Tracmaster CAMON C22 Tiller User manual

Before commissioning the machine, read operang instrucons
and observe warning and safety instrucons.
Manufactured by Tracmaster Ltd
CAMON C22 Tiller
ORIGINAL INSTRUCTION MANUAL
Before commissioning the machine, read operang instrucons
and observe warning and safety instrucons.
Manufactured by Tracmaster Ltd

CAMON C22 Tiller
Manufacturer Details
Tracmaster Ltd
Units 6-7 Winterpick Business Park
Hurstpierpoint Road
Wineham
Heneld
BN5 9BJ
UNITED KINGDOM
Tel: [phone]
www.tracmaster.co.uk
[e-mail]
Machine Details
Model: CAMON C22 Tiller
Serial No: A 1 4 - 11111
Engine Serial No: G A A A A -1111111
Purchase Date: D D -M M -Y Y Y Y
Supplier:
C22-11/2022.A www.tracmaster.co.uk

CAMON C22 Tiller
C22-01/2023.A Page 1
Table of Contents
1.0 Introducon .............................................................................................................................2
1.1 Welcome ................................................................................................................................2
1.2 About This Manual ................................................................................................................2
2.0 What the Machine is Designed For............................................................................................3
2.1 Applicaons ...........................................................................................................................3
3.0 Specicaons............................................................................................................................4
4.0 Unpacking and Assembly ..........................................................................................................5
4.1 Major Components Diagram .................................................................................................5
4.2 Unpacking Instrucons ..........................................................................................................5
5.0 SafetyInstrucons....................................................................................................................6
5.1 Basic Safety Instrucons ........................................................................................................6
5.2 Main Components and Operang Elements .........................................................................6
5.3 Engine and Drive ....................................................................................................................6
5.4 Operang Lever .....................................................................................................................6
5.5 Drag Bar .................................................................................................................................6
5.6 Transport Wheel ....................................................................................................................7
5.7 Throle Lever ........................................................................................................................7
5.8 Commissioning ......................................................................................................................7
5.9 General Safety Instrucons ...................................................................................................7
5.10 Engine Specic Safety Instrucons ........................................................................................8
5.11 Hazard Pictorial Explanaons ................................................................................................8
6.0 SafetyInstruconsStarngandOperang..............................................................................10
6.1 To Start the Engine ..............................................................................................................10
6.2 To Stop the Engine ...............................................................................................................11
6.3 Safety Equipment ................................................................................................................11
6.4 Operaon.............................................................................................................................11
6.5 Procedure for Unexpected Shut Down ................................................................................11
6.6 Residual Risks of the C22 Tiller ............................................................................................11
7.0 Maintenance ..........................................................................................................................12
7.1 Schedule ..............................................................................................................................12
7.2 Basic Maintenance ..............................................................................................................12
7.3 Engine ..................................................................................................................................12
7.3.1 Check Engine Oil Level ..............................................................................................12
7.3.2 Change Engine Oil .....................................................................................................12
7.3.3 Air Filter ....................................................................................................................13
7.3.4 Spark Plug .................................................................................................................13
7.4 Cleaning ...............................................................................................................................14
7.5 Troubleshoong ...................................................................................................................14
7.5.1 Machine ....................................................................................................................14
7.5.2 Engine ......................................................................................................................14
7.5.3 Lubricants ..................................................................................................................14
8.0 Transportaon,StorageandHandling.....................................................................................15
8.1 Transportaon .....................................................................................................................15
8.2 Storage.................................................................................................................................15
8.3 Handling ..............................................................................................................................15
9.0 Spare Parts .............................................................................................................................16
10.0 Service Record ........................................................................................................................17
11.0 ECDeclaraonofConformity..................................................................................................18
12.0 WarrantyInformaon.............................................................................................................19

