Quick-Start-Guide STKa93xxCA
Arm® architecture
© TQ-Systems GmbH 2023 | All data is for information purposes only | Subject to change without notice | EMB_QSG_STKa93xxCA_Rev0001
CONNECT HOST PC AND STKNAME
Use the supplied USB cable (USB2.0 ST-A / Micro-B) to connect Debug USB (X22)
of the STKa93xxCA to a USB port of your host PC.
RUN TERMINAL EMULATOR AND CONFIGURE SERIAL PORT
Run your favourite terminal emulator on the host PC (we recommend Tera Term
Pro) and congure the serial port.
1
SUPPLY THE STK WITH POWER
Double-check the mains voltage required for the included Power supply, then connect it to connector
X23 on the MBa9xxxCA. Caution when using a different power supply! The Starterkit Can be operated
using a regulated supply voltage of 16-30V (nom. 24V)!
ESTABLISH SERIAL CONNECTION
The boot messages of boot loader and operating system are displayed by the terminal emulator.
When the kit has fully booted you can log in to the system with the username root .
2
!For latest documentation, BSPs, etc. please visit:
tq-group.com/en/products/tq-embedded/arm-architecture/stka93xx/
support.tq-group.com/TQMa93xxCA
1
2
Baudrate 115200
Data bits 8
Parity none
Stop bits 1
Handshake XON/XOFF

Quick-Start-Guide STKa93xxCA
Arm® architecture
© TQ-Systems GmbH 2023 | All data is for information purposes only | Subject to change without notice | EMB_QSG_STKa93xxCA_Rev0001
Boot device selection
To select the desired boot device set DIP switch S1 accordingly.
Conguration SD-Card
S1
DIP 1234
Set ON ON OFF OFF
Conguration eMMC
S1
DIP 1234
Set OFF ON OFF OFF
Conguration QSPI-NOR
S1
DIP 1234
Set OFF OFF ON OFF
