Introduction
Split System Heat Pump
Units Designed With
Your Needs In Mind.
The Trane reputation for quality and
reliability in air conditioning is
apparent with Odyssey™ light
commercial split systems. These
Trane systems are designed to meet
your job requirements every
time...and at a competitive price.
Odyssey has Trane quality and
reliability built-in. Couple that with
outstanding efficiency, flexibility and
installation ease, and you have an
unbeatable combination for years of
worry-free service and operation.
Manufacturing Control
Trane’s exclusive control over the
design and manufacturing of all
major components is unique in the
industry. This approach assures total
control over both the quality and
reliability of these components and
allows us to custom match
components to deliver the best in
split system performance.
Designing the Details
Careful attention was given to
designing the details — from control
wiring to the access panels. Odyssey
units feature time-saving colored
and numbered wiring and
removable panels which allow
complete access to all major
components and controls. All
outdoor units feature external high
and low pressure switches for easy
diagnosing and servicing of the unit.
Service valves with gauge ports are
provided on all units.
Standardized Cabinets
In addition, all cabinets have been
standardized. When you are
servicing an outdoor unit or an air
handler, all components are in the
same location from unit to unit.
Filters
The 5, 7½ and 10 ton air handlers are
supplied with 1" throwaway filters as
standard. The filter racks were
designed to easily convert for
installation of 2" filters. The 15 and
20 ton air handlers have 2" filters as
standard.
Figure 1.

SSP-PRC001-EN 3
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Application Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Selection Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Model Number Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
General Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Jobsite Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Typical Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Dimensional Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Mechanical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Contents

4SSP-PRC001-EN
Condensing Units Options
The 7½ and 10-ton single
compressor models feature single
refrigeration circuitry, lowering job
installation costs by requiring only
one set of refrigerant lines. These
units are ideal for low cost, new
construction, building renovation
and unit replacement jobs.
In addition, Odyssey includes 15 and
20-ton dual compressor units to give
true stand-by protection; if one
compressor fails, the second will
automatically start-up. Also, the first
compressor can be serviced without
shutting down the unit since the
refrigerant circuits are independent.
Dual compressors also provide high
energy savings. Most buildings are
designed for peak load requirements
even though the building typically
operates at less than peak load.
During light load conditions only one
compressor functions to maintain
the space comfort, reducing energy
use. For instance, the EER of the 15
ton unit at ARI conditions is 10.1 and
at part load conditions it is 11.6.
Trane split systems have been
specified in thousands of
applications. You’ll find Odyssey will
win you even more jobs with its
compact, manageable cabinet which
will save time and money for rigging
and installation and permit Trane to
replace almost any unit —
effortlessly.
Each heat pump unit can operate to
50°F as standard in the cooling
mode. An accessory Head Pressure
Control gives you the capability to
operate to 0°F. All heat pumps offer
these accessories:
• Head Pressure Control
• Coil Guard Kits
• Isolators - both Rubber-in-Shear
and Spring Type
• Anti-Short-Cycle Kit
• Time Delay Relay
Air Handlers Offer More
Flexibility
Flexibility is a key to meeting
changing market requirements.
Odyssey split systems offer not only
heat pumps, but also convertible air
handlers.
The air handlers can be installed
either vertically in a mechanical
room or horizontally above a ceiling
— and it doesn’t require any removal
of panels to make either airflow
application work.
Figure 2.
These air handlers have a double
sloped condensate drain pan that
allows for either airflow
configuration. The drain pan can
easily be removed for cleaning.
All the air handlers feature factory-
installed belt drive and ball bearing
evaporator fans with adjustable
sheaves for maximum airflow
performance. In fact, the standard
motor on the 10-ton air handler will
deliver 4000 cfm at 1.4" ESP. Plus
oversized motors are available for
higher static applications.
Features and Benefits

SSP-PRC001-EN 5
Features and Benefits
Odyssey’s air handler versatility is
further increased by a complete line
of accessories designed to match and
install smoothly:
• Discharge Plenum and Grille
• Return Grille
• Subbase
• Electric Heaters
• High Static Evaporator Motor
• Isolators both Rubber-in-Shear
and Spring Type
• A full line of Thermostats
• Outdoor Thermostat
Figure 3.
Odyssey — A Complete
Split System
Odyssey delivers the flexibility to
select a complete system that meets
your particular job requirements.
Air handlers are designed, tested and
rated with outdoor units to let you
select the proper match between
capacity and load. Also, these
matched systems can be quickly
engineered for specific applications
using Trane’s computerized selection
and load programs.
Odyssey Lowers Installation Costs
Your installation costs are reduced
with Odyssey Split. Both outdoor
units and air handlers are factory
packaged and assembled so jobsite
installation is quick and easy. You get
a complete system, with all the
components, controls and the
internal wiring, factory-installed for a
smooth jobsite start-up.
Unlike some competitive models the
following components are factory-
installed in Trane air handlers:
• Single Point Power Entry
• Blower Wheel and Housing
• Evaporator Motor with Sheaves
and Pulleys
• Low Voltage Terminal Board
•Transformer
• Contactor
• Fan Relay
• DX Coil with complete
Refrigeration Circuitry
• Expansion Valve and Check
Valves
There’s no need to install
components and put together the air
handler on the job. This provides you
with less labor cost and fewer
chances for installation errors which
cause callbacks. All this means
saving you money both in
replacement and new construction
applications.
Figure 4.

6SSP-PRC001-EN
Application of this product should be
within the catalogued airflow and
performance considerations.
Clearance Requirements
The recommended clearances
identified with unit dimensions
should be maintained to assure
adequate serviceability, maximum
capacity and peak operating
efficiency. Actual clearances which
appear inadequate should be
reviewed with a local Trane
Representative.
180° Blower Rotation
The 5, 7½ and 10 ton air handler
blower section can be rotated 180° to
change the discharge pattern. This
modification must be done in the
field and requires an additional kit.
See unit installer's guide.
Low Ambient Cooling
As manufactured, these units can
operate to 50°F in the cooling mode
of operation. An accessory head
pressure control will allow operation
to 0°F outdoor ambient. When using
these units with control systems
such as bypass changeover Variable
Air Volume, make sure you consider
the requirement for a head pressure
control to allow low ambient
cooling.
Figure 5. Typical Horizontal Air Handler Application
Figure 6. Typical Split System Application
Application Considerations

