Toyota Yaris HV 2017 User manual

YARIS_HV_OM_Europe_OM52G33E
Pictorial index Search by illustration
1For safety
and security Make sure to read through them
2Instrument
cluster
How to read the gauges and meters, the variety of
warning lights and indicators, etc.
3Operation of
each component
Opening and closing the doors and windows,
adjustment before driving, etc.
4Driving Operations and advices which are necessary for driving
5Audio system Operating the audio system
6Interior features Usage of the interior features, etc.
7Maintenance
and care Caring for your vehicle and maintenance procedures
8When trouble
arises What to do in case of malfunction or emergency
9Vehicle
specifications Vehicle specifications, customizable features, etc.
Index Search by symptom
Search alphabetically

TABLE OF CONTENTS
2
YARIS_HV_OM_Europe_OM52G33E
For your information .......................8
Reading this manual.....................12
How to search ..............................13
Pictorial index ...............................14
1-1. For safe use
Before driving.......................32
For safety drive ....................34
Seat belts.............................36
SRS airbags.........................43
Exhaust gas precautions .....55
1-2. Child safety
Airbag manual on-off
system ...............................56
Riding with children..............59
Child restraint systems ........60
1-3. Hybrid system
Hybrid system features ........86
Hybrid system
precautions ........................90
1-4. Theft deterrent system
Immobilizer system ..............96
Double locking system.......104
2. Instrument cluster
Warning lights and
indicators......................... 108
Gauges and meters
(vehicles with
monochrome display)...... 114
Gauges and meters
(vehicles with
color display) ................... 117
Multi-information display
(vehicles with
monochrome display)...... 121
Multi-information display
(vehicles with
color display) ................... 125
Energy monitor/
consumption screen........ 133
3-1. Key information
Keys .................................. 140
3-2. Opening, closing
and locking the doors
Side doors ......................... 152
Back door .......................... 159
Smart entry & start
system............................. 164
1For safety and security
2Instrument cluster
3Operation of
each component

3
1
7
8
6
5
4
3
2
9
YARIS_HV_OM_Europe_OM52G33E
3-3. Adjusting the seats
Front seats.........................182
Rear seats .........................184
Head restraints ..................188
3-4. Adjusting the steering
wheel and mirrors
Steering wheel ...................191
Inside rear view mirror .......193
Outside rear view
mirrors .............................196
3-5. Opening and closing
the windows
Power windows..................199
4-1. Before driving
Driving the vehicle .............204
Cargo and luggage ............213
Trailer towing .....................215
4-2. Driving procedures
Power (ignition) switch
(vehicles without a smart
entry & start system)........216
Power (ignition) switch
(vehicles with a smart
entry & start system)........220
EV drive mode ...................229
Hybrid transmission ...........232
Turn signal lever ................236
Parking brake.....................237
4-3. Operating the lights
and wipers
Headlight switch ................ 238
Fog light switch ................. 244
Windshield wiper
and washer ..................... 246
Rear window wiper
and washer ..................... 250
4-4. Refueling
Opening the fuel tank
cap .................................. 252
4-5. Toyota Safety Sense
Toyota Safety Sense......... 255
PCS (Pre-Crash Safety
system) ........................... 262
LDA (Lane Departure
Alert) ............................... 279
Automatic High Beam ....... 287
RSA (Road Sign Assist) .... 293
4-6. Using the driving support
systems
Cruise control .................... 299
Driving assist systems....... 303
4-7. Driving tips
Hybrid vehicle driving
tips .................................. 310
Winter driving tips.............. 313
4Driving