CAMON C22 Tiller
Page 2 www.tracmaster.co.uk
1.0 Introducon
1.1 Welcome
Welcome to Tracmaster and thank you for choosing CAMON.
We are condent that you will be more than happy with your machine.
Your machine is covered by a comprehensive warranty. However, the lifespan of
your CAMON machine depends on a number of factors. It is important that you read
this manual carefully and follow the instrucons regarding operaon, maintenance,
and care.
1.2 About This Manual
It is crucial that you read this manual carefully and understand it. Reading and
understanding this manual should prevent you from operang the C22 incorrectly
and so extend the life of the machine.
This manual also contains important safety informaon about your machine.
You must observe all safety instrucons at all mes. CAMON machines are oen
updated and improved so models may vary due to dierences in specicaons.
Any illustraons, descripons, specicaons, and technical data in this manual is
correct at the me of prinng.
For any quesons relang to this manual please contact us.
During oce hours (UK) we can be contacted on:
Phone: [phone]
Email: [e-mail]
Website: www.tracmaster.co.uk
IMPORTANT!
READ THIS MANUAL
CAREFULLY
!

CAMON C22 Tiller
C22-01/2023.A Page 3
2.0 What the Machine is Designed For
2.1 Applicaons
The CAMON C22 Tiller has been designed by Tracmaster for culvang soil for
planng of vegetables, plants and owers.
The benet of using a C22 Tiller is the ease and eciency with which the machine is
able to dig the ground, saving the operator substanal me and eort.
The nes of the CAMON C22 Tiller are designed to be used only on soil where there
is no grass present.
DO NOT use the CAMON C22 Tiller for any alternave use other than culvang
soil.
Operang the machine on non-grass surfaces such as concrete or tarmac will cause
damage to the C22 Tiller.

CAMON C22 Tiller
Page 4 www.tracmaster.co.uk
3.0 Specicaons
ENGINE
Engine Manufacturer Honda
Engine Model GX160
Engine Type 4-stroke OHV, single cylinder
Net Engine Power 3.6kW (4.8hp) @ 3600rpm
Engine Sha Size ¾” straight
Spark Plug BPR6ES (NGK) / W20EPR-U (DENSO)
Spark Plug Gap 0.70 - 0.80mm
Engine Ignion Type Recoil
Cold Start System Choke
Fuel Tank Capacity 3.1 litres
Fuel Type Unleaded
Fuel Consumpon 1.4 litres per hour @ 3600rpm
Air Filter Paper
Rated Engine Speed 3600rpm
Engine Oil 10w/30 API SJ or later
Engine Oil Capacity 0.6 litres
Dry Weight 15.1kg
The power rang of the engine indicated in this table is the net power output tested on a producon engine for
the engine model and measured in accordance with SAE J1349 at a specied rpm.
MACHINE
Model C22
Working Width 64cm
No of Blades 16 [8 le / 8 right]
Wheel Types Solid rubber
Handlebar Feature Foldable
Noise Level 97 dB(A)
Vibraon Acceleraon Value 6.9ms2
Max Gradient for Operaon on Slope 20 degrees
Weight 69kg
Dimensions (l x w x h) 140 x 70 x 84cm

CAMON C22 Tiller
C22-01/2023.A Page 5
4.0 Unpacking and Assembly
4.1 Major Components Diagram
① Engine On/O Switch
② Throle Lever
③ Handlebar
④ Handlebar Locking Pin
⑤ Operang Lever
⑥Engine
⑦Belt Guard
⑧Drag Bar
⑨Digging Tines
⑩Transport Wheel
⑪ Tine Guards
4.2 UnpackingInstrucons
The C22 Tiller is usually delivered secured to a wooden pallet, andd covered with
pallet wrap.
Carefully remove any outer packaging.
Locate and remove any cable es or straps that secure the Tiller to the pallet.
Swivel the folded top handlebar unl one of the three holes at the boom of the
handlebar line up with the holes on the handlebar stem.
Insert the locking pin to x handlebars into posion.
Push the machine forward safely and carefully o the pallet.
Dispose of the pallet and other packing material. Recycle where possible.
①
②
⑤
④
③
⑩
⑦
⑧
⑨
⑥
⑪