SSP-PRC001-EN 7
Application Considerations
Figure 7. Typical Vertical Air Handler Application

8SSP-PRC001-EN
Cooling Capacity
Step 1.
Calculate the building’s total and
sensible cooling loads at design
conditions.
Step 2.
Size the equipment using Ta b l e 3 .
Match the cooling loads at design
conditions.
Example: The following are the
building cooling requirements:
a. Electrical Characteristics:
460/60/3
b. Summer Design Conditions:
Entering Evaporator Coil:
80°F DB/67°F WB Outdoor
Ambient: 95°F
Total Cooling Load: 90 MBh
c. Sensible Cooling Load: 64
MBh
d. Airflow: 3000 cfm
External Static Pressure:
0.77 inches of water gauge
Ta b l e 3 shows that TWA090A4 with
TWE090A has a gross cooling
capacity of 91.1 MBh and 65.9 MBh
sensible capacity at 95°F DB ambient
and 3000 cfm with 80°F DB/67°F WB
air entering the evaporator.
To find the net cooling capacities, fan
motor heat must be subtracted.
Determine the total unit static
pressure:
External Static Duct System 0.77 in.
Standard Filter 1 in. 0.10 in.
Supplementary Electric Heat 0.23 in.
Total Static Pressure 1.10 in.
Note: The Evaporator Fan
Performance Table has
included the effect of a 1 in.
filter already. Therefore, the
actual Total Static Pressure is
1.10 - 0.10 = 1.0 0 in. With
3000 cfm and 1.00 in.,
Ta b l e 1 7 shows a 1.17 bhp.
Note: The formula below the table
can be used to calculate Fan
Motor Heat:
3.5 X bhp = MBh
3.5 X 1.17 = 4.09 MBh
Net Total Cooling Capacity =
91.1 MBh - 4.09 = 87.01 MBh
Net Sensible Cooling Capacity =
65.9 MBh - 4.09 = 61.81 MBh
Heating Capacity
Step 1.
Calculate the building heating load
using the Trane calculation form or
any other standard accepted
method.
Step 2.
Size the equipment using Ta b l e 11 to
match the heating loads at design
conditions. The following are
building heating requirements:
a. Total Heating Load: 95.0 MBh
b. Outdoor Ambient (Winter):
17°F DB
c. Indoor Return Temperature:
70°F DB
d. Airflow: 3000 cfm
Ta b l e 11 indicates the mechanical
heating portion of the heat pump will
provide 54.8 MBh for the winter
design conditions.
Step 3.
Because 54.8 MBh is less than the
building’s required heating capacity,
a supplementary heater must be
selected. 95.0 - 54.8 = 40.2 MBh
minimum heater capacity.
From Table 32, the 14.96 kW heater
has a capacity of 51,058 Btu/h.
From Table 37, the 14.96 kW heater
at 460V indicates the heater model
number is BAYHTRL415A.
This heater will be adequate to cover
the residual heat capacity needed for
the application.
Air Delivery Selection
External static pressure drop
through the air distribution system
has been calculated to be 0.77 in. of
water gauge.
From Table 31 static pressure drop
through the electric heater is 0.12 in.
of water (0.77 + 0.12 = .89 in.)
Enter Ta b l e 17 for TWE090A4 at 3000
cfm and .90 static pressure. The
standard motor at 790 RPM will give
the desired airflow.
Selection Procedure

SSP-PRC001-EN 9
Digits 11 - Minor Design Sequence
A = Current Design Sequence
Digits 12 - Service Digit
A = Current Service Digit
Digits 11 - Minor Design Sequence
A = Current Design Sequence
Digits 12 - Service Digit
A = Current Service Digit
Digits 1,2,3 - Product Type
TWA = Split System Heat Pump
Digits 4,5,6 - Nominal Gross Cooling
Capacity (MBh)
090 = 7 1/2 Tons
120 = 10 Tons
180 = 15 Tons
240 = 20 Tons
Digits 7 - Major Development
Sequence
A = Single Compressor
B = Dual Compressor
Digits 1,2,3 - Product Type
TWE = Split System Heat Pump/
Cooling Air Handler
Digits 4,5,6 - Nominal Gross Cooling
Capacity (MBh)
060 = 5 Tons
090 = 7½ Tons
120 = 10 Tons
180 = 15 Tons
240 = 20 Tons
Digits 7 - Refrigerant Circuit
A = Single
B = Dual
Split System Heat Pump Model Nomenclature
TWA 0 9 0 A 3 00 A A
123 4 56 7 8 910 11 12
Air Handler Model Nomenclature
TWE 0 9 0 A 1 00 A A
123 4 56 7 8 910 11 12
Digits 8 - Electrical Characteristics
1 = 208-230/60/1
3 = 208-230/60/3
4 = 460/60/3
W = 575/60/3
Digits 9,10 - Factory Installed
Options
00 = Packed Stock
0S = Black Epoxy Coated Coil
Digits 8 - Electrical Characteristics
1 = 208-230/60/1
3 = 208-230/60/3
4 = 460/60/3
W = 575/60/3
Digits 9,10 - Factory Installed
Options
00 = Packed Stock
Model Number Description

