TRANSCOOL T5 User manual

TRANSCOOL T5
INSTRUCTIONS
12 Volt DC Evaporative Cooler
Please read instructions carefully before
using this product

CAUTION
Please read before using this product
- ALWAYS USE IN A WELL VENTILATED AREA
- ALWAYS OPERATE IN UPRIGHT POSITION
- USE CAUTION IF MOVING AFTER FILLING WATER TANK- WATER CAN SPLASH OUT EASILY
- UNPLUG POWER SUPPLY WHEN MOVING OR FILLING
- DO NOT OVER FILL
- DO NOT DROP UNIT
- DO NOT USE “COOL” MODE WITHOUT - DO NOT USE “COOL” MODE WITHOUT WATER PUMP, DAMAGE WILL RESULT
The unit will make a high pitch whining noise if unit has no water when “COOL” mode is selected
- ENSURE WATER LEVEL IS NEVER BELOW 1/3 FULL WHEN USING IN “COOL” MODE
- ADD UP TO 5ml OF EUCALYTUS or TEA TREE OIL TO A FULL TANK OF WATER
AS A NATURAL ANTI BACTERIAL. THIS WILL ALSO PRODUCE A PLEASANT SMELL
- ALWAYS EMPTY WATER AFTER USE
Before storage always empty water tank and operate fan, (NOT in COOL mode)
For 30 minutes to dry filter and reduce risk of mould or mildew For 30 minutes to dry filter and reduce risk of mould or mildew
- DO NOT OBSTRUCT AIR INTAKE
- UNPLUG POWER WHEN NOT IN USE
- AVOID EXPOSURE TO RAIN OR EXTERNAL WATER or MOISTURE
- DO NOT PLACE FINGERS, HAIR OR FOREIGN OBJECTS INTO LOUVERS DURING OPERATION
- DO NOT OPERATE UNIT WITH DAMAGED POWER CORD OR PLUG
- CHILDREN MUST BE SUPERVISED AT ALL TIMES WHEN THIS UNIT IS IN OPERATION

CONTROL PANEL
1
1A
2
3
4
5
6
2A
2B
2C
3A
4A
4B
4C
5A
6A

1. FILL WATER TANK WITH WATER - MAXIMUM 6L
2. PLUG 12 VOLT POWER LEAD INTO REAR POWER INLET
SOCKET AT REAR OF UNIT
(b)
(a)
3. (a) PLUG CIGARETTE SOCKET INTO 12 VOLT POWER SOURCE, or
(b) PLUG CIGARETTE SOCKET INTO 240VAC to 12VDC POWER
SUPPLY THEN INTO 240V POWER POINT.
4. SWITCH UNIT ON AS PER CONTROL PANEL INSTRUCTIONS

Donegan Assistance Group warrants one year from date of purchase any Transcool T5 that does not perform correctly due to defects
caused by faulty workmanship or materials. Our obligation assumed under this warranty is to the repair or replacement of
parts, without charge, which are defective and have not been misused, carelessly handled or defaced by repairs made or
attampted by others. Consequential damages due to this product are not covered.
Donegan Assistance Group Pty Ltd PO Box 173, Kyneton, Victoria 3444
www.transcool.info
