Tracmaster CAMON LA25B1 User guide

ORIGINAL INSTRUCTION MANUAL
Before commissioning the machine, read operang instrucons
and observe warning and safety instrucons.
Manufactured by Tracmaster Ltd
CAMON LA25B1 Lawn Aerator

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator
Manufacturer Details
Tracmaster Ltd
Units 6-7 Winterpick Business Park
Hurstpierpoint Road
Wineham
Heneld
BN5 9BJ
UNITED KINGDOM
Tel: [phone]
www.tracmaster.co.uk
[e-mail]
Machine Details
Model: CAMON LA25 Lawn Aerator
Serial No: B 1 1 - 11111
Engine Serial No: G A A A A -1111111
Purchase Date: D D -M M -Y Y Y Y
Supplier:

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 1
Table of Contents
1.0 Introducon .............................................................................................................................2
1.1 Welcome ................................................................................................................................2
1.2 About This Manual ................................................................................................................2
2.0 What the Machine is Designed For............................................................................................3
2.1 Applicaons ...........................................................................................................................3
3.0 Specicaons............................................................................................................................4
4.0 Unpacking and Assembly ..........................................................................................................5
4.1 Major Components Diagram .................................................................................................5
4.2 Unpacking Instrucons ..........................................................................................................5
5.0 SafetyInstrucons–Pre-Operaon..........................................................................................6
5.1 Basic Safety Instrucons ........................................................................................................6
5.2 Main Components and Operang Elements .........................................................................6
5.3 Engine and Drive ....................................................................................................................6
5.4 Operang Lever .....................................................................................................................6
5.5 Height Adjustment.................................................................................................................6
5.6 Tines ......................................................................................................................................7
5.7 Solid Spiking Tines & Hollow Coring Tines .............................................................................7
5.8 Commissioning ......................................................................................................................7
5.9 General Safety Instrucons ...................................................................................................7
5.10 Engine Specic Safety Instrucons ........................................................................................8
5.11 Machine Safety Scker Explanaons .....................................................................................8
6.0 SafetyInstruconsStarngandOperang..............................................................................10
6.1 To Start the Engine ..............................................................................................................10
6.2 To Stop the Engine ...............................................................................................................11
6.3 Safety Equipment ................................................................................................................11
6.4 Operaon.............................................................................................................................11
6.5 Procedure for Unexpected Shut Down ................................................................................12
6.6 Residual Risks of the LA25 Aerator ......................................................................................12
7.0 Maintenance ..........................................................................................................................13
7.1 Schedule ..............................................................................................................................13
7.2 Basic Maintenance ..............................................................................................................13
7.3 Gearbox ...............................................................................................................................13
7.4 Engine ..................................................................................................................................14
7.4.1 Check Engine Oil Level ..............................................................................................14
7.4.2 Change Engine Oil .....................................................................................................14
7.4.3 Air Filter ....................................................................................................................14
7.4.4 Spark Plug .................................................................................................................15
7.5 Cleaning ...............................................................................................................................15
7.6 Troubleshoong ...................................................................................................................15
7.6.1 Machine ....................................................................................................................15
7.6.2 Engine ......................................................................................................................16
7.6.3 Lubricants ..................................................................................................................16
8.0 Transportaon,StorageandHandling.....................................................................................17
8.1 Transportaon .....................................................................................................................17
8.2 Storage.................................................................................................................................17
8.3 Handling ..............................................................................................................................17
9.0 Spare Parts .............................................................................................................................18
10.0 Service Record ........................................................................................................................19
11.0 ECDeclaraonofConformity..................................................................................................20
12.0 WarrantyInformaon.............................................................................................................21