CAMON C22 Tiller
Page 6 www.tracmaster.co.uk
5.0 SafetyInstrucons
5.1 BasicSafetyInstrucons
Before starng the machine, read and understand these operang instrucons.
5.2 MainComponentsandOperangElements
Below is a descripon of the main components of the C22 Tiller and how they operate.
5.3 Engine and Drive
The ON/OFF switch for the Honda GX160 engine is
located on the right handlebar. This is the main operang
control for the engine. Rotang the switch to the “I”
posion allows the engine to be started and run. Rotang
the switch to the “0” posion will stop the engine.
The Honda GX160 is a four stroke engine that runs on
standard unleaded fuel.
The engine is air cooled and therefore it is important that
the grille covering the recoil rope is kept clear from debris.
The engine air lter cleans the air drawn in by the engine. A clogged air lter will
reduce performance.
The engine is ed with a choke lever. Read the engine operang instrucons to
understand the operaon of these levers.
5.4 OperangLever
The drive to digging nes is controlled by the operang lever located under the grip
on the le handlebar.
Pulling upwards on this lever engages the drive to the nes which will start rotang
and digging into the ground.
5.5 Drag Bar
Located at the rear of the machine, the drag bar is used to control the depth and
speed at which the C22 will dig into the ground.
The depth is controlled by varying the posion at which the drag bar is held into its
locaon at the rear of the C22. The drag bar has a choice of holes through which its
locang pin can be posioned. The lower the hole used on the drag bar to hold it
in its posion, the deeper the machine will dig.
Forward speed is controlled by the drag bar as during operaon of the ller
downward pressure is applied on the handlebars by the operator that forces the
drag bar into the ground. This acts as an anchor holding the ller in place whilst
it digs down to its required depth. Releasing downward pressure on the drag bar
allows the ller to walk itself forward into its new culvang posion.

CAMON C22 Tiller
C22-01/2023.A Page 7
5.6 Transport Wheel
The transport wheel is used solely for moving the C22 Tiller to its designated digging
locaon.
NB: The transport wheel is not required at any point during actual ground culvaon.
The transport wheel is held in its downwards travel posion using a spring
mechanism. By pulling on the wheel it is possible to overcome the tension of the
spring and rotate the wheel 180o upwards and around to a locaon where it is held
out of the way of the digging nes.
5.7 ThroleLever
The throle lever is mounted under the ON/OFF switch and controls the engine
speed, which in turn controls the speed of the digging nes.
A faster throle speed will result in an increased rotaonal speed of the digging
nes.
5.8 Commissioning
Prior to operaon it is necessary to check the engine oil level and add engine oil
level to the levels indicated in the table in secon 6.1.
The engine fuel tank will not contain fuel so will need lling to the recommended
level before use.
5.9 GeneralSafetyInstrucons
Be aware of all the safety requirements for the machine.
Visually check the machine for operaonal safety, complete components and xed
guarding prior to each use.
Read and be aware of the warning and instrucon signs located on the machinery.
Cordon o the work area to access from the general public.
Before starng work clear the area of any objects that may cause damage to the
machine.
Do not operate the machine if you are under the inuence of alcohol or drugs. This
equipment must only be operated by persons who are medically t both physically
and mentally.
Only work in good light and visibility.
Wear the correct personal protecon equipment as instructed by this manual.
Operator clothing should not be loose and footwear should oer good grip.
Know how to stop the machine in an emergency.

