Delta Electronics SMT Power Inductor 1362 Installation instructions

Mechanical Dimension :
Features
25 , 100KHz, 1V
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG) 252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: [phone]; FAX: [phone]
http://www.deltaww.com
SMT Power Inductor
HMR1350B, 1362, 1365, 1368 & 1370 Type
O
C
Electrical Characteristics :
127
L
(uH)
Li
(uH) MIN.
HEIGHT "B"
(mm/inch) MAX.
o
I2
sat
(Adc)
(m ) MAX
DCR
rms
I
(Adc)
3
1
UNIT : mm/inch
A = 12.80 / 0.504 Max.
C = 10.20 / 0.402 Max.
C' = 10.00 / 0.394 Max.
D = 1.80 / 0.071
E = 7.65 / 0.301
F = 2.00 / 0.09
RECOMMENDED PAD PATTERNS
F
B
E
D
C
C'
A
5.3
2.5
10.0
2.5
1. Tolerance of inductance is 20%.
2. Isat is the DC current which cause the inductance drop to Li.
O
3. Irms is the DC current which cause the surface temperature of the part increase less than 45 C.
OO
4. Operating temperature : -20 C to 105 C ( including self-temperature rise ).
RoHS compliant.
Low profile, SMD type.
High current.
Magnetic shielded.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
HMR1350B-7R0 7.0 5.60 17.00 8.0 7.8 5.0 / 0.197
HMR1362-5R6 5.6 4.48 7.20 10.0 11.0 6.2 / 0.244
HMR1362-100 10.0 8.00 17.00 7.8 8.0 6.2 / 0.244
HMR1365-5R6 5.6 4.45 6.00 8.0 13.0 6.5 / 0.256
HMR1368-1R4 1.4 1.10 1.74 16.0 25.0 6.8 / 0.268
HMR1368-4R5 4.5 4.20 20% 5.10 12.0 14.0 6.8 / 0.268
HMR1370-100 10.0 8.00 17.00 7.8 9.0 7.0 / 0.276
