Trane X13511538-01 Owner's manual

Trane™ Touch-screen Programmable Thermostat
July 2011 BAS-SVX44A-EN
Installation and Operation
Trane Part Number: X13511538-01
Clarksville Part Number: BAYSTAT152A
Service Part Number: THT02775
SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing
of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and
training. Improperly installed, adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the literature and on the tags,
stickers, and labels that are attached to the equipment.

2 BAS-SVX44A-EN
Copyright
© 2011 Trane. All rights reserved.
This document and the information in it are the property of Trane and may not be used
or reproduced in whole or in part, without the written permission of Trane. Trane reserves
the right to revise this publication at any time and to make changes to its content without
obligation to notify any person of such revision or change.
Trademarks
Trane and its logo are trademarks of Trane in the United States and other countries. All
trademarks referenced in this document are the trademarks of their respective owners.
Warnings, Cautions, and Notices
Warnings, cautions, and notices are provided in appropriate places throughout this
document:
WARNING: Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury. It could also be used to alert against
unsafe practices.
NOTICE:Indicates a situation that could result in equipment or property-
damage-only accidents.

Table of Contents
BAS-SVX44A-EN 3
Overview .............................................................. 5
Packaged Contents and Tools ............................................ 5
Packaged Contents ................................................. 5
Tools ............................................................. 5
Specifications and Dimensions .......................................... 6
Product Features and Functions .......................................... 7
Features .......................................................... 7
Functions ......................................................... 7
Pre-Installation ......................................................... 8
Location Considerations ............................................ 8
Height Requirements ............................................... 8
Mounting Surfaces ................................................. 8
Maximum Wire Length ............................................. 9
Installation and Wiring ................................................. 10
Mounting the Thermostat and Cover Removal ........................ 10
Mounting the Backplate ....................................... 10
Wiring and Wiring Diagrams ....................................... 12
Wiring ...................................................... 12
Terminal Identification ........................................ 13
Wiring Diagrams ............................................. 13
Thermostat Cover Replacement ..................................... 18
Power, System Tests, and Software Reset ............................... 19
Applying Power ................................................... 19
Power-up Test .................................................... 19
System Tests ..................................................... 20
Software Reset ................................................... 22
Configuration Option Setup ............................................ 23
Installation Options ............................................... 24
Operation ............................................................. 27
Thermostat Icon Descriptions ....................................... 27
Functions ............................................................. 28
Time Setup ...................................................... 28
Dehumidify Setup ................................................ 28
System Mode Setup .............................................. 29
Fan Mode ....................................................... 29

4 BAS-SVX44A-EN
Temporary Override (TOV) Setup ................................... 30
General Notes: ............................................... 30
Schedule Setup ................................................... 31
Schedule Display Mode ....................................... 31
Day/Period/Time Schedule Change Mode ........................ 32
Setpoint/Fan Schedule Change Mode ........................... 33
General Notes for All Schedule Modes ........................... 34
Other Thermostat Functions ............................................ 36
Heat/Cool Indicator Display ......................................... 36
Non-programmable Mode ......................................... 37
Filter Change ..................................................... 38
Clean Screen ..................................................... 38
Local/Remote/Outdoor Temperature Display and Control .............. 39
Local/Remote Humidity Display and Control .......................... 40
System Lockout ................................................... 41
To lock the thermostat: ........................................ 41
To unlock the thermostat: ...................................... 41
Temperature Cycle Control ............................................. 42
Other Functional Components .......................................... 44
Sleep Mode ...................................................... 44
Changeover Operation ............................................. 44
Changeover Valve Control ......................................... 44
Extension of Fan-on Time .......................................... 45
Economizer/Time of Day (TOD) ..................................... 45
Configuration, Time, and Programming Retention ..................... 45
Heat/Cool Relay Confirmation ...................................... 45
Deadband ........................................................ 45
Temperature Display Offset ........................................ 46
Humidity Display Offset ............................................ 46
LCD Backlight .................................................... 46
Compressor Protection ............................................ 46
Permanent Memory Data .......................................... 46
Compressor and Auxiliary Heat Lockout ............................. 47
Error Codes and Exceptions ............................................ 48
Error Codes ...................................................... 48
Exceptions ....................................................... 49
Troubleshooting ....................................................... 50

