TPS easyFLOW-VS User manual

easyFLOW-VS Variable Speed Peristaltic Dosing Pump
TPS Pty Ltd
ABN 30 009 773 371
Unit 6 / 253 Leitchs Road
Brendale, QLD,
Australia, 4500
Phone : [phone]
International : 61 7 3205 8027
Fax : [phone]
International : 61 7 3808 4871
Email : [email protected]
Web : www.tps.com.au
easyFLOW-VS User Manual
Date : 24-Feb-2006
Version : 1.2

2
Contents
Section 1. – Introduction .......................................................................................................... 3
1.1 easyFLOW-VS Illustration................................................................................................. 4
1.2 Unpacking Information ...................................................................................................... 5
1.3 Specifications ................................................................................................................... 6
Section 2. – Installation ............................................................................................................ 7
2.1 Plan the Installation .......................................................................................................... 7
2.2 Install the optional Injection Tee........................................................................................ 7
2.3 Fit Tubing into Chemical Drum.......................................................................................... 8
2.4 Fit Tubing to Dosing Pump................................................................................................ 8
2.5 Mount the easyFLOW-VS and Make Electrical Connections............................................. 9
2.6 External Control Settings ................................................................................................ 10
2.7 Setting the Pump Speed to 50% ..................................................................................... 11
Section 3. – Operating Instructions....................................................................................... 12
3.1 Manual Operation ........................................................................................................... 12
3.2 External On / Off Control Operation ................................................................................ 12
3.3 External 4-20 mA or 0-1 V Control Operation.................................................................. 12
3.4 External 4-20 mA or 0-1 V Control Operation with Manual OFF Override ....................... 12
3.5 Adjusting the Zero point when using 4-20 mA External Control....................................... 12
Section 4. – Peristaltic Dosing Pumps .................................................................................. 13
4.1 Lubricating the Pump Tubing .......................................................................................... 13
4.2 Replacing the Pump Tubing............................................................................................ 13
Section 5. – Warranty ............................................................................................................. 15
Section 6. – Drilling Template ................................................................................................ 17

Section 1 – Introduction
3
Section 1. – Introduction
Thank you for purchasing an easyFLOW-VS.
The easyFLOW-VS is a high quality peristaltic dosing pump with variable speed control and is
designed for maximum reliability to give you many years of reliable service.
The easyFLOW-VS is a breeze to operate. If at any stage you require assistance, please contact
either your local TPS representative or the TPS factory in Brisbane.
The manual is divided into the following sections:
Section 1 – Introduction
The introduction includes a diagram of the easyFLOW-VS unit, connectors and controls. Please
check the Unpacking Information section to ensure that you have received all accessories and any
optional items you may have ordered.
Section 2 – Installation
This section provides details on installing the easyFLOW-VS, including all connection and set-up
instructions.
Section 3 –Operation
This section provides operational details for easyFLOW-VS.
Section 4 – Peristaltic Dosing Pump
A section devoted to the dosing pump fitted to the easyFLOW-VS. Describes usage and
maintenance instructions.
Section 6 – Warranty
The TPS Warranty conditions are detailed in this section. Also included are details on the
procedure to follow in case the easyFLOW-VS unit needs to be returned for service or repair.
Section 7 – Drilling Template
This section provides details on installing the easyFLOW-VS, including all connection, set-up and
operating instructions.

Section 1 – Introduction
4
1.1 easyFLOW-VS Illustration
1. Peristaltic Dosing Pump
For installation information, see Section 2. – Installation.
For usage and maintenance instructions, see Section 4. – Peristaltic Dosing Pumps.
2. Dose Rate Control
Adjusts the Litres per Hour at which the easyFLOW-VS pumps. This adjustment is not active
when the easyFLOW-VS is set for external speed control mode using a 4-20mA or 0-1V input.
3. External Control Indicator
The External Control indicator LED lights when the easyFLOW-VS is set for either external
on/off control or external speed control.
4. External Control Cable Entry
A waterproof cable gland is provided for use with an external control cable. The unit is
supplied with a plastic rod inserted into the gland to ensure the unit is waterproof when no
external cable is fitted.
5. Power Input Socket
A waterproof connector for the 24V DC power input. An AC/DC adaptor is supplied in the
standard easyFLOW-VS kit.

