Trane Axiom GEHB 006 Installation and operating instructions

15 - 25 Ton
1/2 - 5 Ton
6 - 15 Ton
6 - 10 Ton
Installation,
Operation and
Maintenance
March 2007 WSHP-SVX01E-EN
GEHB GEVB: Design Sequence
006 - 060 – 50/60 HZ 006 - 060 – 50/60 Hz "R" and later
072 - 180 – 50/60 Hz 072 - 300 – 50/60 Hz "D" and later
Axiom™
Horizontal/Vertical
Water-Source Comfort System
Models GEH and GEV

Preface and Warnings and Cautions
© 2007 American Standard All rights reserved WSHP-SVX01E-EN
Overview of Manual
Note: One copy of this document
ships inside the control panel
of each unit and is customer
property. It must be retained
by the unit’s maintenance
personnel.
This booklet describes proper
installation, operation, and
maintenance procedures for air
cooled systems. By carefully
reviewing the information within this
manual and following the
instructions, the risk of improper
operation and/or component damage
will be minimized.
Service and maintenance work
should be performed by a qualified
technician” and all electrical service
and maintenance work should be
performed by a qualified licensed
electrician.
Hazard Identification
Warnings and Cautions appear at
appropriate sections throughout this
manual. Read these carefully.
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury. It
may also be used to alert against
unsafe practices.
CAUTION
Indicates a situation that may result
in equipment or property-damage-
only accidents.
Model Number Description
All products are identified by a
multiple-character model number
that precisely identifies a particular
type of unit. Its use will enable the
owner/operator, installing
contractors, and service engineers to
define the operation, specific
components, and other options for
any specific unit.
When ordering replacement parts or
requesting service, be sure to refer to
the specific model number and serial
number printed on the unit
nameplate.
Inspection
Unpack all components of the kit.
Check carefully for any shipping
damage. If any damage is found it
must be reported immediately and a
claim made against the
transportation company.
Visually inspect the components for
shipping damage as soon as possible
after delivery, before it is stored.
Concealed damage must be reported
within 15 days.
If concealed damage is discovered,
stop unpacking the shipment.
Do not remove damaged material
from the receiving location. Take
photos of the damage, if possible.
The owner must provide reasonable
evidence that the damage did not
occur after delivery.
Notify the carrier’s terminal of
damage immediately by phone and
by mail. Request an immediate joint
inspection of the damage by the
carrier and the consignee.
Note: Do not attempt to repair any
damaged parts until the parts
are inspected by the carrier’s
representative.
Overview
Your unit is designed to comfort
condition all year long with safe,
efficient, trouble-free operation. It is
important that you understand how
to operate and maintain your unit to
keep it operating safely and
efficiently. This manual will acquaint
you with these important procedures.
Familiarize yourself with this manual
and store it in a convenient location
for future reference.
Important!
Equipment is shipped FOB (Free on
Board) at the manufacturer.
Therefore, freight claims for
damages against the carrier must be
initiated by the receiver.
Unit contains HCFC (R-22) Refrigerant
Instructions!
Section 608, Paragraph C of the 1990
Clean Air Act states:
Effective July 1, 1992, it shall be
unlawful for any person, in course of
maintaining, servicing, repairing, or
disposing of an air conditioning
system, to knowingly vent or release
any CFC or HCFC refrigerant. Minimal
releases (air purges or refrigerant
hoses) associated with good faith
attempts to recapture or recycle are
exempt from the ban on venting.

WSHP-SVX01E-EN 3
Overview of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Hazard Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Model Number Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Jobsite Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Jobsite Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unit Nameplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Compressor Nameplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unit Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Air-to-Refrigerant Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Water-to-Refrigerant Coil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
System Input Devices and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Basic 24V Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Deluxe 24V Controls (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Tracer ZN510 or ZN524 Controls (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Waterside Economizer (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Boilerless Control/Electric Heat (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Supplemental or Boilerless Electric Heat (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Hot Gas Reheat (option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Weight Distribution for Hanging the GEH Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
GEH Clearance Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
GEV 1/2 through 5 Ton Clearance Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
GEV 6 through 10 Ton Clearance Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
GEV 12 1/2 through 25 Ton Clearance Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 10
General Installation Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Supply-Air Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Return-Air Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Dual Filtration (GEH 1/2 to 5 ton) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Return-Air Duct Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Sound Attenuation Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Hanging the Horizontal Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Condensate Drain Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Supply/Return Pipe Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Types of Hose Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Cleaning and Flushing the Water Loop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Connecting a Water Regulating Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Installation for Single Compressor Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Installation for Multiple Compressor Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Field Installed Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Main Unit Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Table of Contents

