Trane TTK 509 E User manual

Installation Manual
Mini-Split System
Condensing Units TTK
Horizontal Air Discharge
9,000 to 36,000 BTU/h
50/60 Hz
SS-SVN03B-EN
September 2003
Models:
TTK 509 E TTK 518 E
TTK 512 E TTK 524 E
TTK 530 E
TTK 536 E

©American Standard Inc. 2003 SS-SVN03A-PT
GeneralInformation
Congratulations on your choice of a Trane
mini-split system. These systems have
been carefully designed and manufac-
tured under strict Trane Worldwide Quality
Standards to provide you with years of
comfortable, convenient cooling or heating/
cooling with a minimum of service.
This Installation Manual is given as a
guide to good practice in the installation by
the installer of TTK condensing unit for
mini-split system. Installation procedures
should be performed in the sequence that
they appear in this manual.
For installing the unit to operate properly
and reliably, it must be installed in accor-
dance with these instructions. Also, the
services of a qualified service technician
should be employed, through the mainte-
nance contract with a reputable service
company.
Read these Installation Instructions com-
pletely before installing the air conditioning
system.
AboutthisManual
Cautions appear at appropriate places in
this Instruction Manual. Your personal
safety and proper operation of this ma-
chine require that you follow them carefully.
The Trane Company assumes no liability
for unstalltions or servicing performed by
unqualified personnel.
All phases of the installation of this air
conditioning system must comfort to all
national, provincial, state and local codes.
General
Information
AboutthisUnit
These TTK condensing units are assem-
bled, pressure tested, dehydrated,
charged and run tested before shipment.
The information contained in this manual
applies to TTK condensing units are de-
signed to operate in cooling mode only.
Trane TTK series of condensing units for
mini-split systems offer five models of
capacity.
Reception
On arrival, inspect the unit before signing
the delivery note. Specify any damage of
the unit on the delivery note, and send a
registered letter of protest to the last carrier
of the goods within 72 hours of delivery.
Notify the dealer at the same time.
The unit should be totally inspected within
7 days of delivery. If any concealed dam-
age is discovered, send a registered letter
of protest to the carrier within 7 days of
delivery and notify the dealer.
CAUTION:!
Cautions are provided at appropriate pla-
cesinthismanualtoindicatetoinstallers,
operatorsandservicepersonnelofpoten-
tially hazardous situtions which, if not
avoided,MAY result in minor ormoderate
injuryormalfunctionoftheunit.
Warranty
Warranty is based on the general terms
and conditions by country. The warranty is
void if the equipment is modified or re-
paired without the written approval of The
Trane Company, if the operating limits are
exceeded or if the control system or the
electrical wiring is modified.
Damage due to inappropriate installation,
lack of knowlegde or failure to comply with
the manufacturer’s instructions, is not
covered by the warranty obligation. If the
installtion does not conform to the rules
described in Installtion Manual, it may
entail cacellation of warranty and liabilities
by The Trane Company.
Important
This document is customer property and
is to remain with unit. Please place in
service information pack upon completion
of work.
These instructions do not cover all varia-
tions in systems, nor do they provide for
every possible contingency to be met in
connection with installation.
Should further information be desired or
should particular problems arise which
are not covered sufficiently in this manual,
the matter should be referred to your au-
thorized Trane dealer.
WARNING!!
Warningsareprovidedatappropriatepla-
cesinthismanualtoindicatetoinstallers,
operatorsandservicepersonnelofpoten-
tiallly hazardous situations which, if not
avoided,COULDresultindeathorserious
injury.

