Trane Technologies Thermo King T-590 Series User manual

Revision B
August 2020 TTKK 5566770022--11--OOPP--EENN
T-590, T-690, T-890 and T-1090 Series
Single Temperature Units with Premium H I
Operator’s Manual

2TK 56702-1-OP-EN
Introduction
This manual is published for informational purposes only and the
information furnished herein should not be considered as all-inclusive or
meant to cover all contingencies. If more information is required, consult
your Thermo King Service Directory for the location and telephone number
of the local dealer.
TThheerrmmoo KKiinngg’’ss wwaarrrraannttyy sshhaallll nnoott aappppllyy ttoo aannyy eeqquuiippmmeenntt wwhhiicchh hhaass
bbeeeenn ““ssoo iinnssttaalllleedd,, mmaaiinnttaaiinneedd,, rreeppaaiirreedd oorr aalltteerreedd aass,, iinn tthhee
mmaannuuffaaccttuurreerr’’ss jjuuddggmmeenntt,, ttoo aaffffeecctt iittss iinntteeggrriittyy..””
MMaannuuffaaccttuurreerr sshhaallll hhaavvee nnoo lliiaabbiilliittyy ttoo aannyy ppeerrssoonn oorr eennttiittyy ffoorr aannyy
ppeerrssoonnaall iinnjjuurryy,, pprrooppeerrttyy ddaammaaggee oorr aannyy ootthheerr ddiirreecctt,, iinnddiirreecctt,, ssppeecciiaall,,
oorr ccoonnsseeqquueennttiiaall ddaammaaggeess wwhhaattssooeevveerr,, aarriissiinngg oouutt ooff tthhee uussee ooff tthhiiss
mmaannuuaall oorr aannyy iinnffoorrmmaattiioonn,, rreeccoommmmeennddaattiioonnss oorr ddeessccrriippttiioonnss
ccoonnttaaiinneedd hheerreeiinn.. TThhee pprroocceedduurreess ddeessccrriibbeedd hheerreeiinn sshhoouulldd oonnllyy bbee
uunnddeerrttaakkeenn bbyy ssuuiittaabbllyy qquuaalliiffiieedd ppeerrssoonnnneell.. FFaaiilluurree ttoo iimmpplleemmeenntt tthheessee
pprroocceedduurreess ccoorrrreeccttllyy mmaayy ccaauussee ddaammaaggee ttoo tthhee TThheerrmmoo KKiinngg uunniitt oorr
ootthheerr pprrooppeerrttyy oorr ppeerrssoonnaall iinnjjuurryy..
There is nothing complicated about operating and maintaining your Thermo
King unit, but a few minutes studying this manual will be time well spent.
Performing pre-trip checks and enroute inspections on a regular basis will
minimize operating problems. A regular maintenance program will also help
to keep your unit in top operating condition. If factory recommended
procedures are followed, you will find that you have purchased the most
efficient and dependable temperature control system available.
All service requirements, major and minor, should be handled by a Thermo
King dealer for four very important reasons:
• They are equipped with the factory recommended tools to perform all
service functions
• They have factory trained and certified technicians
• They have genuine Thermo King replacement parts
• The warranty on your new unit is valid only when the repair and
replacement of component parts is performed by an authorized Thermo
King dealer

TK 56702-1-OP-EN 3
Custo er Satisfaction Survey
Let your voice be heard!
Your feedback will help improve our manuals. The survey is accessible
through any internet-connected device with a web browser.
Scan the Quick Response (QR) code or click or type the web address https://
tranetechnologies.iad1.qualtrics.com/jfe/form/SV_2octfSHoUJxsk6x?Q_
CHL=qr&Q_JFE=qdg to complete the survey.
IInnttrroodduuccttiioonn

4TK 56702-1-OP-EN
SSaaffeettyy PPrreeccaauuttiioonnss .................................................................................... 88
Danger, Warning, Caution, and Notice. . . . . . . . . . . . . . . . . . . . . . . . 8
General Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Automatic Start/Stop Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Electrical Hazard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Low Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Refrigeration System Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Refrigerant Oil Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
First Aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Welding Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Safety Nameplates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
UUnniitt DDeessccrriippttiioonn.. ........ .. .. .... .. .. .. ........ ........ .. .. .... .. .. .. .............. .. .. .... .. .. .. .. .... 1166
General Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Design Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Unit Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Engine.................................................... 19
ELC (Extended Life Coolant) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Clutch .................................................... 20
Reciprocating Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
H I Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
CYCLE-SENTRY™Start/Stop System. . . . . . . . . . . . . . . . . . . . . . . . 20
Defrost ................................................... 21
TracKing™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
SmartPower Electric Standby ( odel 50 Units Only) . . . . . . . . . . 21
SmartPower Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . 22
SmartPower Optional Features . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Table of Contents

