controls
Rear window defogger switch
Center differential lock switch
Power antenna switch
Power tilt and telescopic steering switch
Instrument panel light control
Instrument panel
With navigation system
Without navigation system
07 Landcruiser PRG Inside 9/25/06 11:37 AM Page 2

5
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
3For details, refer to “Roll Sensing of Curtain shield Airbags off
switch,” Section 1-10, 2007 Owner’s Manual.
Voltmeter
Speedometer
Gear shift position indicators
Service indicators and reminders
Tachometer
Height control indicator1
Engine oil pressure
Engine coolant temperature
Odometer and two trip meters
Trip meter reset knob
Fuel gauge
1If equipped
Automatic Transmission indicator
Headlight high beam indicator
Turn signal indicator
Slip indicator
Vehicle Stability Control “OFF” indicator
Roll Sensing of Curtain shield Airbags “OFF”
indicator3
Active Traction Control indicator
Cruise control indicator2
Automatic Transmission fluid temperature
warning1
Driving pattern (“POWER” mode) indicator
Automatic Transmission second start indicator
Center differential lock indicator
Unengaged “Park” warning1
Airbag SRS warning1
Low Tire Pressure Warning1
4
OVERVIEW
1For details, refer to “Service reminder indicators and warning
buzzers,” Section 1-6, 2007 Owner’s Manual.
2If this light flashes, refer to “Cruise control,” Section 1-7, 2007
Owner’s Manual.
Instrument cluster
Driver seat belt reminder1
Front passenger seat belt reminder1
Charging system warning1
Brake system warning1
Malfunction/Check Engine indicator1
Engine oil replacement reminder1
Anti-lock Brake System warning1
Low fuel level warning1
When the Anti-lock Brake System (ABS) function is in
action, you may feel the brake pedal pulsating and
hear a noise. In this situation, to let the Anti-lock
Brake System work for you, just hold the brake pedal
down more firmly. Do not pump the brake as this will
result in reduced braking performance.
Indicator symbols
Vehicle Stability Control/Active Traction
Control warning1
Open door warning1
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 4

7
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
6
OVERVIEW
Fuel tank door opener and cap
Turn and store
Pull
NOTE: If the cap is not tightened enough, Check
Engine “ ” indicator may illuminate.
Keyless entry
Locking operation Unlocking operation
Alarm operation
Push Push ONCE: Driver door
TWICE: All doors
Push and hold
NOTE: After unlocking, if a door is not opened within
30 seconds, all doors will relock for safety.
Hood release
Pull
Pull up latch and
raise hood
Engine oil filler cap
Windshield and rear window washer fluid tank
Engine oil level dipstick
Engine coolant reservoir
Power steering fluid reservoir
Note: Regularly scheduled maintenance, including
oil changes, will help extend the life of
your vehicle and maintain performance.
Please refer to the “Owner’s Warranty
Information Booklet,” “Scheduled
Maintenance Guide” or “Owner’sManual
Supplement.”
Engine maintenance
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 6

9
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
8
FEATURES/OPERATIONS
Automatic Transmission
Downshifting increases power going uphill, or
provides engine braking downhill. For best fuel
economy during normal driving conditions, always
drive with the shift lever in the “D” position.
For starting in sand, mud, ice or snow Depress the
brake, then push “2nd” to start the vehicle in
second gear.
In Power mode, the transmission is shifted up and
down at a higher vehicle speed, and a more
powerful acceleration is achieved. For normal
driving conditions, Toyota recommends using the
Normal mode to improve fuel economy.
Park1
Reverse
Neutral
Drive
P
R
N
D
4
Fourth gear
3
Third gear
2
Second gear
L
First gear
1The ignition switch must be ON, and the brake
pedal depressed to shift from “Park.”
Driving pattern selector button
Power mode
Second start mode selector button
Second start mode
Normal mode
Four-Wheel drive
Center differential lock button
For best fuel economy and performance under
normal driving conditions Drive with shifter in “H”
position and center differential unlocked (center
differential lock and “VSC OFF” indicators are not
illuminated).
Four-Wheel drive control lever
High speed
Neutral
Low speed
H
N
L
Center differential lock/unlock
Auto lock functions
Automatic door locks can be programmed to operate
in 4 different modes, or turned OFF.
-Doors lock when shifting from Park.
-Doors lock when the vehicle speed goes above
approximately 12 mph.
-Doors unlock when shifting into Park.
-Doors unlock when the ignition switch is turned
from ON to ACC or LOCK and driver’s door is
opened.
Refer to the Owner’s Manual for more details.
Parking brake
Pull
(2) Push
(1) Pull slightly
(3) Lower
Set Release
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 8

