Trane ProSpace PTEG0701GAA Installation and operating instructions

SSAAFFEETTYY WWAARRNNIINNGG
Only qualified personnel should install and service the equipment The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment
July 2023 PPTTAACC--SSVVXX000044AA--EENN
ProSpace™™
Packaged Terminal Air Conditioner (PTAC)
R32 AC/Heat Pump with Electric Heat
208/230 Volts:
PTEG0701GAA
PTHG0701GAA
PTEG0901GAA
PTHG0901GAA
PTEG1201HAA
PTHG1201HAA
PTEG1501HAA
PTHG1501HAA
265 Volts:
PTEG0702GAA
PTHG0702GAA
PTEG0902GAA
PTHG0902GAA
PTEG1202HAA
PTHG1202HAA
PTEG1502HAA
PTHG1502HAA
nstallation, Operation, and Maintenance

©2023 Trane PTAC-SVX004A-EN
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as
required Your personal safety and the proper
operation of this machine depend upon the strict
observance of these precautions
The three types of advisories are defined as follows:
WARNING
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
CAUTION
Indicates a potentially hazardous situation
which, if not avoided, could result in minor or
moderate injury. It could also be used to alert
against unsafe practices.
NOTICE
Indicates a situation that could result in
equipment or property-damage only
accidents.
mportant Environmental
Concerns
Scientific research has shown that certain man-made
chemicals can affect the earth’s naturally occurring
stratospheric ozone layer when released to the
atmosphere In particular, several of the identified
chemicals that may affect the ozone layer are
refrigerants that contain Chlorine, Fluorine and Carbon
(CFCs) and those containing Hydrogen, Chlorine,
Fluorine and Carbon (HCFCs) Not all refrigerants
containing these compounds have the same potential
impact to the environment Trane advocates the
responsible handling of all refrigerants
In contrast to common refrigerants, R32 does no harm
to the ozonosphere and has a significantly lower
greenhouse warming potential when compared to
previous refrigerants
mportant Responsible
Refrigerant Practices
Trane believes that responsible refrigerant practices
are important to the environment, our customers, and
the air conditioning industry All technicians who
handle refrigerants must be certified according to local
rules For the USA, the Federal Clean Air Act (Section
608) sets forth the requirements for handling,
reclaiming, recovering and recycling of certain
refrigerants and the equipment that is used in these
service procedures In addition, some states or
municipalities may have additional requirements that
must also be adhered to for responsible management
of refrigerants Know the applicable laws and follow
them
WWAARRNNIINNGG
UUnniitt CCoonnttaaiinnss RR3322 RReeffrriiggeerraanntt!!
FFaaiilluurree ttoo ffoollllooww pprrooppeerr pprroocceedduurreess ccaann rreessuulltt iinn
eeqquuiippmmeenntt ddaammaaggee oorr ppeerrssoonnaall iinnjjuurryy
A2L
TThhiiss uunniitt ccoonnttaaiinnss RR3322 rreeffrriiggeerraanntt wwhhiicchh iiss
ffllaammmmaabbllee aanndd ooddoorrlleessss
RReeaadd tthhee IInnssttaallllaattiioonn,, OOppeerraattiioonn aanndd
MMaaiinntteennaannccee mmaannuuaall bbeeffoorree uussiinngg tthhiiss uunniitt
RReeaadd tthhee IInnssttaallllaattiioonn aanndd SSeerrvviiccee mmaannuuaall bbeeffoorree
iinnssttaalllliinngg oorr sseerrvviicciinngg tthhiiss uunniitt
WWAARRNNIINNGG
SSaaffeettyy HHaazzaarrdd!!
•• CChhiillddrreenn aaggeedd 88 yyeeaarrss aanndd aabboovvee aanndd
ppeerrssoonnss wwiitthh rreedduucceedd pphhyyssiiccaall,, sseennssoorryy,, oorr
mmeennttaall ccaappaabbiilliittiieess oorr llaacckk ooff eexxppeerriieennccee aanndd
kknnoowwlleeddggee aarree aalllloowweedd ttoo uussee tthhiiss uunniitt oonnllyy iiff
tthheeyy aarree ssuuppeerrvviisseedd aanndd iinnssttrruucctteedd oonn hhooww ttoo
uussee tthhee uunniitt iinn aa ssaaffee wwaayy aanndd uunnddeerrssttaanndd tthhee
hhaazzaarrddss iinnvvoollvveedd
•• CChhiillddrreenn aarree nnoott ppeerrmmiitttteedd ttoo ppllaayy wwiitthh tthhiiss
uunniitt
•• CChhiillddrreenn sshhoouulldd nnoott cclleeaann oorr mmaaiinnttaaiinn tthhee
uunniitt wwiitthhoouutt ssuuppeerrvviissiioonn
•• KKeeeepp cchhiillddrreenn ffrroomm ppllaayyiinngg oorr cclliimmbbiinngg oonn
tthhee aaiirr ccoonnddiittiioonneerr
WWAARRNNIINNGG
PPrrooppeerr FFiieelldd WWiirriinngg aanndd GGrroouunnddiinngg
RReeqquuiirreedd!!
FFaaiilluurree ttoo ffoollllooww ccooddee ccoouulldd rreessuulltt iinn ddeeaatthh oorr
sseerriioouuss iinnjjuurryy
AAllll ffiieelldd wwiirriinngg MMUUSSTT bbee ppeerrffoorrmmeedd bbyy qquuaalliiffiieedd
ppeerrssoonnnneell IImmpprrooppeerrllyy iinnssttaalllleedd aanndd ggrroouunnddeedd
ffiieelldd wwiirriinngg ppoosseess FFIIRREE aanndd EELLEECCTTRROOCCUUTTIIOONN
hhaazzaarrddss TToo aavvooiidd tthheessee hhaazzaarrddss,, yyoouu MMUUSSTT ffoollllooww
rreeqquuiirreemmeennttss ffoorr ffiieelldd wwiirriinngg iinnssttaallllaattiioonn aanndd
ggrroouunnddiinngg aass ddeessccrriibbeedd iinn NNEECC aanndd yyoouurr llooccaall//
ssttaattee//nnaattiioonnaall eelleeccttrriiccaall ccooddeess