Section 1 – Introduction
5
1.2 Unpacking Information
Please check that you have received all of the items that should have been included with your new
easyFLOW-VS, as illustrated below…
Standard easyFLOW-VS Kit…
easyFLOW-VS Peristaltic Pump
Part No : 118100
Chemical drum lid with gland fitting
Part No : 116362
Peristaltic Pump Input and Output
Tube, 4m. Part No : 116360
Tube weight for chemical drum
Part No : 116354
easyFLOW-VS Handbook
Part No : 130050
24V 500mA/1A AC/DC Adaptor
Part No…
130106 (Australia 240V, 2 Flat Pins)
130108 (Euro/Asia 220V, 2 Round Pins)
130110 (USA 110-120V, 2 Flat Pins)
130112 (UK 240V, Three Pin)
Options and spares…
Injection Tee for 50mm PVC pipe,
with non-return valve
Part No : 117901
(Supplied with two reduction bushes
to adapt to 40mm pipe)
Pump tube assembly, 5 L/Hr
Part No : 116352
Pump tube assembly, 1.5 L/Hr
Part No : 116353
Pump Tube Lubricant, 3mL
Part No : 130103
2-way External Control Cable, 2m
Part No : 130128
4-way External Control Cable, 2m
Part No : 130130

Section 1 – Introduction
6
1.3 Specifications
Peristaltic Pump
•The easyFLOW-VS has 1 x built-in Peristaltic Pump.
•Chemical resistant Santoprene pump tubing.
•Small pump tubing produces 1.6 Litres / Hour at Full setting
Standard large pump tubing produces 5 Litres / Hour at Full setting
Power
•24V DC, 500mA / 1 Amp AC/DC Adaptor to suit country of destination is supplied.
•The easyFLOW-VS unit draws approximately 200 mA of current.
Standard Control
•Dose Rate control allows selection of OFF, Dosing Rate and Full speed.
External Control
•External On and Off switching control, using the Dose Rate setting for constant pump speed.
•External 4-20 mA or 0-1V control which adjusts the speed of the pump according to the input
signal.
Calibration
Zero calibration for 4 – 20 mA External Control operation.

Section 2 – Installation
7
Section 2. – Installation
2.1 Plan the Installation
Ensure that…
1. The easyFLOW-VS controller is close enough to the expected location of the injection point
for the pump output tubing to reach without straining.
2. The maximum suction height from the bottom of the chemical drums to the dosing pumps is 2
metres.
3. The power lead from the AC/DC Adaptor reaches from a mains power point to the
easyFLOW-VS without straining.
The external control cable between the easyFLOW-VS and the device that is controlling the
easyFLOW-VS reaches without straining.
2.2 Install the optional Injection Tee
If the optional Injection Tee (part no 117901) has been ordered, install it as per the diagram below.
Use a suitable PVC joining compound.

Section 2 – Installation
8
2.3 Fit Tubing into Chemical Drum
Insert the suction tubing
through the chemical
drum lid supplied and fit
the drum weight, as per
the diagram. For
hazardous chemicals be
sure to use the correct
type of chemical
resistant drum. For
installations where the lid
provided is not
compatible with the
container, drill a 1/2” or
13mm hole into the lid of
the container and fit the
compression fitting. Drill
a second 2mm diameter
vent hole to avoid
suction build-up.
2.4 Fit Tubing to Dosing Pump
Insert the suction tubing
from the chemical drum
to the left hand side
compression fitting of the
dosing pump. Screw the
retaining nut into place
firmly, ensuring the tube
is securely anchored.
Repeat for the supply
tubing on the right hand
side of the pump.

Section 2 – Installation
9
2.5 Mount the easyFLOW-VS and Make Electrical Connections
For wall mounting, use minimum 3mm or 1/8” stainless steel bolts, screws or masonary anchors.
A drilling template is provided at the back of this manual.

Section 2 – Installation
10
2.6 External Control Settings
The easyFLOW-VS has the ability to be controlled by an external device. For example, it can be
connected to a miniCHEM pH controller to control the pH of an industrial process. Using the
correct cable connections and jumper settings, the easyFLOW-VS can be set up to be externally
controlled in the any of the following ways…
1. Simple On and Off switching, operating at the speed setting of Dose Rate control.
2. Variable speed operation, proportional to a 4-20 mA input, where 4mA is stopped and 20mA is
full speed.
3. Variable speed operation, proportional to a 0 – 1V DC input, where 0V is stopped and 1V is
full speed.
4. Either of the variable speed external control settings above can be set up with a manual
override to switch the unit off.
Refer to the following diagram when setting up the External Control connections…
Notes
To access the circuit board’s settings, remove
the four screws at the corners of the front panel
and remove the lid. Please use caution, to avoid
damaging any connecting cables.
In the table below, “Switch” under H4 refers to
an external switch to turn the easyFLOW-VS on
and off. This can be in the form of standard
on/off switch or the relay contacts of a process
control unit.
“Link” under H4 refers to linking the two
terminals with a piece of wire.
When removing jumpers, we recommend that
you fit it to one of the pins. This way, it will not
be lost if the jumper is to be replaced at a later
time.
“n/c” means “No Connection” at that terminal.
External Control Mode H1 H4 J1 J2 J5 J7 J6
Simple On / Off Switching at Dose
rate setting
n/c Switch Off Off Off On On
4-20mA Variable Speed 4-20 mA Link On On On On Off
4-20mA Variable Speed with Manual
OFF override
4-20 mA Switch On On On On Off
0-1 V DC Variable Speed 0-1 V Link Off Off On On Off
0-1 V DC Variable Speed with Manual
OFF override
0-1 V Switch Off Off On On Off
No external control (factory default
settings)
n/c Link Off Off Off Off On