10 SSP-PRC001-EN
Table 1. General Data — Heat Pumps
7½ Tons 10 Tons 15 Tons 20 Tons
Single Compressor
TWA090A3,A4,AW Single Compressor TWA120A3,A4,AW Dual Compressor TWA180B3,B4,BW Dual Compressor TWA240B3,B4,BW
Cooling Performance(i)
(i) Cooling Performance is rated at 95°F ambient, 80°F entering dry bulb, 67°F entering wet bulb. Gross capacity does not include the effect of fan motor
heat. ARI capacity is net and includes the effect of fan motor heat. Certified in accordance with the Unitary Large Equipment certification program,
which is based on ARI Standard 340/360-00.
Gross Cooling Capacity
Matched Air Handler 91,000 124,000 182,000 240,000
Matched Heat Pump Only(ii)
(ii) Condensing unit only gross cooling capacity rated at 45°F saturated suction temperature and at 95°F ambient.
91,000 124,000 182,000 240,000
ARI Net Cooling Capacity(iii)
(iii) ARI net cooling capacity is calculated with matched blower coil and 25 feet of 1 3/8" or 1/2" OD interconnecting tubing.
89,000 120,000 176,000 234,000
EER(iv)
(iv) EER is rated at ARI conditions and in accordance with DOE test procedures.
Matched Air Handler 10.1 10.1 9.9 9.3
Heat Pump Only 11.5 11.1 10.9 10.3
Integrated Part Load Value(v)
(v) Integrated part load value is based on ARI Standard 340/360-00. Units are rated at 80°F ambient, 80°F entering dry bulb (DB), and 67°F entering
wet bulb (WB) at ARI rated cfm.
- - 11.0 10.5
System/Condensing Unit Power (kW) 8.70/7.95 11.91/11.07 17.77/16.62 24.99/23.20
Heating Performance
ARI Heating and Matched Air Handler
High Temperature Capacity 87,000 122,000 168,000 234,000
System kW/COP 7.68/3.3 10.82/3.2 16.10/3.1 22.42/3.1
Low Temperature Capacity 55,000 80,000 106,000 154,000
System kW/COP 6.73/2.4 9.62/2.4 14.16/2.2 19.54/2.30
Compressor
No./Type 1/Trane 3-DTM Scroll 1/Trane 3-DTM Scroll 2/Trane 3-DTM Scroll 2/Trane 3-DTM Scroll
No. Motors/HP 1/7.5 1/10 2/7.5 2/10
Motor RPM 3450 3450 3450 3450
Sound Rating (BELS)(vi)
(vi) Sound rating shown is tested in accordance with ARI Standard 270 or 370.
8.8 8.8 8.8 8.8
System Data(vii)
(vii) Refer to refrigerant piping applications manual for line sizing and line length.
No. Refrigerant Circuits 1 1 2 2
Suction Line (in.) OD 1 3/8 1 3/8 1 3/8 1 3/8
Liquid Line (in.) OD 1/2 1/2 1/2 1/2
Outdoor Coil - Type Plate Fin Plate Fin Plate Fin Plate Fin
Tube Size (in.) OD .375 .375 .375 .375
Face Area (sq ft) 19.2 29.5 38.5 50.2
Rows/FPI 2/18 2/18 2/18 2/18
Refrigerant Control Expansion Valve Expansion Valve Expansion Valve Expansion Valve
Outdoor Fan - Type Propeller Propeller Propeller Propeller
No. Used/Diameter (in.) 1/26 1/28 2/26 2/28
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct1
CFM 5890 8200 11,780 16,240
No. Motor/HP 1/.50 1/1.00 2/.50 2/1.00
Motor RPM 1100 1100 1100 1100
Refrigerant Charge (Field Supplied)
(lbs of R-22)(viii)
(viii)Refrigerant (operating) charge is for condensing unit (all circuits) with matching blower coils and 25 feet of interconnecting refrigerant lines. All units
are supplied with a small nitrogen holding charge only.
18.00 31.50 36.00 48.50
General Data

SSP-PRC001-EN 11
General Data
Table 2. General Data - Air Handlers
5 Tons 7½ Tons 10 Tons
Single Circuit
TWE060A1(i),
A3, A4, AW
(i) TWE60A1 has motor RPM of 3450 for oversized motor.
Dual Circuit
TWE060B1, B3,
B4
Single Circuit
TWE090A1,
A3(ii), AW
(ii) Ships wired for 208-230/60/3. Field convertible to 460/60/3.
Dual Circuit
TWE090B1,
B3(ii)Single Circuit
TWE120A1(iii)
(iii) TWE120A1 does not have an oversized motor option.
Single Circuit
TWE120A3(ii),
AW
System Data
No. Refrigerant Circuits 1 2 1 2 1 1
Suction Line (in.) OD 1 1/8 3/4 1 3/8 1 1/8 1 3/8 1 3/8
Liquid Line (in.) OD 3/8 5/16 1/2 3/8 1/2 1/2
Indoor Coil - Type Plate Fin Plate Fin Plate Fin Plate Fin Plate Fin Plate Fin
Tube Size (in.) .375 .375 .375 .375 .375 .375
Face Area (sq. ft.) 5.0 5.0 8.1 8.1 11.2 11.2
Rows/FPI 3/12 3/12 3/12 3/12 4/12 4/12
Refrigerant Control Expansion Valve Expansion Valve Expansion Valve Expansion Valve Expansion Valve Expansion Valve
Drain Connection Size (in.) 1 PVC 1 PVC 1 PVC 1 PVC 1 PVC 1 PVC
Indoor Fan - Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
No. Used/Diameter x Width (in.) 1/12 x 12 1/12 x 12 1/15 x 15 1/15 x 15 1/15 x 15 1/15 x 15
Drive Type/No. Speeds Belt/Adjustable Belt/Adjustable Belt/Adjustable Belt/Adjustable Belt/Adjustable Belt/Adjustable
CFM 2000 2000 3000 3000 4000 4000
No. Motors 1 1 1 1 1 1
Motor HP - Standard/Oversized .75/1.00 .75/1.00 1.50/2.00 1.50/2.00 2.00 2.00/3.00
Motor RPM 1725 1725 1725 1725 1725 1725
Motor Frame Size 56 56 56H 56H 56HZ 56HZ
Filters - Type/Furnished Throwaway/Yes Throwaway/Yes Throwaway/Yes Throwaway/Yes Throwaway/Yes Throwaway/Yes
(No.)/Size Recommended (1) 16x20x1 (1) 16x20x1 (3) 16x25x1 (3) 16x25x1 (4) 16x25x1 (4) 16x25x1
(1) 20x20x1 (1) 20x20x1
10 Tons 15 Tons 20 Tons
Dual Circuit
TWE120B1(iv)
(iv) TWE120B1 does not have an oversized motor option.
Dual Circuit
TWE120B3(ii),
B4, BW Dual Circuit TXE120B500B
Dual Circuit
TWE180B3, B4,
BW
Dual Circuit
TWE240B3, B4,
BW, E3, E4, EW
System Data
No. Refrigerant Circuits 2 2 2 2 2
Suction Line (in.) OD 1 1/8 1 1/8 1 1/8 1 3/8 1 3/8
Liquid Line (in.) OD 3/8 3/8 3/8 1/2 1/2
Indoor Coil - Type Plate Fin Plate Fin Plate Fin Plate Fin Plate Fin
Tube Size (in.) .375 .375 .375 .375 .375
Face Area (sq. ft.) 11.2 11.2 11.2 16.3 21.6
Rows/FPI 4/12 4/12 4/12 3/12 3/12
Refrigerant Control Expansion Valve Expansion Valve Expansion Valve Expansion Valve Expansion Valve
Drain Connection Size (in.) 1 PVC 1 PVC 1 PVC 1 PVC 1 PVC
Indoor Fan - Type Centrifugal Centrifugal - Centrifugal Centrifugal
No. Used/Diameter x Width (in.) 1/15x15 1/15x15 - 2/15x15 2/15x15
Drive Type/No. Speeds Belt/Adjustment Belt/Adjustment - Belt/Adjustment Belt/Adjustment
CFM 4000 4000 - 6000 8000
No. Motors 1 1 - 1 1
Motor HP - Standard/Oversized 2.00/- 2.00/3.00 - 3.00/5.00 5.00/7.50
Motor RPM 1725 1725 - 1735/1750 1750/3470
Motor Frame Size 56HZ 56HZ - 145T 184T
Filters - Type/Furnished Throwaway/Yes Throwaway/Yes Throwaway/
Yes(v)
(v) Coil has filter rack as standard, but no filters. When using this coil as a duct coil, use below size recommended. Filters for coil not recommended when
using coil with upflow gas furnaces.
Throwaway/Yes Throwaway/Yes
(No.)/Size Recommended (4) 16x25x1 (4) 16x25x1 (4) 16x25x1 (8) 15x20x2 (4) 16x25x2
(4) 16x20x2