PTAC-SVX004A-EN 3
WWAARRNNIINNGG
PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE))
RReeqquuiirreedd!!
FFaaiilluurree ttoo wweeaarr pprrooppeerr PPPPEE ffoorr tthhee jjoobb bbeeiinngg
uunnddeerrttaakkeenn ccoouulldd rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy
TTeecchhnniicciiaannss,, iinn oorrddeerr ttoo pprrootteecctt tthheemmsseellvveess ffrroomm
ppootteennttiiaall eelleeccttrriiccaall,, mmeecchhaanniiccaall,, aanndd cchheemmiiccaall
hhaazzaarrddss,, MMUUSSTT ffoollllooww pprreeccaauuttiioonnss iinn tthhiiss mmaannuuaall
aanndd oonn tthhee ttaaggss,, ssttiicckkeerrss,, aanndd llaabbeellss,, aass wweellll aass tthhee
iinnssttrruuccttiioonnss bbeellooww::
•• BBeeffoorree iinnssttaalllliinngg//sseerrvviicciinngg tthhiiss uunniitt,,
tteecchhnniicciiaannss MMUUSSTT ppuutt oonn aallll PPPPEE rreeqquuiirreedd ffoorr
tthhee wwoorrkk bbeeiinngg uunnddeerrttaakkeenn ((EExxaammpplleess;; ccuutt
rreessiissttaanntt gglloovveess//sslleeeevveess,, bbuuttyyll gglloovveess,, ssaaffeettyy
ggllaasssseess,, hhaarrdd hhaatt//bbuummpp ccaapp,, ffaallll pprrootteeccttiioonn,,
eelleeccttrriiccaall PPPPEE aanndd aarrcc ffllaasshh ccllootthhiinngg))
AALLWWAAYYSS rreeffeerr ttoo aapppprroopprriiaattee SSaaffeettyy DDaattaa
SShheeeettss ((SSDDSS)) aanndd OOSSHHAA gguuiiddeelliinneess ffoorr
pprrooppeerr PPPPEE
•• WWhheenn wwoorrkkiinngg wwiitthh oorr aarroouunndd hhaazzaarrddoouuss
cchheemmiiccaallss,, AALLWWAAYYSS rreeffeerr ttoo tthhee aapppprroopprriiaattee
SSDDSS aanndd OOSSHHAA//GGHHSS ((GGlloobbaall HHaarrmmoonniizzeedd
SSyysstteemm ooff CCllaassssiiffiiccaattiioonn aanndd LLaabbeelllliinngg ooff
CChheemmiiccaallss)) gguuiiddeelliinneess ffoorr iinnffoorrmmaattiioonn oonn
aalllloowwaabbllee ppeerrssoonnaall eexxppoossuurree lleevveellss,, pprrooppeerr
rreessppiirraattoorryy pprrootteeccttiioonn aanndd hhaannddlliinngg
iinnssttrruuccttiioonnss
•• IIff tthheerree iiss aa rriisskk ooff eenneerrggiizzeedd eelleeccttrriiccaall
ccoonnttaacctt,, aarrcc,, oorr ffllaasshh,, tteecchhnniicciiaannss MMUUSSTT ppuutt
oonn aallll PPPPEE iinn aaccccoorrddaannccee wwiitthh OOSSHHAA,, NNFFPPAA
7700EE,, oorr ootthheerr ccoouunnttrryy--ssppeecciiffiicc rreeqquuiirreemmeennttss
ffoorr aarrcc ffllaasshh pprrootteeccttiioonn,, PPRRIIOORR ttoo sseerrvviicciinngg
tthhee uunniitt NNEEVVEERR PPEERRFFOORRMM AANNYY SSWWIITTCCHHIINNGG,,
DDIISSCCOONNNNEECCTTIINNGG,, OORR VVOOLLTTAAGGEE TTEESSTTIINNGG
WWIITTHHOOUUTT PPRROOPPEERR EELLEECCTTRRIICCAALL PPPPEE AANNDD
AARRCC FFLLAASSHH CCLLOOTTHHIINNGG EENNSSUURREE
EELLEECCTTRRIICCAALL MMEETTEERRSS AANNDD EEQQUUIIPPMMEENNTT AARREE
PPRROOPPEERRLLYY RRAATTEEDD FFOORR IINNTTEENNDDEEDD
VVOOLLTTAAGGEE
WWAARRNNIINNGG
FFiirree HHaazzaarrdd!!
FFaaiilluurree ttoo ffoollllooww tthhiiss wwaarrnniinngg ccoouulldd rreessuulltt iinn
sseerriioouuss iinnjjuurryy,, ddeeaatthh,, oorr pprrooppeerrttyy ddaammaaggee
TThhoouugghh tthhee ffllaammmmaabbiilliittyy ooff tthhee rreeffrriiggeerraanntt iiss llooww,,
iitt ccaann bbee iiggnniitteedd bbyy ffiirree DDoo NNOOTT eexxppoossee tthhee
rreeffrriiggeerraanntt ttoo ooppeenn ffllaammeess oorr aannyy ootthheerr iiggnniittiioonn
ssoouurrccee
WWAARRNNIINNGG
SSaaffeettyy PPrreeccaauuttiioonnss!!
FFaaiilluurree ttoo ffoollllooww tthhee ssaaffeettyy pprreeccaauuttiioonnss ccoouulldd
rreessuulltt iinn sseerriioouuss iinnjjuurryy,, ddeeaatthh,, oorr pprrooppeerrttyy
ddaammaaggee
BBeeffoorree iinnssttaalllliinngg aanndd ooppeerraattiinngg tthhee uunniitt,, oobbsseerrvvee
tthhee ffoolllloowwiinngg ssaaffeettyy pprreeccaauuttiioonnss
•• IInnssttaallll,, ooppeerraattee,, aanndd ssttoorree tthhee uunniitt iinn aa rroooomm
wwiitthh aa fflloooorr aarreeaa llaarrggeerr tthhaann 4433fftt22 ((44mm22))
•• SSttoorree tthhee uunniitt iinn aa rroooomm wwhheerree tthheerree aarree nnoo
ccoonnttiinnuuoouussllyy ooppeerraattiinngg iiggnniittiioonn ssoouurrcceess ((ii ee ,,
ooppeenn ffllaammeess,, aann ooppeerraattiinngg ggaass aapppplliiaannccee,, oorr
aann ooppeerraattiinngg eelleeccttrriicc hheeaatteerr))
•• SSttoorree tthhee uunniitt iinn aa wweellll--vveennttiillaatteedd aarreeaa wwiitthh aa
rroooomm ssiizzee tthhaatt mmaattcchheess ttoo tthhee rroooomm aarreeaa
ssppeecciiffiieedd ffoorr ooppeerraattiioonn
•• SSttoorree tthhee uunniitt ccaarreeffuullllyy ttoo pprreevveenntt
mmeecchhaanniiccaall ddaammaaggee
•• DDuuccttss ccoonnnneeccttiinngg ttoo tthhiiss uunniitt sshhoouulldd nnoott hhaavvee
aann iiggnniittiioonn ssoouurrccee
•• KKeeeepp aannyy rreeqquuiirreedd vveennttiillaattiioonn ooppeenniinnggss cclleeaarr
ooff oobbssttrruuccttiioonn
•• DDoo nnoott ppiieerrccee oorr bbuurrnn tthhiiss uunniitt
•• BBee aawwaarree tthhaatt rreeffrriiggeerraannttss mmaayy nnoott ccoonnttaaiinn
aann ooddoorr
•• DDoo nnoott uussee mmeeaannss ttoo aacccceelleerraattee tthhee
ddeeffrroossttiinngg pprroocceessss oorr ttoo cclleeaann tthhiiss uunniitt OOnnllyy
uussee wwhhaatt iiss rreeccoommmmeennddeedd bbyy tthhee
mmaannuuffaaccttuurreerr
•• AAnnyy sseerrvviicciinngg oonn tthhiiss uunniitt mmuusstt bbee ppeerrffoorrmmeedd
oonnllyy aass rreeccoommmmeennddeedd bbyy mmaannuuffaaccttuurreerr
•• IIff rreeppaaiirr iiss nneecceessssaarryy,, ccoonnttaacctt aann aauutthhoorriizzeedd
sseerrvviiccee cceenntteerr oonnllyy AAnnyy rreeppaaiirrss ccaarrrriieedd oouutt
bbyy uunnqquuaalliiffiieedd ppeerrssoonnnneell mmaayy bbee ddaannggeerroouuss
•• CCoommpplliiaannccee wwiitthh llooccaall aanndd nnaattiioonnaall bbuuiillddiinngg
ccooddeess sshhaallll bbee oobbsseerrvveedd
WWAARRNNIINNGG
FFoollllooww EEHHSS PPoolliicciieess!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss bbeellooww ccoouulldd rreessuulltt iinn
ddeeaatthh oorr sseerriioouuss iinnjjuurryy
•• AAllll TTrraannee ppeerrssoonnnneell mmuusstt ffoollllooww tthhee
ccoommppaannyy’’ss EEnnvviirroonnmmeennttaall,, HHeeaalltthh aanndd SSaaffeettyy
((EEHHSS)) ppoolliicciieess wwhheenn ppeerrffoorrmmiinngg wwoorrkk ssuucchh aass
hhoott wwoorrkk,, eelleeccttrriiccaall,, ffaallll pprrootteeccttiioonn,, lloocckkoouutt//
ttaaggoouutt,, rreeffrriiggeerraanntt hhaannddlliinngg,, eettcc WWhheerree llooccaall
rreegguullaattiioonnss aarree mmoorree ssttrriinnggeenntt tthhaann tthheessee
ppoolliicciieess,, tthhoossee rreegguullaattiioonnss ssuuppeerrsseeddee tthheessee
ppoolliicciieess
•• NNoonn--TTrraannee ppeerrssoonnnneell sshhoouulldd aallwwaayyss ffoollllooww
llooccaall rreegguullaattiioonnss
WWaarrnniinnggss,, CCaauuttiioonnss,, aanndd NNoottiicceess