CAMON LA25 Lawn Aerator
Page 2 LA25 Lawn Aerator
CAMON LA25 Lawn Aerator
1.0 Introducon
1.1 Welcome
Welcome to Tracmaster and thank you for choosing CAMON.
We are condent that you will be more than happy with your machine.
Your machine is covered by a comprehensive warranty. However, the lifespan of
your CAMON machine depends on a number of factors. It is important that you read
this manual carefully and follow the instrucons regarding operaon, maintenance,
and care.
1.2 About This Manual
It is crucial that you read this manual carefully and understand it. Reading and
understanding this manual should prevent you from operang the LA25 incorrectly
and so extend the life of the machine.
This manual also contains important safety informaon about your machine.
You must observe all safety instrucons at all mes. CAMON machines are oen
updated and improved so models may vary due to dierences in specicaons.
Any illustraons, descripons, specicaons, and technical data in this manual is
correct at the me of prinng.
For any quesons relang to this manual please contact us.
During oce hours (UK) we can be contacted on:
Phone: [phone]
Email: [e-mail]
Website: www.tracmaster.co.uk
IMPORTANT!
READ THIS MANUAL
CAREFULLY
!

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 3
2.0 What the Machine is Designed For
2.1 Applicaons
The CAMON LA25 Lawn Aerator has been designed by Tracmaster for aerang grass
lawns and other grass areas.
The benet of aerang a lawn is that it allows air, water and nutrients to reach the
roots of the grass, relieves soil compacon, and removes unwanted sub-surface
thatch.
The nes of the CAMON LA25 Lawn Aerator are designed to be used only on grassed
areas where the surface soil is more than 10cm in depth.
Prior to operaon of the LA25, the operator MUST test the depth of the soil. This
can be done simply with a garden fork.
DO NOT use the CAMON LA25 Lawn Aerator for any alternave use other than
aerang grass areas.
Operang the machine on non-grass surfaces such as concrete or tarmac will cause
damage to the LA25 Lawn Aerator.
Aer aerang DO NOT expose the lawn to high temperatures or drought.
Irrigate the lawn if necessary to ensure that the grass benets from its treatment.

CAMON LA25 Lawn Aerator
Page 4 LA25 Lawn Aerator
3.0 Specicaons
ENGINE
Engine Manufacturer Honda
Engine Model GX160
Engine Type 4-stroke OHV, single cylinder
Net Engine Power 3.6kW (4.8hp) @ 3600rpm
Engine Sha Size ¾” straight
Spark Plug BPR6ES (NGK) / W20EPR-U (DENSO)
Spark Plug Gap 0.70 - 0.80mm
Engine Ignion Type Recoil
Cold Start System Choke
Fuel Tank Capacity 3.1 litres
Fuel Type Unleaded
Fuel Consumpon 1.4 litres per hour @ 3600rpm
Air Filter Paper
Rated Engine Speed 3600rpm
Working RPM 2800rpm
Engine Oil 10w/30 API SJ or equivalent
Engine Oil Capacity 0.6 litres
Dry Weight 15.1kg
The power rang of the engine indicated in this table is the net power output tested on a producon engine for
the engine model and measured in accordance with SAE J1349 at a specied rpm.
MACHINE
Model LA25
Working Width 40cm
Tine Types Solid and hollow
Solid Tine Dimensions 10mm diameter / 100mm length
Hollow Tines Dimensions 21mm diameter / 100mm length
No of Tines Fied in Operaon 4
Tine Depth Adjustment From 90mm to 110mm
Core Discharge To the rear
Wheel Types Solid foam
Steering Handle Foldable
Noise Level 99 dB(A)
Vibraon Acceleraon Value 5.4ms2
Max Gradient for Operaon on Slope 20 degrees
Weight 103kg
Dimensions (l x w x h) 100 x 65 x 68cm

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 5
4.0 Unpacking and Assembly
4.1 Major Components Diagram
① Operang Lever
② Throle
③ Tine Control Lever
④ Handlebar Locking Pins
⑤ Engine
⑥ Gearbox
⑦ Wheels
⑧ Tine Liing Board
⑨ Tine Holder
⑩Tines
4.2 UnpackingInstrucons
The LA25 Lawn Aerator is usually delivered on a pallet and covered with pallet wrap.
Carefully remove any outer packaging.
Locate and remove any cable es or straps that secure the Aerator to the pallet.
Swivel the folded top part of the handlebar unl it locates into posion.
Place the handlebar locking pins into the holes to lock the handlebars in the
operang posion.
Push the machine forward safely and gently o the pallet.
Dispose of the pallet and other packing material. Recycle where possible.
⑩
⑨
⑧
⑥
⑤
⑦
④
③
②
①