12 SSP-PRC001-EN
Table 3. Gross Cooling Capacities (MBh) 7½ Tons TWA090A Heat Pump with 7½ TWE090A Air Handler
CFM Air
flow Ent DB °F
Ambient Temperature
85 95 105
Entering WB
61 67 73 61 67 73 61 67 73
MBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHC
2700 75 84.1 67.2 92.8 56.3 102.1 37.7 81.2 65.7 89.5 55.0 98.5 36.4 78.0 64.2 86.1 53.6 94.8 35.2
80 84.6 78.6 93.0 64.5 102.1 49.6 81.8 77.2 89.8 63.2 98.5 48.3 78.8 75.7 86.3. 61.7 94.8 46.9
85 86.9 86.9 93.1 75.8 102.2 61.3 84.4 84.4 89.9 74.4 98.7 60.0 81.7 81.7 86.4 72.9 95.0 58.6
90 91.2 91.2 93.7 87.3 102.3 72.9 88.7 88.7 90.6 85.9 98.7 71.5 86.0 86.0 87.3 84.5 95.1 70.0
3000 75 87.5 70.3 94.4 54.8 103.7 38.4 82.7 68.8 91.1 53.4 100.0 37.1 79.4 67.2 87.5 51.9 96.1 35.7
80 86.5 82.9 94.6 67.5 103.7 51.2 83.6 81.4 91.1 65.9 100.0 499 80.5 79.9 87.6 64.4 96.2 48.5
85 89.6 89.6 94.7 79.7 103.8 64.0 87.1 87.1 91.4 78.3 100.2 62.6 84.3 84.3 87.9 76.7 96.4 61.3
90 94.1 94.1 95.7 92.4 92.4 103.9 76.4 91.5 92.5 91.0 100.3 75.0 88.6 88.6 88.7 88.7 96.5 73.6
3300 75 87.0 73.3 95.7 56.6 104.9 39.0 83.9 71.7 92.3 55.2 101.2 37.6 80.6 70.1 88.6 53.7 97.3 36.2
80 88.1 87.0 95.8 70.1 105.0 52.8 84.7 84.7 92.4 68.6 101.2 51.4 81.9 81.9 88.8 67.0 97.4 50.0
85 92.0 92.0 96.1 83.4 105.1 66.5 89.3 89.3 92.8 82.0 101.4 65.2 86.4 86.4 89.2 80.4 97.6 63.8
90 96.6 96.6 97.5 97.2 105.2 79.9 93.9 93.9 93.9 93.9 101.5 78.5 90.9 90.9 91.0 91.9 97.7 77.0
3600 75 88.2 76.1 96.8 58.3 106.0 39.5 85.0 74.6 93.3 56.9 102.2 38.1 81.6 73.0 89.6 55.4 98.2 36.7
80 89.3 89.3 96.9 72.7 106.1 54.2 86.6 86.6 93.4 71.2 102.3 52.9 83.7 83.7 89.8 69.6 98.3 51.5
85 94.1 94.1 97.4 87.0 106.2 69.0 91.3 91.3 94.0 85.6 102.5 67.6 88.3 88.3 90.4 84.0 98.4 66.1
90 98.9 98.9 98.9 98.9 106.4 83.2 96.0 96.0 96.1 96.1 102.6 81.8 92.9 92.9 93.0 93.0 98.7 80.3
CFM Air
flow Ent DB °F
Ambient Temperature
115
Enter WB
61 67 73
MBH SHC MBH SHC MBH SHC
2700 75 74.7 62.5 82.4 52.1 90.9 33.8
80 75.6 74.1 82.6 60.0 91.0 45.5
85 78.9 78.9 82.9 71.3 91.1 57.2
90 83.1 83.1 84.0 83.0 91.3 68.5
3000 75 75.9 65.6 83.7 50.4 92.2 34.3
80 77.0 77.0 83.9 62.8 92.3 47.1
85 81.3 81.3 84.3 75.2 92.5 59.9
90 85.6 85.6 85.7 85.7 92.6 72.1
3300 75 77.1 68.5 84.8 52.2 93.3 34.8
80 78.9 78.9 85.0 65.4 93.4 48.6
85 83.3 83.3 85.6 78.9 93.6 62.4
90 87.8 87.8 87.9 87.9 93.7 75.5
3600 75 78.1 71.3 85.7 53.9 94.1 35.3
80 80.6 80.6 85.9 68.0 94.3 50.1
85 85.1 85.1 86.7 82.5 94.4 64.6
90 89.7 89.7 89.8 89.8 94.8 78.8
Notes:
1. Dry coil condition. Total gross capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All temperatures are in °F.
3. All capacities shown are gross and have not considered indoor fan heat.
4. To obtain net cooling capacities, subtract indoor fan heat.
5. MBH = Total Gross Cooling Capacity
6. SHC = Sensible Heat Capacity
Performance Data