TK 56702-1-OP-EN 5
Unit Protection Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Engine Compartment Components. . . . . . . . . . . . . . . . . . . . . . . . . . 23
Unit Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
OOppeerraattiinngg IInnssttrruuccttiioonnss ffoorr PPrreemmiiuumm HH II CCoonnttrrooll
PPaanneell........ .... .. .. .. .. .............. .. .. .... .. .. .. ........ ........ .. .. .... .. .. .. ........ ........ .. .... .. .. .. .. .... 2266
Truck Premium Display H I Control Panel . . . . . . . . . . . . . . . . . . . 26
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Display................................................ 27
Hard Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Soft Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Turning the Unit On and Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
If ore Than One Language is Enabled . . . . . . . . . . . . . . . . . . . . 30
The Standard Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Changing the Setpoint. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Starting the Diesel Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Starting the Electric otor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Switching from Diesel to Electric . . . . . . . . . . . . . . . . . . . . . . . . 39
Switching from Electric to Diesel . . . . . . . . . . . . . . . . . . . . . . . . 40
Initiating a anual Defrost Cycle . . . . . . . . . . . . . . . . . . . . . . . . 42
Terminating a Defrost Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Selecting High Speed Lockout ode (If Enabled) . . . . . . . . . 43
Using the Gauges Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Gauges Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Using the Sensors Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Sensors Available . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Using The ain enu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
ain enu Choices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Alarms................................................ 53
LogAlarms........................................... 53
CheckAlarms......................................... 54
Shutdown Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
TTaabbllee ooff CCoonntteennttss

6TK 56702-1-OP-EN
PreventAlarms........................................ 54
Pretrip Alarm Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Alarm Codes When Switching Between Diesel and
Electric .............................................. 55
Alarm Code Notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Clearing Alarm Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Displaying and Clearing Alarm Codes . . . . . . . . . . . . . . . . . . . . . 57
Table of Alarm Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Datalogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Hourmeters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Hourmeter Names and Definitions. . . . . . . . . . . . . . . . . . . . . . . . 66
ode ................................................. 67
Selecting CYCLE-SENTRY or Continuous ode. . . . . . . . . . . 69
Selecting Temperature Display Units . . . . . . . . . . . . . . . . . . . . 72
Keypad Lockout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Selecting Sleep ode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Pretrip ................................................ 81
Pretrip Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Conditions where Pretrip Tests are Not Allowed . . . . . . . . . . . . 81
Pretrip Test Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Pretrip Test Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Performing a Pretrip Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Diesel/Electric enu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Adjust Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Time.................................................. 87
LLooaaddiinngg aanndd EEnnrroouuttee IInnssppeeccttiioonnss .................. .. .... .. .. .. .. ........ ........ .. 8899
Inspecting the Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Enroute Inspections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
SSppeecciiffiiccaattiioonnss ...... ........ .. .. .... .. .. .. ........ ........ .. .. .... .. .. .. .............. .. .. .... .. .. .. .. .... 9922
Engine Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Refrigeration System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
TTaabbllee ooff CCoonntteennttss

TK 56702-1-OP-EN 7
Electrical Control System Specifications . . . . . . . . . . . . . . . . . . . . . 93
Fuses..................................................... 93
Electric Standby Specifications (SmartPower™ odel 50
Units)..................................................... 94
Electric otor and Overload Relay. . . . . . . . . . . . . . . . . . . . . . . 94
Standby Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . 95
UUnniitt aaiinntteennaannccee .. .. .. .. .. .. ........ .. .. .... .. .. .. .. .............. .. .. .... .. .. .. .. .............. .. .. 9966
aintenance Inspection Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . 97
SSeerriiaall NNuummbbeerr LLooccaattiioonnss ..................................................................110000
EEmmeerrggeennccyy CCoolldd LLiinnee ..........................................................................110022
UUnniitt WWaarrrraannttyy ..........................................................................................110033
EPA and ARB Supplemental Emissions Warranty
Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
TTaabbllee ooff CCoonntteennttss

