TP-Link ARCHER MR200 User manual

AC750 Dual Band Wi-Fi
4G LTE Router
Archer MR200
Share Your 4G LTE Network
AC750 Dual Band Wi-Fi

Highlights
Archer MR200
TP-Link AC750 Wireless Dual Band 4G LTE Router
The Archer MR200 uses 4G LTE technology to achieve speeds of up to 150 Mbps
download and 50 Mbps upload. It also shares a simultaneous dual band Wi-Fi
network with maximum speeds of 300 Mbps on 2.4 GHz and 433 Mbps on 5 GHz for
gaming, streaming, le-sharing and more.
Superfast 4G LTE Speed & Stream-Ready AC Wi-Fi
50 Mbps
150 Mbps
4G LTE
Ideal Use Places
Remote
Areas On Vacation Business Meetings
433 Mbps 5 GHz
300 Mbps 2.4 GHz
Advanced LTE antennas make ecient and stable connections to every device.
Power Amplier and Low Noise Amplier boost sending and receiving
capabilities, creating a wide-coverage Wi-Fi network for your home.
Design for Maximum Network Coverage
5 GHz 433 Mbps
2.4 GHz 300 Mbps

Plug and Play More Devices, More Stability
Simply insert your 3G/4G micro SIM card into the built-in slot, turn on the
MR200 and start surng.
Connect up to 64 wireless devices with ease, thanks to a powerful processor
that boosts data transfer speeds while ensuring dependable network stability.
Start Surng!Micro SIM Card
Up to
64
Devices
1 GHz
Highlights
Archer MR200
TP-Link AC750 Wireless Dual Band 4G LTE Router

Simple Management Flexible Connection
Parental Controls let you easily manage your kids by limiting access to Internet.
Guest Network provides separate Wi-Fi access for guests while securing
network. QoS assigns more bandwidth to preferred devices to ensure the
quality of activities.
With a fully functional WAN/LAN port, Archer MR200 can work as a router
which is compatible with cable, ber, and DSL modems.
Modem
Ethernet Cable
Internet
ModemModem
Highlights
Archer MR200
TP-Link AC750 Wireless Dual Band 4G LTE Router

· 4G LTE – Ideal for cutting-edge 4G LTE network
· Backward Compatible – Compatible with 3G network
4G LTE
· Superior Wireless Speed – Combined wireless speeds up to
300 Mbps over 2.4 GHz, and 433 Mbps over 5 GHz
· 802.11 ac Standard– Provides a data transfer rate 3 times
faster than 802.11n for each stream
Wi-Fi Speed
·Great Coverage – Better coverage with integrated Wi-Fi
omnidirectional antennas
Wi-Fi Range
Features
Archer MR200
TP-Link AC750 Wireless Dual Band 4G LTE Router

Reliability
· Simultaneous Dual Band – Separate Wi-Fi bands enable more
devices to connect to your network without a drop in
performance
· Easy Bandwidth Management – Advanced QoS makes it easier
for you to manage the bandwidth of connected devices
· Superior Stability – Powerful processor enables you to connect
up to 64 wireless devices with ease
· Guest Network – Keeps your main network secure by creating a
separate network for friends and visitors
· Access Control – Establishes a whitelist or blacklist to allow or
restrict certain devices to access the internet
· Parental Controls – Restrict internet access time and contents
for your children’s devices
· Encryptions for Secure Network – WPA-PSK and WPA2-PSK
encryptions provide active protection against security threats
Security
· Intuitive Web UI – Ensures quick and simple installation without
hassle
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Wi-Fi On/O – Conveniently turn on or o wireless radios as
required
· Online Upgrade – Keeps you informed of the latest rmware
and allows online upgrade on the web UI
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android and iOS device
Ease of Use
FeaturesFeatures
Archer MR200
TP-Link AC750 Wireless Dual Band 4G LTE Router

Hardware Wireless
· Network Type
4G: FDD-LTE B1/B3/B7/B8/B20 (2100/1800/2600/900/800 MHz)
TDD-LTE B38/B40/B41 (2600/2300/2500 MHz)
3G: DC-HSPA+/HSPA+/HSPA/UMTS B1/B8 (2100/900 MHz)
· Wireless Standards: IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
· Frequency: 2.4 GHz and 5 GHz
· Signal Rate: 300 Mbps at 2.4 GHz, 433 Mbps at 5 GHz
· EIRP (CE): < 20 dBm (2.4 GHz), < 23 dBm (5 GHz)
· Reception Sensitivity:
5 GHz:
11a 54M: -78 dBm
11ac VHT20 MCS0: -92 dBm 11ac VHT20 MCS8: -72 dBm
11ac VHT40 MCS0: -90 dBm 11ac VHT40 MCS9: -67 dBm
11ac VHT80 MCS0: -87 dBm 11ac VHT80 MCS9: -64 dBm
2.4 GHz:
11g 54M: -74 dBm
11n HT20 MCS0: -91 dBm 11n HT20 MCS7: -72 dBm
11n HT40 MCS0: -88 dBm 11n HT40 MCS7: -69 dBm
· Wireless Function: Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless
Statistics
· Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
· Interface: 3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1 Micro SIM Card Slot
· Buttons: WPS/RESET Button, Wi-Fi ON/OFF Button
· Antennas: 2 Detachable External 4G LTE Antennas
· External Power Supply: 12V/1A
· Dimensions (W x D x H): 6.85 × 4.9 × 1.32 in (174 × 124.5 × 33.5 mm)
SpecicationsSpecications
Power
Wi-Fi On/Off
WPS/Reset
LAN/WAN Port
LAN Ports Micro SIM Card Slot
Archer MR200
TP-Link AC750 Wireless Dual Band 4G LTE Router

Attention: This device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2020 TP-Link Technologies Co., Ltd. All rights reserved.
†
Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and
environmental factors, including building materials, obstacles, volume and density of trac, and client location.
For more information, please visit
https://www.tp-link.com/products/details/?model=Archer+MR200_V5
or scan the QR code left
www.tp-link.com
· Certication:
CE, RoHS
· Requirements:
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Micro SIM Card
· Environment:
Operating Temperature: 0℃~40℃(32℉~104℉)
Storage Temperature: -40℃~60℃(-40℉~140℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
AC750 Wireless Dual Band 4G LTE Router Archer MR200
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
Others
· Operating Modes: 3G/4G Router, Wireless Router
· WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
· DHCP: Server, DHCP Client List, Address Reservation
· Quality of Service: Bandwidth Control
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, NO-IP, TP-Link DDNS
· VPN Server: PPTP VPN, OpenVPN
· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· Management: Access Control, Local Management, Remote Management,
reboot schedule
· Guest Network: 2.4 GHz guest network x 1, 5 GHz guest network x 1
Software
Specications