4WSHP-SVX01E-EN
Table of Contents
Control Power Transformer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Thermostat Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Controls Using 24 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Controls Using 24 VAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Deluxe Board Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Blower Motor Speed-Tap Retrofit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Air Flow Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Waterside Economizer Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Waterside Economizer Installation for GEV and GEH 6 to 25 Ton Models . . . . . . 61
Start-up Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Economizer Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Pre-Start Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Pre-Start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Initial Unit Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Start-Up Checklist and Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Sequence of Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Operating Pressures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Operation Pressures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Water Pressure Drop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Condensate Trap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Standard Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Extended Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

WSHP-SVX01E-EN 5
WARNING
Fiberglass Wool!
Product contains fiberglass wool.
Disturbing the insulation in this
product during installation,
maintenance or repair will expose
you to airborne particles of glass
wool fibers and ceramic fibers
known to the state of California to
cause cancer through inhalation.
Glass wool fibers may also cause
respiratory, skin or eye irritation.
Jobsite Inspection
Always perform the following checks
before accepting a unit:
Verify that the nameplate data
matches the data on the sales order
and bill of lading (including electrical
data).
Verify that the power supply
complies with the unit nameplate
specifications.
Visually inspect the exterior of the
unit, for signs of shipping damage.
Do not sign the bill of lading
accepting the unit(s) until inspection
has been completed. Check for
damage promptly after the unit(s)
are unloaded. Once the bill of lading
is signed at the jobsite, the unit(s)
are now the property of the SOLD TO
party and future freight claims MAY
NOT be accepted by the freight
company.
Verify that the refrigerant charge has
been retained during shipment by
use of gauges. Schrader taps are
located internal to the cabinet.
After assuring that charge has been
retained, reinstall the schrader caps
to assure that refrigerant leakage
does not occur.
WARNING
Microbial Growth!
Wet interior unit insulation can
become an amplification site for
microbial growth (mold), which may
cause odors and serious health
related indoor air quality problems.
If there is evidence of microbial
growth (mold) on the interior
insulation, remove or replace the
insulation prior to operating the
system. Failure to remove microbial
growth could result in serious health
problems.
Jobsite Storage
This unit is intended for indoor use
only. To protect the unit from
damage due to the elements, and to
prevent possible IAQ contaminant
sources from growing, the unit
should be stored indoors. If indoor
storage is not possible, the following
provisions for outdoor storage must
be met:
Place the unit(s) on a dry surface or
raise above the ground to assure
adequate air circulation beneath the
unit.
Cover the unit(s) with a water proof
tarp to protect them from the
elements.
Make provisions for continuous
venting of the covered units to
prevent moisture from standing on
the unit(s) surfaces. Wet interior unit
insulation can become an
amplification site for microbial
growth (mold) which has been
determined to be a cause of odors
and serious health related indoor air
quality problems.
Store units in the normal UP
orientation to maintain oil in the
compressor.
Horizontal units may be stacked no
more than three units high. Do not
stack the vertical unit configurations.
Unit Nameplate
The unit nameplate is located on the
outside of the control box access
panel at the front of the unit. It
includes the unit model number,
serial number, electrical
characteristics, refrigerant charge,
and other pertinent unit data.
Compressor Nameplate
The nameplate for the compressors
are located on the compressor shell.
Unit Description
Before shipment, each unit is leak
tested, dehydrated, charged with
refrigerant and run tested for proper
control operation.
Air-to-Refrigerant Coil
The air-to-refrigerant coil is
aluminum fin, mechanically bonded
to the copper tubing.
Water-to-Refrigerant Coil
The water-to-refrigerant coil is a
copper or cupro-nickel (option) and
steel tube (tube-within-a-tube)
design, leak tested to assure there is
no cross leakage between the water
tube (copper/cupro-nickel) and
refrigerant gas (steel tube).
Controls
The control system offered to control
the unit is a Basic 24 Volt control for
the 1/2 through 5 ton sizes, a Deluxe
24 Volt control option for all unit
sizes, a Tracer™ ZN510, LonTalk™
certified control option for the 1/2
through 5 ton unit sizes, or a Tracer
ZN524, LonTalk certified control
option for all unit sizes.
All power wiring to the equipment is
made at the unit contactor for the 1/2
through 5 ton, and at the high
voltage terminal block for the 6
through 25 ton. All low voltage
wiring is made at the unit’s low
voltage terminal board.
System Input Devices and
Functions
A thermostat, zone sensor or
building automation system is
required to operate the water-source
heat pump. The flexibility of having
several mode capabilities depends
upon the type of sensor and/or
remote panel selected.
General Information

