tradetec TR2789 User manual

Android Car Multimedia
User’s Manual

User’s Manual
2/25
Contents
ANOUNCEMENTS.......................................................................................................................3
OPERATION................................................................................................................................. 4
SETUP............................................................................................................................................ 6
1. Wallpaper..........................................................................................................................6
2. Startup picture................................................................................................................. 7
3. Common setup................................................................................................................ 7
4. Display Setup...................................................................................................................8
5. Sound options..................................................................................................................9
6. Video options................................................................................................................... 9
7. Bluetooth.........................................................................................................................10
8. Navigation.......................................................................................................................11
9. Steering wheel control................................................................................................. 11
ANDROID SETUP...................................................................................................................... 12
RADIO FUNCTION.................................................................................................................... 14
GPS OPERATION......................................................................................................................14
DISC PLAYBACK(OPTIONAL)............................................................................................... 15
U-DISK/SD CARD PLAYBACK...............................................................................................17
IPOD PLAYBACK(OPTIONAL)...............................................................................................19
BT HF OPERATION.................................................................................................................. 20
BT MUSIC (A2DP)..................................................................................................................... 21
AV IN (AUXILIARY INPUT)........................................................................................................21
DISPLAY SCREEN INTRODUCTION.....................................................................................21
GPS ANTENNA INSTALLATION........................................................................................... 23
TROUBLE SHOOTING............................................................................................................. 24

User’s Manual
3/25
ANNOUNCEMENTS
For your safety, please try not to watch the video and operate the machine while
driving; please turn the volume to the level less than the outside sound. Before you
start, please read this manual and other manuals of this system to understand the
safety instructions and warning signs on this manual and the machine. After reading,
please put it in readily reachable place so as to refer to the manual anytime.
Please note that traffic safety firstly.
If you are in trouble with your system, please park your car in a safe place.
Do not allow children to operate the machine, so as to avoid personal injury or
machine damage.
Please follow the traffic rules when using the satellite navigation function.
Please do not use electronic equipment or prohibit the use of fire, such as: gas
stations, wineries, electromagnetic interference areas, etc., or may cause
danger.
Do not carry out maintenance, maintenance and installation of this machine. Do
not install or service the unit in the event of a power supply. Installation and
maintenance of this machine by a person who has not been trained or
inexperienced by an electronic device or vehicle accessory is dangerous.
Do not store or install this machine in direct sunlight, nor place it in other
hazardous substances, especially the LCD screen. If installed, the LCD screen
is just in the air conditioner near the ventilation duct, please ensure that the cool
air or hot air do not blow directly to the machine, otherwise it may damage the
machine, and even the car or personal injury.
Do not use some sharp objects to draw the screen, do not take hard objects to
press the display, otherwise it will cause the display or touch screen damage.
In order to ensure the normal operation of the machine, to prevent the
occurrence of fire or electric shock, please do not expose the machine in the
humid air, not the liquid spilled on the machine.
If the machine supports discs (optional), only 12 cm discs can be played, and
only one disc can be played at a time. Please do not insert 8 cm discs or other
items into the machine.

User’s Manual
4/25
OPERATION
System Reset
1）When using the unit for the first time, press and hold the "RESET" button for
more than 3 seconds to restore the machine to the factory settings.
2）When the abnormal operation caused by improper operation and other abnormal
phenomenon, please press the reset "RESET" button for more than 3 seconds,
the machine can return to normal.
Note: Since the reset button on the panel is small, use a pen tip or similar pointed
object.
Turn on / off the unit
1）When the ACC switch is on, press the "POWER" button on the main panel to
turn on the power;
2）Insert the disc into the disc, the machine will automatically open, open to enter
the disc mode;
3）When starting the machine, long press the main panel "POWER" button switch,
or flame out the car key will turn off the power of the machine.
Volume adjustment
Rotate the volume knob on the panel (the volume control key on some model panels
is the "VOL + / VOL-" button) to adjust the volume of the unit.
Mute switch
Press the "MUTE" button on the panel to mute the system, press again or adjust the
volume to restore the sound.
Backlight switch
Short press the back light switch "LIGHT" button on the panel or remote control to
turn the backlight of the unit's display on or off.
Reversing camera
After the vehicle is reverse, regardless of the machine is turned on or off, the display
will immediately switch to the reverse camera screen.
Play source selection
1）Press the "MODE" button on the main panel or the remote control to toggle
between radio, disc playback, USB playback, SD playback, mobile TV (optional),
IPOD playback (optional), or AVIN
2）In the home page interface, touch the different function icon to enter the
corresponding interface, the detailed operation of each function see the next
chapter. Touch the sliding home page to switch between multiple home pages.

User’s Manual
5/25
DISC ESP electronic shock function (disc is optional)
The machine has an electronic shock function, so the car even if the road is not very
good road and vibration, the machine's audio and video playback will not be affected
much, of course, the length of the shock time will play different discs vary. The
following shock time is for reference only: DVD disc - about 5 seconds; CD / VCD
disc - about 10 seconds; MP3 - about 150 seconds.
Mode and play position memory
Turn off the power of the unit, and then re-boot, the system will return to the original
shutdown mode. If it is a radio, will continue to listen to the memory before the radio,
if it is music or video, will continue to resume from the last resumed playback.
