Keter MANOR 6x4DD User manual

WWW.KETER.COM
ASSEMBLY INSTRUCTIONS | INSTRUCCIONES DE MONTAJE | MONTAGEANLEITUNG | CONSIGNES
DE MONTAGE | SAMLEVEJLEDNING | MONTAGE-VOORSCHRIFTEN | ISTRUZIONI D’ASSEMBLAGGIO
MANOR 6x4DD
A-1274-1 554745
MANOR 6x4DD
2 easy steps to use a QR-code:
1. Download a FREE QR-Code
reader from your smartphone
application site.
2. Scan the QR-Code.
SKU:
17197127 | 17194152
Thank you for your purchase of the Keter shed,
In order to activate your warranty, please enter
www.keter.com, under storage buildings
category and fill in the sheds warranty
activation form.
WARRANTY
ACTIVATION
WWW.KETER.COM
US: # 1-888-374-4262
Canada: # 1-800-661-6721
UK: # 0121-5060008
Other European Countries:
# 31-1612-28301
BRINGEN SIE IHR PRODUKT NICHT GLEICH ZUM LADEN ZURÜCK, FALLS TEILE FEHLEN ODER DEFEKT SIND.
VAN ONTBREKENDE OF GEBROKEN ONDERDELEN NIET HET PRODUCT NAAR DE WINKEL RETOURNEREN.
DI PARTI MANCANTI O DANNEGGIATE, EVITARE DI RESTITUIRE IL PRODOTTO AL NEGOZIO.
PEÇAS EM FALTA OU PARTIDAS, NÃO DEVOLVA O PRODUTO À LOJA.
IF THERE ARE MISSING OR BROKEN PARTS, PLEASE DO NOT RETURN THE PRODUCT TO THE STORE
Please log onto our website, or contact Customer Service at:
S’IL Y A DES PIÈCES MANQUANTES OU CASSÉES, NE RETOURNEZ PAS LE PRODUIT AU MAGASIN
Veuillez visiter notre site Internet, ou contacter notre Service Clientèle:
BITTE
Bitte loggen Sie in unsere Website ein oder wenden Sie sich an unseren Kundenservice:
SI HUBIERA ALGUNA PARTE FALTANTE O DAÑADA, NO DEVUELVA EL PRODUCTO A LA TIENDA
Inicie sesión en nuestro sitio en Internet o contáctese con nuestro servicio de atención al cliente:
IN GEVAL
Ga naar onze website of neem contact op met de Klantenservice:
IN CASO
Accedere al nostro sito o contattare il Servizio Clienti:
SE HOUVER
Entre na nossa página de Internet ou contacte o Serviço de Clientes:

2

3
Clear area of stones | Remove all plants, roots and other obstacles | Rake the ground | Make ground level using a long, flat object
(e.g. wood beam)
Retirez toutes les pierres | Arrachez toutes les plantes, racines et autres obstacles | Ratissez le sol | Aplanissez le sol à l'aide d'un
objet long et plat (une planche en bois par exemple)
Beseitigen Sie Steine | Entfernen Sie alle Pflanzen, Wurzeln und andere Hindernisse | Pflügen Sie den Boden durch | Ebenen Sie den
Boden mit Hilfe eines langen, flachen Objektes (wie z.B. eines Holzbalken) aus.
Saque las piedras del área | Retire todas las plantas, raíces y otros obstáculos | Rastrille la tierra | Nivele el suelo usando un objeto
largo y plano (por ejemplo, una viga de madera).
Verwijder stenen | Verwijder alle planten, wortels en andere obstakels | Hark de grond | Maak de grond met een lang, vlak onderw-
erp (bijv. een houten balk) waterpas
Eliminare le pietre | Rimuovere piante, radici e altri ostacoli | Livellare il terreno | Mettere a livello il terreno utilizzando un oggetto
lungo e piatto (ad es. un asse di legno)
Retire as pedras do local | Retire todas as plantas, raízes e outros obstáculos | Alise o local | Nivele o solo utilizando um objecto
comprido e plano (por exemplo, uma trave de madeira)
LEVEL THE GROUND | NIVELLEMENT DU SOL | NIVELE EL SUELO | SORGEN SIE FÜR EINE EBENE
GRUNDFLÄCHE MAAK DE GROND WATERPAS | METTERE IL TERRENO A LIVELLO | NIVELAR O SOLO
CAUTION | AVERTISSEMENT | WICHTIG | ADVERTENCIA | WAARSCHUWING | ATTENZIONE | ATENÇÃO

4
GENERAL PARTS LIST
FLOOR PARTS LIST (go to stage 1)
s26b
26mm (x10)
t (x4)
c1a (x1)
164cm
c1e (x2)
106cm
f1b (x1)
111cm x 169cm
c1a
t
t
t
t
c1e
c1e
c1d
dsl
dsr
c1d
d1a
sc15
16mm (x6)
d1a (x1) 138cm
dsl (x1) dsr (x1)
c1d (x2)
o
o
door partswalls parts
roof parts
floor parts