11
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
10
FEATURES/OPERATIONS
Position, cushion angle and height
Seatback angle
Lumbar support
Seat adjustments-Front
Seat adjustments-Rear
Second row Third row
Seats-Head restraints
Rear
Height Angle
Lock release button Lock release buttons
Front
Light control-Instrument panel
Brightness
control
+-
Lights & turn signals
Headlights
Turn signals
AUTO
Parking lights
High beam flasher
High beam
Low beam
Headlights
-Daytime Running Light system (DRL) Automatically
turns on the headlights at a reduced intensity.
-Automatic light cut off system Will automatically
turn lights off after a delay of 30 seconds, or when
lock switch on remote is pushed.
Right turn
Left turn
Lane change
Lane change
Front fog lights
Turn
Front fog lights come on only when the headlights
are on low beam.
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 10

13
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
12
FEATURES/OPERATIONS
Windshield wiper & washer
Interval wipe
Slow
Fast
Pull to wash and wipe
Adjust interval
Front
Rear
Wash and wipe
Wipe
Interval wipe
Wash and wipe
Windows
Window
lock switch
Driver side
Automatic operation Push the switch completely
down or pull it completely up and release to fully
open or close. To stop window midway, lightly push
the switch in the opposite direction.
Window lock switch Deactivates all passenger
windows. Driver’s window remains operable.
Up
Down
Up Down
Antenna-Power
Up
Down
Windows-Power rear quarter
Left
Right
CloseOpen
Moonroof
Sliding operation Tilting operation
Open
Close Tilt
Close
Rear hatch
Operating from outside Operating from inside
Pull
Lock
Lock
Unlock
Unlock
Pull
Push
NOTE: Antenna will retract when radio is “OFF.”
NOTE: If battery is disconnected, the moonroof
needs to be reinitialized. Refer to the Owner’s
Manual for more details.
Recommended driving
position to minimize wind
noise.
*Unlock all doors prior to
opening.
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 12

14 15
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
14
FEATURES/OPERATIONS
Cup holders
Front seats
Second row seats Third row seats
Left side
Right side
Front of console box Center console box
Rear console box
Cruise control
1The set speed may also be cancelled by depressing
the brake pedal.
2The set speed may be resumed once vehicle speed
exceeds 25 mph.
Refer to the Owner’s Manual for more details.
Turning system ON/OFF
Functions
System ON/OFF
Resume2/Increase speed
Set/Decrease speed
Cancel1
Tilt and telescopic steering wheel
Note: Do not attempt to adjust while the vehicle
is in motion.
Power outlets
NOTE: Designed for car accessories. Key must be in
the “ACC” or “ON” position to be used.
Instrument panel (12V) Luggage area (12V)
Rear console box (12V)
Without navigation system With navigation system
Control switch
Angle
Control switch
Length
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 14

17
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
16
FEATURES/OPERATIONS
Steering wheel switches
RDS (Radio Data System-FM only)
-Push TYPE “ ” or “ ” to view current program
genre. Push again within 6 seconds to select new
genre.
-Push “SEEK/TRACK” or “SCAN” to find same genre
programs.
-Push “TEXT” to receive information transmitted
from radio stations.
>
>
Clock
H-Hour set
M-Minute set
:00-Round off minutes
With navigation system Without navigation system
“- +”
Volume control
“ ”
-In radio mode Push to select a preset station;
push and hold to seek the next strong station.
-In tape mode Push to skip up or down to
next/previous track; push and hold to fast
forward or reverse.
-In CD mode Push to skip up or down to
next/previous track.
“MODE”
Push to turn audio ON and select an audio mode.
Push and hold to turn the audio system OFF.
>
>
CASSETTE TAPE PLAYER
CD PLAYER
To fast forward Push “ .”
To rewind Push “ .”
To select a direction Push “ .”
To scan tracks on a disc Push “SCAN.” Push again to
hold selection.
CD Changer
-To load one disc Push “LOAD” and insert one disc.
-To load multiple discs Push and hold “LOAD” until
you hear a beep. Insert one disc. Wait until the
green indicator illuminates and shutter opens to
insert next disc.
Audio
Eject CD
Push to
turn
ON/OFF
Push to
adjust
tone &
balance
Seek
station/
CD track
select
Mode
Station/CD
track scan
Eject
cassette
tape Traffic
information
View genre with
RDS system
View radio/CD text
Preset buttons - functions in other
modes indicated above number.
Load CD(s)
RADIO
Topreset stations Tune in the desired station and
hold down a preset button (1-6) until you hear a
beep. Push desired preset button (1-6) to select.
To scan stations Push “SCAN.” Push and hold to scan
preset stations. Push again to hold selection.
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 16