4PTAC-SVX004A-EN
WWAARRNNIINNGG
CCaanncceerr aanndd RReepprroodduuccttiivvee HHaarrmm!!
TThhiiss pprroodduucctt ccaann eexxppoossee yyoouu ttoo cchheemmiiccaallss
iinncclluuddiinngg lleeaadd aanndd bbiisspphheennooll AA ((BBPPAA)),, wwhhiicchh aarree
kknnoowwnn ttoo tthhee SSttaattee ooff CCaalliiffoorrnniiaa ttoo ccaauussee ccaanncceerr
aanndd bbiirrtthh ddeeffeeccttss oorr ootthheerr rreepprroodduuccttiivvee hhaarrmm FFoorr
mmoorree iinnffoorrmmaattiioonn ggoo ttoo wwwwww PP6655WWaarrnniinnggss ccaa
ggoovv
Copyright
This document and the information in it are the
property of Trane, and may not be used or reproduced
in whole or in part without written permission Trane
reserves the right to revise this publication at any time,
and to make changes to its content without obligation
to notify any person of such revision or change
Trademarks
All trademarks referenced in this document are the
trademarks of their respective owners
WWaarrnniinnggss,, CCaauuttiioonnss,, aanndd NNoottiicceess

PTAC-SVX004A-EN 5
General Information 6
Model Number Description 7
Air Conditioners with Electric Heat 8
Heat Pumps with Electric Heaters 9
Electrical 10
Power Connection Options 10
All Units 10
Grounding 10
Voltage Supply 10
Cord/Connected Units 10
Power Cord Protection 11
Refrigerant System Diagrams 12
PTHG Cooling, Heat Pump, Auxiliary
Electric Heat 12
PTEG Cooling and Electric Heat 12
Electrical Wiring Diagrams 13
Electrical Wiring Diagrams for 208V/
230V and 265 13
Installation 14
Trane Wall Sleeve and Grille 14
Considerations for Use of Existing
Sleeves 14
Installing the Chassis into Wall
Sleeve 15
System Configuration 16
Adjusting Air Direction- Only for Duct
Installations 16
DIP Switches 16
Keypad Configuration 17
Auxillary Controls 18
Wiring the Wall Thermostat 18
Energy Management Input (Front Desk
Control) 19
Intelligent Self-Checking Control 19
Operation 20
Control Buttons and Functions 20
LED Display and Digital Display 20
LEDs 20
Digital Display 20
Mode Functions 21
Cooling Mode Functions 21
Heating Mode Functions 21
Operating the Remote Control 23
Changing Batteries in the Remote
Control 24
Care and Cleaning 25
Front Panel and Case 25
Outdoor Coil 25
Base Pan 25
Air Filter 25
Service Installation 26
Disassembling the Unit 27
Temperature and Resistance Charts 31
Troubleshooting and Resources 33
Troubleshooting Error Codes and
Malfunctions 33
Technicians Guidelines 36
Resources 39
Table of Contents

6PTAC-SVX004A-EN
General nformation
The ProSpace™Packaged Terminal Air Conditioners
and heat pumps provide a high standard of quality in
performance, workmanship, durability and appearance
as they heat and cool the occupied air space year
round
This manual provides information for ease of
installation, operation and maintenance All models are
designed for through–the–wall installation Separate
installation instructions are included with all accessory
components
Read this manual completely and carefully before
starting any work Write down the model and serial
number on the space provided on the product
registration card The model and serial number can be
located on the serial number plate attached to the unit
These numbers are required for any service work
IImmppoorrttaanntt:: Ensure that this manual is left with the
owner for future reference. Observe all
local codes and ordinances. Observe all
governing codes and ordinances. These
instructions must be saved for local
inspector's use. Be sure to leave these
instructions with the owner.
Table 1. Operating Temperature Range:
Indoor Side DB/WB (°F/°C) Outdoor Side DB/WB (°F/°C)
Maximum Cooling 80/67 (26.7/19.4) 115/75 (46.1/23.9)
Maximum RC Heating 80/- (26.7/-) 75/65 (23.9/18.3)
Maximum Electric Heating 77/- (25/-) 77/- (25/-)
• Ambient temperature range (indoor temperature) for cooling is 64-80°F (18-26.7°C),
• Ambient temperature range (outdoor temperature) for cooling is 64-115°F (18-46.1°C),
• Ambient temperature range (indoor temperature) for heat pump is 41-80°F (5-26.7°C),
• Ambient temperature range (outdoor temperature) for Electric Heating is 19-77°F (-7-25°C).
• Ambient temperature range (outdoor temperature) for heat pump is 55-75°F (13-23.9°C),

PTAC-SVX004A-EN 7
Model Number Description
Use the following to determine the correct model number:
Size and Cooling
070 = 7,000 Btu
090 = 9,000 Btu
120 = 12,000 Btu
150 = 15,000 Btu
Electrical Voltage
1 = 208/230 Vac
2 = 265 Vac
Development Sequence
F = R410A Refrigerant
G = R32 Refrigerant
Design Sequence
AA = First
AB = Second
Product Family
PT = Packaged Terminal Unit
P T E G 0 7 0 2 G A A
Heating Methods
E = Cooling with Electric Heat
H = Heat Pump with Electric Heat
Electric Heat Size
G = Maximum of 3.5 kW
H = Maximum of 5.0 kW