SS-SVN03B-EN 3
Contents
Model Description 4
General Data 5
General
Unit Location and Preparation
Line Connection 6
Refrigerant Line Connection
Connection using Flange Thread-Type Valve
System Evacuation 7
System Evacuation and Purge
Service Valve 8
Multi-Function - Liquid Line
Electric Connections 9
Electric Connection
System Start-Up 10
System checking before start-up
Dimensional Data 11
TTK 509E / TTK 512E
TTK 518E / TTK 524E / TTK 530E / TTK 536E
Typical Wiring Diagram 13
Wiring Interconnection 14

4SS-SVN03B-EN
Model
Number
1 2 3 4 5 6 7 8 9 10 11
T T K 5 0 9 E 5 U A 0
Digit 11 - Product Service Change
0 First Version
Digit 10 - Optional
A with Multi-Function Service Valve and Orifice Kit
Digit 9 - Agency Listing
U UL, ETL and ARI Standards
L IRAM Standard
Digit 8 - Electric Power Supply Characteristics
5 1 Phase - 60 Hz - 208/230 VAC
B 1 Phase - 50 Hz - 208/230 VAC
Digit 7 - Development Sequence
E Sequence (Brazil)
Digits 5,6 - Nominal Capacity Class (BTU/H)
09 9,000 BTU/h
12 12,000 BTU/h
18 18,000 BTU/h
24 24,000 BTU/h
30 30,000 BTU/h
36 36,000 BTU/h
Digit 4 - Refrigerant and Connection Types
5 Refrigerant R-22 / Service Valve
Digit 3 - Quantity of Refrigerating Circuits
K 1 Refrigerating Circuit
Digit 2 - Functional Type
T Cooling Only
W Heat Pump
Digit 1 - Brand Name
T Trane Mini-split

SS-SVN03B-EN 5
General
Data
General
This “Installation Manual” describes
information for condensing units TTK
509 to TTK 536, with horizontal air
discharge, cooling-only, from 9,000 to
36,000 Btu/h.
After unpacking the unit, inspect the
unit for any damage incurred in transit.
Immediately notify the carrier.
Compare the power supply
characteristics with the unit nameplate
data. The power supply must comply
with the unit nameplate data.
All stages of this installation should
comply with local, state and national
codes.
These installation instructions should
be carefully read prior to the air
conditioning system installation.
These instructions are not intended for
all system variations, nor advise
against all situations that may occur
during an installation. If more
information is required, or problems
that avoid client satisfaction arise,
contact your nearest Trane sales office
or Trane.
Unit Location and Preparation
1. The unit should be installed on a
leveled and reinforced concrete
foundation. The minimum height of
the concrete foundation should be
50 mm (1.97”). Unit shall be fixed to
the foundation with bolts (not
supplied).
2. The concrete foundation must be
positioned at least 250 mm (9.84”)
away from any existing wall or
shrubbery.
3. The minimum clearance on the air
inlet sides of the unit should be
250 mm (9.84”), and on the air
discharge side, 1200 mm (47.24”).
4. When the unit is mounted on a roof,
be sure the roof will support the unit
weight. Proper vibration isolation is
recommended in order to prevent
transmissions to the building
structure.
5. Minimum clearances between the
unit and other objects should be
observed in order to assure proper
ventilation.
WARNING!!
Figure 01 - Recommended installation clearances
Rear
Side
Side
Front
Recommended installation and maintenance clearances
Obstacle (wall)
Distance for air inlet
250 mm (9.84”) (minimum)
Obstacle (wall)
Distance for air inlet
250 mm (9.84”) (minimum)
Obstacle (wall)
Distance for maintenance
300 mm (11.81”) (minimum)
Obstacle (wall)
Distance for air discharge
1200 mm (47.24”) (minimum)
600 mm (23.62”) (minimum)
Note: All dimensions are in mm( inches)

6SS-SVN03B-EN
Line
Connections
Refrigerant Line Connections
Flange thread-type connection:
1. Thread-type connections for series
TTK-5
Do not open liquid or gas line valves
until tube installation and system
evacuation are finished.
Table 01 - Torque
Connection of refrigerant
lines to unit using flange
thread-type service valves
1. Using a tube cutter, cut the
refrigerant tube and remove burrs,
inside and outside (be very carefull
to avoid that burrs fall into the tube).
2. Insulate both refrigerant lines.
3. Remove the service valve falnged
nut and place it in the tube.
WARNING!!
Liquid line
Suction line
TTK 518E/ 524E / 530E / 536E
TTK 509E/512E
Figure 02 - System detail
Service
access
Register cap Line connection
(Flange)
Suction line
Liquid line
4. Make the flange of the tube as
perfect as possible.
5. Apply refrigerant oil on coupling
surfaces of the union of the valve
with the flanged tube end before
coupling them.
6. Align the union center formed by the
tube and the valve, lightly screwing
the nut with the hand, by 3 to 5 turns.
7. Tighten the nut according to the
torque table in the next page .
8. Repeat the previous procedure for
other connections.
mm in. kgfxcm lbsxin.
6,35 1/4" 150-200 130-170
9,52 3/8" 350-400 300-340
12,7 1/2" 500-550 430-470
15,88 5/8" 600-650 520-570
19,05 3/4" 700-750 610-650
Piping Diam. Torque