CAMON LA25 Lawn Aerator
Page 6 LA25 Lawn Aerator
5.0 SafetyInstrucons–Pre-Operaon
5.1 BasicSafetyInstrucons
Before starng the machine, read and understand these operang instrucons.
5.2 MainComponentsandOperangElements
Below is a descripon of the main components of the LA25 Aerator and how they
operate.
5.3 Engine and Drive
The Honda GX160 (Fig. 1) is a four stroke engine that
runs on standard unleaded fuel.
The engine is air cooled and therefore it is important
that the grille covering the recoil rope is kept clear from
debris.
The engine air lter cleans the air sucked in by the
engine. A clogged air lter will reduce performance.
The engine is ed with a fuel on/o lever and a choke lever. Read the engine
operang instrucons to understand the operaon of these levers.
5.4 OperangLever
The LA25 Aerator nes are engaged by using the lever located underneath the top
of the handlebar (Fig. 2).
PLEASE NOTE THAT THIS IS A TWO STAGE LEVER. THE GREY BUTTON MUST BE
DEPRESSED BEFORE THE MAIN LEVER CAN BE PULLED UP.
Once the drive has been engaged it will
transfer the engine power through a gearbox,
to the ne rods that will rotate. The surface
penetrang nes are held at the end of each
ne rod and will be pushed into the ground
before being withdrawn as the ne rods
rotate.
5.5 Height Adjustment
The depth of the ne penetraon of LA25 Aerator is altered by changing the
posion of the back axles.
Each back axle has three holes by which it can be aached to the main chassis
frame.
Aaching the axles using the lowest posion holes has the eect of moving the
nes closer to the ground and increasing the depth that the aerator will penetrate.
Fig. 1
Fig. 2

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 7
The two alternave posioning holes raise the
height of the nes away from the ground and
decrease the depth the nes will penetrate.
Moving from the lowest hole to the middle hole
and to the highest will decrease the depth of the
nes by 10mm each step.
5.6 Tines
Four nes of the same type must be ed at all
mes for the LA25 operator to funcon correctly.
Each ne must be threaded and secured ghtly
into the ne holder rods. Each ne must be ed with
a washer and spring washer to ensure the ne can be
ghtened suciently into the ne rod (Fig. 4).
Use a 17mm spanner to ghten the nes in place.
We recommend checking the ghtness of the nes at
intervals during operaon.
5.7 Solid Spiking Tines & Hollow Coring Tines
The LA25 Aerator is supplied with a set of both 10mm
solid spikes and hollow corer nes (Fig. 5). You must
always use four of the same nes when seng up and
operang the Aerator.
Solid nes help nutrients to reach soil roots and improve drainage.
Hollow nes, in addion to the benets listed for solid nes,
reduce surface compacon by removing a secon of the soil each
me a ne is punched into the soil.
5.8 Commissioning
Prior to operaon it is necessary to check the engine oil level and,
if required, add engine oil to the levels indicated in the table in
secon 6.1.
The engine fuel tank will not contain fuel so will need lling to
the recommended level before use. See engine manual for more
informaon.
5.9 GeneralSafetyInstrucons
Be aware of all the safety requirements for the machine.
Visually check the machine for operaonal safety, complete components and xed
guarding prior to each use.
5.0 SafetyInstrucons–Pre-Operaon
5.1 BasicSafetyInstrucons
Before starng the machine, read and understand these operang instrucons.
5.2 MainComponentsandOperangElements
Below is a descripon of the main components of the LA25 Aerator and how they
operate.
5.3 Engine and Drive
The Honda GX160 (Fig. 1) is a four stroke engine that
runs on standard unleaded fuel.
The engine is air cooled and therefore it is important
that the grille covering the recoil rope is kept clear from
debris.
The engine air lter cleans the air sucked in by the
engine. A clogged air lter will reduce performance.
The engine is ed with a fuel on/o lever and a choke lever. Read the engine
operang instrucons to understand the operaon of these levers.
5.4 OperangLever
The LA25 Aerator nes are engaged by using the lever located underneath the top
of the handlebar (Fig. 2).
PLEASE NOTE THAT THIS IS A TWO STAGE LEVER. THE GREY BUTTON MUST BE
DEPRESSED BEFORE THE MAIN LEVER CAN BE PULLED UP.
Once the drive has been engaged it will
transfer the engine power through a gearbox,
to the ne rods that will rotate. The surface
penetrang nes are held at the end of each
ne rod and will be pushed into the ground
before being withdrawn as the ne rods
rotate.
5.5 Height Adjustment
The depth of the ne penetraon of LA25 Aerator is altered by changing the
posion of the back axles.
Each back axle has three holes by which it can be aached to the main chassis
frame.
Aaching the axles using the lowest posion holes has the eect of moving the
nes closer to the ground and increasing the depth that the aerator will penetrate.
Fig. 3
Spring Washer
Washer
Tine Holder Rod
Tine
Fig. 4
Fig. 5