Section 2 – Installation
11
2.7 Setting the Pump Speed to 50%
Operators who wish to use the easyFLOW-VS at a low speed may find it difficult to set the desired
speed accurately with the Dose Rate control. A “50%” jumper fitting is provided for these users. To
select “50%” speed operation…
1. Remove the front panel and locate the jumper settings, as per the instructions in section 2.6.
2. Set jumper J3 to On to select 50% speed operation.
3. If the unit is returned to the factory default Off setting at a later time, we recommend that you
fit it to one of the pins. This way, it will not be lost if the jumper is to be replaced at a later time.

Section 3 – Operating Instructions
12
Section 3. – Operating Instructions
3.1 Manual Operation
The easyFLOW-VS is set for manual operation by default.
1. Plug the AC/DC Adaptor into a suitable mains power outlet and switch on.
2. Set the Dose Rate control to the desired pump speed.
3.2 External On / Off Control Operation
1. Connect the External Control cable as detailed in section 2.6. The cable gland should be
finger-tight to ensure a good waterproof seal. Use only round cable, as flat or figure-8 cables
will not seal correctly in the gland.
2. Plug the AC/DC Adaptor into a suitable mains power outlet and switch on. Note that the
External Control LED lights up to indicate that the easyFLOW-VS is under external control.
3. Set the Dose Rate control to the desired pump speed.
3.3 External 4-20 mA or 0-1 V Control Operation
1. Connect the External Control cable as detailed in section 2.6. The cable gland should be
finger-tight to ensure a good waterproof seal. Use only round cable, as flat or figure-8 cables
will not seal correctly in the gland.
2. Plug the AC/DC Adaptor into a suitable mains power outlet and switch on. Note that the
External Control LED lights up to indicate that the easyFLOW-VS is under external control.
3. It is not necessary to set the Dose Rate control as the pump speed is determined by the 4-20
mA or 0–1 V signal.
3.4 External 4-20 mA or 0-1 V Control Operation with Manual OFF Override
1. Connect the External Control cable as detailed in section 2.6. The cable gland should be
finger-tight to ensure a good waterproof seal. A single round 4 core cable should be used to
ensure a waterproof seal at the gland.
2. Plug the AC/DC Adaptor into a suitable mains power outlet and switch on. Note that the
External Control LED lights up to indicate that the easyFLOW-VS is under external control.
3. It is not necessary to set the Dose Rate control as the pump speed is determined by the 4-20
mA or 0 – 1 V signal.
3.5 Adjusting the Zero point when using 4-20 mA External Control
Every pump motor has a different point at which it starts and stops. This zero point also varies with
time. For this reason, a Zero adjustment has been provided when using the 4-20 mA External
Control…
1. Set the device that is producing the 4-20mA signal to 4 mA. For a TPS controller, such as a
miniCHEM or proCHEM this can be done by switching the unit to its Limit setting mode and
adjusting the Limit to Zero. This will cause the unit to output 4 mA.
2. Adjust the RV1 control until the pump is running, then adjust it back until the pump just stops.
The Zero point has now been correctly set.