Performance Data
SSP-PRC001-EN 13
Table 4. Gross Cooling Capacities (MBh) 10 Ton TWA120A Heat Pump with 10 Ton TWE120A Air Handler
CFM Air
flow Ent DB °F
Ambient Temperature
85 95 105
Entering WB
61 67 73 61 67 73 61 67 73
MBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHC
3600 75 114.6 90.1 126.2 76.3 138.8 51.1 110.6 88.1 121.8 74.5 134.0 49.4 106.2 85.9 117.1 72.6 128.9 47.7
80 115.0 104.8 126.4 85.8 138.8 66.4 111.1 102.8 122.0 83.9 134.0 64.6 106.9 100.7 117.3 81.9 128.9 62.6
85 117.1 117.1 126.5 100.7 138.8 81.2 113.7 113.7 122.0 98.6 134.0 79.3 110.1 110.1 117.4 96.5 129.0 77.4
90 122.7 122.7 126.9 115.2 138.9 95.9 119.2 119.2 122.7 113.2 134.2 94.0 115.5 115.5 118.2 111.1 129.1 92.1
4000 75 116.7 94.0 128.5 73.3 114.1 52.1 112.5 91.9 123.9 71.4 136.1 50.4 108.1 86.7 119.1 69.3 130.8 48.5
80 117.5 110.2 128.6 89.5 141.1 68.5 113.4 108.1 124.0 87.6 136.1 66.6 109.2 106.0 119.2 85.5 130.8 64.6
85 120.7 120.7 128.6 105.4 141.1 84.5 117.1 117.1 124.1 103.4 136.2 82.6 113.4 113.4 119.3 101.2 131.0 80.7
90 126.6 126.6 129.5 121.4 141.2 100.5 122.9 122.9 125.2 119.4 136.3 98.6 119.1 119.1 120.7 117.3 131.1 96.6
4400 75 118.5 97.7 130.3 75.5 142.9 53.0 114.2 95.6 125.6 73.6 137.8 51.1 109.6 93.4 120.7 71.6 132.4 49.2
80 119.7 115.3 130.4 93.0 142.9 70.4 115.6 113.2 125.8 91.0 137.8 68.5 11.3 111.1 120.8 89.0 132.5 66.5
85 123.9 123.9 130.5 110.0 143.0 87.7 120.2 120.2 125.9 107.9 138.0 85.8 116.3 116.3 121.1 105.8 132.6 83.8
90 129.9 129.9 131.9 127.4 143.1 104.8 126.1 126.1 127.5 125.4 138.1 102.9 122.2 122.2 122.0 122.0 132.7 100.9
4800 75 120.0 101.3 131.9 77.7 144.5 53.6 115.6 99.1 127.1 75.7 139.4 51.7 111.1 96.9 122.1 73.7 133.8 49.8
80 121.7 120.2 132.0 96.3 144.5 72.2 116.7 116.7 127.2 94.4 139.3 70.3 112.8 112.8 122.2 92.3 133.9 68.3
85 126.7 126.7 132.2 114.4 144.6 90.7 122.9 122.9 127.6 112.4 139.5 88.8 118.8 118.8 122.7 110.3 134.0 86.8
90 132.9 132.9 134.1 133.2 144.7 109.0 129.0 129.0 128.9 128.9 138.5 106.9 124.9 124.9 124.8 124.8 134.1 104.8
CFM Air
flow Ent DB °F
Ambient Temperature
115
Enter WB
61 67 73
MBH SHC MBH SHC MBH SHC
3600 75 101.7 83.6 112.2 70.6 123.4 45.8
80 102.6 98.5 112.4 79.8 123.5 60.6
85 106.3 106.3 112.5 94.3 123.6 75.3
90 111.7 111.7 113.5 109.0 123.7 90.0
4000 75 103.5 87.5 114.0 67.2 125.2 46.5
80 104.9 103.8 114.2 83.4 125.3 62.6
85 109.5 109.5 114.4 99.0 125.4 78.6
90 115.0 115.0 115.9 115.2 125.5 94.5
4400 75 105.0 91.1 115.5 69.4 126.7 47.1
80 106.5 106.5 115.7 86.8 126.8 64.5
85 112.2 112.2 116.1 103.6 126.9 81.7
90 117.9 117.9 117.8 117.8 126.9 98.5
4800 75 106.3 94.7 116.7 71.5 128.0 47.7
80 108.7 108.7 116.9 89.8 128.0 66.2
85 114.6 114.6 117.6 108.0 128.2 84.7
90 120.5 120.5 120.4 120.4 128.2 102.6
Notes:
1. Dry coil condition. Total gross capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All temperatures are in °F.
3. All capacities shown are gross and have not considered indoor fan heat.
4. To obtain net cooling capacities, subtract indoor fan heat.
5. MBH = Total Gross Cooling Capacity
6. SHC = Sensible Heat Capacity
10 Tons Gross Cooling Capacities