8TK 56702-1-OP-EN
Safety Precautions
Danger, Warning, Caution, and Notice
Thermo King®recommends that all service be performed by a Thermo King
dealer and to be aware of several general safety practices.
Safety advisories appear throughout this manual as required (refer to
examples below). Your personal safety and the proper operation of this unit
depend upon the strict observance of these precautions.
DDAANNGGEERR
EExxaammppllee!!
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WWAARRNNIINNGG
EExxaammppllee!!
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CCAAUUTTIIOONN
EExxaammppllee!!
Indicates a potentially hazardous situation which, if not avoided, could
result in minor or moderate injury and unsafe practices.
NN TTIICCEE
EExxaammppllee!!
Indicates a situation that could result in equipment or property-damage
only accidents.
General Practices
DDAANNGGEERR
RRiisskk ooff IInnjjuurryy!!
Improper servicing can lead to fire, electrocution, or explosion. Never
service, repair, or troubleshoot a system unless you are a professional
service person.

TK 56702-1-OP-EN 9
DDAANNGGEERR
HHaazzaarrddoouuss GGaasseess!!
Refrigerant in the presence of an open flame, spark, or electrical short
produces toxic gases that are severe respiratory irritants which can cause
serious injury or possible death.
DDAANNGGEERR
CCoonnffiinneedd SSppaaccee HHaazzaarrddss!!
Avoid engine operation in confined spaces and areas or circumstances
where fumes from the engine could become trapped and cause serious
injury or death.
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
When using ladders to install or service refrigeration systems, always
observe the ladder manufacturer’s safety labels and warnings. A work
platform or scaffolding is the recommended method for installations and
servicing.
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
Never operate the unit unless you completely understand the controls;
otherwise serious injury may occur.
CCAAUUTTIIOONN
SSeerrvviiccee PPrroocceedduurreess!!
Turn the unit off before attempting to check the engine oil.
CCAAUUTTIIOONN
HHaazzaarrddoouuss PPrreessssuurreess!!
Do not remove expansion tank cap while coolant is hot.
CCAAUUTTIIOONN
RRiisskk ooff IInnjjuurryy!!
Avoid direct contact with hot coolant.
SSaaffeettyy PPrreeccaauuttiioonnss

10 TK 56702-1-OP-EN
Auto atic Start/Stop Operation
CCAAUUTTIIOONN
RRiisskk ooff IInnjjuurryy!!
The unit can start and run automatically any time the unit is turned on.
Units start automatically in both Cycle Sentry mode and Continuous mode.
Turn the unit icroprocessor On/Off switch Off before doing inspections or
working on any part of the unit.
CCAAUUTTIIOONN
RRiisskk ooff IInnjjuurryy!!
Thermo King units may have options that allow for remote starting from a
fully off state. Turn the unit icroprocessor On/Off Switch Off before doing
inspections or working on any part of the unit.
Electrical Hazard
DDAANNGGEERR
HHaazzaarrddoouuss VVoollttaaggee!!
When servicing or repairing a temperature control unit, the possibility of
serious or even fatal injury from electrical shock exists. Extreme care must
be used when working with a refrigeration unit that is connected to a source
of operating power, even if the unit is not operating. Lethal voltage
potentials can exist at the unit power cord, inside the control box, at the
motors and within the wiring harnesses.
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
On SmartPower electric standby equipped units, always turn off the
external standby power source before handling, connecting, or
disconnecting the power cable. Always disconnect the standby power cord
before servicing the unit.
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee!!
The unit On/Off switch must be turned Off before connecting or
disconnecting the standby power plug. Never attempt to stop the unit by
disconnecting the power plug.
SSaaffeettyy PPrreeccaauuttiioonnss

TK 56702-1-OP-EN 11
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
The unit power plug must be clean and dry before connecting it to a power
source.
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee!!
A certified electrician should verify that the proper standby power
requirements are being supplied before connecting to a new power source.
Low Voltage
IImmppoorrttaanntt:: Some SR-3 components are connected directly to un-switched
battery power. All connections and circuits labeled with a “2”
prefix are connected directly to battery power. Always
disconnect the battery before servicing the unit.
WWAARRNNIINNGG
LLiivvee EElleeccttrriiccaall CCoommppoonneennttss!!
Control circuits used in refrigeration units are low voltage (12 to 24 volts
dc). However, the large amount of amperage available can cause severe
burns if accidentally shorted to ground with metal objects, such as tools. Do
not wear jewelry, watches, or rings because they increase the risk of
shorting out electrical circuits and damaging equipment or causing severe
burns.
Refrigeration Syste Hazards
In the United States all technicians who maintain, service, repair, or dispose
of equipment that could release refrigerants into the atmosphere must be
EPA 608 certified. Thermo King recommends all service be performed by a
Thermo King dealer.
DDAANNGGEERR
HHaazzaarrddoouuss GGaasseess!!
Refrigerant in the presence of an open flame, spark, or electrical short
produces toxic gases that are severe respiratory irritants which can cause
serious injury or possible death.
SSaaffeettyy PPrreeccaauuttiioonnss

