tradetested GS506-V1 User manual

18001820
3070
7401550
1750
www.tradetested.co.nz[email protected]0800 800 880GARDEN SHEDMANUAL GS506-V1Shed Size at Roof: 1750x3070x1820mmShed Size at Floor: 1550x3070x1800mmDoor Size: 1750x740mmInternal Shed Size at Floor: 1510x3030mm

1Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDBefore you begin● Check local building codes regarding shed locaonandanyotherlocalrequirements.● Check the packing list on page 4 to make sure you have all of the necessary parts.● Separate everything in the cartons by the part number while reviewing the parts list.● Be sure the day you select to build your shed is dry and calm.● Whenever possible, two or more people should work together to assemble the shed. Wesuggest that one person posionspartswhiletheotherhandlesthefastenersandtools.Before assembly, decide on a locaonforyourshed.Werecommendalevelareawithgooddrainage. Allow enough space around the building so there's plenty of room to screw thepanels and move the differentpartsintoposion.Remembertoleaveplentyofroomforthedoor to fully open.● An electric drill/driver● A Phillips screwdriver● Gardening or work gloves● Sealant or caulking gum (oponal)● Step ladder● Tape measureSafety FirstSafety precauonsareimportanttofollowthroughouttheconstruconofyourbuilding.● Take care when handling the various pieces of your building since some contain sharpedges. Please wear work gloves, eye proteconandlongsleeveswhenassemblingorperforming any maintenance.● Keep children and pets away from your worksite to avoid distraconsandanyaccidents.● Never concentrate all your weight on the roof of the structure. When using a stepladder make sure it’s fully open and on a level surface.● To avoid any damage, do not aempttoassemblethebuildingonawindyday.Thelarger panels can act as sails making construcondifficultandunsafe.You Will Need...Selecting & Preparing Your Site

2Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDFlooring & FoundationsA solid shed starts with a level floorandfoundaon.Thisisthesinglemostimportantfactorinmakingyour shed as waterghtandstableaspossible.Italsomakestheassemblyprocessassimpleaspossible.We recommend the following foundaonopons:Opon1‐WoodenFloorWe sell wooden floorkitsdesignedtomatchyourshed.AlternavelyyoucanbuildyourownusingH4treated bearers and mberfloorboards.Regardless of which flooringoponyouchoose:● Build on a compacted and levelled base layer.● Plastic sheeting placed under the wood or concrete will prevent moisture wicking through.● We recommend the foundation is the same size as the footprint of your shed to prevent water ingress.Opon2‐ConcreteSlabFor a more permanent soluon,orforlargesheds,werecommenda100mmthickconcretefoundaon,ideally with a 25mm rebate for walls and corner anchors.Assembly OverviewStep 1: Check all parts against the parts listStep 2: Assemble the rear wallStep 3: Assemble the side wallsStep 4: Assemble the front wallStep 5: Assemble the roofStep 6: Assemble the doorStep 7: ConstrucngthewallsStep 8: Installing the BracingStep 9: ConstrucngtheroofStep 10: Installing the doorStep 11: Fixing to the floorStep 12: Finishing touches

3 ASSEMBLYINSTRUCTIONS

4Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDGS506-V1If you’re missing anything, just head to www.tradetested.co.nz and get in touch.PARTS LIST1Check all parts against the parts list12W180Front Wall410 x 180024W180RearWall410 x 180038P175Roof Panel410 x 1750416 W180 410 x 1800589102U155RearWall Channel118 U155SideWall Channel1550 124U155Roof Channel1550 132G175 Roof Channel17502 U155FrontWall Channel15501U180LeDoorFrame18001MR180Right Door Frame1Z0745DoorTop Frame7451U0745745Door BoomFrameITEMQTYPART #NAMESIZE (mm)67Corner Anchor8Hook Anchor4Tek Screws200Wood Anchor Screws10Rivet50Corner Cover4Spacer50Rivet Gun1Tek Screwdriver Bit11800φ4.0Drill Bit1Screw Head Sheath30Phillips Head Screws20 15 16 17 18 19 20Z111 21 22 23E175 x 410E175 x 350U074U175D173H074DOOR PARTQTYPART # 24 25 26 271122112SIZE (mm)410 x 1750350 x 17507401750173074011101550SideWallITEM 28 29 30 31 32 33 34 35NAMEDoor PanelDoor PanelDoor ChannelDoor ChannelDoor Square tubeDoor BarDoor Brace12BoltHingeBoltHingePlease check your contents prior to starngassembly8Z1301300Wall Bracing 14

5Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHED2a#W180 x 4Rear Wall PanelsiAll panels should overlap by one corrugation.#U155 x 2Rear Wall ChannelsibProfile ShapeAssemble the rear wall○ It is helpful to read andunderstand the full instructionmanual before starting.○ For additional helpful ReferenceImages see page 18 of thismanual.○ Select number of panels for rearwall and find flat level ground forassembly.○ Lay the panels out as shown withthe large riboverlappingthe small.○ Slide on the rear wall channels untilthe holes in the top of the channelalign with the peaks of the panels.The holes should be up, on theoutside face of the shed.○ Check that the panels arepushed hard into the channeland are perpendicular.Large RibSmall Rib
#U155
#W180#W180#W180#W180OutsideInside#W180 x 4
OutsideInsideAll pre-drilled holes should line up with the peaks ofthe panel. If this varies, squeeze together or stretchout the panels to make sure they align.
#U155

6Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDcTek ScrewsiStart with the thin peaks where panel overlaps occur,then move on to the middle of each panel.If needed, use a small wooden block behind themiddle of the panel for support while screwing.Make sure the block is not directly underneath thescrew.○ The tek screws provided are selfdrilling, there is no need to create apilot hole.○ Screw through the channel holesand through the overlapped panels.Make sure the screws go through alllayers.○ Do not add screws to the firstand last holes. Indicated withan X in diagram. These needto be left undone.○ Once finished, lay thewall flat out of the way.Assemble the side walls
Block behind
32Assemble the rear walla#W180 x 16Side Wall Panels#U155 x 8Side Wall ChannelsProfile Shape○ Lay the side wall panels out asshown with the large rib overlappingthe small.○ Slide on the side wall channels untilthe holes in the top of the channelalign with the peaks of the panels.○ Check that the panels are pushedhard into the channel and areperpendicular.
#U155#U155
x 2
OutsideInside#W180 x 8
#U155#U15515mm
XXXX

7Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDaAssemble the front wall○ Lay the front wall panels out asshown with the large rib overlappingthe small.○ Place the front wall #MR180channel over the #W180 wall panel.Have the pre-drilled holes in the#MR180 on the panel side.#W180 x 2Front Wall Panels#MR180 x 1Right Door FrameProfile Shape
#W180#W180#MR180
43
#MR180#W180
Assemble the side wallsiStart with the thin peaks where panel overlaps occur,then move on to the middle of each panel.If needed, use a small wooden block behind themiddle of the panel for support while screwing.
Block behind
bTek Screws○ Slide on the #U180 left door frameU channel to the preferred side forthe door.○ This can be done when the back /side walls are up and connectedbefore placing the front wall.○ Screw through the channel holesand through the overlapped panels.Ensure they through all layers.○ Do not addscrews to the firstand last holes.Indicated with anX in diagram.These need to beleft undone.○ Once finished,lay the wallflat out of theway.#U180 x 1Left Door FrameOptional:○ The single door on this shed can be located on theleft, as instructed, or on the right. Keep this in mindwhen placing the #U180.XXXX
#U180#U180 Alternative

8Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDbTek Screwsc#U0745 x 1Door Bottom FrameProfile Shape#U155 x 2Front Wall Channels#Z0745 x 1Door Top FrameProfile Shape
#U155#U155#U0745#Z0745TOPBOTTOM
i○ Slide on the front wall channels,through the slot in the #MR180, untilthe holes in the top of the channelalign with the peaks of the panels.Overhang one side to form doorframe.○ Check that the panelsare pushed hard intothe channel and areperpendicular.○ Slide the #U0745 door bottom frameU channel under the bottom #U155U channel.○ Slide the #Z0745 door top frame Zchannel under the top #U155 Uchannel.○ The positions of these piecesdepend on whether the door openson left or right.○ Screw through the channel holesand through the overlapped panels.Make sure the screws go through alllayers.○ Screw through the channel holesand through the top and bottomdoor frames.○ Do not add screws to thefirst and last holes or at the#MR180. Indicated with anX in diagram. These need tobe left undone.○ Once finished, lay the wallflat out of the way.
#MR180
4Optional:○ The single door on this shed can be located on theleft, as instructed, or on the right. Keep this in mindwhen placing the #U0745 and #Z0745.All pre-drilled holes should line up with the peaks ofthe panel. If this varies, squeeze together or stretchout the panels to make sure they align.Do not add screws to the #MR180, it will need tobe adjusted later on.#Z0745UNDER#U155#U0745UNDER#U155XXXXXXFLUSH ENDS

9Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDa#P175 x 8Roof PanelsbAssemble the roof#U155 x 4Roof ChannelsProfile ShapeTek Screws○ Lay the panels out as shown withthe large rib overlapping the small.○ Slide on the roof channels until theholes in the top of the channel alignwith the peaks of the panels.○ Check that the panels are pushedhard into the channel and areperpendicular.○ Screw through the channel holesand through the overlapped panels.Make sure the screws go through alllayers.○ Do not add screws to the first andlast holes. Indicated with an X indiagram. These need to be leftundone.○ Once finished, lay the roof flat out ofthe way.i5
#U155
OutsideInside
#U155
#P175 x 8
Block behind
All pre-drilled holes should line up with the peaks ofthe panel. If this varies, squeeze together or stretchout the panels to make sure they align.
#U155#U15515mm
XXXX

10Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDaiAll panels should overlap by one corrugation.bAssemble the doors
#E175 x 410#E175 x 350
#E175 x 410 x 1Door PanelRivet#U175 x 2Door Channel#U074 x 2Door Channel#D173 x 1Door Square Tube#E175 x 350 x 1Door Panel#U074
#U175PLACE #D173 BEHIND#U175
#H074Door Bar
FRONTFRONT
○ Lay the panels out as shown withthe large rib overlapping the small.○ Slide on the door channels. Placethe #D173 in position (dashed)behind the #U175.○ Check that the panels are pushedhard into the channel and areperpendicular.○ Drill through the channels and thepanels / #D173 below in thepositions shown with the Ø4.0mmdrill bit.○ Using the rivet gun provided, fix thechannels together with the rivets.Follow the instructions included onthe tool packaging.○ Make sure the rivets go through alllayers.○ Ensure the door is square andpieces are pressed firmly togetherduring construction.○ The Door Bar is located in thecentre of the door panels. Ensureaccurate measuring.6Rivet GuniTo drill rivet holes in panels use a 4.0mm drill bit andset your drill clutch to the drill bit icon. Make a markwhere you want to drill and use this to start the hole.Don’t worry if you have placed a rivet incorrectly, theyare easy to remove. Just drill directly through the topof the rivet using the same drill bit. This will removethe rivet head, causing the whole rivet to fall out.#H074
400mm875mm (central)
#U074#D173UNDER#U175UNDER#U074
#D173 dashed

11Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDcdRivetsFLIP#Z111 x 2Door BraceProfile ShapeiUse the drill bit to drill pilot holes through the doorbracing into the panels. After flipping, fix togetherusing the rivets and spacers through the pilot holes.
DRILLDRILLDRILLDRILLDRILLDRILLFRONTBACKFRONT
FLIP○ Flip the partially complete door overso the back side is facing up.○ Using the Ø4.0mm drill bit, drillthrough the channels and thepanels / #D173 below in the cornerpositions shown.○ Using the rivet gun provided, fix thechannels together with the rivets.○ Slide the door braces under thedoor channels.○ Drill through the channels and thedoor braces below in the positionsshown.○ Using the rivet gun provided, fix thechannels to the ends of the braces.○ Do not force the braces too hard asthis can distort the door. It is okay tofix one brace to another rather thanto the channel.○ Drill pilot holes through the bracesand the panels below in thepositions shown.○ Flip the partially complete door overso the front side is facing up.○ Ensure the pilot holes drilled beforeare still aligned. If they are not, drillthrough again from the front side.○ Prepare 6x rivets with spacers onthe wider end.○ Using the rivet gun provided, fix thepanels to the bracing with spacerrivets.○ Roll the door onto its side. Drill andrivet the door hinges approx. 1hinge length from the top andbottom of the door. Use the hingeitself as a guide.○ Attach the smaller side of the hingesto the door channel.6Hinge x 2Rivetswith spacersAssemble the doors#Z111 AND #U175UNDER#U074BOTH #Z111UNDER#U074
#D173 dashed

12Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDaCorner Anchor x 4○ * If placing on a pre-preparedwooden flooring slide the cornerangles onto edge bearers, underthe perimeter floor board (this iswhy a nail was left out in thecorner).○ Have a friend hold the back wall inplace as shown. If the wall is large,a wheely bin or stepladder aresufficient alternatives.Constructing the wallsTek ScrewsTOP VIEW
CONCRETE SLAB FOUNDATION
*WOODEN FLOORING*WOODEN FLOORINGiIt is very important to have a level foundationprepared to the correct size. A wooden floor, or aconcrete slab.○ Have the same friend hold the sidewall at the same time, at a rightangle to the back wall, over theplaced corner anchor below.○ The wall channel flaps shouldoverlap each other in the corner andjust touch at right angles as seenfrom the outside.○ Fix through the corner anchor to thewall channel top and bottom. It iseasier to start with the top to relieveyour friend from holding duties early.○ When on flat flooring, place a spiritlevel or timber block under the shedcorner. This will ensure the wallsstay at the same height as you drillscrews into corner anchor.○ After the top and bottom corneranchor is fixed, screw through theoverlapping panels from the outsideto make the shed weathertight.
OutsideInside
Optional:○ Once the walls are up and theedges of the panels overlap, wesuggest running sealant up the fullheight between the corner overlapbefore fixing. This will protect theshed more from heavy weather.
Overlap
7
SIDE WALL
BACK WALL
Outside
Temporary Level / Blockunder corner anchor.

13Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDbCorner Anchor x 4Tek ScrewsTOP VIEW○ Hold the side wall at a right angle tothe connected back and side walls,over the placed corner anchorbelow.○ The wall channel flaps shouldoverlap each other in the corner andjust touch at right angles as seenfrom the outside.○ Fix through the corner anchor to thewall channel top and bottom. It iseasier to start with the top to relieveyour friend from holding duties early.○ When on flat flooring, place a spiritlevel or timber block under the shedcorner. This will ensure the wallsstay at the same height as you drillscrews into corner anchor.○ After the top and bottom corneranchor is fixed, screw through theoverlapping panels from the outsideto make the shed weathertight.
OutsideInside
OverlapDiagonal distanceto be equal.
○ Hold the front wall between theconnected side walls, over theplaced corner anchors below.○ When on flat flooring, place a spiritlevel or timber block under the shedcorner. This will ensure the wallsstay at the same height as you drillscrews into corner anchor.○ The far corner of the shed in thediagram is connected the same asthe corners previously.○ After the top and bottom corneranchor is fixed, screw through theoverlapping panels from the outsideto make the shed weathertight.○ The top and bottom door framesshould butt hard into the verticaldoor frame at right angles as seenfrom the top.○ Fix through the corner anchor to thewall channel top and bottom. It iseasier to start with the top to relieveyour friend from holding duties early.○ Check the squareness of the shed.The diagonal measurements needto be equal.Optional:○ Once the walls are up and theedges of the panels overlap, wesuggest running sealant up the fullheight of the corner before fixing.This will protect the shed more fromheavy weather.7
SIDE WALL
FRONT WALL

14Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDa○ Hold a single #Z130 wall bracingprofile, lapped underneath themiddle of the wall top channel. Holdit diagonally. Drill through thebracing channel and wall panel withthe Ø4.0mm drill bit, at the middlepoint between ribs. Drill the holefrom standing inside the shed.○ After creating a hole through bothlayers, have a friend insert a rivetwith spacer from the outside andengage the rivet with the rivet gunsupplied.○ Repeat the above steps with thelower diagonal brace, drill throughthe middle point between lower ribs.○ Where the two braces overlap in themiddle, drill and rivet as shown,from the outside, in the middlebetween ribs. A tek screw from theinside is optional.○ Repeat again for all diagonal bracesin positions indicated.Installing the bracingRivet Gun8Rivetswith spacers#Z130 x 8Wall Bracing
FromOutside
FromOutsideFromOutside
Opt.
Centre of wallBetween ribsBetweenribs
+/- 220mm
DRILL
DRILL
#Z130 x 2
#Z130 x 2
#Z130 x 2
#Z130 x 2
Rivet From OutsideRivet From OutsideInside of Wall shown.DRILLDRILLDRILLDRILLDRILLDRILLDRILLDRILL
#Z130 x 2
#Z130 x 2
Opt.Opt.

15Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDab○ Check the squareness of the shed.The diagonal measurements needto be equal.○ Place the prepared roof panelloosely on top of the nowassembled walls and align theedges with the side walls.○ Maintain an equal overhang to thefront and the back walls. This isusually close to 100mm.○ Prepare tek screws with spacers onthe ends. This helps with shedweather tightness.○ The edge of the roof needs to beparallel with the edge of the wall. Dothis by transferring the same offsetfrom below the overhang to on topwith a measuring tape, just add10mm to find the centre of the top ofthe wall channel. It is recommendedto start in the corners and screw thebase of every second corrugation.○ Twist the shed where required tomaintain the roof alignment with theside walls and keep the shedsquare.Constructing the roof#G175 x 2Roof Channel○ Once the roof is fully secured, pushthe #G175 Roof Channel over theedge of the panels and into the topwall channels front and back.○ Cover the corner of the roof, overthe roof channels, with the plasticcorner covers. Screw these in placewith a single self drilling tek screweach. This screw should go throughthe both channels.○ There should not be any need toclimb on the roof.Optional:○ You may also screw through thecentre of the side roof channel,through to the top of the side wallchannel.○ Use tape provided to cover over theinsides of the shed, all around,between the top of the wallchannels and the underside of theroof panels. Shown dashed in thecut view.Tek ScrewCorner Cover x 4Profile ShapeCUT VIEW
#G175
#G175#G175
+/- 100mm+/- 100mm
9Tek Screwswith Spacers

16Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDInstalling the doorPhillips Head Screw○ Have your shed building buddy holdthe assembled door open with thehinges aligned with the right doorframe #MR180. The top and bottomof the door should fit easily withinthe frame of the front wall.○ Centralise the door vertically andscrew through one of each of thehinges holes, through to the#MR180 only, using the phillipshead screws provided. The screwsare self drilling and do not require apilot hole.○ With one screw in each hinge andthe right door frame free to moveside to side check that the door canclose easily and is at the correctheight.○ If the door is hanging at the correctheight you are free to screw theremaining screws into the hinges.Optional○ If you would like a morepermanently hung door the screwscan be replaced with rivets. Thisdoes limit future adjustments.○ The right door frame should nothave had any screws fixing it inplace and the door should be ableto be adjusted by moving the frameuntil the door sits happily in the doorframe.○ Once you are happy with the doorposition, add screws to secure theright door frame, #MR180, to thetop and bottom front wall channels.○ The door should be able to swingopen and closed without hitting thedoor frame but also be closeenough to the left door frame toallow for bolt install.○ Screw through the right door frameand through the front wall panel tosecure the frame vertically.○ Use phillips head screws to firstsecure the bolt to the door bar,#H074, and then to secure the boltkeeper to the left door frame,#U180. Pilot holes may be requiredhere as any scratches made will bevisible.
Bolt andBolt keeper
#MR180adjustment
10DoorBolt (Outside)

17Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHED○ Place screw head sheaths to anyexposed screw heads within theshed. Most noticable are the screwsthrough the front wall panel behindthe right door frame.○ If the shed is sitting on top of awooden platform (not a flooring kit),use the wood anchor screws andthe hook anchors to secure thebottom wall channels and the corneranchors to the flooring.○ If the shed is sitting on a TradeTested flooring kit, use the woodanchor screws to secure the bottomwall channels to the bearers.○ If the shed is sitting on a concretefoundation, use concrete screws(not included in kitset) and the hookanchors to secure the bottom wallchannels to the flooring.Fixing to the floorWood Anchor ScrewOr Concrete fixingsHook AnchorSFinishing touchesDisplay of PrideMisc. ItemsScrew sheath1112
HookAnchor
i○ Congratulations. You are finished!○ Review the instruction manual andmake sure you haven't missed anyimportant steps.○ The shed has enough fastenings tobe very durable throughout a rangeof weather conditions.○ There are extra fixings included inthe kitset, just in case you wish tomake any further adjustments orhang items from walls. Just be sureto use the spacers on tek screwsthrough walls to keep water out.○ Use silicone to further weatherproofaround the shed (not included).○ If you are having any issuesduring assembly, or decide yourequire an assembly service, justgive us a call on 0800 800 880 oremail [e-mail]- our friendly team are here tohelp!Make sure you remove metal drill filings. This willavoid scratches and will help prevent any corrosionlater on.Peel off part number stickers with a cloth, soap andwater.

18Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDHook AnchorCorner CapCorner Anchor Exterior - BottomCorner Anchor Interior - TopDoor Frame - TopDoor HingePad BoltCorner Anchor Interior - BottomDoor Bracing - BottomDoor BarDoor Bracing - CentreDoor Bracing - TopReference images

19Trade Tested - GS506-V1 - 1.55x3.07 GARDEN SHEDCare & MaintenanceFINISHFor a long lasngfinish,periodicallycleanandwaxtheexteriorofyourunit.Touchupscratchesassoonasyou nocethem.Remember to make sure you remove any metal drill filingsaerconstruconto helppreventanycorrosion and scratches.OTHER TIPS● Do not store swimming pool chemicals in your building as they can cause corrosion.● Use silicone caulking to further waterghtsealsthroughoutthebuilding.● Peel offpartnumbersckerswitha cloth,soapandwater.● Use silicone to further weatherproof seals around the shed (not included).ROOFDOORSKeep doors closed and locked to prevent wind damage.FASTENERSKeep the roof clear of leaves and snow with a long handled, so‐bristledbroom.Heavyamountsofsnowon the roof can damage the structure, making it unsafe to enter.Use all washers supplied to protect the shed panels against weather. Regularly check your building forloose screws or bolts and reghtenthemasneccessary.