Performance Data
14 SSP-PRC001-EN
15 Tons Gross Cooling Capacities
Table 5. Gross Cooling Capacities (MBh) 15 Tons TWA180B Heat Pump with 15 Tons TWE180B Air Handler
CFM Air
flow Ent DB °F
Ambient Temperature
85 95 105
Entering WB
61 67 73 61 67 73 61 67 73
MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
5400 75 167.8 134.1 185.1 112.3 203.6 75.2 161.9 131.2 178.6 109.7 196.4 72.7 155.5 128 171.6 106.9 188.9 70.1
80 168.7 157 185.4 128.9 203.7 99.1 163 154.1 178.9 126.2 196.5 96.4 156.9 151.1 171.8 122.9 189.1 93.7
85 173.3 173.31 185.7 151.5 203.9 122.5 168.4 168.41 179.2 148.6 196.8 119.8 163 163.01 172.3 145.5 189.4 117.1
90 182 182.01 186.8 174.4 204.1 145.5 176.9 176.91 180.6 171.6 197 142.7 171.4 171.41 174 168.7 189.6 139.8
6000 75 170.9 140.3 188.3 109.4 206.8 76.7 164.8 137.3 181.5 106.6 199.3 74.1 158.3 134.2 174.4 103.7 191.6 71.3
80 172.3 165.5 188.4 134.5 206.8 102.3 166.5 162.6 181.7 131.6 199.5 99.7 160.3 159.5 174.7 128.5 191.8 96.9
85 178.8 178.81 188.9 159.2 207.1 127.9 173.6 173.61 182.3 156.3 199.8 125.2 168 168.01 175.3 153.2 192.2 122.5
90 187.9 187.91 190.7 184.5 207.3 152.7 182.5 182.51 184.4 181.7 200 149.9 176.8 176.81 176.9 176.91 192.5 146.9
6600 75 173.5 146.3 190.9 113 209.3 77.8 167.2 143.2 184 110.2 201.7 75.1 160.5 140 176.7 107.3 193.9 72.3
80 175.6 173.7 191.1 139.9 209.4 105.4 169 169.01 184.3 137 201.9 102.7 163.3 163.31 177 133.8 194.1 100
85 183.6 183.61 191.7 166.7 209.8 133 178.1 178.11 184.9 163.7 202.3 130.3 172.3 172.31 177.9 160.6 194.3 127.2
90 192.9 192.91 194.3 194.31 210 159.6 187.3 187.31 187.5 187.51 202.6 156.7 181.4 181.41 181.6 181.61 194.9 153.8
7200 75 175.7 152 193.1 116.5 211.5 78.8 169.4 148.9 186.1 113.7 203.7 76 162.6 145.6 178.6 110.7 195.8 73.3
80 178.2 178.21 193.4 145.1 211.6 108.4 172.7 172.71 186.4 142.1 204 105.7 166.9 166.91 179 139 196.1 102.9
85 187.8 187.81 194.2 173.9 212 138 182.1 182.11 187.4 170.9 204.2 134.8 176.1 176.11 180.2 167.8 196.4 131.8
90 197.4 197.41 197.5 197.51 212.3 166.3 191.6 191.61 191.7 191.71 204.7 163.4 185.4 185.41 185.6 185.61 196.9 160.4
CFM Air
flow Ent DB °F
Ambient Temperature
115
Enter WB
61 67 73
MBH SHC MBH SHC MBH SHC
5400 75 148.8 124.7 164.3 104 181.1 67.5
80 150.4 147.9 164.6 119.8 181.4 90.8
85 157.3 157.31 165.1 142.4 181.8 114.3
90 165.7 165.71 167.2 165.6 182 136.8
6000 75 151.3 130.8 166.9 100.7 183.7 68.5
80 153.5 153.51 167.2 125.3 184 94.1
85 162.1 162.11 168 150 184.4 119.7
90 170.8 170.81 171 171.01 184.7 144
6600 75 153.5 136.6 169.1 104.2 185.8 69.5
80 157.3 157.31 169.5 130.6 186.2 97.2
85 166.2 166.21 170.5 157.5 186.4 124.2
90 175.2 175.21 175.4 175.41 187 150.8
7200 75 155.5 142.2 170.9 107.7 187.6 70.4
80 160.7 160.71 171.3 135.7 188 100.1
85 169.8 169.81 172.8 164.6 188.4 128.8
90 179.1 179.11 179.3 179.31 188.9 157.4
Notes:
1. Dry coil condition. Total gross capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All temperatures are in °F.
3. All capacities shown are gross and have not considered indoor fan heat.
4. To obtain net cooling capacities, subtract indoor fan heat.
5. MBH = Total Gross Cooling Capacity
6. SHC = Sensible Heat Capacity

Performance Data
SSP-PRC001-EN 15
20 Tons Gross Cooling Capacities
Table 6. Gross Cooling Capacities (MBh) 20 Tons TWA240B Heat Pump with 20 Ton TWE240B Air Handler
CFM Air
flow Ent DB °F
Ambient Temperature
85 95 105
Entering WB
61 67 73 61 67 73 61 67 73
MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
7200 75 223.8 177.3 246 148.8 269.9 99.5 215.5 173.1 237 145.1 260.1 96.1 206.9 168.8 227.5 141.3 249.8 92.5
80 224.8 206.8 246.2 169 269.9 130 216.8 202.6 237.3 165.1 260.1 126.2 208.5 198.4 227.9 161 249.8 122.3
85 229.6 229.61 246.4 198.1 270 159.6 222.6 222.61 237.5 194 260.3 155.8 215.3 215.31 228.1 189.7 250 151.9
90 240.5 240.51 247.6 227.3 270.3 189 233.4 233.41 238.9 223.2 260.6 185.2 225.9 225.91 230 219.1 250.3 181.3
8000 75 227.8 185.1 250.2 143.9 274.2 101.4 219.3 180.8 240.9 139.9 264.1 98 210.4 176.4 231.1 135.9 253.4 94.1
80 229.4 217.4 250.4 176.3 274.1 134 221.2 213.2 241.2 172.4 264.1 130.3 212.8 208.9 231.2 167.9 253.4 126.3
85 236.4 236.41 250.6 207.6 274.3 166.2 229.3 229.31 241.4 203.5 264.3 162.4 221.6 221.61 231.9 199.2 253.7 158.5
90 247.9 247.91 252.5 239.7 274.6 198.2 240.4 240.41 243.8 235.6 264.4 193.9 232.6 232.61 234.7 231.4 253.8 189.7
8800 75 231.2 192.5 253.6 148.3 277.7 103 222.4 188.2 244.1 144.4 267.4 99.3 213.4 183.7 234.1 140.3 256.4 95.3
80 233.5 227.6 253.9 183.3 277.6 137.8 225.3 223.4 244.2 178.8 267.3 134.1 215.8 215.81 234.3 174.5 256.5 130.1
85 242.5 242.51 254.2 216.8 277.9 172.5 235 235.01 244.9 212.7 267.6 168.7 227.1 227.11 235.2 208.4 256.8 164.7
90 254.3 254.31 257 251.7 278 206.3 246.5 246.51 248.2 247.6 267.8 202.3 238.4 238.41 238.2 238.21 257 198.1
9600 75 234 199.6 256.5 152.6 280.7 104.3 225.2 195.2 246.8 148.6 270.1 100.5 216 190.8 236.7 144.5 258.9 96.5
80 235.8 235.81 256.6 189.4 280.7 141.5 228.3 228.31 247 185.2 270.1 137.7 220.3 220.31 236.9 180.9 259 133.7
85 247.9 247.91 257.4 225.8 280.9 178.6 240.1 240.11 248 221.6 270.5 174.7 231.9 231.91 238.2 217.2 259.4 170.7
90 260 260.01 259.7 259.71 281.1 214.5 252 252.01 251.8 251.81 270.7 210.4 243.5 243.51 243.4 243.41 259.6 206.2
CFM Air
flow Ent DB °F
Ambient Temperature
115
Enter WB
61 67 73
MBH SHC MBH SHC MBH SHC
7200 75 198 164.3 217.7 137.3 238.9 88.8
80 199.9 194.1 218.1 156.9 238.9 118.3
85 207.7 207.71 218.4 185.3 239.2 147.8
90 218 218.01 220.7 214.8 239.3 176.7
8000 75 201.2 171.9 221 131.7 242.2 90
80 203 203.01 221.2 163.5 242.3 122.3
85 213.6 213.61 222 194.8 242.6 154.4
90 224.3 224.31 224.1 224.11 242.8 185.4
8800 75 204 179.2 223.7 136.1 244.9 91.2
80 207.8 207.81 224 170.1 245 126
85 218.8 218.81 225.1 204 245.4 160.6
90 229.8 229.81 229.6 229.61 245.6 193.7
9600 75 206.6 186.2 226.1 140.3 247.2 92.4
80 212 212.01 226.4 176.4 247.3 129.6
85 223.3 223.31 228 212.8 247.7 166.6
90 234.6 234.61 234.5 234.51 248 201.7
Notes:
1. Dry coil condition. Total gross capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All temperatures are in °F.
3. All capacities shown are gross and have not considered indoor fan heat.
4. To obtain net cooling capacities, subtract indoor fan heat.
5. MBH = Total Gross Cooling Capacity
6. SHC = Sensible Heat Capacity