CAMON LA25 Lawn Aerator
Page 8 LA25 Lawn Aerator
Read and be aware of the warning and instrucon signs located on the machinery.
Cordon o the work area to access from the general public.
Before starng work clear the area of any objects that may cause damage to the
machine.
Do not operate the machine if you are under the inuence of alcohol or drugs. This
equipment must only be operated by persons who are medically t both physically
and mentally.
Only work in good light and visibility.
Do not work in extremes of temperature, or poor weather.
Wear the correct personal protecon equipment as instructed by this manual.
Operator clothing should not be loose and footwear should be enclosed and oer
good grip.
Know how to stop the machine in an emergency.
5.10 EngineSpecicSafetyInstrucons
PETROLIS HIGHLY FLAMMABLE.ALWAYS STOP THEENGINE ANDENSURE THE
FUELTAPISTURNEDOFFBEFOREREFUELING,ORWHENTRANSPORTING,
CLEANING,ORMAKINGADJUSTMENTSTOTHEMACHINERY.
Do not smoke or use a naked ame when refueling.
Use only unleaded petrol from fuel containers designed for this purpose. Refuel
outdoors only and replace the fuel tank cap securely.
Do not mix oil with the fuel.
Leave 25mm (1”) of space in the fuel tank during relling.
Clear up any petrol spillages immediately.
Always start the engine in the open air. Starng an engine within a conned space
can lead to the inhalaon of toxic substances.
Avoid contact with the engine and exhaust during operaon as they will become
hot. Leave the engine to cool prior to contact and storage.
Never interfere with the control sengs of the engine.
5.11 MachineSafetySckerExplanaons
Danger–moving
blades.
Keep hands and feet
away.
!
45342
V
V
X
V
V
X

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 9
Readoperanginstruconsbeforeuse.
Remove spark plug before servicing or
performing maintenance.
Warning: Keep bystanders away.
Maximumsoundpowerlevel(LWA).
Earproteconmustbewornwhenoperangthemachine.
ALWAYSwearsuitablePersonalProtecveEquipment(PPE):
• Ear Defenders
•EyeProtecon
•FootProtecon
• Safety Gloves
Ensure safety guards are in place. Machine MUST NOT
be operated without guards.
Machineidencaonlabel.Indicates
compliance with European standards (CE
mark).Includesuniqueserialnumber,machine
weight,poweroutput,andmonthandyearof
manufacture.
It is important that these sckers are in good condion, are legible, and are in the
correct posions on the LA25 Lawn Aerator.
Do not use the machine if any of these sckers are missing or damaged.
If any sckers are missing or damaged then they must be replaced. They can be
obtained from the Spare Parts Department at Tracmaster Ltd.
!!
1231
2
3
LWA
104
dB
TRACMASTER LTD
Units 6-7
Winterpick Business Park
Hurstpierpoint Road
Wineham, Henfield
BN5 9BJ, UK
T: [phone]
Machine Type: LA25 Lawn Aerator
Weight: 103kg Year ID: June 2021
Power: 3.6kW Serial No: B11-47000