TABLE OF CONTENTS
4
YARIS_HV_OM_Europe_OM52G33E
5-1. Basic Operations
Audio system types............320
Steering wheel audio
switches...........................322
AUX port/USB port.............323
5-2. Using the audio system
Optimal use of the audio
system .............................324
5-3. Using the radio
Radio operation .................326
5-4. Playing audio CDs and
MP3/WMA discs
CD player operation...........330
5-5. Using an external device
Listening to an iPod ...........339
Listening to a USB
memory device ................347
Using the AUX port ............353
5-6. Using Bluetooth®
devices
Bluetooth®audio/phone.....354
Using the steering
wheel switches ................360
Registering a Bluetooth®
device ..............................361
5-7. “SETUP” menu
Using the “SETUP” menu
(“Bluetooth*” menu)......... 362
Using the “SETUP” menu
(“Phone” menu)............... 367
5-8. Bluetooth®Audio
Operating a Bluetooth®
enabled portable
player .............................. 371
5-9. Bluetooth®Phone
Making a phone call .......... 374
Receiving a phone call...... 376
Speaking on the phone ..... 377
5-10.Bluetooth®
Bluetooth®......................... 379
5Audio system
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

5
1
7
8
6
5
4
3
2
9
YARIS_HV_OM_Europe_OM52G33E
6-1. Using the air conditioning
system and defogger
Automatic air conditioning
system .............................386
Seat heaters ......................396
6-2. Using the interior lights
Interior lights list.................398
• Interior light....................398
• Personal lights...............399
6-3. Using the storage features
List of storage features ......400
• Glove box ......................401
• Cup holders ...................402
• Bottle holders ................403
• Auxiliary box ..................403
Luggage compartment
features............................404
6-4. Using the other interior
features
Other interior features........407
• Sun visors......................407
• Vanity mirrors ................407
• Portable ashtray ............408
• Cigarette lighter .............409
• Power outlet ..................410
• Armrest..........................411
• Panoramic roof shade ...411
• Assist grips ....................412
7-1. Maintenance and care
Cleaning and protecting
the vehicle exterior.......... 414
Cleaning and protecting
the vehicle interior........... 419
7-2. Maintenance
Maintenance
requirements ................... 427
7-3. Do-it-yourself maintenance
Do-it-yourself service
precautions ..................... 430
Hood.................................. 433
Positioning a floor jack ...... 435
Engine compartment ......... 437
12-volt battery ................... 445
Tires .................................. 451
Tire inflation pressure........ 468
Wheels .............................. 470
Air conditioning filter.......... 474
Wireless remote control/
electronic key battery ...... 477
Checking and replacing
fuses ............................... 481
Light bulbs......................... 486
6Interior features 7Maintenance and care

TABLE OF CONTENTS
6
YARIS_HV_OM_Europe_OM52G33E
8-1. Essential information
Emergency flashers ...........506
If your vehicle has to
be stopped in
an emergency..................507
8-2. Steps to take in
an emergency
If your vehicle needs to
be towed ..........................509
If you think something is
wrong...............................516
If a warning light turns on
or a warning buzzer
sounds .............................517
If a warning message is
displayed (vehicles with
color display) ...................531
If you have a flat tire
(vehicles with
an emergency tire
puncture repair kit)...........537
If you have a flat tire
(vehicles with
a spare tire) .....................556
If the hybrid system will
not start ........................... 571
If the electronic key does
not operate properly
(vehicles with a smart
entry & start system) ....... 573
If the vehicle 12-volt
battery is discharged....... 576
If your vehicle overheats ... 581
If the vehicle becomes
stuck................................ 587
8When trouble arises

7
1
7
8
6
5
4
3
2
9
YARIS_HV_OM_Europe_OM52G33E
9-1. Specifications
Maintenance data
(fuel, oil level, etc.)...........590
Fuel information .................601
9-2. Customization
Customizable features .......603
9-3. Items to initialize
Items to initialize ................610
What to do if...
(Troubleshooting) .....................612
Alphabetical index ......................616
9Vehicle specifications
Index
For vehicles with navigation system or multimedia system, refer to
“Navigation and multimedia system Owner’s manual” for information
regarding the equipment listed below.
• Navigation system
• Hands-free system
(for cellular phone)
• Rear view monitor system
• Audio system
Toyota Motor Europe NV/SA, Avenue du Bourget 60 - 1140 Brussels,
Belgium www.toyota-europe.com