16 SSP-PRC001-EN
Performance Data
7½ Tons Gross Cooling Capacities and Capacity Curves
Table 7. Gross Cooling Capacities (MBh) 7½ Tons TWA090A Heat Pump Only
Outdoor
Temp (°F)
Suction Temperature (°F)
30 35 40 45 50 55
65 Head press PSIG 168 173 179 185 191 197 Cap. Btuh/1000 81 89 97.2 105.8 114.5 123.4
Unit kW 5.56 5.69 5.83 5.97 6.13 6.28
75 Head press PSIG 194 199 205 211 217 224 Cap. Btuh/1000 77.8 85.3 93.1 101.1 109.4 117.8
Unit kW 6.09 6.23 6.38 6.54 6.7 6.87
85 Head press PSIG 221 227 234 240 247 254 Cap. Btuh/1000 74.1 81.3 88.7 96.3 104.2 112.3
Unit kW 6.71 6.87 7.03 7.2 7.38 7.56
95 Head press PSIG 252 258 265 272 279 286 Cap. Btuh/1000 70.3 77.1 84.1 91.4 98.9 106.7
Unit kW 7.43 7.6 7.77 7.95 8.14 8.33
105 Head press PSIG 285 292 299 306 314 322 Cap. Btuh/1000 66.1 72.6 79.3 86.3 93.5 101.1
Unit kW 8.23 8.41 8.6 8.79 8.98 9.18
115 Head press PSIG 321 328 336 343 351 360 Cap. Btuh/1000 61.8 67.9 74.3 81 88.1 95.5
Unit kW 9.12 9.32 9.51 9.71 9.91 10.12
Notes:
1. Performance data calculated at 15°F subcooling and 20°F superheat and does not include capacity loss due to refrigerant lines.
Figure 8. Capacity Curves 7½ Tons TWA090A Heat Pump Only

SSP-PRC001-EN 17
Performance Data
10 Tons Gross Cooling Capacities and Capacity Curves
Table 8. Gross Cooling Capacities (MBh) 10 Tons TWA120A Heat Pump Only
Outdoor
Temp (°F)
Suction Temperature (°F)
30 35 40 45 50 55
65 Head press PSIG 167 172 178 183 189 195 Cap. Btuh/1000 110.6 121.1 132.1 143.7 155.9 168.6
Unit kW 7.87 8.04 8.22 8.41 8.61 8.83
75 Head press PSIG 192 197 202 208 214 221 Cap. Btuh/1000 105.4 115.4 126.1 137.3 149.1 161.4
Unit kW 8.56 8.75 8.95 9.16 9.38 9.62
85 Head press PSIG 219 224 230 236 243 250 Cap. Btuh/1000 100 109.6 119.9 130.7 142 153.9
Unit kW 9.38 9.59 9.82 10.05 10.3 10.55
95 Head press PSIG 248 254 260 267 274 281 Cap. Btuh/1000 94.5 103.7 113.5 123.8 134.7 146.1
Unit kW 10.35 10.58 10.82 11.07 11.59
105 Head press PSIG 281 287 293 300 307 315 Cap. Btuh/1000 88.8 97.6 107 116.8 127.1 137.8
Unit kW 11.45 11.7 11.96 12.22 12.48 12.74
115 Head press PSIG 316 322 329 336 343 351 Cap. Btuh/1000 83.1 91.4 100.3 109.6 119.2 129.2
Unit kW 12.69 12.95 13.21 13.48 13.73 13.98
Notes:
1. Performance data calculated at 15°F subcooling and 20°F superheat and does not include capacity loss due to refrigerant lines.
Figure 9. Capacity Curves 10 Tons TWA120A Heat Pump Only

18 SSP-PRC001-EN
Performance Data
15 Tons Gross Cooling Capacities and Capacity Curves
Table 9. Gross Cooling Capacities (MBh) 15 Tons TWA180B Heat Pump Only
Outdoor
Temp (°F)
Suction Temperature (°F)
30 35 40 45 50 55
65 Head press PSIG 168 173 179 185 191 197 Cap. Btuh/1000 161.3 177.1 193.6 210.6 228.1 245.8
Unit kW 10.9 11.16 11.43 11.71 12.01 12.32
75 Head press PSIG 193 199 205 211 217 224 Cap. Btuh/1000 154.9 169.9 185.5 201.5 218 234.8
Unit kW 11.94 12.22 12.51 12.82 13.14 13.47
85 Head press PSIG 221 227 233 240 247 254 Cap. Btuh/1000 147.7 162 176.8 192.1 207.8 224
Unit kW 13.16 13.46 13.78 14.11 14.46 14.81
95 Head press PSIG 252 258 265 272 279 286 Cap. Btuh/1000 140.1 153.7 167.8 182.4 197.5 213.1
Unit kW 14.56 14.89 15.23 15.59 15.95 16.32
105 Head press PSIG 285 292 299 306 313 321 Cap. Btuh/1000 131.9 144.8 158.2 172.2 186.8 202.1
Unit kW 16.14 16.49 16.85 17.23 17.61 18
115 Head press PSIG 321 328 335 343 351 360 Cap. Btuh/1000 123.3 135.5 148.3 161.8 176 190.9
Unit kW 17.88 18.25 18.64 19.03 19.43 19.83
Notes:
1. Performance data calculated at 15°F subcooling and 20°F superheat and does not include capacity loss due to refrigerant lines.
Figure 10. Capacity Curves 15 Tons TWA180B Heat Pump Only