SS-SVN03B-EN 7
System Evacuation and Purge
1. The outdoor unit is supplied with
refrigerant pre-loaded in factory . The
load indicated on the nameplate is
the total amount required by a system
with a refrigerant line lenght of up to
7.5 meters (295.3”). Considering that
the outdoor unit does not require
evacuation, except in cases of
refrigerant leakage, the suction and
liquid valves should remain closed.
2. After installation is finished, apply
vacuum in refrigerant lines and indoor
unit.
3. The system should be evacuated until
the vacuum gauge shows a reading
of 350 microns (5.9 x 10-2 inHg).
4. Close the vacuum pump valve, and
observe the vacuum gauge. If the
reading is more than 500 microns
(8.3 x 10-2 inHg) in an interval of one
minute, the evacuation is not
complete, or there is a system
leakage.
5. If the vaccum gauge does not pass
500 microns (8.3 x 10-2 inHg) within
the interval of one minute, the vaccum
is finished.
6. With the vacuum pump off and the
manifold closed, open the service
valves in the liquid and suction lines.
System
Evacuation
7. Replace the register and valve caps
to prevent leakages.
Table 02 - Additional refrigerant load
The refrigerant load will have to be
completed when the distance between
internal and external units is more than
7.5 meters (295.3”). Use table 2 for
recommended additional loads.
Obturator
Cap
Service
Valve
Flange Nut
Thread
Threaded
Cap
Service hose for
Schrader-type valve
Outdoor
Unit
Suction
Pressure
Liquid
Pressure
Electronic
Vacuum
Gauge
Vacuum
Pump
Suction Line
Liquid
Line
Electric
Connection
Figure 03 - Service Valve Figure 04 - Evacuation System
Obs: Notice that the position of suction and liquid lines is different for some models, refer to page 06 - fig. 02
Tubing Sizes
Liquid - Suction
1/4" - 1/2" 26 g/m
17.5x10
-3
lbs/ft
1/4" - 5/8" 30 g/m
20.2x10
-3
lbs/ft
3/8" - 5/8" 59 g/m
39.6x10
-3
lbs/ft
3/8" - 3/4" 60 g/m
40.3x10
-3
lbs/ft
3/8" - 7/8" 62 g/m
41.7x10
-3
lbs/ft
3/8" - 1 1/8" 68
g
/m
45.7x10
-3
lbs/ft
Additional Load