8PTAC-SVX004A-EN
Air Conditioners with Electric Heat
Performance Units PTEG0701GAA PTEG0702GAA PTEG0901GAA PTEG0902GAA PTEG1201HAA PTEG1202HAA PTEG1501HAA PTEG1502HAA
Trade Name: ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™
Style/Function: Cooling Only w/
Heaters
Cooling Only w/
Heaters
Cooling Only w/
Heaters
Cooling Only w/
Heaters
Cooling Only w/
Heaters
Cooling Only w/
Heaters
Cooling Only w/
Heaters
Cooling Only w/
Heaters
Cooling
Capacity: Btu/h 7,200/7,400 7,500 9,900/10,200 10,000 12,100/12,300 12,300 14,400/14,700 14,800
Electric Heat
Power Input
Only:
W2,450(2,010)/
3,450(2,830) 2,450/3,450 2,450(2,010)/
3,450(2,830) 2,450/3,450
2,450(2,010)/ 3,450(2,830)/
5,000(4,090)
2,450/3,450/
5,000
2,450(2,010)/ 3,450(2,830)/
5,000(4,090)
2,450/3,450/
5,000
Rated Input
(Electric Heat +
Fan Motor)
W2,500(2,040)/
3,500(2,860) 2,500/3,500 2,500(2,040)/
3,500(2,860) 2,500/3,500
2,500(2,040)/ 3,500(2,860)/
5,050(4,130)
2,500/3,500/
5,050
2,500(2,040)/ 3,500(2,860)/
5,050(4,130)
2,500/3,500/
5,050
EER: (Btu/h)/
W13.3 13.3 12.5 12.5 11.8/11.6 11.6 10.6/10.4 10.6
Dehumidifying
Vol: Pint/h 1.69 1.69 2.11 2.11 2.75 2.75 3.17 3.17
Application
Area: ft2 108-172 108-172 129-194 129-194 172-258 172-258 226-334 226-334
Electrical
Rated Voltage: V~ 208/230 265 208/230 265 208/230 265 208/230 265
Rated
Frequency: Hz 60 60 60 60 60 60 60 60
Phases: 1 1 1 1 1 1 1 1
Cooling Power
Current: A2.6/2.4 2.1 3.9/3.6 3.2 5.0/4.7 4.0 6.5/6.0 5.3
Power Cord: Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Features
Sound Pressure
Level (L/H): dB (A) 46/50 46/50 46/50 46/50 50/53 50/53 50/53 50/53
Airflow Volume
(L/H): CFM 282/312 282/312 282/330 282/330 306/341 306/341 306/341 306/341
Warranty:
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
Specifications
Dim of Package
(L x W x H): Inch 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19
Net Weight: lb 110 110 110 110 115 115 115 115
Refrigerant: R-32 R-32 R-32 R-32 R-32 R-32 R-32 R-32
Refrigerant
Charge: lb 1.1 1.1 1.1 1.1 1.3 1.3 1.2 1.1

PTAC-SVX004A-EN 9
Heat Pumps with Electric Heaters
Performance Units PTHG0701GAA PTHG0702GAA PTHG0901GAA PTHG0902GAA PTHG1201HAA PTHG1202HAA PTHG1501HAA PTHG1502HAA
Trade Name: ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™
Style/Function: Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Cooling
Capacity: Btu/h 7,200/7,400 7,300 9.400/9,700 9,800 11,900/12,100 12,000 14,200/14,600 14,500
Heating
Capacity: Btu/h 5,800/6,000 6,000 8,200/8,500 8,600 10,700/10,900 10,700 13,300/13,800 13,300
Electric Heat
Power Input
Only:
W2,450(2,010)/
3,450(2,830) 2,450/3,450 2,450(2,010)/
3,450(2,830) 2,450/3,450
2,450(2,010)/ 3,450(2,830)/
5,000(4,090)
2,450/3,450/
5,000
2,450(2,010)/ 3,450(2,830)/
5,000(4,090)
2,450/3,450/
5,000
Rated Input
(Electric Heat +
Fan Motor)
W2,500(2,040)/
3,500(2,860) 2,500/3,500 2,500(2,040)/
3,500(2,860) 2,500/3,500
2,500(2,040)/ 3,500(2,860)/
5,050(4,130)
2,500/3,500/
5,050
2,500(2,040)/ 3,500(2,860)/
5,050(4,130)
2,500/3,500/
5,050
EER: (Btu/h)/
W13.0 13.0 12.1 12.1 11.8/11.6 11.6 10.4 10.4
Dehumidifying
Vol: Pint/h 1.69 1.69 2.11 2.11 2.75 2.75 3.17 3.17
Application
Area: ft2 108-172 108-172 129-194 129-194 172-258 172-258 226-334 226-334
Electrical
Rated Voltage: V~ 208/230 265 208/230 265 208/230 265 208/230 265
Rated
Frequency: Hz 60 60 60 60 60 60 60 60
Phases: 1 1 1 1 1 1 1 1
Cooling Power
Current: A2.6/2.4 2.1 3.9/3.6 3.1 4.9/4.6 4.0 6.5/6.0 5.3
Heating Power
Current: A2.3/2.1 1.8 3.2/3.1 2.6 4.3/4.1 3.5 5.9/5.6 4.7
Power Cord: Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Features
Sound Pressure
Level (L/H): dB (A) 46/50 46/50 46/50 46/50 50/53 50/53 50/53 50/53
Airflow Volume
(L/H): CFM 282/312 282/312 282/330 282/330 306/341 306/341 306/341 306/341
Warranty:
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
Specifications
Dim of Package
(L x W x H): Inch 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19
Net Weight: lb 112 112 115 115 119 119 120 120
Refrigerant: R32 R32 R32 R32 R32 R32 R32 R32
Refrigerant
Charge: lb 1.7 1.7 1.5 1.5 1.8 1.8 1.9 1.8

10 PTAC-SVX004A-EN
Electrical
WWAARRNNIINNGG
LLiivvee EElleeccttrriiccaall CCoommppoonneennttss!!
FFaaiilluurree ttoo ffoollllooww aallll eelleeccttrriiccaall ssaaffeettyy pprreeccaauuttiioonnss
wwhheenn eexxppoosseedd ttoo lliivvee eelleeccttrriiccaall ccoommppoonneennttss ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy
WWhheenn iitt iiss nneecceessssaarryy ttoo wwoorrkk wwiitthh lliivvee eelleeccttrriiccaall
ccoommppoonneennttss,, hhaavvee aa qquuaalliiffiieedd lliicceennsseedd eelleeccttrriicciiaann
oorr ootthheerr iinnddiivviidduuaall wwhhoo hhaass bbeeeenn pprrooppeerrllyy ttrraaiinneedd
iinn hhaannddlliinngg lliivvee eelleeccttrriiccaall ccoommppoonneennttss ppeerrffoorrmm
tthheessee ttaasskkss
WWAARRNNIINNGG
PPoowweerr CCoorrdd!!
IIff tthhee SSUUPPPPLLYY CCOORRDD iiss ddaammaaggeedd,, iitt mmuusstt bbee
rreeppllaacceedd bbyy tthhee mmaannuuffaaccttuurreerr,, iittss sseerrvviiccee aaggeenntt oorr
ssiimmiillaarrllyy qquuaalliiffiieedd ppeerrssoonnss iinn oorrddeerr ttoo aavvooiidd aa
hhaazzaarrdd
Power Connection Options
Appropriate power cord accessory kit is determined by
the voltage and the amperage of the branch circuit,
based on the unit amperage requirements (for
example, electric heater size) This unit ships without a
power cord (or hard wire kit) An accessory power cord
must be ordered to connect the unit to the outlet
NNootteess::
• Ensure the outlet matches the appropriate
prong configuration on the plug. It should
be within reach of the service cord. All
wiring including installation of the
receptacle must be in accordance with the
NEC
™
and all local codes ordinances and
regulations. National codes require the use
of an arc fault or leakage current detection
device on all 208/230V power cords.
• For 265V units if power cord accessory
option is selected then the cord is only 18"
long and must plug into the accessory
electrical 265V sub-base.
All Units
IImmppoorrttaanntt:: Follow NEC and local electrical codes when
installing electrical supply wiring. The
following is only shown as a sample.
Use recommended wire size (Table 1) and install a
single-branch circuit All units are designed to operate
off only one (1) single branch circuit
NNoottee:: Only use copper conductors. Branch circuit wire
is single circuit from main box. AWG wire sizes
are based on copper wire at a 140°F (60°C)
temperature rating.
Table 2. Common Branch Circuit Wire Sizes
Nameplate Amps AWG Wire Size
7.0 to 12 14
12.1 to 16 12
16.1 to 24 10
Grounding
For safety and protection, the unit is grounded through
the service cord plug or through separate ground wire
provided on hard wired units Ensure that the branch
circuit or general purpose outlet is grounded
Voltage Supply
Check voltage supply at outlet For satisfactory results,
the voltage range must always be within the ranges
specified on the data information plate Power cord
does not ship with the unit The cord to order is
determined by the unit voltage and the desired electric
heat capacity
Cord/Connected Units
The 250 Vac field supplied outlet must match the plug
for standard 208/230V units and be within reach of the
service cord
NNoottee:: Do NOT use 30 amp cord with sizes 07 and 09
units.
Table 3. Electric Heater and Cord nformation, PTEG and PTHG Sizes 07 and 09
Voltage: 230 Vac(a) 265 Vac
Amps:(b) 15 20 15 20
Heater Size: 2.5 kW 3.5 kW 2.5 kW 3.5 kW
Plug Layout:
G
G
G
W
G
W
NEMA Plug: 6-15P 6-20P 7-15P 7-20P
Cord #: PWR00286 PWR00288 PWR00287 PWR00289
(a) The 250 Vac field supplied outlet must match the plug for standard 208/230V units and be within reach of the service cord.
(b) Do Not use 30 amp cord with sizes 07 and 09 units.