12 TK 56702-1-OP-EN
DDAANNGGEERR
RReeffrriiggeerraanntt VVaappoorr HHaazzaarrdd!!
Do not inhale refrigerant. Use caution when working with refrigerant or a
refrigeration system in any confined area with a limited air supply.
Refrigerant displaces air and can cause oxygen depletion, resulting in
suffocation and possible death.
WWAARRNNIINNGG
PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE)) RReeqquuiirreedd!!
Refrigerant in a liquid state evaporates rapidly when exposed to the
atmosphere, freezing anything it contacts. Wear butyl lined gloves and
other clothing and eye wear when handling refrigerant to help prevent
frostbite.
Refrigerant Oil Hazards
WWAARRNNIINNGG
PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE)) RReeqquuiirreedd!!
Protect your eyes from contact with refrigerant oil. The oil can cause serious
eye injuries. Protect skin and clothing from prolonged or repeated contact
with refrigerant oil. To prevent irritation, wash your hands and clothing
thoroughly after handling the oil. Rubber gloves are recommended.
NN TTIICCEE
aatteerriiaall DDaammaaggee!!
Wipe up spills immediately. Refrigerant oil can damage paints and rubber
materials.
First Aid
RREEFFRRIIGGEERRAANNTT
•EEyyeess:: For contact with liquid, immediately flush eyes with large amounts
of water and get prompt medical attention.
•SSkkiinn:: Flush area with large amounts of warm water. Do not apply heat.
Remove contaminated clothing and shoes. Wrap burns with dry, sterile,
bulky dressing to protect from infection. Get prompt medical attention.
Wash contaminated clothing before reuse.
•IInnhhaallaattiioonn:: ove victim to fresh air and use Cardio Pulmonary
Resuscitation (CPR) or mouth-to-mouth resuscitation to restore
SSaaffeettyy PPrreeccaauuttiioonnss

TK 56702-1-OP-EN 13
breathing, if necessary. Stay with victim until emergency personnel
arrive.
•FFrroosstt BBiittee:: In the event of frost bite , the objectives of First Aid are to
protect the frozen area from further injury, warm the affected area
rapidly, and to maintain respiration.
RREEFFRRIIGGEERRAANNTT OOIILL
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention.
•SSkkiinn:: Remove contaminated clothing. Wash thoroughly with soap and
water. Get medical attention if irritation persists.
•IInnhhaallaattiioonn:: ove victim to fresh air and use Cardio Pulmonary
Resuscitation (CPR) or mouth-to-mouth resuscitation to restore
breathing, if necessary. Stay with victim until emergency personnel
arrive.
•IInnggeessttiioonn:: Do not induce vomiting. Immediately contact local poison
control center or physician.
EENNGGIINNEE CCOOOOLLAANNTT
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention.
•SSkkiinn:: Remove contaminated clothing. Wash thoroughly with soap and
water. Get medical attention if irritation persists.
•IInnggeessttiioonn:: Do not induce vomiting. Immediately contact local poison
control center or physician.
BBAATTTTEERRYY AACCIIDD
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention. Wash skin with soap and water.
EELLEECCTTRRIICCAALL SSHHOOCCKK
Take I EDIATE action after a person has received an electrical shock. Get
quick medical assistance, if possible.
The source of the shock must be quickly stopped, by either shutting off the
power or removing the victim. If the power cannot be shut off, the wire
should be cut with an non-conductive tool, such as a wood-handle axe or
thickly insulated cable cutters. Rescuers should wear insulated gloves and
safety glasses, and avoid looking at wires being cut. The ensuing flash can
cause burns and blindness.
If the victim must be removed from a live circuit, pull the victim away with a
non-conductive material. Use wood, rope, a belt or coat to pull or push the
SSaaffeettyy PPrreeccaauuttiioonnss