19
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
18
FEATURES/OPERATIONS
Seat heaters
Left front seat
Right front
seat
Garage door opener (HomeLink®)*
Garage door openers manufactured under license
from HomeLink®*can be programmed to operate
garage doors, estate gates, security lighting, etc.
Refer to the Owner’s Manual for more details.
For programming assistance, contact the Toyota
Customer Experience Center at 1-800-331-4331, or
visit http://www.homelink.com
* HomeLink®is a registered trademark of Johnson Controls, Inc.
Rear
Air Conditioning/Heating
Front
Temperature
Automatic climate control ON/OFF
Air flow vent
Air Conditioning ON/OFF
Windshield defogger
Fan speed
Fresh or recirculate cabin air
Climate control OFF
Main switch
Automatic climate control ON/OFF
Air flow vent
Fan speed
Temperature
Climate control OFF
In “ ” or “ ” mode, use fresh air (“ ”
indicator ON) to reduce window fogging.
Door locks
Lock
Unlock
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 18

20
SAFETY AND
EMERGENCY FEATURES
If belt is fully extended, then retracted even
slightly, it cannot be re-extended beyond that point,
unless fully retracted again. This feature is used to
help hold child restraint systems securely.
To find more information about seat belts, and how
to install a child restraint system, refer to the
Owner’s Manual.
Keep as low on
hips as possible
Take up
slack
Too high
Seat belts
Seat belts-Shoulder belt anchor
Squeeze lock release
to lower
Tire Pressure Warning System reset
If tire pressure becomes critically low on any of the
tires (including spare), indicator comes on. Pushing
“SET ” button should not turn off the light.
Correctly adjusting tire inflation will turn off the
light after a few minutes. After replacing/rotating
tire or wheels, push and hold “SET” button until the
indicator blinks 3 times.
Refer to the Owner’s Manual for more details.
07 Landcruiser PRG Inside 9/25/06 11:38 AM Page 20

Doors-Child safety locks
21
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Spare tire & tools
2007
Land Cruiser
!Aword about safe vehicle operations
This Pocket Reference Guide is a summary of
basic vehicle operations. It contains brief
descriptions of fundamental operations so you
can locate and use the vehicle’s main
equipment quickly and easily.
The Pocket Reference Guide is not intended
as a substitute for the Owner’s Manual
located in the vehicle’s glove box. We
strongly encourage you to review the Owner’s
Manual and supplementary manuals so you
will have a better understanding of the
vehicle’scapabilities and limitations.
Your dealership and the entire staff of Toyota
Motor Sales, U.S.A., Inc. wish you many years
of satisfied driving in your new Land Cruiser.
This Pocket Reference Guide is not a full
description of Land Cruiser operations.
Every Land Cruiser owner should review
the Owner’s Manual that accompanies this
vehicle.
Pay special attention to the boxed
information highlighted in yellow
throughout the Owner’s Manual.Each box
contains safe operating instructions to
help you avoid injury or equipment
malfunction.
All information in this Pocket Reference
Guide is current at the time of printing.
Toyota reserves the right to make changes
at any time without notice.
Utility vehicles have a significantly higher
rollover rate than other types of vehicles. Refer
to the Owner’s Manual for important rollover
information.
Moving the lever to “LOCK” will allow the door to
be opened only from the outside.
Removing the spare tire
Assemble the jack handle.
Remove the access hole cover with the
screwdriver.
Insert the jack handle end through the opening in
the bumper, and into the lowering screw.
Turn the jack handle counterclockwise.
Refer to the Owner’s Manual for tire changing and
jack positioning procedures.
Tool location
Tool bag
Jack
Spare tire
Rear door Rear hatch
07 Landcruiser PRG Cover 9/25/06 11:33 AM Page 2