PTAC-SVX004A-EN 11
Table 4. Electric Heater and Cord nformation, PTEG and PTHG Sizes 12 and 15
Voltage: 230 Vac 265 Vac
Amps: 15 20 30 15 20 30
Heater Size: 2.5 kW 3.5 kW 5.0 kW 2.5 kW 3.5 kW 5.0 kW
Plug Layout:
G
G
G
G
W
G
W
G
W
NEMA Plug: 6-15P 6-20P 6-30P 7-15P 7-20P 7-30P
Cord #(a) : PWR00286 PWR00288 PWR00290 PWR00287 PWR00289 PWR00291
(a) Power cord does not ship with the unit.
Power Cord Protection
The power cord for 230/208V units provide protection
from fire The unit power automatically disconnects
when unsafe conditions are detected Power to the unit
can be restored by pressing the reset button on plug
head Upon completion of unit installation for 230/208V
models, an operational check should be performed
using the TEST/RESET buttons on the plug head
NNoottee:: Models with 265V do not incorporate this feature
because they require use of an electrical sub-
base accessory. Connection to a wall socket is
not permitted for 265V units. All 265V units must
be hard wired using the hard wire kit or make
use of the plug-in receptacle in the standard sub-
base.
EElleeccttrriiccaall

12 PTAC-SVX004A-EN
Refrigerant System Diagrams
PTHG Cooling, Heat Pump, Auxiliary Electric Heat
PTEG Cooling and Electric Heat

PTAC-SVX004A-EN 13
Electrical Wiring Diagrams
Symbol
Color/
Name
WH White
YE Yellow
RD Red
YEGN Yellow/Green
VT Violet
GN Green
BN Brown
BU Blue
BK Black
OG Orange
CAP Jumper cap
COMP Compressor
Grounding
Wire
Electrical Wiring Diagrams for
208V/230V and 265
The electrical schematic diagram pictured below is
subject to change Please reference the wiring diagram
on the unit
220088//223300VV;; PPTTEEGG00770011 aanndd PPTTEEGG00990011
226655VV;; PPTTEEGG00770022 aanndd PPTTEEGG00990022
BK
L2
L1
X2
BK
RD
5EH1 1.0KW
EH2 2.45KW
1
EH3 1.55KW
3WH
RD
BU
BK
NG UB
COMP
X1
YE BU
SR
C
C1
G
2
1
RD
BK
COMP
AC-L K1
2
XT1
N1
WH
RD
BU
XT2
BK
KM1
4
1
5
6
BN
WH BK
HEAT1
I-HEAT-2
O-HEAT-2
O-HEAT-1
I-HEAT-1
1
CN2
CN10
N1
OFAN-L
OFAN-H
BU
BN
BN
RD
YEGN
G
C3
FAN MOTOR
CN9 CN1
CN4
AP2
AP1
TR-OUT
TR-IN
TC
FAN
RD
BN
C2
YEGN
G
FAN MOTOR
BK
BU
WH
BK FUT
B1 B2 B3 A1
BKBK
C2:1uF OR 1.5uF C3:1.5uF OR 2uF OR 2.5uF
A2 A3
CN3
WALL
THERMOSTAT
OPTIONAL
Circuit diagram:
BU
K3
BK
COMP.
RELAY
TR-OUT2
K2
OPTIONAL
CN1
CN8
OPTIONAL
AP3
DISP2
DISPLAY
DISP1
DAHT TEMP.
RT4
SENSOR
TUBE TEMP.
ROOM TEMP.
SENSOR
OUTTUBE
TEMP. SENSOR
SENSOR
RT3 RT2 RT1
RD WH BK
15K
BK
20K
K02 K02
CN1
HEATER
DISP3
SUBBASE
(FOR 265V UNIT)
SAT1SAT2
BK
B1 B2 B3 A1 A2 A3
M2
I
II
X3
1
III
M1
2
3
4
6
5
1
7
X4
BK
L1(L) WH
L2(N) GN(YEGN)
POWER
PLUG
JUMP1
JUMP2
MANAGEMENT
CONTROLLER
RECEIVER
ENERGY
(OPTIONAL)
(OPTIONAL)
220088//223300VV;; PPTTEEGG11220011 aanndd PPTTEEGG11550011
226655VV;; PPTTEEGG11220022 aanndd PPTTEEGG11550022
BK
L2
L1
X2
BK
RD
5EH1 1.0KW
EH2 2.45KW
1
EH3 1.55KW
3WH
RD
BU
BK
BU
GN
DAHT TEMP.
RT4
COMP
X1
YE BU
SR
C
C1
G
2
1
RD
K4
BK
K1
2
COMP
AC-L
XT1
N1
WH
RD
BU
XT2
BK
SENSOR
TUBE TEMP.
ROOM TEMP.
SENSOR
OUTTUBE
TEMP. SENSOR
KM1
4
1
5
6
WH BK
BN
HEAT1
I-HEAT-2
O-HEAT-2
O-HEAT-1
I-HEAT-1
1
SENSOR
CN2
CN10
N1
OFAN-L
OFAN-H
BU
BN
BN
RD
YEGN
G
C3
CN9 CN1
CN4
AP2
AP3
AP1
TR-OUT
TR-IN
TC
DISP2
DISPLAY
FAN
RD
BN
C2
YEGN
G
FAN MOTOR
BK
BU
WH
B1 B2 B3
BK FUT BKBK
C2:1uF OR 1.5uF C3:1.5uF OR 2uF OR 2.5uF
A1 A2 A3
CN3
WALL
THERMOSTAT
OPTIONAL
Circuit diagram:
FAN MOTOR
RT3 RT2 RT1
BU
I-HEAT-3
O-HEAT-3
WH
WH
K3
BK
COMP.
RELAY
TR-OUT2
K2
OPTIONAL
θ
θθθ
CN1
DISP1
CN8
OPTIONAL
RD WHBK
15K
BK
20K
K02 K02
CN1
HEATER
DISP3
SUBBASE
(FOR 265V UNIT)
SAT1SAT2
BK
B1 B2 B3 A1 A2 A3
M2
I
X3
II
1
M1
2
III
3
4
6
5
1
7
X4
BK
L1(L) WH
L2(N) GN(YEGN)
POWER
PLUG
JUMP1
JUMP2
MANAGEMENT
CONTROLLER
RECEIVER
ENERGY
(OPTIONAL)
(OPTIONAL)
220088//223300VV;; PPTTHHGG00770011 aanndd PPTTHHGG00990011
226655VV;; PPTTHHGG00770022 aanndd PPTTHHGG00990022
BK
L2
L1
X2
BK
RD
5EH1 1.0KW
EH2 2.45KW
1
EH3 1.55KW
3WH
RD
BU
BK
NG UB
COMP
X1
YE BU
SR
C
C1
G
2
1
RD
BK
K1
2
COMP
AC-L
XT1
N1
WH
RD
BU
XT2
BK
KM1
4
1
5
6
WH BK
BN
HEAT1
I-HEAT-2
O-HEAT-2
O-HEAT-1
I-HEAT-1
1
CN2
CN10
N1
OFAN-L
OFAN-H
BU
BN
BN
RD
YEGN
G
C3
FAN MOTOR
CN9 CN1
CN4
AP2
AP1
TR-OUT
TR-IN
TC
FAN
RD
BN
C2
YEGN
G
FAN MOTOR
BK
BU
WH
BK FUT
B1 B2 B3 A1
BKBK
C2:1uF OR 1.5uF C3:1.5uF OR 2uF OR 2.5uF
A2 A3
CN3
WALL
THERMOSTAT
OPTIONAL
Circuit diagram:
BU
K3
BK
COMP.
RELAY
TR-OUT2
K2
OPTIONAL
CN1
CN8
OPTIONAL
N2 4WAY
4YV
AP3
DISP2
DISPLAY
DISP1
DAHT TEMP.
RT4
SENSOR
TUBE TEMP.
ROOM TEMP.
SENSOR
SENSOR
RT3 RT2 RT1
θ
θθθ
RD WH BK
15K
BK
20K
K02 K02
CN1
HEATER
4-WAY VALVE
DISP3
SUBBASE
(FOR 265V UNIT)
SAT1SAT2
BK
B1 B2 B3 A1 A2 A3
M2
I
X3
II
1
M1
2
III
3
4
6
5
1
7
X4
BK
L1(L) WH
L2(N) GN(YEGN)
POWER
PLUG
JUMP1
JUMP2
MANAGEMENT
CONTROLLER
RECEIVER
(OPTIONAL)
ENERGY
(OPTIONAL)
OUTTUBE
TEMP. SENSOR
220088//223300VV;; PPTTHHGG11220011 aanndd PPTTHHGG11550011
226655VV;; PPTTHHGG11220022 aanndd PPTTHHGG11550022
BK
L2
L1
X2
BK
RD
5EH1 1.0KW
EH2 2.45KW
1
EH3 1.55KW
3WH
SAT1
RD
BU
BK
NG UB
COMP
X1
YE BU
SR
C
C1
G
2
1
RD
K4
BK
COMP
AC-L K1
2
XT1
N1
WH
RD
BU
XT2
BK
KM1
4
1
5
6
BN
WH BK
HEAT1
I-HEAT-2
O-HEAT-2
O-HEAT-1
I-HEAT-1
1
CN2
CN10
N1
OFAN-L
OFAN-H
BU
BN
BN
RD
YEGN
G
C3
FAN MOTOR
CN9 CN1
CN4
AP2
AP1
TR-OUT
TR-IN
TC
FAN
RD
BN
C2
YEGN
G
FAN MOTOR
BK
BU
WH
BK FUT
B1 B2 B3
BK BK
C2:1uF OR 1.5uF C3:1.5uF OR 2uF OR 2.5uF
A1 A2 A3
CN3
WALL
THERMOSTAT
OPTIONAL
Circuit diagram:
BU
I-HEAT-3
O-HEAT-3
WH
WH
K3
BK
COMP.
RELAY
TR-OUT2
K2
OPTIONAL
CN1
CN8
OPTIONAL
N2 4WAY
4YV
AP3
DISP2
DISPLAY
DISP1
DAHT TEMP.
RT4
SENSOR
TUBE TEMP.
ROOM TEMP.
SENSOR
OUTTUBE
TEMP. SENSOR
SENSOR
RT3 RT2 RT1
θ
θθθ
RD WH BK
15K
BK
20K
K02 K02
CN1
HEATER
4-WAY VALVE
DISP3
SUBBASE
(FOR 265V UNIT)
SAT2
BK
B1 B2 B3 A1 A2 A3
M2
I
II
X3
1
M1
III
2
3
4
6
5
1
7
X4
BK
L1(L) WH
L2(N) GN(YEGN)
POWER
PLUG
JUMP1
JUMP2
MANAGEMENT
CONTROLLER
ENERGY
RECEIVER
(OPTIONAL)
(OPTIONAL)