CAMON LA25 Lawn Aerator
Page 10 LA25 Lawn Aerator
6.0 SafetyInstruconsStarngandOperang
6.1 To Start the Engine
Using the dipsck provided,
check the engine oil level.
Top up with SAE 10W/30 oil,
API SJ or later, if the dipsck
is clear of oil.
Check the fuel level. Rell as
necessary and as determined
by the fuel tank type – see
diagram.
Switch the engine ignion
switch to the ON posion.
Turn the fuel tap located
on the engine carburetor
to the ON posion. If the
engine is cold or has not been
operated recently set the
choke lever on the carburetor
to the ON posion.
Pull the engine recoil handle slowly unl it engages then pull hard and fast to start
the engine.
Aer the start, guide the cord back into its posion. Do not let it snap back.
Once the engine has started, if the choke lever has been used, return this to its OFF
posion aer the engine has run for a few seconds.

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 11
6.2 To Stop the Engine
Release the operang lever.
Switch the engine ON/OFF switch to the “O” OFF posion.
Turn the fuel tap lever to the OFF posion.
Ensure the nes have stopped prior to moving the machine.
WARNING:THEEXHAUSTCOVERMAYBEHOT–DONOTTOUCH.
6.3 SafetyEquipment
The LA25 operator must be wearing:
• Ear Defenders
• Gloves
• Protecve Footwear
• Safety Glasses
6.4 Operaon
Before aerang can be carried out the grass must be cut short and be cleared of any
objects such as stones or scks that would damage the Aerator.
WARNING: AERATING LONG GRASS WILL QUICKLY CAUSE DAMAGE TO
COMPONENTS OF THE MACHINE. WE RECOMMEND THE GRASS IS CUT
PRIOR TO AERATING.
Do not operate the Aerator on wet lawns or in wet weather.
Hollow nes should only be used on moist ground condions.
Hardcore or rubble located under the surface of the turf will cause damage to the
machine.
Use a garden fork to test the depth of the turf. The fork must
enter the ground up to 100mm in depth to avoid damage to
the nes or corers.
When safety checks have been completed, start the engine
following the correct procedure.
Posion the throle lever in its midway posion (Fig. 6).
!
!
Fig. 7
Fig. 6

CAMON LA25 Lawn Aerator
Page 12 LA25 Lawn Aerator
Li the operang lever (Fig. 7) to engage
the drive and start the nes rotang in
their lied posion.
PLEASE NOTE THAT THIS IS A TWO STAGE
LEVER. THE GREY BUTTON MUST BE
DEPRESSED BEFORE THE MAIN LEVER
CAN BE PULLED UP.
Push the the ne control lever (Fig. 8),
forward to lower the ne liing board.
This will allow the rotang ne rods to fall to a vercal posion where the nes will
be penetrang the ground.
As the nes begin to penetrate the ground they will start to propel the Aerator
forwards.
DURING OPERATION OF THE LA25 AERATOR APPLY A SMALL PULLING PRESSURE ON
THE HANDLEBAR AS THIS WILL ENSURE THAT THE TINES AND TINE RODS REMAIN
IN A VERTICAL POSITION. THE TINES MUST BE VERTICAL FOR MAXIMUM AERATING
DEPTHS AND EFFICIENT PROPULSION TO BE ACHIEVED.
Do not work the Aerator on slopes of more than 20 degrees. Always work across the
slope, not up and down it.
6.5 ProcedureforUnexpectedShutDown
Release the operang lever.
Turn the engine operang switch located on the handlebars to the OFF posion.
Ensure the nes have stopped prior to moving the machine.
6.6 Residual Risks of the LA25 Aerator
The LA25 Aerator is designed to be pushed by the operator during transportaon
and whilst it propels itself during operaon it does not have a driven axle. It has no
brake system and therefore the operator must hold rmly onto the machine at all
mes when the machine is on sloped areas.
Fig. 7
Fig. 8