6WSHP-SVX01E-EN
General Information
Troubleshooting and connection
diagrams for the 24 Volt control
systems may be located in the back
of this manual. All digital control
troubleshooting tips and connection
diagrams are located in WSHP-IOP-2
(ZN510) or WSHP-PRB002-EN
(ZN524).
Basic 24V Controls
Safety devices for equipment
containing the basic 24V control
option include a low pressure switch
or suction line temperature sensor to
prevent compressor operation during
low temperature activity. The switch
or sensor is set to activate at
refrigerant pressures of 20 psig (1/2
to 5 ton units) or 7 psig (6 to 25 ton
units) to fit most applications.
A high pressure switch prevents
compressor operation during high or
excessive discharge pressures
exceeding 395 psig.
The lockout relay communicates the
low or high pressure situation to the
compressor to prevent operation. For
units that contain a condensate
overflow switch option, a condensate
overflow situation will also be
communicated to the compressor
through the lockout relay if an
overflow condition exists. The relay
may be reset at the thermostat, or by
cycling power to the unit.
General alarm is accomplished
through the lockout relay and is used
in driving light emitting diodes
(LEDs). This feature will drive dry
contacts only, and cannot be used to
drive field installed control inputs.
Trane recommends 3 minute or
greater minimum off time for
compressor control.
Deluxe 24V Controls (option)
Units containing the Deluxe 24V
control design will incorporate a
microprocessor-based control board.
The Trane microprocessor board is
factory wired to a terminal strip to
provide all necessary terminals for
field connection. The deluxe board is
equipped with a random start relay,
anti-short cycle timer, brown out
protection, compressor disable,
condensate overflow, unit safety
control, diagnostics and a generic
relay (which may be available for
field use). SeeTa b l e 3 4 for diagnostic
information and Figure 62 and
Figure 63 for thermostat connections.
Trane recommends 3 minute or
greater minimum off time for
compressor control.
Tracer ZN510 or ZN524
Controls (option)
The digital ZN510 and ZN524
controller is designed to support the
1/2 through 25 ton water-source heat
pumps in either a standalone, peer-
to-peer with a Tracer Loop Controller,
or as a full building automation
(open protocol) system. The 1/2
through 5 ton units that incorporate
direct digital controls will typically
come equipped with the ZN510
control board. The exception to this
would be if the equipment contained
hot gas reheat, waterside
economizer, or boilerless control with
electric heat. The ZN524 digital
control board is designed to interface
and run these mechanical options. All
units over 5 tons would ship with the
Tracer ZN524 control board.
For installation, operation and
diagnostics of the ZN510 and ZN524
WSHP-IOP-2 (ZN510) and/or WSHP-
PRB002-EN (ZN524).
Waterside Economizer
(option)
Instructions for mechanical
connection of the waterside
economizer to the water-source heat
pump may be found in the
dimensional section of this manual.
The waterside economizer is
designed to begin economizing
mode when water temperatures fall
below the field adjustable
temperature of 25, 35, 45, 55 or 65 F
(for the Deluxe control option), or
below the programmed set-point (for
the ZN524 control option).
When the temperature is less than
the setpoint, fluid will flow into the
economizing coil, while
simultaneously halting mechanical
operation of the compressor.
Mechanical cooling will continue on a
call for a second stage from the
thermostat or system control.
Boilerless Control/Electric
Heat (option)
Systems that do not contain a boiler
may contain a boilerless control with
electric heat. Trane offers both a
factory mounted electric heat option,
and a field mounted duct heater
option.
If the 1/2 through 5 ton GEH and GEV
unit incorporates the factory
mounted option, the unit will ship
from the factory with an internally
mounted nichrome open wire
heating element, designed to start-up
electric heat as the systems primary
heat in the event entering water
temperature falls below 55 F. Once
the entering water temperature rises
above 60 F, the boilerless controller
returns the unit to normal
compressor heating operation, and
locks out the electric heater.
If the unit contains a cooling only
heat pump design, the electric heat
contactor is wired directly to the
thermostat for primary heating, and
the compressor contactor for
cooling.
For units comprised of the field
installed duct heater option, the unit
will ship from the factory with
controls available to interface with
the field provided electric heat
selection.
Note: For geothermal applications,
the boilerless controller has
an adjustable setting of 25,
35, 45, 55 and 60 degrees.
Supplemental or Boilerless
Electric Heat (option)
The 6 through 25 ton models which
contain boilerless control electric
heat or supplemental electric heat
will contain the controls interface
ONLY for field provided electric heat
selection. The heater for this model
shall be external to the equipment by
the contractor for ease of installation.
All power connections for the electric