SSP-PRC001-EN 19
Performance Data
20 Tons Gross Cooling Capacities and Capacity Curves
Table 10. Gross Cooling Capacities (MBh) 20 Tons TWA240B Heat Pump Only
Outdoor
Temp (°F)
Suction Temperature (°F)
30 35 40 45 50 55
65 Head press PSIG 183 190 196 203 211 219 Cap. Btuh/1000 217.4 237.4 258.4 280.5 303.5 327.5
Unit kW 16.09 16.51 16.96 17.44 17.96 18.5
75 Head press PSIG 209 216 223 231 239 248 Cap. Btuh/1000 206.8 226 246.3 267.6 290 313.3
Unit kW 17.58 18.05 18.56 19.11 19.68 20.28
85 Head press PSIG 238 245 253 261 270 279 Cap. Btuh/1000 196 214.4 233.9 254.5 276 298.3
Unit kW 19.35 19.88 20.44 21.03 21.65 22.27
95 Head press PSIG 269 277 285 294 303 313 Cap. Btuh/1000 185 202.6 221.3 240.9 261.4 282.6
Unit kW 21.39 21.97 22.57 23.2 23.83 24.47
105 Head press PSIG 304 312 320 329 339 349 Cap. Btuh/1000 173.8 190.6 208.4 227.1 246.5 266.5
Unit kW 23.68 24.31 24.95 25.6 26.24 26.87
115 Head press PSIG 341 349 358 368 378 388 Cap. Btuh/1000 162.4 178.5 195.4 213 231.2 249.9
Unit kW 26.23 26.89 27.56 28.22 28.86 29.46
Notes:
1. Performance data calculated at 15°F subcooling and 20°F superheat and does not include capacity loss due to refrigerant lines.
Figure 11. Capacity Curves 20 Tons TWA240B Heat Pump Only

20 SSP-PRC001-EN
Performance Data
7½, 10 Tons Gross Heating Capacities
Table 11. Gross Heating Capacities (MBh) 7½ Tons TWA090A Heat Pump with 7½ Tons TWE090A Air Handler at 3000 CFM
Outdoor Temp
(°F)
Heating Capacity (BTUH/1000)
at Indicated Indoor Dry Bulb Temperature Total Power in kW at Indicated Indoor Dry Bulb Temperature
60 70 75 80 60 70 75 80
-18 35.2 32 30.9 30.1 5.4 5.9 6.2 6.5
-13 36.8 34 33.1 32.5 5.5 6 6.3 6.6
-8 38.7 36.4 35.7 35.2 5.6 6.1 6.4 6.7
-3 41.1 39.2 38.7 38.3 5.7 6.2 6.5 6.8
2 44.1 42.5 42 41.8 5.8 6.3 6.6 6.9
7 47.5 46.3 45.9 45.7 5.9 6.5 6.8 7.1
12 51.3 50.3 50 49.9 6 6.6 6.9 7.2
17 55.6 54.8 54.5 54.3 6.2 6.7 7.1 7.4
22 60.3 59.6 59.3 59.1 6.3 6.9 7.2 7.6
27 65.5 64.7 64.4 64.2 6.4 7 7.4 7.7
32 71 70.2 69.9 69.6 6.6 7.2 7.5 7.9
37 76.7 75.8 75.4 75 6.7 7.4 7.7 8.1
42 82.7 81.7 81.2 80.7 6.9 7.5 7.9 8.3
47 89 87.8 87.3 86.7 7 7.7 8.1 8.5
52 95.7 94.4 93.7 93.1 7.2 7.9 8.3 8.7
57 102.7 101.2 100.5 99.7 7.3 8 8.4 8.9
62 109.9 108.2 107.4 106.6 7.5 8.2 8.6 9.1
67 117.3 115.5 114.6 113.8 7.7 8.4 8.8 9.3
72 124.8 122.9 122 121.1 7.9 8.6 9 9.5
Notes:
1. Rated with 25 feet of 13/8" suction and ½" liquid line.
Table 12. Gross Heating Capacities (MBh) 10 Tons TWA120A Heat Pump with 10 Tons TWE120A Air Handler at 4000 CFM
Outdoor Temp
(°F)
Heating Capacity (BTUH/1000)
at Indicated Indoor Dry Bulb Temperature Total Power in kW at Indicated Indoor Dry Bulb Temperature
60 70 75 80 60 70 75 80
-18 29.9 42.3 46.5 49.9 7.4 8.4 9 9.5
-13 39.4 47.5 50.6 53 7.7 8.6 9.1 9.6
-8 46.9 52.6 54.8 56.7 7.9 8.8 9.2 9.7
-3 53.7 57.8 59.4 60.7 8.1 9 9.4 9.9
2 60.3 63.1 64.2 65 8.3 9.1 9.6 10
7 66.9 68.6 69.2 69.7 8.5 9.3 9.7 10.2
12 73.4 74.3 74.6 74.7 8.7 9.5 9.9 10.3
17 80.2 80.3 80.2 80.2 8.9 9.6 10.1 10.5
22 87.1 86.6 86.3 86 9 9.8 10.2 10.7
27 94.2 93.2 92.6 92.2 9.2 10 10.4 10.9
32 101.7 100.2 99.5 98.9 9.4 10.2 10.6 11.1
37 109.1 107.2 106.4 105.6 9.5 10.4 10.9 11.4
42 116.7 114.4 113.5 112.7 9.7 10.6 11.1 11.6
47 124.6 122.1 121.1 120.1 9.9 10.8 11.3 11.9
52 132.8 130.1 129 127.9 10.1 11.1 11.6 12.1
57 141.1 138.3 137.1 136 10.4 11.3 11.9 12.4
62 149.6 146.7 145.3 144.1 10.6 11.6 12.1 12.7
67 158.3 155.2 153.8 152.5 10.9 11.9 12.4 13.1
72 167.4 164.1 162.6 161.2 11.2 12.2 12.8 13.4
Notes:
1. Rated with 25 feet of 1 3/8" suction and ½" liquid line.