8SS-SVN03B-EN
Field Installation of the Re-
strictor for Multi-Function
Service Valve (Liquid Line)
Condensing units TTK, are supplied
with a multi-function service valve for
liquid line and a restrictor kit. The use
of the restrictor allows the refrigerant
expansion in installations where the
indoor unit does not have its own ex-
pansion device. The machine is
supplied with a passage orifice in-
stalled at the muti-function valve,
making it adequate for use in conjunc-
tion with indoor units that already have
their own expansion device. For use
with indoor units that does not have
an expansion device, it is necessary
to replace this passage orifice with
one of the restrictor supplied with the
machine.
Step 1. Check in the table below the
restrictor orifice code to be used, ac-
cording to the indoor unit model. The
code is marked on the restrictor body.
Step 2. Isolate the refrigerant circuit,
closing the multi-function service valve
(if the valve is open). Remove the obtu-
rator cover with a 23 mm ( 0.91”)
wrench or other appropriate wrench.
Insert a 5 mm (0.20”) Allen wrench in
the obturator and turn it clockwise until
some resistance is felt. Remove the
flanged nut and the copper cover.
Step 3. Carefully remove passage ori-
fice installed in factory, being careful
not to damage the flare nut thread and
sealing surface between the orifice and
the flare nut.
Step 4. The new restrictor should be
appropriately lubricated and have an o-
ring on the perimeter. The orifice and
the o-ring should be encapsulated in
the valve body seat, and, for that, a
small "crack" should be heard in order
to assure that the orifice was properly
installed. The assembly of these parts
is shown in the figure below:
Step 5. The liquid line tube should be
flanged and burr-free. Clean the tube to
avoid the introduction of dirt or other
strange materials in the refrigerating
circuit and possible damages in the
tube flange while the flanged nut is
tightened.
Step 6. Manually install the flare nut on
the liquid line tube and be sure to apply
the correct torque. Continue the manu-
al assembly on the valve body until a
screwing resistance is felt (metal with
metal). Then, tighten the nut using a
7/8" wrench or other adapted wrench,
according to the flare nut dimensions.
Step 7. Open the valve, turning it coun-
terclockwise (04 turns, or a resistance
is felt), using a 5 mm (0.20”) Allen
wrench.
Step 8. Replace the obturator cover,
manually turning it clockwise by approx.
half-turn.
Multi-Function Service Valve for Liquid Line
Service Valve
Multi-Function (Liquid Line)
TTK509E 034 034
TTK512E 040 040
TTK518E 047 047
TTK524E 055 055
TTK530E 063 063
TTK536E 067 067
MODEL ORIFICE
MCW ORIFICE MCX & MCD
Figure 05 - Multi-Function Service Valve
ATTENTION!!
There are indoor units that have
device valves, have been not
necessarytousetherestrictors.
Flare Nut
Restrictor or Flare
Adapter
Valve Stem Cover

SS-SVN03B-EN 9
Electric Connections
1. Important: do not allow electric
wires from the compressor casing
to touch refrigerant tubes or the
compressor.
2. Equipment electric installation and
grounding should be made
according to IEC 335-2-40: 2002
and local codes and/or NEC.
3. The power supply should comply
with the specification in the
equipment nameplate.
4. Install an exclusive overcurrent
protection circuit-breaker for the
outdoor unit. It can also be used for
system protection.
5. Use flexible electric conduits in
cases where vibrations can
introduce noises inside the
structure.
6. Appropriate color electric wires
should be used, for command, to
allow easier connections between
indoor and outdoor units.
Electric
Connections
Figure 06 - Electric connection detail
Terminal
block
Covering
Cable input

10 SS-SVN03B-EN
System checking before
start-up
1. Make sure that field connections
comply with electric and refrigerant
diagrams for the equipment.
Always refer to Installation and
User Manuals and Engineering or
Service Bulletins provided with the
indoorunits.
2. Check that units are correctly
installed and there is no tool or
debris under or on the units.
3. Check piping and connections for
refrigerant leaks.
4. Check that the unit has a proper
grounding. If there is no grounding at
the site, it is essential to follow
completely this procedure in order to
assure a perfect equipment
operation.
CheckingListforMini-SplitUnitStart-Up
•Verify correctrefrigerant and electric connections
• Check for strange materials or tools under or on the equipment
• Check for possible leaks at connections
• Check that lines are well isolated
• Check that passages through piping structure are well insulated
• Check that water drains are free
•Insufflation and return grids are free and unobstructed
• Air filters are installed and clean
• Use an inpected thermometer to check if the thermostat is accurate
•Check grounding
•Check forpower voltage,fuse/circuit-breaker ratingsin amperes
• Check that wire sizes are adequate for the power load
• Check all field wiring for tight connection
• Check that electric wires do not touch refrigerant pipes
•Check if remote control batteries are charged
5. Check that voltage is within
specified ratings, and check for
proper circuit-breaker/fuse sizes.
6. Check that electrical wiring is as
specified and connections are tight.
Start the system and carefully
observe the operation. Follow all
recommendations in Installation and
User Manuals.
System
Start-Up