CAMON C22 Tiller
Page 8 www.tracmaster.co.uk
5.10 EngineSpecicSafetyInstrucons
Always ensure the engine is turned o and the fuel tap is turned o when
transporng the machinery, cleaning the machinery and making adjustments.
Always start the engine in open air. Starng an engine within a conned space can
lead to the inhalaon of toxic substances.
Do not smoke or use a naked ame when refueling.
Use only unleaded petrol from fuel containers designed for this purpose. Refuel
outdoors only and replace the fuel tank cap securely.
Do not mix oil with the fuel.
Leave one inch of space in the fuel tank during relling.
Clear up any petrol spillages immediately.
Avoid contact with the engine during operaon as it will become hot. Leave the
engine to cool prior to contact.
Never interfere with the control sengs of the engine.
5.11 HazardPictorialExplanaons
Danger-Rotangblades.Keepfeetclearof
diggingnes.
Maximum sound power level (LWA).
Earproteconmustbewornwhenoperangthemachine.
ALWAYSwearsuitablePersonalProtecveEquipment(PPE):
• Ear Defenders
•EyeProtecon
•FootProtecon
• Safety Gloves

CAMON C22 Tiller
C22-01/2023.A Page 9
Ensure safety guards are in place. Machine MUST NOT
be operated without guards.
Readoperang
instruconsbeforeuse.
Remove spark plug before
servicing or performing
maintenance.
Warning: Keep bystanders
away.
Machineidencaonlabel.Indicates
compliance with European standards (CE
mark).Includesuniqueserialnumber,machine
weight,poweroutput,andmonthandyearof
manufacture.
It is important that these sckers are in good condion, are legible, and are in the
correct posions on the C22 Tiller.
Do not use the machine if any of these sckers are missing or damaged.
If any sckers are missing or damaged then they must be replaced. They can be
obtained from the Spare Parts Department at Tracmaster Ltd.
TRACMASTER LTD
Units 6-7
Winterpick Business Park
Hurstpierpoint Road
Wineham, Henfield
BN5 9BJ, UK
T: [phone]
Machine Type: C22 Tiller
Weight: 69kg Year ID: November 2022
Power: 3.6kW Serial No: A14-xxxxx
1 2 3
1
2
3

CAMON C22 Tiller
Page 10 www.tracmaster.co.uk
6.0 SafetyInstruconsStarngandOperang
6.1 To Start the Engine
Using the dipsck provided,
check the engine oil level. Top
up with SAE 10W/30 oil, API SJ
or equivalent, if the dipsck is
clear of oil.
Check the fuel level. Rell as
necessary and as determined
by the fuel tank type – see
diagram.
Switch the engine ignion
switch to the ON posion.
Turn the fuel tap located on the
engine carburetor to the ON
posion. If the engine is cold or
has not been operated recently
set the choke lever on the
carburetor to the ON posion.
Pull the engine recoil handle slowly unl it engages then pull briskly to start the
engine.
Aer the start, return the recoil handle gently. Do not let it snap back.
Once the engine has started, if the choke lever has been used, return this its OFF
posion aer the engine has run for a few seconds.

CAMON C22 Tiller
C22-01/2023.A Page 11
6.2 To Stop the Engine
Release the operang lever.
Switch the engine ON/OFF switch to the “0” OFF posion.
Turn the fuel tap lever to the OFF posion.
WARNING: THE EXHAUST COVER MAY BE HOT – DO NOT TOUCH.
6.3 SafetyEquipment
The C22 operator must be wearing:
• Ear Defenders
• Gloves
• Protecve Footwear
• Safety Glasses
6.4 Operaon
Before culvaon can be carried out, the ground must be cleared of long grass and
any objects such as stones or bricks that would damage the Tiller.
WARNING: USING THE TILLER ON LONG GRASS WILL QUICKLY CAUSE
DAMAGE TO COMPONENTS OF THE MACHINE.
When safety checks have been completed, start the engine following the correct
procedure.
Posion the Tiller in the direcon you wish to culvate
Ensure the transport wheel has been located in its upright digging posion.
6.5 Procedure for Unexpected Shut Down
Release the operang lever.
Turn the engine operang switch located on the engine to the OFF posion.
Ensure the nes have stopped rotang prior to moving the machine.
6.6 Residual Risks of the C22 Tiller
The C22 Tiller is designed to be pushed by the operator during transportaon. It
has no brake system and therefore the operator must hold rmly onto the machine
at all mes when the machine is on sloped areas.
!
!