14 TK 56702-1-OP-EN
victim away from the current. DO NOT TOUCH the victim. You will receive a
shock from current flowing through the victim’s body. After separating the
victim from power source, immediately check for signs of a pulse and
respiration. If no pulse is present, start Cardio Pulmonary Resuscitation
(CPR). If a pulse is present, respiration might be restored by using mouth-to-
mouth resuscitation. Call for emergency medical assistance.
AASSPPHHYYXXIIAATTIIOONN
ove victim to fresh air and use Cardio Pulmonary Resuscitation (CPR) or
mouth-to-mouth resuscitation to restore breathing, if necessary. Stay with
victim until emergency personnel arrive.
Welding Precautions
Take precautions before electrically welding any portion of the unit or the
vehicle to which it is attached. Verify that welding currents are not allowed to
flow through the unit’s electronic circuits.
Observe the following precautions when welding to avoid damaging
electronic components.
• If the microprocessor has a power switch, turn it OFF before connecting
or disconnecting the battery.
• Disconnect power to the unit.
• Disconnect all wire harnesses from the microprocessor.
• If there are any electrical circuit breakers in the control box, switch them
OFF.
• Close the control box.
• Components that could be damaged by welding sparks should be
removed from the unit.
• Use normal welding procedures, but keep the ground return electrode as
close to the area being welded as practical. This will reduce the likelihood
of stray welding currents passing through any electronic circuits.
SSaaffeettyy PPrreeccaauuttiioonnss

TK 56702-1-OP-EN 15
Safety Na eplates
Observe all safety nameplates placed in various locations on the unit.
Figure 1. Proposition 65 Na eplate
Figure 2. Auto atic Start Warning Na eplate
RCS1114
Figure 3. Caution Lifting Na eplate
RCS1112
Figure 4. Caution No Grab No Step Na eplate
RCS1116
Figure 5. High Voltage Na eplate
99-7834
RCS1125
SSaaffeettyy PPrreeccaauuttiioonnss

16 TK 56702-1-OP-EN
Unit Description
General Description
The T-90 Series units are one-piece, front-mounted, diesel powered cooling
and heating systems designed for straight trucks. The condensing portion of
the unit is mounted on to the front of a truck cargo box with the evaporator
portion protruding into the box. The unit uses Chlorine free R-404A
refrigerant.
The basic models provide the following:
SSttaannddaarrdd UUnniitt (( ooddeell 3300)):: Cooling and hot gas heating on engine
operation.
SSmmaarrttPPoowweerr™™ UUnniitt (( ooddeell 5500)):: Cooling and hot gas heating on engine
operation and electric standby operation. Electric evaporator heaters are
optional.
A three cylinder, EPA Tier 4, special clean and quiet diesel engine powers the
unit when in the truck is in route. SmartPower ( odel 50) units are also
equipped with an electric motor for standby power operation while the truck
is stationary.
The SR-3 microprocessor based temperature control system and in-cab H I
controller manage unit functions. CYCLE-SENTRY™, an exclusive Thermo
King feature, automatically starts and stops the unit according to
temperature demands. This continuous monitoring function optimizing the
unit’s performance and reduces fuel consumption while maintaining
temperature in multiple compartments.
The on-board Pretrip unit self check feature can be run before beginning the
daily distribution route to identify any possible unit malfunctions and help
prevent down time.

TK 56702-1-OP-EN 17
Design Features
• icroprocessor Controlled
• Continuous System onitoring
• In-Cab H I Controller
• Alarm Code Display
• Battery Voltage Display
• Coolant Temperature Display
• CYCLE-SENTRY Start/Stop Controls
• Engine and Electric SmartPower ( odel 50) Hour eter
• OptiSet Plus Temperature Profiles
• Smart Defrost
• Unit Self Check-pretripping
• Aerodynamic Thermo Plastic Injection olded Skins with In-mold Color
• Air Cleaner, Dry Type
• Alternator, 12 Volt, 37 Amp
• Bypass Oil Filter
• Coolant Expansion Tank
• Economy ode
• Fahrenheit and Celsius Display
• Fuel Filter, Spin On
• Oil Filter, Full Flow
• Serpentine Belt with anual Tensioner
• R-404A Chlorine-free Refrigerant
• Robotic Welded Steel Frame
• X214 Compressor (T-590 and T-690)
• X430P Compressor (T890, T-1090 and T-1090 SPECTRU )
• ETV (Electronic Throttling Valve) (T-690, T-890, T-1090 and T-1090
SPECTRU )
• TK374F Tier 4 Diesel Engine (T-590, T-690, and T-890)
• TK380F Tier 4 Diesel Engine (T-1090 and T-1090 SPECTRU )
• USB Diagnostic Port
• TracKing™
UUnniitt DDeessccrriippttiioonn