5
WALL PARTS LIST (stage 8)
DOOR PARTS LIST (stage 29)
ROOF PARTS LIST (stage 23)
e1c (x2) 133mm
e1a (x4) 87mm
rc (x4)
kc (x2)
s26b (x44)
26mm
rc
rc
rc
rc
kc
kc
e1c
e1c
e1a
e1a
e1a
e1a
r1b
121cm x 195cm
db1 (x1)
dp1 (x2)
dh (x4)
s13b (x35)
12mm
dpt (x2) dp1
dh
dpt
dp1
dh
dh
dh
dpt
dl1a
dr1a
s26b (x66)
26mm
ds2b (x10)
12mm
s10b (x8)
12mm
bu1a (x1)
c1b (x4 )
186cm
w1b (x2)
111cm x 187cm
fu1a (x1)
dfl (x1) 179cm
dfr (x1) 179cm
v (x2)
fd1b (x2)
17cm x 123cm
bd1a (x1)
169cm x 109cm
h1b (x1)
165cm rm (x1)
lm (x1)
dt (x2)
bu1a
v
fd1b
bd1a
v
h1b
fd1b
w1b
w1b
dt
dt
dfr
dfl
lm
rm
fu1a
c1b
c1b
c1b
c1b

6
FLOOR ASSEMBLY
f1b (x1)
111cm x 169cm d1a (x1) 138cm
18 cm
18 cm
dsr (x1)
dsl (x1)

7
c1d (x2)
c1d
c1d
2
1
t (x4)
c1a (x1)
164cm
c1e (x2)
106cm
c1e
c1e
c1a
1
2
1
2
front

8
Flip the floor upsidedown
s26b (x10)
26mm sc15 (x6)
16mm
s26b
Fully fit the panel
inside the porfile
sc15
sc15
s26b sc15
10cm
10cm
s26b
175 cm

9
Flip the floor upside
WALL ASSEMBLY
c1b (x1)
186cm
w1b (x1)
111cm x 187cm
c1b
front
1
2
front
This side up

10
s26b (x8)
26mm
bd1a (x1)
169cm x 105cm
Fully fit the panel
inside the porfile
bd1a
This side up
back
This side up
s26b
h1b (x1)
165cm
h1b
Outside
Fully fit the panel
inside the porfile

11
c1b (x1)
186cm bu1a (x1)
s26b (x7)
26mm
Fully fit the panel
inside the porfile
s26b
c1b bu1a
Fully fit the panel
inside the porfile
c1b (x1)
186cm
s26b (x5)
26mm
s26b
c1b

12
s26b (x5)
26mm
w1b (x1)
110cm x 185cm
Fully fit the panel
inside the porfile
w1b
This side up
s26b
c1b (x1)
186cm
s26b (x5)
26mm
Fully fit the panel
inside the porfile
c1b
s26b

13
Fully fit the panel
inside the porfile
FRONT WALL & DOOR FRAME ASSEMBLY
s26b (x6)
26mm
fd1b (x2)
17cm x 123cm
s26b
fd1b
fd1b
rm (x1)
lm (x1)
rm
lm
rm
Right
Left

14
s26b (x4)
26mm
fu1a (x1)
fu1a
s26b
s26b
dfr (x1) 179cm
dfl (x1) 179cm
ds2b (x2)
12mmbb
dfl dfr
dfr
1
ds2b
2
This hole
faces outside
and down

15
dt (x2)
ds2b (x8)
12mm
ds2b
x4
dt dt
2
1
s10b (x6)
12mm
Fully fit the panel
inside the porfile
s10b
x8

16
s26b (x18)
26mm
s26b
s26b
s26b (x8)
26mm
s26b
Fully fit the panel
inside the porfile
s26b
s26b

17
ROOF ASSEMBLY
e1c (x2) 133mm e1a (x4) 87mm rc (x4)r1d (x1) folded
rc
Note:
The roof folding line,
and the “This side Down”
label, must be seen
at this stage.
1
2
rc
rc
e1c
e1a
rc
2
e1a
e1a
e1a
e1c
7.5 cm
7.5 cm
1
s26b (x8)
26mm
Fully fit the panel
inside the porfile
s26b

18
s26b (x20)
26mm
Fully fit the panel
inside the porfile
s26b

19
s26b (x12)
26mm
x12
s26b
Screwe on the mark line

20
DOOR ASSEMBLY
Right
Left
dh (x 4)
dl1a (x1)
s13b (x16)
12mm
dr1a (x1)
dr1a (right)
dl1a (left)
dh
dh
s13b
dh
dh