CAMON C22 Tiller
Page 12 www.tracmaster.co.uk
7.0 Maintenance
7.1 Schedule
Operaon Daily Weekly Monthly
Engine Check engine oil level 10W/30.
See separate engine manual. X X
Machine Check condion of nes. X
Check belt condion. X
Check operang lever and cable. X
Check protecon cover condion. X
Check bearings. X
Lubricate wheel bearings. X
Tighten all nuts and bolts. X
7.2 Basic Maintenance
Check that all guards are ed securely.
Ensure the cable connecng the drive lever to the engine is securely fastened at
both ends and shows no sign of wear.
Ensure the wheel is held securely.
7.3 Engine
7.3.1 Check Engine Oil Level
This is to be checked prior to each use and every 8 hours during operaon.
Check only when the engine is o and in a horizontal posion.
Clean the oil ller plug and its surrounding parts.
Remove the oil ller plug. Clean the dipsck with a clean cloth and put the
oil ller plug all the way back into the engine. Remove the oil ller plug and
check the oil level.
Rell the oil if indicator shows more is required. For the Honda GX160 the
recommended oil is SAE 10w/30.
7.3.2 Change Engine Oil
Refer to the engine manufacturer’s manual for locaon of components and
more detailed assistance.
Do not change the oil if the engine is hot.
The rst oil change is aer 50 hours of work.

CAMON C22 Tiller
C22-01/2023.A Page 13
Subsequent oil changes should be made aer each 100 hours of work.
At extreme temperatures or condions change the oil aer every 50 hours.
Drain the oil when the engine is warm, as it will drain quickly and completely
when warm.
Open the drain plug on the engine and the lling plug and drain the oil into
a suitable container or use a sucon pump to remove oil through ller neck.
Ensure the waste oil is disposed of properly.
Re-t the drain plug and ghten.
Fill fresh engine oil through the oil lling opening. Use a funnel or similar
device for ease of lling.
Replace the oil ller plug and ghten.
7.3.3 Air Filter
InspeconCheck:
Remove the air cleaner cover and inspect the lter elements.
Cleaning:
See diagram below containing informaon provided by Honda.
7.3.4 Spark Plug
Clean and replace.

CAMON C22 Tiller
Page 14 www.tracmaster.co.uk
7.4 Cleaning
Aer cleaning, parcularly if a pressure washer has been used, ensure any
lubricaon points are re-lubricated.
Clean the engine with a cloth only. Avoid spraying the engine with jets of water as
this may leak into the fuel and ignion systems.
7.5 Troubleshoong
7.5.1 Machine
Have all serious malfuncons on the machine and engine repaired by an
authorised Tracmaster or Honda agent.
Problem Possible Cause Remedy
No drive to blades.
Broken belt. Replace belt.
Broken spring tensioner. Replace spring.
Poor depth. Drag bar set incorrectly. Adjust drag bar.
7.5.2 Engine
Problem Possible Cause Remedy
Engine does
not start.
Spark plug connector not connected. Connect spark plug connector.
Choke lever is not actuated. Actuate choke lever.
Fuel tank empty. Fill fuel tank.
Fuel line clogged. Clean fuel line.
Defecve spark plug. Clean or replace spark plug.
Engine has too much fuel. Dry and adjust spark plug and
start engine on full throle
Engine
overheats.
Low engine oil. Rell immediately.
Impaired cooling. Clean cooling fan grille.
Air lter clogged. Clean air lter.
7.5.3 Lubricants
Use the specied 10w/30 oil specied by Honda for the engine oil.
To lubricate the roller bearings in the wheels we recommend using bio-
lubricang grease.