Section 4 – Peristaltic Dosing Pumps
13
Section 4. – Peristaltic Dosing Pumps
4.1 Lubricating the Pump Tubing
The easyFLOW-VS is shipped with the correct lubrication on the peristaltic pump tubing. This
lubrication should be re-applied every year. Suitable Silicon lubricant is available from TPS in a
3mL syringe (part no 130103).
To lubricate the pump tubing…
1. Remove the pump tubing, as per the details in section 4.2, below.
2. Smear a small quantity of Silicon grease all around the tube. A thin film is all that is required.
DO NOT use petroleum based oil or lubricants, as these will cause the Santoprene
rubber to perish. Use only Silicon based lubricant.
4.2 Replacing the Pump Tubing
Replace the Pump Tubing if it gets worn, begins to leak, or pumping volume is reduced. The Pump
Tubing may be replaced every year as a precautionary measure.
To remove the old Pump Tube…
1
IMPORTANT
Place the pump suction
tubing into a bucket of
fresh water. Prime the
pump with water by
switching on at full
speed to 3 minutes. This
ensures that there is no
dangerous chemical in
the tube when it is
disconnected.
2 3 4
Switch off the power and
disconnect the power
cord.
Remove the Input and
Output tubing from the
compression fittings.
This is simply a reversal
of the procedure
detailed in section 2.4.
Remove the see-
through protector plate
on the front of the pump.
5
Turn the roller holder so that the rollers are in a horizontal line. Pull the left
hand side compression fitting from its seat. Begin turning the roller holder
clockwise, so that the roller holder acts as a lever which pulls the pump tube
out as it turns. After approximately 3/4 of a turn, the right hand side
compression fitting can be pulled out.
The old pump tube has now been removed.

Section 4 – Peristaltic Dosing Pumps
14
To fit a new Pump Tube…
1
Turn the roller holder so
that the rollers are in a
horizontal line. Push the
left hand side
compression fitting into
its seat, round side
facing in. Begin turning
the roller holder
clockwise, so that the
roller holder acts as a
lever which pulls the
pump tube in as it turns.
After approximately 3/4
of a turn, the right hand
side compression fitting
can be pushed in, round
facing in.
The new pump tube has
now been fitted.
2 3 4
Replace the see-through
protector plate on the
front of the pump. This
is essential to protect
the rollers and tube from
dirt and moisture.
Re-fit the Input and
Output tubing to the
compression fittings.
See the procedure
detailed in section 2.4.
The power to the
easyFLOW-VS can
now be re-connected
and switched on.
Warning : Use only a genuine replacement Tube supplied by TPS. Use of other tubing materials,
sizes or lengths may place undue stress on the rollers, causing them to wear
prematurely. This type of wear is not covered by warranty.

Section 5 – Warranty
15
Section 5. – Warranty
TPS Pty. Ltd. guarantees all instruments and sensors to be free from defects in material and
workmanship when subjected to normal use and service. This guarantee is expressly limited to the
servicing and/or adjustment of an instrument returned to the Factory, or Authorised Service
Station, freight prepaid, within twelve (12) months from the date of delivery, and to the repairing,
replacing, or adjusting of parts which upon inspection are found to be defective. Warranty period
on sensors is three (3) months.
There are no express or implied warranties which extend beyond the face hereof, and TPS Pty.
Ltd. is not liable for any incidental or consequential damages arising from the use or misuse of this
equipment, or from interpretation of information derived from the equipment.
Shipping damage is not covered by this warranty.
PLEASE NOTE
A guarantee card is packed with the instrument or sensor. This card must be completed at the time
of purchase and the registration section returned to TPS Pty. Ltd. within 7 days. No claims will be
recognised without the original guarantee card or other proof of purchase. This warranty becomes
invalid if modifications or repairs are attempted by unauthorised persons, or the serial number is
missing.
PROCEDURE FOR SERVICE
If you feel that this equipment is in need of repair, please re-read the manual. Sometimes,
instruments are received for "repair" in perfect working order. This can occur where the sensor(s)
simply requires cleaning or replacement or some other field serviceable event.
TPS Pty. Ltd. has a fine reputation for prompt and efficient service. In just a few days, our factory
service engineers and technicians will examine and repair your equipment to your full satisfaction.
To obtain this service, please follow this procedure…
Return the instrument AND ALL SENSORS to TPS freight pre-paid and insured in its original
packing or suitable equivalent. INSIST on a proof of delivery receipt from the carrier for your
protection in the case of shipping claims for transit loss or damage. It is your responsibility as the
sender to ensure that TPS receives the unit.
Please check that the following is enclosed with your equipment:
•Your Name and daytime phone number.
•Your return street address.
•A description of the fault. (Please be SPECIFIC.)
(Note: "Please Repair" does NOT describe a fault.)
Your equipment will be repaired and returned to you by air express where possible.
For out-of-warranty units, a repair cost will be calculated from parts and labour costs. If payment is
not received for the additional charges within 30 days, or if you decline to have the equipment
repaired, the complete unit will be returned to you freight paid, not repaired. For full-account
customers, the repair charges will be debited to your account.

Section 5 – Warranty
16
This page has been intentionally left blank, to ensure that the drilling template is on its own
removable page.

Section 6 – Drilling Template
17
Section 6. – Drilling Template