8
YARIS_HV_OM_Europe_OM52G33E
For your information
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Both genuine Toyota and a wide variety of other spare parts and accessories
for Toyota vehicles are currently available in the market. Should it be deter-
mined that any of the genuine Toyota parts or accessories supplied with the
vehicle need to be replaced, Toyota recommends that genuine Toyota parts
or accessories, be used to replace them. Other parts or accessories of
matching quality can also be used. Toyota cannot accept any liability or guar-
antee spare parts and accessories which are not genuine Toyota products,
nor for replacement or installation involving such parts. In addition, damage
or performance problems resulting from the use of non-genuine Toyota spare
parts or accessories may not be covered under warranty.
Main Owner’s Manual
Accessories, spare parts and modification of your Toyota

9
YARIS_HV_OM_Europe_OM52G33E
The installation of an RF-transmitter system in your vehicle could affect elec-
tronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
●Cruise control system (if equipped)
●Anti-lock brake system
●SRS airbag system
●Seat belt pretensioner system
Be sure to check with any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer for precautionary measures or special
instructions regarding installation of an RF-transmitter system.
Further information regarding frequency bands, power levels, antenna posi-
tions and installation provisions for the installation of RF-transmitters, is avail-
able on request at any authorized Toyota retailer or Toyota authorized
repairer, or any reliable repairer.
High voltage parts and cables on the hybrid vehicles emit approximately the
same amount of electromagnetic waves as the conventional gasoline pow-
ered vehicles or home electronic appliances despite of their electromagnetic
shielding.
Unwanted noise may occur in the reception of the radio frequency transmitter
(RF-transmitter).
Installation of an RF-transmitter system

10
YARIS_HV_OM_Europe_OM52G33E
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by any authorized
Toyota retailer or Toyota authorized repairer, or any reliable repairer, before
you scrap your vehicle.
Scrapping of your Toyota

11
YARIS_HV_OM_Europe_OM52G33E
WARNING
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influ-
ence of alcohol or drugs that have impaired your ability to operate your vehi-
cle. Alcohol and certain drugs delay reaction time, impair judgment and
reduce coordination, which could lead to an accident that could result in
death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other
drivers or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that
distracts the driver, such as adjusting controls, talking on a cellular phone or
reading can result in a collision with resulting death or serious injury to you,
your occupants or others.
■General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to
have or use the key.
Children may be able to start the vehicle or shift the vehicle into neutral.
There is also a danger that children may injure themselves by playing with
the cigarette lighter, the windows, the panoramic roof shade, or other fea-
tures of the vehicle. In addition, heat build-up or extremely cold tempera-
tures inside the vehicle can be fatal to children.

12
YARIS_HV_OM_Europe_OM52G33E
Reading this manual
WARNING:
Explains something that, if not obeyed, could cause death or
serious injury to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to
or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps
in numerical order.
Indicates the action (push-
ing, turning, etc.) used to
operate switches and other
devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or
position being explained.
Means “Do not”, “Do not do
this”, or “Do not let this hap-
pen”.
123

13
YARIS_HV_OM_Europe_OM52G33E
How to search
■Searching by name
• Alphabetical index ...... P. 616
■Searching by installation
position
• Pictorial index............... P. 14
■Searching by symptom or
sound
• What to do if...
(Troubleshooting) ....... P. 612
■Searching by title
• Table of contents ............ P. 2

14 Pictorial index
YARIS_HV_OM_Europe_OM52G33E
Pictorial index
■Exterior
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 152
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 152
Opening/closing the side windows . . . . . . . . . . . . . . . . . . . . . P. 199
Locking/unlocking by using the mechanical key*1. . . . . . . . . P. 573
Warning lights*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 521
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159
Warning lights*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 521
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Folding the mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 197
Defogging the mirrors*3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 390
1
2
3