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 13
7.0 Maintenance
Important! Before undertaking any maintenance ensure that the engine is
oandthefueltapiso.
7.1 Schedule
Operaon Daily
Every
Week
Every
Month
Engine Check engine oil level SAE 10W/30 API SJ or equivalent
See separate engine manual X X
Machine
Check condion of nes X
Check condion of ne rods X
Check chain condion X
Check operang lever and cable X
Check protecon cover condion X
Check bearings X
Lubricate wheel bearings X
Tighten all nuts and bolts X
Check gearbox oil X X
7.2 Basic Maintenance
Check that all guards are ed securely.
Ensure the cable connecng the operang lever to the engine is securely fastened
at both ends and shows no sign of wear.
Check the condion of the tyres and ensure that they do not show any indentaons
or signicant wear and tear.
Ensure the wheels are held securely and the bolt that holds the wheels onto the
axles is in place.
7.3 Gearbox
Important! Before checking the
gearboxoilleveltheLA25Aerator
needstobeltedbacktoensure
that the gearbox is level. The
front wheels should be raised
approximately 40mm o the
ground (Fig 9). You can also place a
spiritlevelonthegearbox.
!
!
Li the operang lever (Fig. 7) to engage
the drive and start the nes rotang in
their lied posion.
PLEASE NOTE THAT THIS IS A TWO STAGE
LEVER. THE GREY BUTTON MUST BE
DEPRESSED BEFORE THE MAIN LEVER
CAN BE PULLED UP.
Push the the ne control lever (Fig. 8),
forward to lower the ne liing board.
This will allow the rotang ne rods to fall to a vercal posion where the nes will
be penetrang the ground.
As the nes begin to penetrate the ground they will start to propel the Aerator
forwards.
DURING OPERATION OF THE LA25 AERATOR APPLY A SMALL PULLING PRESSURE ON
THE HANDLEBAR AS THIS WILL ENSURE THAT THE TINES AND TINE RODS REMAIN
IN A VERTICAL POSITION. THE TINES MUST BE VERTICAL FOR MAXIMUM AERATING
DEPTHS AND EFFICIENT PROPULSION TO BE ACHIEVED.
Do not work the Aerator on slopes of more than 20 degrees. Always work across the
slope, not up and down it.
6.5 ProcedureforUnexpectedShutDown
Release the operang lever.
Turn the engine operang switch located on the handlebars to the OFF posion.
Ensure the nes have stopped prior to moving the machine.
6.6 Residual Risks of the LA25 Aerator
The LA25 Aerator is designed to be pushed by the operator during transportaon
and whilst it propels itself during operaon it does not have a driven axle. It has no
brake system and therefore the operator must hold rmly onto the machine at all
mes when the machine is on sloped areas.
Fig. 7
40mm
Spirit Level
Fig. 9

CAMON LA25 Lawn Aerator
Page 14 LA25 Lawn Aerator
Remove the oil dipsck
(Fig. 10) and ll gearbox
with approximately 0.3L
of engine oil SAE 10W-30
or equivalent.
Insert and remove the
dipsck without screwing
it into the ller hole and
check the oil level to
make sure it is between the upper and lower limit (Fig. 11).
It is recommended that the gearbox oil is changed every me the engine oil is
changed.
7.4 Engine
7.4.1 Check Engine Oil Level
This is to be checked prior to each use and every 8 hours during operaon.
Check only when the engine is o and in a horizontal posion.
Clean the oil ller plug and its surrounding parts.
Remove the oil ller plug. Clean the dipsck with a clean cloth and put the
oil ller plug all the way back into the engine. Remove the oil ller plug and
check the oil level.
Rell the oil if indicator shows more is required. For the Honda GX160 the
recommended oil is SAE 10W/30 API SJ or equivalent.
7.4.2 Change Engine Oil
Refer to the engine manufacturer’s manual for locaon of components and
more detailed assistance.
Do not change the oil if the engine is hot.
The rst oil change is aer 50 hours of work.
Subsequent oil changes should be made aer each 100 hours of work.
At extreme temperatures or condions change the oil aer every 50 hours.
Open the drain plug on the engine and the lling plug and drain the oil into
a suitable container or use a sucon pump to remove oil through ller neck.
Ensure the waste oil is disposed of properly.
Re-t the drain plug and ghten.
Fill fresh engine oil through the oil lling opening. Use a funnel or similar
device for ease of lling.
Replace the oil ller plug and ghten.
Fig. 11
Lower
Limit
Upper
Limit
Fig. 10
Dipsck