14 PTAC-SVX004A-EN
nstallation
Trane Wall Sleeve and Grille
The image below shows the typical unit components
that are ordered and installed
IImmppoorrttaanntt:: Proper installation is the responsibility of
the installer. Product failure due to
improper installation is not covered under
warranty.
NNoottee:: To install the Trane Wall Sleeve and Grille refer
to the latest installation instructions PTAC-
SVN028 and PTAC-SVN027.
Considerations for Use of Existing
Sleeves
WWAARRNNIINNGG
LLiivvee EElleeccttrriiccaall CCoommppoonneennttss!!
FFaaiilluurree ttoo ffoollllooww aallll eelleeccttrriiccaall ssaaffeettyy pprreeccaauuttiioonnss
wwhheenn eexxppoosseedd ttoo lliivvee eelleeccttrriiccaall ccoommppoonneennttss ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy
WWhheenn iitt iiss nneecceessssaarryy ttoo wwoorrkk wwiitthh lliivvee eelleeccttrriiccaall
ccoommppoonneennttss,, hhaavvee aa qquuaalliiffiieedd lliicceennsseedd eelleeccttrriicciiaann
oorr ootthheerr iinnddiivviidduuaall wwhhoo hhaass bbeeeenn pprrooppeerrllyy ttrraaiinneedd
iinn hhaannddlliinngg lliivvee eelleeccttrriiccaall ccoommppoonneennttss ppeerrffoorrmm
tthheessee ttaasskkss
In applications when the unit is a replacement, it is
recommended to use a Trane sleeve This unit can be
retrofitted to other manufacturers similar sleeves if
outdoor unit airflow is not restricted or recirculated
IImmppoorrttaanntt:: Ensure the outdoor grille is installed on the
sleeve. For any sleeve retrofit applications
be sure that the foam seals (factory
installed on the tube sheets) provide a
good seal between the grille and outdoor
coil tube sheets. These foam seals provide
a barrier that stops the inside air from
mixing with the outside air (known as air
recirculation).
IImmppoorrttaanntt:: Inspect the wall sleeve thoroughly prior to
installation. The manufacturer does not
assume responsibility for costs or damage
due to defects in the sleeve or for improper
installation.
Remove any existing foam
baffles installed on
competitor’s outdoor grille.
General Electric Metal Wall
Sleeve; interchangeable with
ProSpace wall sleeve.
General Electric Plastic Wall
Sleeve; remove bottom seal
from plastic sleeve.