15
Pictorial index
YARIS_HV_OM_Europe_OM52G33E
Wipers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 246, 250
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 313
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . P. 416
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 252
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 252
Fuel type/fuel tank capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . P. 592
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 451
Tire size/inflation pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 598
Winter tires/tire chain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 313
Checking/rotation/tire pressure warning system*3. . . . . . . . . P. 451
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 537, 556
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 433
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 433
Engine oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 593
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 581
Headlights/front position lights/daytime running lights/
front turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . P. 236, 238
Front fog lights*3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244
Side turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 236
Rear turn signal lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 236
Back-up lights/tail lights (LED type) . . . . . . . . . . . . . . . . . . P. 238
Shifting the shift lever to R. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 232
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 238
Rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 238
4
5
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 486, Watts: P. 600)
*1: Vehicles with a smart entry & start system
*2: Vehicles with monochrome display
*3: If equipped
8
9
10
11
12
13
14
15

16 Pictorial index
YARIS_HV_OM_Europe_OM52G33E
■Instrument panel (Left-hand drive vehicles)
Power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216, 220
Starting the hybrid system . . . . . . . . . . . . . . . . . . . . . . . . P. 216, 220
Changing power switch positions/modes . . . . . . . . . . . . P. 217, 222
Emergency stop of the hybrid system . . . . . . . . . . . . . . . . . . . P. 507
When the hybrid system will not start . . . . . . . . . . . . . . . . . . . P. 571
Warning lights*1, 2/warning messages*1, 3 . . . . . . . . . . . P. 529, 531
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 232
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 232
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 509
When the shift lever does not move . . . . . . . . . . . . . . . . . . . . P. 234
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 114, 117
Reading the meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 114, 117
Adjusting the instrument cluster light. . . . . . . . . . . . . . . . .P. 115, 118
Warning lights/indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 108
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . P. 517
1
2
3

17
Pictorial index
YARIS_HV_OM_Europe_OM52G33E
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . P. 121, 125
If a warning message or indicator is displayed*3. . . . . . . . . . P. 531
Parking brake. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 237
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 314
Warning buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 517
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 236
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 238
Headlights/front position lights/tail lights/
daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 238
Front fog lights*4/rear fog light . . . . . . . . . . . . . . . . . . . . . . . . P. 244
Wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . P. 246, 250
Usage (front) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 246
Usage (rear)*4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 250
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 443
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . P. 506
Hood lock release lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 433
Tilt and telescopic steering lock release lever . . . . . . . . . . P. 191
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 386
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 386
Rear window defogger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 390
Audio system*4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 320
Navigation/Multimedia system*4, 5
*1: Vehicles with a smart entry & start system
*2: Vehicles with monochrome display
*3: Vehicles with color display
*4: If equipped
*5: Refer to “Navigation and multimedia system Owner’s manual”.
4
5
6
7
8
9
10
11
12

18 Pictorial index
YARIS_HV_OM_Europe_OM52G33E
■Switches (Left-hand drive vehicles)
Outside rear view mirror switches*. . . . . . . . . . . . . . . . . . . P. 196
Manual headlight leveling dial . . . . . . . . . . . . . . . . . . . . . . . P. 240
LDA (Lane Departure Alert) switch*. . . . . . . . . . . . . . . . . . P. 280
Automatic high beam switch*. . . . . . . . . . . . . . . . . . . . . . . P. 287
PCS (Pre-Crash Safety system) switch*. . . . . . . . . . . . . . . P. 266
1
2
3
4
5

19
Pictorial index
YARIS_HV_OM_Europe_OM52G33E
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 199
Door lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 156
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 199
Tire pressure warning reset switch*. . . . . . . . . . . . . . . . . . P. 454
*: If equipped
1
2
3
4

20 Pictorial index
YARIS_HV_OM_Europe_OM52G33E
Audio remote control switches . . . . . . . . . . . . . . . . . . . . . . P. 322
Meter control switches*1. . . . . . . . . . . . . . . . . . . . . . . P. 118, 126
Telephone switch*1, 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 360
Cruise control switch*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 299
“EV MODE” switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 229
“ECO MODE” switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 233
Seat heater switches*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 396
VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 304
1
2
3
4
*1: If equipped
*2: For vehicles with navigation/multimedia system, refer to
“Navigation and multimedia system Owner’s manual”.
1
2
3
4