18 TK 56702-1-OP-EN
Unit Options
• Body ount H I Enclosure
• Door Switch
• AX Cooling System
• Electric Evaporator Heaters
• SmartPower Electric Standby ( odel 50)
• SmartPower Automatic Phase Correction ( odel 50)
• SmartPower Diesel/Electric Autoswitching ( odel 50)
• Engine Block Heater
• Fuel Tank (30 gallon aluminum, 18” and 22”)
• Quick Oil Drain Kit
• Rear Remote Control (flushmount)
• Remote Indicator Light
• Snow Cover
• Whisper™Sound Kit
• Top Cover System
• Precision Temperature Control (except T–590 / 690)
• TouchLog
• Bluetooth
• Solar Panels
• Battery Box
• Evaporator Side Screens
UUnniitt DDeessccrriippttiioonn

TK 56702-1-OP-EN 19
Engine
Engine power for the T-590, T-690, and T-890 is provided by the TK374F, a
three-cylinder, EPA Tier 4, special clean and quiet diesel engine rated at
13.27 continuous horsepower (9.9 kW) at 2200 RP and 14.61 continuous
horsepower (10.9 kW) at 2425 RP . A belt drive system transfers energy to
the compressor, unit fans, and alternator.
Engine power for the T-1090 is provided by the TK380F, a three cylinder, EPA
Tier 4, special clean and quiet diesel engine rated at 19.3 continuous
horsepower (14.4 kW) at 2425 RP . A belt drive system transfers energy to
the compressor, unit fans and alternator.
ELC (Extended Life Coolant)
The maintenance interval for ELC is eight years or 15,000 hours. A nameplate
near the coolant expansion tank identifies units with ELC. This coolant is Red
instead of the previous Green or Blue-Green coolants.
Figure 6. ELC (Extended Life Coolant) Na eplate
RCS1161
IImmppoorrttaanntt:: nly AT extended life coolants (Chevron Delo® XLC or
equivalent) should be added to Thermo King systems.
Conventional coolants should not be used (Typically identified
by green or blue-green color). If a conventional coolant is
combined with the Thermo King factory fill up to 25% by volume,
the coolant must be changed at the next service opportunity.
Above 25%, the coolant must be changed immediately.
Conventional coolants dilute/interact with the additive packages
of extended life coolant which significantly reduces the service
life of the coolant.
UUnniitt DDeessccrriippttiioonn

20 TK 56702-1-OP-EN
NNoottee:: The use of 50/50% pre-mixed ELC is recommended to ensure that
deionized water is being used. If 100% full strength concentrate is
used, deionized or distilled water is recommended instead of tap
water to ensure the integrity of the cooling system is maintained. The
engine must have antifreeze protection to -40°F/ -40°C. Check and add
coolant in the expansion tank as needed.
Clutch
The centrifugal clutch engages fully at 600 ± 100 RP on engine operation,
constantly turning the compressor, alternator, and fans at both high and low
speed. The clutch isolates the engine from the belt drive system during
electric standby operation on odel 50 units.
Reciprocating Co pressor
The T-590 and T-690 feature the X214, 2 cylinder reciprocating compressor
with 13.92 cu in (229 cc) displacement.
The T-890 and T-1090 feature the X430P, 4 cylinder reciprocating compressor
with 30.0 cu in (492 cc) displacement.
HMI Controller
The H I Controller communicates with the Base Controller (located inside
the control box) and is used operate the unit and display unit information. It
also provides access to all the controller functions and menus.
CYCLE-SENTRY™™ Start/Stop Syste
The CYCLE-SENTRY Start/Stop fuel saving system provides optimum
operating economy.
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
The unit can start at any time without warning. Press the OFF key on the
H I control panel and place the microprocessor On/Off switch in the Off
position before inspecting or servicing any part of the unit.
The CYCLE-SENTRY system automatically starts the unit on microprocessor
demand and shuts down the unit when all demands are satisfied.
UUnniitt DDeessccrriippttiioonn