PTAC-SVX004A-EN 15
nstalling the Chassis into Wall
Sleeve
NNOOTTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
UUssee sspprreeaaddeerr bbaarrss ttoo pprreevveenntt ssttrraappss ffrroomm
ddaammaaggiinngg tthhee uunniitt IInnssttaallll tthhee bbaarrss bbeettwweeeenn lliiffttiinngg
ssttrraappss,, bbootthh uunnddeerrnneeaatthh tthhee uunniitt aanndd aabboovvee tthhee
uunniitt ttoo pprreevveenntt tthhee ssttrraappss ffrroomm ccrruusshhiinngg tthhee uunniitt
ccaabbiinneett oorr ddaammaaggiinngg tthhee ffiinniisshh
1 Carefully remove shipping tape from the front panel
and vent door
Shipping
tape
2 Remove shipping screw from the vent door, if
present
3 Remove front panel Consider the following
electrical guideline before sliding the unit back into
the wall
• All units require a cord or a hard-wired kit to be
added to complete electrical connection to the
building Follow the instructions provided with
those accessories
4 Lift unit level and slide unit into wall sleeve until
foam seal rests firmly against front of wall sleeve
5 Secure with four screws (supplied) through the unit
flange holes
6 Re-install front panel by first, hooking tabs over top
rail of unit (1) and then pushing in on the bottom of
the front panel until it snaps into place (2)
IInnssttaallllaattiioonn

16 PTAC-SVX004A-EN
System Configuration
Adjusting Air Direction- Only for
Duct nstallations
1 Remove front panel
Louver screws
Louver screws
2 Remove louver screws that hold the louver insert in
place on the back side of the front panel
3 Turn louver insert and rotate it 180°
4 Replace louver insert
5 Replace screws and the front panel
D P Switches
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee!!
FFaaiilluurree ttoo ddiissccoonnnneecctt ppoowweerr bbeeffoorree sseerrvviicciinngg ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy
DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee
ddiissccoonnnneeccttss bbeeffoorree sseerrvviicciinngg FFoollllooww pprrooppeerr
lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr
ccaann nnoott bbee iinnaaddvveerrtteennttllyy eenneerrggiizzeedd VVeerriiffyy tthhaatt nnoo
ppoowweerr iiss pprreesseenntt wwiitthh aa vvoollttmmeetteerr
The auxiliary DIP switch controls are located behind the
front panel and through an opening below the control
panel To access, you must remove the front panel The
DIP switches are accessible without opening the
control box
IImmppoorrttaanntt:: Electrical power supply must be
disconnected from unit to apply DIP switch
changes.
NNoottee:: Factory settings for DIP switches will be in the
DOWN position. Refer to the following for the
functionality of each DIP switch position.
Figure 1. D P switch/wall thermostat enable
DIP Switches
1 2 3 4 5 6 7
Freeze Guard
Setpoint Limit 2
Setpoint Limit 1
Wall Thermostat Enable
Electric Heat Only
for Heat Pumps
Fan CON/CYC for Cooling/
Energy Saver: Cooling
Fan CON/CYC for Heating
Energy Saver: Heating
Table 5. D P Switch Descriptions
DIP Switch Number Up Down Default Remarks
1: Electric Heating Only/Emergency Heat. This
setting is typically used for Emergency Heating.
Electric
Heat Only
Heat Pump Down For only
heat pump
units.
2: Wall Thermostat Enable. A wired wall thermostat
can be connected to the unit. The DIP switch must be
adjusted accordingly in order to allow the wall
thermostat control of the unit. When unit is in wall
thermostat mode, the control panel is disabled.
Wall
Thermostat
Enable
Control
Panel
Enable
Down
3: Energy Saver DIP Switches. Allows the fan to
operate in continuous or cycle mode while the unit is in
heating or cooling mode. DIP Switch 3: Continuous and
allows the fan to run continuously, circulating air even
when the temperature setting has been satisfied. DIP
Switch.
Fan
Continuous
Run for
Heating.
Fan Cycle
for Heat
Down

PTAC-SVX004A-EN 17
Table 5. D P Switch Descriptions (continued)
DIP Switch Number Up Down Default Remarks
4: Energy Saver DIP Switches. Allows the fan to
cycle ON and OFF with the compressor or electric
heater. The fan stops a short time after the temperature
setting is satisfied. This is the most efficient mode for
electrical usage.
Fan Cycle
for Cool.
Fan
Continu-
ous Run
for Cooling
Down
5/6: Setpoint Temperature Limits. Provides a
range of temperature control.
Up/Up
68°F to 75°
F
(20°C to
24°C)
Up/Down
63°F to 80°
F
(17°C to
28°C)
Down/Up
65°F to
78°F
(18°C to
26°C)
Down/
Down
61°F to 86°
F
(16°C to
30°C)
Down/
Down
Configura-
tions 5 and
6 combine
to select set
point range.
When
setpoint
limit set,
display
always
shows full
range.
7: Room Freeze Protection. If the unit senses a room
temperature below 40°F (4.44°C), the fan motor and
electric strip heat turns ON and warms the room to 50°
F (10°C). The fan stops a short time after the
temperature is satisfied.
Freeze
Guard
Disable
Freeze
Guard
Enable
Down
Keypad Configuration
The Trane ProSpace can be customized by configuring
the keypad
1 To enter the keypad configuration screen, first
power up the unit
2 Within the 30 seconds after power-up press and
hold both the ffaann ssppeeeedd and CCoooolleerr bbuuttttoonn for
five (5) seconds
NNoottee:: If waiting more than 30 seconds after power-
up you cannot access the keypad
configuration. Power down and power up the
unit again to restart the process.
3 To scroll through the available options, press and
release the ffaann ssppeeeedd button to select the keypad
configurations The stored value displays
4 To exit the configuration screen, press the mmooddee
button or after 30 seconds, the unit will
automatically exit the configuration screen
5 To modify configuration settings, press and release
simultaneously, either the SSeettppooiinntt and WWaarrmmeerr
bbuuttttoonn or SSeettppooiinntt and CCoooolleerr bbuuttttoonn
Choose from the following four (4) options:
•FFaahhrreennhheeiitt//CCeellssiiuuss DDiissppllaayy SSwwiittcchh; changes
between degrees Fahrenheit (F, default) and
Celsius (C) on the display
•IInnddoooorr AAiirr TTeemmppeerraattuurree SSeennssoorr BBiiaassiinngg ffoorr
CCoooolliinngg MMooddee; adjusts the room air
temperature reading when in cooling mode (not
normally required)
•IInnddoooorr AAiirr TTeemmppeerraattuurree SSeennssoorr BBiiaassiinngg ffoorr
HHeeaattiinngg MMooddee; adjusts the room air
temperature reading when in heating mode (not
normally required)
•IInnddoooorr TTeemmppeerraattuurree DDiissppllaayy; changes
between showing the setpoint or desired
temperature during heating and cooling modes
(SP, default) or displaying the actual room
temperature during heating and cooling modes
(AA)
–Selecting SP displays the desired setpoint
temperature during heating and cooling
modes, regardless of what the actual
temperature is in the room
–Selecting AA displays the room temperature
during heating, cooling, and fan-only modes
–Changing the mode button to either heating
or cooling modes displays the setpoint for
10 seconds After the 10 seconds, the room
temperature displays
–Depressing the ON-OFF when the unit is
OFF, and the last mode was either cooling or
heating, the setpoint displays for 10 seconds
before displaying the room temperature
–Depressing either WWaarrmmeerr bbuuttttoonn or
CCoooolleerr bbuuttttoonn during heating and cooling
mode displays the setpoint for 10 seconds
before displaying the room temperature
6 Press WWaarrmmeerr bbuuttttoonn or CCoooolleerr bbuuttttoonn to
switch between EEmmeerrggeennccyy AAuuttoo CCoooolliinngg
AAlllloowweedd (displays as CA) and EEmmeerrggeennccyy AAuuttoo
CCoooolliinngg RReejjeecctteedd (displays as CD)
7 When activating Auto Cooling Operation and room
temperature reaches 85°F while the unit is in the
SSTTOOPP mode, the unit automatically starts in Air
Conditioning Operation and shuts off when the
room temperature reaches 80°F
SSyysstteemm CCoonnffiigguurraattiioonn