WSHP-SVX01E-EN 7
General Information
heater will be completely separate
from the unit for field supplied
electric heat.
Note: When the unit has boilerless
control, the electric heat is
not used as supplemental
electric heat, but as a primary
heat.
Hot Gas Reheat (option)
With the reheat option, the return-air
from the space is conditioned by the
air-to-refrigerant coil, then reheated
by the reheat coil to control not only
the space temperature, but to also
reduce the relative humidity of the
space. When operating in the reheat
mode (meaning the sensible
temperature has been met in the
space), the humidistat signals the
reheat relay coil to energize, allowing
the high pressure refrigerant gas to
flow from the compressor through
the reheat valve, into the reversing
valve, or reheat coil for
dehumidification.
A switching relay has been provided
for the reheat application to adjust
the blower motor from normal
operation to low speed when the hot
gas reheat is energized (for 1/2
through 5 ton equipment only).
Note: A high static blower motor is
required to support the hot
gas reheat option for the 1/2
through 5 ton equipment.
Note: Units containing the hot gas
reheat option should not be
used as a make-up air unit.
Note: Water regulating valves
should not be used with the
hot gas reheat option. Trane
places a thermal expansion
valve on all WSHPs as well as
GSHPs to regulate refrigerant
flow vs. water flow to the
unit.

8WSHP-SVX01E-EN
WARNING
Improper Unit Lift!
Test lift unit approximately 24 inches
to verify proper center of gravity lift
point. To avoid dropping of unit,
reposition lifting point if unit is not
level. Failure to properly lift unit
could result in death or serious
injury or possible equipment or
property-only damage.
Table 1. Unit weights
GEH
60 HZ GEH 50 HZ GEV 60 HZ GEV 50 HZ Shipping Weight with pallet Shipping Weight w/o pallet
006-015 006-012 188 lb (85 kg) 158 lb (71 kg)
018-030 015-024 278 lb (125 kg) 248 lb (112 kg)
036-042 030-036 318 lb (143 kg) 288 lb (130 kg)
048-060 042-060 428 lb (193 kg) 398 lb (179 kg)
072 - 701 lb (318 kg) 652 lb (296 kg)
090 072 714 lb (325 kg) 666 lb (303 kg)
120 090 831 lb (377 kg) 789 lb (359 kg)
150 120 907 lb (412 kg) 865 lb (393 kg)
180 150 999 lb (454 kg) 957 lb (435 kg)
006-015 006-012 178 lb (80 kg) 158 lb (71 kg)
018-030, 040 015-024 268 lb (121 kg) 248 lb (112 kg)
036, 042 030, 036 308 lb (139 kg) 288 lb (130 kg)
048, 060 042-060 396 lb (178 kg) 248 lb (112 kg)
Operating Weight
072 - 617 lb (280 kg) 577 (262 kg)
090 072 648 (294 kg) 608 (276 kg)
120 090 861 (391 kg) 821 (373 kg)
150 120 1215 lb (547 kg) 1170 lb (527 kg)
180 150 1225 lb (551 kg) 1180 lb (531 kg)
240 180 1615 lb (727 kg) 1580 lb (711 kg)
300 240 1665 lb (749 kg) 1640 lb (738 kg)
Table 2. Table 2: Waterside economizer
weight
GEV
60 HZ GEV 50 HZ Economizer Weight GEH 60 HZ GEH 50 HZ Economizer Weight GEH 60 HZ GEH 50 HZ Economizer Weight
072 - 148 lb (67 kg) 006-015 006-012 54 lb (24.5 kg) 072 - 138 lb (63 kg)
090 072 168 lb (76 kg) 018-030 015-024 65 lb (29.5 kg) 090 072 144 lb (65 kg)
120 090 207 lb (94 kg) 036-042 030-036 76 lb (35 kg) 120 090 166 lb (75 kg)
150, 180 120, 150 275 lb (125 kg) 048-060 042-060 97 lb (44 kg) 150 120 213 lb (97 kg)
240 180 310 lb (141 kg) 180 150 213 lb (97 kg)
300 240 395 lb (179 kg)
Weight Distribution for
Hanging the GEH Model
Approximate weight distribution for
proper hanging of the GEH unit is
indicated by the diagram to the right.
Tolerance on the weights determined
are ± 15%.
Total weights for each unit size are
listed above.
Figure 1. Weight distribution
1/2 through 5 - ton
Figure 2. Weight distribution
6 through 15 - ton
Weights