BAS-SVX44A-EN 5
Overview
The Trane™ Touch-screen Programmable Thermostat is for use with conventional Rooftop Units
(RTU) air conditioners and heat pumps. These units are compact, easy to install, configure, and
operate.
This installation and operation manual provides information about the following:
• Specifications and dimensions
• Product features and functions
• Pre-installation requirements
• Installation and wiring
• Power, system tests, and software reset
• Configuration option setup
• Other thermostat functions
• Temperature cycle control
• Other functional components
• Error codes and exceptions
• Troubleshooting
Note: Before beginning installation, visually inspect all parts for obvious defects for damage. All
components are thoroughly inspected before leaving the factory. Any claims for damage
incurred in shipping should be filed immediately with the carrier.
Packaged Contents and Tools
Packaged Contents
Each programmable thermostat ships with the following:
• One (1) Trane Touch-screen Programmable Thermostat
• One (1) Installation/Configuration Instructions (X39641190-01)
• One (1) Setup/Programming Instructions (X39641189-01)
• One (1) bag of:
-Two (2) machine screws
-Two (2) wood screws
-One (1) security screw
-Two (2) wall anchors
-Two (2) terminal blocks; an 8-pin and a 6-pin
Tools
• One (1) 1/8 inch, flat-bladed service screwdriver
• One (1) small Phillips screwdriver
• Level
• Drill
• Hammer
• Wire cutter/stripper

6 BAS-SVX44A-EN
Specifications and Dimensions
Specifications and Dimensions
The following table and illustration provides the thermostat specifications and dimensions.
Table 1. Specifications and dimensions
Storage
Temperature: –4°F to 158°F (–20°C to 70°C)
Relative Humidity: Between 5% and 95% (noncondensing)
Operating
Temperature: 32°F to 122°F (0°C to 50°C)
Humidity: Between 5% and 95% (noncondensing)
Input Power: 24 Vac (minimum 18 Vac/maximum 32 Vac), 50Hz to 60Hz
Note: Frequency is selected using Configuration Option #0190.
Power Consumption: <2 Watts @24 Vac RMS nominal
Wire Size: 18 to 22 AWG
Output Terminal Rating: 1A @ 30 Vac
Temperature Accuracy: ±1.4°F (0.8°C) from 50°F to 90°F (10°C to 32.2°C)
Temperature Resolution: Configurable @1°F, 0.5°F, 1°C, 0.5C, 0.1°C
Humidity Accuracy: ±3% RH from 20% to 80% RH
Humidity Resolution: 1%
Housing Material:
• Polycarbonate/ABS Blend
• UV protected
• U.L. 94-5VA flammability rating
Mounting: 3.24 in (8.26 cm) for two mounting screws (supplied)
Dimensions
5.90 in
(150 mm)
1.30 in
(33 mm)
0.3 in
(8 mm)
4.65 in
(118 mm)

BAS-SVX44A-EN 7
Product Features and Functions
The following is a list of features and functions of the programmable thermostat.
Features
Liquid Crystal Display (LCD) Touch Screen: with symbols for temperature, setpoints, and system
operating modes. In addition, the thermostat has settings for the day of the week, time of day, and
occupancy.
• System Modes:
-Heat
-Cool
-Auto
-Off
-Emergency heat
• Fan Modes:
-On
-Auto
• System Configurations:
-1 heat/1 cool conventional
-1 heat/1 cool heat pump
-1 heat conventional (with and without fan)
-1 cool conventional
-2 heat/1 cool heat pump
-2 heat/2 cool conventional
-2 heat/1 cool conventional
-1 heat/2 cool conventional
-2 heat/2 cool heat pump
-3 heat/2 cool heat pump
• Time and Dehumidify Settings
• Temporary Override (TOV)
• Scheduling:
-All days: (Mo, Tu, We, Th, Fr, Sa, Su)
-Five (5) days, plus one day, plus one day: (Mo, Tu, We, Th, Fr), (Sa),(Su)
-Five (5) days, plus two days,: (Mo, Tu, We, Th, Fr,) (Sa, Su)
-Seven (7) individual days [default]: (Mo) (Tu) (We) (Th) (Fr) (Sa) (Su)
• Temperature Cycling Control (Patent Pending):
-Integrated adjustable deadband staging
-Configurable cycles per hour (CPH) heat/cool cycles
Functions
The touch-screen programmable thermostat provides additional functions that provide more
flexibility and control. Refer to the sections, “Other Thermostat Functions,” p. 36 and “Other
Functional Components,” p. 44.