18 PTAC-SVX004A-EN
Auxillary Controls
Wiring the Wall Thermostat
WWAARRNNIINNGG
LLiivvee EElleeccttrriiccaall CCoommppoonneennttss!!
FFaaiilluurree ttoo ffoollllooww aallll eelleeccttrriiccaall ssaaffeettyy pprreeccaauuttiioonnss
wwhheenn eexxppoosseedd ttoo lliivvee eelleeccttrriiccaall ccoommppoonneennttss ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy
WWhheenn iitt iiss nneecceessssaarryy ttoo wwoorrkk wwiitthh lliivvee eelleeccttrriiccaall
ccoommppoonneennttss,, hhaavvee aa qquuaalliiffiieedd lliicceennsseedd eelleeccttrriicciiaann
oorr ootthheerr iinnddiivviidduuaall wwhhoo hhaass bbeeeenn pprrooppeerrllyy ttrraaiinneedd
iinn hhaannddlliinngg lliivvee eelleeccttrriiccaall ccoommppoonneennttss ppeerrffoorrmm
tthheessee ttaasskkss
NNOOTTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss wwiillll rreessuulltt iinn
pprreemmaattuurree ffaaiilluurree ooff tthhee uunniitt
IImmpprrooppeerr wwiirriinngg mmaayy ddaammaaggee uunniitt eelleeccttrroonniiccss
CCoommmmoonn bbuussiinngg iiss nnoott ppeerrmmiitttteedd DDaammaaggee oorr
eerrrraattiicc ooppeerraattiioonn mmaayy rreessuulltt
After installing control panel blockoff PLT05872, the
previous control board should be retained to access
event diagnostic codes, if needed in the future
To wire the to the thermostat:
1 Check to be sure power to unit is disconnected
2 Route the wire through the thermostat under the
sleeve and behind the front panel as shown below
THERMOSTAT WIRE ROUTING
(UNDER SLEEVE, BEHIND FRONT PANEL)
3 Remove the terminal connector to simplify wiring
4 Connect wires from the thermostat to terminals on
unit terminal connector
NNoottee:: Thermostat wire is field supplied.
Recommended wire gauge is 18 to 20 gauge
solid thermostat wire.
IImmppoorrttaanntt:: Thermostat wire should always be
routed around or under the wall sleeve
NEVER through the wall sleeve.

PTAC-SVX004A-EN 19
Common
R
W
Y
O
GH
GL
C
Energy
Management
(24 Vac)
• R; 24 Vac
• W; Electric Heat
• Y; Compressor
• O; Reversing Valve (Heat Pump Unit Connection
Only)
• GH; High Fan
• GL; Low Fan
• C; Common (Typically for Digital Thermostats)
NNoottee:: Any incorrect input combinations are
captured as thermostat wiring failures and
will light the STATUS LED indicator on main
board.
5 Reinstall terminal connector
6 Ensure that unit is configured for wall thermostat
enable See Table 5, p 16 (DIP switch setting for
wall thermostat)
7 Replace control panel label with control panel
guard
8 Power-up the unit
GGeenneerraall NNootteess::
• Anytime there is a second-stage call for heating
from the wall thermostat,, the unit automatically
switches over to electric heating for heat pump
models
• For thermostats with two (2) fan speed output (such
as Low fan or Hi fan), the fan speed is determined
by how the terminal connector is wired When
using Low fan speed, wire the GL output from the
thermostat to GL on the terminal block When using
Hi fan speed, wire the GH output from the
thermostat to GH on the terminal block
Energy Management nput
(Front Desk Control)
The controller can handle a switch signal from remote
energy management input, called an EM signal or front
desk control The input must be 24 Vac When the
system receives a 24 Vac signal, it turns OFF the unit;
otherwise it is in normal control This function is
disabled under Freeze Guard protection
ntelligent Self-Checking Control
The PTAC has an on-board computer continuously
checks key components of the unit to ensure they are
operating properly Under normal operation, the unit
status indicator (STATUS, on main PCB), light is
steadily ON If there is a major problem, the unit shuts
down and displays a diagnostic failure code on the
control If it is a minor error and the unit can correct it
by itself, the diagnostic code is flashed on the status
LED that is easily seen when the front panel is
removed Refer to the following table of diagnostic
codes
NNootteess::
• When using a room thermostat diagnostic
codes are not viewable. These codes are
only viewable on the unit control board.
• After the compressor cycles three times the
F0 code can appear if the refrigerant charge
is low.
AAuuxxiillllaarryy CCoonnttrroollss

20 PTAC-SVX004A-EN
Operation
The following sections describe the operation of the
Trane ProSpace unit
Control Buttons and Functions
The section describes the buttons and functionality of
the Trane ProSpace unit
•OONN//OOFFFF; turns the unit ON or OFF
•MMooddee; switches between Cool, Fan, Heat, or Dry
(optional) Pressing this button when in OFF mode
and the controller resumes to the operation status
before power-off
•WWAARRMMEERR oorr CCOOOOLLEERR; the dual–8 nixie tube
displays the indoor temperature for 15 seconds and
then turns OFF It is used to increase/decrease the
temperature or timer setting
•FFaann; sets the High, Medium, Low or Auto fan
speeds
•TTiimmeerr; sets the timer function by using either of the
buttons on the control panel or by the remote
controller
–TTiimmeerr OONN ffuunnccttiioonn; the timer can be set to ON
when the unit is OFF Setting range is between
O 5 hours to 24 hours When timer ON setting is
reached, the system stops and operates
according to the set mode
–TTiimmeerr OOFFFF ffuunnccttiioonn; When the unit is off, timer
OFF can be set Setting range is between O 5
hours, to 24 hours When timer OFF setting is
reached, the system stops operation
–TTiimmeerr PPrreevviieeww ffuunnccttiioonn: use this function to
preview the remaining time of timer
•SSlleeeepp ffuunnccttiioonn; can only be set only using the
remote controller
•DDrryy ffuunnccttiioonn; This operational mode will help to
manage and reduce the humidity in the room,
making it more comfortable In Dry mode the unit
will operate cooling at low fan speed until the room
temperature is 4 degrees F below the room
temperature setting regardless of fan mode
selection This operation will drive more moisture
out by subcooling the space at low speed until 4
degrees below room set point The fan will run
continuous No other fan settings will override this
continuous fan operation of the Dry mode Dry
mode is NOT available when a wall thermostat is
installed This Dry mode is only available via the
unit mounted controls These unit mounted
controls are disabled and may even be removed
when wall thermostats are installed Dry mode or
function should not be considered a substitute for a
stand-alone dehumidifier
•BBuuzzzzeerr ooppttiioonn; when the controller is energized, or
when a valid remote control signal or /button signal
is received, the buzzer beeps
•AAuuttoo FFaann SSppeeeedd ffuunnccttiioonn; can be automatically
selected according to different modes or indoor
temperature to achieve a higher comfort level
•EEmmeerrggeennccyy CCoooolliinngg OOppeerraattiioonn ffuunnccttiioonn; When
the indoor ambient temperature is ≧86°F (30°C), the
unit starts cooling automatically When the indoor
ambient reaches 80 6°F (27°C), the unit stops
operation
•FF--ccooddee RReemmoottee CCoonnttrroolllleerr ffuunnccttiioonn; optional
LED Display and Digital Display
LEDs
The unit has two (2) 8-segment nixie tubes and eleven
(11) LEDs on the main board Each LED is lit for the
corresponding set mode Indicators LEDs are:
• High
• Low
• Auto
• Indoor Temperature
• Setpoint Temperature
• Dry
• Cool
• Constant Fan
• Heat
• Timer
• ON/OFF
Digital Display
When in cooling or heating mode, the digital display
defaults to the set temperature In Fan Mode, it displays
indoor ambient temperature When the display has
three digits, the digital is rolling to display values
When there is error or protection code displayed, the
STATUS LED blinks In OFF mode, the digital does not
display the error code (except the low temperature