WSHP-SVX01E-EN 9
GEH Clearance
Dimensions
Access to the unit for service
purposes should be provided at
installation. All 1/2 through 5 ton
configurations require an 18" (457
mm) surround clearance from other
mechanical and electrical equipment
(where shown) to enable panel
removal from the unit for service/
maintenance ability. Some local
codes require a greater service
clearance than listed below. Check all
code requirements prior to unit
installations.
Equipment containing a same-side
supply/return combination requires
a 3" (229 mm) limitation on one side.
Access to the TXV may not be
possible with this 3" (229 mm)
clearance. This configuration is
typically applied in a corridor
installation, where space limitations
force the left or right side of the unit
against a wall.
Service clearance dimensions for the
6 through 15 ton horizontal includes
a two side access appropriate for
control and blower motor/wheel
access. Some local codes require a
greater service clearance than listed
below. Check all code requirements
prior to unit installations.
Figure 3. GEH 1/2 through 5 ton clearance
Figure 4. GEH 6 through 15 ton clearance
LEFT RETURN
BACK SUPPLY
UNIT FRONT
LEFT RETURN
RIGHT SUPPLY
LEFT RETURN
LEFT SUPPLY
UNIT FRONT UNIT FRONT
3"
(76)
18" (457)
(4-SIDES)
RIGHT RETURN
BACK SUPPLY
UNIT FRONT
RIGHT RETURN
LEFT SUPPLY
RIGHT RETURN
RIGHT SUPPLY
UNIT FRONT UNIT FRONT
3"
(76)
18" (457)
(4-SIDES)
18" (457)
(4-SIDES)
18" (457)
(4-SIDES)
18" (457)
(3-SIDES)
18" (457)
(3-SIDES)
TOP VIEW
36"
(914)
SERVICE
CLEARANCE
20"
(508)
SERVICE
CLEARANCE BLOWER ACCESS
PANEL
CONTROL BOX
Dimensions

10 WSHP-SVX01E-EN
Dimensions
GEV 1/2 through 5 Ton
Clearance Dimensions
Access to the unit for service
purposes should be provided at
installation. All configurations
require an 24" (610 mm) surround
clearance from other mechanical and
electrical equipment (where shown)
to enable panel removal from the
unit for service/maintenance ability.
Some local codes require a greater
service clearance than listed below.
Check all code requirements prior to
unit installations. Units in a free
return application will require more
than a 1" (25.4) clearance to provide
proper air flow to the units air-to-
refrigerant coil.
GEV 6 through 10 Ton
Clearance Dimensions
Minimum access for service
clearances are provided below. Any
one unit side other than the control
panel or return-air side may be
placed against a wall. The unit may
be serviced through the three
remaining open sides. Some local
codes require a greater service
clearance than listed below. Check all
code requirements prior to unit
installations.
GEV 12 1/2 through 25
Ton Clearance
Dimensions
The diagram below outlines the
minimum required unit service
clearances. Any one unit side other
than the control panel or return-air
side may be placed against a wall.
The unit may be serviced through the
three remaining open sides. Some
local codes require a greater service
clearance than listed below. Check all
code requirements prior to unit
installations.
Figure 5. GEV 1/2 through 5 ton clearance
Figure 6. GEH 6 through 15 ton clearance
Figure 7. GEV 12 1/2 through 25 ton clearance
1"
(25.4)
24"
(610)
1"
(25.4)
24"
(610) UNIT FRONT
RIGHT RETURN
TOP/BACK SUPPLY
1"
(25.4)
24"
(610)
1"
(25.4)
24"
(610)
UNIT FRONT
LEFT RETURN
TOP/BACK SUPPLY
ACCESS PANEL FOR
SHEAVES AND BELTS
20"
(508)
SERVICE
CLEARANCE
FRONT RETURN
TOP SUPPLY
36"
(914)
SERVICE
CLEARANCE
CONTROL BOX UNIT FRONT
NEC REQ.
MIN. 36" (914)
C.B.TO WALL
CLEARANCE
16" (406)TO
FILTER FRAME
FOR RETURN-AIR
18" (457)
MIN. SERVICE
CLEARANCE FOR
EITHER LEFT
OR RIGHT SIDE
IS 18" (457). FOR
FAN SHAFT REMOVAL,
A 22" (559) CLEARANCE
MUST BE PROVIDED
ON EITHERTHE
LEFT OR RIGHT SIDE.
FRONT RETURN-AIR
BACK SUPPLY-AIR

WSHP-SVX01E-EN 11
Dimensions
Figure 8. Left return, left supply
Table 3. Measurements
Unit A B C D E F G H J K L NPTI M NPTI N P Q R S
006,
009 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 8" (203) 11 1/2" (292) 4 1/4" (108) 2 1/8" (54) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
012,
015 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 9 7/8" (251) 11 1/2" (292) 4 1/4" (108) 2 5/8" (67) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
018 46"
(1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 9 3/4" (248) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
024,
030 46" (1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 11 3/8" (289) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
036,
042 50" (1270) 25" (635) 19" (483) 25" (635) 20" (508) 10 1/2" (267) 13 1/2" (343) 16 3/8" (416) 4" (102) 1 3/4" (45) 3/4" (19) 3/4" (19) 48 3/4" (1238) 23 3/4" (603) 17 5/8" (448) 23 1/2" (597) 3 1/4" (83)
048,
060 58" (1473) 33" (838) 21" (533) 25" (635) 28" (711) 13 7/8" (352) 13 7/8" (352) 18" (457) 6 5/8" (168) 2" (51) 1" (25.4) 1"
(25.4) 56 3/4" (1441) 31 3/4" (806) 19 5/8" (498) 23 1/2" (597) 5 1/2" (140)