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 15
7.4.3 Air Filter
InspeconCheck:
Remove the air cleaner cover and inspect the lter elements.
Cleaning:
See diagram below containing informaon provided by Honda.
7.4.4 Spark Plug
Clean and replace.
7.5 Cleaning
Aer cleaning, parcularly if a pressure washer has been used, ensure any
lubricaon points are re-lubricated.
Clean the engine with a cloth only. Avoid spraying the engine with jets of water as
this may leak into the fuel and ignion systems.
7.6 Troubleshoong
7.6.1 Machine
Have all serious malfuncons on the machine and engine repaired by an
authorised Tracmaster or Honda agent.
Problem Possible Cause Remedy
No drive to blades Broken chain Replace chain
Poor depth and
propulsion
Operator is pushing the
machine
Pull back on handlebar
during operaon to
ensure nes are vercal

CAMON LA25 Lawn Aerator
Page 16 LA25 Lawn Aerator
7.6.2 Engine
Problem Possible Cause Remedy
Engine does not
start
Spark plug connector
not connected
Connect spark plug
connector
Choke lever is not
actuated Actuate choke lever
Fuel tank empty Fill fuel tank
Fuel line clogged Clean fuel line
Defecve spark plug Clean or replace spark plug
Engine has too much
fuel
Dry and adjust spark plug
and start engine on full
throle
Engine overheats
Low engine oil Rell immediately
Impaired cooling Clean cooling fan grille
Air lter clogged Clean air lter
7.6.3 Lubricants
Use engine oil SAE 10W/30 API SJ or equivalent, as specied by Honda.

CAMON LA25 Lawn Aerator
LA25 Lawn Aerator Page 17
8.0 Transportaon,StorageandHandling
8.1 Transportaon
Use ramps where possible to manoeuvre the Aerator into a transportaon vehicle.
The LA25 Aerator must be xed securely using straps and by placing chocks behind
the wheels.
Always transport the LA25 Aerator horizontally and not lted at an angle.
Ensure that the fuel control lever on the engine is moved into the OFF posion so
fuel does not leak into the carburetor during transportaon.
8.2 Storage
Always allow the engine to cool down prior to storage.
Always clean the machine and dry thoroughly prior to storage and ensure all
lubricaon points have been re-greased.
For periods of long storage, change the engine oil.
Either drain the fuel completely or ll the fuel tank and add fuel stabilizer.
Do not store the Aerator in wet rooms, where ferliser is stored, or in stables as
heavy corrosion may occur.
Always store the machine in a horizontal posion.
8.3 Handling
Do not aempt to li the machine alone. At least two people is the minimum
required.
Gloves must be worn when liing the LA25 Aerator.
Do not lt the machine so that fuel can leak into the air lter of the engine.
When performing maintenance on the Aerator when it is situated on a work bench,
ensure that the machine is rmly held in posion at all mes.
Do not li the machine solely by the engine at any point.

CAMON LA25 Lawn Aerator
Page 18 LA25 Lawn Aerator
9.0 Spare Parts
The spare parts diagrams and part numbers for the CAMON LA25 Lawn Aerator can
be found on our website or by contacng our spare parts department.
Spare parts can be ordered via the following methods:
Phone: [phone] (opon 1)
Website: www.tracmaster.co.uk
Email: [e-mail]
Or via your local Authorised Dealer.