8 BAS-SVX44A-EN
Pre-Installation
Pre-Installation
This section provides the following pre-installation information:
• Location considerations
• Height requirements
• Mounting surfaces
• Maximum wire length
Location Considerations
When selecting a location, avoid the following areas when installing the thermostat:
• Direct sunlight
• Direct airstream of air diffusers
• Exterior walls and other walls that have a temperature differential between the two sides
• Close proximity to heat sources such as sunlight, appliances, concealed pipes, chimneys, or
other heat-generating equipment
• Drafty regions
• Dead spots behind doors, projection screens, or corners
• Walls subject to high vibration
• High humidity regions
• High traffic areas (to reduce accidental damage or tampering)
Height Requirements
It is recommended to mount the thermostat a maximum distance of 54 inches (137 cm) above the
floor. If a parallel approach by a person in a wheelchair is required, reduce the maximum height
to 48 inches.
Note: For further details regarding wheelchair requirements, refer to ADA Standards for
Accessible Design/4.27 Controls and Operating Mechanisms/4.27.3 Height online at
www.ADA.gov and to local building codes.
Mounting Surfaces
The thermostat can be mounted to any sturdy, vertical surface. Plastic-threaded anchors and M3.5
x 20 mm screws are provided for mounting to plaster or wallboard; 6-32 x 3/4 inch machine screws
are provided for mounting directly to a standard electrical device box. For other surface types, the
user must provide fasteners that are appropriate for the surface.

BAS-SVX44A-EN 9
Pre-Installation
Maximum Wire Length
The thermostat may not function properly if the total resistance of any of the thermostat wires
exceeds 2.5 ohms (refer to Table 2).
Important: Ensure that the wires from the thermostat to the HVAC equipment do not exceed
lengths shown in Table 2.Best practice: use shorter wire lengths.
18 AWG (0.75 mm2) 385 ft (117 m) 2,500 ft (762 m) 385 ft (117 m)
20 AWG (0.50 mm2) 240 ft (73 m) 1,500 ft (457 m) 240 ft (73 m)
22 AWG (0.33 mm2) 150 ft (46 m) 1,000 ft (305 m) 150 ft (46 m)
Table 2. Maximum wire lengths
Copper Wire size
Maximum Recommended Wire
Length From Thermostat to HVAC
Equipment
Remote
Temperature Sensor
to Thermostat
(Max(a))
Remote Humidity Sensor to
Thermostat (Max(a))
(a) Temperature and humidity readings can be adjusted in the configuration setup for longer wire runs.

10 BAS-SVX44A-EN
Installation and Wiring
This section provides information about the following:
• Mounting the thermostat and cover removal
• Wiring and wiring diagrams
• Thermostat cover replacement
Mounting the Thermostat and Cover Removal
Before beginning installation, it is recommended to re-read the section, “Pre-Installation,” p. 8 and
then ensure that the following conditions are met:
• A wire access hole is available at the thermostat location
• The wires are accessible through the hole
• The wires are attached to the appropriate terminals on the HVAC equipment
• There is continuity (and not more than 2.5 ohms resistance) between the thermostat location
and the HVAC equipment
• The wires are accurately labeled or color coded
Mounting the Backplate
WARNING
Hazardous voltage!
Disconnect all electric power, including remote disconnects before servicing. Follow proper
lockout/tagout procedures to ensure the power cannot be inadvertently energized. Failure to
disconnect power before servicing could result in death or serious injury.
NOTICE
Equipment damage!
Applying excessive voltage to the thermostat can permanently damage it.
To mount the backplate:
1. Shut off the power to all HVAC equipment. If the security screw was previously installed,
remove it (refer to Figure 1, p. 11).