12 WSHP-SVX01E-EN
Dimensions
Figure 9. Left return/back supply
Table 4. Measurements
Unit A B C D E F G H J K L NPTI M NPTI N P Q R S
006,
009 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 8" (203) 11 1/2" (292) 4 1/4" (108) 2 1/8" (54) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
012,
015 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 9 7/8" (251) 11 1/2" (292) 4 1/4" (108) 2 5/8" (67) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
018 46"
(1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 9 3/4" (248) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
024,
030 46" (1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 11 3/8" (289) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
036,
042 50" (1270) 25" (635) 19" (483) 25" (635) 20" (508) 10 1/2" (267) 13 1/2" (343) 16 3/8" (416) 4" (102) 1 3/4" (45) 3/4" (19) 3/4" (19) 48 3/4" (1238) 23 3/4" (603) 17 5/8" (448) 23 1/2" (597) 3 1/4" (83)
048,
060 58" (1473) 33" (838) 21" (533) 25" (635) 28" (711) 13 7/8" (352) 13 7/8" (352) 18" (457) 6 5/8" (168) 2" (51) 1" (25.4) 1" (25.4) 56 3/4" (1441) 31 3/4" (806) 19 5/8" (498) 23 1/2" (597) 5 1/2" (140)

WSHP-SVX01E-EN 13
Dimensions
Figure 10. Left return/right supply
Table 5. Measurements
Unit
60
HZ
Unit
50
HZ A B C D E F G H J K L NPTI M NPTI N P Q R
006-
009 006 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 8" (203) 11 1/2" (292) 4 1/4" (108) 2 1/8" (54) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470)
012-
015 009- 012 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 9 7/8" (251) 11 1/2" (292) 4 1/4" (108) 2 5/8" (67) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470)
018 015 46"
(1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 9 3/4" (248) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470)
024-
030 018- 024 46" (1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 11 3/8" (289) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470)
036-
042 030- 036 50" (1270) 25" (635) 19" (483) 25" (635) 20" (508) 10 1/2" (267) 13 1/2" (343) 16 3/8" (416) 4" (102) 1 3/4" (45) 3/4" (19) 3/4" (19) 48 3/4" (1238) 23 3/4" (603) 17 5/8" (448) 23 1/2" (597)
048-
060 042- 060 58" (1473) 33" (838) 21" (533) 29 1/2" (749) 21 1/2" (546) 13 7/8" (352) 13 7/8" (352) 18" (457) 6 5/8" (168) 2" (51) 1" (25.4) 1" (25.4) 56 3/4"
(1441) 31 3/4" (806) 19 5/8" (498) 23 1/2" (597)

14 WSHP-SVX01E-EN
Dimensions
Figure 11. Right return/left supply
Table 6. Measurements
Unit A B C D E F G H J K L NPTI M NPTI N P Q R S
006,
009 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 8" (203) 11 1/2" (292) 4 1/4" (108) 2 1/8" (54) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
012,
015 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 9 7/8" (251) 11 1/2" (292) 4 1/4" (108) 2 5/8" (67) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
018 46"
(1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 9 3/4" (248) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
024,
030 46" (1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 11 3/8" (289) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
036,
042 50" (1270) 25" (635) 19" (483) 25" (635) 20" (508) 10 1/2" (267) 13 1/2" (343) 16 3/8" (416) 4" (102) 1 3/4" (45) 3/4" (19) 3/4" (19) 48 3/4" (1238) 23 3/4" (603) 17 5/8" (448) 23 1/2" (597) 3 1/4" (83)
048,
060 58" (1473) 33" (838) 21" (533) 25" (635) 28" (711) 13 7/8" (352) 13 7/8" (352) 18" (457) 6 5/8" (168) 2" (51) 1" (25.4) 1"
(25.4) 56 3/4" (1441) 31 3/4" (806) 19 5/8" (498) 23 1/2" (597) 5 1/2" (140)