CAMON C22 Tiller
C22-01/2023.A Page 15
8.0 Transportaon,StorageandHandling
8.1 Transportaon
Use ramps where possible to manoeuvre the Tiller into a transportaon vehicle.
The C22 Tiller must be xed securely using straps and by placing chocks behind the
wheels.
Always transport the C22 Tiller horizontally and not lted at an angle.
Ensure that the fuel control lever on the engine is moved into the OFF posion so
fuel does not leak into the carburetor during transportaon.
8.2 Storage
Always clean the machine and thoroughly dry prior to storage and ensure all
lubricaon points have been re-greased.
For periods of long storage, change the engine oil.
Either drain the fuel completely or ll the fuel tank and add fuel stabilizer.
Do not store the Tiller in wet rooms, where ferliser is stored, or in stables as heavy
corrosion may occur.
Always store the machine in a horizontal posion.
8.3 Handling
Do not aempt to li the machine alone. At least two people is the minimum
required.
Gloves must be worn when liing the C22 Tiller.
Do not lt the machine so that fuel can leak into the air lter of the engine.
When performing maintenance on the Tiller when it is situated on a work bench,
ensure that the machine is rmly held in posion at all mes.
Do not li the machine solely by the engine at any point.

CAMON C22 Tiller
Page 16 www.tracmaster.co.uk
9.0 Spare Parts
The spare parts diagrams and part numbers for the CAMON C22 Tiller can be found
on our website or by contacng our spare parts department.
Spare parts can be ordered via the following methods:
Phone: [phone] (opon 1)
Website: www.tracmaster.co.uk
Email: [e-mail]
Or via your local Authorised Dealer.

CAMON C22 Tiller
C22-01/2023.A Page 17
10.0 Service Record
To ensure your machine is kept in peak condion we recommend that your Tiller is
serviced regularly.
Contact Tracmaster on 01444 247689 to nd out who your local Authorised Agent is.
Company: Company:
Date: Date:
Company
Stamp:
(or address
& authorised
signature)
Company
Stamp:
(or address
& authorised
signature)
Company: Company:
Date: Date:
Company
Stamp:
(or address
& authorised
signature)
Company
Stamp:
(or address
& authorised
signature)
Company: Company:
Date: Date:
Company
Stamp:
(or address
& authorised
signature)
Company
Stamp:
(or address
& authorised
signature)
1 2
3 4
5 6

CAMON C22 Tiller
Page 18 www.tracmaster.co.uk
11.0 ECDeclaraonofConformity
Tracmaster Ltd declares that the machinery spulated below complies with all the relevant
provisions of:
MachineryDirecve2006/42/EC
EMCDirecve2004/108/EC
and the Naonal Laws and Regulaons adopng these direcves and other relevant direcve.
Manufacturer: Tracmaster Ltd
Units 6-7 Winterpick Business Park
Hurstpierpoint Road
Wineham
Heneld
BN5 9BJ
UNITED KINGDOM
Machine Descripon: Tiller
Type: CAMON C22
Harmonised Standards applied (including parts of):
EN 13857:2008 Safety of machinery: Safety distance to prevent danger zones being
reached by the upper and lower limbs.
EN 12100-1:2003 Safety of machinery: Basic Principles. Terminology. Methodology.
EN 12100-2:2003 Safety of machinery: Basic Principles. Technical Principles.
EN 709:1997 Agricultural & Forestry Machinery – Pedestrian Controlled Tractors with
mounted rotary culvators, motor hoes, motor hoes with drive wheels.
Responsible Person: Jody Symons
Posion in Company: Technical Director
Address: Tracmaster Ltd, Units 6-7 Winterpick Business Park, Hurstpierpoint Road,
Wineham, Heneld, BN5 9BJ
Date: January 2023
Signature: ........................................................................................