WSHP-SVX01E-EN 15
Dimensions
Figure 12. Right return/back supply
Table 7. Measurements
Unit A B C D E F G H J K L NPTI M NPTI N P Q R S
006,
009 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 8" (203) 11 1/2" (292) 4 1/4" (108) 2 1/8" (54) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
012,
015 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 9 7/8" (251) 11 1/2" (292) 4 1/4" (108) 2 5/8" (67) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
018 46"
(1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 9 3/4" (248) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8"
(397) 18 1/2" (470) 4 1/4" (108)
024,
030 46" (1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 11 3/8" (289) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
036,
042 50" (1270) 25" (635) 19" (483) 25" (635) 20" (508) 10 1/2" (267) 13 1/2" (343) 16 3/8" (416) 4" (102) 1 3/4" (45) 3/4" (19) 3/4" (19) 48 3/4" (1238) 23 3/4" (603) 17 5/8" (448) 23 1/2" (597) 3 1/4" (83)
048,
060 58" (1473) 33" (838) 21" (533) 25" (635) 28" (711) 13 7/8" (352) 13 7/8" (352) 18" (457) 6 5/8" (168) 2" (51) 1" (25.4) 1"
(25.4) 56 3/4" (1441) 31 3/4" (806) 19 5/8" (498) 23 1/2" (597) 5 1/2" (140)

16 WSHP-SVX01E-EN
Dimensions
Figure 13. Right return/right supply
Table 8. Measurements
Unit A B C D E F G H J K L NPTI M NPTI N P Q R S
006,
009 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 8" (203) 11 1/2" (292) 4 1/4" (108) 2 1/8" (54) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
012,
015 40" (1016) 20" (508) 15" (381) 20" (508) 15" (381) 6 7/8" (175) 9 7/8" (251) 11 1/2" (292) 4 1/4" (108) 2 5/8" (67) 1/2" (12.7) 1/2" (12.7) 38 3/4" (984) 18 3/4" (476) 13 5/8" (346) 18 1/2" (470) 3 3/8" (86)
018 46"
(1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 9 3/4" (248) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8"
(397) 18 1/2" (470) 4 1/4" (108)
024,
030 46" (1168) 23" (584) 17" (432) 23" (584) 18" (457) 8 1/4" (210) 11 3/8" (289) 13 1/2" (343) 4 3/4" (121) 2 7/8" (73) 3/4" (19) 3/4" (19) 44 3/4" (1137) 21 3/4" (552) 15 5/8" (397) 18 1/2" (470) 4 1/4" (108)
036,
042 50" (1270) 25" (635) 19" (483) 25" (635) 20" (508) 10 1/2" (267) 13 1/2" (343) 16 3/8" (416) 4" (102) 1 3/4" (45) 3/4" (19) 3/4" (19) 48 3/4" (1238) 23 3/4" (603) 17 5/8" (448) 23 1/2" (597) 3 1/4" (83)
048,
060 58" (1473) 33" (838) 21" (533) 25" (635) 28" (711) 13 7/8" (352) 13 7/8" (352) 18" (457) 6 5/8" (168) 2" (51) 1" (25.4) 1"
(25.4) 56 3/4" (1441) 31 3/4" (806) 19 5/8" (498) 23 1/2" (597) 5 1/2" (140)

WSHP-SVX01E-EN 17
Dimensions
Figure 14. Left return/top supply
Table 9. Measurements
Unit
GEV A B C D E F G H J K L M N W.I. NPTI W.O. NPTI Drain FPT
006-
015 19 1/2" (495) 31 1/4" (794) 21 1/2" (546) 11 1/2" (292) 4" (102) 3 3/4" (95) 16 1/2" (419) 15" (381) 18" (457) 6 7/8" (175) 8" (203) 3/4" (19) 2" (51) 1/2" (12.7) 1/2" (12.7
)
3/4"
(19)
018,
024, 21 1/2"
(546) 39 1/4" (997) 21 1/2" (546) 13 1/2" (343) 4" (102) 4" (1021) 17 1/2" (445) 23 3/4" (603) 17" (432) 8 1/4" (368)
9 3/4"
(248) 3/4"
(19) 2" (51) 3/4" (19) 3/4" (19) 3/4" (19)
030,
040 11 3/8" (289)
036,
042 24 1/2" (622) 41 7/8" (1064) 26 1/2" (673) 18" (457) 3 1/4" (83) 1 7/8" (48) 19 1/2" (495) 19" (483) 23" (584) 10 1/2" (267) 13 1/2"
(343) 1 3/4" (19) 03/4" (19) 3/4" (19) 3/4" (19)
Std-
048 26 1/2" (673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 7/8" (352) 13 7/8" (352) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4
)
3/4"
(19)
Hi-
048,
060
26 1/2"
(673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 1/8" (333) 11 3/8" (289) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4
)
3/4"
(19)

18 WSHP-SVX01E-EN
Dimensions
Figure 15. Left return/back supply
Table 10. Measurements
Unit
GEV A B C D E F G H J K L M N W.I. NPTI W.O. NPTI Drain FPT
006-
015 19 1/2" (495) 31 1/4" (794) 21 1/2" (546) 11 1/2" (292) 4" (102) 3 3/4" (95) 16 1/2" (419) 15" (381) 18" (457) 6 7/8" (175) 8" (203) 3/4" (19) 2" (51) 1/2" (12.7) 1/2" (12.7
)
3/4"
(19)
018,
024,
030,
040
21 1/2"
(546) 39 1/4" (997) 21 1/2" (546) 13 1/2" (343) 4" (102) 4" (1021) 17 1/2" (445) 23 3/4" (603) 17" (432) 8 1/4" (368)
9 3/4"
(248) 3/4"
(19) 2" (51) 3/4" (19) 3/4" (19) 3/4" (19)
11 3/8"
(289)
036,
042 24 1/2" (622) 41 7/8" (1064) 26 1/2" (673) 18" (457) 3 1/4" (83) 1 7/8" (48) 19 1/2" (495) 19" (483) 23" (584) 10 1/2" (267) 13 1/2"
(343) 1 3/4" (19) 03/4" (19) 3/4" (19) 3/4" (19)
Std-
048 26 1/2" (673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 7/8" (352) 13 7/8" (352) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4
)
3/4"
(19)
Hi-
048,
060
26 1/2"
(673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 1/8" (333) 11 3/8" (289) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4
)
3/4"
(19)

WSHP-SVX01E-EN 19
Dimensions
Figure 16. Right return/top supply
Table 11. Measurements
Unit
GEV A B C D E F G H J K L M N W.I. NPTI W.O. NPTI Drain FPT
006-
015 19 1/2" (495) 31 1/4" (794) 21 1/2" (546) 11 1/2" (292) 4" (102) 3 3/4" (95) 16 1/2" (419) 15" (381) 18" (457) 6 7/8" (175) 8" (203) 3/4" (19) 2" (51) 1/2" (12.7) 1/2" (12.7) 3/4" (19)
018,
024,
030,
040
21 1/2"
(546) 39 1/4" (997) 21 1/2" (546) 13 1/2" (343) 4" (102) 4" (1021) 17 1/2" (445) 23 3/4" (603) 17" (432) 8 1/4" (368)
9 3/4"
(248) 3/4"
(19) 2" (51) 3/4" (19) 3/4" (19) 3/4" (19)
11 3/8"
(289)
036,
042 24 1/2" (622) 41 7/8" (1064) 26 1/2" (673) 18" (457) 3 1/4" (83) 1 7/8" (48) 19 1/2" (495) 19" (483) 23" (584) 10 1/2" (267) 13 1/2"
(343) 1 3/4" (19) 03/4" (19) 3/4" (19) 3/4" (19)
Std-
048 26 1/2" (673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 7/8" (352) 13 7/8" (352) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4) 3/4" (19)
Hi-
048,
060
26 1/2"
(673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 1/8" (333) 11 3/8" (289) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4) 3/4" (19)

20 WSHP-SVX01E-EN
Dimensions
Figure 17. Right return/back supply
Table 12. Measurements
Unit
GEV A B C D E F G H J K L M N W.I. NPTI W.O. NPTI Drain FPT
006-
015 19 1/2" (495) 31 1/4" (794) 21 1/2" (546) 11 1/2" (292) 4" (102) 3 3/4" (95) 16 1/2" (419) 15" (381) 18" (457) 6 7/8" (175) 8" (203) 3/4" (19) 2" (51) 1/2" (12.7) 1/2" (12.7) 3/4" (19)
018,
024,
030,
040
21 1/2"
(546) 39 1/4" (997) 21 1/2" (546) 13 1/2" (343) 4" (102) 4" (1021) 17 1/2" (445) 23 3/4" (603) 17" (432) 8 1/4" (368)
9 3/4"
(248) 3/4"
(19) 2" (51) 3/4" (19) 3/4" (19) 3/4" (19)
11 3/8"
(289)
036,
042 24 1/2" (622) 41 7/8" (1064) 26 1/2" (673) 18" (457) 3 1/4" (83) 1 7/8" (48) 19 1/2" (495) 19" (483) 23" (584) 10 1/2" (267) 13 1/2"
(343) 1 3/4" (19) 03/4" (19) 3/4" (19) 3/4" (19)
Std-
048 26 1/2" (673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 7/8" (352) 13 7/8" (352) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4) 3/4" (19)
Hi-
048,
060
26 1/2"
(673) 46 7/8" (1191) 30 1/2" (775) 18" (457) 4 1/4" (108) 2" (51) 21 1/2" (546) 29" (737) 27" (686) 13 1/8" (333) 11 3/8" (289) 2 1/4" (57) 3 1/2" (89) 1" (25.4) 1" (25.4) 3/4" (19)
